In this study, a series of carrier-phase direct numerical simulations are conducted on spherical expanding premixed hydrogen/air flames with liquid water addition. An Eulerian–Lagrangian approach with two-way coupling is employed to describe the liquid–gas interaction. The impacts of preferential diffusion, the equivalence ratio, water loading, and the initial diameter of the water droplets are examined and analyzed in terms of flame evolution. It is observed that liquid water has the potential to influence flame propagation characteristics by reducing the total burning rate, flame area, and burning rate per unit area, attributed to flame cooling effects. However, these effects become discernible only under conditions where water evaporation is sufficiently intense. For the conditions investigated, the influence of preferential diffusion on flame evolution is found to be more significant than the interaction with liquid water. The results suggest that due to the slow evaporation rate of water, which is a result of its high latent heat of evaporation, the water droplets do not disturb the initial flame kernel growth significantly. This has implications for water injection concepts in internal combustion engines and for explosion mitigation. Full article

A hydrogen under-expanded jet released from a high-pressure vessel or equipment into the atmosphere through a 0.53 mm diameter orifice results in a sustained lifted flame for pressures above 4 MPa and flame blow-out at pressures below 3 MPa. Knowledge of whether the leaked hydrogen creates a sustained flame or is extinguished is an important issue for safety engineering. This study aims to clarify, in detail, a mechanism of flame stabilisation and blow-out depending on the spouting pressure. The model of flame stabilisation is derived using measurements and observations at the flame base location by means of high-speed schlieren images, laser diagnostics, and electrostatic probe techniques. The sustained stable flame originating from the 0.53 mm orifice is characterised by the existence of the spherical flame structures with a diameter of about 5 to 7 mm that appear one after another at the flame base and outside the streamlines of the hydrogen jet. As the spouting pressure reduces to 3.5 MPa, the sustained lifted flame becomes quasi-steady with higher fluctuations in amplitude of the flame base (lift-off height). In addition to that, flame structures are moving further from the hydrogen jet outlet, with a further decrease of spouting pressure leading to blow-out. The existence of spherical flame formations plays an important role in flame stabilisation. Based on the measurements of OH radicals using the PLIF method and ion currents, multiple flame surfaces were found to be folded in the flame structures. The hydrogen jet generates the vortex-like flow near its outer edge, creating flamelets upon ignition, ultimately forming the observed in the experiments spherical flame structures. Full article

Recent efforts to understand low-temperature combustion (LTC) in internal combustion engines highlight the need to improve chemical kinetic mechanisms involved in the negative temperature coefficient (aka cool flame) regime. Interestingly, microgravity droplet combustion experiments demonstrate this cool flame behavior, allowing a greater focus on chemistry after buoyancy, and the corresponding influence of the conservation of momentum is removed. In Experimental terms, the LTC regime is often characterized by a reduction in heat transfer losses. Novel findings in this area demonstrate that lower entropy generation, in conjunction with diminished heat transfer losses, could more definitively define the LTC regime. As a result, the simulation of the entropy equation for spherical droplet combustion under microgravity could help us to investigate fundamental LTC chemical kinetic pathways. To provide a starting point for researchers who are new to this field, this effort first provides a comprehensive and detailed derivation of the conservation of entropy equation using spherical coordinates and gathers all relevant information under one cohesive framework, which is a resource not readily available in the literature. Subsequently, the well-known d² law analytical model is determined and compared to experimental data that highlight shortcomings of the law. The potential improvements in the d² law are then discussed, and a numerical model is presented that includes entropy. The resulting codes are available in an online repository to ensure that other researchers interested in expanding this field of work have a fundamental starting point. Full article

Rigid polyurethane foams were prepared by the one-step expandable foam method using casting molding followed by forming clay-based composites. Polyurethane/vermiculite foam composites (PU/VMT) were controlled based on adding the percentage of clay in the formulation. The effects of composite modifications were evaluated by X-ray diffraction (XRD), thermogravimetric analysis (TG/DTG), and scanning electron microscopy (SEM/EDS) applied to the flame retardancy explored by the vertical burn test. The results indicated that adding clay controlled the particle size concerning polyurethane (PU) foams. However, they exhibited spherical structures with closed cells with relatively uniform distribution. XRD analysis showed the peaks defined at 2θ = 18° and 2θ = 73° relative to the crystallinity in formation and interaction of rigid segments were identified, as well as the influence of crystallinity reduction in composites. In the flame test, the flame retardant surface was successful in all composites, given the success of the dispersibility and planar orientation of the clay layers and the existence of an ideal content of vermiculite (VMT) incorporated in the foam matrix. Full article

In this study, 3D premixed turbulent ammonia-hydrogen flames in air were studied using DNS. Mixtures with 75%, 50% and 25% ammonia (by mole fraction in the fuel mixture) and equivalence ratios of 0.8, 1.0 and 1.2 were studied. The studies were conducted in a decaying turbulence field with an initial Karlovitz number of 10. The flame structure and the influence of ammonia and the equivalence ratio were first studied. It was observed that the increase in equivalence ratio smoothened out the small scale wrinkles while leading to strongly curved leading edges. Increasing the amount of hydrogen in the fuel mixtures also led to increasingly distorted flames. These effects are attributed to local increases in the equivalence ratio due to the preferential diffusion effects of hydrogen. The effects of curvature on the flame chemistry were studied by looking at fuel consumption rates and key reactions. It was observed that the highly mobile H₂ and H species were responsible for differential rates of fuel consumption in the positively curved and negatively curved regions of the flame. The indication of a critical amount of hydrogen in the fuel mixture was observed, after which the trends of reactions involving H radical reactions were flipped with respect to the sign of the curvature. This also has implications on NO formation. Finally, the spatial profiles of heat release and temperature for 50% hydrogen were studied, which showed that the flame brush of the lean case increases in width and that the flame propagation is slow for stoichiometric and rich cases attributed to suppression of flame chemistry due to preferential diffusion effects. Full article

Since both ethanol and acetone are the main components in many alternative fuels, research on the burning characteristics of ethanol-acetone blends is important to understand the combustion phenomena of these alternative fuels. In the present study, the burning characteristics of ethanol-acetone fuel blends are investigated at a temperature of 358 K and pressure of 0.1 MPa with equivalence ratios ranging from 0.7 to 1.4. Ethanol at 100% vol., 25% vol. ethanol/75% vol. acetone, 50% vol. ethanol/50% vol. acetone, 75% vol. ethanol/25% vol. acetone, and 100% vol. acetone are studied by the constant volume combustion chamber (CVCC) method. The results show that the laminar burning velocities of the fuel blends are between that of 100% vol. acetone and 100% vol. ethanol. As the ethanol content increases, the laminar burning velocities of the mixed fuels increase. Furthermore, a detailed chemical kinetic mechanism (AramcoMech 3.0) is used for simulating the burning characteristics of the mixtures. The directed relation graph (DRG), DRG with error propagation (DRGEP), sensitivity analysis (SA), and full species sensitivity analysis (FSSA) are used for mechanism reduction. The flame structure of the skeletal mechanism does not change significantly, and the concentration of each species remains basically the same value after the reaction. The numbers of reactions and species are reduced by 90% compared to the detailed mechanism. Sensitivity and reaction pathway analyses of the burning characteristics of the mixtures indicate that the reaction C₂H₂+H(+M)<=>C₂H₃(+M) is the key reaction. Full article

Knowledge of the drying properties of tobacco in high temperatures above 100 °C and its dust are crucial in the design of dryers, both in the optimization of the superheated-steam-drying process and in the correct selection of innovative explosion protection and mitigation systems. In this study, tobacco properties were determined and incorporated into the proposed model of an expanding superheated steam flash dryer. The results obtained from the proposed model were validated by using experimental data yielded during test runs of an industrial scale of a closed-loop expansion dryer on lamina cut tobacco. Moreover, the explosion and fire properties of tobacco dust before and after the superheated steam-drying process at 160, 170, 180, and 190 °C were experimentally investigated, using a 20 L spherical explosion chamber, a hot plate apparatus, a Hartmann tube apparatus, and a Godbert–Greenwald furnace apparatus. The results indicate that the higher the drying temperature, the more likely the ignition of the dust tobacco cloud, the faster the explosion flame propagation, and the greater the explosion severity. Tobacco dust is of weak explosion class. Dust obtained by drying with superheated steam at 190 °C is characterized by the highest value of explosion index amounting to 109 ± 14 m·bar·s⁻¹, the highest explosion pressure rate (405 ± 32 bar/s), and the maximum explosion pressure (6.7 ± 0.3 bar). The prevention of tobacco-dust accumulation and its removal from the outer surfaces of machinery and equipment used in the superheated steam-drying process are highly desirable. Full article

A recent predictive scenario of premixed flame propagation in unobstructed passages is extended to account for obstructions that can be encountered in facilities dealing with explosive materials such as in coalmines. Specifically, the theory of globally-spherical, self-accelerating premixed expanding flames and that of flame acceleration in obstructed conduits are combined to form a new analytical formulation. The coalmining configuration is imitated by two-dimensional and cylindrical passages of high aspect ratio, with a comb-shaped array of tightly placed obstacles attached to the walls. It is assumed that the spacing between the obstacles is much less or, at least, does not exceed the obstacle height. The passage has one extreme open end such that a flame is ignited at a closed end and propagates to an exit. The key stages of the flame evolution such as the velocity of the flame front and the run-up distance are scrutinized for variety of the flame and mining parameters. Starting with gaseous methane-air and propane-air flames, the analysis is subsequently extended to gaseous-dusty environments. Specifically, the coal (combustible, i.e., facilitating the fire) and inert (such as sand, moderating the process) dust and their combinations are considered, and the impact of the size and concentration of the dust particles on flame acceleration is quantified. Overall, the influence of both the obstacles and the combustion instability on the fire scenario is substantial, and it gets stronger with the blockage ratio. Full article

The effects of Lewis number on the physical mechanisms pertinent to the curvature evolution have been investigated using three-dimensional Direct Numerical Simulation (DNS) of spherically expanding turbulent premixed flames with characteristic Lewis number of $Le=0.8$ , 1.0 and 1.2. It has been found that the overall burning rate and the extent of flame wrinkling increase with decreasing Lewis number $Le$ , and this tendency is particularly prevalent for the sub-unity Lewis number (e.g., $Le=0.8$ ) case due to the occurrence of the thermo-diffusive instability. Accordingly, the $Le=0.8$ case has been found to exhibit higher probability of finding saddle topologies with large magnitude negative curvatures in comparison to the corresponding $Le=1.0$ and 1.2 cases. It has been found that the terms in the curvature transport equation due to normal strain rate gradients and curl of vorticity arising from both fluid flow and flame normal propagation play pivotal roles in the curvature evolution in all cases considered here. The net contribution of the source/sink terms of the curvature transport equation tends to increase the concavity and convexity of the flame surface in the negatively and positively curved locations, respectively for the $Le=0.8$ case. This along with the occurrence of high and low temperature (and burning rate) values at the positively and negatively curved zones, respectively acts to augment positive and negative curved wrinkles induced by turbulence in the $Le=0.8$ case, which is indicative of thermo-diffusive instability. By contrast, flame propagation effects tend to weakly promote the concavity of the negatively curved cusps, and act to decrease the convexity of the highly positively curved bulges in the $Le=1.0$ and 1.2 cases, which are eventually smoothed out due to high and low values of displacement speed $S_d$ at negatively and positively curved locations, respectively. Thus, flame propagation tends to smoothen the flame surface in the $Le=1.0$ and 1.2 cases. Full article

This paper compares numerical simulations with experiments to study the deformation of lean premixed spherically expanding flames under a negative direct current (DC) electric field. The experiments, including the flame deformation and the ionic distribution on the flame surface were investigated in a mesh to mesh electric field. Besides, a numerical model of adding an electric body force to the positive ions on the flame surface was also established to perform a relevant simulation. Results show that the spherical flame will acquire an elliptical shape with a marked flame stretch in the horizontal direction and a slight inhibition in the vertical direction under a negative DC electric field. Meanwhile, a non-uniform ionic distribution on the flame surface was also detected by the Langmuir probe. The simulation results from the numerical model show good agreement with experimental data. According to the velocity field analysis in simulation, it was found the particular motion of positive ions and neutral molecules on the flame surface should be responsible for the special flame deformation. When a negative DC electric field was applied, the majority of positive ions and colliding neutral molecules will form an ionic flow along the flame surface by a superposition of the electric field force and the aerodynamic drag. The ionic flow was not uniform and mainly formed on the upper and lower sides, so it will lead to a non-uniform ionic distribution along the flame surface. What’s more, this ionic flow will also induce two vortexes both inside and outside of the flame surface due to viscosity effects. The external vortexes could produce an entraining effect on the premixed gas and take away the heat from the flame surface by forced convection, and then suppress the flame propagation in the vertical direction, while, the inner vortexes would scroll the burned zones and induce an inward flow at the horizontal center, which could be the reason for the pitted structure at the horizontal center when a high voltage was applied. Full article

The laminar combustion characteristics of blends of isooctane and C1–C5 primary alcohols (i.e., methanol, ethanol, n-propanol, n-butanol and n-pentanol) were investigated using the spherical expanding flame methodology in a constant volume chamber at various equivalence ratios and volume fractions of alcohol. The stretch effect was removed using the nonlinear methodology. The results indicate that the laminar flame speeds of alcohol-isooctane blends increase monotonously with the increasing volume fraction of alcohol. Among the five alcohols, the addition of methanol is identified to be the most effective in enhancing laminar flame speed. The addition of ethanol results in an approximately equivalent laminar flame speed enhancement rate as those of n-propanol, n-butanol and n-pentanol at ratios of 0.8 and 1.5, and a higher rate at 1.0 and 1.2. An empirical correlation is provided to describe the laminar flame speed variation with the volume fraction of alcohol. Meanwhile, the laminar flame speed increases with the mass content of oxygen in the fuel blends. At the equivalence ratio of 0.8 and fixed oxygen content, similar laminar flame speeds are observed with different alcohols blended into isooctane. Nevertheless, with the increase of equivalence ratio, heavier alcohol-isooctane blends tend to exhibit higher values. Markstein lengths of alcohol-isooctane blends decrease with the addition of alcohol into isooctane at 0.8, 1.0 and 1.2, however they increase at 1.5. This is consistent with the behavior deduced from the Schlieren images. Full article

Buoyant unstable behavior in initially spherical lean hydrogen-air premixed flames within a center-ignited combustion vessel have been studied experimentally under a wide range of pressures (including reduced, normal, and elevated pressures). The experimental observations show that the flame front of lean hydrogen-air premixed flames will not give rise to the phenomenon of cellular instability when the equivalence ratio has been reduced to a certain value, which is totally different from the traditional understanding of the instability characteristics of lean hydrogen premixed flames. Accompanied by the smoothened flame front, the propagation mode of lean hydrogen premixed flames transitions from initially spherical outwardly towards upwardly when the flames expand to certain sizes. To quantitatively investigate such buoyant instability behaviors, two parameters, “float rate (ψ)” and “critical flame radius (R_cr)”, have been proposed in the present article. The quantitative results demonstrate that the influences of initial pressure (P_int) on buoyant unstable behaviors are different. Based on the effects of variation of density difference and stretch rate on the flame front, the mechanism of such buoyant unstable behaviors has been explained by the competition between the stretch force and the results of gravity and buoyancy, and lean hydrogen premixed flames will display buoyant unstable behavior when the stretch effects on the flame front are weaker than the effects of gravity and buoyancy. Full article

Experimental characterization of the burning behavior of gaseous mixtures has been carried out, analyzing spherical expanding flames. Tests were performed in the Device for Hydrogen-Air Reaction Mode Analysis (DHARMA) laboratory of Istituto Motori—CNR. Based on a high-pressure, constant-volume bomb, the activity is aimed at populating a systematic database on the burning properties of CH₄, H₂ and other species of interest, in conditions typical of internal combustion (i.c.) engines and gas turbines. High-speed shadowgraph is used to record the flame growth, allowing to infer the laminar burning parameters and the flame stability properties. Mixtures of CH₄, H₂ and air have been analyzed at initial temperature 293÷305 K, initial pressure 3÷18 bar and equivalence ratio = 1.0. The amount of H₂ in the mixture was 0%, 20% and 30% (vol.). The effect of the initial pressure and of the Hydrogen content on the laminar burning velocity and the Markstein length has been evaluated: the relative weight and mutual interaction has been assessed of the two controlling parameters. Analysis has been carried out of the flame instability, expressed in terms of the critical radius for the onset of cellularity, as a function of the operating conditions. Full article

A thermodynamic model has been developed to calculate burning speed and entropy production of transient expending spherical laminar flame in an enclosed vessel. The model also predicts the particle trajectories of both unburned and burned gases in the vessel. The input to this model is the dynamic pressure rise due to combustion process. The unburned gases are divided into three regions: The core unburned gases which are compressed isentropically, the vessel walls and electrodes boundary layer gases, and gases in the preheat zone of the flames. The burned gases are in many shells having the same pressure but different temperatures. The model also includes radiation losses from the burned gases to vessel walls. Entropy production due to irreversibility has been calculated by applying entropy balance to the gas mixtures. Burning speed of premixed n-decane air mixture has been reported for temperatures and pressures along an isentrope. Full article
