Biofilm Medium Chemistry and Calcium Oxalate Morphogenesis
Abstract
:1. Introduction
2. Results
2.1. The Precipitate Phase Composition and the Morphology of Calcium Oxalate Crystals
2.1.1. Syntheses without Additives
2.1.2. Syntheses with the Addition of Environmental Ions
2.1.3. Syntheses with the Addition of Organic Acids
2.1.4. Syntheses with the Addition of Citric Acid + Environmental Ions
2.1.5. Syntheses with Citric Acid; Addition of Organic Acids and K+, Mg2+, Fe3+, SO42− and PO43− Ions
2.2. Crystal Chemistry Characterization of Synthesized Weddellites
3. Discussion
3.1. The Influence of Medium Chemistry on the Formation of Weddellite and the Content of Zeolite Water in It
- -
- Organic acids (fumaric + malic, succinic + malic, fumaric + succinic + malic);
- -
- Environmental ions (CO32−, Mg2+ + SO42− + CO32−, K+ + PO43− + Sr2+, K+ + Mg2+ + Fe2+ + SO42− + PO43− + CO32−);
- -
- Environmental ions (K+ + Mg2+ + Fe2+ + SO42− + PO43− + CO32−) simultaneously with either of the combinations of organic acids: fumaric, succinic, malic, fumaric + succinic, malic + fumaric, malic + succinic; or malic + succinic + fumaric.
3.2. The Influence of pH on Weddellite Formation and Its Characteristic
3.3. The Influence of Biofilm Additives on the Morphology of Calcium Oxalates
- Single dipyramidal or dipyramidal–prismatic crystals.
- Skeletal crystals with a flattened dipyramid.
- Regular intergrowths.
3.4. Mechanisms of the Interaction of Additives with Crystallizing Calcium Oxalates
4. Materials and Methods
4.1. Synthesis
4.2. Methods
4.2.1. X-ray Powder Diffraction (XRPD)
4.2.2. Scanning Electron Microscopy (SEM) and Energy-Dispersive X-ray (EDXS) Spectroscopy
5. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
Appendix A
Synthesis No. | Additives in Solution * | pH | ||
---|---|---|---|---|
Organic Acids | Environmental Ions | Initial | Final | |
Without additives | ||||
1 | - | - | 6.36 | 6.46 |
Environmental ions only | ||||
2 | - | K+, Mg2+, SO42− | 6.82 | 6.79 |
3 | - | K+, Mg2+, Fe3+, SO42−, PO43− | 5.02 | 4.94 |
Organic acids only | ||||
4 | citric | - | 5.01 | 5.35 |
5 | citric | - | 5.56 | 6.20 |
6 | citric | - | 6.06 | 6.90 |
7 | citric | - | 8.60 | 7.48 |
8 | citric, malic | - | 5.25 | 5.47 |
9 | citric, fumaric, malic | - | 4.52 | 4.62 |
10 | citric, fumaric, succinic, malic | - | 4.46 | 4.57 |
11 | citric, succinic, malic | - | 4.45 | 4.56 |
12 | fumaric, succinic, malic | - | 5.82 | 6.17 |
Citric acid + environmental ions | ||||
13 | citric | K+ | 5.82 | 5.62 |
14 | citric | Mg2+ | 4.32 | 4.90 |
15 | citric | Mg2+ | 6.5 | 5.61 |
16 | citric | Fe3+ | 4.01 | 4.60 |
17 | citric | Fe3+ | 5.00 | 5.22 |
18 | citric | Fe3+ | 5.48 | 5.88 |
19 | citric | Fe3+ | 6.07 | 7.01 |
20 | citric | CO32− | 4.78 | 5.34 |
21 | citric | K+, PO43− | 4.18 | 4.82 |
22 | citric | Mg2+, SO42− | 5.06 | 5.36 |
23 | citric | Mg2+, CO32− | 6.00 | 5.15 |
24 | citric | Fe3+, SO42− | 4.62 | 4.72 |
25 | citric | K+, Mg2+, PO43− | 4.78 | 5.32 |
26 | citric | Mg2+, SO42−, CO32− | 5.72 | 6.46 |
27 | citric | K+, Mg2+, PO43− | 6.50 | 5.01 |
28 | citric | K+, Sr2+, PO43− | 6.50 | 6.81 |
29 | citric | K+, Mg2+, SO42−, PO43− | 4.90 | 6.75 |
30 | citric | K+, Mg2+, Fe3+, SO42−, PO43− | 4.73 | 6.45 |
31 | citric | K+, Mg2+, Fe2+, SO42−, PO43−, CO32− | 4.91 | 5.62 |
Organic acid combinations and K+, Mg2+, Fe3+, SO42−, PO43− ions | ||||
32 | citric, fumaric | K+, Mg2+, Fe3+, SO42−, PO43− | 4.66 | 5.09 |
33 | citric, succinic | K+, Mg2+, Fe3+, SO42−, PO43− | 4.64 | 5.01 |
34 | citric, malic | K+, Mg2+, Fe3+, SO42−, PO43− | 4.87 | 5.84 |
35 | citric, fumaric, succinic | K+, Mg2+, Fe3+, SO42−, PO43− | 4.78 | 5.21 |
36 | citric, malic, fumaric | K+, Mg2+, Fe3+, SO42−, PO43− | 4.69 | 5.17 |
37 | citric, malic, succinic | K+, Mg2+, Fe3+, SO42−, PO43− | 4.72 | 5.20 |
38 | citric, malic, fumaric, succinic | K+, Mg2+, Fe3+, SO42−, PO43− | 4.67 | 5.21 |
Synthesis No. (Table A1) | Wd Content via XRPD, wt% | Weddellite Characterization | |||
---|---|---|---|---|---|
a, Å | c, Å | CSD, Å | x, apfu * | ||
Without additives | |||||
1 | 0 | - | - | - | - |
Environmental ions only | |||||
2 | 0 | - | - | - | - |
3 | 3 | no data | no data | no data | no data |
Organic acids only | |||||
4 | 100 | 12.342(1) | 7.352(1) | 104(1) | 0.22 |
5 | 100 | 12.374(1) | 7.359(1) | 107(2) | 0.39 |
6 | 100 | 12.339(1) | 7.359(1) | 157(3) | 0.20 |
7 | 100 | 12.312(2) | 7.343(1) | 72(1) | 0.05 |
8 | 75 | 12.329(1) | 7.352(1) | 75(1) | 0.15 |
9 | 39 | 12.346(1) | 7.352(1) | 218(10) | 0.24 |
10 | 23 | 12.359(1) | 7.357(1) | 204(15) | 0.31 |
11 | 24 | 12.383(2) | 7.362(1) | 168(13) | 0.44 |
12 | 12 | 12.35(1) | 7.357(8) | 55(4) | 0.24 |
Citric acid + environmental ions | |||||
13 | 99 | 12.338(1) | 7.352(1) | 98(1) | 0.20 |
14 | 80 | 12.345(1) | 7.353(1) | 196(5) | 0.23 |
15 | 100 | 12.370(2) | 7.363(1) | 122(2) | 0.37 |
16 | 41 | 12.353(5) | 7.358(3) | 72(2) | 0.28 |
17 | 100 | 12.348(1) | 7.353(1) | 158(2) | 0.25 |
18 | 100 | 12.334(1) | 7.350(1) | 140(2) | 0.17 |
19 | 100 | 12.317(3) | 7.348(2) | 70(1) | 0.08 |
20 | 23 | 12.351(3) | 7.357(2) | 115(6) | 0.27 |
21 | 76 | 12.358(1) | 7.353(1) | 195(4) | 0.30 |
22 | 61 | 12.348(1) | 7.355(1) | 131(3) | 0.25 |
23 | 88 | 12.351(1) | 7.356(1) | 267(7) | 0.27 |
24 | 63 | 12.360(1) | 7.355(1) | 186(6) | 0.31 |
25 | 62 | 12.349(1) | 7.352(1) | 188(5) | 0.26 |
26 | 27 | 12.367(6) | 7.357(3) | 76(6) | 0.35 |
27 | 98 | 12.350(1) | 7.357(1) | 202(4) | 0.26 |
28 | 22 | 12.376(1) | 7.368(1) | 148(6) | 0.40 |
29 | 89 | 12.356(1) | 7.354(1) | 118(2) | 0.29 |
30 | 100 | 12.354(1) | 7.353(1) | 66(1) | 0.28 |
31 | 9 | 12.367(11) | 7.366(6) | 77(8) | 0.35 |
Organic acid combinations and K+, Mg2+, Fe3+, SO42− and PO43− ions | |||||
32 | 17 | 12.354(4) | 7.356(2) | 128(9) | 0.28 |
33 | 15 | 12.362(4) | 7.356(2) | 158(19) | 0.33 |
34 | 20 | 12.339(1) | 7.530(1) | 207(14) | 0.20 |
35 | 21 | 12.341(9) | 7.352(5) | 75(4) | 0.21 |
36 | 9 | 12.376(16) | 7.366(9) | 52(5) | 0.40 |
37 | 16 | 12.348(8) | 7.358(4) | 87(6) | 0.25 |
38 | 23 | 12.352(3) | 7.356(2) | 121(6) | 0.27 |
No. (Table A1 and Table A2) | Ca | Mg | Fe | Sr | K | Na | Σ Cations | P | S | Cl |
---|---|---|---|---|---|---|---|---|---|---|
1 | 32.4 | 0.0 | 0.0 | 0.0 | 0.0 | 0.1 | 0.1 | 0.0 | 0.0 | 0.1 |
2 | 30.9 | 0.0 | 0.0 | 0.0 | 0.0 | 0.1 | 0.1 | 0.0 | 0.2 | 0.1 |
3 | 36.7 | 0.0 | 1.7 | 0.0 | 0.2 | 0.1 | 2.0 | 1.3 | 0.2 | 0.1 |
4 | 37.3 | 0.0 | 0.0 | 0.0 | 0.0 | 0.1 | 0.1 | 0.0 | 0.0 | 0.1 |
13 | 27.5 | 0.0 | 0.0 | 0.0 | 0.4 | 0.1 | 0.5 | 0.0 | 0.0 | 0.1 |
14 | 33.6 | 0.0 | 0.0 | 0.0 | 0.0 | 0.1 | 0.1 | 0.0 | 0.0 | 0.1 |
15 | 22.7 | 0.1 | 0.0 | 0.0 | 0.0 | 0.1 | 0.2 | 0.0 | 0.0 | 0.1 |
16 | 34.9 | 0.0 | 0.2 | 0.0 | 0.0 | 0.1 | 0.3 | 0.0 | 0.0 | 0.1 |
17 | 41.3 | 0.0 | 0.4 | 0.0 | 0.0 | 0.2 | 0.6 | 0.0 | 0.0 | 0.1 |
18 | 29.7 | 0.0 | 0.2 | 0.0 | 0.0 | 0.0 | 0.2 | 0.0 | 0.0 | 0.1 |
19 | 41.0 | 0.0 | 0.3 | 0.0 | 0.0 | 0.2 | 0.5 | 0.0 | 0.0 | 0.1 |
21 | 34.8 | 0.0 | 0.0 | 0.0 | 0.1 | 0.1 | 0.2 | 0.0 | 0.0 | 0.1 |
22 | 40.7 | 0.0 | 0.0 | 0.0 | 0.0 | 0.1 | 0.1 | 0.0 | 0.1 | 0.1 |
23 | 19.5 | 0.0 | 0.0 | 0.0 | 0.0 | 0.2 | 0.2 | 0.0 | 0.0 | 0.1 |
24 | 35.1 | 0.0 | 0.3 | 0.0 | 0.0 | 0.1 | 0.4 | 0.0 | 0.1 | 0.1 |
25 | 33.5 | 0.0 | 0.0 | 0.0 | 0.1 | 0.1 | 0.2 | 0.1 | 0.0 | 0.1 |
27 | 24.9 | 0.1 | 0.0 | 0.0 | 0.0 | 0.2 | 0.3 | 0.0 | 0.0 | 0.1 |
28 | 22.5 | 0.0 | 0.0 | 2.1 | 0.0 | 0.1 | 2.3 | 0.0 | 0.0 | 0.1 |
29 | 34.9 | 0.1 | 0.0 | 0.0 | 0.4 | 0.3 | 0.8 | 3.0 | 1.4 | 0.1 |
30 | 31.2 | 0.2 | 0.3 | 0.0 | 0.4 | 0.4 | 1.3 | 2.8 | 1.5 | 0.1 |
32 | 44.0 | 0.0 | 0.1 | 0.0 | 0.1 | 0.1 | 0.3 | 0.1 | 0.1 | 0.1 |
33 | 48.5 | 0.1 | 0.1 | 0.0 | 0.0 | 0.1 | 0.3 | 0.1 | 0.1 | 0.1 |
34 | 35.9 | 0.1 | 0.1 | 0.0 | 0.0 | 0.1 | 0.3 | 0.1 | 0.1 | 0.1 |
35 | 38.3 | 0.0 | 0.1 | 0.0 | 0.0 | 0.1 | 0.2 | 0.1 | 0.1 | 0.1 |
36 | 33.0 | 0.0 | 0.1 | 0.0 | 0.0 | 0.1 | 0.2 | 0.1 | 0.1 | 0.1 |
37 | 36.8 | 0.0 | 0.1 | 0.0 | 0.0 | 0.1 | 0.2 | 0.1 | 0.1 | 0.1 |
38 | 31.5 | 0.0 | 0.1 | 0.0 | 0.0 | 0.1 | 0.2 | 0.1 | 0.1 | 0.1 |
