Two-dimensional black phosphorus (2D BP) has emerged as one of the most promising two-dimensional semiconductors for next-generation micro and nanoelectronics beyond Moore’s Law. It is distinguished by its unique combination of a layer dependent direct bandgap, broadband photoresponse, and pronounced in-plane anisotropy, addressing key intrinsic limitations that have hindered the widespread application of graphene and conventional transition metal dichalcogenides (TMDCs). This review provides a systematic and comprehensive overview of recent advances in the controllable fabrication of 2D BP and its applications in transistors and photodetectors. We first elucidate its crystal lattice structure and fundamental physical properties, then categorize and summarize synthesis strategies based on production scale ranging from small scale methods (e.g., mechanical exfoliation and solution based exfoliation) to large scale methods (e.g., Chemical Vapor Deposition (CVD) and Pulsed Laser Deposition (PLD)), with a particular focus on recent advances in high-speed field-effect transistors and broadband photodetectors. In summary, the key to achieving large-scale controllable synthesis lies in addressing the challenges of high-temperature oxidation of black phosphorus and the uncontrollable diffusion of phosphorus sources. In the future, industrial applications are expected to be realized through CVD based regulation of phosphorus sources, low-temperature growth by PLD, and deep integration with silicon-based processes. Full article

High-entropy alloy (HEA) coatings exhibit enhanced chemical stability when doped with carbon, primarily due to the strong bonding between carbon and transition metals. Typical transition metals used in these coatings include Cr, Fe, Co, Ni, Cu, Ti, V, W, Nb, Ta, and Zr. Owing to their excellent chemical stability, HEA coatings are widely employed to protect component surfaces operating in highly corrosive environments. Against this backdrop, the present study investigates the effect of carbon doping introduced via methane gas flow during the physical vapor deposition of TiAlTaZrNb HEA coatings on corrosion resistance. The morphology and structure of the coatings were analyzed by field emission scanning electron microscopy, X-ray diffraction, and Raman spectroscopy. Corrosion protection and coating resistance were assessed through potentiodynamic polarization and electrochemical impedance spectroscopy. While increasing the methane flow resulted in an approximately 34% reduction in coating thickness, the overall coating resistance increased by one order of magnitude, reaching a maximum at a methane flow rate of 9 sccm, corresponding to the carbon solubility limit. This improvement was evidenced by a decrease in the corrosion rate from 8.02 × 10⁻² mm y⁻¹ for the uncoated H13 steel to 8.00 × 10⁻⁴ mm y⁻¹ for the HEA-coated samples. However, at higher methane flow rates, carbon precipitation and the formation of parallel microcracks contributed to an increase in corrosion rate. Full article

This study investigated porous materials based on cellulose acetate (CA), poly(lactic acid) (PLA), and their multilayer combinations fabricated by solution blow spinning (SBS) for potential food packaging applications. Single-layer neat polymers and multilayer structures (CA/PLA, CA/PLA/CA, and PLA/CA/PLA) were produced through sequential deposition, enabling control of layer arrangement while preserving high porosity. Attenuated total reflectance Fourier-transformed infrared spectroscopy, differential scanning calorimetry, and thermogravimetric analysis showed negligible polymer interdiffusion or specific intermolecular interactions, indicating that layer integration occurs mainly through physical contact and void filling rather than molecular mixing. Scanning electron microscopy analysis revealed that cellulose acetate possesses a highly porous, interconnected structure, whereas poly(lactic acid) exhibits a predominantly fibrous morphology with clearly distinguishable layers in multilayer systems. Mechanical testing demonstrated that poly(lactic acid) mats had higher stiffness and tensile strength, while cellulose acetate films were more flexible and compliant. Multilayer systems showed complex tensile behavior characterized by interfacial failure and limited load transfer, indicating no synergistic mechanical reinforcement between layers. Water vapor permeability remained high and narrowly distributed for all configurations (890–920 g·m⁻²·day⁻¹), independent of layer sequence, reflecting the porous morphology. These values exceed those of conventional polymer packaging films, highlighting the suitability of the materials for breathable packaging. Overall, solution blow spinning enables scalable fabrication of biodegradable multilayer materials with tunable mechanical performance for sustainable food packaging applications requiring controlled moisture exchange. Full article

Surface engineering strongly influences the performance, reliability, and safety of medical and biomedical devices, yet failures often originate at interfaces rather than in bulk materials alone. This review addresses the fragmented evidence base linking coating selection, interphase design, qualification testing, advanced characterization, and data-driven durability analysis. The objective is to provide an integrative, failure-mode-based framework for implants, reusable instruments, inhalation systems, diagnostics, wearables, and implantable electronics. A narrative synthesis of the peer-reviewed literature in coatings, biomaterials, electrochemistry, reliability, standards, and materials informatics was conducted, with qualitative tables used only when protocols were too heterogeneous for numerical pooling. The review compares physical vapor deposition (PVD), chemical and plasma-enhanced chemical vapor deposition (CVD/PECVD), atomic layer deposition (ALD), sol–gel/organically modified silica (ORMOSIL) hybrids, plasma polymers, parylene, bioactive or antimicrobial surfaces, and electronic encapsulation strategies. The main finding is that no universally superior coating exists; reliable performance depends on matching architecture and characterization to the dominant failure pathway, substrate compliance, geometry, sterilization or physiologic exposure, and the standards-constrained endpoint. The review further shows how electrochemical diagnostics, interfacial mechanics, multiphysics models, survival/reliability statistics, and carefully governed AI workflows can be combined to support service-life prediction and decision-oriented qualification. Full article

Two-dimensional molybdenum disulfide (MoS₂) has emerged as a promising candidate for next-generation electronics and optoelectronics; however, its scalable synthesis with precise control over domain size and film continuity remains challenging. Herein, we report a physical vapor deposition (PVD)-assisted chemical vapor deposition (CVD) strategy for the controllable growth of high-quality monolayer MoS₂. By thermally evaporating an ultrathin (3 nm) MoO₃ precursor film, spontaneous post-deposition dewetting yields a porous honeycomb morphology that significantly enhances vapor–solid reaction kinetics during subsequent sulfurization. Crucially, by modulating the argon carrier gas flow rate to regulate the local sulfur chemical potential, we achieve distinct growth regimes: a high flow rate (70 sccm) suppresses nucleation density, enabling isolated triangular and hexagonal single crystals with lateral dimensions up to 500 μm, whereas a reduced flow rate (50 sccm) promotes high-density nucleation and coalescence into continuous centimeter-scale polycrystalline films. Comprehensive structural and optical characterizations, including atomic force microscopy, Raman spectroscopy, photoluminescence, and X-ray photoelectron spectroscopy, confirm that the synthesized MoS₂ exhibits prototypical monolayer thickness (~0.7 nm), well-defined local crystallinity and a direct bandgap emission at 1.84 eV. This work establishes a robust, scalable, and highly tunable route for synthesizing large-area 2D TMDs tailored for advanced device integration. Full article

This work presents advanced binder-free self-assembling Zn nanowire anodes synthesized by an easy-to-handle one-step low-pressure physical vapor deposition method. The morphology and structure of zinc nanowire networks are controlled and altered by the substrate temperature during deposition. Electrochemical performance of two types of Zn nanowire network samples of different morphology is studied in alkaline and mildly acidic aqueous electrolytes using cyclic voltammetry and electrochemical impedance spectroscopy techniques and compared to that of Zn foil electrodes. It is found that the morphology and structure of the Zn nanowire electrodes are directly related to their electrochemical performance and can be tuned for the type and concentration of the electrolyte to reach optimal electrochemical performance. The resulting binder-free self-assembled Zn nanowire anodes significantly outperform traditional Zn-based electrodes in both mild acidic and alkaline electrolytes, showing an areal capacitance of ~3.3 F/cm² and 3.5 F/cm² for acidic and alkaline electrolytes, respectively, and stability up to 1000 h of cycling in mild acidic electrolytes. These findings provide a pathway to fabricate and optimize binder-free zinc anodes for a variety of efficient and long-lasting aqueous zinc-based batteries and supercapacitors. Full article

Controlling deposition parameters is fundamental to obtaining the desired properties of cathodic arc physical vapor deposition (PVD) coatings. Achieving uniform coatings on tools with complex, sharp geometries remains a significant challenge due to localized ion flux concentration. Pulsing the substrate bias is an effective way of controlling deposition energy. However, while widely used in cathodic arc PVD, the relationship between the actual bias waveform, coating integrity on sharp tool geometries, and resulting machining performance has not been systematically established. This study investigates the effect of pulsed bias duty cycle (20% to 90%) and frequency (1 to 20 kHz) on the microstructural evolution, residual stress state, and machining performance of AlTiN coated tools. Real-time oscilloscope measurements demonstrated that system inductance and capacitance significantly distort the ideal bias waveform. Microstructural analysis via Focused Ion Beam/Scanning Electron Microscopy (FIB/SEM) cross-sectioning confirmed that all bias parameters generated a dense microstructure. While pulse frequency had no significant influence on micromechanical properties or residual stress states, the duty cycle was the dominant variable. High-energy deposition (90% duty cycle) increased hardness to 33.9 GPa but generated severe compressive residual stresses (−5.2 GPa). This extreme compressive stress led to catastrophic edge delamination on sharp solid carbide endmills. Conversely, a low-energy 20% duty cycle generated a coating with lower hardness (29.4 GPa) and a near-neutral stress state (0.5 GPa), effectively preserving the edge integrity. Unlike the endmills, the turning inserts maintained their edge integrity across all deposition conditions. During the high-speed (350 m/min) dry turning of AISI 304 stainless steel, all evaluated coatings exhibited comparable tool life and cutting forces. Wear progression was characterized by rake cratering, combined with abrasion and adhesion-induced attrition on the flank. The results indicate that tool life in this extreme environment is governed primarily by high-temperature thermo-chemical stability rather than initial room-temperature hardness. Lower-energy pulsed bias deposition therefore represents a robust strategy for coating a wide range of tool geometries, delivering equivalent high-speed machining performance while preventing stress-induced delamination on sharp features. Full article

Since the first successful synthesis of borophene in 2015, this atomically thin boron allotrope has attracted extensive attention due to its polymorphic structures, metallic conductivity, and outstanding mechanical flexibility. As a new member of the two-dimensional (2D) materials family, borophene exhibits a unique triangular lattice with tunable hexagonal vacancies, leading to rich structural diversity and anisotropic physical properties. Recent breakthroughs in synthesis—particularly molecular beam epitaxy (MBE), chemical vapor deposition (CVD), and solvothermal-assisted liquid-phase exfoliation (S-LPE)—have significantly expanded the accessible structural phases and improved control over film quality and stability. Meanwhile, borophene’s distinctive combination of structural and electronic characteristics has enabled its rapid development in both energy and biomedical applications. In energy storage, borophene serves as a promising anode material for lithium/sodium-ion batteries and a lightweight medium for hydrogen storage and supercapacitors, owing to its metallic conductivity, high surface charge density, and large adsorption capacity. In biomedicine, borophene-based nanoplatforms exhibit excellent photothermal conversion efficiency, enabling multifunctional roles in cancer diagnosis and therapy. Despite these advances, several challenges—such as environmental instability, oxidation susceptibility, and limited scalable synthesis—continue to restrict practical implementation. Future progress will depend on chemical functionalization, surface passivation, and machine-learning-assisted materials design to achieve oxidation-resistant, large-area, and biocompatible borophene derivatives. This review summarizes recent advances in borophene synthesis, structural engineering, and multifunctional applications, while outlining key scientific challenges and future opportunities for the realization of borophene-based materials in next-generation energy and biomedical systems. Full article

The development of fusion technology requires materials that can withstand heat, erosion, and activation at the edge of fusion plasma. Thanks to its high melting point, superior thermal conductivity, and excellent resistance to sputtering and retention, tungsten (W) has been regarded as the leading candidate for the plasma-facing materials (PFMs) of the main chambers and divertors in controlled thermonuclear fusion reactors. Nevertheless, W-PFMs are prone to complex severe surface deterioration under extreme service conditions during operation in fusion reactors. This includes physical/chemical sputtering, which results in material loss and plasma contamination; He-induced blistering and fuzz formation, which reduce thermal conductivity by several orders of magnitude; thermal fatigue cracking caused by transient loads; and neutron irradiation embrittlement, which leads to hardening, swelling, and loss of ductility. To overcome these issues while maintaining core thermophysical properties, protective surface layers have been fabricated primarily via chemical vapor deposition (CVD), physical vapor deposition (PVD), and spray and plasma-based surface modification technologies. This review assesses the recent progress in the fabrication of protective surface layers on W for PFM application in fusion reactors from a technical perspective, thereby offering new insights that advance the feasibility of fusion reactors and accelerating the practical realization of sustainable fusion energy systems. Full article

To simulate the erosion damage behavior of thermal barrier coatings (TBCs) under actual service conditions in an aircraft engine environment, this study developed a multi-factor coupled test setup capable of simulating combined loading under high-temperature (1150 °C), high-speed (0.4 Mach), and solid-particle erosion conditions. Yttria-stabilized zirconia (YSZ) TBCs were prepared using electron beam physical vapor deposition (EB-PVD). For different erosion durations (2 h, 5 h, 8 h, 12 h), the evolution of macroscopic and microscopic morphologies as well as the development of residual stresses in the thermally grown oxide (TGO) layer were systematically investigated. The results indicate that the erosion process of the YSZ coating can be divided into three stages. During the initial high-erosion-rate stage (8.17 g/kg), erosion damage was confined to the grain tips of the columnar crystals, primarily caused by brittle fracture at the grain tips, and the TGO stress was relatively low (−0.6 GPa). During the intermediate stage, the erosion rate was lower (2.74 g/kg). Impact stresses induced microcracks within the columnar grains, which gradually connected to form intergranular fractures. This led to the expansion of localized spalling pits. The interface began to wrinkle, and the stress rose to −2.2 GPa. In the final accelerated failure stage (5.88 g/kg), horizontal cracks fully propagated, leading to large-scale peeling of the coating. The stress was released to −0.9 GPa. The coating failure mechanism evolves from surface damage to interfacial peeling, which is closely related to the coating structure, stress evolution, and interfacial state. Full article

In the post-Moore era, large-area manufacturing of high-quality two-dimensional (2D) materials remains a central bottleneck for the industrialization of next-generation microelectronic and optoelectronic devices. Conventional mechanical exfoliation is limited by randomness and small lateral size, whereas chemical vapor deposition inevitably introduces grain boundaries, stress, and interfacial contamination, making it difficult to achieve both high quality and scalability. Metal-assisted exfoliation (MAE) enables controllable exfoliation and nondestructive transfer of large-area, high-quality monolayer 2D materials via precise modulation of metal-2D interfacial interactions dominated by strain-induced decoupling and atomic intercalation. This article systematically outlines the interfacial physical mechanisms and technological evolution of MAE, and highlights its state-of-the-art applications in patterned transfer, high-performance field-effect transistors, and complementary logic circuits, aiming to provide a firm theoretical and technical basis for advancing 2D materials from fundamental research toward practical applications. Full article

Zinc oxide (ZnO) is currently one of the most significant wide-bandgap semiconductor materials, attracting extensive research across diverse fields including materials science, chemistry, physics, medicine, electronics, and power engineering. Its exceptional properties, such as high optical transparency, high electron mobility, chemical stability, and compatibility with low-cost fabrication techniques, have established ZnO as a versatile material with immense application potential. A critical application for ZnO is its role as a transparent conducting oxide (TCO) in modern optoelectronic and photovoltaic devices, as well as in sensors, transparent electronics, and spintronics. To meet the requirements of these advanced applications, precise control over the structural, optical, and electrical properties of ZnO thin films is essential. This is effectively achieved through the selection of specific synthesis methods and intentional modification techniques, such as doping. This review provides a comprehensive overview of the synthesis and modification of ZnO thin films, with a particular focus on how various dopants influence their fundamental characteristics. The work discusses a range of deposition techniques, including physical vapor deposition (PVD), chemical vapor deposition (CVD), atomic layer deposition (ALD), sol–gel methods, spray pyrolysis, and other solution-based approaches. The novelty of this review lies in its comparative analysis of different doping strategies combined with various thin-film deposition techniques, highlighting how specific synthesis routes influence dopant incorporation and ultimately determine functional properties. Furthermore, recent advances in tailoring ZnO thin films are summarized, alongside the identification of key challenges and future research directions. Ultimately, this work aims to provide researchers with a systematic perspective on the synthesis–structure–property relationships in doped ZnO thin films to support the development of optimized materials for next-generation electronic and optoelectronic devices. This review, thus, serves as a comprehensive reference for researchers and engineers seeking to optimize the functionality of ZnO-based thin films for emerging technological applications. Full article

The threshold voltage (Vth) of p-GaN gate enhancement-mode (E-mode) high electron mobility transistors (HEMTs) on silicon substrates grown by metal–organic chemical vapor deposition (MOCVD) is often limited to 1.0–1.5 V. Apart from the low Mg acceptor activation rate, the non-uniform vertical Mg distribution in thin p-GaN layers is also a key bottleneck limiting Vth. This work reveals that the vertical distribution (not only magnitude) of Mg doping fundamentally influences Vth by modulating the charge centroid and electric field coupling to the heterointerface. Through bis(cyclopentadienyl)magnesium (Cp₂Mg) flow modulation, surfactant-assisted growth, and growth rate adjustment, the vertical Mg doping uniformity within the 80 nm p-GaN layer was improved while effectively suppressing Mg out-diffusion. A short-cycle gate-first self-aligned process was used to fabricate the devices, and the results showed that the improved Mg vertical distribution led to a significant Vth enhancement by 0.75 V. Technology Computer-Aided Design (TCAD) simulations further demonstrated that the uniform doping profile builds a stronger negative space charge field beneath the gate, raising the energy band and increasing Vth. This work not only presents practical strategies, but also establishes a direct physical link between vertical Mg doping distribution and Vth in Si-based E-mode HEMTs. Full article

Titanium alloys exhibit exceptional strength-to-density ratios, high hardness, and outstanding resistance to elevated temperatures, making them indispensable structural materials in aerospace engineering, marine construction, and biomedical applications. In aerospace systems specifically, fatigue failure represents the predominant failure mode for titanium alloy components. This review systematically examines prevalent surface treatment techniques for titanium alloys—including shot peening, ultrasonic rolling treatment, hot isostatic pressing (HIP), physical vapor deposition (PVD), micro-arc oxidation (MAO), and thermal spray processes—and critically evaluates their respective effects on fatigue performance. The underlying mechanisms of each technique are concisely outlined, with emphasis on stress state evolution, near-surface microstructural refinement, and interfacial integrity. Building upon the characteristic surface-dominated fatigue fracture behavior of titanium alloys, this work focuses on how coating composition, architecture (e.g., graded, multilayer, or nanocomposite designs), and interfacial bonding strength govern fatigue resistance. A unified analysis is presented on the distinct yet complementary roles of substrate deformation strengthening (e.g., residual compression, grain refinement) and coating-mediated protection (e.g., barrier function, crack deflection, stress redistribution) during fatigue crack initiation and propagation. Key determinants of fatigue performance, including residual stress distribution, coating/substrate adhesion, thermal mismatch, and environmental degradation susceptibility, are rigorously assessed. Finally, emerging research frontiers are identified, including intelligent process–structure–property mapping, in situ monitoring of fatigue damage at coated interfaces, and design of multifunctional gradient coatings that synergistically enhance strength, wear resistance, and fatigue endurance of titanium alloy components. Full article

Indium Tin Oxide (ITO) is one of the most widely used ohmic materials for fabricating ohmic layers in thin-film solar cells. ITO thin layers have reached almost the maximum theoretical conductivity and the lowest practical resistivity. Along with indium’s toxic environmental impact and the high cost of materials, these are the reasons why new materials for efficient, cheaper thin-film transparent ohmic layers are being examined. One of those materials is copper-doped zinc oxide (ZnO:Cu). In this paper, we present a new approach to copper-doped zinc oxide fabrication methods, based on the modern authorial Physical Vapor Co-Deposition technique, which involves optimizing Cu concentration to fine-tune crystal structure, optical band gap, and electrical properties, creating n-type TCOs essential for efficient charge transport in next-generation thin films perovskite solar cells. Full article
