Sizing is a critical operation in woven fabric production, as it enhances weaving efficiency by improving warp yarn performance. Conventional sizing agents include maize starch, polyvinyl alcohol (PVA), and commercial carboxymethyl cellulose (CMC). In this study, a low-cost and biodegradable carboxymethyl cellulose derived from wheat straw (CMC_ws) was investigated as an alternative sizing agent for cotton open-end yarns with a count of Nm 12.2. The high degree of substitution (DS = 1.23) of CMC_ws indicates extensive carboxymethylation, which enhances the polymer’s hydrophilicity and solubility in water. This, in turn, contributes to a higher apparent viscosity (η = 903.03 cP at 300 s⁻¹), reflecting stronger molecular chain interactions and better film-forming ability. CMC_ws was applied using a high-pressure squeezing technique, and its effect on yarn performance was evaluated in terms of tensile properties, film characteristics, and yarn surface morphology. The results showed that CMC_ws provided a tenacity gain of 28.57%, a hairiness reduction of 54.34%, and an abrasion resistance gain of 37.14%. These values fall within acceptable industrial ranges and are comparable to those obtained using conventional sizing agents. Furthermore, the optimized CMC_ws formulation, containing plasticizer and lubricant additives, exhibited good desizing efficiency, with effective removal achieved in hot water. The findings indicate that wheat-straw-derived CMC_ws is a viable, sustainable alternative to traditional sizing agents for woven fabric production. Full article

Oxidation can lead to intrinsic degradation and loss in the load-bearing capacity of ceramic matrix composites (CMCs) in high-temperature service, thereby compromising structural integrity and operational safety. To elucidate the mechanism of its oxidation effects, this study predicted the oxygen diffusion coefficient within 2.5D woven C/SiC fibre bundles based on gas diffusion and oxidation kinetics theory, and subsequently constructed a meso-scale constitutive model incorporating oxidation damage and fibre defect distribution. Furthermore, a micro-scale framework for yarns was established by integrating interfacial slip behaviour, and an RVE model for 2.5D woven C/SiC was constructed based on X-ray computed tomography reconstruction of the actual microstructure. Building upon this foundation, an oxidation constitutive model applicable to loading–unloading cycles was proposed and validated through high-temperature oxidation tests at 700 °C, 900 °C, and 1100 °C. Results demonstrate that this model effectively characterizes the strength degradation and stiffness reduction caused by oxidation, enabling prediction of CMCs’ mechanical properties under oxidizing conditions and providing a physics-based foundation for the reliable design and life assessment of C/SiC components operating in oxidizing environments. Full article

Accurate material performance parameters are the prerequisite for conducting composite material structural analysis and design. However, the complex multiscale structure of ceramic matrix composites (CMCs) makes it extremely difficult to accurately obtain their mechanical performance parameters. To address this issue, a CMC micro-scale constituents (fiber bundles and matrix) elastic parameter inversion method was proposed based on the integration of macro–micro finite element models. This model was established based on the μCT scan data of a plain-woven CMC tensile specimen using the chemical vapor infiltration (CVI) process, which could reflect the real microstructure and surface morphology characteristics of the material. A BP neural network was used to predict the multiscale stiffness, considering the influence of the porous structure on the macroscopic stiffness of the material. The inversion process of the constituent elastic parameters was established using the trust-region algorithm combined with an improved error function. The inversion results showed that this method could accurately invert the CMC constituent elastic parameters with excellent robustness and anti-noise performance. Under four different degrees of deviation in the initial iteration conditions, the inversion error of all parameters was within 1%, and the maximum inversion error was only 2.16% under a 10% high noise level. Full article

Fully reversed tension–compression fatigue of a hybrid material comprising polymer matrix composite (PMC) co-cured with a ceramic matrix composite (CMC) was investigated. The PMC portion had a polyimide matrix reinforced with 15 plies of carbon fibers woven in an eight-harness satin weave (8HSW). The CMC portion had three plies of a quartz-fiber 8HSW fabric in a zirconia-based ceramic matrix. The hybrid PMC/CMC was developed for use in aerospace thermal protection systems (TPS). Hence, the experimental setup aimed to simulate the TPS service environment—the CMC side was kept at 329 °C, whereas the PMC side was open to laboratory air. Compression stress–strain response was studied, and compressive properties were measured at room and elevated temperature. Tension–compression fatigue tests were conducted at elevated temperature at 1.0 Hz. The evolution of tensile and compressive strains with fatigue cycles, as well as changes in the stress–strain hysteresis behavior and stiffness were examined. The tension–compression fatigue of a PMC with the same constituents and fiber architecture as the PMC portion of the PMC/CMC was studied for comparison. Tension–compression fatigue was found to be more damaging than tension–tension fatigue for both materials. The PMC outperformed the PMC/CMC in tension–compression fatigue. Post-test examination showed widespread delamination and striking non-uniform deformation modes of the PMC/CMC. Full article

This work aims at the design and engineering of sustainable biomaterials based on natural fibers to replace non-renewable fiber sources in the development of non-woven delivery systems. Cellulose fibers were used as the main support to produce multi-structured materials with the incorporation of microfibrillated cellulose (MFC) as an additive. A 3D carboxymethylcellulose matrix retaining a natural bioactive product, eucalyptus essential oil, (CMC/EO), with controlled release functionalities, was also applied to these materials using bulk and spray coating methodologies. Additionally, using a 3D modeling and simulation strategy, different interest scenarios were predicted to design new formulations with improved functional properties. Overall, the results showed that MFC provided up to 5% improved strength (+48%) at the expense of reduced softness (−10%) and absorbency (−13%) and presented a good potential to be used as an additive to maximize natural eucalyptus fibers content in formulations. The addition of CMC/EO into formulations’ bulk revealed better strength properties (21–28%), while its surface coating improved absorption (23–25%). This indicated that both application methods can be used in structures proposed for different sustainable applications or a more localized therapy, respectively. This optimization methodology consists of a competitive benefit to produce high-quality functionalized biomaterials for added-value applications. Full article

In this paper, micromechanical constitutive models are developed to predict the tensile and fatigue behavior of fiber-reinforced ceramic-matrix composites (CMCs) considering matrix fragmentation and closure. Damage models of matrix fragmentation, interface debonding, and fiber’s failure are considered in the micromechanical analysis of tensile response, and the matrix fragmentation closure, interface debonding and repeated sliding are considered in the hysteresis response. Relationships between the matrix fragmentation and closure, tensile and fatigue response, and interface debonding and fiber’s failure are established. Experimental matrix fragmentation density, tensile curves, and fatigue hysteresis loops of mini, unidirectional, cross-ply, and 2D plain-woven SiC/SiC composites are predicted using the developed constitutive models. Matrix fragmentation density changes with increasing or decreasing applied stress, which affects the nonlinear strain of SiC/SiC composite under tensile loading, and the interface debonding and sliding range of SiC/SiC composite under fatigue loading. Full article

Ceramic matrix composites (CMCs) have been designed and developed for extreme operating environments. The aim of the present study is to look for a rapid densification process providing a high level of material performance. The fibrous preform was made of Hi-Nicalon S fibers woven in a 3D interlock weave. The matrix was composed of Si₂N₂O prepared inside the CMCs by reacting a mixture of Si and SiO₂ under high nitrogen pressure (1 to 3 MPa). Silica was either impregnated by slurry or obtained by oxidation of silicon grains inside the preform. The synthesis reaction was initiated by heating the impregnated preform by means of a carbon resistor submitted to Joule effect. Composition, homogeneity and porosity of the formed matrix were studied and interpreted as a function of the experimental parameters (nitrogen pressure, heating rate of the preform) as well as the recorded thermal history of the process. The present results show that the matrix formation is almost completed in less than one minute. Melting of silicon has a major influence on the process. Competition was observed between the formation of Si₃N₄ and Si₂N₂O, which could be mainly controlled by the heating rate of the preform and the nitrogen partial pressure. Full article

The film-cooling performance of a 2.5D braided ceramic matrix composite (CMC) plate with preformed holes was numerically studied. Four numerical models containing braided structures were established: one model with film-cooling holes preformed through fiber extrusion deformation (EP-Hole), one model with film-cooling holes directly woven through fibers (WP-Hole), and two models with directly drilled holes (DP-Hole1,2). Besides, the influence of the ratio between the equivalent thermal conductivities on the axial and radial directions of fiber Kr was investigated. The results show that the preformed holes have better performance in controlling the thermal gradient with the increase of Kr. The maximum thermal gradient around the DP-Hole is significantly higher than that of the WP-Hole and EP-Hole, and the maximum relative variation reaches 123.3%. With Kr increasing from 3.32 to 13.05, the overall cooling effectiveness on the hot-side wall decreases for all models, by about 10%. Compared with the traditional drill method, the new preformed film-cooling hole studied in this paper can reduce the temperature and the thermal gradient in the region around the holes. Full article

This paper presents a damage-based failure criterion and its implementation in order to predict failure in ceramic matrix composites (CMC) manufactured via filament winding. The material behavior of CMCs is anisotropic and strongly depends on the angle between fiber orientation and loading direction. The inelastic behavior of laminates with different fiber orientations under tension and shear is modeled with the help of continuum damage mechanics. The parameters required for the damage model are obtained from a standard tensile and shear test. An isotropic damage law determines the evolution of damage in thermodynamic space and considers the interaction of damage parameters in different principal material directions. A quadratic damage-based failure criterion inspired by the Tsai-Wu failure criterion is proposed. Failure stress and strain can be predicted with higher accuracy compared to the Tsai-Wu failure criterion in stress- or strain-space. The use of the proposed damage limits allows designing a CMC component based on the microstructural phenomenon of stiffness loss. With the help of results obtained from modeling and experiments, fracture mechanics during the Iosipescu-shear test of CMCs and its capability to determine the shear strength of the material is discussed. Full article

Cycle-dependent damage evolution in self-healing, 2.5D woven Hi-Nicalon^TM SiC/[Si-B-C] and 2D woven Hi-Nicalon^TM SiC/[SiC-B₄C] ceramic-matrix composites (CMCs) at 600 and 1200 °C was investigated. The cycle-dependent damage parameters of internal friction, dissipated energy, Kachanov’s damage parameter, and broken fiber fraction were obtained to describe damage development in self-healing CMCs. The relationships between cycle-dependent damage parameters and multiple fatigue damage mechanisms were established. The experimental fatigue damage development of self-healing Hi-Nicalon^TM SiC/[Si-B-C] and Hi-Nicalon^TM SiC/[SiC-B₄C] composites was predicted for different temperatures, peak stresses, and loading frequencies. The cycle-dependent damage evolution of self-healing Hi-Nicalon^TM SiC/[Si-B-C] and Hi-Nicalon^TM SiC/[SiC-B₄C] composites depends on temperature, testing environment, peak stress, and loading frequency. For the Hi-Nicalon^TM SiC/[Si-B-C] composite, temperature is a governing parameter for the fatigue process. At an elevated temperature of 600 °C in an air atmosphere, the internal frictional parameter of Hi-Nicalon^TM SiC/[Si-B-C] composite decreases first and then increases with applied cycle number; however, at an elevated temperature of 1200 °C in an air atmosphere, the internal frictional parameter of Hi-Nicalon^TM SiC/[Si-B-C] composite decreases with applied cycle number, and the interface shear stress at 1200 °C is much lower than that at 600 °C. For Hi-Nicalon^TM SiC/[SiC-B₄C] composite at 1200 °C, loading frequency is a governing parameter for the fatigue process. The degradation rate of interface shear stress is much higher at the loading frequency of 0.1 Hz than that at the loading frequency of 1 Hz. Full article

A combustion facility which includes uniaxial mechanical loading was implemented that enables environmental conditions more akin to jet engine environments compared to conventional static environment tests. Two types of woven SiC/SiC ceramic matrix composites (CMCs), melt-infiltrated (MI) and chemical vapor infiltrated (CVI), were subjected to fatigue loading in the combustion facility and under isothermal furnace conditions. Some CVI test coupons were coated with a multilayer environmental barrier coating (EBC) of mullite + ytterbium monosilicate using slurry infiltration process to demonstrate the performance with a coating. Combustion conditions were applied using a high velocity oxy fuel gun on the front side of the specimen and mechanical loading was applied using a horizontal hydraulic MTS machine. All the specimens considered were subjected to tension-tension fatigue loading at 100 MPa, stress ratio of 0.1 and specimen front-side surface temperature of 1200 ± 20 °C. Nondestructive evaluation (NDE) methods, such as electrical resistance (ER), was used as an in-situ health monitoring technique. Similar fatigue tests were performed in an isothermal furnace for comparison. A much lower fatigue life was observed for the uncoated specimens tested under combustion conditions in comparison to isothermal furnace condition. This difference in fatigue life was attributed to damage associated with added thermal stress due to the thermal gradient and higher rate of oxidative embrittlement due to the presence of high velocity combustion gases in the combustion environment. EBC coating increased the fatigue life in combustion environment. However, EBC coated specimens experienced spallation in the high-velocity flame due to the presence of micro cracks in the coating surface. Fracture surfaces of the failed specimens were investigated under the scanning electron microscope (SEM) to determine the extent of oxidation and damage. Full article

Acoustic emission (AE) has proven to be a very useful technique for determining damage in ceramic matrix composites (CMCs). CMCs rely on various cracking mechanisms which enable non-linear stress–strain behavior with ultimate failure of the composite due to fiber failure. Since these damage mechanisms are all microfracture mechanisms, they emit stress waves ideal for AE monitoring. These are typically plate waves since, for most specimens or applications, one dimension is significantly smaller than the wavelength of the sound waves emitted. By utilizing the information of the sound waveforms captured on multiple channels from individual events, the location and identity of the sources can often be elucidated. The keys to the technique are the use of wide-band frequency sensors, digitization of the waveforms (modal AE), strategic placement of sensors to sort the data and acquire important contents of the waveforms pertinent for identification, and familiarity with the material as to the damage mechanisms occurring at prescribed points of the stress history. The AE information informs the damage progression in a unique way, which adds to the understanding of the process of failure for these composites. The AE methodology was applied to woven SiC fiber-reinforced melt-infiltrated SiC matrix composites tested in fatigue (R = 0.1) at different frequencies. Identification of when and where AE occurred coupled with waveform analysis led to source identification and failure progression. For low frequency fatigue conditions, damage progression leading to failure appeared to be due to fiber failure at or near the peak stress of the stress cycle. For higher frequency fatigue conditions, significantly greater amounts of AE were detected compared to low frequency tests a few hours prior to failure. Damage progression leading to failure included AE detected events which occurred on the unloading part of the fatigue cycle near the valley of the stress cycle. These events were associated with 90 tow longitudinal split and shear cracks presumably due to local compressive stresses associated with mating crack surface interactions during unloading. The local region where these occurred was the eventual failure location and the “valley” events appeared to influence the formation of increased local transverse cracking based on AE. Full article

Carbon fiber-carbon microcoil (CF-CMC) hybrids were formed on carbon fiber (CF)-based fabric. The morphologies of CF-based fabrics and CF-CMC hybridized fabrics were investigated. The electrical conductivities of the CF-CMC hybridized fabrics were examined and compared with those of native CF-based fabrics. Furthermore, the electromagnetic wave shielding effectiveness (SE) of the CF-CMC hybridized fabrics was investigated across operating frequencies in the 8.0–12.0 GHz range, and the results were compared with those for native CF-based fabrics. For the CF-based nonwoven fabrics, the SE values were improved by the CF-CMC hybridization reaction, although the electrical conductivities of the nonwoven fabric were reduced by the CF-CMC hybrid formation. For the CF-based woven fabrics, the SE values were improved by more than twofold throughout the entire range of frequencies, owing to the CF-CMC hybrid formation. This dramatic improvement was partly ascribed to the enhanced electrical conductivity, particularly in the transverse direction to the individual CFs. Owing to the increased thickness of the woven or nonwoven fabrics after the CF-CMC hybrid formation and the intrinsic characteristics of CMCs, the absorption mechanism for the SE was determined for the main factor that contributed to the improvement of the SE values. Full article

In this paper, the cyclic fatigue hysteresis loops of 2D woven SiC/SiC ceramic matrix composites (CMCs) at elevated temperatures in steam have been investigated. The interface slip between fibers and the matrix existing in matrix cracking modes 3 and 5, in which matrix cracking and interface debonding occurred in longitudinal yarns, is considered as the major reason for hysteresis loops of 2D woven CMCs. The hysteresis loops of 2D SiC/SiC composites corresponding to different peak stresses, test conditions, and loading frequencies have been predicted using the present analysis. The damage parameter, i.e., the proportion of matrix cracking mode 3 in the entire matrix cracking modes of the composite, and the hysteresis dissipated energy increase with increasing fatigue peak stress. With increasing cycle number, the interface shear stress in the longitudinal yarns decreases, leading to transition of interface slip types of matrix cracking modes 3 and 5. Full article
