Synthesis and Antifungal Activity of Novel Sulfone Derivatives Containing 1,3,4-Oxadiazole Moieties

by
Weiming Xu
*,
Jiang He
,
Ming He
,
Feifei Han
,
Xuehai Chen
,
Zhaoxi Pan
,
Jian Wang
and
Maoguo Tong
State Key Laboratory Breeding Base of Green Pesticide and Agricultural Bioengineering, Key Laboratory of Green Pesticide and Agricultural Bioengineering, Ministry of Education, Center for Research and Development of Fine Chemicals, Guizhou University, Guiyang 550025, China
*
Author to whom correspondence should be addressed.
Molecules 2011, 16(11), 9129-9141; https://doi.org/10.3390/molecules16119129
Submission received: 8 October 2011 / Revised: 24 October 2011 / Accepted: 25 October 2011 / Published: 1 November 2011
(This article belongs to the Section Medicinal Chemistry)
Browse Figures
Versions Notes

Abstract

:
A series of new sulfone compounds containing 1,3,4-oxadiazole moieties were synthesized. The structures of these compounds were confirmed by spectroscopic data (IR, 1H- and 13C-NMR) and elemental analyses. Antifungal tests indicated that all the title compounds exhibited good antifungal activities against eight kinds of plant pathogenic fungi, and some showed superiority over the commercial fungicide hymexazol. Among them, compounds 5d, 5e, 5f, and 5i showed prominent activity against B. cinerea, with determined EC50 values of 5.21 μg/mL, 8.25 µg/mL, 8.03 µg/mL, and 21.00 µg/mL, respectively. The present work demonstrates that sulfone derivatives such as 5dcontaining a 1,3,4-oxadiazole moiety can be used as possible lead compounds for the development of potential agrochemicals.

1. Introduction

The emergence of fungal resistance to existing fungicides has posed a serious concern for pesticide professionals during the last decade, and the desire for safer and more effective agrochemicals with reduced environmental toxicity also remains a high priority [1]. A further aim is to produce novel fungicides that do not impede the role of beneficial organisms in plant development and which do not persist in the environment and food chains [2], so the synthesis and antifungal evaluation of new compounds is greatly needed.
In this context, sulfone derivatives provide an example of an important class of bioactive compounds with a wide spectrum of activities, as the sulfone group is an important core found in numerous biologically active compounds with a wide range of biological activity including insecticidal [3], antifungal [4], herbicidal [5], anti-hepatitis [6], antitumor [7], anti-inflammatory [8], anticancer [9], anti-HIV-1 [10] and anti-tubercular [11] properties. There is evidence that the key feature of these compounds is a 5- or 6-membered heterocyclic ring attached to a sulfone, and additional modification of the heterocyclic ring has been considered. Among these derivatives, a 2-((4-chlorobenzyl)sulfonyl)-5-(methylsulfonyl)-1,3,4-thiadiazole sulfone prepared by Joachim et al. exhibited good inhibitory activity against Plasmopara viticola [12] at a concentration of 1 × 10−5 mg/kg, 2,4-dibromo-5-methyl-1-((2-methyl-5-nitrophenyl)sulfonyl)-1H-imidazole sulfone, reported by Assmann et al., exhibited strong activity against Phytophthora infestans and Plasmopara viticola [13] at a concentration of 50 g/ha, and 2-(5-ethyl-1-methyl-1H-pyrazol-3-yl)-5-(methylsulfonyl)-1,3,4-oxadiazole sulfone, prepared by Yuan et al., exhibited medium inhibitory activity against Phoma asparagi [14]. As an illustration of a practical application, the agricultural fungicide oxycarboxin was successfully commercialized by Uniroyal Co. in the year 1966. In the past few decades, a large number of other fungicides with potent bioactivity containing sulfone units such as tolylfluanid, dichlofluanid, cyazofamid, amisulbrom and oryzaemate have been introduced in the market by various companies [15,16].
The 1,3,4-oxadiazole scaffold is an important pharmacophore in agricultural science and compounds bearing this moiety often display antifungal [17], herbicidal [18] and insecticidal [19,20] activities. As a illustration of the activity of 1,3,4-oxadiazole sulfones, Keshari et al. reported that 2-(5-sulfanyl-1,3,4-oxadiazol-2-yl)phenylacetate and 5-(pyridin-3-yl)-1,3,4-oxadiazole-2-thiol exhibit good antibacterial activities against Escherichia coli (MTCC 443) [21].
As part of our ongoing search for novel sulfone compounds possessing antifungal properties, new derivatives of 2-sulfonyl-5-(3,4,5-trimethoxyphenyl)-1,3,4-oxadiazole (I) [22] and 2-sulfinyl-5-(3,4,5-trimethoxyphenyl)-1,3,4-oxadiazole (II) [23] were synthesized. Subsequent in vitro bioassays disclosed that the compounds 2-(methylsulfonyl)-5-(3,4,5-trimethoxyphenyl)-1,3,4-oxadiazole (Ia) and 2-(benzylsulfinyl)-5-(3,4,5-trimethoxyphenyl)-1,3,4-oxadiazole (IIa) possess high antifungal activities against 10 kinds of fungi, with EC50 values ranging from 19.9 μg/mL to 93.3 μg/mL, being equivalent or more potent against the tested fungi than the commercial agricultural fungicide hymexazol, and they also showed broad-spectrum bioactivity.
The SAR suggested that 2-(methylsulfonyl)-1,3,4-oxadiazole is the core ring system that affords potent antifungal activities [22,23]. Given the apparent lack of scope for changes to the core ring system, the majority of our efforts were directed towards compounds of the general structure of the title compounds in which the core ring system was kept constant and the peripheral groups were altered. As a consequence, in an attempt to increase the fitting to the pharmacophoric model, and possibly to obtain new fungicides, we report here the synthesis, characterization and antifungal activity of novel sulfone derivatives containing 1,3,4-oxadiazole moieties 5, as shown in Scheme 1.
Molecules 16 09129 g002 550
Scheme 1. Synthetic route to the title compounds.
Scheme 1. Synthetic route to the title compounds.
Molecules 16 09129 g002

2. Results and Discussion

2.1. Chemistry Benzohydrazide

The key intermediate 2-thiol-5-substituted-1,3,4-oxadiazole (3) was prepared by cyclization of substituted phenylhydrazide, potassium hydroxide, and carbon disulfide in ethanol under reflux conditions. The key point of this reaction is that water must be removed completely; as the presence of even a little water may cause the cyclization to fail.
Although the electron rich methylthio moiety in compounds 4 can be oxidized to a sulfone by a variety of agents such as m-CPBA [24] or H2O2catalyzed by methyltrioxorhenium [25], unfortunately, most of these reagents are not satisfactory. They are either harmful or expensive, and a simple procedure is not easily available. In this experiment, the methylthio moiety in 4 was oxidized with potassium permanganate [26] in glacial acetic acid to afford the corresponding methylsulfonyl species 5, the advantage of this oxidation is that it uses an inexpensive oxidant without a catalyst; furthermore, the reaction is quickly complete and easy to work up. The physical characteristics, IR, 1H-NMR, 13C-NMR and elemental analyses data for all the synthesized compounds are reported in the Experimental section.

2.2. The Antifungal Activities of Oxadiazole Methyl Sulfones

The inhibitory effects of the synthesized oxadiazole methyl sulfone compounds on phytopathogenic fungi was studied. Two fungi, F. oxysporum and C. mandshurica, representing typical fungi often occurring in the Chinese agro-ecosystem were chosen for fungicide screening using the mycelial growth rate method. The results were compared with that of the commercial agricultural fungicide hymexazol (a broad spectrum fungicide), as indicated in Table 1.
Table
Table 1. Inhibition effect of oxadiazole methyl sulfones against phytopathogenic fungi at 50 µg/mL. Molecules 16 09129 i002
Table 1. Inhibition effect of oxadiazole methyl sulfones against phytopathogenic fungi at 50 µg/mL. Molecules 16 09129 i002
CompoundRInhibition (%)
F. oxysporumC. mandshurica
5a Molecules 16 09129 i00371.1 ± 7.768.3 ± 9.3
5b Molecules 16 09129 i00497.5 ± 3.389.7 ± 3.1
5c Molecules 16 09129 i00572.6 ± 6.478.2 ± 4.7
5d Molecules 16 09129 i00670.1 ± 4.964.0 ± 1.3
5e Molecules 16 09129 i00798.8 ± 8.097.8 ± 11.8
5f Molecules 16 09129 i00894.0 ± 4.197.6 ± 4.3
5g Molecules 16 09129 i00989.6 ± 4.591.3 ± 9.6
5h Molecules 16 09129 i01074.6 ± 8.599.3 ± 12.8
5i Molecules 16 09129 i01177.0 ± 6.679.6 ± 7.1
5j Molecules 16 09129 i01267.1 ± 4.864.0 ± 2.6
Hymexazol58.4 ± 0.857.3 ± 0.3
As indicated in Table 1, at the concentration of 50 µg/mL, all of the tested compounds exhibited good inhibitory effects against F. oxysporum, and all of them showed superiority over the commercial fungicide hymexazol. Among them, compounds 5b, 5e and 5f almost completely inhibited the growth of F. oxysporum, with control efficacies of 97.5%, 98.8%, and 94.0%, respectively. Compound 5g showed 89.6% fungicidal activity against F. oxysporum, while the others had inhibition activities between 67.1% and 77.0%. As the results described in Table 1 indicate, all of the tested compounds possessed promising inhibitory effects against C. mandshurica. Among them, compounds 5e, 5f, 5g, and 5h almost completely inhibited the growth of C. mandshurica, with inhibition values of more than 90.0%, whereas compound 5b showed 89.7% fungicidal activity against C. mandshurica, and compounds 5a, 5c, 5d, 5i, and 5j inhibited the growth of C. mandshurica by 68.3%, 78.2%, 64.0%, 79.6%, and 64.0%, respectively.

2.3. Toxicity of Some Title Compounds on 8 Kinds of Pathogenic Fungi

We choose some representative compounds with good, ordinary antifungal activity, as indicated in the previous bioassays, to conduct further work which disclosed that some sulfone compounds containing a methyl oxadiazole showed remarkable inhibitory effect on eight kinds of plant pathogenic fungi, which represent typical fungi often occurring in the Chinese agro-ecosystem. The results are summarized in Table 2.
Table
Table 2. Toxicity of some methyl sulfones on eight kinds of pathogenic fungi.
Table 2. Toxicity of some methyl sulfones on eight kinds of pathogenic fungi.
CompoundsFungiToxic regression equationEC50 (µg/mL)R
5d C. mandshuricay = 1.428x + 2.28379.92 ± 14.790.861
F. oxysporumy = 1.355x + 3.01729.07 ± 7.820.952
R. solani y = 2.163x + 3.2516.43 ± 1.340.878
B. cinereay = 1.341x + 4.0385.21 ± 2.050.921
P. infestansy = 1.372x + 3.39714.73 ± 3.230.846
C. gloeosporioidesy = 2.930x + 1.17320.23 ± 6.650.961
S. sclerotiorumy = 1.860x + 3.2728.49 ± 3.510.919
T. cucumerisy = 3.537x + 1.46010.01 ± 5.640.974
5e C. mandshuricay = 3.623x − 0.73538.27 ± 3.210.867
F. oxysporumy = 1.439x + 2.38465.75 ± 7.040.976
T. cucumerisy = 7.95x − 5.87823.35 ± 4.760.980
R. solani y = 3.681x + 0.11521.23 ± 4.120.916
B. cinereay = 1.993x + 3.1738.25 ± 0.850.853
P. infestansy = 1.216x + 2.84259.52 ± 16.790.991
C. gloeosporioidesy = 4.629x − 1.55626.07 ± 7.320.943
S. sclerotiorumy = 5.984x − 2.03414.97 ± 6.830.974
5f C. mandshuricay = 1.131x + 2.74798.18 ± 8.350.981
F. oxysporumy = 1.081x + 2.91285.41 ± 17.920.988
T. cucumerisy = 2.381x + 1.66125.25 ± 2.340.911
R. solani y = 2.432x + 2.06116.16 ± 9.760.916
B. cinereay = 2.528x + 2.7128.03 ± 0.860.962
P. infestansy = 1.163x + 3.10142.93 ± 7.380.993
C. gloeosporioidesy = 1.861x + 2.17133.12 ± 8.290.979
S. sclerotiorumy = 5.036x − 1.22317.20 ± 4.720.951
5i F. oxysporumy = 4.243x − 1.26129.89 ± 1.310.918
C. mandshuricay = 4.355x − 2.17944.50 ± 3.560.947
R. solani y = 5.036x − 1.87920.02 ± 1.280.978
T. cucumerisy = 5.285x − 3.99424.78 ± 4.290.964
S. sclerotiorumy = 2.562x + 2.00314.78 ± 1.020.879
B. cinereay = 7.582x − 5.02621.00 ± 2.010.947
C. gloeosporioidesy = 6.364x − 3.53721.95 ± 2.930.963
P. infestansy = 1.358x + 2.69749.64 ± 9.390.958
HymexazolF. oxysporumy = 1.343x + 3.05827.93 ± 1.020.980
C. mandshuricay = 2.103x + 1.64739.26 ± 2.790.999
R. solani y = 3.532x − 0.60438.64 ± 0.450.880
T. cucumerisy = 1.298x + 3.04332.21 ± 5.820.958
S. sclerotiorumy = 2.346x + 2.9007.76 ± 2.980.998
C. gloeosporioidesy = 3.896x − 1.13637.58 ± 3.160.946
P. infestansy = 1.715x + 2.55926.49 ± 1.420.858
B. cinereay = 2.014x + 2.17725.23 ± 6.120.917
As indicated in Table 2, all of the test compounds possessed prominent antifungal activities against eight plant pathogens (F. oxysporum, C. mandshurica, R. solani, T. cucumeris, S. sclerotiorum, C. gloeosporioides, P. infestans, B. cinerea), with EC50 values between 5.21 µg/mL to 98.18 µg/mL. Among them, the bioassay results showed that compounds 5d, 5e, 5f, and 5i showed prominent activity against R. solani (EC50 values of 6.43 µg/mL, 21.23 µg/mL, 16.16 µg/mL, and 20.02 µg/mL, respectively), which was superior to the activity of the commercial fungicide hymexazol (38.64 µg/mL). B. cinerea has been identified as a pathogen of more than 235 plant species, including grapes, lettuce, tomatoes, tobacco, and strawberries, producing a gray powdery mold on the infected crops. To our delight, compounds 5d, 5e, 5f, and 5i showed prominent activity against B. cinerea, the EC50values of 5.21 µg/mL, 8.25 µg/mL, 8.03 µg/mL, and 21.00 µg/mL, respectively, all of them being more effective than the positive control. The results also suggested that compound 5d can be used as a possible lead compound for the development of potential agrochemicals. Compounds 5d, 5e, 5f, and 5i showed ordinary activity against S. sclerotiorum, the EC50 values of 8.49 µg/mL, 14.97 µg/mL, 17.20 µg/mL, and 14.78 µg/mL, respectively, less effective than the positive control hymexazol (7.76 µg/mL). Compounds 5d, 5e, 5f, and 5i showed weak effectivity against C. mandshurica, with EC50 values of 79.92 µg/mL, 38.27 µg/mL, 98.18 µg/mL, and 44.50 µg/mL, respectively. Generally speaking, compounds 5d, 5e, 5f, and 5i showed weak to normal effective against F. oxysporum, T. cucumeris, S. sclerotiorum, C. gloeosporioides, and P. infestans, with EC50 values ranging from 14.73 µg/mL to 85.41 µg/mL. As indicated in Table 1 and Table 2, with C. mandshurica as the experimental target the relationship between antifungal activity and substituent attached to the benzene ring showed that a fluorinated phenyl group, such as compound 5e (R = 2,6-2F), had better antifungal activity (97.8% fungicidal activity against C. mandshurica at 50 µg/mL, and the EC50 was 38.27 µg/mL).
Compound 5d had prominent antifungal activities against most of the tested fungi, and showed a broad-spectrum bioactivity; the inhibition effects of compound 5d on mycelia growth in vitro at different concentrations are illustrated in Figure 1.
Molecules 16 09129 g001 550
Figure 1. Effect of different concentrations of 5d on the mycelial growth of pathogenic fungi (50, 25, 12.5, 6.25, 3.125, 0 µg/mL, the smaller of zone, the higher of concentration).
Figure 1. Effect of different concentrations of 5d on the mycelial growth of pathogenic fungi (50, 25, 12.5, 6.25, 3.125, 0 µg/mL, the smaller of zone, the higher of concentration).
Molecules 16 09129 g001

3. Experimental

3.1. General

Unless otherwise indicated, all common reagents and solvents were used as obtained from commercial suppliers without further purifications. The melting points of the products were determined on a XT-4 binocular microscope (Beijing Tech Instrument Co., China) and were not corrected. The IR spectra were recorded on a Bruker VECTOR 22 spectrometer in KBr disks. 1H- and 13C-NMR spectra (solvent CDCl3) were recorded on a JEOL-ECX 500 NMR spectrometer at room temperature using TMS as an internal standard, chemical shift values (δ) are given in parts per million. Elemental analysis was performed on an Elementar Vario-III CHN analyzer. Analytical TLC was performed on silica gel GF254. Column chromatographic purification was carried out using silica gel.

3.2. Preparation of the Intermediates 1–3

Starting from the corresponding acid, and following the reported method [27,28], intermediates 3 were synthesized in three steps involving esterification, hydrazination, and cyclization. Specifically, 2-thiol-5-substituted-1,3,4-oxadiazole intermediates 3 were prepared by the reaction of substituted phenylhydrazide intermediates 2, potassium hydroxide, and carbon disulfide in ethanol under reflux conditions. Intermediates 2 were synthesized from intermediates 1 and hydrazine hydrate in methanol under reflux condition. Intermediates 1 (substituted benzoic acid esters) were made through esterification reactions from the starting acids.

3.3. Preparation of the Intermediates 4

To a solution of 2-thiol-5-substituted-1,3,4-oxadiazole 3 (2 mmol) and sodium hydroxide (0.08 g, 2 mmol) in water (20 mL), dimethyl sulfate (0.32 g, 2.5 mmol) was added dropwise. After stirring for 3 h at room temperature (20–23 °С), for solid products, the precipitate was filtered off, washed with 5% Na2CO3 solution and distilled water, dried and recrystallized from ethanol to afford the white solid products 4; for liquid products, the reaction mixture was washed with 5% Na2CO3solution, and then extracted with ethyl ether (4 × 20 mL), the ethyl ether layer was dried with anhydrous Na2SO4, after removal of the organic solvent under reduced pressure, and oily products 4 were thus obtained.
2-(Methylthio)-5-(2-(trifluoromethyl)phenyl)-1,3,4-oxadiazole (4a): yield 79.2%; white solid; m.p. 76–78 °С; 1H-NMR δ: 7.58–7.43 (m, 4H, benzene-H), 3.15 (s, 3H, SCH3); 13C-NMR δ: 162.23, 159.43, 133.05, 132.78, 132.31, 131.67, 131.03, 122.34, 14.73.
2-(Methylthio)-5-(2,3,4-trifluorophenyl)-1,3,4-oxadiazole (4b): yield 77.9%;oil; 1H-NMR δ: 7.88–7.46 (m, 2H, benzene-H), 3.22 (s, 3H, SCH3).
2-(Methylthio)-5-(pyridin-4-yl)-1,3,4-oxadiazole (4c): yield 75.4%; oil. 1H-NMR δ: 8.66–7.47 (m, 4H, pyridin-H), 2.91 (s, 3H, SCH3).
2-(Methylthio)-5-(2-fluorophenyl)-1,3,4-oxadiazole (4d): yield 85.0%; oil; 1H-NMR δ: 7.61–7.25 (m, 4H, benzene-H), 2.93 (s, 3H, SCH3); 13C-NMR δ: 163.41, 159.94, 159.73, 136.37, 133.71, 132.32, 129.74, 121.45, 14.71.
2-(Methylthio)-5-(2,6-difluorophenyl)-1,3,4-oxadiazole (4e): yield 88.4%; oil; 1H-NMR δ: 7.84–7.27 (m, 3H, benzene-H), 2.78 (s, 3H, SCH3); 13C-NMR δ: 165.73, 164.15, 153.63, 151.74, 149.75, 123.50, 118.38, 116.23, 14.72.
2-(Methylthio)-5-(2,6-dichlorophenyl)-1,3,4-oxadiazole (4f): yield 78.3%; oil; 1H-NMR δ: 7.63–7.24 (m, 3H, benzene-H), 2.81 (s, 3H, SCH3).
2-(Methylthio)-5-(2-methoxyphenyl)-1,3,4-oxadiazole (4g): yield 79.0%; oil; 1H-NMR δ: 7.88–7.27 (m, 4H, benzene-H), 3.02 (s, 3H, OCH3), 2.79 (s, 3H, SCH3). 13C-NMR δ: 165.23, 162.43, 138.69, 131.87, 128.77, 125.22, 122.37, 45.23, 14.43.
2-(Methylthio)-5-(2-methylphenyl)-1,3,4-oxadiazole (4h): yield 85.2%; oil; 1H-NMR δ: 7.88–7.27 (m, 4H, benzene-H), 2.79 (s, 3H, SCH3), 2.68 (s, 3H, CH3); 13C-NMR δ: 166.14, 161.67, 138.34, 131.92, 128.80, 126.21, 121.43, 22.13, 14.68.
2-(Methylthio)-5-(2-bromophenyl)-1,3,4-oxadiazole (4i): yield 85.3%; oil; 1H-NMR δ: 7.81–7.44 (m, 4H, benzene-H), 3.03 (s, 3H, SCH3).
2-(Methylthio)-5-(2-chloro-6-fluorophenyl)-1,3,4-oxadiazole (4j): yield 79.3%; oil; 1H-NMR δ: 7.94–7.33 (m, 3H, benzene-H), 2.71 (s, 3H, SCH3).

3.4. Preparation of the Title Compounds 5

A solution of 2-methylthio-5-substituted-1,3,4-oxadiazole 4 (3.83 mmol) in glacial acetic acid (10 mL) was treated dropwise at 10 °C with potassium permanganate (0.78 g, 4.98 mmol) as a 5% aqueous solution over 20 min. The reaction was allowed to proceed for an additional 20 min, 40% strength aqueous sodium hydrogen sulphite solution was subsequently added until the mixture was decolorized, and diluted with 50 mL of water. The product was filtered and recrystallised from ethanol give the title compounds 5.
2-(Methylsulfonyl)-5-(2-(trifluoromethyl)phenyl)-1,3,4-oxadiazole (5a): yield 86.6%; white solid; m.p. 102–104 °С; 1H-NMR δ: 7.66–7.14 (m, 4H, ArH), 3.54 (s, 3H, CH3); 13C-NMR δ: 162.81, 161.81, 135.43, 135.25, 133.65, 133.29, 112.86, 110.50, 43.12; IR (cm−1) ν: 2931, 1616, 1558, 1543, 1458, 1338, 1192; Anal. Calcd for C10H7F3N2O3S: C 41.10, H 2.41, N 9.59; found: C 41.46, H 2.02, N 9.88.
2-(Methylsulfonyl)-5-(2,3,4-trifluorophenyl)-1,3,4-oxadiazole (5b): yield 84.3%; white solid; m.p. 114–115 °С; 1H-NMR δ: 7.97–7.32 (m, 2H, ArH), 3.54 (s, 3H, CH3); 13C-NMR δ: 167.56, 161.52, 161.47, 125.65, 123.74, 121.74, 119.78, 111.23, 43.11; IR (cm−1) ν: 3027, 2926, 1616, 1558, 1506, 1350, 1156; Anal. Calcd for C9H5F3N2O3S: C 38.85, H 1.81, N 10.07; found: C 38.56, H 1.51, N 9.82.
2-(Methylsulfonyl)-5-(pyridin-4-yl)-1,3,4-oxadiazole (5c): yield 84.0%; white solid; m.p. 134–136 °С; 1H-NMR δ: 8.41–7.27 (m, 4H, pyridine-H), 3.54 (s, 3H, CH3); 13C-NMR δ: 167.38, 162.45, 151.12, 150.45, 133.12, 121.15, 112.40, 40.32; IR (cm−1) ν: 3031, 2927, 1616, 1558, 1373, 1153; Anal. Calcd for C8H7N3O3S: C 42.66, H 3.13, N 18.66; found: C 41.29, H 2.97, N 19.01.
2-(Methylsulfonyl)-5-(2-fluorophenyl)-1,3,4-oxadiazole (5d): yield 83.7%; white solid; m.p. 97–99 °С; 1H-NMR δ: 8.12–7.29 (m, 4H, ArH), 3.54 (s, 3H, CH3); 13C-NMR δ: 162.30, 161.58, 159.52, 135.34, 135.27, 130.35, 125.07, 117.50, 117.33, 110.85, 43.08; IR (cm−1) ν: 3012, 2927, 1616, 1541, 1458, 1340, 1145; Anal. Calcd for C9H7FN2O3S: C 44.63, H 2.91, N 11.56; found: C 44.41, H 2.68, N 11.72.
2-(Methylsulfonyl)-5-(2,6-difluorophenyl)-1,3,4-oxadiazole (5e): yield 80.2%; white solid; m.p. 131–132 °С; 1H-NMR δ: 7.63–7.12 (m, 3H, ArH); 3.53 (s, 3H, CH3); 13C-NMR δ: 162.86, 162.02, 159,94, 159.17, 135.25, 112.89, 112.73, 43.12; IR (cm−1) ν: 3022, 2931, 1629, 1587, 1477, 1352, 1153; Anal. Calcd for C9H6F2N2O3S: C 41.54, H 2.32, N 10.77; found: C 41.41, H 2.01, N 10.48.
2-(Methylsulfonyl)-5-(2,6-dichlorophenyl)-1,3,4-oxadiazole (5f): yield 84.3%; white solid; m.p. 126–128 °С; 1H-NMR δ: 7.51 (s, 3H, ArH), 3.55 (s, 3H, CH3); 13C-NMR δ: 163.37, 162.00, 136.65, 134.00, 128.62, 128.44, 122.53, 43.13; IR (cm−1) ν: 3028, 2927, 1616, 1587, 1473, 1372, 1153; Anal. Calcd for C9H6Cl2N2O3S: C 36.88, H 2.06, N 9.56; found: C 36.82, H 1.97, N 9.71.
2-(Methylsulfonyl)-5-(2-methoxyphenyl)-1,3,4-oxadiazole (5g): yield 87.2%; white solid; m.p. 127–129 °С; 1H-NMR δ: 8.02–7.36 (m, 4H, ArH), 3.54 (s, 3H, CH3), 2.74 (s, 3H, OCH3); 13C-NMR δ: 155.79, 155.32, 132.81, 131.83, 131.36, 129.76, 128.26, 122.49, 43.01, 22.21; IR (m−1) ν: 3084, 2827, 1635, 1558, 1506, 1458, 1379, 1163; Anal. Calcd for C10H10N2O4S: C 47.24, H 3.96, N 11.02; found: C 47.19, H 4.28, N 10.96.
2-(Methylsulfonyl)-5-(2-methylphenyl)-1,3,4-oxadiazole (5h): yield 83.4%; white solid; m.p. 117–119 °С; 1H-NMR δ: 8.00–7.08 (m, 4H, ArH), 3.99 (s, 3H, CH3), 3.52 (s, 3H, CH3); 13C-NMR δ: 165.66, 161.94, 158.56, 134.76, 131.14, 121.01, 112.16, 56.17, 43.04; IR (KBr, cm−1) ν: 3010, 2926, 1604, 1533, 1498, 1338, 1155; Anal. Calcd for C10H10N2O3S: C 50.41, H 4.23, N 11.76; found: C 50.03, H 4.45, N 11.49.
2-(Methylsulfonyl)-5-(2-bromophenyl)-1,3,4-oxadiazole (5i): yield 78.8%; white solid; m.p. 134–135 °С; 1H-NMR δ: 8.00–7.46 (m, 4H, ArH), 3.54 (s, 3H, CH3);13C-NMR δ: 165.54, 162.55, 135.02, 133.87, 132.22, 127.96, 123.57, 122.29, 43.07; IR (cm−1) ν: 3028, 2943, 1615 1557, 1516, 1443, 1373, 1155; Anal. Calcd for C9H7BrN2O3S: C 35.66, H 2.33, N 9.24; found: C 35.87, H 2.44, N 9.61.
2-(Methylsulfonyl)-5-(2-chloro-6-fluorophenyl)-1,3,4-oxadiazole (5j): yield 86.1%; white solid; m.p. 121–123 °С; 1H-NMR δ: 8.89–7.45 (m, 3H, ArH), 3.543 (s, 3H, CH3); 13C-NMR δ: 165.91, 161.87, 134.71, 134.65, 132.54, 131.23, 127.38, 42.95; IR (cm−1) ν: 3033, 2941, 1615, 1557, 1456, 1337, 1151; Anal. Calcd for C9H6ClFN2O3S: C 39.07, H 2.19, N 10.13; found: C 39.02, H 2.29, N 10.11.

3.5. Antifungal Activities Test

The antifungal activities were tested against two pathogenic fungi, Fusarium oxysporum and Cytospora mandshurica, by the poison plate technique [29]. Compounds were dissolved in dimethyl sulfoxide (1 mL) before mixing with potato dextrose agar (PDA, 90 mL). The compounds were tested at a concentration of 50 μg/mL. All fungi were incubated in PDA at 27 ± 1 °C for 4 days to get new mycelium for antifungal assay. Then mycelia dishes of approximately 4 mm diameter were cut from culture medium, and one of them was picked up with a sterilized inoculation needle and inoculated in the center of PDA plate aseptically. The inoculated plates were incubated at 27 ± 1 °C for 5 days. DMSO in sterile distilled water served as negative control, while hymexazol acted as positive control. For each treatment, three replicates were conducted. The radial growth of the fungal colonies was measured and the data were statistically analyzed. The inhibitory effects of the test compounds in vitro on these fungi were calculated by the formula: I(%) = [(C − T)/(C − 0.4)] × 100, where C represents the diameter of fungi growth on untreated PDA, and T represents the diameter of fungi on treated PDA while I means the inhibition rate.
Some of the title compounds were tested against eight pathogenic fungi namely F. oxysporum, C. mandshurica, Phytophthora infestans, Rhizoctonia solani, Thanatephorus cucumeris, Colletotrichum gloeosporioides, Botrytis cinerea and Sclerotinia sclerotiorum at different concentrations of 50, 25, 12.5, 6.25, 3.125, 0 µg/mL. The EC50 (effective dose for 50% inhibition µg/mL) values were estimated statistically by probit analysis with the help of the probit package of the SPSS software using a personal computer. The average EC50 was taken from at least three separate analyses for inhibition of growth using the basic EC50 program version SPSS 11.5.

4. Conclusions

In summary, a series of new sulfone compounds containing 1,3,4-oxadiazole moieties and based on the lead compound Ia was designed and synthesized. The title compounds showed promising antifungal activities against some typical fungi often occurring in the Chinese agro-ecosystem, including F. oxysporum, C. mandshurica, R. solani, T. cucumeris, S. sclerotiorum, C. gloeosporioides, P. infestans, B. cinerea. Among them, some compounds showed superiority over the lead compound Ia, such as compound 5b with EC50 values ranging from 5.21 μg/mL to 79.2 μg/mL, and some, such as compounds 5b, 5d and 5e showed superiority over the commercial fungicide hymexazol. In particular, compounds 5d, 5e, 5f, and 5i showed prominent activity against B. cinerea, with EC50 values of 5.21 µg/mL, 8.25 µg/mL, 8.03 µg/mL, and 21.00 µg/mL, respectively. These results demonstrated that some compounds such as 5d can be used as possible lead compounds for the development of potential agrochemicals.

Acknowledgments

We are grateful to the National Natural Science Foundation of China (Nos. 20962005, 20762002), the National Key Technology R&D Program (Nos. 2011BAE06B05-6, 2011BAE06B02-14, 2011BAE06B02-09), S&T Program of Guizhou Province (No. [2011]3016) for supporting the project.

Conflict of Interest

The authors declare no conflict of interest.

References and Notes

  1. Russell, P.E. A century of fungicide evolution. J. Agric. Sci. 2005, 143, 11–25. [Google Scholar] [CrossRef]
  2. Copping, L.G.; Menn, J.J. Biopesticides: A review of their action, applications and efficacy. Pest. Manag. Sci. 2000, 56, 651–767. [Google Scholar] [CrossRef]
  3. Fitzjohn, S.; Robinson, M.P. Benzoxazole and benzothiazole derivatives. WO 9406783, 1994. Chem. Abst. 1994, 121, 9394. [Google Scholar]
  4. Hiromichi, I.; Masakazu, T.; Ten, U.; Seiichi, K. Preparation of disulfonylthiadiazoles and their use as agrochemical microbicides. JP 94116252, 1994. Chem. Abst. 1994, 121, 127847. [Google Scholar]
  5. Plant, A.; Boehmer, J.E.; Black, J.; Sparks, T.D. Isoxazoline derivatives and their preparation, herbicidal composition, and use as herbicides to control weeds or plant growth inhibition. WO 2006024820, 2006. Chem. Abst. 2006, 144, 274262. [Google Scholar]
  6. Gong, P.; Chai, H.F.; Zhao, Y.F.; Zhao, C.S. Synthesis and in vitro anti-hepatitis B virus activities of some ethyl 5-hydroxy-1H-indole-3-carboxylates. Bioorg. Med. Chem. 2006, 14, 2552–2558. [Google Scholar] [CrossRef]
  7. Tai, X.S.; Yin, X.H.; Tan, M.Y. Crystal structure and antitumor activity of tri[2-[N-(4'-methyl-benzylsulfonyl)amino]ethyl]-amine. Chin. J. Struct. Chem. 2003, 22, 411–414. [Google Scholar]
  8. Fang, S.H.; Padmavathi, V.; Rao, Y.K.; Subbaiah, D.R.C.; Thriveni, P.; Geethangili, M.; Padaja, A.; Tzeng, Y.M. Biological evaluation of sulfone derivatives as anti-inflammatory and tumor cells growth inhibitory agents. Int. Immunopharmacol. 2006, 6, 1699–1705. [Google Scholar] [CrossRef]
  9. Vedula, M.S.; Pulipaka, A.B.; Venna, C.; Chintakunta, V.K.; Jinnapally, S.; Kattuboina, V.A.; Vallakati, R.K.; Basetti, V.; Akella, V.; Rajgopai, S.; et al. New styryl sulfones as anticancer agents. Eur.J.Med.Chem. 2003, 38, 811–824. [Google Scholar] [CrossRef]
  10. Silvestri, R.; Artico, M.; Regina, G.L. Anti-HIV-1 activity of pyrryl aryl sulfone (PAS) derivatives: Synthesis and SAR studies of novel esters and amides at the position 2 of the pyrrole nucleus. Farmaco 2004, 59, 201–210. [Google Scholar] [CrossRef]
  11. Talath, S.; Gadad, A.K. Synthesis, antibacterial and anti-tubercular activities of some 7-[4-(5-amino-[1,3,4]thiadiazole-2-sulfonyl)-piperazin-1-yl] fluoroquinolonic derivatives. Eur. J. Med. Chem. 2006, 41, 918–924. [Google Scholar] [CrossRef]
  12. Diehr, H.J.; Marhold, A.; Brandes, W.; Hanssler, G. Preparation of 2,5-bis (alkylsulfonyl)-1,3,4-thiadiazoles as agrochemical fungicides. DE 3838432, 1990. Chem. Abst. 1990, 113, 191364. [Google Scholar]
  13. Assmann, L.; Stenzel, K.; Erdelen, C.; Kugler, M.; Wachtler, P. Nitrophenyl sulfonyl imidazoles and use thereof for controlling vegetable and animal pests. US 20020094936 A1, 2002. Chem. Abst. 2002, 130, 125074. [Google Scholar]
  14. Yuan, D.K.; Li, Z.M.; Zhao, W.G.; Chen, H.S. Synthesis and bioactivity of 2-substituted amino-5-pyrazolyl-1,3,4-oxadiazoles. Chin. J. Appl. Chem. 2003, 20, 624–628. [Google Scholar]
  15. Ohshima, T.; Komyojia, T.; Mitani, S. Development of a novel fungicide, eyazofamid. J. Pestic. Sci. 2004, 29, 136–138. [Google Scholar] [CrossRef]
  16. Komyji, N.; Terumasa, K.; Kazumi, S.; Keiichiro, I. Imidazole compounds and biocidal compositions comprising the same. EP 0298196A1, 1989. Chem. Abst. 1989, 110, 192824. [Google Scholar]
  17. Liu, Z.; Yang, G.; Qin, X. Syntheses and biological activities of novel diheterocyclic compounds containing 1,2,4-triazolo[1,5-α]pyrimidine and 1,3,4-oxadiazole. J. Chem. Technol. Biotechnol. 2001, 76, 1154–1158. [Google Scholar] [CrossRef]
  18. Jiang, L.; Tan, Y.; Zhu, X.; Wang, Z.; Zuo, Y.; Chen, Q.; Xi, Z.; Yang, G.F. Design, synthesis, and 3D-QSAR analysis of novel 1,3,4-oxadiazol-2(3H)-ones as protoporphyrinogen oxidase inhibitors. J. Agric. Food Chem. 2010, 58, 2643–2651. [Google Scholar] [CrossRef]
  19. Qian, X.; Zhang, R. Syntheses and insecticidal activities of novel 2,5-disubstituted-1,3,4-oxadiazoles. J. Chem. Tech. Biotechnol. 1996, 67, 124–130. [Google Scholar] [CrossRef]
  20. Cao, S.; Qian, X.; Song, G.; Chai, B.; Jiang, Z. Synthesis and antifeedant activity of new oxadiazolyl 3(2H)-pyridazinones. J. Agric. Food Chem. 2003, 51, 152–155. [Google Scholar] [CrossRef]
  21. Keshari, K.J.; Abdul, S.; Yatendra, K.; Mohd, S.; Ratan, L.K.; Jainendra, J.; Vikash, K.; Priyanka, S. Design, synthesis and biological evaluation of 1,3,4-oxadiazole derivatives. Eur. J. Med. Chem. 2010, 45, 4963–4967. [Google Scholar] [CrossRef]
  22. Chen, C.J.; Song, B.A.; Yang, S.; Xu, G.F.; Bhadury, P.S.; Jin, L.H.; Hu, D.Y.; Li, Q.Z.; Liu, F.; Xue, W.; et al. Synthesis and antifungal activities of 5-(3,4,5-trimethoxyphenyl)-2-sulfonyl-1,3,4-thiadiazole and 5-(3,4,5-trimethoxyphenyl)-2-sulfonyl-1,3,4-oxadiazole derivatives. Bioorg. Med. Chem. 2007, 15, 3981–3989. [Google Scholar] [CrossRef]
  23. Liu, F.; Luo, X.Q.; Song, B.A.; Bhadury, P.S.; Yang, S.; Jin, L.H.; Xue, W.; Hu, D.Y. Synthesis and antifungal activity of novel sulfoxide derivatives containing trimethoxyphenyl substituted 1,3,4-thiadiazole and 1,3,4-oxadiazole moiety. Bioorg. Med. Chem. 2008, 16, 3632–3640. [Google Scholar] [CrossRef]
  24. Pees, B.; Paul, J.M.; Oget, N.; Sindt, M.; Mieloszynski, J.L. Synthesis of fluoro-substituted monomers bearing a functionalised lateral chain: Part 2. Preparation of sulfoxides and sulfones containing monomers. J. Fluorine Chem. 2003, 124, 139–146. [Google Scholar] [CrossRef]
  25. Yamazaki, S. Selective synthesis of sulfones and sulfoxides by methytrioxorhenium catalyzed oxidation of sulfides with hydrogen peroxide. Bull. Chem. Soc. Jpn. 1996, 69, 2955–2959. [Google Scholar] [CrossRef]
  26. Confalone, P.N.; Woodward, R.B. A novel synthesis of peptides based on the photochemistry of 5-azido-1,3,4-oxadiazoles. J. Am. Chem. Soc. 1983, 105, 902–906. [Google Scholar] [CrossRef]
  27. Song, B.A.; Chen, C.J.; Yang, S.; Jin, L.H.; Xue, W.; Zhang, S.M.; Zou, Z.H.; Hu, D.Y. Synthesis, structure and antitumor activity of 2-alkylthio-5-(3,4,5-trimethoxyphenyl)-1,3,4-thiadiazole compounds. Acta Chim. Sinica 2005, 63, 1720–1726. [Google Scholar]
  28. Chen, C.J.; Song, B.A.; Yang, S.; Xu, G.F.; Bhadury, P.S.; Jin, L.H.; Hu, D.Y.; Li, Q.Z.; Liu, F.; Xue, W.; et al. Synthesis and antifungal activities of 5-(3,4,5-trimethoxyphenyl)- 2-sulfonyl-1,3,4-thiadiazole and 5-(3,4,5-trimethoxyphenyl)-2-sulfonyl-1,3,4-oxadiazole derivatives. Bioorg. Med. Chem. 2007, 15, 3981–3989. [Google Scholar]
  29. Tarun, K.C.; Prem, D.J. Antifungal activity of 4-methyl-6-alkyl-2H-pyran-2-ones. J. Agric. Food Chem. 2006, 54, 2129–2133. [Google Scholar] [CrossRef]
  • Sample Availability: Samples of the compounds are available from the authors.
