Search Results (15)

Magnetic levitation (maglev) technology offers significant advantages for rail transport, including frictionless propulsion, reduced noise, and lower maintenance costs. However, its widespread adoption has been limited due to the need for a dedicated infrastructure incompatible with conventional rail networks. The MaDe4Rail project, funded by Europe’s Rail Joint Undertaking (ERJU), explores Maglev-Derived Systems (MDSs) as means to integrate maglev-inspired solutions into existing railway corridors with minimal modifications. This paper focuses on the so-called “hybrid MDS” configuration, which refers to levitating systems that can operate on existing rail infrastructure. Unlike current maglev systems, which require dedicated tracks, the proposed MDS system is designed to operate on conventional rail tracks, allowing for its compatibility with traditional trains and ensuring the interoperability of lines. In order to identify the most viable solution, two different configurations have been analysed. The evaluated scenario could benefit from the introduction of hybrid MDSs based on magnetic levitation, where a group of single vehicles, also called pods, is used in a virtual coupling configuration. The objective of this case study is to increase the capacity of traffic on the existing railway line by significantly reducing travel time, while maintaining a similar energy consumption to that of the current conventional trains operating on this line. Simulation results indicate that the hybrid MDS can optimise railway operations by taking advantage of virtual coupling to improve traffic flow, reducing travel times and energy consumption with the optimisation of the aerodynamic drag. The system achieves a balance between increased speed and energy efficiency, making it a viable alternative for future rail transport. An initial cost–benefit analysis suggests that the hybrid MDS could deliver substantial economic advantages, positioning it as a promising solution for enhancing European railway networks with minimal infrastructure investment. Full article

Base excitation sources significantly impact vehicle-body vibrations in maglev systems, with the dynamic performance of the suspension system playing a crucial role in mitigating these effects. The second-series suspension system of a maglev vehicle typically employs an air spring, which has a great impact on the stability of maglev vehicle operation. Considering that the suspension system has certain dynamic characteristics under the foundation excitation, the present study proposes the fractional-order nonlinear Nishimura model to describe the memory-restoring force characteristics of the air spring. The fractional-order derivative term is made equivalent to a term in the form of trigonometric function, the steady-state response of the system is solved by the harmonic balance method, and the results are compared with a variety of other methods. The influence of the foundation excitation source on the dynamic behavior of the vibration isolation system is discussed significantly. The variation law of the jump phenomenon and the diversity of periodic motion of the multi-value amplitude curve are summarized. The numerical simulation also revealed the presence of multi-periodic motion in the system when variations occurred in the gap of the suspension system. Combined with the cell mapping algorithm, the distribution law of different attractors on the attraction domain of periodic motion is discussed, and the rule of the transition of periodic motion stability with different fundamental excitation amplitudes is summarized with the Lyapunov exponent. Full article

This paper is centered around the autonomous displacement of the maglev ruler system, with the core objective of optimizing the performance of its horizontal control system. The horizontal positioning precision of the maglev ruler’s mover core plays a crucial role in determining the survey accuracy. Moreover, its horizontal system exhibits distinct nonlinear and strongly coupled characteristics. Initially, a mathematical model is meticulously established based on the principles of magnetic circuits and dynamics. By analyzing the relationship between the Ampere force and the coil current, and constructing the dynamic equations, it is clearly demonstrated that this system belongs to a nonlinear and strongly coupled type with two inputs and two outputs. Subsequently, the active disturbance rejection control algorithm is employed to address the decoupling issue, and a novel differential tracker, SYSTD, is designed. SYSTD is constructed using specific elementary functions. Through rigorous theoretical derivation, its favorable stability is verified. The basis for parameter selection is obtained through phase-plane analysis, and a detailed tuning method is provided. Additionally, a sensor-less control technology is proposed, where survey coils are wound along the horizontal control coils to estimate the position of the mover core. The simulation and experimental results indicate that the improved system showcases excellent performance. In the simulation, the positioning accuracy can reach ±5 μm, while, in the experiment, the control accuracy can achieve ±2 μm. It can effectively realize decoupling control and possesses good dynamic, static characteristics, as well as remarkable robustness. This research paves the way for the practical application of the maglev ruler system in fields such as coordinate survey. Full article

The working accuracy of space optical payloads, sensitive components, greatly depends on the pointing accuracy and stability of the platform. This article establishes a mathematical model for relative position and attitude measurement based on PSD and eddy current and analyzes the failure modes under the measurement models. Through model derivation, it can be concluded that the position and attitude measurement system has high redundancy; in the event of sensor failure in the horizontal or vertical direction, relative position and attitude measurement and resolution can still be completed, which solves the relative measurement problem of position and attitude measurement of the space Maglev vibration isolation control system, providing high-precision closed-loop control for the control system to achieve high-precision pointing and stability. In response to the requirements of high-precision non-contact displacement and attitude measurement, eddy current sensors were selected, and a sensor circuit box was designed. The testing and calibration system adopts an eight-bar Maglev layout, and the actuator has unidirectional dual-mode output. The actuator adopts a double closed magnetic circuit structure, and the coil adopts a winding single-coil structure. The system includes a multi-degree-of-freedom high-precision coil spatial pose automatic positioning platform, a strong magnetic structure, strong uniform magnetic field magnetization, an integrated assembly testing platform, etc. According to the test data, the driver has strong linearity in both low- and high-current ranges. The relative output error in the low-current range does not exceed 0.1 mA, and the relative output error in the high-current range does not exceed 2 mA. After fitting and calibration, it can meet the design requirements. Within redundant designing, fault mode analyzing, and system testing, the relative measurement system can ensure the working accuracy of the optical payload of the spacecraft, which reaches the advanced level in the field. Full article

Magnetic levitation (maglev) offers unique opportunities for guided transport; however, only a few existing maglev systems have demonstrated their potential benefits. This paper explores the potential of maglev-derived systems (MDS) in conventional rail, focusing on the use of linear motors to enhance freight operations. Such traction boosters provide additional propulsion capabilities by reducing the train consist’s dependence on wheel–rail adhesion and improving performance without needing an additional locomotive. The study analyses the Gothenburg–Borås railway in Sweden, a single-track, mixed-traffic line with limited capacity and slow speeds, where installing linear motors on uphill sections would allow freight trains to match the performance of passenger trains, even under challenging adhesion conditions. Target speed profiles were precomputed using dynamic programming, while a model predictive control algorithm determined the optimal train state and control trajectories. The results show that freight trains can achieve desired speeds but at the cost of increased energy consumption. A system-level cost–benefit analysis reveals a positive impact with a positive benefit-to-cost ratio. Although energy consumption increases, the time savings and reduced CO₂ emissions from shifting goods from road to rail demonstrate substantial economic and environmental benefits, improving the efficiency and sustainability of rail freight traffic. Full article

Maglev vehicles apply the entire vehicle load uniformly onto bridges through levitation forces. In assessing the dynamic characteristics of the maglev train–bridge coupling system, it is reasonable to simplify the distributed levitation force as a concentrated force. This article theoretically derives the analytical response of bridge dynamics under the action of a single constant force and conducts numerical simulations for a moving single constant force and a series of equally spaced constant forces passing over simply supported beams and two-span continuous beams, respectively. The topic of discussion is the response of bridge dynamics when different degrees of force concentration are involved. High-precision displacement and acceleration sensors were utilized to conduct tests on the Shanghai maglev line to verify the accuracy of the simulation results. The results indicate that when simplifying the distributed levitation force into a concentrated force model, a frequency ratio can be used to analyze the conditions for resonance between the train and the bridge and to calculate the critical speed of the train; the levitation distribution force of a high-speed maglev vehicle can be simplified into four groups of concentrated forces based on the number of levitation frames to achieve sufficient accuracy, with the dynamic response of the bridge being close to that under distributed loads. Full article

Road vehicles and maglev trains have garnered significant attention, with their suspension systems being crucial for safe and stable performance. However, these systems can be compromised by faults such as sensor and actuator failures, posing risks to stability and safety. This review explores fault-tolerant controls for suspension systems, driven by the need to enhance fault tolerance in such scenarios. We examine the dynamic similarities between the semi-active/active suspension systems in road vehicles and the suspension systems in maglev trains, offering a comprehensive summary of fault-tolerant control strategies for both. Our analysis covers the histories, technical characteristics, fundamentals, modeling, mathematical derivations, and control objectives of both systems. The review categorizes fault-tolerant control methods into hardware redundancy, passive fault-tolerant control, and active fault-tolerant control. We evaluate the advantages and disadvantages of these strategies and propose future directions for the development of fault-tolerant control in suspension systems. Full article

As new advanced vehicles, electromagnetic suspension (EMS)-type maglev trains have received wide attention because of their advantages such as high speed, no mechanical friction, low noise, low cost and energy consumption, strong climbing ability, and green environmental protection. The open-loop instability is one of the key points and difficulties for the levitation control systems of maglev trains. The closed-loop feedback control method must be applied to realize stable levitation. However, there are currently many levitation control methods just in theory. Considering their advantages and disadvantages, it is a major demand for maglev trains to select efficient, stable, applicable, and cost-saving methods to improve their dynamic performance and safety, which motivated this review. First, the current status of research on maglev trains is introduced in this paper, including types, system components, and research modes in various countries, followed by an analysis of the levitation control methods for EMS-type maglev trains. Then, the technical characteristics of the levitation control systems are described according to the basic principles of levitation systems, model building, mathematical derivation, and control objectives. Next, three kinds of typical levitation control methods are reviewed, namely, linear state feedback methods, nonlinear control methods, and intelligent control methods, according to their improvements and applications. Lastly, we summarize and evaluate the advantages and disadvantages of the three methods, and future developments of levitation control are suggested. Full article

The suspension system of the maglev train is a complex system, which is difficult to model accurately. The horizontal misalignment between the suspension magnet and the rail is one of the common uncertainty factors in the suspension system, which will affect the suspension performance. This article focuses on this problem. Firstly, the formula of suspension force considering horizontal misalignment is derived and the results of the formula and the FEA (Finite Element Analysis) simulation is consistent. Secondly, a suspension system model considering the horizontal misalignment is established for the first time, which can effectively describe the impact of the horizontal misalignment on the suspension system. Thirdly, a controller for the suspension system is designed by using the GIMC (Generalized Internal Model Control) paradigm and how the controller can effectively suppress the uncertainty caused by the horizontal misalignment is proved theoretically for the first time. Finally, the simulation and physical experiment verify that the proposed algorithm shows excellent performance and robustness in the system. Full article

The suspension electromagnet (SEM) is one of the most critical components of the low-speed maglev train to achieve the stable suspension and non-contact operation with the track. Therefore, it is valuable for optimizing the maglev system to study the characteristics of the SEM. This paper proposes a novel analytic method to calculate the equivalent stray capacitance of the SEM efficiently. It considers the capacitances inside the winding (turn to turn and layer to layer) and between the winding and core. Firstly, utilizing the compensation analytic method (CAM) calculates the static capacitances to reduce the calculation error, and the results of the CAM have significant improvement comparing with that of the traditional analytic method (TAM). Secondly, the analytical formula of the core floating potential is derived based on the partial capacitance theory, which has a 2.1% relative error to the finite element method (FEM). Finally, the experiment results of the SEM of a test rig prove the accuracy and efficiency of the proposed method. Full article

The environment in space provides favorable conditions for space missions. However, low frequency vibration poses a great challenge to high sensitivity equipment, resulting in performance degradation of sensitive systems. Due to the ever-increasing requirements to protect sensitive payloads, there is a pressing need for micro-vibration suppression. This paper deals with the modeling and control of a maglev vibration isolation system. A high-precision nonlinear dynamic model with six degrees of freedom was derived, which contains the mathematical model of Lorentz actuators and umbilical cables. Regarding the system performance, a double closed-loop control strategy was proposed, and a sliding mode control algorithm was adopted to improve the vibration isolation performance. A simulation program of the system was developed in a MATLAB environment. A vibration isolation performance in the frequency range of 0.01–100 Hz and a tracking performance below 0.01 Hz were obtained. In order to verify the nonlinear dynamic model and the isolation performance, a principle prototype of the maglev isolation system equipped with accelerometers and position sensors was developed for the experiments. By comparing the simulation results and the experiment results, the nonlinear dynamic model of the maglev vibration isolation system was verified and the control strategy of the system was proved to be highly effective. Full article

Magnetic levitation technology shows promise for realizing multiple degrees of free precision motion for modern manufacturing, as the bearing and guiding parts are not used. However, motion decoupling in a magnetically levitated (maglev) system is difficult because it is hard to derive accurate magnetic force and a torque model considering the translation and rotation in all axes. In this work, a magnetic levitation rotary table that has the potential to realize unlimited rotation around the vertical axis and a relatively long stroke in the horizontal plane is proposed and analyzed, and the corresponding real-time numerical decoupling method is presented. The numerical magnetic force and torque model solves the current to magnetic force and torque transformation matrix, and the matrix is used to allocate the exact current in each coil phase to produce the required motion in the magnetically levitated (maglev) system. Next, utilizing a high-level synthesis tool and hardware description language, the proposed motion-decoupling module is implemented on a field programmable gate array (FPGA). To realize real-time computation, a pipelined program architecture and finite-state machine with a strict timing sequence are employed for maximum data throughput. In the last decoupling module of the maglev system, the delay for each sampling point is less than $200\mathsf{\mu }$ s. To illustrate and evaluate real-time solutions, they are presented via the DAC adapter on the oscilloscope and stored in the SD card. The error ratios of the force and torque results solved by the numerical wrench model were less than $5\%$ and $10\%$ using the solutions from the boundary element method (BEM) program package Radia^TM as a benchmark. Full article

In the eddy current braking system of high-speed maglev, the peak braking force and the critical speed are key factors determining the performance of eddy current braking force. In this paper, the analytical formula of eddy current braking force is derived by a subdomain method considering the skin effect of the induction plate, and, subsequently, the characteristics of peak braking force and critical speed are analyzed. The analytical model is set up in a 2D Cartesian coordinate system. The Poisson equations in each subdomain are listed by treating the vector magnetic potential as a variable. By combining the boundary conditions between two adjacent subdomains, the expressions of eddy current density and magnetic density in the induction plate are obtained. Then, the analytical formula of the eddy current braking force is obtained by the Ampere force formula. The results of finite-element analysis confirm the validity of the analytical calculation. The methods of improving the performance of eddy current braking force under high speed are proposed by parametric analysis of peak braking force and critical speed, which provides guidance for the design of the eddy current braking system in high-speed maglev. Full article

In order to realize the high speed and high-precision control of a maglev planar motor, a high-precision electromagnetic model is needed in the first place, which can also contribute to meeting the real-time running requirements. Traditionally, the electromagnetic model is based on analytical calculations. However, this neglects the model simplification and the manufacturing errors, which may bring certain errors to the model. Aiming to handle this inaccuracy, this paper proposes a novel design method for a maglev planar motor control system based on two-dimensional linear interpolation. First, the magnetic field is divided into several regions according to the symmetry of the Halbach magnetic array, and the uniform grid method is adopted to partition one of these regions. Second, targeting this region, it is possible to sample the electromagnetic forces and torques on each node of the grid and obtain the complete electromagnetic model in this region through the two-dimensional linear interpolation method. Third, the whole electromagnetic model of the maglev planar motor can be derived according to the symmetry of the magnetic field. Finally, the decoupling method and controller are designed according to this electromagnetic model, and thereafter, the control model can be established. The designed control system is demonstrated through simulations and experiments to feature better accuracy and meet the requirements of real-time control. Full article

The traditional model of the electromagnetic force and torque does not take the coil corners into account, which is the major cause for the motor fluctuation. To reduce the fluctuation, a more accurate real-time computation model, which considers the influence of the coil corners, is proposed in this paper. Three coordinate systems respectively for the stator, the mover, and the corner are established. The first harmonic of the magnetic flux density distribution of a Halbach magnet array is taken into account in this model. The coil is divided into the straight coil segment and the corner coil segment based on its structure. For the straight coil segment, the traditional Lorenz force method can be used to compute its electromagnetic force and torque, which is a function of the mover position. For the corner coil segment, however, the numerical calculation method can be used to get its respective electromagnetic force and torque. Based on the above separate analysis, an electromagnetic model can be derived, which is suitable for practical application. Compared with the well-known harmonic model, the proposed real-time computation model is found to have less model inaccuracy. Additionally, the real-time ability of the maglev planar motor model and the decoupling computation is validated by NI PXI platform (Austin, TX, USA). Full article
