Search Results (3)

Search Parameters:
Keywords = optical pin-like beams

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 3671 KB
Article
Method for Suppressing Scintillation in Up-Link Optical Communication Using Optical Pin-like Beams Propagating Through Atmospheric Turbulence
by Rong Wang, Bin Lan, Chao Liu, Kaihe Zhang, Jiaxin Zhou, Xueying Li, Tianjun Dai and Hao Xian
Photonics 2025, 12(7), 739; https://doi.org/10.3390/photonics12070739 - 20 Jul 2025
Viewed by 396
Abstract
Free space optical communication (FSOC) systems operating in the space–atmosphere channel are susceptible to severe turbulence-induced scintillation, particularly in up-link configurations where the adaptive optics (AO) pre-correction becomes ineffective due to anisoplanatic constraints. This study presents a novel scintillation suppression strategy utilizing self-focusing [...] Read more.
Free space optical communication (FSOC) systems operating in the space–atmosphere channel are susceptible to severe turbulence-induced scintillation, particularly in up-link configurations where the adaptive optics (AO) pre-correction becomes ineffective due to anisoplanatic constraints. This study presents a novel scintillation suppression strategy utilizing self-focusing optical pin-like beams (OPBs) with tailored phase modulation, combining theoretical derivation and numerical simulation. It is found that increasing the shape factor γ and modulation depth C elevates the average received power and reduces the scintillation index at the focal point. Meanwhile, quantitative evaluation of the five OPB configurations shows that the parameter set γ = 1.4 and C = 7 × 10−5 gives a peak scintillation suppression efficiency. It shows that turbulence induced scintillation is suppressed by 44% with the turbulence intensity D/r0 = 10, demonstrating exceptional effectiveness in up-link transmission. The findings demonstrate that OPB with optimized γ and C establish an approach for uplink FSOC, which is achieved through suppressed scintillation and stabilized power reception. Full article
Show Figures

Figure 1

14 pages, 2572 KB
Article
The Role of Substrate on Thermal Evolution of Ag/TiO2 Nanogranular Thin Films
by Vincenzo Balzano, Emanuele Cavaliere, Mattia Fanetti, Sandra Gardonio and Luca Gavioli
Nanomaterials 2021, 11(9), 2253; https://doi.org/10.3390/nano11092253 - 31 Aug 2021
Cited by 11 | Viewed by 2853
Abstract
In multicomponent thin films, properties and functionalities related to post-deposition annealing treatments, such as thermal stability, optical absorption and surface morphology are typically rationalized, neglecting the role of the substrate. Here, we show the role of the substrate in determining the temperature dependent [...] Read more.
In multicomponent thin films, properties and functionalities related to post-deposition annealing treatments, such as thermal stability, optical absorption and surface morphology are typically rationalized, neglecting the role of the substrate. Here, we show the role of the substrate in determining the temperature dependent behaviour of a paradigmatic two-component nanogranular thin film (Ag/TiO2) deposited by gas phase supersonic cluster beam deposition (SCBD) on silica and sapphire. Up to 600 °C, no TiO2 grain growth nor crystallization is observed, likely inhibited by the Zener pinning pressure exerted by the Ag nanoparticles on the TiO2 grain boundaries. Above 600 °C, grain coalescence, formation of However, the two substrates steer the evolution of the film morphology and optical properties in two different directions. anatase and rutile phases and drastic modification of the optical absorption are observed. On silica, Ag is still present as NPs distributed into the TiO2 matrix, while on sapphire, hundreds of nm wide Ag aggregates appear on the film surface. Moreover, the silica-deposited film shows a broad absorption band in the visible range while the sapphire-deposited film becomes almost transparent for wavelengths above 380 nm. We discuss this result in terms of substrate differences in thermal conductivity, thermal expansion coefficient and Ag diffusivity. The study of the substrate role during annealing is possible since SCBD allows the synthesis of the same film independently of the substrate, and suggests new perspectives on the thermodynamics and physical exchanges between thin films and their substrates during heat treatments. Full article
(This article belongs to the Section Synthesis, Interfaces and Nanostructures)
Show Figures

Figure 1

13 pages, 5121 KB
Article
Experimental Setup of the Fast Current Controller for the Buenos Aires Heavy Ion Microbeam
by Nahuel Agustín Vega, Nahuel Agustín Müller, Emmanuel de la Fourniére, Emilia Beatriz Halac and Mario Ernesto Debray
Quantum Beam Sci. 2019, 3(2), 10; https://doi.org/10.3390/qubs3020010 - 3 Jun 2019
Viewed by 3606
Abstract
Recently we used the heavy ion microprobe of the Buenos Aires TANDAR Laboratory for Single Event Effects (SEE) and Total Dose (TD) experiments in electronics devices and components, requiring very low beam currents. The facility includes a fast beam switch that allows the [...] Read more.
Recently we used the heavy ion microprobe of the Buenos Aires TANDAR Laboratory for Single Event Effects (SEE) and Total Dose (TD) experiments in electronics devices and components, requiring very low beam currents. The facility includes a fast beam switch that allows the control of the ion beam current and a mobile Si PIN (p-type, intrinsic, n-type) diode that directly measures the number of ions hitting the device. The fast beam deflector was used to reduce the current by producing a pulsed beam or generating a quasi-continuous (Poisson-like distributed) beam with currents ranging from tens to hundreds of ions/s. As an application for this current control method we present a single event effect (SEE) pulses map generated by a 32S8+ beam at 75 MeV on two 0.5 µm technology CMOS digital output buffers where the device was formed by cascading four CMOS inverters with increasing sizes from input to output to drive large loads. Using the same concept of pulse width modulated deflection, we developed a novel gradient scanning method. This system allows to produce in a single irradiation a distribution with a cumulative damage with a difference of two orders of magnitude at constant gradient. To demonstrate the method, we irradiated a lithium niobate monocrystal with 32S8+ beam at 75 MeV energy and later analyzed the produced damage by the micro-Raman technique and an optical profilometer. Full article
(This article belongs to the Collection Facilities)
Show Figures

Figure 1
