In order to establish a transferring chain from a photon flux of a single-photon source in quantum radiometry, the nonlinearity of the photodetector needs to be accurately measured. Using the flux superposition method, a nonlinearity measurement setup has been designed. The measurement setup consists of two tungsten halogen lamps, parent–child integrating spheres, an adjustable aperture, a diaphragm tube, and an optical filter. It has the advantage of low polarization error, low interference error, and low stray light effect. The Si photodiode to be measured is cooled to −40 °C to obtain a low noise level for low-flux radiation measurement. The nonlinearity of the Si photodetector is measured for photocurrent ranges from 10⁻¹² A~10⁻⁶ A level, with a relative standard uncertainty from 0.0092~0.023%. The relative standard uncertainty of the nonlinearity correction factor ranged from 0.023~0.049%. Full article

We performed a systematic study involving simulation and experimental techniques to develop induced-junction silicon photodetectors passivated with thermally grown SiO₂ and plasma-enhanced chemical vapor deposited (PECVD) SiN_x thin films that show a record high quantum efficiency. We investigated PECVD SiN_x passivation and optimized the film deposition conditions to minimize the recombination losses at the silicon–dielectric interface as well as optical losses. Depositions with varied process parameters were carried out on test samples, followed by measurements of minority carrier lifetime, fixed charge density, and optical absorbance and reflectance. Subsequently, the surface recombination velocity, which is the limiting factor for internal quantum deficiency (IQD), was obtained for different film depositions via 2D simulations where the measured effective lifetime, fixed charge density, and substrate parameters were used as input. The quantum deficiency of induced-junction photodiodes that would be fabricated with a surface passivation of given characteristics was then estimated using improved 3D simulation models. A batch of induced-junction photodiodes was fabricated based on the passivation optimizations performed on test samples and predictions of simulations. Photodiodes passivated with PECVD SiN_x film as well as with a stack of thermally grown SiO₂ and PECVD SiN_x films were fabricated. The photodiodes were assembled as light-trap detector with 7-reflections and their efficiency was tested with respect to a reference Predictable Quantum Efficient Detector (PQED) of known external quantum deficiency. The preliminary measurement results show that PQEDs based on our improved photodiodes passivated with stack of SiO₂/SiN_x have negligible quantum deficiencies with IQDs down to 1 ppm within 30 ppm measurement uncertainty. Full article

Climate observations and their applications require measurements with high stability and low uncertainty in order to detect and assess climate variability and trends. The difficulty with space-based observations is that it is generally not possible to trace them to standard calibration references when in orbit. In order to overcome this problem, it has been proposed to deploy space-based radiometric reference systems which intercalibrate measurements from multiple satellite platforms. Such reference systems have been strongly recommended by international expert teams. This paper describes the Chinese Space-based Radiometric Benchmark (CSRB) project which has been under development since 2014. The goal of CSRB is to launch a reference-type satellite named LIBRA in around 2025. We present the roadmap for CSRB as well as requirements and specifications for LIBRA. Key technologies of the system include miniature phase-change cells providing fixed-temperature points, a cryogenic absolute radiometer, and a spontaneous parametric down-conversion detector. LIBRA will offer measurements with SI traceability for the outgoing radiation from the Earth and the incoming radiation from the Sun with high spectral resolution. The system will be realized with four payloads, i.e., the Infrared Spectrometer (IRS), the Earth-Moon Imaging Spectrometer (EMIS), the Total Solar Irradiance (TSI), and the Solar spectral Irradiance Traceable to Quantum benchmark (SITQ). An on-orbit mode for radiometric calibration traceability and a balloon-based demonstration system for LIBRA are introduced as well in the last part of this paper. As a complementary project to the Climate Absolute Radiance and Refractivity Observatory (CLARREO) and the Traceable Radiometry Underpinning Terrestrial- and Helio- Studies (TRUTHS), LIBRA is expected to join the Earth observation satellite constellation and intends to contribute to space-based climate studies via publicly available data. Full article

We propose a space benchmark sensor with onboard SI (Système International) traceability by means of quantum optical radiometry. Correlated photon pairs generated by spontaneous parametric down-conversion (SPDC) in nonlinear crystals are used to calibrate the absolute responsivity of a solar observing radiometer. The calibration is systematic, insensitive to degradation and independent of external radiometric standards. Solar spectral irradiance at 380–2500 nm is traceable to the photon rate and Planck’s constant with an expected uncertainty of about 0.35%. The principle of SPDC calibration and a prototype design of the solar radiometer are introduced. The uncertainty budget is analyzed in consideration of errors arising from calibration and observation modes. Full article
