Mutations in Splicing Factor Genes in Myeloid Malignancies: Significance and Impact on Clinical Features

Abstract

Components of the pre-messenger RNA splicing machinery are frequently mutated in myeloid malignancies. Mutations in LUC7L2, PRPF8, SF3B1, SRSF2, U2AF1, and ZRSR2 genes occur at various frequencies ranging between 40% and 85% in different subtypes of myelodysplastic syndrome (MDS) and 5% and 10% of acute myeloid leukemia (AML) and myeloproliferative neoplasms (MPNs). In some instances, splicing factor (SF) mutations have provided diagnostic utility and information on clinical outcomes as exemplified by SF3B1 mutations associated with increased ring sideroblasts (RS) in MDS-RS or MDS/MPN-RS with thrombocytosis. SF3B1 mutations are associated with better survival outcomes, while SRSF2 mutations are associated with a shorter survival time and increased AML progression, and U2AF1 mutations with a lower remission rate and shorter survival time. Beside the presence of mutations, transcriptomics technologies have shown that one third of genes in AML patients are differentially expressed, leading to altered transcript stability, interruption of protein function, and improper translation compared to those of healthy individuals. The detection of SF mutations demonstrates the importance of splicing abnormalities in the hematopoiesis of MDS and AML patients given the fact that abnormal splicing regulates the function of several transcriptional factors (PU.1, RUNX1, etc.) crucial in hematopoietic function. This review provides a summary of the significance of the most frequently mutated SF genes in myeloid malignancies and an update on novel targeted therapies in experimental and clinical trial stages.

1. Genetics of Myeloid Malignancies

Myelodysplastic syndromes (MDS) are a genetically and clinically diverse group of clonal stem cell malignancies characterized by inefficient hematopoiesis, peripheral blood cytopenias, and an increased risk of transformation to acute myeloid leukemia (AML). Genetic alterations occurring at the level of a multipotent stem cell are believed to accelerate clonal evolution from MDS, sometimes resulting in transformation to acute leukemia, although no specific disease-initiating defect has been identified to date. In the last decade, several gene mutations acting as driver events have been identified with various frequencies across the spectrum of MDS and AML. Disease evolution is driven by positive selection of driver mutations. So far, more than 30 driver genes have been associated with the pathogenesis of leukemia [1,2]. Gene functional analysis has clustered these genes into pathways including DNA methylation, chromatin remodeling, RNA-splicing, cohesion complex, RAS family signaling, gene transcription, and DNA repair. One of the major classes of driver mutations is mutations in splicing factors (SF) (SF3B1, U2AF1, SRSF2, ZRSR2, PRPF8, LUC7L2) (Figure 1). SF genes encode for components of the spliceosomes. Spliceosomes are nuclear structures composed of five small nuclear RNAs (snRNA) and approximately 150 proteins, which catalyze the splicing reaction. The complex removes non-coding sequences (introns) from precursor messenger RNA and ligates coding sequences (exons) in order to form mature mRNA transcripts through early and late steps. Early steps involve recognition of the 5′ and 3′ exon/intron junctions and late steps recall all the spliceosome together. The information to define the splicing regions are included in short and conserved sequences at the 5′ splice site (SS), the 3′SS, and the branch site (BS). In higher eukaryotes, the BS is located approximately 18–40 nucleotides upstream of the 3′SS and is followed by a polypyrimidine tract. Many genes in humans are spliced into two or more transcripts with altered sequences through a process called alternative splicing. There are two types of pre-mRNA introns: U2-dependent (major spliceosome), which accounts for almost all the human introns, and U12-dependent (minor spliceosome), which accounts for less than a thousand introns [3,4].

As a whole, SF mutations are detected in 45–85% of different MDS subtypes and in 5–10% of primary AML [5,6]. Mutations in the SF genes occur in the same spots in MDS and AML. In MDS, SF mutations are associated with mutations in epigenetic genes, e.g., SF3B1 with DNMT3A mutations, SRSF2 with RUNX1, IDH1/2 and ASXL1 mutations and U2AF1 with ASXL1 and DNMT3A mutations. In AML, SF mutations are associated mainly with RUNX1, ASXL1, IDH2 and TET2 [6].

The mutations often occur in genes controlling 3′SS selection. Missense mutations are a hallmark of SF3B1, SRSF2, and U2AF1 and inactivating mutations (nonsense or frameshift) are often detected in the ZRSR2 gene. These SF mutations are the most commonly observed mutations in MDS and AML, and are found in approximately two-thirds of SF-mutated cases. Except for ZRSR2, the other SF are part of the U2-type spliceosome. The heterozygous configuration of the mutations at selective sites and the absence of nonsense or truncating mutations in major SF (SF3B1, SRSF2, U2AF1) suggest that SF are likely gain-of-function oncogenes [7,8]. The consequences of SF mutations and the production of alternative transcripts are presented in Figure 2.

Mutations in SF3B1, SRSF2, and U2AF1 have been associated with specific disease subtypes with SF3B1 being mostly mutated in MDS-RS, SRSF2 occurring mostly in chronic myelomonocytic leukemia (CMML), and U2AF1 in secondary AML [9]. Representative cases of SF mutant patients and morphologic features are presented in Figure 3.

2. Overview of Splicing Factor Mutations in Myeloid Malignancies

SF3B1. The SF3B1 gene (chromosome 2q33.1) encodes a core component of the U2 nuclear ribonucleoprotein, which recognizes the 3′SS at intron-exon junctions. Mutations are located preferentially in four consecutive HEAT (Huntington elongation factor 3 protein phosphatase 2A, and the yeast PI3-kinase TOR1) domains of the C-terminal region, with the lysine to glutamic acid substitution at codon 700 (K700E) accounting for more than 50% of all mutant cases. Other common hotspot mutations involve the conserved amino acids 622, 625, 662, and 666 [10]. As such, all mutations occur quite distant to the region of the protein involved in the 3′ branch site recognition suggesting that these alterations do not influence the RNA-binding properties of the protein. Studies in murine models have shown that homozygous mutations of the SF3B1 gene are incompatible with life [11,12]. Clonal analysis and in vitro experiments of human leukemia cells have shown that SF3B1 mutations are initiating events which occur in rare lympho-myeloid hematopoietic stem cells (HSCs) (Lin− CD34+ CD38− CD90+ CD45RA−) [13,14]. The cells seem to provide a marked clonal advantage to the MDS-RS HSCs. Indeed, the percentage of RS in the bone marrow correlates with the SF3B1 variant allele frequency [15]. Xenotransplantation studies showed that clones with SF3B1 mutations are often not suppressed by other clones with different mutations (e.g., DNMT3A, JAK2) [14]. SF3B1 mutations are significantly associated with older age [16]. More recently, SF3B1 mutations have also been found in a proportion of individuals with clonal hematopoiesis of indeterminate potential (CHIP) at risk for developing malignancies including MDS [17]. Mutual exclusivity in SF mutations suggest that co-occurring mutations are incompatible with life. SF mutations induce a variety of splicing changes which are unique to specific SF. RNA-sequencing analysis of many tumor types have found that splicing abnormalities in SF3B1 mutant cells are exclusively related to the utilization of a cryptic splice acceptor site located upstream of the canonical 3′SS [18,19]. These splicing events often produce framing errors. Among the several target genes of SF, most have been studied for effects of mutations in the SF3B1 gene. SF3B1 mutant cells have a defect in the splicing of ABCB7 (ATP Binding Cassette Subfamily B, Member 7) due to the usage of an alternative 3′SS which causes an early termination of the protein [20,21]. The change in splicing seems to be the major determinant in decreasing ABCB7 mRNA levels and consequent increase in iron deposition (a feature of MDS-RS). Moreover, alternative 3′SS were also observed in PPOX (1q23.3) and TMEM14C (6p24.2) genes, particularly during erythroid maturation, using in vitro cellular systems [22]. Other events of aberrant splicing with resultant low mRNA production were also found in tumor suppressor genes including NF1, DICER1, PML, PDS5A, MAP3K7, and PPP2R5A [23]. Mice conditionally expressing K700E mutation (Mx1-Cre Sf3b1^+/K700E) develop progressive macrocytic anemia, inefficient cellular differentiation, and failure in bone marrow reconstitution capacity [12].

SF3B1 mutations often co-occur with TET2 mutations [24]. Double mutant mice generated by the breeding of Sf3b1^+/K700E and Tet2 knock-out mice manifested a more severe anemia compared to mice with a sole alteration in Sf3b1 or Tet2 [12]. RNA-sequencing analysis of human and Sf3b1^+/K700E mice have shown that about 68% of splicing defects are due to alternative 3′SS usage occurring at −15 and −24 nucleotides upstream the canonical 3′ [12]. In vitro experiments expressing mutations often observed in human MDS in the yeast orthologue of SF3B1 (Hsh155) have shown that those mutations alter the interaction of SF3B1 and Prp5 a protein helicase involved in the first ATP-dependent catalysis of the splicing cascade [25].

U2AF1. The U2-complex auxiliary factor 1 gene (U2AF1, 21q22.3) encodes a 35-kDa protein (alias U2AF35) of the U2-spliceosome responsible for recognition of the terminal 3′ AG dinucleotide in pre-messenger RNA introns. The protein has four major domains including two zinc finger regions, a serine-arginine (SR) domain, and an U2AF-homology domain. The U2AF1 unit forms a complex by heterodimerization with the 65-Kda protein called U2AF2 in order to bind the polypyrimidine tract upstream the 3′SS and recognize the branch point and the AG dinucleotide of the 3′SS. Mutations in U2AF1 at codon S34 and Q157 are found in about 11% of patients with MDS and in 4% of patients with AML. Mutations are associated with a worse survival and are associated with an increased risk of AML transformation. U2AF1 mutations result in the production of neomorphic phenotypes by chancing splicing patterns for many RNA downstream genes. These changes are lineage-specific and seem to influence the division of erythroid progenitors and subsequently change the differentiation trajectory of granulocytes and monocytes [26]. Analysis of the transcriptome of U2AF1 mutant cells has shown changes in the splicing patterns (cassette exons) of genes present in the granulocytic compartment (H2AFY, STRAP) [27]. Primary cells expressing U2AF1 mutations showed missplicing in mitotic (ATR, CEP164, EHMT1, WAC) and RNA processing (PABPC4, PPWD1, PTBP1, STRAP, UPF3B) genes [28]. Studies have also shown that cells expressing U2AF1^S34F have a decrease in ATG7 protein levels due to aberrant splicing resulting in a decrease in autophagy (as ATG7 is one of the key genes in autophagy). U2AF1^S34F cells with low levels of ATG7 and reduced autophagy had also increased reactive oxygen species and increased chromosomal instability [29]. Presence of U2AF1 mutations was also correlated with increased IRAK4 isoforms which activate the NF-KB signaling pathway [30]. Genetically engineered murine models expressing U2AF1^S34F have been generated using the Cre recombinase tool and by activating Cre specifically in hematopoietic tissues. Upon Cre activation, mice expressing the S34 mutation developed features recapitulating MDS (dysplasia, cytopenias) as well as abnormal splicing profiles similar to the splicing patterns observed in human MDS [31]. Transgenic U2AF1 mice also are sensitive to pharmacologic treatment with the splicing modulator, sudemycin [26].

SRSF2. The SRSF2 gene is located on chromosome 17q25.2 and encodes a member of the serine/arginine (SR)-rich family of pre-mRNA splicing components. It contains an RNA recognition motif (RRM) for binding RNA and an arginine and serine domain for binding other proteins. The arginine and serine domain is enriched in SR residues facilitating the interaction between SR and SF. SR proteins have versatile functions such as regulating pre-mRNA splicing, RNA stability, and translation. SRSF2 mutations occur almost exclusively at proline 95 and alter binding affinity of the RRM motif. SRSF2 mutations have been found in 28–47% of patients with CMML and about 14% of patients with MDS [32] and have been associated with increased age, higher levels of hemoglobin, and normal cytogenetics. SRSF2 mutations are almost never sole mutations. In CMML, SRSF2 mutations are often found with TET2 mutations, while in AML are typically associated with RUNX1, IDH2, and ASXL1 mutations. Pooled meta-analysis studies of MDS patients have shown that patients with SRSF2 mutations predict for a worse survival and an increased risk for AML transformation [32,33] and have no prognostic effects in CMML [34].

In AML, SRSF2 mutations have been found in about 25% of patients and associated with older age [35]. Studies have shown that proline 95 in normal SRSF2 forms a strong interaction with the second cytosine in the UCCAGU site and the second guanine in the UGGAGU site of the DNA. When mutations alter proline to histidine, the change in amino acid creates an alteration in the hydrogen bond leading to a change in the structural conformation. SRSF2 mutations seem to induce differential splicing in EZH2, a known gene implicated in the pathogenesis of MDS and AML, and in several HNRNP proteins, including HNRNPA2B1, HNRNPH1, HNRNPM, and HNRNPH3 [36,37]. The diverse biological effects of SRSF2 mutations are also demonstrated by the fact that other pathways are affected by the mutations, e.g., perturbation of double-strand DNA breaks, increase in p53 phosphorylation, and cell cycle arrest. In inducible Mx1-Cre Srsf2^+/P95H knock-in mice, sole alterations in SRSF2 produce a phenotype similar to MDS. These features are also recapitulated by mice carrying homozygous Srsf2 [36,38]

3. Other Splicing Factor Mutations

Mutations in other SF have been found in myeloid malignancies at lower frequencies and with patterns different from those of SF3B1, SRSF2, and U2AF1.

ZRSR2 is a gene located on chromosome Xp22.2, which is mutated in about 5% of patients with MDS, predominantly males. The protein is another member of the SR-rich family of SF, and the gene encodes a component of the U2 auxiliary factor heterodimer which is responsible for the recognition of the 3′ splice acceptor site. The nature of the mutations resembles loss-of-function mutations [39]. Out-of-frame insertions and deletions, nonsense, missense, and splice site mutations have all been detected. No mutation hotspots have been observed and the mutations scatter across the entire coding region. In terms of splicing abnormalities, ZRSR2 mutations cause abnormal splicing via intron retention of U12-depedent introns [39].

PRPF8 is a gene located on chromosome 17p13.3 and has been found to be affected by somatic mutations or hemizygous deletions. A majority of patients (50%) with PRPF8 mutations and del(17p) were found to be AML patients with poor prognosis. PRPF8 alterations were found to correlate with increased RS and myeloblasts [40]. A subsequent analysis of a large cohort showed that PRPF8 mutations were common and found in 4% (65/1700) of patients with MDS and AML [41]. Mutations were mainly missense, nonsense, frameshift, and splice site mutations, and showed a strong association with dismal prognosis. Based on studies of the yeast Prp8 protein, PRPF8 protein appears to be involved in spliceosome assembly, however a clear function in myeloid malignancies has not yet been demonstrated [42]. Cryo-electron microscopy technology has helped to resolve the structure of many components of the spliceosome and added more information on the function of PRPF8, specifically the N domain of PRPF8. PRPF8 interacts with U5 snRNA to stabilize the pre-mRNA in the spliceosome active site and it potentiates the U2 and U6 snRNA interactions with the intron [43].

LUC7L2 is located on chromosome 7q34, and thus is a common target of gene deletions given the frequency of deletion of the long arm of chromosome 7 [del(7q)] and monosomy 7 (−7) in myeloid malignancies. The gene encodes a protein with a C2H2-type zinc finger, a coiled-coil region, and an SR domain. To date the function of LUC7L2 is not well characterized and the majority of what is known about the protein is based on observations of its ortholog splicing factor LUC7 which is involved in recruitment and interaction of SF. LUC7L2 mutations can be hemizygous, heterozygous, and homozygous. LUC7L2 mutations have been associated with shorter survival in patients with -7/del7q compared to patients with normal LUC7L2 expression [44,45]. LUCL7L2 has been found aberrantly spliced in MDS cases harboring SRSF2 small deletions [46]. Very rare mutations (<1%) have been found in other SF genes including SF3A1, SF1, PRPF40B, and U2AF2 [5,47].

4. Therapeutic Intervention for Splicing Factor Mutations

As we have described, there are multiple ways by which pathologically altered splicing can promote the initiation and maintenance of cancer. In the last eight years, interest has grown in targeting splicing catalysis, splicing regulatory proteins, and specific altered splicing events. Splicing requires protein–protein and protein–RNA interaction, and is directed by a number of proteins, which are also subjected to regulation via post-translational modifications and protein–RNA interactions. This variety of interactions provides a range of possibilities to manipulate splicing for pharmacologic purposes. Pan-splicing modulators have been developed and are being tested in myeloid malignancies associated with SF mutations. Because splicing is ubiquitous and SF interact with many different proteins, it is possible that splicing modulators might also have effects against leukemic cells that do not harbor SF mutations [48]. Bacterially-derived products and their derivatives have been shown to bind the SF3B component to disrupt the early stages of the spliceosome cascade. These compounds have different stabilities in in vitro systems, and include low stability-agents such as FR901463, FR901464, FR901465, herboxidienes, and pladienolides, and high stability-agents such as E7107 (an analog of pladienolide B), spliceostatin A (SSA; from FR901464), and sudemycins, which block early spliceosome assembly [49]. While several compounds have only been shown to biologically alter splicing in vitro, a few compounds have been tested in both in vitro and in vivo. For instance, E7107 seems to induce marked splicing inhibition in several cellular and animal models [50]. The susceptibility of the spliceosomal mutant leukemia to splicing modulation via E7107 has also been validated in patient-derived xenografts obtained from primary AML cells with SF mutations [48].

Recently, H3B-8800 (a semi-derivative of pladienolides), a selective and orally bioavailable modulator of normal and mutant SF3b complex, has shown dose-dependent modulation of splicing in pre-clinical studies. Oral administration of H3B-8800 demonstrated preferential induction of cell growth arrest in several pre-clinical xenograft models of MDS/AML carrying SF mutations. H3B-8800 entered an open-label, multicenter phase 1 trial to evaluate pharmacokinetics/pharmacodynamics in AML, CMML, and MDS with SF mutations [51]. Several studies are ongoing using agents with non-spliceosome functions. More recently, several hematopoietic cells have been found more sensitive to the treatment with aryl sulfonamides (e.g., indisulam) compared to other cancer cell lines. Drug-sensitivity has been correlated with increased DCAF15 expression levels and copy number variation. The mechanism of action of indisulam seems to be shared with other sulfonamides such as tasisulam and chloroquinoxaline sulfonamide. Indeed, indisulam seems to induce the degradation of RBM39 (RNA binding motif protein 39) which in turn causes abnormal mRNA splicing (intron retention, exon skipping). RBM39 is a nuclear protein which associates with the E3 ubiquitin ligase complex (CUL4-DCAF15) in the presence of indisulam [52]. Inhibition of protein arginine methyltransferases (PRMTs) has also been correlated with increased anti-proliferative activity of SF mutant cell lines. The possibility of using protein arginine methyltransferases (PRMTs) inhibitors was demonstrated after subjecting murine AML cells driven by MLL-AF9 fusion with and without Srsf2^P95H mutation to 45 compounds. Srsf2 mutant cells were more sensitive than wild type cells to two PRMTs inhibitors, GSK591 (PRMT5 inhibitor) and MS023 (a pan type I PRMTs inhibitor) [53]. Very recently, SF3B1 mutations have been shown to provoke interruption of the open reading frame of BRD9 with resultant decrease in the half-life of the protein. Cells derived from patients harboring SF3B1 mutations have a reduced expression of BRD9 compared to cells of patients with wild type SF3B1 [54].

Recently, luspatercept (ACE-536), a fusion protein containing a modified extracellular domain of the human activin receptor type IIB combined with a human IgG1 Fc domain and influencing the TGF-β and SMAD family proteins, is a phase II clinical trial for MDS patients and seems to induce a better clinical response in patients with SF3B1 mutations [55]. In addition, SF3B1 mutations represent a positive factor for erythroid response in a randomized phase II clinical trial of azacitidine and epoietin-β [56].

5. Conclusions

Mutations in SF genes are common in myeloid malignancies and induce different disease phenotypes according to cellular context. Each SF is also associated with a distinct pattern of mutations in other genes commonly detected in myeloid malignancies, as in the case of SRSF2 mutations with TET2 mutations in CMML and with RUNX1, IDH2, and ASXL1 mutations in AML. Targeting SF mutations represents a novel avenue of drug discovery and development. In vitro studies have shown several different ways to impact splicing and restore splicing defects. Future experimental trials will shed light on the safety of pharmacologic agents targeting SF mutations.
