Search Results (17)

Microwave camera provides 3-D high-resolution radar images at video frame rates, enabling the capture of dynamic target features. Multiple-input–multiple-output (MIMO) array-based 3-D radar imaging system requires fewer antennas, which effectively reduces hardware costs. Due to the limited computational resources of the miniaturized MIMO microwave camera, real-time processing of a large amount of 3-D echo data requires an imaging algorithm that has both real-time performance and large output spatial extent. This paper presents the limited output spatial extent and spatial aliasing in existing MIMO wavenumber domain algorithms through theoretical derivation and simulation. To suppress aliasing while expanding the output spatial extent, an optimization approach for the wavenumber domain algorithms is proposed. The improved wavenumber domain algorithms divide the target area into multiple sub-blocks, and a broader range of imaging results is obtained through independent imaging of the sub-blocks and a spatial aliasing suppression filter. Simulation results show that the improved wavenumber domain algorithms effectively suppress the aliasing energy of each sub-block while maintaining the advantage of low time complexity. Expansion of output spatial extent in existing MIMO wavenumber domain algorithms is achieved. Full article

This paper presents an improved algorithm for retrieving ocean surface currents from X-band marine radar images. The original polar current shell (PCS) method begins with a 3D fast Fourier transform (FFT) of the radar image sequence, followed by the extraction of the dispersion shell from the 3D image spectrum, which is then transformed into a PCS using polar coordinates. Building on this foundation, the improved approach is to analyze all data points corresponding to different wavenumber magnitudes in the PCS domain rather than analyzing each specific wavenumber magnitude separately. In addition, kernel density estimation (KDE) to identify high-density directions, interquartile range filtering to remove outliers, and symmetry-based filtering to further reduce noise by comparing data from opposite directions are also utilized for further improvement. Finally, a single curve fitting is applied to the filtered data rather than conducting multiple curve fittings as in the original method. The algorithm is validated using simulated data and real radar data from both the Decca radar, established in 2008, and the Koden radar, established in 2017. For the 2008 Decca radar data, the improved PCS method reduced the root-mean-square deviation (RMSD) for speed estimation by 0.06 m/s and for direction estimation by 3.8° while improving the correlation coefficients (CCs) for current speed by 0.06 and direction by 0.07 compared to the original PCS method. For the 2017 Koden radar data, the improved PCS method reduced the RMSD for speed by 0.02 m/s and for direction by 4.6°, with CCs being improved for current speed by 0.03 and direction by 0.05 compared to the original PCS method. Full article

The performance of marine radar constant false alarm rate (CFAR) detection method is significantly influenced by the modeling of sea clutter distribution and detector decision rules. The false alarm rate and detection rate are therefore unstable. In order to address low CFAR detection performance and the modeling problem of non-uniform, non-Gaussian, and non-stationary sea clutter distribution in marine radar images, in this paper, a CFAR detection method in generalized extreme value distribution modeling based on marine radar space-time filtering background clutter is proposed. Initially, three-dimensional (3D) frequency wave-number (space-time) domain adaptive filter is employed to filter the original radar image, so as to obtain uniform and stable background clutter. Subsequently, generalized extreme value (GEV) distribution is introduced to integrally model the filtered background clutter. Finally, Inclusion/Exclusion (IE) with the best performance under the GEV distribution is selected as the clutter range profile CFAR (CRP-CFAR) detector decision rule in the final detection. The proposed method is verified by utilizing real marine radar image data. The results indicate that when the $P_{fa}$ is set at 0.0001, the proposed method exhibits an average improvement in $P_D$ of 2.3% compared to STAF-RCBD-CFAR, and a 6.2% improvement compared to STCS-WL-CFAR. When the $P_{fa}$ is set at 0.001, the proposed method exhibits an average improvement in $P_D$ of 6.9% compared to STAF-RCBD-CFAR, and a 9.6% improvement compared to STCS-WL-CFAR. Full article

The gravity and gradient anomalies contain valuable information about the underground geological structures at various depths. Deep and shallow buried source bodies are able to be identified through multi-scale field separation processes, and visual comprehensions of geological structures can be obtained via 3D density inversion techniques. In this study, we propose an improved 3D imaging strategy based on gravitational field separation using the preferential continuation filter. This strategy incorporates the relationship between spectral features and buried depths of source bodies, allowing for a one-step transformation from planar gravity and full-tensor gradient field observations to a 3D density structure in the wave-number domain. Synthetic tests validate the effectiveness and robustness of the gravity and gradient imaging approaches, highlighting their advantages in high vertical resolution and low computational requirements. Nonetheless, it should be noted that the imaging effects of horizontal gradients ${\Gamma }_{xx}$ and ${\Gamma }_{yy}$ are unsatisfactory due to their weak noise resistance. Thus, they are not suitable for real data applications. The other imaging approaches are further applied to recover the subsurface 3D density structure beneath the Weishan cone in Wudalianchi Volcanic Field, Northeastern China. Our results provide insights into the possible location and shape of the low-density magma chamber. Also, the potential presence of partial melts is inferred and supported from a gravity perspective. The primary advantage of these approaches is their ability to generate a reasonable geological model in scenarios with limited prior information and physical property constraints. As a result, they have significant practical value in the field of applied geophysics, including mineral exploration and volcanology studies. Full article

Ground-penetrating radar (GPR) is a classic geophysical exploration method that utilizes the emission and reception of electromagnetic waves to non-destructively detect target objects in the target medium. It has been widely applied in various fields such as pipeline detection, cavity detection, and rebar detection. However, GPR systems are susceptible to environmental clutter interference, which poses challenges for data interpretation and subsequent processing. In this paper, the separability of clutter and target signal in the frequency-wavenumber (F-K) domain is validated through modeling, leading to the proposal of a comprehensive clutter removal method based on the F-K domain for complex scenarios. The direct coupling wave is initially eliminated by applying a peak matching mean subtraction filter, which avoids the artifacts. Subsequently, the F-K domain transformation is performed and surface clutter undulations are effectively removed using a method based on singular value decomposition and k-means clustering. Finally, an angle filter with Gaussian tapering at the edges is designed based on physical models to efficiently eliminate linear interference without undesired ringing interference. The commonly used clutter removal algorithms, including mean subtraction (MS), singular value decomposition (SVD), robust principal component analysis (RPCA), and traditional F-K filtering methods, are compared with the proposed algorithm on both the numerical simulated data and actual GPR data. The results from visual and quantitative analysis confirm that our proposed method is more effective than current commonly used clutter suppression algorithms. We have successfully enhanced the Signal-to-Clutter Ratio (SCR) of the GPR data, resulting in an Improvement Factor (IF) of 30.63 dB, 23.59 dB, and 30.60 dB for simulated data, experimental data, and TU1208 public data, respectively. The detection capability of buried targets is enhanced, thereby establishing a solid foundation for subsequent data interpretation and target identification. Full article

Polar format algorithm (PFA) is a widely used high-resolution SAR imaging algorithm that can be implemented in advanced widefield staring synthetic aperture radar (WFS-SAR). However, existing algorithms have limited analysis in wavefront curvature error (WCE) and are challenging to apply to WFS-SAR with high-resolution and large-swath scenes. This paper proposes an extended polar format algorithm for joint envelope and phase error correction in WFS-SAR imaging with maneuvering trajectory. The impact of the WCE and residual acceleration error (RAE) are analyzed in detail by deriving the specific wavenumber domain signal based on the mapping relationship between the geometry space and wavenumber space. Subsequently, this paper improves the traditional WCE compensation function and introduces a new range cell migration (RCM) recalibration function for joint envelope and phase error correction. The 2D precisely focused SAR image is acquired based on the spatially variant inverse filtering in the final. Simulation experiments validate the effectiveness of the proposed method. Full article

Aerospace thin-walled structures are susceptible to various forms of damage and they can be effectively inspected using Lamb wavefields. However, Lamb wavefields contain at least two dispersive modes which interfere with the generation of a clear image for damage visualization. Conventional mode filters produce inconsistent results due to the need for the ad hoc or manual adjustment of the processing parameters by experienced users. An automatic, adaptive mode filter is proposed to remove human subjectivity, thereby improving the consistency of the results and making it more practical to utilize. It converts the wavefield from the space-time domain to the wavenumber-time domain and then consolidates the data in the time and angular axes into a wavenumber response function (WRF) where the modes can be automatically isolated. The single-mode data were converted back into space-time domain for result visualization. Its effectiveness was experimentally proven by keeping 78.2–122.0% of energy for a wanted mode and suppressing the energy of an unwanted mode to 0.1–4.5%. Its automatic adaptability was demonstrated through the improved visibility of a blind hole, corrosion, water-ingress in honeycomb panel, and impact damage in a complex composite wing. Consistent results can be generated in a highly efficient manner while significantly reducing the computational workload and hardware requirements. Full article

Ultrasonic flow meters (UFMs) based on transducer arrays offer several advantages. With electronic beam steering, it is possible to tune the steering angle of the beam for optimal signal-tonoise ratio (SNR) upon reception. Moreover, multiple beams can be generated to propagate through different travel paths, covering a wider section of the flow profile. Furthermore, in a clamp-on configuration, UFMs based on transducer arrays can perform self-calibration. In this manner, userinput is minimized and measurement repeatability is increased. In practice, transducer array elements may break down. This could happen due to aging, exposure to rough environments, and/or rough mechanical contact. As a consequence of inactive array elements, the measured transit time difference contains two offsets. One offset originates from non-uniform spatial sampling of the generated wavefield. Another offset originates from the ill-defined beam propagating through a travel path different from the intended one. In this paper, an algorithm is proposed that corrects for both of these offsets. The algorithm also performs a filtering operation in the frequency-wavenumber domain of all spurious (i.e., flow-insensitive) wave modes. The advantage of implementing the proposed algorithm is demonstrated on simulations and measurements, showing improved accuracy and precision of the transit time differences compared to the values obtained when the algorithm is not applied. The proposed algorithm can be implemented in both in-line and clamp-on configuration of UFMs based on transducer arrays. Full article

In marine radar target detection, sea clutter will cause a large number of missed alarms and false alarms, which will affect the accuracy of target detection. In order to suppress sea clutter effectively, a sea clutter suppression and target detection algorithm of marine radar image sequence based on spatio-temporal domain joint filtering is proposed in this paper. The proposed method is to add a sea clutter suppression link before detecting the target. Firstly, the marine radar image sequence is transformed into three-dimensional frequency wavenumber domain by three-dimensional fast Fourier transform (3D-FFT), and then the three-dimensional image spectrum is obtained. According to the fact that the sea clutter spectrum obtained from the image spectrum satisfies the dispersion relation of linear wave theory in the three-dimensional frequency wavenumber domain, a sea clutter model is established. Then, through the established sea clutter model, a spatio-temporal domain joint sea clutter suppressor is designed to filter the image spectrum. After that, the filtered image spectrum is transformed by three-dimensional inverse fast Fourier transform (3D-IFFT) to obtain the image sequence in which sea clutter is suppressed. Finally, target detection is carried out for sea clutter suppressed image sequence. The method is validated by using the real data of X-band marine radar. Compared with the classical Empirical mode decomposition (EMD) method, the improvement of signal-to-noise ratio (SNR) is more obvious, and SNR can be increased by 15.3 db at most. In addition, compared with target detection on original images directly, the proposed method has excellent detection rate and can increase detection rates by at least 8%. Full article

Fractured imaging is an important target for oil and gas exploration, as these images are heterogeneous and have contain low-impedance contrast, which indicate the complexity in a geological structure. These small-scale discontinuities, such as fractures and faults, present themselves in seismic data in the form of diffracted waves. Generally, seismic data contain both reflected and diffracted events because of the physical phenomena in the subsurface and due to the recording system. Seismic diffractions are produced once the acoustic impedance contrast appears, including faults, fractures, channels, rough edges of structures, and karst sections. In this study, a double square root (DSR) equation is used for modeling of the diffraction hyperbola with different velocities and depths of point diffraction to elaborate the diffraction hyperbolic pattern. Further, we study the diffraction separation methods and the effects of the velocity analysis methods (semblance vs. hybrid travel time) for velocity model building for imaging. As a proof of concept, we apply our research work on a steep dipping fault model, which demonstrates the possibility of separating seismic diffractions using dip frequency filtering (DFF) in the frequency–wavenumber (F-K) domain. The imaging is performed using two different velocity models, namely the semblance and hybrid travel time (HTT) analysis methods. The HTT method provides the optimum results for imaging of complex structures and imaging below shadow zones. Full article

In this study, both linear and nonlinear vibrational defect imaging is performed for a cross-ply carbon fiber-reinforced polymer (CFRP) plate with artificial delaminations and for a quasi-isotropic CFRP with delaminations at the edge. The measured broadband chirp vibrational response is decomposed into different components: the linear response and the nonlinear response in terms of the higher harmonics. This decomposition is performed using the short-time Fourier transformation combined with bandpass filtering in the time-frequency domain. The linear and nonlinear vibrational response of the defect is analyzed by calculation of the defect-to-background ratio. Damage maps are created using band power calculation, which does not require any user-input nor prior information about the inspected sample. It is shown that the damage map resulting from the linear band power shows high sensitivity to shallow defects, while the damage map associated to the nonlinear band power shows a high sensitivity to both shallow and deep defects. Finally, a baseline-free framework is proposed for the detection and localization of out-of-sight damage. The damage is localized by source localization of the observed nonlinear wave components in the wavenumber domain. Full article

We present work to detect and visualize near-surface damage in concrete using contactless ultrasonic wavefield imaging technology. A fully contactless ultrasonic scanning system that utilizes a micro-electro-mechanical systems (MEMS) ultrasonic microphone array is used to collect ultrasonic surface wave data from a concrete sample. The obtained wavefield data sets are processed with a frequency-wavenumber (f-k) domain wavefield filtering approach to extract non-propagating oscillatory fields set up by near-surface concrete cracking damage. The experimental results demonstrate that near-surface concrete damage can be detected and visualized using the proposed ultrasonic wavefield imaging approach. Full article

Ultrasonic non-destructive testing techniques (NDT) based on the application of guided waves are already used for inspection of plate-type structures made of various materials, including composite materials. Air-coupled ultrasonic techniques are used to test such structures by means of guided waves. The objective of this research was development and investigation of air-coupled excitation of a slow A₀ Lamb wave mode in thin plastic films by a PMN-32%PT ultrasonic array. It is known that when the velocity of the A₀ mode in the film is less than the ultrasound velocity in air no leaky wave is observed in a surrounding air. It opens new possibilities for NDT of composite structures. The influence of the airborne wave may be eliminated by 3D filtering in a wavenumbers-frequency domain. A special filter and corresponding signals processing technique were developed in order to obtain directivity patterns and velocity maps of the waves propagating in all directions. The measured ultrasound velocity values prove that, with the proposed method, it is possible to excite a slow A₀ Lamb wave mode and to separate it from other parasitic waves propagating in air. Measurements of the parameters of the slow A₀ mode, such as the propagation velocity in the plastic film, may be applied for the material characterization. Full article

This paper aims to use the Lamb wave local wavenumber approach to characterize flat bottom defects (including circular flat bottom holes and a rectangular groove) in an isotropic thin plate. An air-coupled transducer (ACT) with a special incidence angle is used to actuate the fundamental anti-symmetric mode (A0). A laser Doppler vibrometer (LDV) is employed to measure the out-of-plane velocity over a target area. These signals are processed by the wavenumber domain filtering technique in order to remove any modes other than the A0 mode. The filtered signals are transformed back into the time-space domain. The space-frequency-wavenumber spectrum is then obtained by using three-dimensional fast Fourier transform (3D FFT) and a short space transform, which can retain the spatial information and reduce the magnitude of side lobes in the wavenumber domain. The average wavenumber is calculated, as a real signal usually contains a certain bandwidth instead of the singular frequency component. Both simulation results and experimental results demonstrate that the average wavenumber can be used not only to identify shape, location, and size of the damage, but also quantify the depth of the damage. In addition, the direction of an inclined rectangular groove is obtained by calculating the image moments under grayscale. This hybrid and non-contact system based on the local wavenumber approach can be provided with a high resolution. Full article

Precise azimuth-variant motion compensation (MOCO) is an essential and difficult task for high-resolution synthetic aperture radar (SAR) imagery. In conventional post-filtering approaches, residual azimuth-variant motion errors are generally compensated through a set of spatial post-filters, where the coarse-focused image is segmented into overlapped blocks concerning the azimuth-dependent residual errors. However, image domain post-filtering approaches, such as precise topography- and aperture-dependent motion compensation algorithm (PTA), have difficulty of robustness in declining, when strong motion errors are involved in the coarse-focused image. In this case, in order to capture the complete motion blurring function within each image block, both the block size and the overlapped part need necessary extension leading to degeneration of efficiency and robustness inevitably. Herein, a frequency domain fast back-projection algorithm (FDFBPA) is introduced to deal with strong azimuth-variant motion errors. FDFBPA disposes of the azimuth-variant motion errors based on a precise azimuth spectrum expression in the azimuth wavenumber domain. First, a wavenumber domain sub-aperture processing strategy is introduced to accelerate computation. After that, the azimuth wavenumber spectrum is partitioned into a set of wavenumber blocks, and each block is formed into a sub-aperture coarse resolution image via the back-projection integral. Then, the sub-aperture images are straightforwardly fused together in azimuth wavenumber domain to obtain a full resolution image. Moreover, chirp-Z transform (CZT) is also introduced to implement the sub-aperture back-projection integral, increasing the efficiency of the algorithm. By disusing the image domain post-filtering strategy, robustness of the proposed algorithm is improved. Both simulation and real-measured data experiments demonstrate the effectiveness and superiority of the proposal. Full article
