Search Results (82)

To increase semiconductor production yield and meet the growing global demand, air bearings offering higher processing speeds and reduced friction losses have been proposed as an ideal solution. However, due to the non-contact support characteristic of air bearings, challenges such as shaft displacement caused by processing resistance inevitably arise. As an engineering requirement, the shaft must restrict lateral deflection to within 30 μm under transverse force. In our previous research, a compensation system using a nozzle–flapper mechanism as a displacement sensor was proposed to address shaft displacement. The effectiveness of the nozzle–flapper system in measuring shaft displacement was validated at rotational speeds up to 20,000 rpm. Furthermore, the compensation system’s ability to maintain the shaft’s initial position under a 5 N external force was verified in related collaborative research. In this study, building upon prior work, we further analyze the system characteristics of the cylindrical nozzle–flapper. This includes modeling the geometric space formed by the specific shape of the cylindrical flapper and nozzle and proposing an airflow hypothesis based on this geometry. The hypothesis is incorporated into the theoretical model of a standard nozzle–flapper system, resulting in an optimized theoretical method applicable to cylindrical configurations. Experimental results validating the effectiveness of the proposed model are also presented. Full article

The paper presents some design principles of an inductive displacement transducer for measuring the displacement of rock specimens under high hydrostatic pressure. It consists of a single-layer, coreless solenoid mounted directly onto the specimen and connected to an LC oscillator located outside the pressure chamber, in which it serves as the inductive component. The specimen’s deformation changes the coil’s length and inductance, thereby altering the oscillator’s resonant frequency. Paired with a reference coil, the system achieves strain resolution of ~100 nm at pressures exceeding 400 MPa. Sensor design challenges include both electrical parameters (inductance and resistance of the sensor, capacitance of the resonant circuit) and mechanical parameters (number and diameter of coil turns, their positional stability, wire diameter). The basic requirement is to achieve stable oscillations (i.e., a high Q-factor of the resonant circuit) while maintaining maximum sensor sensitivity. Miniaturization of the sensor and minimizing the tensile force at its mounting points on the specimen are also essential. Improvement of certain sensor parameters often leads to the degradation of others; therefore, the design requires a compromise depending on the specific measurement conditions. This article presents the mathematical interdependencies among key sensor parameters, facilitating optimized sensor design. Full article

This paper presents a novel diagnostic method that employs the fuel injection system as a sensor for monitoring internal combustion engine pressure, analysing series resistance to detect connector degradation, and evaluating needle movement within the injector’s magnetic core. Experimental results showed that reducing the injector needle opening from 100% to 20% of its maximum displacement caused up to a 35% reduction in peak current amplitude and a 0.2 ms delay in coil charging. Increasing fuel pressure from 0.3 bar to 2.5 bar resulted in a rise in peak current by approximately 35% and an extension of coil charging delay by 0.4 ms. Furthermore, increasing the series resistance from 0.2 Ω to 2.0 Ω reduced the current amplitude by nearly 50% and significantly distorted the waveform, simulating connector oxidation or wear. Comparative analysis of reference and fault current waveforms confirmed that variations in electrical parameters correlate with injector needle displacement, fuel pressure, and resistance changes. Finally, an automated diagnostic system was developed that achieved over 90% accuracy in independently detecting injector faults based on current waveform characteristics. Full article

In this study, the impacts of various grouting methods and volumes on the vertical bearing characteristics of model piles in clay strata were investigated through indoor static load tests on one ungrouted model pile and two model piles with grouting at the pile tip, as well as two model piles with distributed grouting at the pile tip and along the pile side. These tests were performed in conjunction with data obtained from optical fiber sensors that monitored changes in the internal forces of the pile body. The results indicate that, compared to the ungrouted model pile Z1, the ultimate bearing capacities of the grouted model piles Z2 to Z5 were increased by 83.9%, 175.0%, 125.0%, and 253.6%, respectively. Additionally, the displacements at the pile tops after failure reached 57.6%, 62.3%, 69.5%, and 73.5% that of the ungrouted model pile Z1. These results demonstrate that post-grouting can significantly enhance the ultimate bearing capacity of model piles and reduce settlement at the pile top. Under various loads, the axial force of the pile body decreases gradually with the increasing depth of the pile foundation and increases with the increasing load at the pile top. The increase in the ultimate average side friction resistance and ultimate tip resistance of the grouted model piles (i.e., Z2 to Z5), in comparison to the ungrouted pile, was positively correlated with the grouting volume at the pile tip and along the pile side. All five model piles displayed the characteristics of friction piles. Full article

This article analyzes the operating principle of the BMM sensor emitter in order to improve the accuracy of the wireless determination of the BMM sensor coordinates under a massif of destroyed rock in the context of the problem of determining the shift of rocks during gold ore mining. Using numerical simulations, FEM has been developed to develop digital models reflecting individual cases of the propagation of the magnetic field of the emitter located in various geological conditions and positions relative to the rock surface and the vertical axis. The accuracy of determining the coordinates of the radio beacon in the rock has been analyzed, and data on the deviation of the coordinates of the peaks of the magnetic field strength from the radio beacon axis have been obtained in cases of a heterogeneous composition of the rock massif, the influence of the deviation of the emitter axis angle from the vertical, the influence of the unevenness of the collapse relief, and the influence of the superposition of fields from different radiation sources. A study has been carried out to determine the direction of the radio beacon search based on the resulting vector of the emitter’s magnetic field strength. Full article

This study proposes a non-contact framework for evaluating the skid resistance of shared roadside pavements to improve cyclist and pedestrian safety. By integrating a friction tester and a laser scanner, we synchronize high-resolution three-dimensional (3D) surface texture characterization with friction coefficient measurements under dry and wet conditions. Key metrics—including fractal dimension (FD), macro/micro-texture depth density (HL_TX and WL_TX), mean texture depth (MTD), and joint dimensions—were derived from 3D laser scans. A hierarchical regression analysis was employed to prioritize the influence of texture and joint parameters on skid resistance across environmental conditions. Combined with material types (brick, tile, and stone) and drainage performance, these metrics are systematically analyzed to quantify their correlations with skid resistance. Results indicate that raised macro-textures and high FD (>2.5) significantly enhance dry-condition skid resistance, whereas recessed textures degrade performance. The hierarchical model further reveals that FD and MTD dominate dry friction (β = 0.61 and −0.53, respectively), while micro-texture density (WL_TX) and seam depth are critical predictors of wet skid resistance (β = −0.76 and 0.31). In wet environments, skid resistance is dominated by micro-texture density (WL_TX < 3500) and macro-texture-driven water displacement, with higher WL_TX values indicating denser micro-textures that impede drainage. The study validates that non-contact laser scanning enables efficient mapping of critical texture data (e.g., pore connectivity, joint depth ≥0.25 mm) and friction properties, supporting rapid large-scale pavement assessments. These findings establish a data-driven linkage between measurable surface indicators (texture, morphometry, drainage) and skid resistance, offering a practical foundation for proactive sidewalk safety management, especially in high-risk areas. Future work should focus on refining predictive models through multi-sensor fusion and standardized design guidelines. Full article

Piezoelectric materials (PZTs) enjoy extensive applications in the field of electromechanical sensors due to their sensitive response to external electric fields. The limited piezoelectric response for single-layer piezoceramic pellets drives the use of multilayered technology to increase the electric displacement of a single piezo device. As is well known, Ag is commonly used as a metal for electrodes in devices based on traditional PZTs, which always densify at a high temperature above 1100 °C, resulting in Ag migration. Here, a high-performance samarium-ion-doped Sm_0.01Pb_0.99(Zr_0.54Ti_0.46)O₃ ceramic was selected as parent materials to develop a new Ag-cofired ceramic matrix with a sintering temperature of 920 °C by glass flux. The ceramic composition with 2.0 wt% glass addition exhibits the excellent performance of piezoelectric d₃₃~492 pC/N, planar electromechanical coupling coefficient k_p~50.1%, mechanical quality factor Q_m~68.71, and Curie temperature T_c~356 °C, respectively. The cyclic stability of d₃₃ was measured below 6.6% at 30 kV/cm, which indicates that the piezoceramic has good temperature stability and fatigue resistance. Therefore, this study provides a novel high-performance piezoelectric system to meet the cofired requirement for multilayered piezoelectric devices. Full article

Direct wide-bandgap III-Ns and II-Os have recently gained considerable attention due to their unique electrical and chemical properties. These novel semiconductors are being explored to design short-wavelength light-emitting diodes, sensors/biosensors, photodetectors for integration into flexible transparent nanoelectronics/photonics to achieve high-power radio-frequency modules, and heat-resistant optical switches for communication networks. Knowledge of the elastic constants structural and mechanical properties has played crucial roles both in the basic understanding and assessing materials’ use in thermal management applications. In the absence of experimental structural, elastic constants, and mechanical traits, many theoretical simulations have yielded inconsistent results. This work aims to investigate the basic characteristics of tetrahedrally coordinated, partially ionic BeO, MgO, ZnO, and CdO, and partially covalent BN, AlN, GaN, and InN materials. By incorporating a bond-orbital and a valance force field model, we have reported comparative results of our systematic calculations for the bond length $\mathrm{d}$, bond polarity ${\mathsf{\alpha }}_{\mathrm{P}}$, covalency ${\mathsf{\alpha }}_{\mathrm{C}}$, bulk modulus $\mathrm{B}$, elastic stiffness $\mathrm{C}(={\displaystyle \frac{\left[{\mathrm{c}}_{11}-{\mathrm{c}}_{12}\right]}{2}})$, bond-stretching $\mathsf{\alpha }$ and bond-bending $\mathsf{\beta }$ force constants, Kleinmann’s internal displacement ζ, and Born’s transverse effective charge ${\mathrm{e}}_{\mathrm{T}}^{*}$. Correlations between $\mathrm{C}/\mathrm{B}$, $\mathsf{\beta }$/$\mathsf{\alpha }$, ${\displaystyle \frac{{\mathrm{c}}_{12}}{{\mathrm{c}}_{11}}},$ ζ, $\mathrm{a}\mathrm{n}\mathrm{d}$ ${\mathsf{\alpha }}_{\mathrm{C}}$revealed valuable trends of structural, elastic, and bonding characteristics. The study noticed AlN and GaN (MgO and ZnO) showing nearly comparable features, while BN (BeO) is much harder compared to InN (CdO) material, with drastically softer bonding. Calculations of microhardness $\mathrm{H}$, shear modulus $\mathrm{G},$ and Young’s modulus $\mathrm{Y}$ have predicted BN (BeO) satisfying a criterion of super hardness. III-Ns (II-Os) could be vital in electronics, aerospace, defense, nuclear reactors, and automotive industries, providing integrity and performance at high temperature in high-power applications, ranging from heat sinks to electronic substrates to insulators in high-power devices. Full article

In recent years, the EnodePro^® device has been one of the most frequently used velocity sensors to track the bar velocity in resistance training, with the aim of providing load–velocity profiles. However, recent articles highlight a lack of reliability and validity in the estimated maximal strength, which can cause a serious health risk due to the overestimation of the bar velocity. With this study, we aimed to investigate whether imprecision in the measurement could explain the variance in this measurement error. Methods: The research question was evaluated by comparing the integrated velocities from the EnodePro^® with the velocities from a high-resolution displacement sensor for the squat and bench press. The velocity was measured with loads corresponding to 30%, 50%, and 70% of the one-repetition maximum (1RM) in moderately trained participants (n = 53, f = 16, m = 37). Intraclass correlation coefficients (ICC) for agreement were supplemented by an exploration of the systematic bias and the random error (mean absolute error (MAE), mean absolute percentage error (MAPE)). Results: The results indicated movement specificity, with the ICC values for the squat ranging from 0.204 to 0.991 and with ICC = 0.678–0.991 for the bench press. Systematically higher velocities were reported by the EnodePro^® sensor (p < 0.001–0.176), with an MAE = 0.036–0.198 m/s, which corresponds to an MAPE of 4.09–42.15%. Discussion: The EnodePro^® seems to provide overly high velocities, which could result in the previously reported overestimation of the 1RM. Despite the validity problems of force/load–velocity profiles, we suggest evaluating the bar velocity with accurate measurement devices, which is, contrary to previous reports, not the case with the EnodePro^®. Full article

Sensors operating in extreme environments are currently a focal point of global research. Extreme environmental conditions, such as overload, vibration, corrosion, high pressure, high temperature, and radiation, can affect the performance of sensors to the point of failure. It is noteworthy that, compared to the resistance to overload and vibration achieved through structural design, the application of sensors under high-temperature and radiation extreme conditions poses a greater challenge. Silicon carbide (SiC) material, due to its excellent physical and chemical properties, such as a large band gap and high atomic critical displacement energy, demonstrates outstanding potential for application in high-temperature and radiation extreme environments. This review presents the current status and research progress of SiC sensors in high-temperature and radiation extreme environments. Finally, given the limited research on the radiation resistance of SiC sensors, it identifies several challenges and research deficiencies in the application of SiC sensors under radiation extreme environments and discusses the future development direction of SiC-based substrate sensors. Full article

This paper aims to investigate the effects of soil penetration resistance, tillage depth, and operating speeds on the deformation and fatigue of the subsoiling shovel based on the real-time measurement of tractor-operating conditions data. Various types of sensors, such as force, displacement, and angle, were integrated. The software and hardware architectures of the monitoring system were designed to develop a field operation condition parameter monitoring system, which can measure the tractor’s traction force of the lower tie-bar, the real-time speed, the latitude and longitude, tillage depth, and the strain of the subsoiling shovel and other condition parameters in real-time. The time domain extrapolation method was used to process the measured data to obtain the load spectrum. The linear damage accumulation theory was used to calculate the load damage of the subsoiling shovel. The magnitude of the damage value was used to characterize the severity of the operation. The signal acquisition test and typical parameter test were conducted for the monitoring system, and the test results showed that the reliability and accuracy of the monitoring system met the requirements. The subsoiling operation test of the system was carried out, which mainly included two kinds of soil penetration resistances (1750 kPa and 2750 kPa), three kinds of tillage depth (250 mm, 300 mm, and 350 mm), and three kinds of operation speed (4 km/h low speed, 6 km/h medium speed, and 8 km/h high speed), totaling 18 kinds of test conditions. Eventually, the effects of changes in working condition parameters of the subsoiling operation on the overall damage of subsoiling shovels and the differences in damage occurring between the front and rear rows of subsoiling shovels under the same test conditions were analyzed. The test results show that under the same soil penetration resistance, the overall damage sustained by the subsoiling shovels increases regardless of the increase in the tillage depth or operating speed. In particular, the increase in the tillage depth increased the severity of subsoiling shovel damage by 19.73%, which was higher than the 17.48% increase due to soil penetration resistance and the 13.07% increase due to the operating speed. It should be noted that the front subsoiling shovels consistently sustained more damage than the rear, and the difference was able to reach 16.86%. This paper may provide useful information for subsoiling operations, i.e., the operational efficiency and the damage level of subsoiling shovels should be considered. Full article

This paper presents the design, simulation, fabrication, and characterization of a novel large-scan-range electrothermal micromirror integrated with a pair of position sensors. Note that the micromirror and the sensors can be manufactured within a single MEMS process flow. Thanks to the precise control of the fabrication of the grid-based large-size Al/SiO₂ bimorph actuators, the maximum piston displacement and optical scan angle of the micromirror reach 370 μm and 36° at only 6 Vdc, respectively. Furthermore, the working principle of the sensors is deeply investigated, where the motion of the micromirror is reflected by monitoring the temperature variation-induced resistance change of the thermistors on the substrate during the synchronous movement of the mirror plate and the heaters. The results show that the full-range motion of the micromirror can be recognized by the sensors with sensitivities of 0.3 mV/μm in the piston displacement sensing and 2.1 mV/° in the tip-tilt sensing, respectively. The demonstrated large-scan-range micromirror that can be monitored by position sensors has a promising prospect for the MEMS Fourier transform spectrometers (FTS) systems. Full article

Nowadays, 3D printing is becoming an increasingly common option for the manufacturing of sensors, primarily due to its capacity to produce intricate geometric shapes. However, a significant challenge persists in integrating multiple materials during printing, for various reasons. In this study, we propose a straightforward approach that combines 3D printing with metal coating to create an array of resistive force sensors from a single material. The core concept involves printing a sensing element using a conductive material and subsequently separating it into distinct parts using metal-coated lines connected to the electrical ground. This post-printing separation process involves manual intervention utilizing a stencil and metallic spray. The primary obstacle lies in establishing a sufficient contact surface between the sprayed metal and the structure, to ensure effective isolation among different zones. To address this challenge, we suggest employing a lattice structure to augment the contact surface area. Through experimental validation, we demonstrate the feasibility of fabricating two sensing elements from a single-material 3D-printed structure, with a maximum electrical isolation ratio between the sensors of above 30. These findings hold promise for the development of a new generation of low-tech 3D-printed force/displacement sensor arrays. Full article

Soft transportation devices with high flexibility, good stability, and quick controllability have attracted increasing attention. However, a smart soft transportation device with tactile perception and a non-contact actuating mode remains a challenge. This work reports a magnetic soft pipeline (MSP) composed of sensor film, a magnetorheological elastomer (MRE) cavity pipeline, and heater film, which can not only respond well to tactile compression stimuli but also be transported by magnetic actuation. Notably, the sensor film was integrated on the upper surface of an MRE pipeline, and the relative resistance change (∆R/R₀) of the MSP was maintained at 55.8% under 2.2 mm compression displacement during 4000 loading cycles. Moreover, the heater film was integrated on the lower surface of the MRE pipeline, which endows the MSP with an electrothermal heating characteristic. The temperature of the MSP can be increased from 26.7 °C to 38.1 °C within 1 min under 0.6 V. Furthermore, the MSP was attracted and deformed under the magnetic field, and the ∆R/R₀ of the MSP reached 69.1% under application of a 165 mT magnetic field density. Benefiting from the excellent perception and magnetic deformation performances, the magnetic actuate transportation of the MSP with self-sensing was successfully achieved. This multi-functional soft pipeline integrated with in situ self-sensing, electrothermal heating, and non-contact magnetic actuating transportation performance possess high potential in smart flexible electronic devices. Full article

This paper presents a suitably general model for resistive displacement sensors where the model parameters depend on the current sensor conditions, thereby capturing wearout and failure, and proposes a novel fault detection method that can be seamlessly applied during sensor operation, providing self-diagnostic capabilities. On the basis of the estimation of model parameters, an innovative self-compensation method is derived to increase the accuracy of sensors subject to progressive wearout. The proposed model and methods have been validated by both numerical simulations and experimental tests on two real resistive displacement sensors, placed in undamaged and faulty conditions, respectively. The fault detection method has shown an accuracy of 97.2%. The position estimation error is < ±0.2% of the full-scale span for the undamaged sensor, while the self-compensation method successfully reduces the position estimation error from ±15% to approximately ±2% of the full-scale span for the faulty sensor. Full article
