Upgrading existing hydropower plants into pump storage using pump-turbines is an economical approach to increasing energy storage capacity. Installing an additional pump at the pump-turbine outlet can improve cavitation performance and reduce submergence requirements. The present work proposes a methodology for designing an axial flow pump for such retrofitting applications. A classical method available in the literature was used for establishing the global parameters and boundary conditions of the pump design. The method was automated using a Python 3.13 script to handle a wide range of design parameters. The design output was verified with five different cases covering a wide operational range, from low to high specific speed axial pumps. The results met the required performance criteria, with deviations in head prediction ranging from 0.28 to 1.70 m for most cases. The estimated maximum error was 20% for the mid-range of specific speeds, and the largest deviations were observed for the extreme design conditions. These deviations under extreme specific speeds can be attributed to the limitation of the underlying empirical correlations, which are primarily developed for a typical axial pump. Therefore, further refinement or robust optimization is necessary for reliable application under such extreme conditions. Overall, the verification clearly demonstrated the potential to produce geometrically consistent and hydraulically reasonable designs. The adapted design approach provides good confidence and will provide baseline designs for the booster pump in retrofitted hydropower plants. Full article

The ramping requirement in new power systems primarily stems from net load variations and forecast errors of renewable energy and load. Designing an equitable cost allocation mechanism for ramping services based on these factors facilitates incentives for generation and load to actively reduce ramping demands, thereby alleviating system ramping pressure. Accordingly, this paper proposes a fair ramping cost allocation mechanism based on the ramping responsibility coefficients of market participants. Under this mechanism, a market-oriented operation model for wind–hydro-storage joint operation is established to verify its effectiveness in market applications. First, a ramping cost allocation mechanism is constructed based on ramping responsibility coefficients. According to the responsibility coefficients of market participants for deterministic and uncertain ramping requirements, ramping costs are allocated to the corresponding contributors in proportion to the ramping demands caused by net load variations, load forecast deviations, and renewable energy forecast deviations. Specifically, for costs arising from renewable energy forecast errors, an allocation mechanism is designed based on the difference between the declared error range and the actual error. Second, within this allocation framework, hydropower and storage (including cascade hydropower and hybrid pumped storage) are utilized as flexible resources to mitigate wind power uncertainty and reduce its ramping costs. A two-stage day-ahead and real-time bi-level game model for wind–hydro-storage cooperative decision-making is developed. The upper level optimizes bilateral trading and market bidding strategies for wind–hydro-storage, while the lower level simulates the market clearing process. Through Stackelberg game modeling, joint optimal operation of wind–hydro-storage is achieved, ensuring mutual benefits. Finally, simulation results validate that the proposed ramping cost allocation mechanism can guide renewable energy to improve output controllability through economic signals. Furthermore, the bilateral trading and coordinated market participation of wind–hydro-storage realize win–win outcomes, reduce the ramping cost allocation for wind power by 23.10%, effectively narrow peak-valley price differences, and enhance market operational efficiency. Full article

Multi-regional electricity markets increasingly struggle to balance data privacy requirements with the computational burden of centralized clearing. To address this issue, this study proposes a distributed joint-clearing framework based on the Alternating Direction Method of Multipliers (ADMM) to co-optimize pumped storage hydropower (PSH) and battery energy storage systems (BESS) across energy, frequency regulation, and reserve markets. A mixed-integer programming model is formulated to maximize social welfare, explicitly capturing the time-coupled, energy-oriented characteristics of PSH and the fast-response, power-oriented capabilities of BESS. The global problem is decomposed into regional subproblems that can be solved in parallel. An adaptive penalty parameter strategy is further introduced to dynamically balance primal and dual residuals, thereby improving convergence and robustness in the mixed-integer setting. To address the limited economic interpretability of dual variables in mixed-integer programming (MIP) models, an approximate marginal pricing mechanism based on subproblem sensitivity analysis is proposed. A two-region, 24 h case study shows that the proposed method converges in around 65 iterations and achieves a social welfare outcome within 0.61% of the centralized optimum. By minimizing information exchange, the framework offers a scalable and privacy-aware solution for future multi-regional market operations involving heterogeneous energy storage resources. Full article

This review synthesizes recent progress in modern energy storage technologies and proposes a selection-oriented comparison for power-system stabilization. Technologies are grouped into electrochemical, mechanical, chemical, and thermal storage, and evaluated using harmonized criteria (power and energy capability, response time, round-trip efficiency, lifetime, cost proxies, and maturity level). A comparative dataset and use-case mapping are used to link technology characteristics to grid services, with emphasis on voltage support, operational durability, and waste-heat utilization. The analysis highlights pumped-storage hydropower as the most robust option for long-duration, high-capacity applications, while battery energy storage systems are best suited for fast ancillary services, provided that cycle life, safety, and system integration constraints are met. Finally, the review discusses current technology trends (e.g., LFP and sodium-ion deployment, solid-state development, and commercialization barriers for lithium-sulfur) and identifies evidence-based directions for future research and deployment. Full article

Hybrid renewable energy systems (HRESs), mixing conventional and renewable power sources and occasionally storage units, have become the norm regarding electricity generation. Robust long-term planning of such systems requires stakeholders to test different layouts and system configurations, while their operational management relies on forecasting surpluses and deficits to achieve optimal decision making. However, both tasks, which in fact constitute a flow allocation problem across power networks, are subject to multiple peculiarities, arising from the nonlinear dynamics of the underlying processes, subject to numerous technical and operational constraints. Interestingly, a mutual problem emerges in water resource systems, also comprising network-type storage, abstraction and conveyance components. In this vein, triggered from well-established simulation approaches from the water domain, we introduce a generic (i.e., topology-free) and time-agnostic framework, the key methodological elements of which are: (a) the graph-based representation of the power fluxes; (b) the effective handling of energy uses and constraints through virtual nodes and edges; (c) the implementation of priorities via proper assignment of virtual costs across all graph components; and (d) the configuration of the overall problem as a network linear programming context, which allows the use of exceptionally fast solvers. Specific adjustments are required to address highly complex issues within HRESs, particularly the representation of conventional thermal and pumped-storage hydropower units, as well as the power losses across transmission lines. The modeling approach is stress-tested by means of configuring a hypothetical HRES in a non-interconnected Aegean island, i.e., Sifnos, Greece. Full article

Despite the growing adoption of hybrid energy systems integrating solar photovoltaic (PV), pumped storage hydropower (PSH), and battery energy storage (BES), comprehensive studies on their dynamic stability and interaction mechanisms remain limited, particularly under weak grid conditions. Due to the high impedance of weak grids, ensuring stability across varied operating scenarios is crucial for advancing grid resilience and energy reliability. This paper addresses these research gaps by examining the interaction dynamics between PV, PSH, and BES on the DC side and the utility grid on the AC side. The study identifies operating-region-dependent instability mechanisms arising from negative incremental resistance behavior and weak grid interactions and proposes a virtual-impedance-based active damping control strategy to suppress poorly damped oscillatory modes. The proposed controller effectively reshapes the converter output impedance, shifts unstable eigenmodes into the left-half plane, and improves phase margins without requiring additional hardware components or introducing steady-state power losses. System stability is analytically assessed using root-locus, Bode, and Nyquist criteria within a developed small-signal state-space model, and further validated through large-signal real-time simulations on an OPAL-RT platform. The main contributions of this study are threefold: (i) a comprehensive stability analysis of a utility-scale grid-connected hybrid PV–PSH–BES system under weak grid conditions, (ii) identification of operating-region-dependent instability mechanisms associated with DC–link interactions, and (iii) development and real-time validation of a practical virtual-impedance-based active damping strategy for enhancing system stability and grid integration reliability. Full article

Against the backdrop of the carbon peaking and neutrality (“dual-carbon”) goals and evolving new-type power system dispatch, the share of pumped-storage hydropower (PSH) in power systems continues to increase, imposing stricter requirements on units for higher cycling frequency, greater operational flexibility, and rapid, stable startup and shutdown. Focusing on the entire hot-standby-to-generation transition of a PSH plant, a full-flow-path three-dimensional transient numerical model encompassing kilometer-scale headrace/tailrace systems, meter-scale runner and casing passages, and millimeter-scale inter-component clearances is developed. Three-dimensional unsteady computational fluid dynamics are determined, while the surge tank free surface and gaseous phase are captured using a volume-of-fluid (VOF) two-phase formula. Grid independence is demonstrated, and time-resolved validation is performed against the experimental model–test operating data. Internal instability structures are diagnosed via pressure fluctuation spectral analysis and characteristic mode identification, complemented by entropy production analysis to quantify dissipative losses. The results indicate that hydraulic instabilities concentrate in the acceleration phase at small guide vane openings, where misalignment between inflow incidence and blade setting induces separation and vortical structures. Concurrently, an intensified adverse pressure gradient in the draft tube generates an axial recirculation core and a vortex rope, driving upstream propagation of low-frequency pressure pulsations. These findings deepen our mechanistic understanding of hydraulic transients during the hot-standby-to-generation transition of PSH units and provide a theoretical basis for improving transitional stability and optimizing control strategies. Full article

The rapid development of renewable energy has highlighted the issue of its accommodation, which has become a critical challenge for power grids with high renewable energy penetration. Accurately assessing a grid’s renewable energy accommodation capability is essential for ensuring power grid operational security, as well as for the rational planning and efficient operation of renewable energy sources and adjustable power resources. This paper adopts a long-term chronological power balance simulation approach, integrating the dynamic balance among multiple types of power sources, loads, and outbound transmission. Dispatch schemes suitable for different types of power sources, including hydropower, thermal power, wind power, solar power, and nuclear power, were designed based on their operational characteristics. Key operational constraints, such as output limits, staged water levels, pumping/generation modes of pumped storage, and nuclear power regulation duration, were considered. A refined analysis model for renewable energy accommodation in regional power grids was constructed, aiming to maximize the total accommodated renewable energy electricity. Using actual data from the Northeast China Power Grid in 2024, the model was validated, showing results largely consistent with actual accommodation conditions. Analysis based on next-year forecast data indicated that the renewable energy utilization rate is expected to decline to 90.6%, with the proportion of curtailment due to insufficient peaking capacity and grid constraints expanding to 8:2. Sensitivity analysis revealed a clear correlation between the renewable energy utilization rate and the scale of newly installed renewable capacity and energy storage. It is recommended to control the expansion of new renewable energy installations while increasing the construction of flexible power sources such as pumped storage and other energy storage technologies. Full article

This study investigates the optimization of Pumped Storage Hydropower (PSH) integrated with Floating Photovoltaic (FPV) systems, with a focus on sustainable energy management. A nonlinear programming framework combined with scenario analysis was applied to a real hydropower system in Trentino, Italy. The optimization maximizes revenues through energy arbitrage while accounting for water resource and environmental objectives. Upgrading the traditional hydropower plant to PSH operation increases revenues by 4–8% over two hydrological years. Multi-objective optimization further reveals large gains in water availability, confirming PSH’s dual role as energy storage and water management infrastructure. Different FPV configurations analyzed show a 2–3% increase in photovoltaic energy yield due to the water-cooling effect, while the overall hybrid PSH–FPV integration mainly reduces grid dependency and pumping-related emissions, with near-complete decarbonization achievable under optimized scheduling. Overall, PSH provides the primary economic and operational advantage, while FPV strengthens sustainability, enabling resilient hydro–solar operation and contributing to renewable integration and decarbonization in future energy systems. Full article

The fluctuating nature of renewable energy sources such as wind and solar power poses significant challenges to the stability of power grids, while pumped-storage hydropower, with its advantages in peak regulation and frequency control, has become an essential component of modern energy strategies. However, sediment in rivers adversely affects the operational efficiency and stability of PSH units, leading to accelerated wear and shortened service life. In this study, the low-pressure stage of a two-stage pump turbine was selected as the research object, and the Euler–Euler numerical method was employed to investigate the solid–liquid two-phase flow characteristics of the pump turbine in pump mode. The results show that, compared with the clear-water condition, the head and efficiency decrease by up to 7.9% and 15%, respectively, after the addition of sand particles. The average pressure within the flow-passage components increases, while the streamlines become more non-uniform, accompanied by the formation of vortices and backflow in the guide and return vanes. The total entropy generation increases with rising particle concentration but decreases with larger particle size. Among the components, the high-entropy regions are mainly located on the suction surface and trailing edges of the impeller blades, the inlet and blade surfaces of the guide vanes, and the inlet and trailing edges of the return vanes. Moreover, the pressure pulsation amplitudes at monitoring points in the vaneless region, guide vane–return vane interaction region, and leading edge of the return vane increase progressively with both particle size and concentration. The dominant and secondary frequencies at all monitoring points correspond to the blade-passing frequency (BPF) and its harmonics, indicating that rotor–stator interaction is the principal cause of pressure pulsations under pump operating conditions. Full article

Under the global imperative for climate action and sustainable development, accelerating the transition towards high-penetration renewable energy systems remains a universal priority, central to achieving the United Nations Sustainable Development Goals. However, the inherent uncertainty and volatility of renewables such as wind and solar PV pose fundamental challenges to power system stability and flexibility worldwide. These challenges, if unaddressed, could significantly hinder the reliable and sustainable integration of clean energy on a global scale. While pumped storage hydropower (PSH) represents a mature, large-scale solution for enhancing system regulation capabilities, existing planning methodologies frequently suffer from critical limitations. These included oversimplified scenario representations—particularly the inadequate consideration of escalating extreme weather events under climate change—and computational inefficiencies in solving large-scale stochastic optimization models. These shortcomings ultimately constrained the practical value of such approaches for advancing sustainable energy planning and building climate-resilient power infrastructures globally. To address these issues, this paper proposed a bi-level stochastic planning method integrating scenario optimization and improved Benders decomposition. Specifically, an integrated framework combining affinity propagation clustering and isolation forest algorithms was developed to generate a comprehensive scenario set that covered both typical and anomalous operating days, thereby capturing a wider range of system uncertainties. A two-layer stochastic optimization model was established, aiming to minimize total investment and operational costs while ensuring system reliability and renewable integration. The upper layer determined PSH capacity, while the lower layer simulated multi-scenario system operations. To efficiently solve the model, the Benders decomposition algorithm was enhanced through the introduction of a heuristic feasible cut generation mechanism, which strengthened subproblem feasibility and accelerated convergence. Simulation results demonstrated that the proposed method achieved a 96.7% annual renewable energy integration rate and completely avoided load shedding events with minimal investment cost, verifying its effectiveness, economic efficiency, and enhanced adaptability to diverse operational scenarios. Full article

The transition toward renewable-dominated power systems is increasingly constrained by the shortage of flexible regulation resources. Hydropower, with its rapid response and strong load-adjustment capability, remains a cornerstone for enabling large-scale integration of intermittent wind and solar energy. Splitter-blade runners are widely employed in medium- and high-head conventional hydropower plants and pumped-storage stations due to their broad high-efficiency operating range and superior stability. In this study, based on a runner replacement project at an existing hydropower station, refined computational fluid dynamics (CFD) simulations were carried out to design a splitter-blade runner under strict dimensional constraints. The optimized runner expanded the unit’s stable operating range from 50–100% to 0–100% rated power, while also improving overall efficiency and reducing pressure pulsations. The optimized splitter-blade runner improved efficiency by 1–2%, reduced pressure pulsations in the draft tube by ≈25%, and decreased the runner radial force by ≈12% compared with the baseline configuration. Importantly, this work demonstrates for the first time that splitter-blade runners can be successfully applied at head ranges below 100 m, thereby extending their applicability beyond traditional limits. The results provide both theoretical and practical guidance for flexibility retrofits of existing Francis turbine units in China, offering a feasible pathway to support the adaptability of future renewable energy systems. Full article

The role of sedimentary heterogeneity in reactive transport processes is becoming increasingly important as closed open-pit lignite mines are converted into post-mining lakes or pumped hydropower storage reservoirs. Flooding of the open pits introduces constant oxygen-rich inflows that reactivate pyrite oxidation within internal mine dumps. A reactive transport model coupling groundwater flow, advection–diffusion–dispersion, and geochemical reactions was applied to a 2D cross-section of a water-saturated mine dump to determine the processes governing pyrite oxidation. Spatially correlated fields representing permeability and pyrite distributions were generated via exponential covariance models reflecting the end-dumping depositional architecture, supported by a suite of scenarios with systematically varied correlation lengths and variances. Simulation results covering a time span of 100 years quantify the impact of heterogeneous permeability fields that result in preferential flow paths, which advance tracer breakthrough by ~15 % and increase the cumulative solute outflux up to 139 % relative to the homogeneous baseline. Low initial pyrite concentrations (0.05 wt %) allow for deeper oxygen penetration, extending oxidation fronts over the complete length of the modeling domain. Here, high initial pyrite concentrations (0.5 wt %) confine reactions close to the inlet. Kinetic oxidation allows for more precise simulation of redox dynamics, while equilibrium assumptions substantially reduce the computational time (>10×), but may oversimplify the redox system. We conclude that reliable risk assessments for post-mining redevelopment should not simplify numerical models by assuming average homogeneous porosity and mineral distributions, but have to incorporate site-specific spatial heterogeneity, as it critically controls acid generation, sulfate mobilization, and the timing of contaminant release. Full article

China has witnessed extensive construction of underground powerhouses for pumped storage power stations. With the continuous increase in unit capacity, vibration problems have become particularly pronounced. Intense vibrations may not only disrupt the normal operation of hydropower units but also compromise the overall structural safety of the powerhouse. Moreover, in dynamic analyses of powerhouse structures, different parameters exert varying degrees of influence on the results, making it essential to systematically examine their impacts. This study focuses on a large-scale underground powerhouse, establishing a three-dimensional finite element model of Unit #1 to investigate its dynamic characteristics and parametric sensitivity. Through modal and harmonic response analyses, the effects of key parameters—including the zone of surrounding rock, elastic modulus of surrounding rock, dynamic elastic modulus of concrete, and damping ratio—were systematically evaluated. Results indicate that an expanded surrounding rock zone reduces natural frequency and increases dynamic displacement, with a zone twice the span length offering an optimal balance between accuracy and computational efficiency. Increasing the elastic modulus of the surrounding rock raises the natural frequency and slightly reduces displacement, while having a limited impact on dynamic stress. The dynamic elastic modulus of concrete shows a square-root relationship with natural frequency and an inverse correlation with dynamic displacement. The damping ratio has negligible influence on natural frequency, dynamic displacement, and dynamic stress. These findings provide a theoretical basis and practical guidance for parameter selection in the dynamic analysis of underground powerhouse structures, enhancing the reliability of numerical simulations. Full article

A novel pumped storage system using centrifugal pumps to transfer water between reservoirs in coastal hydropower plants has significantly mitigated grid instability. However, frequent start–stop operations of large vertical centrifugal pumps, which serve as the core equipment, severely affect the operational stability of these systems. In this study, the intrinsic connection between the cavitating flow field and irreversible losses during the process was analyzed using the entropy production theory. The time–frequency characteristics of pressure pulsation in pump were analyzed by using the continuous wavelet transform. The results indicate that with the reduction in the flow rate and rotational speed, the sheet cavitation at the impeller inlet rapidly weakens until it vanishes. The cavity cavitation within the draft tube commences to emerge in the turbine mode. Separation vortices are formed due to the mismatch in the flow angle at the impeller outlet. These vortices induce local cavitation, causing both a rapid energy loss increase and high-amplitude, low-frequency pressure pulsations. During transient processes, flow instabilities induce high-amplitude, low-frequency pressure pulsations within the stay vane region, with maximum amplitude attained during runaway condition. The research results provide a theoretical foundation for the stable operation of centrifugal pumps. Full article
