Advanced Fiber-Coupled Diode Laser Sensor for Calibration-Free 1f-WMS Determination of an Absorption Line Intensity
Abstract
:1. Introduction
2. Setup
3. Theoretical Background
3.1. 1f-WMS and Logarithmic Processing
3.2. Fitting of the 1f-WMS Spectra
4. Results and Discussions
4.1. Efficiency of the MPRR
4.2. Tolerance to the Nature of Photodetector
4.3. Tolerance to the Turbulences in the Optical Path
4.4. Fitting of the Experimental Spectra
4.5. Linearity
4.6. Effect of Non-Ideal LC
4.7. Wavelength Multiplexing with MPRR and Multifiber Bundle
5. Conclusions
Author Contributions
Funding
Conflicts of Interest
Appendix A
References
