Photonics, Volume 11, Issue 5 (May 2024) – 83 articles

Optical power splitters (OPSs) are utilized extensively in integrated photonic circuits, drawing significant interest in research on power splitters with adjustable splitting ratios. This paper introduces a compact, low-loss 1 × 2 asymmetric multimode interferometric (MMI) optical power splitter on a silicon-on-insulator (SOI) platform. The device is simulated using the finite difference method (FDM) and eigenmode expansion solver (EME). It is possible to attain various output power splitting ratios by making the geometry of the MMI central section asymmetric relative to the propagation axis. Six distinct optical power splitters are designed with unconventional splitting ratios in this paper, which substantiates that the device can achieve any power splitter ratios (PSRs) in the range of 95:5 to 50:50. The dimensions of the multimode section were established at 2.9 × (9.5–10.9) μm. Simulation results show a range of unique advantages of the device, including a low extra loss of less than 0.4 dB, good fabrication tolerance, and power splitting ratio fluctuation below 3% across the 1500 nm to 1600 nm wavelength span. Full article

Early identification of vulnerable plaques is a major challenge in diagnosis and assessment of atherosclerosis. In atherosclerotic plaque development, the proportion change in components caused plaque mechanical property change and induced plaque rupture. In this paper, a photoacoustic viscoelasticity imaging (PAVEI) technique was proposed to measure the viscosity–elasticity ratio of atherosclerotic plaque and evaluated for the potential in characterizing vulnerable plaques. Apolipoprotein E-knockout mice fed with a high-fat/high-cholesterol diet were chosen as the atherosclerotic model. Plaque component phantoms were examined to demonstrate the high efficiency of PAVEI in detecting the proportion change in components compared to single elasticity or viscosity detection. Finally, atherosclerotic plaques from mice aortas at different stages were imaged by PAVEI, which provided an insight into the compositional and functional characterization of vulnerability plaques and suggested its potential applications in the identification of high-risk plaques. Full article

In this work, a doubly resonant photonic crystal (PhC) cavity is proposed to enhance second harmonic generation (SHG) efficiency and photon pair generation rate (PGR). Through the exploration of geometry parameters, a band-edge mode within the light cone is identified as the first harmonic (FH) mode, and a band-edge mode outside the light cone is designated as the second harmonic (SH). Subsequently, by increasing the layers of the core region, a heterostructure PhC cavity is designed. The results showcase a doubly resonant PhC cavity achieving a 133/W SHG efficiency and a photon pair generation rate of 3.7 × 10⁸/s. The exceptional conversion efficiency is attributed to the high quality factors Q observed in the FH and SH modes with values of approximately 280,000 and 2100, respectively. The remarkably high Q factors compensate for nonlinear efficiency degradation caused by detuning, simultaneously making the manufacturing process easier and more feasible. This work is anticipated to provide valuable insights into efficient nonlinear conversion and photon pair generation rates. Full article

In this paper, an absorber with multi-band, tunable, high Q, and high sensitivity, based on terahertz periodic two-dimensional patterned graphene surface plasmon resonance (SPR), is proposed. The absorber consists of a bottom metal film separated by a periodically patterned graphene metamaterial structure and a SiO₂ dielectric layer, where the patterned graphene layer is etched by “+” and “L” shapes and circles. It has simple structural features that can greatly simplify the fabrication process. We have analyzed the optical properties of a graphene surface plasmon perfect metamaterial absorber based on graphene in the terahertz region using the finite-difference method in time domain (FDTD). The results show that the absorber device exhibits three perfect absorption peaks in the terahertz bands of f1 = 1.55 THz, f2 = 4.19 THz, and f3 = 6.92 THz, with absorption rates as high as 98.70%, 99.63%, and 99.42%, respectively. By discussing the effects of parameters such as the geometrical dimensions of patterned graphene metamaterial structure “+” width W1, “L” width W2, circular width R, and the thickness of the dielectric layer on the absorption performance of absorber, as well as investigating the chemical potential and relaxation time of patterned-layer graphene material, it was found that the amplitude of the absorption peaks and the frequency of resonance of absorber devices can be dynamically adjusted. Finally, we simulated the spectra as the surrounding refractive index n varied to better evaluate the sensing performance of the structure, yielding structural sensitivities up to 382 GHz/RIU. Based on this study, we find that the results of our research will open new doors for the use of multi-band, tunable, polarization-independent metamaterial absorbers that are insensitive to large-angle oblique incidence. Full article

In this study, a compact and low-power-consumption quantum random number generator (QRNG) based on a laser diode and a hybrid chip with integrated silicon photonics is proposed and verified experimentally. The hybrid chip’s size is 8.8 × 2.6 × 1 ${\mathrm{mm}}^3$, and the power of the entropy source is 80 mW. A common-mode rejection ratio greater than 40 dB was achieved using an optimized 1 × 2 multimode interferometer structure. A method for optimizing the quantum-to-classical noise ratio is presented. A quantum-to-classical noise ratio of approximately 9 dB was achieved when the photoelectron current is 1 $\mathsf{\mu }$A using a balance homodyne detector with a high dark current GeSi photodiode. The proposed QRNG has the potential for use in scenarios of moderate MHz random number generation speed, with low power, small volume, and low cost prioritized. Full article

The cavity form of complex microcavity lasers predominantly relies on disordered structures, whether found in nature or artificially prepared. These structures, characterized by disorder, facilitate random lasing through the feedback effect of the cavity boundary and the internal scattering medium via various mechanisms. In this paper, we report on a random fiber laser employing a disordered scattering cladding medium affixed to the inner cladding of a hollow-core fiber. The internal flowing liquid gain establishes a stable liquid-core waveguide environment, enabling long-term directional coupling output for random laser emission. Through theoretical analysis and experimental validation, we demonstrate that controlling the disorder at the cavity boundary allows liquid-core fiber random microcavities to exhibit random lasing output with different mechanisms. This provides a broad platform for in-depth research into the generation and control of complex microcavity lasers, as well as the detection of scattered matter within micro- and nanostructures. Full article

We propose a new vortex lens for producing multiple focused coaxial vortices with approximately equal intensities along the optical axis, termed equal-intensity multi-focus composite spiral zone plates (EMCSZPs). In this typical methodology, two concentric conventional spiral zone plates (SZPs) of different focal lengths were composited together and the alternate transparent and opaque zones were arranged with specific m-bonacci sequence. Based on the Fresnel–Kirchhoff diffraction theory, the focusing properties of the EMCSZPs were calculated in detail and the corresponding demonstration experiment was been carried out to verify our proposal. The investigations indicate that the EMCSZPs indeed exhibit superior performance, which accords well with our physical design. In addition, the topological charges (TCs) of the multi-focus vortices can be flexibly selected and controlled by optimizing the parameters of the zone plates. These findings which were demonstrated by the performed experiment may open new avenues towards improving the performance of biomedical imaging, quantum computation and optical manipulation. Full article

Measurements of atmosphere density in the upper thermosphere and exosphere are of great significance for studying space–atmosphere interactions. However, the region from 200 km to 1000 km has been a blind area for traditional ground-based active remote sensing techniques due to the limitation of facilities and the paucity of neutral atmosphere. To fulfill this gap, the University of Science and Technology of China is developing a powerful metastable helium resonance fluorescent lidar incorporating a 2 m aperture telescope, a high-energy 1083 nm pulsed laser, as well as a superconducting nanowire single-photon detector (SNSPD) with high quantum efficiency and low dark noise. The system is described in detail in this work. To evaluate the performance of the lidar system, numerical simulation is implemented. The results show that metastable helium density measurements can be achieved with a relative error of less than 20% above 370 km in winter and less than 200% in 270–460 km in summer, demonstrating the feasibility of metastable helium lidar. Full article

We theoretically demonstrate a scheme to generate circularly polarized (CP) isolated attosecond pulses (IAPs) with tunable helicity using a polarization gating laser field interacting with the CO molecule. The results show that a broadband CP supercontinuum is produced from the oriented CO molecule, which supports the generation of an IAP with an ellipticity of 0.98 and a duration of 90 as. Furthermore, the helicity of the generated harmonics and IAP can be effectively controlled by modulating the laser field and the orientation angle of the CO molecule. Our method will advance research on chiral-specific dynamics and magnetic circular dichroism on the attosecond timescale. Full article

The application of non-uniform spiral gratings to control the structure, topological parameters and propagation of orbital angular momentum (OAM) beams was studied experimentally with coherent near-infrared light. Adapted digital spiral grating structures were programmed into the phase map of a high-resolution liquid-crystal-on-silicon spatial light modulator (LCoS-SLM). It is shown that characteristic spatio-spectral anomalies related to Gouy phase shift can be used as pointers to quantify rotational beam properties. Depending on the sign and gradient of spatially variable periods of chirped spiral gratings (CSGs), variations in rotation angle and angular velocity were measured as a function of the propagation distance. Propagation-dependent self-torque is introduced in analogy to known local self-torque phenomena of OAM beams as obtained by the superposition of temporally chirped or phase-modulated wavepackets. Applications in metrology, nonlinear optics or particle trapping are conceivable. Full article

The study of extreme events (EEs) in photonics has expanded significantly due to straightforward implementation conditions. EEs have not been discussed systematically, to the best of our knowledge, in the chaotic dynamics of a Fabry–Perot laser with optical feedback, so we address this in the current contribution. Herein, we not only find EEs in all modes but also divide the EEs in total output into two categories for further discussion. The two types of EEs have similar statistical features to conventional rogue waves. The occurrence probability of EEs undergoes a saturation effect as the feedback strength increases. Additionally, we analyze the influence of feedback strength, feedback delay, and pump current on the probability of EEs defined by two criteria of EEs and find similar trends. We hope that this work contributes to a deep understanding and serves as inspiration for further research into various multimode semiconductor laser systems. Full article

As a space camera works in orbit, the stress rebound caused by gravity inevitably results in the deformation of its optomechanical structure, and the relative position change between different optical components will affect the Line-Of-Sight pointing of the camera. In this paper, the optical sensitivity calculation of a space camera’s Line-Of-Sight pointing is realized based on the optomechanical constraint equations, and the Line-Of-Sight equations are constructed using the second type of response (DRESP2) method to realize an optomechanical integrated analysis of the camera’s Line-Of-Sight stability at the structural finite element solver level. The verification results show that the Line-Of-Sight stability error is 6.38%, meaning that this method can identify the sensitive optical elements of the optical system efficiently and quickly. Thus, the method in this paper has important significance as a reference for the analysis of the Line-Of-Sight stability of complex optical systems. Full article

An analysis of the features of measurements and correction of phase distortions in optical waves propagating in the atmosphere at various levels of turbulence was performed. It is shown that with increasing intensity fluctuations, the limiting capabilities of phase correction decrease, and the phase of an optical wave that has passed through a turbulence layer consists of two components: potential and vortex. It was found that even in the region of weak fluctuations there is an overlap of spectral filtering functions for intensity and phase fluctuations. Areas of turbulence inhomogeneities have been identified that will have mutual influence and negatively affect the operation of the phase meter. It is noted that correlation functions, both phase and intensity, are less susceptible to this compared to structural functions. The results of experimental studies on the reconstruction of the wavefront of laser radiation distorted by atmospheric turbulence using a Shack–Hartmann wavefront sensor during vignetting and central screening of the entrance pupil in the optical system are presented. Studies have been carried out on the propagation of laser radiation along a horizontal atmospheric path for various levels of turbulence. The results are analyzed in terms of Zernike polynomials. Full article

We present experimental results for the controlled mitigation of the electromagnetic pulses (EMPs) produced in the interactions of a 1 PW high-power 30 fs Ti:Sa laser VEGA-3 with solid-density targets transparent to laser-forward-accelerated relativistic electrons. This study aims at the band of very high frequencies (VHFs), i.e., those in the hundreds of MHz, which comprise the fundamental cavity modes of the rectangular VEGA-3 vacuum chamber. We demonstrate mode suppression by a tailoring of the laser-produced space charge distribution. Full article

Structured light three-dimensional reconstruction is one of the important methods for non-contact acquisition of sparse texture object surfaces. Variations in ambient illumination and disparities in object surface reflectance can significantly impact the fidelity of three-dimensional reconstruction, introducing considerable inaccuracies. We introduce a robust method for color speckle structured light encoding, which is based on a variant of the De Bruijn sequence, termed the Homogeneous De Bruijn Sequence. This innovative approach enhances the reliability and accuracy of structured light techniques for three-dimensional reconstruction by utilizing the distinctive characteristics of Homogeneous De Bruijn Sequences. Through a pruning process applied to the De Bruijn sequence, a structured light pattern with seven distinct color patches is generated. This approach ensures a more equitable distribution of speckle information. Full article

To the best of our knowledge, a novel concept of mode heterogeneity for the design of multimode devices is presented in this paper and applied to the design of scalable multimode power splitters. Based on a cascade of mode-dependent splitters and converters, we achieve beam splitting and mode conversion for four modes from $T{E}_0$ to $T{E}_3$ in the bandwidth from 1525 nm to 1560 nm. The measurements of the device at 1550 nm show excellent performance, with the insertion loss ranging from 0.16 dB to 0.63 dB, crosstalk all below −16.71 dB, and power uniformity between 0.026 dB and 0.168 dB. Full article

In this paper, we use the geometric optics and discuss the path of laser beam in a simple laser (concave-plano) cavity with the birefringence crystal. In specific lengths of the laser cavity, we can observe various types of Lissajous-like structural laser modes that can be simulated using our ray tracing model. At the end of this paper, we provide an adjusted ABCD matrix. With the adjusted ABCD matrix and iterative calculation, we can obtain the 3D trajectories which are similar to the experimental results. These structural laser modes can be realized by a ${\text{Nd:YVO}}_4$ solid-state laser with off-axis pumping. From the comparison between the experimental data and the numerical data, we clarify the relationship between the 3D Lissajous-like structural laser modes and ray trajectory in the laser cavity. Full article

In recent years, optical systems near the diffraction limit have been widely used in high-end applications. Evidently, an analytical solution of the point spread function (PSF) will help to enhance both understanding and dealing with the imaging process. This paper analyzes the Fresnel diffraction of diffraction-limited optical systems in defocused conditions. For this work, an analytical solution of the defocused PSF was obtained using the series expansion of the confluent hypergeometric functions. The analytical expression of the defocused optical transfer function is also presented herein for comparison with the PSF. Additionally, some characteristic parameters for the PSF are provided, such as the equivalent bandwidth and the Strehl ratio. Comparing the PSF obtained using the fast Fourier transform algorithm of an optical system with known, detailed parameters to the analytical solution derived in this paper using only the typical parameters, the root mean square errors of the two methods were found to be less than 3% in the weak and medium defocus range. The attractive advantages of the universal model, which is independent of design details, objective types, and applications, are discussed. Full article

Modern stealth application systems require integrated meta-devices to operate effectively and have gained significant attention recently. This research paper proposes a 1-bit coding metasurface (CM) design. The fundamental component of the proposed CM is integrated to convert linearly polarized incoming electromagnetic waves into their orthogonal counterpart within frequency bands of 12.37–13.03 GHz and 18.96–32.37 GHz, achieving a polarization conversion ratio exceeding 99%. Furthermore, it enables linear-to-circular polarization conversion from 11.80 to 12.29, 13.17 to 18.44, and 33.33 to 40.35 GHz. A second element is produced by rotating a fundamental component by 90°, introducing a phase difference of π (pi) between them. Both elements are arranged in an array using a random aperiodic coding sequence to create a 1-bit CM for reducing the radar cross-section (RCS). The planar structure achieved over 10 dB RCS reduction for polarized waves in the frequency bands of 13.1–13.8 GHz and 20.4–30.9 GHz. A prototype was fabricated and tested, with the experimental results showing a good agreement with the simulated outcomes. The proposed design holds potential applications in radar systems, reflector antennas, stealth technologies, and satellite communication. Full article

A high-precision catadioptric telescope such as a space-borne telescope is usually tested with interferometer to check the optical quality in assembly. The coarse and fine alignment of the telescope are mainly based on the information from the coordinate measuring machine and the fringe pattern of the interferometer, respectively. In addition, further fine-tuning can be achieved according to the variation in wavefront error and Zernike data. The issue is that the vast majority of the catadioptric telescopes contain plural lens surfaces which could produce unwanted ghost fringes, disturbing the wavefront measurement. Technically, off-axis installation to shift away ghost fringes from central interferogram could be acceptable in some cases. Nevertheless, in this paper, the source of ghost fringe in interferometric measurement for catadioptric telescopes is investigated with light path simulation, and a solution of reducing the f-number of the diverger lens is proposed to eliminate the ghost fringe disturbance. Both simulation and experimental results verify the effectiveness of the proposed concept. Full article

The precise estimation of fluid motion is critical across various fields, including aerodynamics, hydrodynamics, and industrial fluid mechanics. However, refraction at complex interfaces in the light path can cause image deterioration and lead to severe measurement errors if the aberration changes with time, e.g., at fluctuating air–water interfaces. This challenge is particularly pronounced in technical energy conversion processes such as bubble formation in electrolysis, droplet formation in fuel cells, or film flows. In this paper, a flow field estimation algorithm that can perform the aberration correction function is proposed, which integrates the flow field distribution estimation algorithm based on the Particle Image Velocimetry (PIV) technique and the novel actuator-free adaptive optics technique. Two different multi-input convolutional neural network (CNN) structures are established, with two frames of distorted PIV images and measured wavefront distortion information as inputs. The corrected flow field results are directly output, which are divided into two types based on different network structures: dense estimation and sparse estimation. Based on a series of models, a corresponding dataset synthesis model is established to generate training datasets. Finally, the algorithm performance is evaluated from different perspectives. Compared with traditional algorithms, the two proposed algorithms achieves reductions in the root mean square value of velocity residual error by 84% and 89%, respectively. By integrating both flow field measurement and novel adaptive optics technique into deep CNNs, this method lays a foundation for future research aimed at exploring more intricate distortion phenomena in flow field measurement. Full article

In long-range laser communication, adaptive optics tracking systems are often used to achieve high-precision tracking. When recognizing beacon spots for tracking, the traditional threshold segmentation method is highly susceptible to segmentation errors in the face of interference. In this study, an improved DeepLabV3+ network is designed for fast and accurate capture of beacon spots in complex situations. In order to speed up the inference process, the backbone of the model was rewritten as MobileNetV2. This study improves the ASPP (Atrous Spatial Pyramid Pooling) module by splicing and fusing the outputs and inputs of its different layers. Meanwhile, the original convolution in the module is rewritten as a depthwise separable convolution with a dilation rate to reduce the computational burden. CBAM (Convolutional Block Attention Module) is applied, and the focus loss function is introduced during training. The network yields an accuracy of 98.76% mean intersection over union on self-constructed beacon spot dataset, and the segmentation consumes only 12 milliseconds, which realizes the fast and high-precision capturing of beacon spots. Full article

The article presents a comparative analysis of published data for the physical parameters of the ZGP (ZnGeP₂) crystal, its nonlinear and phase-matching properties, and functional capabilities for all frequency conversion processes (harmonics, sum and difference frequencies, and parametric generation). At the first time, the possibilities for obtaining the temperature-noncritical processes for some combinations of wavelengths are shown. Full article

We demonstrate a pulsed Er-doped ZBLAN fiber laser operating at 3.75 μm based on the gain-switching scheme. A diffraction grating is introduced as a wavelength selection component to enable stable lasing in this long-wavelength region that deviates from the emission peak of ⁴F_9/2→⁴I_9/2 transition in Er³⁺. Different from the conventional gain-switching behavior where the pulse repetition frequency of the output laser is same as the that of the pump, the gain-switched laser demonstrated here shows a variable pulse repetition frequency, which accounts for 1/n (n = 4, 3, 2) of the pump pulse repetition frequency, in response to the 1950 nm pump power. The output pulse characteristics, including average output power, repetition frequency, pulse duration, and peak power, are investigated in detail. Over 200 mW average output power at 3.75 μm was obtained at 12 W of 1950 nm pump power. This work demonstrates that the Er-doped ZBLAN fiber laser, in combination with gain-switched scheme, is a feasible and promising approach to generate powerful pulsed emission > 3.7 μm. Full article

This paper considers the scattering of a probe laser pulse by an intense light spring in a QED vacuum. This new scattering configuration can be seen as the vacuum equivalent to the process originally associated with the scattering of light by a rotating black hole, which is usually called Penrose superradiance. Here, the rotating object is an intense laser beam containing two different components of orbital angular momentum. Due to these two components having slightly different frequencies, the energy profile of the intense laser beam rotates with an angular velocity that depends on the frequency difference. The nonlinear properties of a quantum vacuum are described by a first-order Euler–Heisenberg Lagrangian. It is shown that in such a configuration, nonlinear photon–photon coupling leads to scattered radiation with frequency shift and angular dispersion. These two distinct properties, of frequency and propagation direction, could eventually be favorable for possible experimental observations. In principle, this new scattering configuration can also be reproduced in a nonlinear optical medium. Full article

Ferroelectric domain engineering has wide applications in optical and electronic industries. Compared with traditional electric field poling, femtosecond laser poling has many advantages, such as higher fabrication resolution, 3D engineering applicability, and lower costs of production. In this review, the recent research progress on ferroelectric domain engineering with femtosecond laser pulses is presented. We show the latest results, including complex domain structures fabricated in various kinds of ferroelectric crystals, and discuss the influence of laser poling parameters and conditions on the morphologies of inverted domains and their physical mechanisms. The technical challenges to overcome in future are also briefly discussed. Full article

This study presents a systematic optimization of wide-angle metamaterial long-pass (LP) edge filters based on silicon nanospheres (SiNP). Multi-layered configurations incorporating SiNP-meta-films and anti-reflection coating (ARC) elements not previously considered in the literature are explored to enhance their filter performance in both stop and pass bands. This research has successfully developed an accurate model for the effective refractive index using Kramers–Kronig relations, enabling the use of classical thin-film design software for rapid device performance optimization, which is verified by full-wave numerical software. This systematic optimization has produced highly efficient, near-shift-free long-pass metamaterial filters, evidenced by their high optical density (OD = 2.55) and low spectral shift across a wide angular range (0°–60°). These advancements herald the development of high-efficiency metamaterial optical components suitable for a variety of applications that require a consistent performance across diverse angles of incidence. Full article

Active illumination light becomes strongly reflective interference light after specular reflection. It causes saturation in some areas of the image during target detection, resulting in the inability to recognize detailed target feature information. This greatly limits the application of active illumination detection. Based on the Mueller matrix analysis of the difference in polarization characteristics between the background specular reflected light and the target reflected light, we propose a reflection suppression method based on orthogonal polarization imaging. The method employs a polarization modulation strategy in a bidirectional manner between the light source and the detector. First, the polarization information difference is amplified by active polarized illumination between the background specular reflected light and the target reflected light. Then, the target recovery is achieved by suppressing the background specular reflected light through the polarized orthogonal imaging method. Meanwhile, this method can also be used for moving target detection. The experimental results show that the reflection suppression method of orthogonal polarization imaging can effectively suppress the interference of specular reflection on the target image. Additionally, it can reduce the problems of missed and false detection that occurs in moving target detection and improve the active illumination detection effect. Full article

High directional emission and high radiative quantum efficiency are strongly needed when moving a single optical nano-emitter (such as a quantum dot) into the practical realm. However, a typical optical nano-emitter struggles to meet the requirements above, which limits its practical applications in next-generation nano-photonic devices such as single-photon sources. Here, to achieve these features simultaneously, we propose and theoretically investigate a composite plasmonic antenna consisting of a hemispherical solid immersion lens (SIL) and a bowtie plasmonic nano-antenna, wherein a high directional emission of 10° and 2.5 × 10³ of Purcell factor have both been enabled. Moreover, we find that directionality and the Purcell factor can be manipulated independently in our antenna, which provides a novel platform for the optimization of single-photon sources. Full article

The paper proposes a method for the calibration of spacing in dual-grating based on Multiple Improved Complete Ensemble Empirical Mode Decomposition with Adaptive Noise (ICEEMDAN) combined with Hilbert Transform (HT), referred to as Multiple ICEEMDAN-HT. This method addresses the potential impact of nonlinear factors on phase extraction accuracy, consequently on ranging precision in the homodyne interference of the dual-grating. Building upon the ICEEMDAN algorithm, the signal undergoes iterative decomposition and reconstruction using the sample entropy criterion. The intrinsic mode functions (IMFs) obtained from multiple iterations are then reconstructed to obtain the complete signal. Through a simulation and comparison with other signal decomposition methods, the repeatability and completeness of signal reconstruction by Multiple ICEEMDAN are verified. Finally, an actual dual-grating ranging system is utilized to calibrate the spacing of the planar grating. Experimental results demonstrate that the calibration relative error of the Multiple ICEEMDAN-HT phase unwrapping method can be reduced to as low as 0.07%, effectively enhancing the signal robustness and spacing calibration precision. Full article
