Determination of Methylene Blue and Its Metabolite Residues in Aquatic Products by High-Performance Liquid Chromatography–Tandem Mass Spectrometry
Abstract
:1. Introduction
2. Results and Discussion
2.1. HPLC–MS/MS Conditions
2.2. Method Development
2.3. Method Validation
2.4. Application of the Method
3. Materials and Methods
3.1. Materials
3.2. Instrumentation and Chromatographic Conditions
3.3. Standard Stock Solutions Preparation
3.4. Method Validation
3.5. Sample Collection and Sample Preparation
3.6. Statistical Analysis
4. Conclusions
Supplementary Materials
Author Contributions
Funding
Institutional Review Board Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
Sample Availability
References
- Kram, S.J.; Kram, B.L.; Cook, J.C.; Ohman, K.L.; Ghadimi, K. Hydroxocobalamin or Methylene Blue for Vasoplegic Syndrome in Adult Cardiothoracic Surgery. J. Cardiothorac. Vasc. Anesth. 2021, 1–8. [Google Scholar] [CrossRef]
- Priyamvada, L.; Burgado, J.; Baker-Wagner, M.; Kitaygorodskyy, A.; Olson, V.; Lingappa, V.R.; Satheshkumar, P.S. New methylene blue derivatives suggest novel anti-orthopoxviral strategies. Antivir. Res. 2021, 191, 105086. [Google Scholar] [CrossRef]
- Badiee, H.; Zanjanchi, M.A.; Zamani, A.; Fashi, A. Hollow fiber liquid-phase microextraction based on the use of a rotating extraction cell: A green approach for trace determination of rhodamine 6G and methylene blue dyes. Environ. Pollut. 2019, 255, 113287. [Google Scholar] [CrossRef]
- Hakami, A.A.H.; Wabaidur, S.M.; Khan, M.A.; Alothman, Z.A.; Rafatullah, M.; Siddiqui, M.R. Development of Ultra-Performance Liquid Chromatography–Mass Spectrometry Method for Simultaneous Determination of Three Cationic Dyes in Environmental Samples. Molecules 2020, 25, 4564. [Google Scholar] [CrossRef]
- Ratna; Padhi, B.S. Pollution due to synthetic dyes toxicity & carcinogenicity studies and remediation. Int. J. Environ. Sci. 2012, 3, 940–955. [Google Scholar] [CrossRef]
- Li, C.; Huang, Y.; Lai, K.; Rasco, B.A.; Fan, Y. Analysis of trace methylene blue in fish muscles using ultra-sensitive surface-enhanced Raman spectroscopy. Food Control. 2016, 65, 99–105. [Google Scholar] [CrossRef]
- Schirmer, R.H.; Adler, H.; Pickhardt, M.; Mandelkow, E. “Lest we forget you—Methylene blue …”. Neurobiol. Aging 2011, 32, 2325.e7–2325.e16. [Google Scholar] [CrossRef] [PubMed]
- Turnipseed, S.B.; Roybal, J.E.; Plakas, S.M.; Pfenning, A.P.; Hurlbut, J.A.; Long, A.R. Determination of methylene blue in channel catfish (Ictalurus punctatus) tissue by liquid chromatography with visible detection. J. Assoc. Off. Anal. Chem. 1997, 80, 31–35. [Google Scholar] [CrossRef] [Green Version]
- Legal Information Institute. Electronic Code of Federal Regulations 40, § 180. 940 Food-Contact Surface Sanitizing Solutions; Exemptions from the Requirement of a Tolerance. 2002. Available online: https://www.law.cornell.edu/cfr/text/40/180.940 (accessed on 20 July 2021).
- Yamjala, K.; Nainar, M.S.; Ramisetti, N.R. Methods for the analysis of azo dyes employed in food industry—A review. Food Chem. 2016, 192, 813–824. [Google Scholar] [CrossRef] [PubMed]
- Lv, X.-M.; Yang, X.-L.; Xie, X.-Y.; Yang, Z.-Y.; Hu, K.; Wu, Y.-J.; Jiang, Y.-Y.; Liu, T.-F.; Fang, W.-H.; Huang, X.-Y. Comparative transcriptome analysis ofAnguilla japonicalivers following exposure to methylene blue. Aquac. Res. 2018, 49, 1232–1241. [Google Scholar] [CrossRef]
- Liu, X.-J.; Li, M.-F.; Singh, S.K. Manganese-modified lignin biochar as adsorbent for removal of methylene blue. J. Mater. Res. Technol. 2021, 12, 1434–1445. [Google Scholar] [CrossRef]
- Almehizia, A.A.; Al-Omar, M.A.; Naglah, A.M.; Bhat, M.A.; Al-Shakliah, N.S. Facile synthesis and characterization of ZnO nanoparticles for studying their biological activities and photocatalytic degradation properties toward methylene blue dye. Alex. Eng. J. 2021, 1–10. [Google Scholar] [CrossRef]
- Xu, T.; Wang, X.; Huang, Y.; Lai, K.; Fan, Y. Rapid detection of trace methylene blue and malachite green in four fish tissues by ultra-sensitive surface-enhanced Raman spectroscopy coated with gold nanorods. Food Control 2019, 106, 106720. [Google Scholar] [CrossRef]
- Huang, X.; Yang, G.; Kong, C.; Huang, D.; Cai, Y. Detection of methylene blue in fish by indirect competitive enzyme linked immunosorbent assay. Chin. J. Food Saf. Qual. 2020, 11, 8235–8239. [Google Scholar] [CrossRef]
- Fan, J.; Xie, Z.-H.; Teng, X.-X.; Zhang, Y. Determination of methylene blue by resonance light scattering method using silica nanoparticles as probe. Chin. Chem. Lett. 2017, 28, 1104–1110. [Google Scholar] [CrossRef]
- Tarbin, J.A.; Chan, D.; Stubbings, G.; Sharman, M. Multiresidue determination of triarylmethane and phenothiazine dyes in fish tissues by LC–MS/MS. Anal. Chim. Acta 2008, 625, 188–194. [Google Scholar] [CrossRef] [PubMed]
- Amelin, V.G.; Korotkov, A.I.; Andoralov, A.M. Simultaneous determination of dyes of different classes in aquaculture products and spices using HPLC–high-resolution quadrupole time-of-flight mass spectrometry. J. Anal. Chem. 2017, 72, 183–190. [Google Scholar] [CrossRef]
- Yu, W.; Huang, D.; Shi, Y.; Kong, C.; Tian, L.; Han, F.; Zhang, Z. Determination of brilliant green, methylene blue and their metabolites in aquatic products by liquid chromatography-tandem mass spectrometry. Chin. J. Instrum. Anal. 2019, 38, 58–63. [Google Scholar] [CrossRef]
- Kim, S.-J.; Ha, D.-J.; Koo, T.-S. Simultaneous quantification of methylene blue and its major metabolite, azure B, in plasma by LC-MS/MS and its application for a pharmacokinetic study. Biomed. Chromatogr. 2014, 28, 518–524. [Google Scholar] [CrossRef]
- Reyns, T.; Belpaire, C.; Geeraerts, C.; Van Loco, J. Multi-dye residue analysis of triarylmethane, xanthene, phenothiazine and phenoxazine dyes in fish tissues by ultra-performance liquid chromatography–tandem mass spectrometry. J. Chromatogr. B 2014, 953–954, 92–101. [Google Scholar] [CrossRef]
- Xu, J.-Z.; Dai, L.; Wu, B.; Ding, T.; Zhu, J.-J.; Lin, H.; Chen, H.-L.; Shen, C.-Y.; Jiang, Y. Determination of methylene blue residues in aquatic products by liquid chromatography-tandem mass spectrometry. J. Sep. Sci. 2009, 32, 4193–4199. [Google Scholar] [CrossRef] [PubMed]
- European Commission. Commission decision 2002/657/EC implementing Council Directive 92/23/EC concerning the performance of analytical methods and the interpretation of results. Off. J. Eur. Communities 2002, L221, 8–36. Available online: http://refhub.elsevier.com/S0039-9140(17)30912-8/sbref29 (accessed on 20 July 2021).
- Verdon, E.; Hurtaud-Pessel, D.; Sanders, P. Evaluation of the limit of performance of an analytical method based on a statistical calculation of its critical concentrations according to ISO standard 11843: Application to routine control of banned veterinary drug residues in food according to European Decision 657/2002/EC. Accredit. Qual. Assur. 2006, 11, 58–62. [Google Scholar] [CrossRef]
- Jia, W.; Chu, X.; Ling, Y.; Huang, J.; Chang, J. High-throughput screening of pesticide and veterinary drug residues in baby food by liquid chromatography coupled to quadrupole Orbitrap mass spectrometry. J. Chromatogr. A 2014, 1347, 122–128. [Google Scholar] [CrossRef] [PubMed]
- Gosetti, F.; Mazzucco, E.; Zampieri, D.; Gennaro, M.C. Signal suppression/enhancement in high-performance liquid chromatography tandem mass spectrometry. J. Chromatogr. A 2010, 1217, 3929–3937. [Google Scholar] [CrossRef] [PubMed]
Compounds | Retention Time (min) | Q1 Mass (m/z) | Q3 Mass (m/z) | Collision Energy (eV) | Ion Ratio (%) |
---|---|---|---|---|---|
MB | 3.48 | 284.0 | 268.1 1/252.0 | 34/49 | 28 |
AZA | 2.49 | 256.1 | 241.0 1/199.0 | 32/33 | 70 |
AZB | 2.98 | 270.1 | 254.1 1/212.0 | 34/51 | 30 |
AZC | 1.84 | 242.1 | 200.1 1/227.0 | 33/26 | 34 |
Compounds | LR (µg/kg) | R2 | LOD (µg/kg) | LOQ (µg/kg) | Intraday RSD (n = 3) (%) | Inter-Day RSD (n = 3, day) (%) | ME (%) |
---|---|---|---|---|---|---|---|
MB | 1–500 | 0.9982 | 0.75 | 1.0 | 4.95 | 6.47 | 2.9 |
AZA | 1–500 | 0.9966 | 0.75 | 1.0 | 6.75 | 8.50 | 12.8 |
AZB | 1–500 | 0.9978 | 0.75 | 1.0 | 4.34 | 5.61 | 7.0 |
AZC | 1–500 | 0.9959 | 0.75 | 1.0 | 7.08 | 9.59 | 15.9 |
Analytes | Add Level(µg/kg) | Recovery/% (RSD/%) | ||||||||
---|---|---|---|---|---|---|---|---|---|---|
Bream | Trout | Grass Carp | Fresh Shrimps | Chinese Mitten Crab | Crucian Carp | Perch | Catfish | Mussel | ||
MB | 1 | 93.2 (2.63) | 96.5 (4.27) | 95.2 (4.51) | 96.7 (7.04) | 89.9 (6.58) | 92.7 (3.04) | 91.5 (2.21) | 90.5 (4.18) | 89.7 (6.24) |
5 | 90.5 (5.23) | 95.0 (4.01) | 93.4 (3.28) | 95.1 (3.24) | 91.1 (5.63) | 93.3 (5.32) | 93.5 (3.08) | 96.0 (5.36) | 90.5 (6.06) | |
10 | 96.4 (6.37) | 95.3 (7.68) | 92.5 (4.05) | 97.5 (2.84) | 90.7 (6.70) | 90.5 (5.01) | 93.9 (4.29) | 93.2 (1.05) | 91.5 (5.71) | |
AZA | 1 | 86.2 (7.15) | 82.9 (7.52) | 88.9 (3.57) | 87.2 (6.35) | 83.2 (8.04) | 86.1 (3.82) | 88.6 (3.66) | 83.5 (6.01) | 81.6 (1.28) |
5 | 88.3 (8.63) | 84.9 (7.67) | 90.7 (3.69) | 84.9 (5.08) | 86.4 (8.36) | 83.1 (3.66) | 87.9 (2.08) | 85.5 (5.47) | 82.0 (1.38) | |
10 | 91.0 (5.72) | 89.5 (5.34) | 91.0 (2.61) | 86.5 (7.04) | 88.7 (6.04) | 88.6 (2.79) | 89.2 (1.99) | 83.9 (3.28) | 85.0 (1.98) | |
AZB | 1 | 95.3 (4.25) | 96.0 (5.05) | 97.1 (1.07) | 95.4 (5.60) | 92.5 (7.74) | 94.3 (1.35) | 92.8 (5.27) | 91.8 (2.04) | 93.4 (3.06) |
5 | 96.0 (3.35) | 94.2 (4.75) | 95.0 (2.67) | 96.2 (5.07) | 93.4 (6.66) | 90.5 (2.07) | 90.8 (3.31) | 93.0 (1.29) | 96.0 (1.08) | |
10 | 94.2 (3.07) | 93.8 (5.01) | 93.8 (1.96) | 93.7 (4.14) | 95.2 (4.24) | 92.0 (1.72) | 95.4 (3.07) | 91.2 (2.22) | 94.4 (1.66) | |
AZC | 1 | 73.2 (3.58) | 75.1 (5.05) | 74.5 (3.77) | 72.1 (5.74) | 71.8 (8.05) | 75.4 (4.76) | 74.8 (6.12) | 75.5 (7.22) | 72.1 (6.01) |
5 | 72.8 (4.57) | 77.0 (5.34) | 74.3 (3.04) | 75.4 (4.87) | 72.2 (6.80) | 73.5 (5.33) | 73.0 (5.76) | 72.0 (2.05) | 74.2 (5.20) | |
10 | 75.7 (3.39) | 78.7 (1.87) | 72.7 (3.30) | 72.7 (5.02) | 78.1 (6.17) | 78.6 (4.21) | 72.8 (3.35) | 74.6 (5.00) | 76.6 (6.45) |
Extraction Organic Solvent | Purification Agent | Sample | N 1 | LR (µg/L) | LOQ (µg/kg) | RSD (%) | Recovery (%) | Ref. |
---|---|---|---|---|---|---|---|---|
Acetonitrile | ALN cartridge | Aquatic products | 4 | 1–500 | 1.0 | 1.05–8.63 | 71.8–97.5 | Present method |
Acetonitrile containing 0.1% of formic acid | - | Aquatic products | 4 | 0.04–2.0 | 0.4–4 | 5–15 | 87–130 | [18] |
Ammonium acetate buffer solution and acetonitrile | Liquid–liquid distribution and PRS 2 cartridge | Aquatic products | 4 | 1–100 | 2 | 2.3–13.0 | 70.3–92.1 | [19] |
Acetonitrile | - | Plasma | 2 | 1–1000 | 30 | 3.6–11.9 | 97.9–108.0 | [20] |
Acetonitrile | CBA and SCX-SPE 3 cartridges | Eel | 2 | 2–16 | 0.25 | 8.3–14.5 | 84.1–102.1 | [21] |
Acetonitrile/sodium acetate buffer solution | ALN cartridge | Eel, toasted eel, and shrimp | 1 | 2.0–100.0 | 0.5 | 4.4–16.3 | 73.0–108.3 | [22] |
Time (min) | Mobile Phase A (%) | Mobile Phase B (%) | Mobile Phase C (%) |
---|---|---|---|
0.0 | 63 | 22 | 15 |
2.4 | 63 | 22 | 15 |
2.5 | 28 | 42 | 30 |
7.0 | 28 | 42 | 30 |
7.1 | 0 | 60 | 40 |
15.0 | 0 | 60 | 40 |
15.1 | 63 | 22 | 15 |
18.0 | 63 | 22 | 15 |
