The dynamic response of multi-story steel frames under impact loading exhibits a complex nonlinear behavior. This study develops a three-story, multi-scale spatial steel frame finite element model using ABAQUS 2023 software, and the contact algorithm and material parameters were validated through published drop-weight impact beam tests. A total of 48 impact parameter combinations were defined, covering rational mass–velocity ranges while accounting for column position variations at the first story. Systematic comparisons were conducted on the influence of varying impact parameters on structural dynamic responses. This study investigates deformation damage and progressive collapse mechanisms in spatial steel frames under impact loading. Structural dynamic responses show significant enhancement with increasing impact mass and velocity. As impact kinetic energy increases, the steel frame transitions from localized denting at impact zones to global bending deformation, inducing structural tilting. The steel frame exhibits potential collapse risk under severe impact conditions. Under identical impact energy, corner column impact displacements differ by <1% from edge-middle column displacements, with vertical displacement variations ranging 0–17.6%. The displacement of the first-floor joints of the structure with three spans in the impact direction was reduced by about 50% compared to that with two spans. When designing the structure, it is necessary to increase the number of frame spans in the impact direction to improve the overall stability of the structure. Based on the development of the rotation angle of the beam members during the impact process, the steel frame collapse process was divided into three stages, the elastic stage, the plastic and catenary stage, and the column member failure stage; the steel frame finally collapsed due to an excessive beam rotation angle and column failure. Full article

Tungsten Inert Gas (TIG) welding is a widespread welding process used in the industry for high-quality joints. However, this welding process suffers from lower productivity. Activated Tungsten Inert Gas (ATIG) is a variant of the TIG that aims to increase the depth penetration capability of conventional TIG welding. This is achieved by applying a thin coating of activating flux material onto the workpiece surface before welding. This work investigates the effect of the thermophysical properties of individual metallic oxide fluxes on 316L stainless steel weld morphology. Four levels of current intensity (120, 150, 180, 200 A) are considered. The weld speed up to 15 cm/min and arc length of 2 mm are maintained constant. Thirteen oxides were tested under various levels of current intensity in addition to multiple thermophysical properties combinations, and the depth penetration (D) and the aspect ratio (R) were recorded. This process has provided 52 combinations (13 oxides * 4 currents). Based on the numerical observations, linear and nonlinear models for describing the effect of the thermophysical parameters on the weld characteristics were tuned using a particle swarm optimization algorithm. While the linear model provided good prediction accuracy, the nonlinear exponential model outperformed the linear one for the depth yielding a mean absolute percentage error of 17%, a coefficient of determination of 0.8266, and a root mean square error of 0.9665 mm. The inverse optimization process, where the depth penetration ranged from 1.5 mm to 12 mm, thus covering a large spectrum of industries, the automotive, power plants, and construction industries, was solved to determine the envelopes’ lower and upper limits of optimal oxide thermophysical properties. The results that allowed the design of the fluxes to be used in advance were promising since they provided the oxide designer with the numerical ranges of the oxide components to achieve the targeted depths. Future directions of this work can be built around investigating additional nonlinear models, including saturation and dead-zone, to efficiently estimate the effect of the thermophysical properties on the welding process of other materials. Full article

The thick-walled thickness effect in layered-symmetrical structure is very important for considering the external thermal heating on the surface of functionally graded material (FGM) plates. Dynamic thermal vibration with advanced shear correction on the FGM plates are presented. The third-order shear deformation theory (TSDT) is included to calculate the values of advanced shear correction for the thick plates based on the displacement assumed in the middle symmetry plane. The values of advanced shear correction coefficient are in nonlinear variation with respect to the power-law index value for FGM. The dynamic stresses are calculated when the displacements and shear rotations are obtained for the given natural frequency of displacements, frequency of applied heat flux and time. The natural frequencies of sinusoidal displacements and shear rotations are obtained by using the determinant of the coefficient matrix in the fully homogeneous equation. Only the numerical dynamic results of displacements and stresses subjected to sinusoidal applied heat loads are investigated. The heating study in symmetry structure of FGMs to induce thermal vibration is interesting in the field of engineering and materials. The center displacements can withstand a higher temperature of 1000 K and a power-law index of 5, for which the length-to-thickness ratio 5 is better than that for 10. Full article

High production costs and extended development timelines pose significant challenges to the manufacturing of bearingless permanent magnet synchronous motors (BPMSMs). Moreover, uncertainties regarding the motor’s ability to generate suspension and torque often persist even after prototyping, primarily due to the limitations of lumped parameter models in capturing the system’s complex dynamics. Since this technology is not yet fully consolidated, there is a clear need for a solution that enables the effective evaluation of BPMSMs prior to physical production. To address this, a reduced-order model (ROM) was developed for BPMSMs with combined windings, capturing the cross-coupling effects associated with rotor eccentricity, magnetic saturation, and topological complexity. The model was constructed using the parametric interpolation method (PIM), enabling efficient and accurate representations of nonlinear electromechanical behavior as ferromagnetic materials and spatial harmonics are addressed through finite element modeling. Additionally, hardware-in-the-loop (HIL) techniques were used for gain tuning, and active disturbance rejection control (ADRC) was applied to enhance performance. This combined approach offers a comprehensive solution for the design and control of BPMSMs. Full article

This article aims to clarify the applicability of He’s two-scale fractal dimension transform by replacing $t^{\mathsf{\alpha }}$ with $\mathsf{\tau }$. It demonstrates the potential to capture the influence of the fractal parameter on the system’s damping frequency, particularly when the viscoelastic term (damping) does not equal half of the fractional inertia force term. The analysis examines the elastomer materials’ dynamic fractal amplitude–time response, considering the viscohyperelastic effects related to the material’s energy dissipation capacity. To determine the amplitude of oscillations for the nonlinear equation of motion of a body supported by a viscohyperelastic elastomer subjected to uniaxial stretching, the harmonic balance perturbation method, combined with the two-scale fractal dimension transform and Ross’s formula, is employed. Numerical calculations demonstrate the effectiveness of He’s two-scale fractal transformation in capturing fractal phenomena associated with the fractional time derivative of deformation. This is due to a correlation between the fractional rate of viscoelasticity and the fractal structure of media in elastomer materials, which is reflected in the oscillation amplitude decay. Furthermore, the approach introduced by El-Dib to replace the original fractional equation of motion with an equivalent linear oscillator with integer derivatives is used to further assess the qualitative and quantitative performance of our derived solution. The proposed approach elucidates the applicability of He’s two-scale fractal calculus for determining the amplitude of oscillations in viscohyperelastic systems, where the fractal derivative order of the inertia and damping terms varies. Full article

As critical components in marine engineering fluid transmission systems, fiber-reinforced flexible (FRF) pipes have static mechanical properties that depend on internal fluid pressure. Current analytical approaches predominantly employ uniformly distributed load (UDL) assumptions to simulate unidirectional fluid pressure effects on pipe surfaces. However, existing methodologies neglect fluid–pipe structure coupling effects. This study investigates the rubber-based FRF pipe by establishing a numerical model incorporating fluid–structure interaction effects and material nonlinearity, aiming to explore how different fluid states (closed or constant pressure) and fluid types (incompressible or compressible) influence the mechanical behavior of the FRF pipe under axial loading. Experimental validation of the numerical model demonstrates that UDL assumptions remain valid for gas-filled pipes (both in the closed and constant pressure states) and the liquid-filled pipe in the constant pressure state. The incompressibility of the filled liquid significantly enhances pipe axial stiffness, invalidating the UDL approximation method in liquid-filled closed states. Furthermore, the asymptotic saturation model proposed effectively quantifies the liquid-induced enhancement in axial stiffness. The developed numerical model and derived conclusions provide valuable insights into structural design optimization, experimental protocol development, and practical engineering applications for FRF pipes. Full article

The paper innovatively studies the impact of dual randomness of structural parameters and seismic excitation on the seismic reliability of highway pile–slab structures using the probability density evolution method. A nonlinear stochastic dynamic model was established through the platform, integrating, for the first time, the randomness of concrete material properties and seismic motion variability. The main findings include the following: Under deterministic seismic input, the displacement angle fluctuation range caused by structural parameter randomness is ±3%, and reliability decreases from 100% to 65.26%. For seismic excitation randomness, compared to structural parameter randomness, reliability at the 3.3% threshold decreases by 7.99%, reaching 92.01%. Dual randomness amplifies the variability of structural response, reducing reliability to 86.38% and 62%, with a maximum difference of 20.5% compared to single-factor scenarios. Compared to the Monte Carlo method, probability density evolution shows significant advantages in computational accuracy and efficiency for large-scale systems, revealing enhanced discreteness and irregularity under combined randomness. This study emphasizes the necessity of addressing dual randomness in seismic design, advancing probabilistic seismic assessment methods for complex engineering systems, thereby aiding the design phase in enhancing facility safety and providing scientific basis for improved design specifications. Full article

Shaping or splitting of a Gaussian beam is often desired to optimise laser–material interactions, improving throughput and quality. This can be achieved holographically using liquid crystal-on-silicon spatial light modulators (LC-SLMs). Until recently, maximum exposure has been limited to circa 120 W average power with a Gaussian profile, restricting potential applications due to the non-linear (NL) phase response of the liquid crystal above this threshold. In this study, we present experimental tests of a new SLM device, demonstrating high first-order diffraction efficiency of η = 0.98 ± 0.01 at 300 W average power and a phase range Δφ > 2π at P = 383 W, an exceptional performance. The numerically calculated device temperature response with power closely matches that measured, supporting the higher power-handling capability. Surface modification of mild steel and molybdenum up to P = 350 W exposure is demonstrated when employing a single-mode (SM) fibre laser source. Exposure on mild steel with a vortex beam (m = +6) displays numerous ringed regions with varying micro-structures and clear elemental separation created by the radial heat flow. On molybdenum, with multi-spot Gaussian exposure, both MoO₃ films and recrystallisation rings were observed, exposure-dependent. The step change in device capability will accelerate new applications for this LC-SLM in both subtractive and additive manufacturing. Full article

Background/Objectives: This work prospectively evaluates the vendor-provided Low Variance (LOVA) apparent diffusion coefficient (ADC) gradient nonlinearity correction (GNC) technique for primary tumors, neck nodal metastases, and normal masseter muscles in patients with head and neck cancers (HNCs). Methods: Multiple b-value diffusion-weighted (DW)-MR images were acquired on a 3.0 T scanner using a single-shot echo planar imaging (SS-EPI) and multi-shot (MS)-EPI for diffusion phantom materials (20% and 40% polyvinylpyrrolidone (PVP) in water). Pretreatment DW-MRI acquisitions were performed for sixty HNC patients (n = 60) who underwent chemoradiation therapy. ADC values with and without GNC were calculated offline using a monoexponential diffusion model over all b-values, relative percentage (r%) changes (Δ) in ADC values with and without GNC were calculated, and the ADC histograms were analyzed. Results: Mean ADC values calculated using SS-EPI DW data with and without GNC differed by ≤1% for both PVP20% and PVP40% at the isocenter, whereas off-center differences were ≤19.6% for both concentrations. A similar trend was observed for these materials with MS-EPI. In patients, the mean rΔADC (%) values measured with SS-EPI differed by 4.77%, 3.98%, and 5.68% for primary tumors, metastatic nodes, and masseter muscle. MS-EPI exhibited a similar result with 5.56%, 3.95%, and 4.85%, respectively. Conclusions: This study showed that the GNC method improves the robustness of the ADC measurement, enhancing its value as a quantitative imaging biomarker used in HNC clinical trials. Full article

The Asymmetric Double Cantilever Beam (ADCB) is a common test configuration used to produce mixed mode I/II in composite materials. It consists of two sublaminates with different thicknesses or elastic properties, a situation that usually occurs in bimaterial adhesive joints. During this test, the sample undergoes rotation. In this work, the influence of this rotation on the calculation of the energy release rate (ERR) in modes I and II was studied using the Finite Element Method (FEM). Several models with different degrees of asymmetry (different thickness ratio and/or elastic modulus ratio) and different applied displacements were prepared to obtain different levels of rotation during the test. As is known, the concept of modes I and II refers to the components of the energy release rate calculated in the direction perpendicular and tangential to the delamination plane, respectively. If the model experiences significant rotation during the application of the load, this non-linearity must be considered in the calculation of the mode partition I/II. In this work, appreciable differences were observed in the values of modes I and II, depending on their calculation in a global system or a local system that rotates with the sample. When performing crack growth calculations, the difference between critical loads can be in the order of 4%, while the difference between mode I and mode II results can reach 4% and 14%, respectively, for an applied displacement of only 5 mm. Currently, this correction is not usually implemented in Finite Element calculation codes or in analytical developments. The purpose of this article is to draw attention to this aspect when the rotation of the specimen is not negligible. Full article

With the popularization of the concept of seismic performance-based design, the correct and quantitative evaluation of post-earthquake damage to structural components has become a research focus. Referring to the concrete constitutive relationship mentioned in the Chinese national standard GB/T 50010-2010, this study proposes a damage assessment method for concrete components based on material damage. According to the value of the uniaxial damage evolution parameter of concrete (d_c(t)), the damage grades of concrete components are defined. It is specified that, when the value of d_c(t) is less than the d_c(t),r value corresponding to the peak concrete strain (ε_c(t),r), the concrete component is in a non-damaged state (Level L1). When the value of d_c(t) is greater than the d_c(t)u value corresponding to the concrete strain (ε_c(t)u), the concrete component is in a severely damaged state (Level L6). When the value of d_c(t) is between these two values, the damage grade of the concrete component (levels L2 to L5) is determined using linear interpolation. To promote its engineering application, this study also proposes a quantitative expression for the damage assessment method for concrete components based on d_c(t). To verify the rationality of the damage assessment method for concrete components based on d_c(t), a refined model of rectangular, T-shaped, and L-shaped concrete shear wall components was established using ABAQUS software, and a nonlinear finite element analysis was carried out. The simulation results show that (a) the damage assessment method for concrete components based on d_c(t) can better characterize damage to concrete shear wall components; (b) when defining the damage grades of concrete shear wall components, using d_c is more reasonable than using d_t; and (c), from a macroscopic perspective, the damage assessment method for concrete components based on d_c(t) is more in line with actual expectations and has a higher safety factor compared with the damage assessment method for concrete components based on the concrete compressive strain (ε_c) mentioned in the Chinese association standard T/CECA 20024-2022. Full article

Background and Objectives: Postoperative atrial fibrillation (AF) is a frequent complication after coronary artery bypass grafting (CABG), and is particularly associated with poor outcomes. Heart rate variability (HRV), a non-invasive marker of autonomic function, has been proposed as a tool to predict AF risk, but its utility in off-pump CABG remains unclear. This study aimed to evaluate the predictive value of preoperative HRV parameters, including nonlinear metrics, for postoperative AF in patients undergoing off-pump CABG. Materials and Methods: We prospectively enrolled 67 patients undergoing elective off-pump CABG. HRV was assessed using 15 min high-resolution ECGs. Linear and nonlinear HRV parameters were analyzed. Postoperative AF was monitored through continuous ECG (days 0–4), daily 12-lead ECGs (days 5–7), and a 24 h Holter ECG on day 7. Statistical comparisons between AF and non-AF groups were performed, and the predictive accuracy was evaluated using ROC analysis. Results: Postoperative AF occurred in 40.3% (n = 27) of patients. Standard HRV measures (total power, frequency components, LF/HF ratio) did not differ significantly between groups. However, preoperative DFA Alpha 1 was significantly lower in patients who developed AF (p = 0.010) and showed the highest predictive value (AUC = 0.725, specificity = 80%). Alpha 1 also remained significantly reduced postoperatively in the AF group. Other nonlinear parameters, such as low and average fractal dimension, were also lower postoperatively in the AF group. Conclusions: Traditional HRV parameters showed limited predictive value for postoperative AF following off-pump CABG. The nonlinear DFA Alpha 1 index demonstrated a moderate predictive performance and may serve as a useful marker of autonomic dysregulation. Incorporating nonlinear HRV measures into preoperative assessment may improve AF risk stratification. Full article

Polyvinyl alcohol cryogels (PVA-C) are promising materials for vascular tissue engineering due to their biocompatibility, hydrophilicity, and tuneable mechanical properties. This study investigates the mechanical performance of multi-layered PVA-C constructs fabricated via sub-zero extrusion-based three-dimensional (3D) bioprinting. Samples with two, four, and six alternating layers were evaluated to assess the effect of layered architecture on elastic and viscoelastic behaviour. Uniaxial tensile testing revealed that increasing the number of layers led to a moderate reduction in stiffness; for instance, at 20% strain, six-layered constructs showed a significantly lower (p < 0.05) Young’s modulus (36.7 ± 2.5 kPa) compared to two-layered ones (47.3 ± 3.1 kPa). Stress–strain curves exhibited nonlinear characteristics, better captured by quadratic (as opposed to linear) fitting, within the tested strain range (≤40%). Dynamic mechanical analysis demonstrated a frequency-independent storage modulus (E′) across 1–10 Hz, with subtle variations in viscoelastic response linked to the number of layers. Visual inspection confirmed improved print fidelity and hydration retention in thicker constructs. These findings demonstrate that a multi-layered design influences the mechanical profile of PVA-C and suggests potential for functionally graded design strategies to enhance compliance matching and mimic the biomechanics of native vessels in small-diameter vascular grafts. Full article

Metal magnetic memory testing technology can not only detect macroscopic defects in ferromagnetic materials but also rapidly and conveniently detect early damage and stress concentration areas of components. Therefore, it is widely used in the nondestructive testing of ferromagnetic materials. However, the mechanism of magnetic memory detection is not yet clarified, and experimental research is unsystematic. Previous studies mainly focus on the normal and tangential components of magnetic memory signals (MMSs), and the third directional component is rarely considered, resulting in problems such as missed detection and misjudgement in practical applications. In this research, specimens without and with a circular hole defect were designed, and the correlation between the 3D MMS and the defect size, as well as the applied load, were investigated using tensile tests. Magnetic parameters were defined to characterize the stress and defect-induced abnormal magnetic change. The effects of applied load and defect size on magnetic parameters were discussed. The experimental results showed that the peak–valley difference in the 3D MMS increases with increasing load and defect size, and the peak–valley spacing in the 3D MMS is not influenced by applied load but increases with increasing defect size. The 3D MMS gradient exhibits a good correlation with the equivalent stress along the loading direction. Additionally, the applied load and defect size were quantitatively evaluated by utilizing the Lissajous figure area generated from the X and Z components of the 3D MMS. Finally, a nonlinear fitting equation for defect size evaluation was presented. This study can provide a theoretical basis for the quantitative detection and evaluation of defect size and stress in engineering applications. Full article

Compared with the traditional rigid solar wings, flexible solar arrays are characterized by light weight and high stowing/deployment ratio, and the repeatable stowing/deployment flexible solar arrays have become one of the hotspots of solar arrays research in the aerospace field. As integrated rigid–flexible structures, flexible solar arrays face risks of repeatable stowing/deployment function failure due to the nonlinear force-heat coupling effects. This paper takes symmetry as the core design concept, and through the introduction of rotationally symmetric sector layout, material stacking, and the stowing/deployment mechanism, the thermal response of flexible solar arrays under extreme thermal environments was systematically investigated, which significantly improves thermal distribution uniformity of the flexible solar arrays and provides a new way of solving the problem of repeatable stowing/deployment of flexible solar arrays. Furthermore, we propose a high- and low-temperature unfolding test method for fan-shaped flexible solar arrays, which verifies the reliability of symmetric fan-shaped arrays in high and low temperatures during the working process of repeatable stowing/deployment and the safety of the stowing/deployment process, as well as providing a reference for the subsequent design and test of flexible solar arrays of other configurations. Full article
