Modelingof Acetylene Pyrolysis under Steel Vacuum Carburizing Conditions in a Tubular Flow Reactor
Abstract
:Introduction
Results and Discussion
Reaction Mechanism and CFD Model
Rate constant | ||||
No. | Reaction | Rate Expression | Ai (mol, m3, sec) | EA,i (kJ/mol) |
1 | C2H2 + H2 → C2H4 | r1 = k1 · cC2H2 · cH20.36 | 4.4 · 103 | 103.0 |
2 | C2H4 → C2H4 + H2 | r2 = k2 · cC2H40.5 | 3.8 · 107 | 200.0 |
3 | C2H2 + 3H2 → 2CH4 | r3 = k3 · cC2H20.35 · cH20.22 | 1.4 · 105 | 150.0 |
4 | 2CH4 → C2H2 + 3H2 | r4 = k4 · cCH40.21 | 8.6 · 106 | 195.0 |
5 | C2H2 → 2C(S) + H2 | | 5.5 · 106 | 165.0 |
6 | C2H2 + C2H2 → C4H4 | r6 = k6 · cC2H21.6 | 1.2 · 105 | 120.7 |
7 | C4H4 → C2H2 + C2H2 | r7 = k7 · cC4H40.75 | 1.0 · 1015 | 335.2 |
8 | C4H4 + C2H2 → C6H6 | r8 = k8 · cC2H21.3 · cC4H40.6 | 1.8 · 103 | 64.5 |
9 | C6H6 → 6C(S) + 3H2 | | 1.0· 103 | 75.0 |
Conclusions
Experimental
Acknowledgments
References
- Wu, C. H.; Singh, H. J.; Kern, R. D. Pyrolysis of acetylene behind reflected shock waves. International. Int. J. Chem. Kin. 1987, 19, 975–996. [Google Scholar] [CrossRef]
- Frenklach, M.; Durgaprasad, M. B.; Taki, S.; Matula, R. Soot formation in shock-tube pyrolysis of acetylene, allene, and 1, 3-butadiene. Combust. Flame 1983, 54, 81–101. [Google Scholar] [CrossRef]
- Frenklach, M.; Clary, D. W.; Gardiner, W. C.; Stein, S. E. Detailed kinetic modeling of soot formation in shock-tube pyrolysis of acetylene. Proc. Combust. Inst. 1984, 20, 887–901. [Google Scholar]
- Frenklach, M. Reaction mechanism of soot formation in flames. Phys. Chem. Chem. Phys. 2002, 4, 2028–2037. [Google Scholar] [CrossRef]
- Back, M. H. Mechanism of the Pyrolysis of Acetylene. Can. J. Chem. 1971, 49, 2199–2204. [Google Scholar]
- Kiefer, J. H.; Von Drasek, W. A. The mechanism of the homogeneous pyrolysis of acetylene. Int. J. Chem. Kinet. 1990, 22, 747–786. [Google Scholar]
- Gay, I. D.; Kistiakowsky, G. B.; Michael, J. V.; Niki, H. Thermal decomposition of acetylene in shock waves. J. Chem. Phys. 1965, 43, 1720–1726. [Google Scholar] [CrossRef]
- Kruse, T.; Roth, P. Kinetics of C2 Reactions during High-Temperature Pyrolysis of Acetylene. J. Phys. Chem. A. 1997, 101, 2138–2146. [Google Scholar] [CrossRef]
- Tanzawa, T.; Gardiner, W. C., Jr. Reaction mechanism of the homogeneous thermal decomposition of acetylene. J. Phys. Chem. 1980, 84, 236–239. [Google Scholar]
- Laskin, A.; Wang, H. On initiation reactions of acetylene oxidation in shock tubes- A quantum mechanical and kinetic modeling study. J. Chem. Phys. Lett. 1999, 303, 43–49. [Google Scholar]
- Kiefer, J. H.; Sidhu, S. S.; Kern, R. D.; Xie, K.; Chen, H.; Harding, L. B. The homogeneous pyrolysis of acetylene II: the high temperature radical chain mechanism. J. Combust. Sci. Tech. 1992, 82, 101–130. [Google Scholar] [CrossRef]
- Böhm, H.; Jander, H. PAH formation in acetylene-benzene pyrolysis. Phys. Chem. Chem. Phys. 1999, 1, 3775–3781. [Google Scholar] [CrossRef]
- Norinaga, K.; Deutschmann, O.; Hüttinger, K. J. Analysis of gas phase compounds in chemical vapor deposition of carbon from light hydrocarbons. Carbon 2006, 44, 1790–1800. [Google Scholar] [CrossRef]
- Dimitrijevic, S. T.; Paterson, S.; Pacey, P. D. Pyrolysis of acetylene during viscous flow at low conversions; influence of acetone. J. Anal. App. Pyrol. 2000, 53, 107–122. [Google Scholar]
- Cullis, C. F.; Franklin, N. H. The pyrolysis of mixtures of acetylene with other hydrocarbons. J. Combust. Flame 1964, 8, 246–248. [Google Scholar] [CrossRef]
- Krestinin, A. V. On the Kinetics of Heterogeneous Acetylene Pyrolysis. Kinet. Catal. 2000, 41, 729–736. [Google Scholar] [CrossRef]
- Hu, Z. J.; Hüttinger, K. J. Mechanisms of carbon deposition-A kinetic approach. Carbon 2002, 40, 624–628. [Google Scholar] [CrossRef]
- Hu, Z. J.; Hüttinger, K. J. Influence of the surface area/volume ratio on the chemistry of carbon deposition from methane. Carbon 2003, 41, 501–1508. [Google Scholar]
- Norinaga, K.; Hüttinger, K. J. Kinetics of surface reactions in carbon deposition from light hydrocarbons. Carbon 2003, 41, 1509–1514. [Google Scholar] [CrossRef]
- Zhang, W. G.; Hu, Z. J.; Hüttinger, K. J. Chemical vapor infiltration of carbon fiber felt: optimization of densification and carbon microstructure. Carbon 2002, 40, 2529–2545. [Google Scholar] [CrossRef]
© 2007 by MDPI (http://www.mdpi.org). Reproduction is permitted for noncommercial purposes.
Share and Cite
Khan, R.U.; Bajohr, S.; Graf, F.; Reimert, R. Modelingof Acetylene Pyrolysis under Steel Vacuum Carburizing Conditions in a Tubular Flow Reactor. Molecules 2007, 12, 290-296. https://doi.org/10.3390/12030290
Khan RU, Bajohr S, Graf F, Reimert R. Modelingof Acetylene Pyrolysis under Steel Vacuum Carburizing Conditions in a Tubular Flow Reactor. Molecules. 2007; 12(3):290-296. https://doi.org/10.3390/12030290
Chicago/Turabian StyleKhan, Rafi Ullah, Siegfried Bajohr, Frank Graf, and Rainer Reimert. 2007. "Modelingof Acetylene Pyrolysis under Steel Vacuum Carburizing Conditions in a Tubular Flow Reactor" Molecules 12, no. 3: 290-296. https://doi.org/10.3390/12030290
