Lead–bismuth eutectic alloy (LBE, Pb_44.5Bi_55.5) has emerged as a promising candidate for use in advanced nuclear and solar energy systems due to its favorable thermophysical characteristics and radiation shielding capabilities. The aim of this research is to assess the applicability of the induction melting technique to synthesize LBE. This paper presents a comprehensive evaluation of the structural, thermophysical, and radiation shielding properties of the obtained LBE sample. Various techniques were employed to investigate the solid-to-liquid eutectic transformation, phase composition, morphology, and homogeneity of the obtained material. Experimental and theoretical determinations on density, void, molar volume, thermal conductivity, heat capacity, thermal diffusivity, and electrical conductivity were performed. Radiation shielding performance over photon energies ranging from 0.015 to 15 MeV was simulated using the Phy-X/PSD program. The results revealed the eutectic structure comprising Pb₇Bi₃ and Bi phases with near-ideal stoichiometry and a melting point of 127.6 °C. The alloy demonstrated a small void that corresponds to a high degree of sample compaction, high specific heat capacity, moderate thermal conductivity, low thermal diffusivity, and effective radiation shielding. These findings confirm that LBE obtained by the induction melting technique possesses the necessary structural stability and functional properties for integration into nuclear reactor and solar thermal technologies. Full article

Lead-bismuth eutectic (LBE) is a eutectic alloy of lead (44.5 at%) and bismuth (55.5 at%) that can be used as the coolant for the fast nuclear reactors. In the event of specific conditions or even accidents of the reactors, the temperature of liquid LBE decreases, and it may undergo solidification and volume expansion during the aging process after solidification, which can easily cause damage to the reactor’s internal structure as well as the reactor vessels. In this study, the microstructure and mechanical properties of solidified LBE obtained at different cooling rates are systematically investigated after different aging times. It was found that the internal structure of LBE after aging remained a eutectic microstructure, consisting of the γ-phase (Bi-rich phase) and β-phase (Pb₇Bi₃). After a long period of static aging, the white γ-phase precipitated into the black β-phase, which further confirms the phase transition mechanism. Meanwhile, the acceleration of the cooling rate can aggravate volume expansion. As the aging time increases, there is no significant difference in the compressive yield strength σ of the LBE samples with the same cooling rate and only a certain degree of fluctuation. The elastic modulus E also shows similar results, indicating that aging time has a minor effect on the compressive yield strength σ and elastic modulus E of the LBE. With the increase in cooling rate, the compressive yield strength σ shows an upward trend, while the elastic modulus E is not significantly affected, with a small amplitude of fluctuation. Meanwhile, the hardness of LBE samples after long-term aging treatment is enhanced. After long-term aging, the overall density of the LBE samples shows a decreasing trend, the density fluctuation range of the fast cooling rates (5 K/min and 10 K/min) are significantly larger than that of the slow cooling rates. The decrease in density leads to volume expansion of the LBE during the aging process after solidification. Full article

With the advancement of lead–bismuth fast reactors, there has been increasing attention directed towards the design of and manufacturing technology for electromagnetic pumps employed to drive liquid lead–bismuth eutectic (LBE). These electromagnetic pumps are characterized by a simple structure, effective sealing, and ease of flow control. They exploit the excellent electrical conductivity of liquid metals, allowing the liquid metal to be propelled by Lorentz forces generated by the traveling magnetic field within the pump. To better understand the performance characteristics of electromagnetic pumps and master the techniques for integrated manufacturing and performance optimization, this study conducted fundamental research, development of key components, and the assembly of the complete pump. Consequently, an annular linear induction pump (ALIP) suitable for liquid lead–bismuth eutectic was developed. Additionally, within the lead–bismuth thermal experimental loop, startup and preheating experiments, performance tests, and flow-head experiments were conducted on this electromagnetic pump. The experimental results demonstrated that the output flow of the electromagnetic pump increased linearly with the input current. When the input current reached 99 A, the loop achieved a maximum flow rate of 8 m³/h. The efficiency of the electromagnetic pump also increased with the input current, with a maximum efficiency of 5.96% during the experiments. Finally, by analyzing the relationship between the flow rate and the pressure difference of the electromagnetic pump, a flow-head model specifically applicable to lead–bismuth electromagnetic pumps was established. Full article

A CaO-MgO-Al₂O₃-SiO₂ glass–ceramic coating was prepared by the slurry method and subsequent sintering to improve the corrosion resistance of 316L steel in liquid lead–bismuth eutectic alloy at high temperatures. The glass–ceramic coating, sintered at 884 °C, was dense and demonstrated strong adhesion to the substrate. It was composed of the crystalline phases diopside (CaMgSi₂O₆) and anorthite (CaAl₂Si₂O₈) and had an average Vickers hardness of 595 HV, which was over three times that of 316L steel. After corrosion in an oxygen-saturated, static lead–bismuth eutectic alloy at 500 °C for 1000 h, the uncoated 316L experienced significant mass gain (0.04 g) due to severe oxidative corrosion, resulting in the formation of Fe₃O₄ and Pb₂O on its surface. In contrast, the glass–ceramic-coated specimens showed a very small mass gain (0.0012 g) after corrosion. The coating maintained good thermal stability; its crystalline phase composition remained largely unchanged after the corrosion test. The glass–ceramic coating still exhibited dense microstructure and tightly adhered to the substrate after corrosion. There was no evident penetration of lead–bismuth into the coating, and no dissolution of the coating’s elements into the lead–bismuth alloy was detected. These observations confirm that the glass–ceramic coating possessed superior corrosion resistance in liquid lead–bismuth eutectic environments. Full article

The hydrodynamic and thermal interaction of water with the high-temperature melt of a heavy metal was studied via the Volume-of-Fluid (VOF) method formulated for three immiscible phases (liquid melt, water, and water vapor), with account for phase changes. The VOF method relies on a first-principle description of phase interactions, including drag, heat transfer, and water evaporation, in contrast to multifluid models relying on empirical correlations. The verification of the VOF model implemented in OpenFOAM software was performed by solving one- and two-dimensional reference problems. Water jet penetration into a melt pool was first calculated in two-dimensional problem formulation, and the results were compared with analytical models and empirical correlations available, with emphasis on the effects of jet velocity and diameter. Three-dimensional simulations were performed in geometry, corresponding to known experiments performed in a narrow planar vessel with a semi-circular bottom. The VOF results obtained for water jet impact on molten heavy metal (lead–bismuth eutectic alloy at the temperature 820 K) are here presented for a water temperature of 298 K, jet diameter 6 mm, and jet velocity 6.2 m/s. Development of a cavity filled with a three-phase melt–water–vapor mixture is revealed, including its propagation down to the vessel bottom, with lateral displacement of melt, and subsequent detachment from the bottom due to gravitational settling of melt. The best agreement of predicted cavity depth, velocity, and aspect ratio with experiments (within 10%) was achieved at the stage of downward cavity propagation; at the later stages, the differences increased to about 30%. Adequacy of the numerical mesh containing about 5.6 million cells was demonstrated by comparing the penetration dynamics obtained on a sequence of meshes with the cell size ranging from 180 to 350 µm. Full article

Liquid lead–bismuth eutectic alloy is one of the candidate coolants for fourth-generation nuclear power systems because of its good physical and chemical properties, neutron economic performance, and safety. However, the compatibility between the coolant and structural steel is still the main factor restricting its large-scale industrial application in the nuclear energy field. Structural steel in a liquid lead–bismuth eutectic alloy for a long time would cause severe corrosion. The erosion of structural steel by high-flow-rate liquid lead–bismuth alloy will lead to a more complex corrosion process. This paper mainly reviews the corrosion characteristics of liquid lead–bismuth and the corrosion behavior of structural steel in liquid lead-bismuth eutectic. The main methods of inhibiting liquid lead–bismuth corrosion are summarized, and future research directions are suggested. Full article

The amorphous AlTiCrFeMoSi high entropy alloy (HEA) coating with high hardness (11.88 GPa) is successfully deposited on T91 substrate by the magnetron sputtering method. Both T91 steel and as−deposited AlTiCrFeMoSi coating samples are exposed to a static liquid lead−bismuth eutectic (LBE) at 550 °C for up to 2000 h. The coating exhibits excellent corrosion resistance against lead−bismuth eutectic (LBE) compared with the uncoated T91 steel. The results show that the AlTiCrFeMoSi HEA coating has great potential in LBE−cooled fast reactor application. Full article

Heavy liquid metals (HLM) are attractive coolants for nuclear fission and fusion applications due to their excellent thermal properties. In these reactors, a high coolant flow rate must be processed in compact heat exchangers, and as such, it may be convenient to have the HLM flowing on the shell side of a helical coil steam generator. Technical knowledge about HLM turbulent heat transfer in cross-flow tube bundles is rather limited, and this paper aims to investigate the suitability of Reynolds Average Navier–Stokes (RANS) models for the simulation of this problem. Staggered and in-line finite tube bundles are considered for compact ($a=1.25$), medium ($a=1.45$), and wide ($a=1.65$) pitch ratios. The lead bismuth eutectic alloy with $\mathrm{Pr}=2.21\times {10}^{-2}$ is considered as the working fluid. A 2D computational domain is used relying on the $k-\omega$ Shear Stress Transport (SST) for the turbulent momentum flux and the ${\mathrm{Pr}}_t$ concept for the turbulent heat flux prediction. The effect of uniform and spatially varying ${\mathrm{Pr}}_t$ assumptions has been investigated. For the in-line bundle, unsteady $k-\omega$ SST/${\mathrm{Pr}}_t=0.85$ has been found to significantly underpredict the integral heat transfer with regard to theory, featuring a good to acceptable agreement for wide bundles and $\mathrm{Pe}\ge 1150$. For the staggered tube bank, steady $k-\omega$ SST and a spatially varying ${\mathrm{Pr}}_t$ has been the best modeling strategy featuring a good to excellent agreement for medium and wide bundles. A poor agreement for compact bundles has been observed for all the models considered. Full article

Lead–Bismuth Eutectic (LBE) is a heavy metal liquid alloy used as a coolant for compact high temperature reactors (CHTRs), fast breeder reactor (FBRs) and as a spallation target for ADS. In spite of many advantages due to its thermophysical properties, corrosion towards structural materials remains one of the major issues of LBE. In absence of any oxygen impurity, corrosion in LBE is driven by dissolution processes and the solubility of the main elements of the structural material alloys. Using the CALPHAD method, Thermo-Calc software, a thermodynamic database was developed to assess the interaction between Ni and LBE coolant. The solubilities of Ni in LBE, Bi and Pb liquids have been calculated at different temperatures. Full article

The objective of this paper is to enhance the corrosion resistance of coolant pipes in high temperature and lateral hydrostatic pressure in critical engineering environment, especially for circular coolant pipes under hydrostatic pressure of LBE (lead-bismuth eutectic) applications in nuclear power plants. The resistance against corrosion caused by LBE liquid is mainly formed by Fe-12Cr-2Si solid solutions coatings on the pipe. The silicon concentration in Fe-12Cr-2Si can interact with LBE as an effective oxidized compound such as SiO₂ and Fe₂SiO₄ when the silicon concentration is higher than 1.25 wt.%. The oxide film formed on the coating can resist the LBE corroding in the Fe-12Cr-2Si structure. The primary material of a constructing coolant pipe is T91 ferritic-martensitic alloys, and the surface anti-corrosion coating is Fe-12Cr-2Si solid solution. With a high strength structure, FGC (functionally graded composite material), ensures that the pipe resists the corrosion from LBE liquid. In this study, both the steady-state stress values and silicon concentration are evaluated at 700, 1000, and 1200 °C to know the fatigue problems. The research result indicates the FGM (functionally graded material) structure performs better in promoting the margin of safety on stress distribution and reserving the silicon concentration on the inner surface higher than 1.25 wt.% over 60 years as compared to the FGC structure with 34 μm thickness of Fe-12Cr-2Si coating in a high temperature environment. Full article

In neutron transmission spectroscopic imaging, the transmission spectrum of each pixel on a two-dimensional detector is analyzed and the real-space distribution of microscopic information in an object is visualized with a wide field of view by mapping the obtained parameters. In the analysis of the transmission spectrum, since the spectrum can be classified with certain characteristics, it is possible for machine learning methods to be applied. In this study, we selected the subject of solid–liquid phase fraction imaging as the simplest application of the machine learning method. Firstly, liquid and solid transmission spectra have characteristic shapes, so spectrum classification according to their fraction can be carried out. Unsupervised and supervised machine learning analysis methods were tested and evaluated with simulated datasets of solid–liquid spectrum combinations. Then, the established methods were used to perform an analysis with actual measured spectrum datasets. As a result, the solid–liquid interface zone was specified from the solid–liquid phase fraction imaging using machine learning analysis. Full article

Partially stabilized zirconia (PSZ) is considered for use as an oxygen-sensor material in liquid lead-bismuth eutectic (LBE) alloys in the radiation environment of an acceleration-driven system (ADS). To predict its lifetime for operating in an ADS, the effects of radiation on the PSZ were clarified in this study. A tetragonal PSZ was irradiated with 100 keV electrons and analyzed by X-ray diffraction (XRD). The results indicate that the phase transition in the PSZ, from the tetragonal to the monoclinic phase, was caused after the irradiation. The deposition energy of the lattice and the deposition energy for the displacement damage of a 100 keV electron in the PSZ are estimated using the particle and heavy ion transport code system and the non-ionizing energy loss, respectively. The results suggest that conventional radiation effects, such as stopping power, are not the main mechanism behind the phase transition. The phase transition is known to be caused by the low-temperature degradation of the PSZ and is attributed to the shift of oxygen ions to oxygen sites. When the electron beam is incident to the material, the kinetic energy deposition and excitation-related processes are caused, and it is suggested to be a factor of the phase transition. Full article

Liquid metal fast reactors were considered to be the most promising solution to meet the enormous energy demand in the future. However, corrosion phenomenon caused by the liquid metal, especially in high-temperature lead-bismuth coolant, has greatly hindered the commercialization of the advanced Generation-IV nuclear system. This review discussed current research on the corrosion resistance of structural materials (such as EP823, T91, ODS, and authentic steels) in high-temperature liquid metal served as reactor coolants. The current corrosion resistance evaluation has proved that even for the excellent performance of EP823, the structural material selected in pressurized water reactor is not the ideal material for operation in the high-temperature lead-bismuth eutectic (LBE). Furthermore, the latest coating technologies that are expected to be applied to cladding materials for coolant system were extensively discussed, including Al-containing coatings, ceramic coatings, oxide coatings, amorphous coatings and high-entropy alloy coatings. The detailed comparison summarized the corrosion morphology and corrosion products of various coatings in LBE. This review not only provided a systematic understanding of the corrosion phenomena, but also demonstrated that coating technology is an effective method to solve the corrosion issues of the advanced next-generation reactors. Full article

Element clustering and structural features of liquid lead-bismuth eutectic (LBE) alloy have been investigated up to 720 °C by means of high temperature X-ray diffraction (HT-XRD), X-ray Photoemission Spectroscopy (XPS) and Scanning Photoemission Microscopy (SPEM) at the Elettra synchrotron in Trieste. The short-range order in liquid metal after melting corresponds to the cuboctahedral atomic arrangement and progressively evolves towards the icosahedral one as temperature increases. Such process, that involve a negative expansion of the alloy, is mainly connected to the reduction of atom distance in Pb–Pb pairs which takes place from 350 °C to 520 °C. On an atomic scale, it is observed a change of the relative number of Bi–Bi, Pb–Pb, and Pb–Bi pairs. The Pb–Bi pairs are detected only at a temperature above ~350 °C, and its fraction progressively increases, giving rise to a more homogeneous distribution of the elements. SPEM results showed evidence that the process of chemical homogenization on an atomic scale is preceded and accompanied by homogenization on micro-scale. Clusters rich of Bi and Pb, which are observed after melting, progressively dissolve as temperature increases: Only a few residuals remain at 350 °C, and no more clusters are detected a 520 °C. Full article

An Al₂O₃–TiO₂ amorphous composite coating with a thickness of 100–120 μm was fabricated on China low activation martensitic steel (CLAM steel) by oxygen acetylene flame spraying technology and the laser in-situ reaction method. We investigated the microstructures and mechanical properties of the coating after liquid lead-bismuth eutectic (LBE) alloy corrosion under different temperatures for 300 h and found that the corrosion temperature of the LBE had no observable effect on the microstructure and chemical phase of the Al₂O₃–TiO₂ amorphous composite coatings. However, the mechanical properties (micro-hardness and shear strength) of the Al₂O₃–TiO₂ multiphase coating deteriorated slightly with the increase in the immersion temperature of the LBE. As a result of oxygen acetylene flame spraying and laser in-situ reaction technology, it was found that the Al₂O₃–TiO₂ amorphous composite coating exhibits an excellent LBE corrosion resistance, which is a candidate structural material for the accelerator-driven subcritical system (ADS) to handle nuclear waste under extreme conditions. Full article
