Tribolayer build-up was investigated on wet clutch steel disks with experiments in three different test levels of the tribological verification chain via X-ray photoelectron spectroscopy. A new characteristic value of the tribolayers was developed, i.e., the lateral elemental distribution uniformity. This value together with the parameters of additive elemental concentration as well as the thickness and the vertical composition of the layers were the basis for the subsequent correlation of the tribolayer properties with the tribological performance of clutch systems from different tests. One important finding was a non-zero threshold concentration of the additive elements calcium and phosphorous below which the clutch performance was unsatisfactory, even with a uniformly covered disk, concluding that the presence of some slightly higher additive element concentration seemed to stabilize the clutch performance. The importance of representative investigation area selection was demonstrated. Full article

Wet multi-disc clutches in transmission systems suffer from the incomplete separation of the friction components, which raises the drag torque and results in power loss and heightened fuel consumption. This incomplete separation arises from the force imbalance between resistance forces, such as the oil viscosity force, and the lack of an axial separating force. Therefore, providing an axial separating force is a potential solution to this problem. In this investigation, small-angle conical separate plates were designed which can provide the elastic restoring force during the separation process. Based on its structural properties, a model describing the clutch engagement and separation process was established. Through bench tests, the feasibility of the model was verified. The influence of the conical plate on the dynamics of the clutch was studied, including the influence of the separation gap, uniformity, and drag torque. Though the transmitted torque was reduced by 10.31% in the low-piston-pressure condition and by less than 2% in the high-piston-pressure condition, the problem of incomplete separation was successfully resolved. The results show that when applying the conical plates, the separation time was reduced by 18.78%, with a 25.31% increase in the uniformity of the gaps. Accordingly, the drag torque was reduced by 37.73%. Full article

Integrating the electric motor with a multi-speed transmission is an effective way to improve the efficiency and performance of battery electric vehicles (BEVs). This paper innovatively proposes a design method for matching a single-motor and dual-speed dual-clutch transmission (2-Speed Wet DCT) powertrain system and constructs a variable speed efficiency model (VSEM) and constant speed efficiency model (CSEM) for the inverter, motor, and transmission. Research shows that the design parameters of the motor and transmission significantly affect the optimal powertrain system. This study uses an enhanced NSGA-II multi-objective genetic algorithm to optimize the driving performance of energy efficiency and powertrain cost under two different acceleration times (10 s and 12 s), with the key parameters of the motor and transmission as optimization variables and dynamic indicators as constraints, and compares VSEM and CSEM. The optimization results indicate that VSEM have better energy-saving effects than CSEM, with the energy consumption reduced by 3.7% and 3.3% under the two driving performances, respectively. The Pareto frontier further confirms that, for multi-speed transmission systems in electric vehicles, matching a high-power, high-torque motor with a smaller transmission ratio powertrain can achieve higher energy efficiency and thus longer driving range. Additionally, this study quantifies the correlation between energy efficiency and powertrain cost using grey relational analysis (GRA), with a result of 0.77431. Full article

Binary logic transmission (BLT), a stepped transmission system, has been utilized in military vehicles and heavy-duty commercial vehicles due to its high transmission efficiency, strong load-bearing capacity, and compact structure. Its adaptability to agricultural tractor operations is notable. This study modularizes BLT into a binary logic transmission unit (BLT-U) for application in agricultural tractor Hydro-Mechanical Continuously Variable Transmission (HMCVT), optimizing its wet clutch to enhance HMCVT shifting performance. This provides a basis for BLT-U’s application in other transmission systems and subsequent optimization. A wet clutch test bench was employed to validate the modeling approach. The optimal BLT-U configuration was selected using both light/heavy load conditions and subjective–objective evaluation criteria. The WOA improved the spread value in the GRNN algorithm, establishing a GRNN to predict the optimal range for wet clutch design values in BLT-U; the model validation showed an average correlation coefficient of 0.92 for speed curves and an average relative error of 5.58% for dynamic loads. Under light-load conditions, the optimal configuration improved average and maximum scores by 13.38% and 11.53%, respectively, while under heavy-load conditions, the corresponding improvements were 9.38% and 5.86%. Under light-load conditions, the optimized GRNN reduced total relative error by 39.6%, while under heavy-load conditions, it achieved a 61% reduction. This study confirms the rationality of the modeling method, identifies Configuration 1 as optimal, and determines the optimal range for clutch design values under light-load and heavy-load conditions, respectively. Full article

The groove parameters on the friction base of wet clutches significantly affect the temperature distribution of the steel plates. However, existing methods have not thoroughly investigated the mechanisms by which these parameters influence the thermoelastic instability of wet clutches. To address this gap, a comprehensive co-simulation model of the friction sub-multi-physical field was developed to systematically examine the effects of groove inclination, groove density, and groove depth on the surface temperature and mechanical response of the steel plates. The results indicate that both the tilt angle of the grooves and the number of grooves substantially influence the surface temperature distribution of the steel plates. Specifically, increasing the number of grooves leads to a more concentrated distribution of high-temperature hot spots in the circumferential direction, gradually transitioning the surface temperature–hot spot pattern from isolated hot spots to a more uniform high-temperature tropical distribution, which subsequently reduces the maximum surface temperature. On the other hand, increasing the groove inclination angle causes the high-temperature distribution to shift from localized hot spots to a more tropical pattern, with a relatively minor impact on the peak surface temperature. Furthermore, increasing the groove depth results in the dispersion of the high-temperature tropical zone in the circumferential direction, causing the maximum temperature to initially decrease and then increase. Full article

Wet brakes and clutches are crucial drivetrain components widely used in many sectors. However, their drag losses can account for a considerable share of the overall drivetrain losses. Therefore, investigation of the drag loss behavior of wet brakes and clutches has been the subject of research since the 1970s. This paper aims to provide a comprehensive overview of existing knowledge of drag loss behavior and identify future research directions. To this end, a scoping review was conducted according to the PRISMA guideline. It was found that research mainly, but not only, focused on gaining a fundamental understanding of the drag loss generation process, investigating the integral drag loss behavior, analyzing the flow in the sub-millimeter gaps, and modeling and calculating the drag losses. The review summarizes the state of the art and may support researchers and engineers in developing low-loss wet brake and clutch systems. Several research gaps were identified and are provided. Full article

The motion state of the friction plate in a wet friction clutch is investigated by analyzing the causes of friction coefficient formation. This study establishes static and dynamic friction coefficient models for the friction plate based on a fractal model. The fractal dimension and scaling coefficient are studied to understand the fractal characteristics and variation patterns of the surface morphology of friction pairs during engagement. The MM6000 friction and wear testing machine is utilized for experiments, measuring surface morphology changes due to wear and changes in the engagement motion state of the friction plate. The theoretical content is compared and analyzed to verify the accuracy of the friction coefficient prediction model for the friction pair. Experiments are conducted on paper-based friction materials under different bonding pressures, and the relationship between bonding times and surface morphology changes is established. A comparative experiment between the joint motion state and dynamic simulation is performed, concluding that the micro convex contact model has certain accuracy in predicting the contact state of friction plates under various working conditions. Full article

The control of the vehicle transmission system is of great significance to driving comfort. In order to design a controller for smooth shifting and comfortable driving, a dynamic model of dual-clutch transmission is established in this paper. An optimal control strategy for clutch oil pressure based on linear quadratics is proposed, which is used to optimally control the oil pressure of two clutches in the torque stage and inertia stage. The control strategy selects the slipping work and jerk as evaluation indices of shift quality and establishes an optimization objective function. On the premise of optimizing the input torque, the relative speed difference between the engine and the sliding clutch in the inertia stage is adjusted. Through the optimal trajectory control of the wet clutch oil pressure, slipping work and jerk are reduced, thereby improving driving comfort. The simulation results show that the slipping work and jerk generated by the system during the shift stage are reduced, and the shift quality is improved. Additionally, compared with the controller using the MATLAB particle swarm optimization algorithm, the response speed of the proposed controller is faster, the slipping work and jerk are better reduced, and the shift quality is improved. Full article

A fundamental understanding of wet clutches’ drag loss behavior is essential for designing efficient clutch systems. It has been widely recognized that the separation behavior immediately after disengaging the clutch and the resulting clearance distribution influence the drag loss behavior. However, these influencing factors have yet to be systematically investigated. Therefore, this study aimed to experimentally investigate the effects of plate separation and clearance distribution on drag loss behavior under different operating conditions and modes. For this purpose, image series of an operating clutch system were recorded and subsequently analyzed using image processing algorithms to evaluate the movements of the plates. Based on this, the effects on drag loss behavior were analyzed. The investigations were carried out on a clutch system used in an industrial application. The measurements show that the axial movements of the plates comprise main and superimposed non-periodic movements of much a smaller amplitude. The separation of the plates is primarily driven by the applied differential speed so that the set total clearance is only utilized mainly in the higher differential speed range. The separation behavior, therefore, decisively influences the drag loss behavior. The plates can even remain in contact in the low differential speed range. The investigations also showed that the separation behavior and, thus, the drag loss behavior can be improved by using waved plates, especially in the low differential speed range. It was also found that a high plate number and a large set total clearance support a non-uniform clearance distribution. Based on the investigations conducted, it is possible to expand our fundamental knowledge of separation behavior and clearance distribution, allowing for a reduction in the drag losses of wet clutches. The findings can thus contribute to the development of low-loss and compact clutch systems. Full article

The friction pair gap affects not only the temperature increase of the multi-disc wet clutch, but also the efficiency of the helicopter transmission system. Consequently, a rotational–axial engagement and disengagement-coupled kinetic model of a wet multi-disc clutch considering asperity contact, hydrodynamic lubrication, spline resistance, and a separating spring model are developed in this paper. The effects of operating conditions on the dynamic characteristics of the wet clutch are investigated. Further, the gap deviation coefficient is proposed to characterize the dynamic behavior of the friction pair gap. As the control oil pressure increases from 1.3 MPa to 1.7 MPa, the gap deviation coefficient increases by 8.6%. Moreover, as the rotation speed increases from 888 rpm to 2488 rpm and the lubricant oil temperature increases from 25 °C to 85 °C, the gap deviation coefficient decreases by 1.1% and 4.44%, respectively. Therefore, an appropriate increase in lubricant oil temperature and rotation speed can facilitate the friction pair gap to be more uniform. These results are useful for the development of optimal control strategies for aviation wet clutch systems. Full article

The safe and efficient torque transmission of wet disk clutch systems requires high coefficients of friction. To achieve good controllability and high comfort, a positive slope of the coefficient of friction over sliding velocity is ensured by a reasonable formulation of the lubricant and choice of the friction pairing. This results in low transmittable torque at low sliding velocities. Thus, the occurrence of unwanted micro-slip in dynamic operation modes must be considered for the design of safety-relevant clutch systems. This work presents a methodology for the holistic measurement of the friction behavior of wet disk clutches. It is suitable for numerous applications and supports a sound understanding of frictional properties in the range of sliding velocities occurring in brake shifts through forced slip operation down to static torque transmission. The experimental determination of the holistic friction behavior is crucial for developing optimized design guidelines for modern clutch systems. Full article

The spline teeth fracture of separator plates in wet multi-plate clutches compromises driving safety and the vehicle’s lifespan. Tooth fracture is mainly caused by stress concentration at the tooth root and uneven circumferential load distribution. This paper considers parameters such as torque, teeth count, tooth profile, and misalignment errors, establishing the corresponding finite element (FE) model to analyze the impact of the above-mentioned parameters on the strength of the separator plates. Analysis under even and biased load circumstances demonstrated that an optimum tooth count and profile can significantly increase the strength of the separator plates, offering advice for the optimized design of wet multi-plate clutch separator plates. Full article

Power shift tractors have been widely used in agricultural tractors in recent years because of their advantages of uninterrupted power during shifting, high transmission efficiency and high stability. As one of the indispensable driving states of the power shift tractor, the starting process requires a small impact and a starting speed that meets the driver’s requirements. In this paper, aiming at such contradictory requirements, the starting control strategy of a power shift tractor is formulated with the goal of starting quality and the driver’s intention. Firstly, the identification characteristics of the driver under three starting intentions are obtained by a real vehicle test. An extreme learning machine with fast identification speed and short training time is used to establish the basic driver’s intention identification model. For the instability of the identification results of the Extreme Learning Machine (ELM), the particle swarm optimization algorithm (PSO) is used to optimize the ELM. The optimized extreme learning machine model has an accuracy of 96.891% for driver’s intention identification. The wet clutch is an important part of the power shift gearbox. In this paper, the starting control strategy knowledge base of the starting clutch is established by a combination of bench tests and simulation tests. Through the fuzzy algorithm, the driver’s intention is combined with the starting control strategy. Different drivers’ intentions will affect the comprehensive evaluation model of the clutch (the single evaluation index of the clutch is: the maximum sliding power, the sliding power, the speed stability time, the impact degree), thus affecting the final choice of the starting clutch control strategy considering the driver’s intention. On this basis, this paper studies and establishes the MPC starting controller for the power shift gearbox. Compared with the linear control strategy, the PSO-ELM-fuzzy weight starting strategy proposed in this paper can reduce the maximum sliding friction power by 45%, the sliding friction power by 69.45%, and the speed stabilization time by 0.11 s. The effectiveness of the starting control strategy considering the driver’s intention proposed in this paper to improve the starting quality of the power shift tractor is verified. Full article

The aim of this study is to design and manufacture a multi-plate clutch system that uses magnetorheological (MR) fluid control to allow for a variable power transmission ratio in power distribution systems. MR fluid is a smart material that enables presenting a solution to the shocks and power loss that occur due to mechanical problems in power distribution systems. As such, the longitudinal and lateral dynamic properties of 4WD (four-wheel drive) vehicles were examined and analyzed to develop an algorithm to control the front/rear power distribution according to the road surface state and driving conditions. To verify the algorithm, the CarSim vehicle dynamics simulation program was adopted to perform experiments to understand the vehicle’s dynamic performance improvements and turning stability via a HILS (Hardware in the Loop) system. In this study, an MR fluid, multi-plate clutch was used that combines a dry clutch and a wet clutch using the characteristics of the MR fluid. Such a clutch was designed to enable continuous and smooth torque transmission by utilizing the strengths of each of the dry and wet clutches. The CarSim vehicle dynamics program was used to conduct the experiments, which were conducted by linking to the manufactured MR fluid clutch experimental device. The experiments investigated the dynamic performance based on the power distribution ratio by performing longitudinal flat, inclined driving and lateral DLC (double lane change) driving. In summary, this study found that it is possible to perform power transmission by applying a current to an MR fluid and forming a magnetic field to change the flow properties of the fluid to control the torque transmission ratio that occurs in an MR fluid clutch. Full article

As a core component for efficient variable speed transmission and energy saving, wet clutches are widely used in the transmission systems of energy-saving and new energy vehicles. However, with an increase in the service mileage of the wet clutch, the friction coefficient undergoes alterations. This leads to a deterioration of the control accuracy of the clutch transmission torque, which ultimately has a negative impact on the dynamic characteristics and driving safety of the entire vehicle. In order to understand the service behavior of the friction coefficient in a wet clutch, wet clutches with different service mileages were investigated experimentally and theoretically. The results show that as the service mileage increased, the hydrodynamic lubrication phase was extended. Analyses of the three-dimensional profile of the friction plate and the theoretical simulation of the friction revealed that the edge ridges of the friction pads were flattened. This increased the clutch engagement force when the asperities on the separator and friction plates came into contact. Full article
