Water and sand inrush is frequently accompanied by surface subsidence, which severely constrains the sustainable development of coordinated coal mining and ecological environment. This study investigated four key influencing factors based on a water and sand inrush test system: fracture width, aquifer thickness, sand particle size composition and stratigraphic sedimentary structure. It obtained the morphological evolution characteristics of collapse funnels and revealed the evolution mechanism of collapse funnels induced by water and sand inrush. The results indicate that fracture width and aquifer thickness mainly affect the range of collapse funnel, and both show a positive correlation with the radius of collapse funnels. Sandy particle size composition plays a dominant role in the morphology of collapse funnels induced by disasters: as the size of the soil skeleton particles increases, the morphology of collapse funnels changes sequentially from a bowl shape to an inverted cone shape and then to a funnel shape with a sunken center and raised slopes. The stratigraphic sedimentary structure has a significant impact on the morphology and damage induced by disasters in collapse funnels. The upper clay layer of the underlying aquifer inhibits the water and sand inrush processes to some extent. An increase in the thickness and number of clay layers effectively prevents the water and sand mixture from flowing into the fracture channel from the lateral direction. This reduces the damage range of collapse funnels and decreases the rate of water and sand inrush. This study clarifies the formation mechanism of surface collapse funnels under the influence of the disaster-causing factors of water and sand inrush, and provides theoretical guidance for the prevention and control of such disasters. Full article

Subsidence over abandoned goaves is a primary trigger for secondary geological hazards such as surface collapse, landslides, and cracking. This threatens safe mining operations, impairs regional economic progress, and endangers local inhabitants and their assets. At present, goaf areas are mainly treated through grouting. However, owing to the deficiencies of traditional deformation monitoring methods (e.g., leveling and GPS), including their slow speed, high cost, and limited data accuracy influenced by the number of monitoring points, the surface deformation features of goaf zones treated with grouting cannot be obtained in a timely fashion. Therefore, this study proposes a method to analyze the spatio-temporal patterns of surface deformation in grout-filled goaves based on the fusion of Multi-temporal InSAR technologies, leveraging the complementary advantages of D-InSAR, PS-InSAR, and SBAS-InSAR techniques. An investigation was conducted in a coal mine located in Shandong Province, China, utilizing an integrated suite of C-band satellite data. This dataset included 39 scenes from the RadarSAT-2 and 40 scenes from the Sentinel missions, acquired between September 2019 and September 2022. Key results reveal a significant reduction in surface deformation rates following grouting operations: pre-grouting deformation reached up to −98 mm/a (subsidence) and +134 mm/a (uplift), which decreased to −11.2 mm/a and +18.7 mm/a during grouting, and further stabilized to −10.0 mm/a and +16.0 mm/a post-grouting. Time-series analysis of cumulative deformation and typical coherent points confirmed that grouting effectively mitigated residual subsidence and induced localized uplift due to soil compaction and fracture expansion. The comparison with the leveling measurement data shows that the accuracy of this method meets the requirements, confirming the method’s efficacy in capturing the actual ground dynamics during grouting. It provides a scientific basis for the safe expansion of mining cities and the safe reuse of land resources. Full article

To optimize the support performance of rock bolts in high-stress environments, this study employs the ANSYS (Version 2022 R2) finite element numerical simulation method to systematically investigate the influence of bolt geometrical parameters (rib spacing, rib height, and bolt diameter) on the stress state of the anchoring system. A bolt–resin–sleeve model was established to analyze Mises equivalent stress distribution and peaks under a 150 kN pull-out load. The simulation results indicate that a rib spacing of 36 mm effectively promotes the diffusion of pre-stress into deeper regions, with peak stress in the bolt rod and resin ring increasing by 34.42% and 61.64%, respectively, compared to a spacing of 12 mm. Further increase in rib spacing provides limited enhancement in peak stress. A rib height of 1.0 mm achieves optimal system performance without excessively compromising the interfacial stress level. Increasing the diameter to 22 mm raised peak stress in the bolt, sleeve, and resin by 14.19%, 30.48%, and 50.77%, respectively, compared to 18 mm, balancing load capacity and material use efficiently. The optimal parameter set (36 mm spacing, 1.0 mm height, and 22 mm diameter) was validated in a field trial in Zhongmacun Mine’s 3903 East Transportation Bottom Drainage Roadway. Monitoring recorded maximum roof subsidence of 102.9 mm, stabilizing within 25 days (daily deformation < 0.2 mm), confirming the excellent performance of the bolt support system with this parameter combination in high-stress roadways. This study provides a theoretical basis and engineering reference for the optimal design of high-performance rock bolts. Full article

In the semi-desert aeolian sand areas of Northern China, surface deformation monitoring with SAR is challenged by loss of coherence due to mobile dunes, seasonal vegetation changes, and large-gradient, nonlinear subsidence from underground mining. This study utilizes PALSAR-2 (L-band, 3 m resolution) and Sentinel-1 (C-band, 30 m resolution) data, applying InSAR and Offset tracking methods combined with differential, Stacking, and SBAS techniques to analyze deformation monitoring effectiveness and propose an efficient dynamic monitoring strategy for the Shendong Coalfield. The main conclusions can be summarized as follows: (1) PALSAR-2 data, which has advantages in wavelength and resolution (L-band, multi-look spatial resolution of 3 m), exhibits better interference effects and deformation details compared to Sentinel-1 data (C-band, multi-look spatial resolution of 30 m). The highly sensitive differential-InSAR (D-InSAR) can promptly detect new deformations, while Stacking-InSAR can accurately delineate the range of rock strata movement. SBAS-InSAR can reflect the dynamic growth process of the deformation range as a whole, and SBAS-Offset is suitable for observing the absolute values and morphology of the surface moving basin. The combined application of Stacking-InSAR and Stacking-Offset methods can accurately acquire the three-dimensional deformation field of mining-induced strata movement. (2) The spatiotemporal process of surface deformation caused by coal mining-induced strata movement revealed by InSAR exhibits good correspondence with both the underground mining progress and the development of ground fissures identified in UAV images. (3) The maximum displacement along the line of sight (LOS) measured in the mining area is approximately 2 to 3 m, which is close to the 2.14 m observed on site and aligns with previous studies. The calculated advance influence angle of the No. 22308 working face in the study area is about 38.3°. The influence angle on the solid coal side is 49°, while that on the goaf side approaches 90°. These findings further deepen the understanding of rock movement and surface displacement parameters in this region. The dynamic monitoring strategy proposed in this study is cost-effective and operational, enhancing the observational effectiveness of InSAR technology for surface deformation due to coal mining in this area, and it enriches the understanding of surface strata movement patterns and parameters in this region. Full article

Extensive high and steep open-pit slopes in gneiss are distributed in cold regions at high altitudes or high latitudes of China, such as Qinghai, Tibet, and Xinjiang, posing significant hazards to mine safety. Several recent slope failure incidents highlight the urgent need to study the failure modes and mechanisms of gneiss open-pit slopes in these cold regions. This study focuses on the 14 September 2023 landslide at the Jinbao Mine in Xinjiang. Initially, field investigation and displacement monitoring were employed to analyze its failure characteristics and mode. Subsequently, utilizing mechanical parameters of the gneissic foliation and the rock mass obtained under various conditions, discrete element numerical modeling was conducted to study the failure mechanisms. The results indicate that the landslide was a typical bedding failure characterized by an upper bedding-controlled sliding zone, combined with buckling and crushing of the slope toe. Under the long-term combined effects of rainfall, freeze–thaw cycles and blasting, the shear strength of the gneissic foliation decreased. This reduction led to a decrease in the anti-sliding force and an increase in the sliding force within the upper bedding-controlled sliding zone. Consequently, the load transferred to the rock mass at the slope toe progressively increased. Under prolonged compression, the toe rock mass experienced bending, which intensified over time. Coupled with the strength reduction caused by the repeated action of rainfall, freeze–thaw cycles and blasting, the toe rock mass gradually fractured and ultimately failed in a buckling mode. This led to the loss of support for the upper mass, which then subsided along the foliation, precipitating the landslide’s overall instability. Full article

As one of the world’s primary energy sources, coal has driven economic development but has also led to severe surface subsidence. Currently, many regions around the world face significant ground deformation risks due to ongoing or legacy mining activities. Accurate monitoring and trend prediction are critical for enhancing subsidence early-warning capabilities and urban resilience. The northern region of Huainan City exhibits a spatial pattern characterized by the coexistence of mining areas, urban areas, and decommissioned mining sites, among which the mining areas show more pronounced surface deformation due to prolonged mining activities. To fully understand the subsidence evolution characteristics and differences across various regions, an LSTM–Transformer prediction model was constructed based on SBAS-InSAR monitoring technology to predict the surface subsidence processes in the three types of areas separately. The results indicated that the subsidence rate and cumulative subsidence in the mining areas were significantly greater than those in the urban and decommissioned areas, demonstrating more intense deformation activity. The average subsidence rates for the mining areas, urban areas, and decommissioned mining sites were −57.42 mm/yr, −5.37 mm/yr, and −3.21 mm/yr, respectively. The model’s prediction results demonstrated good accuracy across different regions, with the root mean square errors (RMSEs) for the mining areas, urban areas, and decommissioned mining sites being 2.16 mm, 1.03 mm, and 0.22 mm, respectively. The study shows that the constructed LSTM–Transformer hybrid model not only possesses strong capability in fitting subsidence trends but will also provide a scientific basis for future monitoring and early warning of surface subsidence hazards. Full article

This study investigates the influence of shallow water-bearing sand layers on surface subsidence characteristics in coal mining areas with thick loose strata, with the ultimate goal of contributing to sustainable environmental protection. Firstly, a numerical simulation test was designed to analyze and study the influence of the loose layer thickness, mining height, bedrock slope, and sand inclusion on the surface movement and deformation characteristics. Secondly, the mechanical model of seepage flow in the sand layer was established to study the influence mechanism of the internal stress distribution of the sand layer and the seepage of the water body after mining on the surface subsidence. Finally, by studying the law of surface subsidence corresponding to the mining of 3205 working face in a mine, it was found that mining caused the partial overlying soil layer to move integrally and generate a large displacement difference with the adjacent layer, which verifies the conclusions of numerical simulation and mechanical analysis. The results of the study show that the thickness of the loose layer is the main control factor that causes the surface subsidence range and the building damage to increase; the shallow water-bearing sand-bearing layer has two types of movements: displacement and flow. The critical hydraulic slope has not reached the sand. The layer has a linearly increasing horizontal displacement value in the thickness direction; when the critical hydraulic slope is reached, the sand layer cannot transmit the frictional force, causing the overlying soil layer to slide as a whole. Both forms are prone to tensile damage on the surface. The research results provide a theoretical basis and practical case for surface subsidence reduction and green mining under similar geological conditions. Full article

Monitoring large-gradient surface displacement caused by underground mining remains a significant challenge for conventional Synthetic Aperture Radar (SAR)-based techniques. This study introduces optical flow methods to monitor large-gradient displacement in mining areas and conducts a comprehensive comparison with Small Baseline Subset Interferometric SAR (SBAS-InSAR) and Pixel Offset Tracking (POT) methods. Using 12 high-resolution TerraSAR-X (TSX) SAR images over the Daliuta mining area in Yulin, China, we evaluate the performance of each method in terms of sensitivity to displacement gradients, computational efficiency, and monitoring accuracy. Results indicate that SBAS-InSAR is only capable of detecting displacement at the decimeter level in the Dalinta mining area and is unable to monitor rapid, large-gradient displacement exceeding the meter scale. While POT can detect meter-scale displacements, it suffers from low efficiency and low precision. In contrast, the proposed optical flow method (OFM) achieves sub-pixel accuracy with root mean square errors of 0.17 m (compared to 0.26 m for POT) when validated against Global Navigation Satellite System (GNSS) data while improving computational efficiency by nearly 30 times compared to POT. Furthermore, based on the optical flow results, mining parameters and three-dimensional (3D) displacement fields were successfully inverted, revealing maximum vertical subsidence exceeding 4.4 m and horizontal displacement over 1.5 m. These findings demonstrate that the OFM is a reliable and efficient tool for large-gradient displacement monitoring in mining areas, offering valuable support for hazard assessment and mining management. Full article

The Shendong mining area, a pivotal coal production base in China, faces considerable challenges due to extensive mining activities. The significant development of overlying rock fractures and the widespread occurrence of surface cracks present a major challenge to mining safety and ecological preservation in China and other mining nations. This study focuses on the Panel 12,401 fully mechanized longwall face at Shangwan Coal Mine to systematically investigate overburden movement and the evolution of surface fractures. By combining UDEC discrete element modeling with a computational framework that links subsurface strata subsidence and surface settlement, this research examines the spatial and mechanical properties of fracture propagation. Experimental results show that surface fractures continue to develop as the working face advances, with their horizontal apertures gradually decreasing and eventually closing after the face passes. Both the maximum surface subsidence and the maximum fracture aperture exhibit a strong positive correlation with mining height. In contrast, increased mining depth leads to reductions in maximum surface subsidence, the subsidence factor, and the size of surface fracture apertures. These findings provide a theoretical basis for reducing mining-induced damage and promoting ecological restoration in mining areas. Full article

Mining-induced subsidence boundaries, i.e., the surface areas affected by underground mining, play an important role in surface damage assessment and illegal mining identification. Traditional boundary delineation methods rely on field surveys, which restrict their applicability in regions with limited ground observations. Interferometric Synthetic Aperture Radar (InSAR) technology provides a cost-effective and non-contact solution for delineating subsidence boundaries. However, existing InSAR-based methods for subsidence boundary delineation are susceptible to observation noise and other deformation sources, which reduce the accuracy of boundary identification. To this end, this study proposes a novel method for delineating mining-induced subsidence boundaries by integrating both the magnitude and direction of InSAR-derived deformation gradients, referred to as DMSB-DG. First, time-series line-of-sight (LOS) deformation is obtained based on InSAR technology over mining areas. Then, the Roberts operator is employed to compute the magnitude and direction of the deformation gradients, which serve as the basis for boundary delineation. Finally, the ISODATA clustering algorithm is used, incorporating both the magnitude and direction of the deformation gradients as dual constraints to achieve accurate delineation of mining-affected boundaries. The combination of the two features effectively enhances the completeness and accuracy of boundary delineation. The performance of the proposed DMSB-DG method has been verified by simulation and field data. Specifically, compared with the adaptive mining subsidence boundary delimitation (ASBD) method, the proposed method achieved Kappa coefficients of 91.96% and 87.28%, representing improvements of 21.23% and 27.14% in two field tests, respectively. Furthermore, the influence of ascending and descending SAR images, as well as observational noise, on the performance of the proposed algorithm is also evaluated. The results demonstrate that the proposed method effectively suppresses InSAR noise and other interfering deformations, enabling high-precision delineation of mining impact boundaries. Full article

Backfilling mining methods control the surrounding pressure and ground subsidence by backfilling goaf and managing the ground pressure, providing a safety guarantee for mining in complex environments and serving as a key means of achieving the deep mining of metal minerals. However, in the design of backfill strength, material mix ratios are determined under indoor standard constant temperature and humidity conditions, which differ significantly from the in situ curing environment. Strength measurements obtained from field samples are notably higher than those from indoor test specimens. To address this issue, this study designed a curing device simulating the in situ thermal-hydraulic multi-field environment of the mining site and tested the strength and porosity of the backfill under different curing temperatures, curing pressures, and pore water pressures. The results indicate that curing pressure and pore water pressure significantly altered the pore structure of the specimens. Specifically, when the curing pressure increased to 750 kPa, the maximum pore diameter decreased from 3110.52 nm to approximately 2055 nm, accompanied by a continuous reduction in porosity. Pore water pressure exhibited a positive linear correlation with specimen porosity, which increased continuously as the pore water pressure rose. With increasing curing temperature, the strength of the backfilled specimens first increased and then decreased, reaching a maximum at 45 °C. As the curing pressure increased, the strength of the backfilled specimens rose, but the rate of increase gradually slowed. With increasing pore water pressure, the strength of the backfilled specimens showed a gradual decreasing trend. Full article

The objective of this study is to quantify and characterize ground deformations induced by underground coal mining in the Karaganda coal basin, Kazakhstan, in order to improve the understanding of subsidence processes and their long-term evolution. The SBAS-InSAR method was applied to Sentinel-1 (C-band) and TerraSAR-X (X-band) data from 2019–2021 to estimate the magnitude, extent, and temporal behavior of displacements over the Kostenko, Kuzembayev, Aktasskaya, and Saranskaya mines. The results reveal spatially coherent and progressive deformation, with maximum cumulative LOS displacements exceeding –800 mm in TerraSAR-X data within active longwall mining zones. Time-series analysis confirmed acceleration of displacement during active extraction and its subsequent attenuation after mining ceased. Comparative assessment demonstrated a strong agreement between Sentinel-1 and TerraSAR-X results (r = 0.9628), despite differences in resolution and acquisition geometry, highlighting the robustness of the SBAS-InSAR approach. Analysis of displacement over individual longwalls showed that several panels (3, 5, 8, 15, and 18) already exceeded their projected maximum subsidence values, underlining the necessity of continuous monitoring for ensuring safety. In contrast, other longwalls have not yet reached their maximum deformation, indicating potential for further activity. Overall, this study demonstrates the value of multi-sensor InSAR monitoring for reliable assessment of mining-induced subsidence and for supporting geotechnical risk management in post-industrial regions. Full article

Transmission towers located above mined-out areas may experience collapse or instability due to mining-induced ground subsidence and deformation, which poses significant risks to the safe operation of power transmission lines. To clearly evaluate the deformation resistance and failure threshold of transmission towers under mining-induced ground deformation, this article examines a typical 220 kV self-supporting transmission tower located in a mining area of Northern Shaanxi Province through a detailed three-dimensional finite element model constructed and simulated using ANSYS 2022. The mechanical response and failure process of the tower structure were systematically simulated under five typical deformation conditions: tilt, horizontal compression, horizontal tension, tilt–compression, and tilt–tension. The results indicate that under individual deformation conditions, the critical deformation values of the tower are 35 mm/m for tilt, 10 mm/m for horizontal compression, and 8 mm/m for horizontal tension, demonstrating that the structure is most sensitive to horizontal tensile deformation. Under combined deformation conditions, the critical deformation values for the combined tilt–compression and tilt–tension conditions exhibited a marked reduction, reaching 8 mm/m and 6 mm/m. Compared to individual deformation conditions, transmission towers demonstrate a significantly higher susceptibility to structural failure under combined deformation conditions. The displacement at the tower head and the tower tilt angle exhibit a linear positive correlation with the values of ground surface deformation. Under individual deformation conditions, the tilt of the tower was approximately 0.903 times the tilt deformation value and 0.089 times the values of horizontal compression and tension deformation, indicating that tilt deformation exerts a more pronounced influence on the inclination of the tower. Under combined deformation conditions, the tilt of the tower reached approximately 0.981 times that of the tilt–compression deformation value and 0.829 times that of the tilt–tension deformation value. Compared to the tower tilt induced individually by horizontal compression or tension deformation, the tilt under combined deformation conditions demonstrated a significantly greater value. Under mining-induced ground deformation, a redistribution of support reactions occurs, exhibiting either nonlinear or linear increasing trends depending on the type of deformation. The findings of this article provide a theoretical basis and data support for disaster prevention and control, safety evaluation, and structural design of transmission lines in mining areas. Full article

With the progressive depletion of coal resources, the recovery of shaft pillars has become an important means of improving resource utilization and reducing waste. Taking the main shaft pillar recovery of the Longxiang Coal Mine at the stage of mine closure as the engineering background, this study systematically investigates ground subsidence prediction and shaft stability control under strip mining with symmetrical extraction. An improved subsidence prediction model was established by integrating the probability integral method with superposition theory, and its validity was verified through numerical simulations and field monitoring data. The results demonstrate that the proposed method can accurately capture the subsidence behavior under complex geological conditions, with prediction errors ranging from 6.4 mm to 399.1 mm. In fully subsided zones, the percentage error was as low as 1.1–3.5%, while larger deviations were observed in areas where subsidence was incomplete, confirming both the reliability and the practical limitations of the method under different conditions. Furthermore, the deformation mechanisms of the shaft during pillar recovery were analyzed. Monitoring results indicated that the maximum subsidence at the east and west sides of the shaft reached 7620.6 mm, accompanied by local cracks exceeding 1500 mm, which caused significant damage to surface structures. To address these risks, a safety control scheme based on an integrated “prediction–monitoring–control” framework is proposed, including shaft wall reinforcement, optimization of mining parameters, and continuous ground subsidence monitoring. By combining real-time monitoring with the superposition of small working face predictions, the scheme enables maximum recovery of shaft pillar coal while ensuring operational safety. This study provides a scientific basis and technical support for shaft pillar recovery in Longxiang Coal Mine and offers valuable theoretical guidance for similar mine closure projects, with significant implications for engineering practice. Full article

Coal mining in the aeolian sandy regions of western China has caused extensive land degradation. Traditional single-component soil amendments have proven inadequate for ecological restoration, underscoring the need for integrated and sustainable strategies to restore soil fertility and vegetation. A pot experiment using alfalfa (Medicago sativa L.) evaluated the effects of weathered coal, cow manure, and potassium polyacrylate combined in a three-factor three-level orthogonal design on plant growth, nutrient uptake, and soil properties. Results showed that compared with the control (C0O0P0), amendment treatments significantly increased alfalfa fresh weight (+47.57~107.38%), dry weight (+43.46~104.93%), plant height (+43.46~104.93%), and stem diameter (+12.62~31.52%), along with improved plant phosphorus and potassium concentrations (+15.41~46.65%). Soil fertility was also notably enhanced, with increases in soil organic matter, total nitrogen (TN), total phosphorus (TP), available nitrogen (AN), available phosphorus (AP), and available potassium (AK) ranging from 4.25% to 777.78%. In contrast, soil pH and bulk density were significantly reduced. The optimal amendment combination was identified as 10 g·kg⁻¹ weathered coal, 5 g·kg⁻¹ cow manure, and 0.6 g·kg⁻¹ potassium polyacrylate. Structural equation modeling revealed that the amendments promoted plant growth both directly by improving soil conditions and indirectly by enhancing nutrient uptake. However, high doses (30 g·kg⁻¹) of weathered coal may inhibit plant growth, and the co-application of high-dose weathered coal or manure with potassium polyacrylate may lead to antagonistic effects. This study provides fundamental insights into soil–plant interactions and proposes a sustainable amendment strategy for improving aeolian sandy soils, which could support future ecological reclamation efforts in coal mining area. Full article
