Article

Removal of Extended-Spectrum Beta-Lactamase-Producing Escherichia coli, ST98, in Water for Human Consumption by Black Ceramic Water Filters in Low-Income Ecuadorian Highlands

by
Carlos Bastidas-Caldes
1,2,*,
Juan Ochoa
3,
Laura Guerrero-Latorre
4,
Carlos Moyota-Tello
3,
Wilson Tapia
3,
Joaquín María Rey-Pérez
5 and
Maria Isabel Baroja
3,6,*
1
One Health Research Group, Biotecnología, Facultad de Ingeniería y Ciencias Aplicadas (FICA), Universidad de las Américas (UDLA), Quito 170125, Ecuador
2
Programa de Doctorado en Salud Pública y Animal, Universidad de Extremadura, 10003 Mérida, Spain
3
Ingeniería en Biotecnología, Facultad de Ingeniería y Ciencias Aplicadas (FICA), Universidad de las Américas (UDLA), Quito 170125, Ecuador
4
Catalan Institute for Water Research (ICRA), Water Quality Area, Emili Grahit 101, 17003 Girona, Spain
5
Unidad de Patología Infecciosa, Facultad de Veterinaria, Universidad de Extremadura, 10003 Mérida, Spain
6
Programa de Doctorado en Biología Molecular y Celular, Biomedicina y Biotecnología, Universidad de Extremadura, 10003 Mérida, Spain
*
Authors to whom correspondence should be addressed.
Int. J. Environ. Res. Public Health 2022, 19(8), 4736; https://doi.org/10.3390/ijerph19084736
Submission received: 25 February 2022 / Revised: 25 March 2022 / Accepted: 6 April 2022 / Published: 14 April 2022
(This article belongs to the Topic Impact of Toxic Elements on Water Quality and Treatment Methods)
Browse Figure
Review Reports Versions Notes

Abstract

:
Fecal contamination in natural water sources is a common problem in low-income countries. Several health risks are associated with unprotected water sources, such as gastrointestinal infections caused by parasites, viruses, and bacteria. Moreover, antibiotic-resistant bacteria in water sources have become an increasing problem worldwide. This study aimed to evaluate the bacterial pathogens present in water within a rural context in Ecuador, along with the efficiency of black ceramic water filters (BCWFs) as a sustainable household water treatment. We monitored five natural water sources that were used for human consumption in the highlands of Ecuador and analyzed the total coliforms and E. coli before and after BCWF installation. The results indicated a variable bacterial contamination (29–300 colony-forming units/100mL) in all unfiltered samples, and they were considered as high risk for human consumption, but after filtration, no bacteria were present. Moreover, extended-spectrum beta-lactamase-producing E. coli with blaTEM, blaCTX-M9, and blaCTX-M1 genes, and two E. coli classified in the clonal complex ST10 (ST98) were detected in two of the locations sampled; these strains can severely impact public health. The clonal complex ST10, found in the E. coli isolates, possesses the potential to spread bacteria-resistant genes to humans and animals. The results of the use of BCWFs, however, argue for the filters’ potential impact within those contexts, as the BCWFs completely removed even antibiotic-resistant contaminants from the water.

1. Introduction

Water pollution is a problem greatly impacting human health. Only an estimated 71% of the world’s population has access to safe drinking water [1,2]. Among the pollutants are bacteria, protozoa, viruses, and noxious chemicals. A study carried out in 2019 by the United Nations’ International Emergency Children’s Fund and the World Health Organization to assess water quality found that approximately 844 million people lacked a readily available source of safe drinking water. Of this number of people, 263 million spent more than 30 min per day finding water, and 159 million were using natural water sources for consumption. As a consequence of this lack of safe drinking water in rural areas, along with poor sanitation, the appearance of gastrointestinal diseases, such as infectious diarrhea, cholera, dysentery, hepatitis A, and typhoid, have become a serious human health problem [2].
Indeed, contaminated water has been estimated to cause approximately 502,000 deaths from diarrhea per year [3], while 10% of the deaths of children under five years old are related to diarrhea, with a total of 800,000 deaths per year [4]; these cases are clearly more frequent in developing countries. In Ecuador, diarrhea is the third leading cause of morbidity, along with 30,269 hospital discharges per year [5,6]. This frequency mainly occurs because of the very limited access to safe drinking water in rural areas. In fact, only 57.5% of the inhabitants have access to sanitation systems [7]. In addition, as a consequence of this contamination of water, multidrug-resistant bacteria, now globally widespread, represent a continuous risk of increased morbidity and mortality in the rural areas of developing countries [8].
The highlands of Ecuador, with rural villages and hamlets, is a prime example of this problem. According to the most recent data published by the government, only 52.1% of Ecuador’s inhabitants have access to a potable water system, while 47.9% must obtain this resource from wells, rivers, or rainwater [7]. Contamination from sewage, garbage, livestock, agricultural chemicals, debris, and other inputs, however, makes these alternative water sources unfit for human consumption. In addition, the data from the government specify that 19% of the inhabitants of the country do not have a correct mechanism for fecal elimination, with 7% eliminating waste into the same rivers that populations will later use for their consumption. Consequently, according to data from 2019, contaminated food and water were the cause of ca. 24,000 clinical cases [5,9].
Furthermore, in rural areas of Ecuador, certain antibiotics are used in animals for prophylactic treatment and growth promotion in unknown quantities [10,11]. These uncontrolled practices increase the selection for antibiotic resistance in the resident bacteria. These antibiotics are dumped into the rivers and ponds from which the inhabitants consume water. The antibiotics also reach the intestinal saprophytic microbiota in situ so as to reduce the effectiveness of those same drugs when they are subsequently used to treat gastrointestinal infections against the bacteria thus exposed [12]. This uncontrolled practice in recent years has led to the initiation of several types of research in Germany, Algeria, China, and Brazil, aimed at detecting bacterial-resistance genes, such as mobile colistin-resistant (mcr-1) and ESBL-producing E. coli in water samples [13,14,15,16]. In Ecuador, ESBL-producing E. coli and mcr-1 genes were detected in the feces of yard animals and in urban fauna, as well as in human fecal samples [17,18,19,20]. In the Andean region of Ecuador, however, research on natural water sources has been very limited.
Within this context, a definite and sustainable solution that has been suggested for providing safe drinking water in low-income settings is the use of household water treatment [2]. The advantage of water-purification technology is its ease of use and its accessibility to remote communities. Among the devices that have been studied, compared to the classic models implemented worldwide, black ceramic water filters (BCWFs), new household water treatment devices that have been recently developed to improve microbial removal, were the best option. BCWFs have proved to be a viable alternative for eliminating bacteria and reducing viruses in contaminated water. Such filters, in addition to a complementary treatment, such as chlorination, can be used in homes to reduce enteric viruses and fully eliminate protozoa and bacteria, thus markedly diminishing the incidence of gastrointestinal diseases generated by contaminated water [21,22].
Consequently, BCWFs could be readily used for water purification among populations with limited access to safe drinking water. The present study was thus aimed at evaluating the degree of bacterial contamination in the water; genotyping E. coli; surveying the antibiotic-resistance genes in ESBL-producing strains from the water sources; and, finally, verifying the feasibility of BCWFs as effective household water-treatment devices for low-income populations in the highlands of Ecuador.

2. Materials and Methods

2.1. Study Area and Water Sampling

The highlands of Ecuador are Andean environments that range from 2300 to over 4500 m above sea level. Livestock activities and rural settlements are common in this area. The study region was located in rural neighborhoods around Nono village (0003.9263 S, 07834.6171 W) in the Pichincha province, a mountainous area located 30 km from Quito, the capital of Ecuador, with 2.5 million inhabitants (Figure 1). Firstly, we performed a survey of 40 families in the villages to identify the sampling sites through consideration of the water sources that were used for drinking by the local inhabitants. The procedure, in brief, was as follows: From each location selected after survey, samples were collected from the water sources (ponds and rivers) of the Nono district. Next, 5 L were taken in water sampling polypropylene bottles and transported to laboratories at the University of the Americas for subsequent analysis. In addition, samples from each drinking water source were collected in order to assess the effectiveness of BCWF in filtering fecal bacteria. The BCWFs used were an in-house developed technology for household water treatment, published in a previous study and applied in Ecuadorian low-income communities [23] (technical specifications in Supplementary Materials 1).

2.2. Physicochemical and Microbiologic Analysis of BCWF Efficacy

The samples from the five locations were first analyzed to evaluate the contamination present in the water sources for those communities. The characterization of physicochemical and microbiologic parameters of water quality was carried out through the use of standard methodologies [24] before and after BCWF filtration; 1 l from each natural water source was filtered through a BCWF for efficiency analysis. A Student t-test was performed in order to determine significant differences between before and after filtrating for physicochemical analysis. Microbial analysis consisted of quantification of the total coliforms and E. coli present. To that end, 100 mL of the water samples, before and after BCWF filtration, were filtered through nitrocellulose membranes of 0.45 µm pore size (Millipore, Amsterdam, The Netherlands) and incubated in a chromogenic agar (Chromocult Agar, Merck, Darmstadt, Germany) at 37 °C for 18 h. Typical colonies of E. coli and coliforms were counted and quantified [25] For the confirmation of E. coli, the colonies from the chromogenic agar were transferred to EMB agar and incubated at 37 °C for 24 h. Typical metallic-green colonies were selected for the indole and TSI biochemical tests. Bacterial cryopreservation was performed in brain heart infusion broth, with 10% (v/v) glycerol, and was frozen at −20 °C and −80 °C for further analysis.

2.3. Molecular Genetic Determination of Resistance Genes in E. coli

In order to detect the presence of resistance genes, the genomic DNA of E. coli was extracted with the PureLink® Genomic DNA Kit (Invitrogen, Waltham, MA, USA), according to the manufacturer’s instructions. The resulting DNA samples were quantified in NanoDrop equipment (Thermo ScientificTM, Waltham, MA, USA, ND-2000) and stored at –80 °C. For genetic identification of mcr genes, a polymerase chain reaction (PCR) was performed for mcr-1 with the forward, 5’-GCTACTGATCACCACGCTGT-3’, and reverse, 5’-AGCTGAACATACACGGCACA-3’, primers, yielding a product size of 698 bp. ESBL genotyping was performed through the use of a Qiagen Multiplex PCR-plus kit (Qiagen, Germantown, MD, USA) in a method that can simultaneously detect blaTEM, blaSHV, blaCTX-M1, blaCTX-M2, blaCTX-M9, and blaCTX-M8/25, as previously described [26].
Gene amplification was carried out in an Eppendorf thermocycler, Mastercycler® PRO (Eppendorf, Hamburg, Germany). The conditions and cycles for thermocycling for the mcr-1 gene were as follows: initial activation (1 cycle at 95 °C, 15 min), denaturation (94 °C, 30 s), annealing (62 °C, 90 s), and extension (72 °C, 90 s) for 30 cycles, followed by a final extension (1 cycle at 72 °C, 10 min). In addition, the conditions for ESBL screening were as follows: initial activation (1 cycle at 95 °C, 3 min), denaturation (95 °C, 30 s), annealing (60 °C, 90 s), and extension (72 °C, 90 s) for 30 cycles, followed by a final extension (1 cycle at 68° C, 10 min). The PCR products were analyzed on a 2% (w/w) agarose gel with SYBR Safe and 1X Tris-borate-EDTA buffer. Electrophoresis was programmed at 100 V for 30 min in a Labnet Enduro Gel XL horizontal chamber (Labnet International, Inc., Edison, NJ, USA). The agarose gel was visualized on a ChemiDocTM Imaging Systems photo-documentation system (BioRad, Hercules, CA, USA) by means of Image LabTM software version 5.2.1 (BioRad, Hercules, CA, USA). The size of each band observed in the gel was determined through comparison with a 100 bp DNA ladder. The positive control DNA for both mcr-1 and ESBLs multiplex was kindly donated by the Osaka Institute of Public Health, Japan.

2.4. Multilocus Sequence Typing (MLST)

MLST was performed to determine the genetic diversity of E. coli isolates according to the MLST Pasteur database (http://pubmlst.org, accessed on 20 June 2021). The PCR conditions of seven housekeeping genes (adk, fumC, gyrB, icd, mdh, purA, and recA) were amplified and sequenced as described by Wirth et al. (2006). The PCR products were sequenced using the Sanger sequencing technique in an ABI 3500xL Genetic Analyzer (Applied Biosystems, Waltham, MA, USA) with a BigDye 3.1® capillary electrophoresis matrix. The procedure, stated in brief, was as follows: the allelic profiling and sequence-type (ST) determination were also confirmed at the above PubMLST website. In addition, to further analyze the relationship between the different sequencing types, a phylogenetic analysis of the housekeeping genes was performed.

3. Results

3.1. Sampling Sites

Five natural water sources, three ponds and two rivers, were identified as being used for human consumption in the vicinity of the inhabited areas of Nono (Figure 1, Table 1). In the map of the Nono district (Pichincha province, Ecuador) in Figure 1, the numbers (1–5) indicate the location where the samples of water were taken, and the Universal Transverse Mercator coordinates of each sampling site are listed in the accompanying table.

3.2. Physicochemical Analysis of BCFW Efficacy

The physicochemical parameters indicated a difference in the percentage of the various components assayed before and after BCWF filtration of the water. All parameters tested showed significant levels of reduction after BCWF treatment, with the exception of nitrate, BOD, and alkalinity (Table 1).

3.3. Microbiological and Molecular Genetic Determination

Microbiological analyses before filtrating revealed the presence of E. coli, along with total and fecal coliforms at all the locations analyzed. Table 1 summarizes the counts of E. coli colonies in the water from each location before and after BCWF filtration. These findings point to significant bacterial contamination in the natural water sources that Nono’s population routinely uses for consumption. As for bacterial concentration, the locations with the highest bacterial presence of E. coli were the ones at the lowest altitudes, with >300 colony-forming units (CFU/100 mL) at sampling sites three and five, at 2439 and 2435 m above sea level, respectively (Supplementary Materials 2). Furthermore, molecular genetic analyses revealed the presence of these three types of ESBL genes: blaTEM and blaCTX-M-1 at site three, and blaTEM and blaCTX-M-9 at site five (Supplementary Materials 3.1). Both E. coli isolates were determined to be of ST 98 in the bacterial lineage referred to as clonal complex (CC) ST10 (Table 2). No isolate was positive for the mcr-1 gene (Supplementary Materials 3.2).

4. Discussion

To the best of our knowledge, the study reported here is the first to report the existence of ESBL genes in the water consumed in rural areas of the highlands in Ecuador. Indeed, we detected three different ESBL genes: blaTEM, blaCTX-M9, and blaCTX-M1. Several studies have indicated that the finding of ESBL genes in E. coli isolated from water samples is common. In a study on water sources in Germany, Hetty Blaak (2014) identified blaCTX-M1 and blaCTX-M15 genes [28]. In addition, in the Białka river in Poland, blaCTX-M, blaTEM, and blaOXA genes were detected in a river near sewage treatment plants [29]. A study of the water in Lebanese estuaries identified a high prevalence of blaCTX-M15 genes in the E. coli present [30]. In Ecuador, a study carried out by Ortega (2020) determined that the CTX-M-1 group, and specifically the blaCTX-M15 gene, was the most prevalent in the Machángara River in Quito; this finding agrees with the prevalence of ESBL genes in Ecuador, with that locus being the most common ESBL-encoding gene found in humans worldwide [31].
It is noteworthy that the previous studies were performed in the lowlands, where the bacterial load is normally greater because of a drain on the associated bodies of water through greater human activity and a higher population density. However, the finding of ESBL genes in highland isolates with relatively few inhabitants is indeed striking, although it is not rare. One possible explanation is that the source of that water contamination is both animal and human [28,32]. In environmental samples, the genes of the CTX-M-1 group are the most prevalent. Furthermore, the feces of wild animals, such as birds, have been thought to contribute to ESBL-producing E. coli in surface water [33,34,35]. Schierack et al. (2020), in a study on wild birds in Germany and Mongolia, reported that blaCTX-M-1 and blaCTX-M-9 genes were detected in the two respective countries, along with a direct correlation with the prevalence of human infections in those countries [36]. In contrast, the genes of the TEM group are known to be more common in human environments; this association implies either a direct or indirect human contamination of the water sources in our study—and this is very likely because of the absence of an adequate program for water contamination management to protect and conserve that resource [29,35].
No positive isolates for the colistin-resistance gene, mcr-1, were found in the E. coli bacteria present in the water samples of this study, even though the inhabitants had been found to use this antibiotic as a fattening supplement in the cattle feed. Moreover, cattle graze in close proximity to the water sources that the population use for their consumption. Nevertheless, resistant pathogens may possibly be diluted in those natural water sources. Similar studies, however, have demonstrated the presence of mcr genes in water samples elsewhere. A study by Yang et al. (2017) detected mcr-1 in E. coli and Klebsiella pneumoniae in a river in China [37]. Likewise, other investigations carried out by Hembach et al. (2017) found the resistance locus, mcr-1, in seven wastewater treatment plants in Germany [14]. The mcr-1 gene can be present in aquatic environments because aquatic ecosystems, in general, are considered reservoirs of antibiotic-resistant bacteria. In Ecuador, a study conducted by Loayza-Villa et al. (2020) detected this gene in the feces of dogs and a chicken [17,20].
The finding that the MLST analysis of E. coli isolates indicated CC10 to be the predominant clonal complex in the water samples was of significance, as it agrees with other studies carried out in which ST10 CC was likewise predominant in extraintestinal environments, such as river water [31], wastewater [28], and food [38], as opposed to other clonal groups more commonly found in clinical samples, such as ST131 [39,40]. Furthermore, E. coli ST10 is widely found in intestinal samples from animals and humans as both a commensal and a pathogen. Although ST10 CC is commonly found to be susceptible to antimicrobials, the ability of this group to spread rapidly and survive in the environment is of concern [41]. ST10 CC is linked to multidrug resistance and ESBL and is recognized as an emerging lineage of foodborne extraintestinal pathogenic E. coli (ExPEC) [42].
In addition, within the overall diversity in the E. coli population, two lineages (ST10 and ST155) might function as reservoirs of the mcr-1 gene; the larger of these sources was linked to ST10 [43]. Although mcr-1 genes were not found in the present study, we consider the role of ST10 CC, as one of the main E. coli clonal complexes associated with animal enterotoxigenicity, to be highly relevant. In fact, Shepard et al. (2012) found that the majority of the porcine enterotoxigenic E. coli isolates belonged to three clonal complexes, 10, 23, and 165, and pointed out the relationship exhibited by ST10 CC to ESBL-resistance-associated elements [44].
This current ESBL presence could be involved in the increasing mortality rate, since patients with gastrointestinal infection do not present favorable responses to treatment with these antibiotics, which results in the clinical syndrome evolving into sepsis [45,46]. For the present study area, these findings point to a serious public health problem because the main cause of death for Nono’s inhabitants is related to gastrointestinal diseases, which are usually treated mainly with antibiotics; the frequency of this therapy can cause antibiotic resistance to increase progressively [5,23].
The use of BCWF in isolated populations that are without access to adequate sanitary systems is a suitable alternative recourse for water purification, and also represents an effective, environmentally friendly, and inexpensive device capable of preventing the health complications associated with multidrug-resistant bacterial infections. The hazard to human health was verified, since the initial physicochemical and biologic parameters of the water bodies tested were far outside the permissible limits [24]. Contamination with sewage water, garbage, and debris, as well as the leaching of chemicals involved in livestock production, have led to a marked deterioration of water quality and, therefore, the consumption of that water constitutes a serious health hazard [47,48]. BCWFs were effective in reducing the major contamination parameters in raw water, such as nitrites, biochemical oxygen demand, and chloride, by >70% (Table 1). Similar results have been obtained in several studies, where ceramic filters proved to be highly useful alternative tools for removing pollutants from water sources [23,48]. In the present work, the removal of bacteria by BCWF was 100% effective, as no bacterial colonies developed after filtration, including those carrying resistance genes. Finally, although the use of BCWF proved to be effective in the removal of bacterial pathogens, disinfection processes after filtering, such as chlorination, are recommended to ensure the quality of the water and the health of the people who consume it.

5. Limitations

The present study had several limitations. First, the survey was performed on a restricted number of natural water sources, though the sampling sites selected were representative sources of natural water that the inhabitants routinely used for their consumption. The geographical situation and the accessibility to the water bodies were limitations for the sampling of larger areas. Another limitation was that the origin of the fecal contamination was unknown, and to clarify that source would require more data from upstream and from higher ground. Due to the evidence of the use of colistin as a growth promoter in animals, the possibility of finding mcr-1 genes in future studies remains pending. Moreover, a determination of whether the fecal contamination was of human, porcine, avian, or a wild origin—or a mixture of any of those possible sources—would also be necessary. To do so, molecular flocculation techniques would be required, along with isolation and identification of species-specific enteric viruses. Despite these limitations, we believe that the data presented in this study will assist in more completely understanding the status of the water for human consumption in the highlands of the Ecuadorian Andes and serve to make decisions for the implementation of the specific and affordable sanitary measures that we recommend for low-income populations.

6. Conclusions

The water sources for human consumption in the highlands of Ecuador exhibited major microbial pollution, including contamination with ESBL-producing E. coli that carried the blaTEM, blaCTX-M9, and blaCTX-M1 genes, and were detected in two of the five water sources. These findings represent a significant hazard to the health of the inhabitants of these highlands. Although the use of the antibiotic colistin as a growth promoter in animals was common in the study area, the samples screened did not manifest any presence of mcr-1 genes. Nevertheless, two of the E. coli isolates belonged to the ST10 (ST98) clonal complex, which indicates the presence of these bacteria as a continuous potential risk in spreading multidrug-resistant enteric bacteria within these low-income populations. As a solution, the BWCFs made in Ecuador would be effective in the complete removal of these potentially dangerous bacteria, present in natural water sources, and undesirable chemical species. We therefore strongly recommend the distribution of BCWFs in all areas with limited access to drinking water in order to reduce the incidence of diseases associated with the use of contaminated water. It is necessary to deepen studies into the contamination of natural water sources that are used for human consumption by using molecular and phylogenetic techniques that would allow us to determine the origin of the contamination. This is important since natural water sources are the only ones that many inhabitants of low-income rural communities have access to.

Supplementary Materials

The following supporting information can be downloaded at: https://www.mdpi.com/article/10.3390/ijerph19084736/s1, Supplementary Materials 1: BCWF specification; Supplementary Materials 2: Bacterial growth on Chromocult Agar (Merck, USA) on filtration membranes with 5-point natural water samples; Supplementary Materials 3.1: Agarose gel 2% for ESBL multiplex PCR; Supplementary Materials 3.2: Agarose gel 2% of the PCR resistance to mcr-1. References [49,50,51,52,53,54,55,56,57,58,59,60,61,62,63,64,65,66,67,68,69,70,71,72,73,74,75,76,77,78,79,80] are cited in the supplementary materials.

Author Contributions

Conceptualization, C.B.-C.; and M.I.B.; methodology, J.O.; and C.M.-T.; validation, C.B.-C., J.O.; and M.I.B.; formal analysis, L.G.-L.; investigation, C.B.-C. and M.I.B.; writing—original draft preparation, C.B.-C.; and M.I.B.; writing—review and editing C.B.-C.; J.M.R.-P. and L.G.-L.; supervision, M.I.B.; and L.G.-L.; project administration, M.I.B. and W.T.; funding acquisition, W.T. and M.I.B. All authors have read and agreed to the published version of the manuscript.

Funding

This research was funded by Universidad de las Americas in “Proyecto de Vinculación”, and Junta de Extremadura. Consejería de Economía e Infraestructuras: Grant number IB18047. The APC was funded by Universidad de las Americas.

Institutional Review Board Statement

Not applicable.

Informed Consent Statement

Not applicable.

Data Availability Statement

Any data, photographs, coordinates, sequences, or analysis will be made available to readers upon reasonable request.

Acknowledgments

We thank the leaders of the town of Nono for their collaboration and openness to carrying out this study and are grateful to the inhabitants of the sampling areas for their cooperation. Donald F. Haggerty, a retired academic career investigator and native English speaker, edited the final version of the manuscript.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. United Nations Children’s Fund. The State of the World’s Children 2021: On My Mind: Promoting, Protecting and Caring for Children’s Mental Health; UNICEF: New York, NY, USA, 2021. [Google Scholar]
  2. World Health Organization. Water, Sanitation, Hygiene and Health. A Primer for Health Professionals; Department of Environment, Climate Change and Health: Geneva, Switzerland, 2019; pp. 1–31. [Google Scholar]
  3. UNICEF/WHO. Diarrhoea: Why Children Are Still Dying and What Can Be Done; World Health Organization, UNICEF: Geneva, Switzerland, 2009; ISBN 978-92-4-159841-5. [Google Scholar]
  4. Kotloff, K.L.; Nataro, J.P.; Blackwelder, W.C.; Nasrin, D.; Farag, T.H.; Panchalingam, S.; Wu, Y.; Sow, S.O.; Sur, D.; Breiman, R.F.; et al. Burden and aetiology of diarrhoeal disease in infants and young children in developing countries (the Global Enteric Multicenter Study, GEMS): A prospective, case-control study. Lancet 2013, 382, 209–222. [Google Scholar] [CrossRef]
  5. Vasco, G.; Trueba, G.; Atherton, R.; Calvopiña, M.; Cevallos, W.; Andrade, T.; Eguiguren, M.; Eisenberg, J.N.S. Identifying Etiological Agents Causing Diarrhea in Low Income Ecuadorian Communities. Am. J. Trop. Med. Hyg. 2014, 91, 563–569. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  6. Lugmaña, G. Anuario de Estadísticas Hospitalarias: Egresos y Camas. Inst. Nac. Estadística Y Censos. 2014, 1, 522. [Google Scholar]
  7. Pozo, M.; Serrano, J.C.; Castillo, R.; Moreno, L. Diagnóstico de Los Indicadores ODS de Agua, Saneamiento e Higiene En Ecuador. Estud. Temáticos INEC 2016, 1, 1–27. [Google Scholar]
  8. Collignon, P.; Beggs, J.J.; Walsh, T.R.; Gandra, S.; Laxminarayan, R. Anthropological and socioeconomic factors contributing to global antimicrobial resistance: A univariate and multivariable analysis. Lancet Planet. Health 2018, 2, e398–e405. [Google Scholar] [CrossRef]
  9. Lee, G.O.; Whitney, H.J.; Blum, A.G.; Lybik, N.; Cevallos, W.; Trueba, G.; Levy, K.; Eisenberg, J.N. Household coping strategies associated with unreliable water supplies and diarrhea in Ecuador, an upper-middle-income country. Water Res. 2021, 1, 1–22. [Google Scholar] [CrossRef] [PubMed]
  10. Andrade, F.F.; Silva, D.; Rodrigues, A.; Pina-Vaz, C. Colistin Update on Its Mechanism of Action and Resistance, Present and Future Challenges. Microorganisms 2020, 8, 1716. [Google Scholar] [CrossRef] [PubMed]
  11. Wang, Y.; Xu, C.; Zhang, R.; Chen, Y.; Shen, Y.; Hu, F.; Liu, D.; Lu, J.; Guo, Y.; Xia, X.; et al. Changes in colistin resistance and mcr-1 abundance in Escherichia coli of animal and human origins following the ban of colistin-positive additives in China: An epidemiological comparative study. Lancet Infect. Dis. 2020, 20, 1161–1171. [Google Scholar] [CrossRef]
  12. Mora, F.X.; Avilés-Reyes, R.X.; Guerrero-Latorre, L.; Fernández-Moreira, E. Atypical enteropathogenic Escherichia coli (aEPEC) in children under five years old with diarrhea in Quito (Ecuador). Int. Microbiol. 2017, 19, 157–160. [Google Scholar] [CrossRef]
  13. Drali, R.; Berrazeg, M.; Zidouni, L.L.; Hamitouche, F.; Abbas, A.A.; Deriet, A.; Mouffok, F. Emergence of mcr-1 plasmid-mediated colistin-resistant Escherichia coli isolates from seawater. Sci. Total Environ. 2018, 642, 90–94. [Google Scholar] [CrossRef]
  14. Hembach, N.; Schmid, F.; Alexander, J.; Hiller, C.; Rogall, E.T.; Schwartz, T. Occurrence of the mcr-1 Colistin Resistance Gene and other Clinically Relevant Antibiotic Resistance Genes in Microbial Populations at Different Municipal Wastewater Treatment Plants in Germany. Front. Microbiol. 2017, 8, 1282. [Google Scholar] [CrossRef] [PubMed]
  15. Li, R.; Xie, M.; Zhang, J.; Yang, Z.; Liu, L.; Liu, X.; Zheng, Z.; Chan, E.W.-C.; Chen, S. Genetic characterization of mcr-1 -bearing plasmids to depict molecular mechanisms underlying dissemination of the colistin resistance determinant. J. Antimicrob. Chemother. 2016, 72, 393–401. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  16. Fernandes, M.R.; Cerdeira, L.; Silva, M.M.; Sellera, F.; Muñoz, M.; Junior, F.G.; Azevedo, S.S.; Power, P.; Gutkind, G.; Lincopan, N. Novel mcr-5.3 variant in a CTX-M-8-producing Escherichia coli ST711 isolated from an infected horse. J. Antimicrob. Chemother. 2018, 73, 3520–3522. [Google Scholar] [CrossRef] [PubMed]
  17. Loayza-Villa, F.; Salinas, L.; Tijet, N.; Villavicencio, F.; Tamayo, R.; Salas, S.; Rivera, R.; Villacis, J.; Satan, C.; Ushiña, L.; et al. Diverse Escherichia coli lineages from domestic animals carrying colistin resistance gene mcr-1 in an Ecuadorian household. J. Glob. Antimicrob. Resist. 2019, 22, 63–67. [Google Scholar] [CrossRef]
  18. Zurita, J.; Yánez, F.; Sevillano, G.; Ortega-Paredes, D.; Miño, A.P.Y. Ready-to-eat street food: A potential source for dissemination of multidrug-resistant Escherichia coli epidemic clones in Quito, Ecuador. Lett. Appl. Microbiol. 2019, 70, 203–209. [Google Scholar] [CrossRef]
  19. Yamaguchi, T.; Kawahara, R.; Harada, K.; Teruya, S.; Nakayama, T.; Motooka, D.; Nakamura, S.; Nguyen, P.D.; Kumeda, Y.; Van Dang, C.; et al. The presence of colistin resistance gene mcr-1 and -3 in ESBL producing Escherichia coli isolated from food in Ho Chi Minh City, Vietnam. FEMS Microbiol. Lett. 2018, 365, fny100. [Google Scholar] [CrossRef]
  20. Yamamoto, Y.; Calvopina, M.; Izurieta, R.; Villacres, I.; Kawahara, R.; Sasaki, M.; Yamamoto, M. Colistin-resistant Escherichia coli with mcr genes in the livestock of rural small-scale farms in Ecuador. BMC Res. Notes 2019, 12, 121. [Google Scholar] [CrossRef]
  21. Mwabi, J.; Adeyemo, F.; Mahlangu, T.; Mamba, B.; Brouckaert, B.; Swartz, C.; Offringa, G.; Mpenyana-Monyatsi, L.; Momba, M. Household water treatment systems: A solution to the production of safe drinking water by the low-income communities of Southern Africa. Phys. Chem. Earth Parts A/B/C 2011, 36, 1120–1128. [Google Scholar] [CrossRef]
  22. Guerrero-Latorre, L.; Rusiñol, M.; Hundesa, A.; Garcia-Valles, M.; Martinez, S.; Joseph, O.; Bofill-Mas, S.; Girones, R. Development of improved low-cost ceramic water filters for viral removal in the Haitian context. J. Water Sanit. Hyg. Dev. 2015, 5, 28–38. [Google Scholar] [CrossRef] [Green Version]
  23. Guerrero-Latorre, L.; Balseca-Enriquez, P.; Moyota-Tello, C.; Bravo-Camino, R.; Davila-Chavez, S.; Bonifaz-Arcos, E.; Romero-Carpio, B.; Chico-Terán, M. Performance of black ceramic water filters and their implementation in rural Ecuador. J. Water Sanit. Hyg. Dev. 2019, 9, 694–702. [Google Scholar] [CrossRef]
  24. Ministerio de Ambiente del Ecuador. Revisión y Actiualización de La Norma de Calidad Ambiental y de Deacraga de Efluentes: Recurso Agua. Regist. Of. No. 387 2015, No. 97, 1–40. Available online: https://www.ambiente.gob.ec/wp-content/uploads/downloads/2018/05/Acuerdo-097.pdf (accessed on 5 April 2022).
  25. ISO International Standard 9308-1:2014; Water Quality. Enumeration of Escherichia Coli and Coliform Bacteria—Part 1: Membrane Filtration Method for Waters with Low Bacterial Background Flora; ISO/TC 147/SC 4 Microbiological Methods. International Organization for Standardization (ISO): Geneva, Switzerland, 2014; p. 10.
  26. Nakayama, T.; Ueda, S.; Huong, B.T.M.; Tuyen, L.D.; Komalamisra, C.; Kusolsuk, T.; Hirai, I.; Yamamoto, Y. Wide dissemination of extended-spectrum β-lactamase-producing Escherichia coli in community residents in the Indochinese peninsula. Infect. Drug Resist. 2015, 8, 1–5. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  27. Herschy, R.W. Water Quality for Drinking: WHO Guidelines. Encycl. Earth Sci. Ser. 2012, 8, 876–883. [Google Scholar] [CrossRef]
  28. Blaak, H.; de Kruijf, P.; Hamidjaja, R.A.; van Hoek, A.H.A.M.; de Roda Husman, A.M.; Schets, F.M. Prevalence and characteristics of ESBL-producing E. coli in Dutch recreational waters influenced by wastewater treatment plants. Vet. Microbiol. 2014, 171, 448–459. [Google Scholar] [CrossRef] [PubMed]
  29. Lenart-Boroń, A.M.; Kulik, K.; Jelonkiewicz, E. Antimicrobial resistance and ESBL genes in E. coli isolated in proximity to a sewage treatment plant. J. Environ. Sci. Health Part A Toxic/Hazard. Subst. Environ. Eng. 2020, 55, 1571–1580. [Google Scholar] [CrossRef] [PubMed]
  30. Diab, M.; Hamze, M.; Bonnet, R.; Saras, E.; Madec, J.-Y.; Haenni, M. Extended-spectrum beta-lactamase (ESBL)- and carbapenemase-producing Enterobacteriaceae in water sources in Lebanon. Vet.-Microbiol. 2018, 217, 97–103. [Google Scholar] [CrossRef] [PubMed]
  31. Ortega-Paredes, D.; Barba, P.; Mena-López, S.; Espinel, N.; Crespo-Pérez, V.; Zurita, J. High quantities of multidrug-resistant Escherichia coli are present in the Machángara urban river in Quito, Ecuador. J. Water Health 2020, 18, 67–76. [Google Scholar] [CrossRef]
  32. Hernández, J.; Stedt, J.; Bonnedahl, J.; Molin, Y.; Drobni, M.; Calisto-Ulloa, N.; Gomez-Fuentes, C.; España, M.S.A.; González-Acuña, D.; Waldenström, J.; et al. Human-Associated Extended-Spectrum β-Lactamase in the Antarctic. Appl. Environ. Microbiol. 2012, 78, 2056–2058. [Google Scholar] [CrossRef] [Green Version]
  33. Vingino, A.; Roberts, M.C.; Wainstein, M.; West, J.; Norman, S.A.; Lambourn, D.; Lahti, J.; Ruiz, R.; D’Angeli, M.; Weissman, S.J.; et al. Surveillance for Antibiotic-Resistant E. coli in the Salish Sea Ecosystem. Antibiotics 2021, 10, 1201. [Google Scholar] [CrossRef]
  34. Silverman, A.I.; Boehm, A.B. Systematic Review and Meta-Analysis of the Persistence and Disinfection of Human Coronaviruses and Their Viral Surrogates in Water and Wastewater. Environ. Sci. Technol. Lett. 2020, 7, 544–553. [Google Scholar] [CrossRef]
  35. Doi, Y.; Iovleva, A.; Bonomo, R.A. The ecology of extended-spectrum β-lactamases (ESBLs) in the developed world. J. Travel Med. 2017, 24, S44–S51. [Google Scholar] [CrossRef]
  36. Schierack, P.; Heiden, S.; Khan, M.M.; Nikolaus, L.; Kolenda, R.; Stubbe, M.; Lkhagvasuren, D.; Rödiger, S.; Guenther, S.; Schaufler, K. Genomic and Phenotypic Analysis of an ESBL-Producing E. coli ST1159 Clonal Lineage From Wild Birds in Mongolia. Front. Microbiol. 2020, 11, 1699. [Google Scholar] [CrossRef] [PubMed]
  37. Yang, D.; Qiu, Z.; Shen, Z.; Zhao, H.; Jin, M.; Li, H.; Liu, W.; Li, J.-W. The Occurrence of the Colistin Resistance Gene mcr-1 in the Haihe River (China). Int. J. Environ. Res. Public Health 2017, 14, 576. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  38. Freitag, C.; Michael, G.; Li, J.; Kadlec, K.; Wang, Y.; Hassel, M.; Schwarz, S. Occurrence and characterisation of ESBL-encoding plasmids among Escherichia coli isolates from fresh vegetables. Vet.-Microbiol. 2018, 219, 63–69. [Google Scholar] [CrossRef] [PubMed]
  39. Jørgensen, S.B.; Søraas, A.V.; Arnesen, L.S.; Leegaard, T.M.; Sundsfjord, A.; Jenum, P.A. A comparison of extended spectrum β-lactamase producing Escherichia coli from clinical, recreational water and wastewater samples associated in time and location. PLoS ONE 2017, 12, e186576. [Google Scholar] [CrossRef] [Green Version]
  40. Ortega-Paredes, D.; De Janon, S.; Villavicencio, F.; Ruales, K.J.; De La Torre, K.; Villacís, J.E.; Wagenaar, J.A.; Matheu, J.; Bravo-Vallejo, C.; Fernández-Moreira, E.; et al. Broiler Farms and Carcasses Are an Important Reservoir of Multi-Drug Resistant Escherichia coli in Ecuador. Front. Vet.-Sci. 2020, 7, 979. [Google Scholar] [CrossRef]
  41. Kamal, S.M.; Cimdins-Ahne, A.; Lee, C.; Li, F.; Martín-Rodríguez, A.J.; Seferbekova, Z.; Afasizhev, R.; Wami, H.T.; Katikaridis, P.; Meins, L.; et al. A recently isolated human commensal Escherichia coli ST10 clone member mediates enhanced thermotolerance and tetrathionate respiration on a P1 phage-derived IncY plasmid. Mol. Microbiol. 2021, 115, 255–271. [Google Scholar] [CrossRef]
  42. Meniño, I.G.; García, V.; Mora, A.; Jiménez, D.D.; Simon, S.C.F.; Alonso, M.P.; Blanco, J.E.; Blanco, M.; Blanco, J. Swine Enteric Colibacillosis in Spain: Pathogenic Potential of mcr-1 ST10 and ST131 E. coli. Isolates. Front. Microbiol. 2018, 9, 2659. [Google Scholar] [CrossRef]
  43. Matamoros, S.; van Hattem, J.M.; Arcilla, M.S.; Willemse, N.; Melles, D.C.; Penders, J.; Vinh, T.N.; Hoa, N.T.; Bootsma, M.C.J.; van Genderen, P.J.; et al. Global phylogenetic analysis of Escherichia coli and plasmids carrying the mcr-1 gene indicates bacterial diversity but plasmid restriction. Sci. Rep. 2017, 7, 15364. [Google Scholar] [CrossRef] [Green Version]
  44. Shepard, S.M.; Danzeisen, J.L.; Isaacson, R.E.; Seemann, T.; Achtman, M.; Johnson, T.J. Genome Sequences and Phylogenetic Analysis of K88- and F18-Positive Porcine Enterotoxigenic Escherichia coli. J. Bacteriol. 2012, 194, 395–405. [Google Scholar] [CrossRef] [Green Version]
  45. Kawamura, K.; Nagano, N.; Suzuki, M.; Wachino, J.-I.; Kimura, K.; Arakawa, Y. ESBL-producing Escherichia coli and Its Rapid Rise among Healthy People. Food Saf. 2017, 5, 122–150. [Google Scholar] [CrossRef] [Green Version]
  46. Chong, Y.; Shimoda, S.; Shimono, N. Current epidemiology, genetic evolution and clinical impact of extended-spectrum β-lactamase-producing Escherichia coli and Klebsiella pneumoniae. Infect. Genet. Evol. 2018, 61, 185–188. [Google Scholar] [CrossRef] [PubMed]
  47. Lloyd, B.J.; Bartram, J. Surveillance Solutions to Microbiological Problems in Water Quality Control in Developing Countries. Water Sci. Technol. 1991, 24, 61–75. [Google Scholar] [CrossRef]
  48. Bottoni, P.; Caroli, S.; Caracciolo, A. Pharmaceuticals as priority water contaminants. Toxicol. Environ. Chem. 2010, 92, 549–565. [Google Scholar] [CrossRef]
  49. Abebe, L.S.; Chen, X.; Sobsey, M.D. Chitosan Coagulation to Improve Microbial and Turbidity Removal by Ceramic Water Filtration for Household Drinking Water Treatment. Int. J. Environ. Res. Public Health 2016, 13, 269. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  50. Hihara, L. Environmental Degradation of Advanced and Traditional Engineering Materials; CRC: Boca Raton, FL, USA, 2014. [Google Scholar]
  51. Bloem, S.C.; van Halem, D.; Sampson, M.L.; Huoy, L.S.; Heijman, B. Silver Impregnated Ceramic Pot Filter: Flow Rate Versus the Removal Efficiency of Pathogens; International Ceramic Pot Filter Workshop: Atlanta, GA, USA, 2009. [Google Scholar]
  52. Brown, J.M.; Sobsey, M.D. Effectiveness of Ceramic Filtration for Drinking Watertreatment in Cambodia. Ph.D. Thesis, The University of North Carolina at Chapel Hill, Chapel Hill, NC, USA, 2007; p. 275. [Google Scholar] [CrossRef]
  53. Brown, J.; Sobsey, M.D.; Loomis, D. Local drinking water filters reduce diarrheal disease in Cambodia: A randomized, controlled trial of the ceramic water purifier. Am. J. Trop. Med. Hygiene 2008, 79, 394–400. [Google Scholar] [CrossRef]
  54. Ceramic, B.; Based, P.; Slag, O.N.O. Black Ceramic Pigments Based on Open-Hearth Slag. Glass Ceram. 2012, 69, 99–103. [Google Scholar] [CrossRef]
  55. Cheng, K. Evaluating Access to Drinking Water in Northern Ghana 2013 Group Report; Massachusetts Institute of Technology Civil and Environmental Engineering Department: Cambridge, MA, USA, 2013. [Google Scholar]
  56. Clasen, T.F.; Alexander, K.T.; Sinclair, D.; Boisson, S.; Peletz, R.; Chang, H.H.; Cairncross, S. Interventions to improve water quality for preventing diarrhoea. Cochrane Database Syst. Rev. 2015, 10, 1–201. [Google Scholar] [CrossRef] [Green Version]
  57. Cui, X.; Antonietti, M.; Yu, S.H. Structural Effects of Iron Oxide Nanoparticles and Iron Ions on the Hydrothermal Carbonization of Starch and Rice Carbohydrates. Small 2006, 2, 756–759. [Google Scholar] [CrossRef]
  58. Denis, M.; Jeanneau, L.; Pierson-Wickman, A.C.; Humbert, G.; Petitjean, P.; Jaffrézic, A.; Gruau, G. A comparative study on the pore-size and filter type effect on the molecular composition of soil and stream dissolved organic matter. Organic Geochem. 2017, 110, 36–44. [Google Scholar] [CrossRef] [Green Version]
  59. Ehdaie, B.; Rento, C.T.; Son, V.; Turner, S.S.; Samie, A.; Dillingham, R.A.; Smith, J.A. Evaluation of a Silver-Embedded Ceramic Tablet as a Primary and Secondary Point-of-Use Water Purification Technology in Limpopo Province, S. Africa. PLoS ONE 2017, 12, e0169502. [Google Scholar] [CrossRef]
  60. Fahlin, C.J. Hydraulic Properties Investigation of the Potters for Peace Colloidal Silver Impregnated, Ceramic Filter; University of Colorado at Boulder College of Engineering: Boulder, CO, USA, 2003. [Google Scholar]
  61. Hutten, I.M.; Hutten, I.M. Chapter 4–Raw Materials for Nonwoven Filter Media. Handbook of Nonwoven Filter Media; Butterworth-Heinemann: Oxford, UK, 2016. [Google Scholar] [CrossRef]
  62. Johnson, A.C.; Jürgens, M.D.; Lawlor, A.J.; Cisowska, I.; Williams, R.J. Particulate and 25 colloidal silver in sewage effluent and sludge discharged from British wastewater treatment plants. Chemosphere 2014, 112, 49–55. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  63. Lanata, C.F.; Fischer-Walker, C.L.; Olascoaga, A.C.; Torres, C.X.; Aryee, M.J.; Black, R.E. Global Causes of Diarrheal Disease Mortality in Children <5 Years of Age: A Systematic Review. PLoS ONE 2013, 8, e72788. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  64. Lantagne, D.; Klarman, M.; Mayer, A.; Preston, K.; Napotnik, J.; Jellison, K. Effect of production variables on microbiological removal in locally-produced ceramic filters for household water treatment. Int. J. Environ. Health Res. 2010, 20, 171–187. [Google Scholar] [CrossRef] [PubMed]
  65. Lantagne, D.S.; Environmental, A. Investigation of the Potters for Peace Colloidal Silver Impregnated Ceramic Filter Report 2: Field Investigations. Methods 2001, 1–121. [Google Scholar]
  66. Lin, J.C.T.; Hsiao, T.C.; Hsiau, S.S.; Chen, D.R.; Chen, Y.K.; Huang, S.H.; Chang, M.B. Effects of temperature, dust concentration, and filtration superficial velocity on the loading behavior and dust cakes of ceramic candle filters during hot gas filtration. Sep. Purif. Technol. 2018, 198, 146–154. [Google Scholar] [CrossRef]
  67. Mahlangu, O.; Mamba, B.; Momba, M. Efficiency of Silver Impregnated Porous Pot (SIPP) Filters for Production of Clean Potable Water. Int. J. Environ. Res. Public Health 2012, 9, 3014–3029. [Google Scholar] [CrossRef] [Green Version]
  68. Mayoral, J.M.; Castañon, E.; Alcantara, L.; Tepalcapa, S. Seismic response characterization of high plasticity clays. Soil Dyn. Earthq. Eng. 2016, 84, 174–189. [Google Scholar] [CrossRef]
  69. Murphy, H.M.; McBean, E.A.; Farahbakhsh, K. A critical evaluation of two point-of-use water treatment technologies: Can they provide water that meets WHO drinking water guidelines? J. Water Health 2010, 8, 611–630. [Google Scholar] [CrossRef] [Green Version]
  70. Oyanedel-Craver, V.A.; Smith, J.A. Sustainable colloidal-silver-impregnated ceramic filter for point-of-use water treatment. Environ. Sci. Technol. 2008, 42, 927–933. [Google Scholar] [CrossRef]
  71. Potters for Peace. Best Practice Recommendations for Local Manufacturing of Ceramic Pot Filters for Household Water Treatment. Ceram. Manuf. Group 2011, 1, 187. [Google Scholar]
  72. Roberts, M. Field test of a silver-impregnated ceramic water filter. In Proceedings of the 30th WEDC International Conference, Vientiane, Laos, 25–29 October 2003; pp. 1–6. [Google Scholar]
  73. Savage, D.; Liu, J. Water/clay ratio, clay porosity models and impacts upon clay transformations. Appl. Clay Sci. 2015, 116–117, 16–22. [Google Scholar] [CrossRef]
  74. Tufiño, G.; Vieira, N.; Lascano, L. Propiedades Térmicas de Arcillas Ecuatorianas para ser Utilizadas como Material Refractario. 2015, Volume 6, p. 14. Available online: https://nanopdf.com/download/propiedades-termicas-de-arcillas-ecuatorianas-para_pdf (accessed on 5 April 2022).
  75. Van der Laan, H.; van Halem, D.; Smeets, P.W.M.H.; Soppe, A.I.A.; Kroesbergen, J.; Wubbels, G.; Heijman, S.G.J. Bacteria and virus removal effectiveness of ceramic pot filters with different silver applications in a long term experiment. Water Res. 2014, 51, 47–54. [Google Scholar] [CrossRef] [PubMed]
  76. Van Halem, D.; Heijman, S.G.J.; Soppe, A.I.A.; Van Dijk, J.C.; Amy, G.L. Ceramic silver-impregnated pot filters for household drinking water treatment in developing countries: Material characterization and performance study. Water Sci. Technol. Water Supply 2007, 7, 9–17. [Google Scholar] [CrossRef]
  77. van Halem, D.; van der Laan, H.; Soppe, A.I.A.; Heijman, S.G.J. High flow ceramic pot 26 filters. Water Res. 2017, 124, 398–406. [Google Scholar] [CrossRef]
  78. Voigt, C.; Jäckel, E.; Taina, F.; Zienert, T.; Salomon, A.; Wolf, G.; Le Brun, P. Filtration Efficiency of Functionalized Ceramic Foam Filters for Aluminum Melt Filtration. Metall. Mater. Trans. B 2017, 48, 497–505. [Google Scholar] [CrossRef]
  79. Wang, S.; Javadpour, F.; Feng, Q. Confinement Correction to Mercury Intrusion Capillary Pressure of Shale Nanopores. Sci. Rep. 2016, 6, 20160. [Google Scholar] [CrossRef] [Green Version]
  80. WHO; UNICEF. Progress on sanitation and drinking-water—2014 update. Monitor. Programme Water Supply Sanitat. 2014, 1–78. [Google Scholar]
Ijerph 19 04736 g001 550
Figure 1. Map of Nono district, Pichincha province, Ecuador. The overall figure illustrates the geographical orientation of Ecuador within Central America. In the expanded map of the inset, the numbers (1–5) indicate the locations where the samples of water were taken, with the Universal Transverse Mercator coordinates of each point listed in the table below.
Figure 1. Map of Nono district, Pichincha province, Ecuador. The overall figure illustrates the geographical orientation of Ecuador within Central America. In the expanded map of the inset, the numbers (1–5) indicate the locations where the samples of water were taken, with the Universal Transverse Mercator coordinates of each point listed in the table below.
Ijerph 19 04736 g001
Table
Table 1. BCWF bacteria-removal assay with natural water testing, physicochemical removal in filtered water on the basis of drinking water guidelines [27].
Table 1. BCWF bacteria-removal assay with natural water testing, physicochemical removal in filtered water on the basis of drinking water guidelines [27].
ParameterBefore BCWF After BCWF (n = 5)SD (After BCWF)Reduction Level (%) After BCWF p Value
Turbidity (NTU)3.381.721.8349.11 *0.02138
Nitrite (mg/L)0.130.020.0285.18 *0.02708
Nitrate (mg/L)1.771.540.6013.39 NS0.07752
BOD17.802.801.3084.27 NS0.1226
COD34.4110.651.8869.06 **0.00475
Ammonia (mg/L)0.110.040.0263.70 **0.002501
Phosphate (mg/L)1.841.130.0538.49 ***0.00018
Chloride (mg/L)58.4617.538.5470.01 ***0.00007
Sulfate (mg/L)14.749.845.9133.26 **0.00678
Oil (mg/L)0.010.010.0058.90 *0.03597
Alkalinity (mg/L)131.19109.2936.9316.69 NS0.05738
Significance level: * 0.05; ** 0.01; *** 0.001; NS no significance. Bold p-values indicate significant differences obtained by the Student t-test of parameter-reduction indices upon the use of BCWF for water purification. BOD, biochemical oxygen demand; COD, chemical oxygen demand; SD, standard deviation; NTU, nephelometric turbidity unit.
Table
Table 2. Comparison of the microbiological characteristics of the water before and after the filtration with black ceramic water filters.
Table 2. Comparison of the microbiological characteristics of the water before and after the filtration with black ceramic water filters.
Sampling PointsNatural SourceDistance to the Town Center (Km)Altitude (Masl) *CFU/mL
before Filtering		ESBL-Producing E. coliClonal Complex (Strain)CFU/mL after Filtering
1Pond4.07259429-ND **0
2River4.2258331-ND0
3Pond4.982429>300blaTEM, blaCTX-M-1ST10 (98)0
4Pond4.72262374-ND0
5River4.182435>300blaTEM, blaCTX-M-9ST10 (98)0
* Meters above sea level; ** ND, not determined ST.
Publisher’s Note: MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Share and Cite

MDPI and ACS Style

Bastidas-Caldes, C.; Ochoa, J.; Guerrero-Latorre, L.; Moyota-Tello, C.; Tapia, W.; Rey-Pérez, J.M.; Baroja, M.I. Removal of Extended-Spectrum Beta-Lactamase-Producing Escherichia coli, ST98, in Water for Human Consumption by Black Ceramic Water Filters in Low-Income Ecuadorian Highlands. Int. J. Environ. Res. Public Health 2022, 19, 4736. https://doi.org/10.3390/ijerph19084736

AMA Style

Bastidas-Caldes C, Ochoa J, Guerrero-Latorre L, Moyota-Tello C, Tapia W, Rey-Pérez JM, Baroja MI. Removal of Extended-Spectrum Beta-Lactamase-Producing Escherichia coli, ST98, in Water for Human Consumption by Black Ceramic Water Filters in Low-Income Ecuadorian Highlands. International Journal of Environmental Research and Public Health. 2022; 19(8):4736. https://doi.org/10.3390/ijerph19084736

Chicago/Turabian Style

Bastidas-Caldes, Carlos, Juan Ochoa, Laura Guerrero-Latorre, Carlos Moyota-Tello, Wilson Tapia, Joaquín María Rey-Pérez, and Maria Isabel Baroja. 2022. "Removal of Extended-Spectrum Beta-Lactamase-Producing Escherichia coli, ST98, in Water for Human Consumption by Black Ceramic Water Filters in Low-Income Ecuadorian Highlands" International Journal of Environmental Research and Public Health 19, no. 8: 4736. https://doi.org/10.3390/ijerph19084736

APA Style

Bastidas-Caldes, C., Ochoa, J., Guerrero-Latorre, L., Moyota-Tello, C., Tapia, W., Rey-Pérez, J. M., & Baroja, M. I. (2022). Removal of Extended-Spectrum Beta-Lactamase-Producing Escherichia coli, ST98, in Water for Human Consumption by Black Ceramic Water Filters in Low-Income Ecuadorian Highlands. International Journal of Environmental Research and Public Health, 19(8), 4736. https://doi.org/10.3390/ijerph19084736

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
