This dataset comprises specklegram images acquired from a multimode optical fiber subjected to varying thermal conditions. Designed for training neural networks focused on developing Fiber Optic Specklegram Sensors (FSSs), these experimental data enable the detection of changes in speckle patterns corresponding to applied temperature variations. The dataset includes 24,528 images captured over a temperature range from 25 °C to 200 °C, with incremental steps of approximately 0.175 °C. Key acquisition parameters include a wavelength of 633 nm, a sensing zone length of 20 mm, and a multimode fiber with a core diameter of 62.5 μm. This dataset supports developing and validating temperature-sensing models using fiber optic technology and can facilitate benchmarking against other experimental or synthetic datasets. Finally, an implementation is presented for utilizing the dataset in a deep learning interrogation scheme. Full article

Since an MMF-based distributed sensor requires the simultaneous measurement of multiple perturbation positions and their intensities, the collection of a large amount of specklegram data is time consuming and challenging for recognizing multiple perturbations. To address this issue, we propose a novel approach to recognize multi-position load using an MMF specklegram sensor, supported by theoretical analysis and experimental verification. Our study introduces a construction method for a multi-variable, multi-class, one-shot specklegram dataset, significantly enhancing the sample diversity for more perturbation positions and intensities in an MMF-distributed sensor recognition model. We theoretically derive the mathematical model of total local intensity for each region and investigate its sensitivity to the external perturbations. Based on these theoretical analyses, this paper proposes a specklegram traversal occlusion data augmentation with a shallow convolutional neural network (CNN) model to mitigate overfitting in specklegram datasets. Experimental validation using a multi-position load-recognition MMF demonstrates that our approach achieves nearly 100% accuracy in simultaneously recognized load positions and its magnitudes across up to 1545 distinct load forms. Furthermore, the shallow CNN model exhibits superior training efficiency and stability compared with the existing MMF sensing models. This work provides a proof of concept of a distributed sensor based on an MMF specklegram sensor, highlighting its potential for high-resolution distributed measurements under the diverse external perturbations. Our method represents a significant advancement in this field, offering a cost-effective and efficient solution for distributed sensing applications. Full article

A high-resolution and wide measurement range displacement sensing method based on multimode fiber (MMF) is proposed. To achieve a high-resolution displacement detection model, a one-shot dataset was constructed by collecting MMF specklegram images for 1801 displacements with resolution of 0.01 mm. This work modifies the fully connected layer of a residual network (ResNet) to achieve displacement prediction and applies residual scaling to reduce prediction errors in the one-shot learning task. Under stable environmental conditions, experimental results show that this method achieves an average error as low as 0.0083 mm in displacement prediction with resolution of 0.01 mm; meanwhile, the measurement range reaches 18 mm. Additionally, the model trained on a 0.01 mm resolution dataset was evaluated on a specklegram dataset with a resolution of 0.005 mm for its generalization ability, yielding an average error of 0.0138 mm. Regression evaluation metrics demonstrate that the proposed model has a significant improvement over other displacement-sensing methods based on MMF specklegrams, with prediction errors approximately three times lower than ResNet. Additionally, temperature immunity was studied within an 18 mm measurement range under a temperature range from 21.25 °C to 22.35 °C; the MMF displacement sensor demonstrates a dispersion of 5.08%, an average nonlinearity of 7.71% and a hysteresis of 6.13%. These findings demonstrate the potential of this method for high-performance displacement-sensing in practical applications. Full article

The study proposes a novel speckle interferometric method for detecting and quantifying microplastic leaching from paper cups, addressing concerns raised by the World Health Organization regarding human health risks. Hot water at varying temperatures is placed in 36 paper cups from different manufacturers, and the specklegrams of the paper cups’ interior surface are recorded. The quantity of microplastics leached into water is estimated by the Neubauer chamber method, which increases with rising water temperature. Surface morphology analysis through atomic force microscopic images reveals thermal-induced melting and smearing of microplastics, decreasing roughness parameters. Co-occurrence matrix analysis of specklegrams correlates image parameters—inertia moment, homogeneity, energy, contrast, and entropy—with the microplastics count, showing surface modifications and altered pixel intensity distribution with increasing water temperature. Regression equations based on image parameters establish a strong correlation with the microplastics count, that are validated against the Neubauer chamber method. The study indicates contrast as the potential sensitive specklegram feature for microplastics detection and quantification. Full article

Optical fiber sensors have been studied, developed, and already used in the industry for more than 50 years due to their multiplexing capabilities, lightweight design, compact form factors, and electromagnetic field immunity. The scientific community continuously studies new materials, schemes, and architectures aiming to improve existing technologies. Navigating through diverse sensor technologies, including interferometry, intensity variation, nonlinear effects, and grating-based sensors, fiber specklegram sensors (FSSs) emerge as promising alternatives due to their simplicity and low cost. This review paper, emphasizing the potential of FSSs, contributes insights to the present state and future prospects for FSSs, providing a holistic view of advancements propelling FSSs to new frontiers of innovation. Subsequent sections explore recent research, technological trends, and emerging applications, contributing to a deeper understanding of the intricacies shaping the future of FFS sensor technologies. Full article

Carcinoembryonic antigen (CEACAM5), as a broad-spectrum tumor biomarker, plays a crucial role in analyzing the therapeutic efficacy and progression of cancer. Herein, we propose a novel biosensor based on specklegrams of tapered multimode fiber (MMF) and two-dimensional convolutional neural networks (2D-CNNs) for the detection of CEACAM5. The microfiber is modified with CEA antibodies to specifically recognize antigens. The biosensor utilizes the interference effect of tapered MMF to generate highly sensitive specklegrams in response to different CEACAM5 concentrations. A zero mean normalized cross-correlation (ZNCC) function is explored to calculate the image matching degree of the specklegrams. Profiting from the extremely high detection limit of the speckle sensor, variations in the specklegrams of antibody concentrations from 1 to 1000 ng/mL are measured in the experiment. The surface sensitivity of the biosensor is 0.0012 (ng/mL)⁻¹ within a range of 1 to 50 ng/mL. Moreover, a 2D-CNN was introduced to solve the problem of nonlinear detection surface sensitivity variation in a large dynamic range, and in the search for image features to improve evaluation accuracy, achieving more accurate CEACAM5 monitoring, with a maximum detection error of 0.358%. The proposed fiber specklegram biosensing scheme is easy to implement and has great potential in analyzing the postoperative condition of patients. Full article

Wavemeters are very important for precise and accurate measurements of both pulses and continuous-wave optical sources. Conventional wavemeters employ gratings, prisms, and other wavelength-sensitive devices in their design. Here, we report a simple and low-cost wavemeter based on a section of multimode fiber (MMF). The concept is to correlate the multimodal interference pattern (i.e., speckle patterns or specklegrams) at the end face of an MMF with the wavelength of the input light source. Through a series of experiments, specklegrams from the end face of an MMF as captured by a CCD camera (acting as a low-cost interrogation unit) were analyzed using a convolutional neural network (CNN) model. The developed machine learning specklegram wavemeter (MaSWave) can accurately map specklegrams of wavelengths up to 1 pm resolution when employing a 0.1 m long MMF. Moreover, the CNN was trained with several categories of image datasets (from 10 nm to 1 pm wavelength shifts). In addition, analysis for different step-index and graded-index MMF types was carried out. The work shows how further robustness to the effects of environmental changes (mainly vibrations and temperature changes) can be achieved at the expense of decreased wavelength shift resolution, by employing a shorter length MMF section (e.g., 0.02 m long MMF). In summary, this work demonstrates how a machine learning model can be used for the analysis of specklegrams in the design of a wavemeter. Full article

We report a simple and robust fiber specklegram refractive index sensor with a multimode fiber-single mode fiber-multimode fiber structure based on focused ion beam milling. In this work, a series of fluid channels are etched on the single-mode fiber by using focused ion beam milling to enhance the interaction between light and matter, and a deep learning model is employed to demodulate the sensing signal according to the speckle patterns collected from the output end of the multimode fiber. The feasibility and effectiveness of the proposed scheme were verified by rigorous experiments, and the test results showed that the demodulation accuracy and speed could reach 99.68% and 4.5 ms per frame, respectively, for the refractive index range of 1.3326 to 1.3679. The proposed sensing scheme has the advantages of low cost, easy implementation, and a simple measurement system, and it is expected to find applications in various chemical and biological sensing. Full article

In this paper, a learning-based fiber specklegram sensor for bending recognition is proposed and demonstrated. Specifically, since the curvature-induced variations of mode interference in optical fibers can be characterized by speckle patterns, Resnet18, a classification model based on convolutional neural network architecture with excellent performance, is used to identify the bending state and disturbed position simultaneously according to the speckle patterns collected from the distal end of the multimode fiber. The feasibility of the proposed scheme is verified by rigorous experiments, and the test results indicate that the proposed sensing system is effective and robust. The accuracy of the trained model is 99.13%, and the prediction speed can reach 4.75 ms per frame. The scheme proposed in this work has the advantages of low cost, easy implementation, and a simple measurement system and is expected to find applications in distributed sensing and bending identification in complex environments. Full article

The relationship between wood and its degree of humidity is one of the most important aspects of its use in construction and restoration. The wood presents a behavior similar to a sponge, therefore, moisture is related to its expansion and contraction. The nondestructive evaluation (NDE) of the amount of moisture in wood materials allows to define, e.g., the restoration procedures of buildings or artworks. In this work, an integrated study of two non-contact techniques is presented. Infrared thermography (IRT) was able to retrieve thermal parameters of the wood related to the amount of water added to the samples, while the interference pattern generated by speckles was used to quantify the expansion and contraction of wood that can be related to the amount of water. In twenty-seven wooded samples, a known quantity of water was added in a controlled manner. By applying advanced image processing to thermograms and specklegrams, it was possible to determine fundamental values controlling both the absorption of water and the main thermophysical parameters that link the samples. On the one hand, results here shown should be considered preliminary because the experimental values obtained by IRT need to be optimized for low water contents introduced into the samples. On the other hand, speckle interferometry by applying an innovative procedure provided robust results for both high and low water contents. Full article

Here, we report a fiber-optic point-based sensor to measure temperature and weight based on correlated specklegrams induced by spatial multimode interference. The device is realized simply by splicing a multimode fiber (MMF) to a single-mode fiber (SMF) with a core offset. A series of experiments demonstrates the approximately linear relation between the correlation coefficient and variation. Furthermore, we show the potential applications of the refractive index sensing of our device by disconnecting the splicing point of MMF and SMF. A modification of the algorithm in order to improve the sensitivity of the sensor is also discussed at the end of the paper. Full article
