Search Results (248)

Search Parameters:
Keywords = shear connectors

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 1027 KB
Article
Design Method for Combined Shear Connectors in Steel–UHPC Composite Beams
by Jingnan Ding, Tiange Gao and Jinsong Zhu
Materials 2026, 19(8), 1498; https://doi.org/10.3390/ma19081498 - 9 Apr 2026
Abstract
Steel–UHPC composite beams are widely used in bridge engineering due to their high strength, durability, and suitability for prefabricated construction. However, the mechanical performance of shear connectors in UHPC differs significantly, and the uniform use of a single connector type along the beam [...] Read more.
Steel–UHPC composite beams are widely used in bridge engineering due to their high strength, durability, and suitability for prefabricated construction. However, the mechanical performance of shear connectors in UHPC differs significantly, and the uniform use of a single connector type along the beam span may result in a mismatch between connector mechanical characteristics and regional force demands, leading to suboptimal force transfer and inefficient utilization of connector capacity along the beam span. While previous studies have mainly focused on the local behavior of individual connectors, a system-level design strategy considering regional force demands is still limited. This study proposes a system-level design method for combined shear connectors in steel–UHPC composite beams, in which headed stud connectors and trapezoidal composite dowel connectors are arranged according to bending moment distribution and interface shear demand, thereby integrating connector mechanical characteristics with the spatial variation in internal forces along the beam span. The design procedure includes shear span division, longitudinal interface shear calculation, and resistance verification of different connector types. The method is applied to a practical steel–UHPC composite beam in a long-span approach bridge. Results show that headed studs provide reliable uplift resistance and ductile behavior in negative bending regions, whereas composite dowel connectors are shown to be more suitable for shear-dominated positive bending regions due to their higher shear capacity and stiffness. The combined system ensures effective composite action under different stress states and reduces total connector steel consumption compared with a stud-only layout. The proposed approach advances connector design toward performance-oriented and system-level structural optimization, providing a practical framework for connector arrangement in steel–UHPC composite beams. Full article
(This article belongs to the Section Metals and Alloys)
Show Figures

Figure 1

21 pages, 10044 KB
Article
Axial Compressive Behavior of SCS Composite Wall Members for Wind Turbine Towers: Numerical Investigation and Performance Evaluation
by Shuchen Zhang, Yong Yang, Longkang Xu, Shiqiang Feng, Gejia Liu and Samuel Elias Hernandez Gadea
Buildings 2026, 16(6), 1139; https://doi.org/10.3390/buildings16061139 - 13 Mar 2026
Viewed by 288
Abstract
The rapid development of multimegawatt wind turbines presents greater demands on the structural safety and stability of tower structures. In response, this study investigates the axial compressive behavior of steel–concrete–steel (SCS) composite towers with a low steel ratio and enhanced shear connection. The [...] Read more.
The rapid development of multimegawatt wind turbines presents greater demands on the structural safety and stability of tower structures. In response, this study investigates the axial compressive behavior of steel–concrete–steel (SCS) composite towers with a low steel ratio and enhanced shear connection. The two steel plates are integrated by bolt connectors to ensure overall stiffness and effective composite action. Axial compression tests are conducted on curved tower wall members representing a 1/16 segment of the tower cross-section. Previous experimental results indicate that failure is dominated by local buckling of steel plates between adjacent connectors, highlighting the critical role of connector-induced confinement in controlling instability. Numerical models of curved composite walls are established and validated against previously published experimental results, showing good agreement in both failure modes and bearing capacity. Parametric analysis indicates that increasing the bolt diameter from 16 mm to 20 mm and 24 mm enhances the ultimate load by 3.09% and 6.58%, respectively. For the full-section tower model, reducing bolt spacing to 500 mm, 300 mm, and 250 mm increases the ultimate load by 16.33%, 20.05%, and 21.79%, respectively, compared to the bolt-free model. These results confirm that reducing connector spacing substantially enhances bearing capacity through improved confinement and delayed local buckling. A calculation method for evaluating the axial bearing capacity of SCS composite towers incorporating confinement effects is proposed, showing good consistency with both experimental and numerical data. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

29 pages, 2072 KB
Review
Research Advances in U-Shaped Steel−Concrete Composite Beams: State of the Art
by Qingli Lin, Fangliang Yu, Wenxiang Han, Long Zhang and Jinyan Wang
Buildings 2026, 16(5), 1040; https://doi.org/10.3390/buildings16051040 - 6 Mar 2026
Viewed by 361
Abstract
U-shaped steel−concrete composite beams (USCCBs) have been widely used in civil engineering due to their numerous advantages, including high load-bearing capacity, high rigidity, good ductility, short construction periods, and compatibility with the development of prefabricated buildings. In particular, USCCBs have been increasingly applied [...] Read more.
U-shaped steel−concrete composite beams (USCCBs) have been widely used in civil engineering due to their numerous advantages, including high load-bearing capacity, high rigidity, good ductility, short construction periods, and compatibility with the development of prefabricated buildings. In particular, USCCBs have been increasingly applied to super high-rise buildings and extra-large span bridges. Over the past decade or so, many new types of shear connectors and structural forms for USCCBs have been developed. Meanwhile, significant progress has been achieved in research on the flexural, shear, torsional, and fire-resistance performance of USCCBs, the seismic behavior of beam−column joints, and the strengthening of concrete beams with U-shaped steel casings. Nevertheless, challenges and limitations remain in both experimental research and practical applications. This paper presents a systematic review of recent research advances in USCCBs. Existing problems, development prospects, and future research priorities are comprehensively summarized and discussed, with the aim of further promoting the development and engineering application of USCCBs. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

12 pages, 1038 KB
Article
Load-Dependent Non-Uniform Bending Stiffness and Curvature-Based Deflection Calculation in Timber–Concrete Composite Beams
by Yuchen Jiang and Xiamin Hu
Buildings 2026, 16(5), 989; https://doi.org/10.3390/buildings16050989 - 3 Mar 2026
Viewed by 288
Abstract
The effective bending stiffness formula for cross-sections of timber–concrete composite (TCC) beams was derived under semi-sinusoidal loading condition in Eurocode 5; however, this formula does not account for the non-uniform distribution of bending stiffness along the span. This limitation prevents it from characterizing [...] Read more.
The effective bending stiffness formula for cross-sections of timber–concrete composite (TCC) beams was derived under semi-sinusoidal loading condition in Eurocode 5; however, this formula does not account for the non-uniform distribution of bending stiffness along the span. This limitation prevents it from characterizing the mechanical behavior under real loading conditions, which could potentially compromise the safety and serviceability of the structural design. To investigate the distribution pattern of bending stiffness, differential segment analysis was conducted, incorporating interfacial slip effects. A governing differential equation for curvature was established, and the resulting curvature distribution was used to compute deflections by means of the conjugate beam method. The results demonstrate that the bending stiffness distribution depends critically on shear connector arrangement and loading conditions. Under third-point loading, the bending stiffness monotonically decreases from the mid-span to the load application points and increases toward the supports. Under uniform loads, bending stiffness peaks at the mid-span and declines gradually toward the supports. Reducing shear connector spacing enhances composite action while amplifying bending stiffness non-uniformity. Experimental validation confirms that both the conjugate beam method (using analytical curvature solutions) and the simplified approach in Eurocode 5 achieve 99% average accuracy in predicting the mid-span deflection of TCC beams. In addition, careful attention must be paid to the deflection values at loading points, particularly when the loading position is close to the supports. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

32 pages, 9312 KB
Article
Push-Out Testing of Demountable Bolted Shear Connection in Composite Cold-Formed Steel Beams: Experimental Evaluation and Analysis
by Vlaho Žuvelek, Ivan Ćurković, Ivan Lukačević, Andrea Rajić and Marko Bartolac
Buildings 2026, 16(5), 979; https://doi.org/10.3390/buildings16050979 - 2 Mar 2026
Viewed by 280
Abstract
The Innovative Lightweight Cold-Formed Steel–Concrete Composite Floor System (LWT-FLOOR) addresses key challenges faced by the construction industry related to the efficiency, adaptability, and life-cycle usability of structural elements. Within this context, the present study investigated the behaviour of demountable bolted shear connections in [...] Read more.
The Innovative Lightweight Cold-Formed Steel–Concrete Composite Floor System (LWT-FLOOR) addresses key challenges faced by the construction industry related to the efficiency, adaptability, and life-cycle usability of structural elements. Within this context, the present study investigated the behaviour of demountable bolted shear connections in a composite system combining built-up cold-formed steel (CFS) girders and concrete slabs. An experimental programme comprising 18 push-out tests was conducted on two composite configurations: built-up back-to-back CFS sections and built-up sections incorporating a corrugated web. The influence of key parameters, including the bolt diameter, CFS thickness, steel grade, and connector spacing, was evaluated. The results show that increasing the bolt diameter enhanced the shear resistance and initial stiffness while reducing ductility, whereas reducing the CFS thickness led to a moderate decrease in resistance accompanied by a pronounced increase in ductility. The incorporation of a corrugated web increased the ultimate shear resistance by approximately 30–40%. The existing analytical models from current standards were found to be inadequate; however, the introduction of a spacing-dependent correction factor into the prEN 1994-1-1 model significantly improved the prediction accuracy, reducing the coefficient of variation from 16% to 4.36%. The findings provide a quantitative basis for improving the design of demountable shear connections in lightweight composite CFS-concrete systems. Full article
Show Figures

Figure 1

27 pages, 7563 KB
Article
Research on the Elastic Stiffness of Stud–PBL Composite Shear Connectors in Composite Bridge Pylons
by Qinhe Li, Ronghui Wang, Yuyang Chen, Zhe Hu and Hengjie Zhao
Buildings 2026, 16(4), 720; https://doi.org/10.3390/buildings16040720 - 10 Feb 2026
Viewed by 326
Abstract
The application of steel–concrete composite structures in the pylons of long-span cable-stayed bridges can effectively address the issue of insufficient structural stiffness. Shear connectors are critical load-transfer components in steel–concrete composite segments, where they are typically arranged to ensure coordinated force transmission between [...] Read more.
The application of steel–concrete composite structures in the pylons of long-span cable-stayed bridges can effectively address the issue of insufficient structural stiffness. Shear connectors are critical load-transfer components in steel–concrete composite segments, where they are typically arranged to ensure coordinated force transmission between steel and concrete. The stud–PBL composite shear connector, as a novel type of connector, has been implemented in engineering practice. However, the collaborative load-bearing performance between studs and PBL connectors remains unclear. Most shear connectors operate within the elastic stage during service, making their elastic stiffness a key evaluation metric. Based on the Winkler elastic foundation beam theory, plane strain theory, and the spring series–parallel model, this study derives the elastic stiffness calculation formulas for stud shear connectors and PBL shear connectors, respectively. The primary focus of this study was the single-layer stud–PBL composite shear connector within the steel–concrete composite section of bridge pylons. Embedded push-out tests were designed and conducted, comprising three main categories and eight subcategories. The load–slip curves for the three types of shear connectors were generated, and the stiffness calculation formula for the stud–PBL composite shear connector was verified through finite element analysis. The comparative push-out tests and finite element simulations demonstrate that the theoretical formula proposed in this study can effectively analyze the elastic stiffness of three types of shear connectors. The elastic stiffness of composite shear connectors can be regarded as the superposition of the elastic stiffness of studs and PBL shear connectors. Compared with single shear connectors, composite shear connectors exhibit superior elastic stiffness and shear resistance, meeting the application requirements of steel–concrete composite bridge pylons. The research findings provide a theoretical basis for the optimal design of shear connectors in large-span cable-stayed bridge composite pylons. Furthermore, the established formula has broad applicability. Full article
(This article belongs to the Special Issue Innovative Design and Optimization of Steel Structures)
Show Figures

Figure 1

29 pages, 11513 KB
Article
Performance Study on a New Type of Connection Joint for Prefabricated Stiffened Column and Composite Beam Frame Structures
by Yufen Gao, Zheng Yang, Lu Chen, Zhongshan Zhang and Shengzhao Cheng
Buildings 2026, 16(3), 628; https://doi.org/10.3390/buildings16030628 - 2 Feb 2026
Viewed by 307
Abstract
To address complex connections in prefabricated concrete structures, a novel joint connecting a prefabricated concrete-filled steel tubular column and a composite beam is proposed. Pseudo-static tests on six scaled specimens and ABAQUS finite element analyses were conducted to investigate seismic mechanisms, focusing on [...] Read more.
To address complex connections in prefabricated concrete structures, a novel joint connecting a prefabricated concrete-filled steel tubular column and a composite beam is proposed. Pseudo-static tests on six scaled specimens and ABAQUS finite element analyses were conducted to investigate seismic mechanisms, focusing on slab effects and beam-bottom configurations. Experimental results show the joints exhibit plump hysteretic curves. The composite beams displayed distinct shear-dominated failure, while the stiffened column remained intact. With an average ductility coefficient of 2.84 and an ultimate equivalent viscous damping coefficient of 0.207, the specimens demonstrated excellent deformation and energy dissipation capabilities. The slab’s flange effect significantly enhanced negative bearing capacity, causing mechanical asymmetry. Comparatively, the steel plate beam bottom configuration offered superior stiffness and stability over the reinforcement beam bottom configuration. Sensitivity analysis revealed that bearing capacity is highly sensitive to beam parameters (e.g., longitudinal rebar strength, connector length) but less sensitive to column parameters. Notably, the bearing capacity of the beam bottom configuration using reinforcement increases significantly with concrete strength and reinforcement ratio, whereas the beam bottom configuration using a steel plate shows marked insensitivity to these factors. These findings clarify the load transfer mechanism and support the seismic design of prefabricated structures. Full article
(This article belongs to the Special Issue High-Performance Steel–Concrete Composite/Hybrid Structures)
Show Figures

Figure 1

14 pages, 3172 KB
Article
Flexural Deformation Calculation Theory and Numerical Method for Steel-Plate–Concrete Composite Reinforcement Considering Interfacial Slip
by Kanghua Yang, Xu Xie, Aijun Zhang and Peiyun Zhu
Buildings 2026, 16(2), 416; https://doi.org/10.3390/buildings16020416 - 19 Jan 2026
Viewed by 322
Abstract
The steel-plate–concrete composite reinforcement method is derived from the bonded steel plate and increased-section techniques. It is employed to enhance the strength of concrete structures that require a substantial increase in load-bearing capacity. To develop a flexural deformation calculation theory that accounts for [...] Read more.
The steel-plate–concrete composite reinforcement method is derived from the bonded steel plate and increased-section techniques. It is employed to enhance the strength of concrete structures that require a substantial increase in load-bearing capacity. To develop a flexural deformation calculation theory that accounts for slip effects in general reinforced cross-sections with bilateral symmetry, interfacial slip and deflection equations are formulated based on the relationship between interlayer slip and the rotational angle of beams in the plane, as well as the principle of force equilibrium. A numerical method, established based on this theoretical framework, is proposed to facilitate the analytical solution and is verified to be consistent with analytical results. Furthermore, the accuracy of the calculation theory is validated through bending experiments. Finally, the influence of key parameters affecting slip on the flexural stiffness of the reinforced beam is evaluated by determining the stiffness reduction coefficient according to the theory. The results indicate that the flexural stiffness of reinforced beams is governed by three non-dimensional parameters: the boundary condition parameter (μ), composite action parameter (shear connector stiffness (βl)), and relative bending stiffness parameter (G/G0). The loading mode does not affect the flexural stiffness of the reinforced beams. As βl approaches 100 and G/G0 approaches 1, η approaches 100%. In cases where high stiffness is required, reducing interfacial slip can minimize the loss of flexural stiffness in composite structures. Conservative calculations indicate that satisfying the conditions βl ≥ 8 and G/G0 ≤ 1.6 during design can ensure that the reduction in flexural stiffness of the reinforced beam remains above 90%. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

22 pages, 6234 KB
Article
Experimental and Numerical Investigation on Mechanical Behavior of Corrugated Steel–Concrete Composite Bridge Decks
by Fanlei Kong, Rongrong Bai, Junlong He, Mingzhe Li and Zhen Wang
Buildings 2026, 16(2), 330; https://doi.org/10.3390/buildings16020330 - 13 Jan 2026
Viewed by 503
Abstract
This study presents an experimental and numerical investigation into the mechanical behavior of corrugated steel–concrete composite bridge decks with composite dowel shear connectors. Four full-scale specimens were fabricated and subjected to flexural tests to obtain and analyze the load–deflection and load–strain curves. A [...] Read more.
This study presents an experimental and numerical investigation into the mechanical behavior of corrugated steel–concrete composite bridge decks with composite dowel shear connectors. Four full-scale specimens were fabricated and subjected to flexural tests to obtain and analyze the load–deflection and load–strain curves. A finite element model was developed and validated against the experimental results. The validated model was subsequently applied to analyze the load-carrying process and to perform parametric sensitivity analysis. The effects of the concrete strength grade, steel strength, corrugated steel plate thickness, concrete slab thickness, and corrugated steel plate height on the ultimate bearing capacity were evaluated. The results indicate that corrugated steel–concrete composite bridge decks were subjected to concrete shear failure. The ultimate bearing capacity of the bridge deck reached approximately 3.36 times the design value, demonstrating a high safety reserve. Throughout the entire flexural failure process, the shear connectors performed effectively, with only minimal relative slip observed at the steel–concrete interface. At the instance of failure, only partial areas of the corrugated steel plate yielded. To fully exploit the structural potential, the key design parameters require rational coordination. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

30 pages, 3322 KB
Article
Insights into the Feature-Selection Mechanisms for Modeling the Shear Capacity of Stud Connectors in Concrete: A Machine Learning Approach
by Sadi Ibrahim Haruna, Abdulwarith Ibrahim Bibi Farouk, Yasser E. Ibrahim, Mahmoud T. Nawar, Suleiman Abdulrahman and Mustapha Abdulhadi
J. Compos. Sci. 2026, 10(1), 34; https://doi.org/10.3390/jcs10010034 - 8 Jan 2026
Cited by 1 | Viewed by 395
Abstract
Shear connections between concrete structural elements play a vital role in defining performance and overall stability. However, limitations in traditional methods for predicting the shear capacity (Vu) of stud connectors in concrete have been highlighted. Developing strategies that precisely describe the performance of [...] Read more.
Shear connections between concrete structural elements play a vital role in defining performance and overall stability. However, limitations in traditional methods for predicting the shear capacity (Vu) of stud connectors in concrete have been highlighted. Developing strategies that precisely describe the performance of stud-headed connectors requires insight into their failure mechanisms and the corresponding shear transmission. Therefore, leveraging advancements in machine learning, this study aims to predict the Vu of the headed stud connector in concrete structures using various input parameters. A database (1121) of the shear strength collected from the literature was trained using six machine learning (ML) algorithms: extreme learning machine (ELM), decision tree (DT), artificial neural network (ANN), multi-linear regression (MLR), support vector machine (SVM), and hybrid ANN–particle swarm optimization (ANN-PSO). Feature selection methods and system identification were applied to explore the optimal or most relevant input parameters. The feature selection techniques indicated that the geometric properties of the stud connector (diameter and cross-sectional area), the concrete modulus of elasticity (Ec), and the height of the weld collar (hw) are the most relevant input variables. The ANN-PSO model outperformed the other classical models in estimating the shear capacity at two modeling stages. The hybrid ANN-PSO achieved R2 = 0.976, MAE = 7.61 kN, RMSE = 10.8 kN, and MAPE = 8.04%, demonstrating the best predictive accuracy among the classical models. On the other hand, DT is the second-best model, with an R2 of 0.958, MAE of 10.27 kN, RMSE of 14.43 kN, and MAPE of 8.53 kN for forecasting the shear capacity of stud connectors in concrete. Full article
(This article belongs to the Section Composites Modelling and Characterization)
Show Figures

Figure 1

20 pages, 3106 KB
Article
Shear Performance and Load–Slip Model of a Cross-Type FRP Rod Connector for Precast Concrete Sandwich Panels
by Ya Li, Weichen Xue and Jialin Yang
Buildings 2026, 16(1), 139; https://doi.org/10.3390/buildings16010139 - 27 Dec 2025
Viewed by 527
Abstract
A precast concrete sandwich panel (PCSP), consisting of inner and outer wythes, an insulation layer, and connectors, relies heavily on the shear behavior of these connectors, which governs the structural performance of the entire system. Owing to their low thermal conductivity, excellent durability, [...] Read more.
A precast concrete sandwich panel (PCSP), consisting of inner and outer wythes, an insulation layer, and connectors, relies heavily on the shear behavior of these connectors, which governs the structural performance of the entire system. Owing to their low thermal conductivity, excellent durability, and high strength, fiber-reinforced polymer (FRP) connectors offer strong potential for widespread application. This study introduces a novel cross-shaped FRP rod connector designed to provide improved anchorage performance, bidirectional shear resistance, and ease of installation. However, concern remains about the specific influence of embedment depth, outer-wythe thickness, and insulation-layer thickness on its shear performance. Moreover, no calculation model for shear capacity or shear–slip model has been established considering the shear-bending interaction within the connector. To evaluate its shear behavior, six groups of push-out tests were conducted, with key parameters including embedment depth, outer-wythe thickness, and insulation-layer thickness. The specimens exhibited two primary failure modes: connector fracture and concrete anchorage failure. The measured shear capacity per connector ranged from 5.63 kN to 14.19 kN, increasing with longer embedment depths, decreasing with increasing insulation thickness, and showing no clear dependence on outer-wythe thickness. Guided by test results and the Hashin failure criterion for composite materials, analytical formulas to estimate the shear capacity of FRP connectors were developed. The mean ratio of calculated to experimental values is 0.97, with a standard deviation of 0.06, indicating good agreement between the predicted and measured shear capacities. Furthermore, a theoretical shear–slip model was established. The correlation coefficients between the experimental and calculated load–slip curves for all specimens are greater than 0.98, indicating a high consistency in curve shape and variation trend. Full article
(This article belongs to the Special Issue The Latest Research on Building Materials and Structures)
Show Figures

Figure 1

22 pages, 7147 KB
Article
Experimental Study on the Flexural Behavior of Steel–Concrete Composite Bridge Decks with Stud–PBL Shear Connectors
by Ruifeng Dou, Jun Zhao, Longhua Shi, Dongjie Weng, Ding Zhou and Wei Zhao
Buildings 2026, 16(1), 104; https://doi.org/10.3390/buildings16010104 - 25 Dec 2025
Cited by 1 | Viewed by 431
Abstract
To investigate the flexural behavior of steel–concrete composite bridge decks with stud–perfobond leist (PBL) shear connectors, two specimens were designed with the stud spacing as the main variable, and static bending tests were conducted. Additionally, refined finite element models were constructed for evaluating [...] Read more.
To investigate the flexural behavior of steel–concrete composite bridge decks with stud–perfobond leist (PBL) shear connectors, two specimens were designed with the stud spacing as the main variable, and static bending tests were conducted. Additionally, refined finite element models were constructed for evaluating the influence of shear connector types, concrete strength, stud diameter, stud height, and PBL hole diameter on the performance and flexural capacity of the structure. The results show that, under bending loads, the failure of the composite bridge deck is mainly concrete crushing and steel plate yielding. When the spacing of the stud decreases, both the flexural behavior of the composite bridge decks and the shear resistance at the steel–concrete interface are enhanced. The steel–concrete composite bridge decks with stud–PBL shear connectors showed higher overall flexural stiffness and flexural capacity than the steel–concrete composite bridge decks with single-type shear connectors. Concrete strength had a pronounced influence on the flexural capacity of the deck system, while the effects of stud diameter and height were minor. As the PBL hole diameter increased, the flexural capacity of the specimens exhibited a decreasing tendency. Full article
Show Figures

Figure 1

26 pages, 5054 KB
Article
Energy-Based Design for the Seismic Improvement of Historic Churches by Nonlinear Modelling
by Nicola Longarini, Pietro Crespi, Luigi Cabras and Michele Santoro
Buildings 2026, 16(1), 12; https://doi.org/10.3390/buildings16010012 - 19 Dec 2025
Viewed by 384
Abstract
This study investigates the seismic retrofit of historic single-nave churches through the optimization of roof diaphragms designed to enhance energy dissipation. The proposed strategy introduces a deformable box-type diaphragm above the existing roof, composed of timber panels and steel connectors with a cover [...] Read more.
This study investigates the seismic retrofit of historic single-nave churches through the optimization of roof diaphragms designed to enhance energy dissipation. The proposed strategy introduces a deformable box-type diaphragm above the existing roof, composed of timber panels and steel connectors with a cover of steel stripes, where energy dissipation is concentrated in the connections. The retrofit design is guided by the estimation of Equivalent Damping Ratio (EDR) instead of the usually adopted resistance criterion, considering an energy-based approach to improve global seismic performance while preserving architectural integrity. In this way, the retrofitted configuration of the roof can be considered a damper. Three numerical phases are presented to assess the effectiveness of the equivalent damping-based intervention. In the first one, the seismic response of the initial non-retrofitted configuration is implemented using a 3D linear finite element model subjected to a response spectrum. Subsequently, nonlinear equivalent models subjected to spectrum-compatible accelerograms are implemented, simulating the possible retrofitted configurations of the roofs to detect the optimum damping and finding the corresponding roof diaphragm configuration. In the third one, the response of the detected retrofitted configuration is also evaluated by nonlinear 3D model subjected to accelerograms. The three phases with the relative numerical approaches are here applied to a case study, located in a high seismic hazard area. The results demonstrate that the EDR-based methodology can optimize the retrofitted roof diaphragm configuration; the nave transverse response is improved in comparison with that designed with the traditional approach, considering only the over-strength of the interventions. Comparisons about the approaches based on the EDR and the strength criteria are presented in terms of lateral displacements, in-plane shear acting on the roof diaphragm, and in-plane stresses on the façade. Full article
(This article belongs to the Special Issue Modeling and Testing the Performance of Masonry Structures)
Show Figures

Figure 1

19 pages, 5801 KB
Article
Structural Performance of Textile-Reinforced Concrete Sandwich Panels Utilizing GFRP Shear Connectors
by Lukas Steffen, Ismael Viejo, Belén Hernández-Gascón, Mario Stelzmann, Klaus Holschemacher and Robert Böhm
Constr. Mater. 2025, 5(4), 92; https://doi.org/10.3390/constrmater5040092 - 18 Dec 2025
Viewed by 685
Abstract
Textile-reinforced concrete (TRC) sandwich panels with lightweight cores are a promising solution for sustainable and slender building envelopes. However, their structural performance depends strongly on the shear connection between the outer shells. This study investigates the flexural behavior of TRC sandwich panels with [...] Read more.
Textile-reinforced concrete (TRC) sandwich panels with lightweight cores are a promising solution for sustainable and slender building envelopes. However, their structural performance depends strongly on the shear connection between the outer shells. This study investigates the flexural behavior of TRC sandwich panels with glass fiber-reinforced polymer (GFRP) rod connectors under four-point bending. Three full-scale specimens were manufactured with high-performance concrete (HPC) face layers, an expanded polystyrene (EPS) core, and 12 mm GFRP rods as shear connectors. The panels were tested up to failure, with measurements of load–deflection behavior, crack development, and interlayer slip. Additionally, a linear-elastic finite element model was developed to complement the experimental campaign, capturing the global stiffness of the system and providing complementary insight into the internal stress distribution. The experimental results revealed stable load-bearing behavior with ductile post-cracking response. A degree of composite interaction of γ = 0.33 was obtained, indicating partially composite action. Slip measurements confirmed effective shear transfer by the GFRP connectors, while no brittle failure or connector rupture was observed. The numerical analysis confirmed the elastic response observed in the tests and highlighted the key role of the GFRP connectors in coupling the TRC shells, extending the interpretation beyond experimental results. Overall, the study demonstrates the potential of TRC sandwich panels with mechanical connectors as a safe and reliable structural solution. Full article
Show Figures

Figure 1

32 pages, 16602 KB
Article
Structural Behavior and Failure Characteristics of Fiber-Reinforced Polymer-Concrete Composite Beams Incorporating Glass Roving Tied GFRP Shear Connectors
by Ankit Singh Mehra, Shamsher Bahadur Singh and Venkatesh Kodur
Polymers 2025, 17(23), 3201; https://doi.org/10.3390/polym17233201 - 30 Nov 2025
Cited by 1 | Viewed by 833
Abstract
This paper presents the findings of an experimental study on the structural response of glass fiber-reinforced polymer (GFRP)-concrete composite beams. The connectors were fabricated from GFRP dowels, epoxy resin-saturated E-glass roving, and/or adhesive layers. The composite beams were subjected to a four-point bending [...] Read more.
This paper presents the findings of an experimental study on the structural response of glass fiber-reinforced polymer (GFRP)-concrete composite beams. The connectors were fabricated from GFRP dowels, epoxy resin-saturated E-glass roving, and/or adhesive layers. The composite beams were subjected to a four-point bending test configuration and examined for their failure modes and load-deformation characteristics. The test results showed that the developed configurations of composite beams significantly outperformed the response of the standalone GFRP I-section profile and non-composite beams. The provision of a discrete interfacial connection successfully prevented the local and lateral torsional buckling of the profile, doubled the initial stiffness, increased the load-carrying capacity by around three times, and imparted a certain degree of ductility and reserve capacity to the otherwise brittle system. The failure occurred primarily due to the shearing of the web. Other modes of failure were observed in the form of the cracking/crushing of concrete, delamination of the laminate, and buckling/crushing of the web. The epoxy-bonded composite beams displayed the highest stiffness, while those with 45° inclined dowels exhibited the highest load-carrying capacity. The results were compared against those predicted by the available analytical expressions, and required modifications are suggested. Full article
(This article belongs to the Section Polymer Composites and Nanocomposites)
Show Figures

Figure 1
