The blue coloration model of a closed pond, Ao-ike Pond, Aomori Prefecture, Japan, was formulated in terms of radiance by applying a theory of observation devices proposed by Szirmay-Kalos (2008) and Hanaishi’s reverse ray tracing method. In this model, three potential contributions to the coloration were considered; irregular reflection at the Lambertian pond bottom, density fluctuation scattering by water, and Mie scattering by suspended solids. By utilizing model formulas for these mechanisms, some parameters were determined in order to duplicate the images of the pond surface without solar shading by tree leaves above the pond surface, in addition to the images with sunbeam trajectories by solar radiations passing through tree leaves, which are emitted from the water and visible on the surface. Simulating the pictures of the pond surface and the sun-beam-image analyses revealed that the blue colorations of Ao-ike Pond are mainly produced (1) by the density fluctuation scattering of water itself and the white Mie scattering by suspended solids and (2) by the red-light absorption by water in the optical paths before and after the two scatterings. Then, the density fluctuation scattering of water and the Mie scattering by suspended solids exhibited contributions of almost equal magnitude. The contribution of irregular reflections at the pond bottom was judged to be relatively small. Full article

This study focuses on the recovery of information from shadowed pixels in RGB or multispectral imagery sensed from unmanned aerial vehicles (UAVs). The proposed technique is based on the concept that a property characterizing a given surface is its spectral reflectance, i.e., the ratio between the flux reflected by the surface and the radiant flux received by the surface, and this ratio is usually similar under direct-plus-diffuse irradiance and under diffuse irradiance when a Lambertian behavior can be assumed. Scene-dependent elements, such as trees, shrubs, man-made constructions, or terrain relief, can block part of the direct irradiance (usually sunbeams), in which part of the surface only receives diffuse irradiance. As a consequence, shadowed surfaces comprising pixels of the image created by the UAV remote sensor appear. Regardless of whether the imagery is analyzed by means of photointerpretation or digital classification methods, when the objective is to create land cover maps, it is hard to treat these areas in a coherent way in terms of the areas receiving direct and diffuse irradiance. The hypothesis of the present work is that the relationship between irradiance conditions in shadowed areas and non-shadowed areas can be determined by following classical empirical line techniques for fulfilling the objective of a coherent treatment in both kinds of areas. The novelty of the presented method relies on the simultaneous recovery of information in non-shadowed and shadowed areas by the in situ spectral reflectance measurements of characterized Lambertian targets followed by smoothing of the penumbra area. Once in the lab, firstly, we accurately detected the shadowed pixels by combining two well-known techniques for the detection of the shadowed areas: (1) using a physical approach based on the sun’s position and the digital surface model of the area covered by the imagery; and (2) the image-based approach using the histogram properties of the intensity image. In this paper, we present the benefits of the combined usage of both techniques. Secondly, we applied a fit between non-shadowed and shadowed areas by using a twin set of spectrally characterized target sets. One set was placed under direct and diffuse irradiance (non-shadowed targets), whereas the second set (with the same spectral characteristics) was placed under diffuse irradiance (shadowed targets). Assuming that the reflectance of the homologous targets of each set was the same, we approximated the diffuse incoming irradiance through an empirical line correction. The model was applied to all detected shadowed areas in the whole scene. Finally, a smoothing filter was applied to the penumbra transitions. The presented empirical method allowed the operational and coherent recovery of information from shadowed areas, which is very common in high-resolution UAV imagery. Full article
