This study presents a semi-empirical approach to generalizing the acoustic radiation generated by serrated airfoil configurations, based on small-scale aerodynamic/acoustic experiments and functional regression techniques. In the context of passive noise reduction strategies, such as leading-edge and trailing-edge serrations, acoustic measurements are performed in a controlled subsonic wind tunnel environment. Sound pressure level (SPL) spectra and acoustic power metrics are acquired for various geometric configurations and flow conditions. These spectral data are then analyzed using regression-based modeling techniques—linear, quadratic, logarithmic, and exponential forms—to capture the dependence of acoustic emission on key geometric and flow-related variables (e.g., serration amplitude, wavelength, angle of attack), without relying explicitly on predefined nondimensional numbers. The resulting predictive models aim to describe SPL behavior across relevant frequency bands (e.g., broadband or 1/3 octave) and to extrapolate acoustic trends for configurations beyond those tested. The proposed methodology allows for the identification of compact functional relationships between configuration parameters and acoustic output, offering a practical tool for the preliminary design and optimization of low-noise serrated profiles. The findings are intended to support both physical understanding and engineering application, bridging experimental data and parametric acoustic modeling in aerodynamic noise control. Full article

In this study, data assimilation using PIV measurement data of the cylinder wake obtained from wind tunnel tests was applied to tune the simulation model parameters of Detached Eddy Simulation (DES) to improve the accuracy of large-scale separated flow simulations around a cylinder. The use of DES enables more accurate simulation of large-scale separation flows than RANS. However, it increases computational costs and makes parameter tuning using data assimilation difficult. To reduce the computational time required for data assimilation, the conventional data assimilation method was modified. The background values used for data assimilation were constructed by extracting only velocity data from locations corresponding to observation points. This approach reduced the computational time for background error covariance and Kalman gain, thereby significantly reducing the execution time of the filtering step in data assimilation. As a result of tuning, $C_{des}$ significantly increased, while $C_{b1}$ decreased. This adjustment extended the length of the recirculation bubble, bringing the time-averaged velocity distribution closer to the PIV measurement data. However, the peak frequency in the PSD obtained from the FFT analysis of velocity fluctuations in the wake shifted slightly toward lower frequencies, slightly increasing the discrepancy with the measurement data. Verifying the relationship between parameter values and flow, it was found that parameter tuning stabilized the separation shear layer generated at the leading edge of the cylinder and enlarged the size of the recirculation bubbles. On the other hand, frequency variations did not show consistent changes in response to parameter value changes, indicating that the effect of parameter tuning was limited under the simulation conditions of this study. To bring the frequency fluctuations closer to experimental results, it is suggested that other methods, such as higher-order spatial and temporal accuracy, should be combined. Full article

This paper proposes a rotating test method to address the limitations of high costs and the inability to replicate high-speed multiphase environments in icing wind tunnels and artificial climate chambers. The method simulates high-speed multiphase in an enclosed space using relative motion and duct regulation at a lower cost. Using the FQJG2-30/16-400 type roof insulator, the Eulerian–Eulerian and CFD (computational fluid dynamics) method was employed to compare the proposed rotating method with traditional linear airflow tests in wind–sand erosion and high-speed icing experiments. Results show maximum differences of 3.23% in the collision rate and 4.34% in the icing mass, indicating good consistency. Validation experiments in an artificial climate chamber further confirmed the feasibility of the rotating test method, with icing mass differences within 5–8%. This study provides a cost-effective approach for high-speed testing in multiphase environments. Full article

This study proposes an improved formulation of the blade element momentum theory (BEMT) to enhance its robustness and versatility for urban/advanced air mobility (UAM/AAM) applications. A new velocity factor was introduced to eliminate numerical singularity issue under low inflow velocity conditions. The BEMT framework was further extended and modified to account for non-axial inflow and descent flight conditions. The proposed approach was validated for an isolated propeller case by comparing the results with wind tunnel test data and the computational fluid dynamics (CFD) based on both the overset mesh and sliding mesh methods. The improved BEMT provided reliable accuracy even in low inflow velocity conditions where basic BEMT fails to converge, and yielded reasonable performance predictions with respect to the sliding mesh results. The practicality of the method was confirmed through further application studies such as analyzing on the tilt propeller of single-seated UAM along its mission profile and constructing a propeller performance database for the lift and propulsion propellers of a lift and cruise type 5-seated UAM. The improved BEMT exhibited satisfactory engineering-level accuracy for various flight conditions, with prediction errors within 14% of the CFD results. The results and observations indicate that the proposed BEMT framework is suitable for use in the early design stages, performance analysis, and construction of a performance database, for distributed propulsion aircraft, such as eVTOL and UAM/AAM. Full article

The jet fan system is a widely adopted form of longitudinal ventilation due to its cost-effectiveness, operational flexibility, and high reliability. However, in large-section highway tunnels with a low height-to-span ratio, the limited clearance between the tunnel ceiling and surrounding structural boundaries imposes significant constraints on improving ventilation performance by adjusting the installation height or pitch angle of the jet fan. To address this limitation, this study proposes a deflector shield system to enhance the aerodynamic efficiency of jet fans. A total of thirteen test cases, including a control group, three deflector plate quantities, and four deflector pitch angles, were tested in a full-scale field test conducted in a large-section tunnel. The objective of this study was to evaluate the influence of the number and pitch angle of deflector plates on tunnel ventilation efficiency and to identify the optimal parameter combination for application in large-section tunnels. The results show that static pressure along the tunnel initially rises with distance from the fan, peaks, and then declines sharply. The pressure rise coefficient is significantly enhanced under several configurations, particularly with four deflector plates at 8° and 10° pitches, and with five plates at 4° to 10° pitches. When the number of deflector plates is five, a sharp drop in average wind speed is observed 15 m downstream of the fan, and extensive low-velocity regions appear further downstream. In contrast, the configurations with four deflector plates at 8° and 10° exhibit better wind speed uniformity in the downstream flow field. Considering both the pressure rise coefficient and wind speed uniformity, the optimal ventilation performance of the jet fan system is achieved with four deflector plates at a pitch angle of 8°. Full article

The bridge girder’s aerodynamic configuration substantially governs its aerodynamic loading and wind-induced vibration characteristics. Extensive research has been performed to optimize the configuration of girders and implement aerodynamic measures to enhance the bridge’s wind resistance. In some practical bridge engineering projects, the aerodynamic configuration of the bridge girder is asymmetric. However, studies investigating the aerodynamic properties of asymmetric girders are limited. In this paper, the aerodynamic loading and vibration characteristics of the Π-shaped girders and box girders with asymmetric bikeways are experimentally studied. Through an extensive series of wind tunnel experiments, the static wind loading coefficients, flutter derivatives, vortex-induced vibration (VIV) responses, and the critical flutter velocities are compared across varying wind direction angles (WDAs). The experimental results demonstrate that the asymmetric girder configurations have different characteristics in both the static wind loading coefficient and flutter derivative in different WDAs. The influence of WDAs on the above-mentioned aerodynamic force coefficients of the asymmetric Π-shaped girder is more pronounced than that on the asymmetric box girder. For the asymmetric Π-shaped girder, the heaving VIV responses at a 0° WDA are smaller than those at a 180° WDA, but the torsional VIV responses at a 0° WDA are larger. Experimental results for critical flutter velocities indicate that the flutter performance at a 0° WDA is better than that at a 180° WDA, especially at positive angles of attack (AOAs) for the two types of asymmetric bridge girders. Full article

The present study reports the outcome of an experimental study of organic vapor trailing edge flows. As a working fluid, the organic vapor Novec 649 was used under representative pressure and temperature conditions for organic Rankine cycle (ORC) turbine applications characterized by values of the fundamental derivative of gas dynamics below unity. An idealized vane configuration was placed in the test section of a closed-loop organic vapor wind tunnel. The effect of the Reynolds number was assessed independently from the Mach number by charging the closed wind tunnel. The airfoil surface roughness and the trailing edge shape were evaluated by experimenting with different test blades. The flow and the loss behavior were obtained using Pitot probes, static wall pressure taps, and background-oriented schlieren (BOS) optics. Isentropic exit Mach numbers up to 1.5 were investigated. Features predicted via a simple flow model proposed by Denton and Xu in 1989 were observed for organic vapor flows. Still, roughness affected the downstream loss behavior significantly due to shockwave boundary-layer interactions and flow separation. The new experimental results obtained for this organic vapor are compared with correlations from the literature and available loss data. Full article

Nonlinear wind-induced vibrations and coupled static–dynamic instabilities pose significant challenges for long-span suspension bridges, especially under large-amplitude and high-angle-of-attack conditions. However, existing studies have yet to fully capture the mechanisms behind large-amplitude torsional flutter. To address this, wind tunnel experiments were performed on H-shaped bluff sections and closed box girders using a high-precision five-component piezoelectric balance combined with a custom support system. Complementing these experiments, a finite element time-domain simulation framework was developed, incorporating experimentally derived nonlinear flutter derivatives. Validation was achieved through aeroelastic testing of a 1:110-scale model of the original Tacoma Narrows Bridge and corresponding numerical simulations. The results revealed Hopf bifurcation phenomena in H-shaped bluff sections, indicated by amplitude-dependent flutter derivatives and equivalent damping coefficients. The simulation results showed less than a 10% deviation from experimental and historical wind speed–amplitude data, confirming the model’s accuracy. Failure analysis identified suspenders as the critical failure components in the Tacoma collapse. This work develops a comprehensive performance-based design framework that improves the safety, robustness, and resilience of long-span suspension bridges against complex nonlinear aerodynamic effects while enabling cost-effective, targeted reinforcement strategies to advance modern bridge engineering. Full article

In wind tunnel tests for aerospace and bridge engineering, the accurate prediction of Mach number remains a core challenge to ensure the reliability of airflow dynamics characterization. Pure data-driven models often fail to meet high-precision prediction requirements due to the lack of physical mechanism constraints and insufficient generalization capability. This paper proposes a physical information-based long short-term memory network (P-LSTM), which constructs a physical loss function by embedding isentropic flow equations from gas dynamics, thereby constraining the Mach number prediction solution space within the physically feasible domain. This approach effectively balances the neural network’s ability to capture temporal features with the interpretability of physical mechanisms. Aiming at the scarcity of data in new wind tunnel scenarios, an adaptive weight transfer learning method (AWTL) is further proposed, realizing efficient knowledge transfer across different-scale wind tunnels via cross-domain data calibration, adaptive source-domain weight reweighting, and target-domain fine-tuning. Experimental results show that the P-LSTM method achieves a 50.65–62.54% reduction in RMSE, 48.00–54.05% in MAE, and 47.88–73.68% in MD compared with traditional LSTM for Mach number prediction in the 0.6 m continuous wind tunnel flow field. The AWTL model also outperforms the direct training model significantly in the 2.4 m continuous wind tunnel, with RMSE, MAE, and MD reduced by 85.26%, 95.12%, and 71.14%, respectively. These results validate that the proposed models achieve high-precision Mach number prediction with strong generalization capability. Full article

Icing on eight-bundled conductors can significantly alter their aerodynamic behavior, potentially leading to structural instabilities such as galloping. This study employed wind tunnel experiments and numerical simulations to analyze the aerodynamic parameters of each iced conductor across various angles of attack. The simulations incorporated detailed stranded conductor geometries to assess their influence on aerodynamic accuracy. Incorporating stranded geometry in simulations reduced average errors in lift and drag coefficients by 45–50% compared to smooth models. The Den Hartog coefficient prediction error decreased from 15.6% to 3.9%, indicating improved reliability in oscillation predictions. Additionally, conductors with larger windward areas exhibited more pronounced wake effects, with lower sub-conductors experiencing greater wake interference than upper ones. The above results illustrate that explicit modeling of stranded conductor surfaces enhances the precision of aerodynamic simulations, providing a more accurate framework for predicting icing-induced galloping in multi-bundled conductors. Full article

Originally introduced in the 1960s by DISA Elektronik as a calibration tunnel for hot-wire anemometers, the Type 55D41 has now been reengineered into a versatile and modern aerodynamic test platform. While retaining key legacy components, such as the converging nozzle and the 55D42 power unit, the upgraded system features a redesigned modular test section with optical-grade quartz windows. This enhancement enables compatibility with advanced flow diagnostics and visualization methods, including PTV, DIC, and schlieren imaging. The modernized facility maintains the precision and flow stability that made the original design widely respected, while expanding its functionality to meet the demands of contemporary experimental research. Its architecture supports the aerodynamic characterization of micro-scale static pressure probes used in aerospace, propulsion, and micro gas turbine applications. Special attention is given to assessing the influence of probe tip geometry (e.g., conical, ogive), port positioning, and stem interference on measurement accuracy. Full article

This paper presents a preliminary investigation into the aeroelastic behavior of a tailless flying wing equipped with a rotating wingtip. Based on the configuration of Innovative Control Effectors (ICE) aircraft, an aeroelastic model of the tailless flying wing with a rotating wingtip has been developed. Both numerical simulation and wind tunnel tests (WTTs) are employed to study the aeroelastic characteristics of this unique design. The numerical simulation involves the coupling of computational fluid dynamics (CFD) and implicit dynamic approaches (IDAs). Using the CFD/IDA coupling method, aeroelastic response results are obtained under different flow dynamic pressures. The critical flutter dynamic pressure is identified by analyzing the trend of the damping coefficient, with a focus on its transition from negative to positive values. Additionally, the critical flutter velocity and flutter frequency are obtained from the WTT results. The critical flutter parameters, including dynamic pressure, velocity, and flutter frequency, are examined under different wingtip rotation frequencies and angles. These parameters are derived using both the CFD/IDA coupling method and WTT. The results indicate that the rotating wingtip plays a significant role in influencing the flutter behavior of aircraft with such a configuration. Research has shown that the rotation characteristics of the rotating wingtip are the primary factor affecting its aeroelastic behavior, and increasing both the rotation frequency and rotation angle can raise the flutter boundary and effectively suppress flutter onset. Full article

Surface Air-Cooled Oil Coolers (SACOCs) can become a critical component in managing the increasing thermal loads of modern turbofan engines. Installed within the bypass duct, SACOCs utilize high-mass flow bypass air for convective heat rejection, reducing reliance on traditional Fuel-Oil Heat Exchangers. This review explores SACOC design principles, integration challenges, aerodynamic impacts, and performance trade-offs. Emphasis is placed on the balance between thermal efficiency and aerodynamic penalties such as pressure drop and flow distortion. Experimental techniques, including wind tunnel testing, are discussed alongside numerical methods, and Conjugate Heat Transfer modeling. Presented studies mostly demonstrate the impact of fin geometry and placement on both heat transfer and drag. Optimization strategies and Additive Manufacturing techniques are also covered. SACOCs are positioned to play a central role in future propulsion systems, especially in ultra-high bypass ratio and hybrid-electric architectures, where traditional cooling strategies are insufficient. This review highlights current advancements, identifies limitations, and outlines research directions to enhance SACOC efficiency in aerospace applications. Full article

Medium and large-sized birds exhibit remarkable agility and maneuverability in flight, with their flapping motion encompassing degrees of freedom in flapping, twist, and swing, which enables them to adapt effectively to harsh ecological environments. This study proposes a flapping–twist coupled driving mechanism for large-scale flapping-wing aircraft by mimicking the motion patterns of birds. The mechanism generates simultaneous twist and flapping motions based on the phase difference of double cranks, allowing for the adjustment of twist amplitude through modifications in crank radius and phase difference. The objective of this work is to optimize the lift and thrust of the flapping wing to enhance its flight performance. To achieve this, we first derived the kinematic model of the mechanism and conducted motion simulations. To mitigate the effects of the flapping wing’s flexibility, a rigid flapping wing was designed and manufactured. Through wind tunnel experiments, the flapping wing system was tested. The results demonstrated that, compared to the non-twist condition, there exists an optimal twist amplitude that slightly increases the lift of the flapping wing while significantly enhancing the thrust. It is hoped that this study will provide guidance for the design of multi-degree-of-freedom flapping wing mechanisms. Full article

This paper aims to analyze the performance of a tilt-rotor fixed-wing RPAS (Remotely Piloted Aircraft System) using a segmented approach, focusing on a nominal mission for SAR (Search and Rescue) applications. The study employs optimization techniques tailored to each segment to meet power consumption requirements, and the results highlight the accuracy of the physical characterization, which incorporates nonlinear propulsive and aerodynamic models derived from wind tunnel test campaigns. Critical segments for this nominal mission, such as the vertical take off or the transition from vertical to horizontal flight regimes, are addressed to fully understand the performance response of the aircraft. The proposed framework integrates experimental models into trajectory optimization procedures for each segment, enabling a realistic and modular analysis of energy use and aerodynamic performance. This approach provides valuable insights for both flight control design and future sizing iterations of convertible UAVs (Uncrewed Aerial Vehicles). Full article
