The objective of this study is to accurately, expeditiously, and efficiently identify the wear state of milling cutters. To this end, a state identification method is proposed that combines continuous wavelet transform and an improved MobileViT lightweight network. The methodology involves the transformation of the cutting force signal during the milling cutter cutting process into a time–frequency image by continuous wavelet transform. This is followed by the introduction of a Contextual Transformer module after layer 1 and the embedding of a Global Attention Mechanism module after layer 2 of the MobileViT network structure. These modifications are intended to enhance visual representation capability, reduce information loss, and improve the interaction between global features. The result is an improvement in the overall performance of the model. The improved MobileViT network model was shown to enhance accuracy, precision, recall, and F1 score by 1.58%, 1.23%, 1.92%, and 1.57%, respectively, in comparison with the original MobileViT. The experimental results demonstrate that the proposed model in this study exhibits a substantial advantage in terms of memory occupation and prediction accuracy in comparison to models such as VGG16, ResNet18, and Pool Former. This study proposes an efficient identification method for milling cutter wear state identification, which can identify the tool wear state in near real-time. The proposed method has potential applications in the field of industrial production. Full article

Complex, thin-walled components are the most important load-bearing structures in aircraft equipment. Monitoring the wear status of milling cutters is critical for enhancing the precision and efficiency of thin-walled item machining. The cutting force signals of milling cutters are non-stationary and non-linear, making it difficult to detect wear stages. In response to this issue, a system for monitoring milling cutter wear has been presented, which is based on parameterized Variational Mode Decomposition (VMD) Multiscale Permutation Entropy. Initially, an updated whale optimization technique is used, with the joint correlation coefficient serving as the fitness value for determining the VMD parameters. The improved VMD technique is then used to break down the original signal into a series of intrinsic mode functions, and the Multiscale Permutation Entropy of each effective mode is determined to generate a feature vector. Finally, a 1D Convolutional Neural Network (1D CNN) is employed as the input model for state monitoring using the feature vector. The experimental findings show that the suggested technique can efficiently extract characteristics indicating the wear condition of milling cutters, allowing for the precise monitoring of milling cutter wear states. The recognition rate is as high as 98.4375%, which is superior to those of comparable approaches. Full article

Real-time tool condition monitoring (TCM) is becoming more and more important to meet the increased requirement of reducing downtime and ensuring the machining quality of manufacturing systems. However, it is difficult to satisfy both robustness and effectiveness of pattern recognition for a TCM system without using an unsupervised strategy. In this paper, a clustering-based TCM system is proposed that can be used for different machining conditions such as variable cutting parameters, variable cutters, and even variable cutting methods. The solution is based on a significant statistical correlation between tool wear and the distribution of cutting force features, which is revealed through the clustering results obtained from a novel clustering method based on adjacent grids searching (CAGS). This statistical correlation is converted into tool wear status by using an empirical factor that is robust for variable cutting processes. The proposed TCM system is completely unsupervised as a training-free procedure is used in the monitoring process. To verify the effectiveness of the system, a series of experiments are conducted, such as whole life-cycle wear experiment under same milling condition, tool wear experiment under variable milling conditions and tool wear experiment under same turning condition. The prediction accuracy of our system for tool wear experiment under variable milling conditions is 100%, 75% and 75%, respectively. In contrast, BP neural network, Bayesian network and SVM are used for tool wear prediction under the same conditions. Experimental results show the superiority and effectiveness of our TCM system based on cluster density of CAGS over several state-of-the-art supervised methods. Full article
