Search Results (15)

To address the limitations of one-dimensional vibration signals in convolutional neural networks and the insufficient feature extraction capability of traditional single data processing methods under complex operating conditions, this paper proposes a novel fault diagnosis method that integrates dual-graph transformation and an improved residual network. Firstly, the one-dimensional vibration signals are converted into time–frequency representations using the short-time Fourier transform (STFT) and the synchrosqueezed wavelet transform (SWT). Subsequently, these dual-domain representations are fed in parallel into a customized parallel two-dimensional residual network (P2D-Sk-ResNet), which incorporates the selective kernel network (SKNet) mechanism into a ResNet architecture. This design enables adaptive multi-scale feature extraction. Finally, the features from the fully connected layer are classified using the extreme gradient boosting (XGBoost) algorithm to complete the fault diagnosis task. Comparative experiments demonstrate that the proposed STFT-SWT-P2D-Sk-ResNet-XGBoost achieves a diagnostic accuracy of 98.51% under constant load conditions, significantly outperforming several baseline models. Furthermore, the model exhibits superior generalization capability under varying load conditions and strong robustness in noisy environments. The proposed method provides a valuable and practical reference for intelligent fault diagnosis in industrial applications. Full article

The proliferation of renewable energy sources and distributed generation systems interfaced to the grid by power electronics systems is forcing us to better understand the issues arising due to the quality of electrical signals generated through these devices. Understanding and monitoring these harmonics is crucial to ensure the smooth and seamless operation of these networks, as well as to protect and manage the renewable energy sources-based power system. In this paper, we propose an advanced method of dynamic modal decomposition, called Higher-Order Dynamic Mode Decomposition (HODMD), one of the recently proposed data-driven methods used to estimate the frequency/amplitude and phase with high resolution, to identify the harmonic spectrum in power systems dominated by renewable energy generation. In the proposed method, several time-shifted copies of the measured signals are integrated to create the initial data matrices. A hard thresholding technique based on singular value decomposition is applied to eliminate ambiguities in the measured signal. The proposed method is validated and compared to Synchrosqueezing Transform based on Short-Time Fourier Transform (SST-STFT) and the Concentration of Frequency and Time via Short-Time Fourier Transform (ConceFT-STFT) using synthetic signals and real measurements, demonstrating its practical effectiveness in identifying harmonics in emerging power networks. Finally, the effectiveness of the proposed methodology is analyzed on the energy storage-based laboratory-scale microgrid setup using an Opal-RT-based real-time simulator. Full article

Worldwide, heart disease is the leading cause of mortality. Cardiac auscultation, when conducted by a trained professional, is a non-invasive, cost-effective, and readily available method for the initial assessment of cardiac health. Automated heart sound analysis offers a promising and accessible approach to supporting cardiac diagnosis. This work introduces a novel method for classifying heart sounds as normal or abnormal by leveraging time-frequency representations. Our approach combines three distinct time-frequency representations—short-time Fourier transform (STFT), mel-scale spectrogram, and wavelet synchrosqueezed transform (WSST)—to create images that enhance classification performance. These images are used to train five convolutional neural networks (CNNs): AlexNet, VGG-16, ResNet50, a CNN specialized in STFT images, and our proposed CNN model. The method was trained and tested using three public heart sound datasets: PhysioNet/CinC Challenge 2016, CirCor DigiScope Phonocardiogram Dataset 2022, and another open database. While individual representations achieve maximum accuracy of ≈85.9%, combining STFT, mel, and WSST boosts accuracy to ≈99%. By integrating complementary time-frequency features, our approach demonstrates robust heart sound analysis, achieving consistent classification performance across diverse CNN architectures, thus ensuring reliability and generalizability. Full article

This study proposes a novel rolling bearing fault diagnosis technique based on a synchrosqueezing wavelet transform (SWT) and a transfer residual convolutional neural network (TRCNN) designed to address the difficulties of feature extraction caused by the non-stationarity of fault signals, as well as the issue of low fault diagnosis accuracy resulting from small sample quantities. This approach transforms the one-dimensional vibration signal into time–frequency diagrams using an SWT based on complex Morlet wavelet basis functions, which redistributes (squeezes) the values of the wavelet coefficients at different localized points in a time–frequency plane to the estimated instantaneous frequencies. This allows the energy to be more fully concentrated in actual corresponding frequency components. This strategy improves both the time–frequency aggregation and the resolution, which better reflects the eigenvalues of non-stationary signals. In this process, transfer learning and a residual structure are used in the training of a convolutional neural network. The resulting time–frequency diagrams, acquired using the steps discussed above, are then input to the TRCNN for diagnosis. A series of validation experiments confirmed that applying the TRCNN structure made it possible to achieve high diagnostic accuracy, even when training the network with only a small number of fault samples, as all 12 fault types from the test dataset were diagnosed correctly. Further simulation experiments demonstrated that our proposed method improved fault diagnosis accuracy compared to that of conventional techniques (with increases of 1.74% over RCNN, 1.28% over TCNN, 1.62% over STFT, 1.73% over WT, 2.83% over PWVD, and 1.39% over STFA-PD). In addition, diagnostic accuracy reached 100% during the application of three-time transfer learning, validating the effectiveness of the proposed method for rolling bearing fault diagnosis. Full article

In engineering applications, the accuracy of on-load tap changer (OLTC) mechanical fault identification methods based on vibration signals is constrained by the quantity and quality of the samples. Therefore, a novel small-sample-size OLTC mechanical fault identification method incorporating short-time Fourier transform (STFT), synchrosqueezed wavelet transform (SWT), a dual-stream convolutional neural network (DSCNN), and support vector machine (SVM) is proposed. Firstly, the one-dimensional time-series vibration signals are transformed using STFT and SWT to obtain time–frequency graphs. STFT time–frequency graphs capture the global features of the OLTC vibration signals, while SWT time–frequency graphs capture the local features of the OLTC vibration signals. Secondly, these time–frequency graphs are input into the CNN to extract key features. In the fusion layer, the feature vectors from the STFT and SWT graphs are combined to form a fusion vector that encompasses both global and local time–frequency features. Finally, the softmax classifier of the traditional CNN is replaced with an SVM classifier, and the fusion vector is input into this classifier. Compared to the traditional fault identification methods, the proposed method demonstrates higher identification accuracy and stronger generalization ability under the conditions of small sample sizes and noise interference. Full article

Intrapulse modulation classification of radar signals plays an important role in modern electronic reconnaissance, countermeasures, etc. In this paper, to improve the recognition rate at low signal-to-noise ratio (SNR), we propose a recognition method using the second-order short-time Fourier transform (STFT)-based synchrosqueezing transform (FSST2) combined with a modified convolution neural network, which we name MeNet. In particular, the radar signals are first preprocessed via the time–frequency analysis and STFT-based FSST2. Then, the informative features of the time–frequency images (TFIs) are deeply learned and classified through the MeNet with several specific convolutional blocks. The simulation results show that the overall recognition rate for seven types of intrapulse modulation radar signals can reach 95.6%, even when the SNR is −12 dB. Compared with other networks, the excellent recognition rate proves the superiority of our method. Full article

Accurate vibration classification using inertial measurement unit (IMU) data is critical for various applications such as condition monitoring and fault diagnosis. This study proposes a novel convolutional neural network (CNN) based approach, the IMU6DoF-SST-CNN in six variants, for robust vibration classification. The method utilizes Fourier synchrosqueezed transform (FSST) and wavelet synchrosqueezed transform (WSST) for time-frequency analysis, effectively capturing the temporal and spectral characteristics of the vibration data. Additionally, was used the IMU6DoF-SST-CNN to explore three different fusion strategies for sensor data to combine information from the IMU’s multiple axes, allowing the CNN to learn from complementary information across various axes. The efficacy of the proposed method was validated using three datasets. The first dataset consisted of constant fan velocity data (three classes: idle, normal operation, and fault) at 200 Hz. The second dataset contained variable fan velocity data (also with three classes: normal operation, fault 1, and fault 2) at 2000 Hz. Finally, a third dataset of Case Western Reserve University (CWRU) comprised bearing fault data with thirteen classes, sampled at 12 kHz. The proposed method achieved a perfect validation accuracy for the investigated vibration classification task. While all variants of the method achieved high accuracy, a trade-off between training speed and image generation efficiency was observed. Furthermore, FSST demonstrated superior localization capabilities compared to traditional methods like continuous wavelet transform (CWT) and short-time Fourier transform (STFT), as confirmed by image representations and interpretability analysis. This improved localization allows the CNN to effectively capture transient features associated with faults, leading to more accurate vibration classification. Overall, this study presents a promising and efficient approach for vibration classification using IMU data with the proposed IMU6DoF-SST-CNN method. The best result was obtained for IMU6DoF-SST-CNN with FSST and sensor-type fusion. Full article

Time–frequency analysis is an important tool used for the processing and interpretation of non-stationary signals, such as seismic data and remote sensing data. In this paper, based on the novel short-time fractional Fourier transform (STFRFT), a new modified STFRFT is first proposed which can also generalize the properties of the modified short-time Fourier transform (STFT). Then, in the modified STFRFT domain, we derive the instantaneous frequency estimator for the chirp signal and present a new type of synchrosqueezing STFRFT (FRSST). The proposed FRSST presents many results similar to those of the synchrosqueezing STFT (FSST), and it extends the harmonic signal to a chirp signal that offers attractive new features. Furthermore, we provide a detailed analysis of the signal reconstruction, theories, and some properties of the proposed FRSST. Several experiments are conducted, and all of the results illustrate that the proposed FRSST is more effective than the FSST. Finally, based on the linear amplitude modulation and frequency modulation signal, we present a derivation for analyzing the limitations of the FRSST. Full article

For the problem of low time-frequency aggregation of the short-time Fourier transform (STFT), which causes the parameter estimation performance degradation of linear frequency modulation (LFM) signals at low signal-to-noise ratio (SNR), second-order synchrosqueezing transform (SSST) is proposed based on the square of STFT amplitude. The time-frequency resolution and energy aggregation are improved by means of squeezing and reassigning the time-frequency spectrum. Meanwhile, in order to decrease the calculation of classical parameter estimation methods, the Hough transform is used for rough estimation, and then the fractional Fourier transform (FRFT) is used for accuracy estimation based on the Renyi entropy. The simulation result shows that higher estimation accuracy is obtained at low SNR, and it has better robustness. Full article

We propose a method based on Synchrosqueezing Transform (SST) for vibration event analysis and identification in Phase Sensitive Optical Time-Domain Reflectometry (Φ-OTDR) systems. SST has high time-frequency resolution and phase information, which can distinguish and enhance different vibration events. We use six tap events with different intensities and six other events as experimental data and test the effect of attenuation. We use Visual Geometry Group (VGG), Vision Transformer (ViT), and Residual Network (ResNet) as deep classifiers for the SST transformed data. The results show that our method outperforms the methods based on Continuous Wavelet Transform (CWT) and Short-Time Fourier Transform (STFT), while ResNet is the best classifier. Our method can achieve high recognition rate under different signal strengths, event types, and attenuation levels, which shows its value for Φ-OTDR system. Full article

The synchrosqueezing transform (SST) has attracted much attention as a post-processing technique since it was proposed. In recent years, improvements to SST have been made. However, the existing methods are mainly based on the time-domain signal model, and the weak frequency modulation assumption for the components composing the signal is always taken into account. Thus, the signals characterized by a rapidly changing instantaneous frequency (IF) may fail to be adequately tackled. To address this problem, the paper presents a novel seismic time–frequency analysis method via synchrosqueezing transform where a frequency-domain Gaussian modulated linear chirp model is utilized to deduce the SST. The group delay (GD) rather than the IF estimator is implemented to compute an estimation of the ridge. Furthermore, a new synchrosqueezing operator is constructed to rearrange the energy around the ridge. A synthetic example verifies the efficiency and robustness of the proposed SST method, which generates better results than some classic time–frequency analysis (TFA) approaches, e.g., short-time Fourier transform (STFT) and STFT-based SST (FSST). A field dataset further demonstrates this method’s potential in the delineation of subsurface geological structures. Full article

In a previous work, we proposed a time-frequency analysis called instantaneous spectral analysis (ISA), which generalizes the notion of the Fourier spectrum and in which instantaneous frequency is utilized to the fullest extent. In this paper, we recast both the Fourier transform (FT) and filterbank (FB) interpretations of the short-time Fourier transform (STFT) as instantaneous spectra. We show that to recast the FB interpretation of STFT as an instantaneous spectrum with valid structure, frequency reassignment is a fundamental necessity, thus demonstrating that this IS is closely related to the synchrosqueezed STFT. This result provides a new theoretical motivation for the synchrosqueezed STFT. Finally, we illustrate through example the instantaneous spectra corresponding to the FT and FB interpretations of STFT using two closed-form examples. Full article

The micro-Doppler signal generated by the rotors of an Unmanned Aerial Vehicle (UAV) contains the structural features and motion information of the target, which can be used for detection and classification of the target, however, the standard STFT has the problems such as the lower time-frequency resolution and larger error in rotor parameter estimation, an FRFT (Fractional Fourier Transform)-FSST (STFT based synchrosqueezing)-based method for micro-Doppler signal detection and parameter estimation is proposed in this paper. Firstly, the FRFT is used in the proposed method to eliminate the influence of the velocity and acceleration of the target on the time-frequency features of the echo signal from the rotors. Secondly, the higher time-frequency resolution of FSST is used to extract the time-frequency features of micro-Doppler signals. Moreover, the specific solution methodologies for the selection of window length in STFT and the estimation of rotor parameters are given in the proposed method. Finally, the effectiveness and accuracy of the proposed method for target detection and rotor parameter estimation are verified through simulation and measured data. Full article

High-rate dynamic systems are defined as engineering systems experiencing dynamic events of typical amplitudes higher than 100 g${}_n$ for a duration of less than 100 ms. The implementation of feedback decision mechanisms in high-rate systems could improve their operations and safety, and even be critical to their deployment. However, these systems are characterized by large uncertainties, high non-stationarities, and unmodeled dynamics, and it follows that the design of real-time state-estimators for such purpose is difficult. In this paper, we compare the promise of five time-frequency representation (TFR) methods at conducting real-time state estimation for high-rate systems, with the objective of providing a path to designing implementable algorithms. In particular, we examine the performance of the short-time Fourier transform (STFT), wavelet transformation (WT), Wigner–Ville distribution (WVD), synchrosqueezed transform (SST), and multi-synchrosqueezed transform (MSST) methods. This study is conducted using experimental data from the DROPBEAR (Dynamic Reproduction of Projectiles in Ballistic Environments for Advanced Research) testbed, consisting of a rapidly moving cart on a cantilever beam that acts as a moving boundary condition. The capability of each method at extracting the beam’s fundamental frequency is evaluated in terms of precision, spectral energy concentration, computation speed, and convergence speed. It is found that both the STFT and WT methods are promising methods due to their fast computation speed, with the WT showing particular promise due to its faster convergence, but at the cost of lower precision on the estimation depending on circumstances. Full article

Respiration rate (RR) provides useful information for assessing the status of a patient. We propose RR estimation based on photoplethysmography (PPG) because the blood perfusion dynamics are known to carry information on breathing, as respiration-induced modulations in the PPG signal. We studied the use of amplitude variability of transmittance mode finger PPG signal in RR estimation by comparing four time-frequency (TF) representation methods of the signal cascaded with a particle filter. The TF methods compared were short-time Fourier transform (STFT) and three types of synchrosqueezing methods. The public VORTAL database was used in this study. The results indicate that the advanced frequency reallocation methods based on synchrosqueezing approach may present improvement over linear methods, such as STFT. The best results were achieved using wavelet synchrosqueezing transform, having a mean absolute error and median error of 2.33 and 1.15 breaths per minute, respectively. Synchrosqueezing methods were generally more accurate than STFT on most of the subjects when particle filtering was applied. While TF analysis combined with particle filtering is a promising alternative for real-time estimation of RR, artefacts and non-respiration-related frequency components remain problematic and impose requirements for further studies in the areas of signal processing algorithms an PPG instrumentation. Full article
