Search Results (723)

This article presents a high-efficiency dual-polarized transmitarray antenna which achieves flat gain characteristics. First, a wideband triple-layer subwavelength element is designed, achieving high transmission amplitude and a full 360° transmission phase range at 10 GHz. To enhance the passband, an isolated element and a cross-shaped middle layer are incorporated. Additionally, four vias connect the top and bottom layers to induce the current resonance, extending the phase range to 360° and improving the radiation efficiency. Based on the element, a transmitarray prototype with 185 elements is fabricated and measured, showing a gain of 27.1 dBi at the center frequency 10.2 GHz, with a radiation efficiency of 58.9%, and a 0.5 dB gain bandwidth of 12.7%. Within the 1 dB gain bandwidth, a minimum radiation efficiency of 37% is achieved at 11.4 GHz. Full article

A single-band-notched ultra-wideband (UWB) low-sidelobe planar array antenna for millimeter-wave (mmWave) applications is presented. The antenna element employs a planar dipole excited through an H-shaped coupling slot to achieve broadband impedance matching, while a centrally loaded parasitic patch acts as a half-wavelength resonator to generate a controllable notch band. Additional parasitic patches are introduced to recover the high-frequency matching without degrading the notch response. An $8\times 8$ array is then developed using a Taylor-weighted feed network implemented with three classes of 1-to-4 microstrip power dividers. Measured results show that the array operates from 19.0 to 45.0 GHz with $\mathrm{VSWR}<2$, while providing a rejection band from 35.0 to 38.5 GHz. The notch suppresses the realized gain by about 5 dB around 37.0 GHz, the peak gain reaches 20.5 dBi in the passband, and average sidelobe levels better than $-17$ dB are obtained. The proposed design provides a practical approach for combining ultra-wide bandwidth, in-band interference rejection, and low-sidelobe radiation in a compact mmWave planar array. Full article

Near-field communication is regarded as a key enabling technology for future 6G wireless systems. However, when operating over wide bandwidths, the beam split effect arising from frequency-independent analog phase shifters leads to significant beamforming gain degradation. Different from existing works that address this issue through true-time-delay hardware, this paper exploits the emerging movable antenna technology for beam split alleviation. Specifically, we consider a movable antenna-enabled near-field wideband uplink system with an analog beamforming architecture. Under this setup, we jointly optimize the analog phase shifts and antenna positions to maximize the minimum beamforming gain across all subcarriers. The formulated problem is highly non-convex due to the constant-modulus constraint on the analog combiner and the nonlinear dependence of the near-field channel on antenna positions, which makes conventional optimization methods difficult to apply. To this end, we develop a deep reinforcement learning framework based on the soft actor–critic algorithm that operates in a continuous action space and effectively handles the non-smooth max-min objective. Simulation results show that the proposed approach alleviates the beam split effect and achieves a higher minimum beamforming gain than conventional schemes. Full article

A wideband linearly polarized over-2-bit transmitarray antenna (TA) using the receiving-transmitting (R-T) scheme in the millimeter-wave band is presented in this work. The TA unit consists of two rectangular patches with a pair of bent branches, and the patches are connected by a metalized via. Two methods are used in this TA to obtain an over-2-bit phase shift of 0–90° and 180–270° from 18 GHz to 30 GHz. Firstly, 180° phase resolution is obtained by rotating the receiving patch around via by 180°. Secondly, by tuning the connection position between the branches and rectangular patch of the TA unit cell, a continuous 90° phase shift is further achieved. A TA prototype with $20\times 20$ units is designed, fabricated, and measured. The measured 1 dB and 3 dB gain bandwidth is 24.9% (24.47–31.43 GHz) and 46.96% (20.45–33 GHz) respectively, with a peak gain of 25.17 dBi and a peak aperture efficiency of 55.2%. The measured results agree well with the simulated ones. Full article

With the rapid development of software-defined radio (SDR) technology, a digital, software-reconfigurable, and flexible solution is provided for microwave radiometers, particularly suitable for atmospheric water vapor and oxygen detection with wideband, multi-channel requirements, significantly improving system efficiency. Meanwhile, digitization helps improve channel consistency and address nonlinearity issues, while the digital zero-balancing mechanism implemented through adaptive integration is more suitable for digital platforms. This paper proposes a digital Dicke-type radiometer system based on an SDR platform, using Xilinx RFSoC XCZU47DR (AMD, San Jose, CA, USA) as the core hardware to achieve single-chip integration of RF signal sampling, digital local oscillator generation, and signal processing. The system implements a 46-channel channelized receiver (23 channels each for K-band and V-band) on an FPGA using a polyphase filter bank. The prototype filters achieve 70 dB stopband attenuation and 0.5 dB passband ripple, with each polyphase branch requiring only 25 coefficients, significantly reducing hardware resource consumption. An adaptive integration method is proposed, where an adaptive switch controller dynamically adjusts the hot source injection time ratio by calculating the power difference between adjacent integration periods, enabling the Dicke zero-balancing mechanism to operate entirely in the digital domain. Furthermore, a complete hardware transfer model is established for three signal branches (antenna, hot source, and matched load), and full-chain calibration of all 46 channels is performed using a liquid nitrogen cold source, with calibration reliability verified through blackbody measurements. Experimental results demonstrate brightness temperature consistency better than 0.7 K, with a sensitivity of less than 0.15 K for the K-band and less than 0.21 K for the V-band at 1 s integration time. Full article

This paper proposes a compact axial-ratio-enhanced wideband circularly polarized rectenna for ambient RF energy harvesting. The proposed rectenna is designed to operate across the mainstream Wi-Fi (2.45 GHz) and 5G (2.6 GHz and 3.5 GHz) communication bands, achieving efficient RF energy capture and effective direct current (DC) conversion. From a design perspective, the proposed approach is developed based on parasitic-element-enabled current redistribution for broadband circular polarization and nonlinear-aware multi-stage impedance matching for wideband rectification. The receiving antenna is based on a crossed-dipole configuration integrated with quarter-ring elements. By employing techniques such as slotting and incorporating additional parasitic patches, a fractional 3-dB axial ratio bandwidth (ARBW) of 52.7% (2.39–4.10 GHz) is achieved, with a peak radiation efficiency of 90% and an average efficiency of 76% within the operating band. To realize wideband impedance matching with the receiving antenna, the rectifying circuit adopts a single-shunt diode half-wave topology, combining L-type and T-type matching networks to significantly extend the operating bandwidth. Experimental results demonstrate that at input power levels of 7 dBm, 7 dBm, and 9 dBm, the rectifier achieves peak conversion efficiencies of 56.7%, 59.8%, and 56.3% at the three target frequencies (2.45 GHz, 2.6 GHz, and 3.5 GHz), respectively. Furthermore, the rectifier exhibits stable rectification performance across a wide input power dynamic range from −15 dBm to 7 dBm. Consequently, the proposed rectenna holds significant application value for passive IoT nodes, low-power sensors, and self-sustainable electronic devices. Full article

A compact multiband shark-fin antenna is proposed for integrated vehicle-to-everything (V2X) platforms. The design incorporates five radiating elements within a compact $90\times 15\times 30{\mathrm{mm}}^3$ footprint, simultaneously supporting FM (88–108 MHz), TETRA (380–470 MHz), wideband cellular (0.68–6.05 GHz), and dual-band Wi-Fi services. Wideband cellular operation is realized using two mirrored planar inverted-F antennas (PIFAs), while a dual-band IFA provides Wi-Fi connectivity for in-vehicle and vehicle-to-infrastructure communications. The FM and TETRA elements employ compact meandered-line configurations to satisfy stringent rooftop space constraints. To improve multi-radio coexistence, the FM radiator is strategically placed between the two cellular elements, achieving inter-element isolation better than $-15$ dB across all operating bands. Experimental results demonstrate stable radiation performance, with realized gains ranging from 1.5 dBi to above 5 dBi and cross-polarization levels below $-13$ dB, in good agreement with simulations. With overall dimensions of $90\times 15\times 30{\mathrm{mm}}^3$, the proposed antenna is well suited for integrated V2X applications. Full article

This work introduces a wideband four-element multiple-input multiple-output (MIMO) antenna system with four rectangular patches arranged in a sequentially rotated configuration. Wideband frequency operation is realized by exploiting the TM₁₀, TM₀₁ and TM_11δ modes through the utilization of a slot and metallized vias in the patch design. Another group of metallized vias are used to control coupling between the antenna elements, achieving an isolation level of over 17 dB. A prototype is fabricated and measured, demonstrating −6 dB impedance bandwidth ranging from 4.23 GHz to 5.96 GHz, enabling coverage of the N79 (4.4–5 GHz), V2X (5.905–5.925 GHz) and Wi-Fi 5/6 (5.150–5.850 GHz) frequency bands. The MIMO antenna features an efficiency of over 45% and a low envelope correlation coefficient (ECC) lower than 0.25. Owing to its broad bandwidth, compact geometry, and good isolation, the proposed MIMO antenna provides an efficient and practical solution for 5G MIMO applications integrated within mobile terminal back covers. Full article

Continuous introduction of advanced optimization algorithms promotes the development of electromagnetic (EM) technology in radar and communication systems. Wideband antenna design within a given space and wideband array pattern synthesis, especially in the scenario of strong mutual coupling, are two typical challenging electromagnetic problems. In this paper, a nature-inspired algorithm, i.e., the water cycle algorithm (WCA), is introduced to resolve the above two EM problems. Two typical wideband antennas, i.e., the dual-band E-shaped microstrip antenna and the typical magnetoelectric (ME) dipole antenna, are designed on the basis of the established WCA-based antenna design scheme. Compared with the well-known algorithms that have been introduced in antenna design, including the differential evolution (DE) algorithm and the gray wolf optimizer (GWO), better results can be achieved with WCA. In the sequel, a WCA-based low peak sidelobe level (PSLL) pattern synthesis is implemented based on a uniformly spaced 27-element folded fractal ME dipole array antenna with mutual coupling as high as −10 dB, the results of which further validate the superiority of WCA in array pattern synthesis and demonstrate the value of this application innovation. Full article

A broadband low-RCS circularly polarized (CP) antenna based on a bi-functional, single-layer polarization conversion metasurface (PCM) is proposed in this manuscript. The designed bi-functional PCM unit cell achieves a polarization conversion ratio (PCR) exceeding 90% across an ultra-wideband from 15.8 GHz to 31.2 GHz. According to the principle of phase cancellation, they are configured as a checkerboard array to reduce the monostatic RCS. A co-design strategy was employed for the design of the feeding structure. Analysis reveals that the slot has a significant impact on the subarray PCR, leading to multiple zeros that affect the RCS reduction. Notably, further analysis indicates that an appropriate feed structure can compensate for the zeros caused by the slot, achieving a balance between radiation performance and scattering performance. The array exhibits an RCS reduction exceeding 6 dB over a wide frequency band from 15.9 to 31.3 GHz and realizes a circularly polarized far-field pattern with an axial ratio (AR) below 0.5 from 16.3 to 17 GHz and a maximum gain of 10.38 dBi. Measured results of the antenna prototype match the simulations well. The proposed integrated design offers a viable solution for stealth platforms. Full article

The rapid expansion of wireless communication in urban environments requires antenna systems that balance high electromagnetic performance with stringent aesthetic and security constraints. This review examines recent advances in concealed antenna technologies integrated into building structures, with a focus on performance variation, material-induced attenuation, and emerging concealment strategies. Techniques such as transparent conductors on glass, structural embedding within walls, and camouflage-based designs are shown to significantly influence resonance behavior, radiation efficiency, and pattern characteristics compared to free-space operation. Despite these challenges, optimized solutions including transparent conductive oxide arrays, wideband embedded antenna geometries, and metasurface-enhanced window structures can partially recover performance while maintaining optical transparency above 70%. Material loading effects are found to induce resonant frequency shifts of approximately 10–44%, depending on dielectric properties and environmental conditions. Transparent antenna arrays achieve gains ranging from 0.34 to 13.2 dBi, while signal-transmissive wall systems demonstrate transmission improvements of up to 22 dB relative to untreated building materials. These technologies enable a wide range of applications, including 5G and beyond-5G cellular networks across sub-6 GHz and millimeter-wave bands, as well as Internet of Things systems and smart city infrastructure. However, key challenges remain, including the need for comprehensive characterization of building material electromagnetic properties, optimization of multilayer structural environments, and the development of standardized design and evaluation methodologies. This review provides a unified framework for understanding the tradeoffs associated with antenna concealment and identifies critical research directions for the development of building-integrated wireless systems in next-generation communication networks. Full article

This article presents the design and characterization process of a lightweight Vivaldi antenna for high-voltage ultra-wideband systems. The proposed antenna consists of two radiating arms with different exponential curves on their inner and outer edges fed with an insulated-coplanar-plates transmission line. Weight reduction is achieved by implementing the antenna with sheets composed of a polyester layer between two aluminum layers, with a polylactic acid insulator inserted between the arms. The reflection coefficient of the implemented antenna demonstrates an impedance bandwidth ranging from 0.61 GHz to 3.44 GHz. High-voltage operation of up to 12.4 kV is also experimentally demonstrated. In addition to satisfying the high-voltage and ultra-wideband operational requirements, the proposed antenna is shown to achieve, among antennas with comparable characteristics, the most effective combination of low minimum operating frequency and low weight. The transfer function between the voltage applied to the antenna, $V_s$, and the radiated electric field, $E_r$, is measured. Using this transfer function, the radiated electric field is calculated for an input voltage pulse with a rise time of 110 ps to confirm the antenna’s capability of producing radiated pulses with low distortion. The calculated radiated electric field pulse closely matches the results obtained with full-wave simulation. To assess the similarity between the radiated and applied pulses, the pulse width stretch ratio is calculated, yielding a variation of 3.86% for the direction of maximum gain and 9.36% for 30° in the H-plane of the antenna. This feature is desirable for EMC, EMI and sensing applications. The antenna is also characterized in the frequency domain, achieving a maximum gain of 10.09 dBi at 3.63 GHz and a 30° 3 dB beamwidth for ultra-wideband pulses. Full article

In ultra-wideband (UWB) synthetic aperture radar (SAR) imaging, in-band antenna standing waves (SW) can generate range ghosts, degrading image quality. To address this issue, an image-domain suppression method is proposed, leveraging the phase symmetry property (PSP) between the SW signal and its mirror SW (MSW) signal. Based on PSP, the MSW signal is rapidly constructed from the SW signal, ensuring that both share the same target region but exhibit different ghost regions. PSP is further extended to the image domain. Specifically, the SW-induced phase is extracted in the wavenumber domain. Based on the PSP, this phase is then used to construct the MSW signal, which exhibits a phase spectrum that is symmetric to that of the SW signal with respect to the origin. The MSW image is subsequently fused with the original SAR image, thereby effectively suppressing SW-induced ghosts. The experimental results demonstrate that the proposed method significantly mitigates ghosting while preserving the amplitude and structural integrity of the main signal, thereby enhancing overall imaging quality. Full article

This paper proposes a non-overlapping planar cross-arranged ultra-wideband shared-aperture base station antenna array targeting the 2 to 6 GHz application bandwidth. The low-frequency module (double-layer parasitic coupling) and the high-frequency module (chamfered slotted patch) are independently designed, and metal baffles are introduced around the antenna elements to reshape the boundary conditions and physically block the electromagnetic coupling paths. Both simulation and experimental results demonstrate that the fabricated prototype successfully exceeds the targeted 2–6 GHz spectrum, achieving an actual continuous coverage from 1.84 to 6.3 GHz. Specifically, the antenna achieves a gain higher than 5.9 dBi in the measured low-frequency band (1.84–3.72 GHz) and higher than 6.1 dBi in the high-frequency band (3.63–6.3 GHz), with a voltage standing wave ratio (VSWR) below 2 across the entire band. The metal baffles successfully correct the high-frequency radiation pattern distortion and ensure stable directional radiation over the full operating bandwidth. This design provides an efficient, robust, and manufacturable solution for 5G offshore wind power multi-band base station antennas. Full article

Compact 5G millimeter-wave (mm-Wave) multiple-input multiple-output (MIMO) systems face a serious challenge as high isolation is required for high spectral efficiency. This paper presents a novel computational design framework for enhancing the isolation of a two-port ultra-wideband (UWB) MIMO antenna, specifically targeting the 5G n257 band (26.5–29.5 GHz). A pixelated metasurface is presented and optimized with the help of a binary-coded Grey Wolf Optimizer (B-GWO) algorithm through a MATLAB-Computer Simulation Technology (CST) co-simulation interface, which is used in contrast to some conventional decoupling structures. A Geometric Mirror Symmetry method is used to accelerate the optimization process, which halves the number of optimization variables and significantly reduces the computational load. Crucially, this symmetry is also a fundamental requirement to ensure that the reflection coefficients ($S_{11}$, $S_{22}$) of the antennas remain identical. The proposed design achieves isolation levels better than 20 dB across the entire target band, reaching a peak isolation of $32.58$ dB at $28.67$ GHz, while maintaining reflection coefficients ($S_{11}$, $S_{22}$) below $-10$ dB. The MIMO diversity performance is comprehensively validated with an Envelope Correlation Coefficient (ECC) $<0.005$, a Diversity Gain (DG) of $9.99$ dB, and a Total Active Reflection Coefficient (TARC) $<-10$ dB. Moreover, the suppression of surface waves enhances the realized gain to $4.51$ dBi, providing a $0.57$ dB improvement over the reference antenna. In addition, an equivalent passive RLC circuit model is constructed to observe the physical process of the pixelated surface, which shows the optimized structure as a band stop filter at the coupling frequency. The high correlation of the Equivalent Circuit Model and full-wave simulation outcomes confirms that the suggested design procedure is a strong verification alternative to physical fabrication. Full article
