Alumina and Silica Oxides as Catalysts for the Oxidation of Benzoins to Benzils under Solvent-free Conditions

Abstract

Alumina or silica gel are used as catalysts for a solvent-free oxidation of benzoins to the corresponding benzils. These catalysts are easily recovered after completion of the reactions, which are carried out either by heating in a sand bath or using microwave irradiation. Comparison of the results obtained with both catalysts indicates that all the reactants examined were oxidized faster on alumina than on silica under these conditions.

Introduction

α-Diketones are versatile compounds in organic chemistry that can be utilized for the preparation of a variety of molecules, many of which are show a diversity of interesting biologically activities [1]. Oxidations of α-hydroxy ketones to α-diketones by a wide range of reagents have been reported, including, among others, the dinitrogen tetroxide complex of iron (III) and copper (II) [2], dimethyl sulfide ditriflate [3], peracetic acid in the presence of sodium bromide [4], dimethyl sulfoxide (DMSO)-SbCl₅ [5], thallium (III) nitrate (TTN) [6], a cerium (IV) ammonium nitrate (CAN)-charcoal system [7], nickel acetate [8] and р-toluenesulfonic acid in boiling xylene [9]. Alumina and silica gel are both important reagents in industry and in the laboratory and numerous reactions have carried out using these substances as solid supports. In recent years Al₂O₃ and SiO₂ based reagents have been widely used for dehydration or dehydrogenation of alcohols [10,11,12,13,14] and in many oxidation reactions carried out under microwave irradiation or under solid state conditions [15,16,17,18,19].

Benzoins are rapidly oxidized to benzils in high yield by the solid copper (II) sulfate-alumina reagent system under the influence of microwaves [20]. The iodobenzene diacetate-alumina solid reagent system expeditiously and selectively oxidizes sulfides to sulfoxides and alcohols to carbonyl compounds in high yield under the influence of microwaves [21]. A simple and selective method for the oxidation of alcohols to carbonyl compounds using chromium (VI) oxide supported on wet alumina under solvent-free conditions has also been described, again accelerated by microwave irradiation [22]. Other reactions that can be carried out using silica gel as a support include the conversion of epoxides to β-halohydrins with silica gel supported lithium halide [23], the silica gel supported hetero Diels-Alder reaction of quinolinetriones [24], oxidative glycol cleavage with silica gel supported sodium metaperiodate [25], synthesis of benzophenones with Lewis acid catalysts using silica gel [26] and so on. We now report the use of both Al₂O₃ and SiO₂ separately as oxidizing agents in the absence of an additional supported oxidant.

Results and Discussion

Benzoins are oxidized to benzils in high yield on alumina and silica under solvent-free conditions, under both microwave irradiation assisted conditions and upon heating in a sand bath, without any additional supported oxidant on the alumina or silica gel surface (Scheme 1).

Scheme 1.

Scheme 1.

Our results are summarized in Table 1, Table 2, Table 3 and Table 4. They show that both alumina and silica gel are suitable oxidants, but that alumina was consistently a better oxidation catalyst than silica gel under the conditions used.

Table 1. Solid phase oxidation of benzoins on alumina ^a in a sand bath (140 ^oC)

Compound	Substituents	Time (min)	Yield (%) b
1	Ar′ = C6H5, Ar =C6H5-CO	10	100
2	Ar′ = C6H5, Ar = 4-Me2NC6H4-CO	60	95
3	Ar′ = 4-MeOC6H4, Ar = 4-MeOC6H4-CO	180	100
4	Ar′ = C6H5, Ar =4-MeOC6H4-CO	65	90
5	Ar′ = Ar = C6H5	N.R.c	--
6	Ar′ = C6H5, Ar = H	N.R.	--

a) Activated alumina. b) Yields based on the products isolated by column chromatography. c) N.R. = no reaction.

Table 1. Solid phase oxidation of benzoins on alumina ^a in a sand bath (140 ^oC)

Compound	Substituents	Time (min)	Yield (%) b
1	Ar′ = C6H5, Ar =C6H5-CO	10	100
2	Ar′ = C6H5, Ar = 4-Me2NC6H4-CO	60	95
3	Ar′ = 4-MeOC6H4, Ar = 4-MeOC6H4-CO	180	100
4	Ar′ = C6H5, Ar =4-MeOC6H4-CO	65	90
5	Ar′ = Ar = C6H5	N.R.c	--
6	Ar′ = C6H5, Ar = H	N.R.	--

a) Activated alumina. b) Yields based on the products isolated by column chromatography. c) N.R. = no reaction.

Table 2. Solid phase oxidation of benzoins on alumina under microwave irradiation.

Compound	Time (min)	Yield (%)
1	5	100
2	5	95
3	5	90
4	5	70
5	N.R.	--
6	N.R.	--

Table 2. Solid phase oxidation of benzoins on alumina under microwave irradiation.

Compound	Time (min)	Yield (%)
1	5	100
2	5	95
3	5	90
4	5	70
5	N.R.	--
6	N.R.	--

Table 3. Solid phase oxidation of benzoins on silica gel ^a in a sand bath (140 ^oC).

Compound	Time (min)	Yield (%)
1	180	100
2	180	70
3	150	90
4	b	100
5	N.R.	--
6	N.R.	--

a) HF ₂₅₄(type 60). b) The reaction time was more than 20 hours.

Table 3. Solid phase oxidation of benzoins on silica gel ^a in a sand bath (140 ^oC).

Compound	Time (min)	Yield (%)
1	180	100
2	180	70
3	150	90
4	b	100
5	N.R.	--
6	N.R.	--

a) HF ₂₅₄(type 60). b) The reaction time was more than 20 hours.

Table 4. Solid phase oxidation of benzoins on silica gel under microwave irradiation.

Compound	Time (min)	Yield (%)
1	5	95
2	10	95
3	15	85
4	15	70
5	N.R.	--
6	N.R.	--

Table 4. Solid phase oxidation of benzoins on silica gel under microwave irradiation.

Compound	Time (min)	Yield (%)
1	5	95
2	10	95
3	15	85
4	15	70
5	N.R.	--
6	N.R.	--

All of benzoins examined were readily oxidized but neither diphenyl carbinol (5a) nor benzyl alcohol (6a) reacted. It seems that an adjacent carbonyl group is necessary for the oxidation of the hydroxyl groups to take place. Naturally, substrates such as 1a- 6a can be partially oxidized in air after extended exposure to oxygen, but if O₂ played an important role in this oxidation we would expect compounds 5a and 6a to have been oxidized too. We attribute the observation that alumina is a better oxidation catalyst than silica to the fact that it is a stronger Lewis acid than silica, although so far we have not proposed a mechanism for this process and at this time we are simply reporting our experimental observations. The reaction times also appear to depend on the temperature, as they are seen to decrease as the temperature increases.

Conclusions

We report that benzoins are oxidized to benzils in the solid state in good yields under microwave irradiation or in a heated sand bath, using alumina or silica gel as catalysts without added oxidants. The main advantages of these reactions are: (1) easy recovery of the alumina or the silica gel upon completion of the reactions; (2) yields are high and the products contain minimum by-products; (3) no environmental pollution; (4) low cost as no reaction solvents are required.

Experimental

General

Melting points were determined on a Gallenkamp apparatus and are uncorrected. All IR spectra were recorded on a Shimadzu IR-470 spectrometer and ¹H-NMR spectra were recorded on a Varian EM390 instrument. Chemical shifts (δ-scale) are quoted in parts per million and following abbreviations are used: s = singlet; d = doublet; m = multiplet. All the benzoin starting materials were synthesized in our laboratory and were characterized by comparison of their physical data (melting points) with those of authentic samples [27]. All the reported yields refer to isolated products after purification. All products were characterized by comparison of their spectral (IR, ¹H-NMR and TLC) and physical data (melting points) with those of authentic samples [2,28]. The apparatus used for the oxidations was either a Samsung domestic microwave oven (2450MHz, 900w) or a sand-bath mortar oven.

Typical procedure for the oxidation of benzoins to benzils on alumina or silica gel.

Benzoins (0.05 g) was added to Al₂O₃ or SiO₂ (0.5 g, 1:10 w/w), mixed and homogenized in a mortar. The reactions were then allowed to proceed for the times given in Table 1, Table 2, Table 3 and Table 4, respectively, either in a sand-bath at 140 ^oC or under microwave irradiation. Reaction times were monitored and optimized by TLC (checking every 5 minutes under microwave irradiation and every 10 minutes under sand-bath conditions). Upon completion of the reactions the mixtures were washed with a few mL of CH₂Cl_2, filtered, evaporated and the products purified by silica gel column chromatography. The analytical data of two products, 1b and 3b, are given as examples: Benzil (1b): light green needle-like crystals, mp 95 °C, (lit. [2,28] 95 °C); IR (KBr): 3100 (C–H, Ar), 1680 (C=O), 1595 (C=C); ¹H-NMR δ_H (90 MHz, CCl₄), 7.3 – 7.9 (m, 3H, m and p-PhH), 8.0 – 8.3 (m, 2H, o-PhH); 4,4'-Dimethoxybenzil (3b): green solid, mp 133 °C, (lit. [2,28] 132-134 °C); IR (KBr): 3050(C–H, ar.), 2900(s), 2800 (C–H, aliph.), 1670 (C=O), 1595 (C=C), 1160 (C–O); ¹H-NMR δ_H (90 MHz, CDCl₃, CCl₄); 4.0 (s, 3H, CH₃), 7.2 (d, J = 9Hz, 2H, m-PhH), 8.2 (d, J = 9Hz, 2H, o-PhH).
