Regular inspection of overhead power line (OPL) systems is required to detect damage early and ensure the efficient and uninterrupted transmission of high-voltage electric power. In the past, these checks were conducted utilizing line crawling, inspection robots, and a helicopter. Yet, these traditional solutions are slow, costly, and hazardous. Advancements in drones, edge computing platforms, deep learning, and high-resolution cameras may enable real-time OPL inspections using drones. Some research has been conducted on OPL inspection with autonomous drones. However, it is essential to explore how to achieve real-time OPL component detection effectively and efficiently. In this paper, we report our research on OPL component detection on edge computing devices. The original OPL dataset is generated in this study. In this paper, we evaluate the detection performance with several sizes of training datasets. We also implement simple data augmentation to extend the size of datasets. The performance of the YOLOv7 model is also evaluated on several edge computing platforms, such as Raspberry Pi 4B, Jetson Nano, and Jetson Orin Nano. The model quantization method is used to improve the real-time performance of the detection model. The simulation results show that the proposed YOLOv7 model can achieve mean average precision (mAP) over 90%. While the hardware evaluation shows the real-time detection performance can be achieved in several circumstances. Full article

This paper presents an enhanced version of YOLOv8 specifically designed for detecting damage in overhead power lines. Firstly, to improve the model’s robustness, an adaptive threshold mechanism is introduced that can dynamically adjust the detection threshold based on the brightness, contrast, and other characteristics of the input image. Secondly, a novel convolution method, GSConv, is adopted in the YOLOv8 framework, which balances the model’s running speed and accuracy. Finally, a lightweight network structure, Slim Neck, is introduced, effectively reducing the model’s complexity and computational load while maintaining good performance. These improvements enable our YOLOv8 model to achieve excellent performance in detecting ‘thunderbolt’ and ‘break’ types of cable damage. Experimental results show that the improved YOLOv8 network model has an average detection accuracy (mAP) of 90.2%, a recall rate of 91.6%, and a precision of 89.8% on the ‘Cable Damage Detection’ dataset from RoboFlow for ‘thunderbolt’. For ‘break’, the mAP is 86.5%, the recall rate is 84.1%, and the precision is 86.1%. Compared with the original YOLOv8 model, these indicators have been significantly improved, highlighting the high practical value and strong generalization ability of the proposed algorithm in detecting damage to overhead power lines. This also demonstrates the high practical value of the method in future research directions. Full article

Insulators of the kind used for overhead transmission lines institute important kinds of insulation control, namely, electrical insulation and mechanical fixing. Because of their large exposure to the environment, they are affected by factors such as climate, temperature, durability, the easy occurrence of explosions, damage, the threat of going missing, and other faults. These seriously influence the safety of the power transmission, so insulation monitoring must be conducted. With the development of unmanned technology, the staff used unmanned aircraft to take aerial photos of the detected insulators, and the insulator images were obtained by naked eye observation. Although this method looks very reliable, in practice, due to the large quantity of insulator-collected seismic data, and the complex background, workers are usually relying on their experience to make judgements, so it is easy for mistakes to appear. In recent years, with the rapid development of computer technology, more and more attention has been paid to fault detection and identification in insulators by computer-aided workers. In order to improve the detection accuracy of self-exploding insulators, especially in bad weather environments, and to overcome the influence of fog on target detection, a regression attention convolutional neural network is used for optimization. Through the recursive operation of multi-scale attention, multi-scale feature information is connected in series, the regional focus is recursively generated from coarse to fine, and the target region is detected to achieve optimal results. The experimental results show that the proposed method can effectively improve the fault diagnosis ability of insulators. Compared with the accuracy of other basic models, such as FCAN and MG-CNN, the accuracy of RA-CNN in multi-layer cascade optimization is higher than that in the previous two models, which is 74.9% and 75.6%, respectively. In addition, the results of the ablation experiments at different scales showed that the identification results of different two-level combinations were 78.2%, 81.4%, and 83.6%, and the accuracy of selecting three-level combinations was up to 85.3%, which was significantly higher than the other models. Full article

Today, there are many attempts to introduce the Internet of Things (IoT) in high-voltage systems, where partial discharges are a focus of concern since they degrade the insulation. The idea is to detect such discharges at a very early stage so that corrective actions can be taken before major damage is produced. Electronic image sensors are traditionally based on charge-coupled devices (CCDs) and, next, on complementary metal oxide semiconductor (CMOS) devices. This paper performs a review and analysis of state-of-the-art image sensors for detecting, locating, and quantifying partial discharges in insulation systems and, in particular, corona discharges since it is an area with an important potential for expansion due to the important consequences of discharges and the complexity of their detection. The paper also discusses the recent progress, as well as the research needs and the challenges to be faced, in applying image sensors in this area. Although many of the cited research works focused on high-voltage applications, partial discharges can also occur in medium- and low-voltage applications. Thus, the potential applications that could potentially benefit from the introduction of image sensors to detect electrical discharges include power substations, buried power cables, overhead power lines, and automotive applications, among others. Full article

Power systems and their primary components, mostly the transmission and distribution of overhead lines, substations, and other power facilities, are distributed in space and are exposed to various atmospheric and meteorological conditions. These conditions carry a certain level of risk for reliable electrical power delivery. Various atmospheric hazards endanger the operation of power systems, where the most significant are thunderstorms, wildfire events, and floods which can cause various ranges of disturbances, faults, and damages to the power grid, or even negatively affect the quality of life. By utilizing a weather monitoring and early warning system, it is possible to ensure a faster reaction against different weather-caused fault detections and elimination, to ensure a faster and more adequate preparation for fighting extreme weather events, while maintaining overhead line protection and fault elimination. Moreso, it is possible to bypass overhead lines that have the highest risk of unfavorable meteorological events and hazards, and reroute the energy, thus providing electricity to endangered areas in times of need while minimizing blackouts, and consequently, improving the quality of human life. This paper will present an analysis of the various risks of atmospheric phenomena, in the meteorological and climate context, and discuss various power system components, the power system control, operations, planning, and power quality. A concept with the main functionalities and data sources needed for the establishment of an early warning weather hazard system will be proposed. The proposed solution can be used as a utility function in power system control to mitigate risks to the power system due to atmospheric influences and ongoing climate change. Full article

The drastic consequences of emergencies force us to look for ways to increase the stability of the device operation at overhead power transmission lines (OHPTL). It can be achieved by developing new algorithms for determining the protection operation setpoints and detecting the damage location. Fault detection at OHPTL of 10 kV and above is mainly carried out by the devices based on the measurement of emergency mode parameters. For fault detecting one should analyze the parameters of not only current and voltage at the accident time, but also of the overhead power line. Specific active resistance, specific reactance, specific active conductivity and specific reactive conductivity are used to characterize the overhead power transmission lines. As a rule, these parameters are normalized to the unit of length of the overhead line (OHL) and linear values are used in the calculations. When analyzing power lines, tabular approximate values of longitudinal and transversal parameters in equivalent circuits are used, although solving problems in an unsimplified form leads to significant refinements of the known solutions, since OHLs are influenced by external atmospheric factors (ambient temperature, soil moisture, wind force, ice formation, etc.). The paper analyzes these characteristics and evaluates the influence of the listed factors on the linear longitudinal and transversal parameters of overhead lines. A functional dependence of external factors on the distance protection actuation setpoint was obtained. A method for automatic correction of the setpoint of the intelligent protection complex and an adaptive relay protection algorithm was developed, taking into account changes in climatic factors, enabling to reduce the “dead zone” length and increase the protection sensitivity. The use of line parameters obtained from the sensors in the calculations give rise to a more accurate fault detection based on the use of remote sensing methods. Full article
