Clinical Considerations for Implanted Neurological Devices in Patients Undergoing Hyperbaric Oxygen Therapy: A Case Report and Review of Manufacturer Guidelines
Abstract
:1. Introduction
2. Detailed Case Description
3. Discussion
“It is possible to damage the pump due to deformation of the bottom shield of the pump if it is exposed to pressures greater than 2.0 ATA for a single treatment, or at pressures less than or equal to 2 ATA with multiple treatments if the reservoir is not kept close to full; a full reservoir helps to support the bottom shield of the pump. [While the functioning of the pump is not affected by HBOT] a collapsed bottom shield may significantly reduce the pump’s drug capacity and would require pump replacement surgery. [Therefore, the suggested management of the pump would be to] keep the reservoir volume within 2 mL of the recommended [maximum] capacity of the [20 mL Medtronic SynchroMed] pump, and it should be refilled during the hyperbaric treatment period to keep it at or above these volumes”.
4. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
- Kuder, M.; Gelman, A.; Zenilman, J.M. Prevalence of Implanted Medical Devices in Medicine Inpatients. J. Patient Saf. 2018, 14, 153–156. [Google Scholar] [CrossRef] [PubMed]
- Hunter, C.W.; Lee, E.T.; Masone, R.; Deer, T.R. Disease Indications. In Atlas of Implantable Therapies for Pain Management; Springer: New York, NY, USA, 2016; pp. 11–14. [Google Scholar]
- Sdrulla, A.D.; Guan, Y.; Raja, S.N. Spinal Cord Stimulation: Clinical Efficacy and Potential Mechanisms. Pain Pract. 2018, 18, 1048–1067. [Google Scholar] [CrossRef] [PubMed]
- Lozano, A.M.; Lipsman, N.; Bergman, H.; Brown, P.; Chabardes, S.; Chang, J.W.; Matthews, K.; McIntyre, C.C.; Schlaepfer, T.E.; Schulder, M.; et al. Deep brain stimulation: Current challenges and future directions. Nat. Rev. Neurol. 2019, 15, 148–160. [Google Scholar] [CrossRef] [PubMed]
- Deer, T.R.; Pope, J.E. Selection and Indications for Intrathecal Pump Placement. In Atlas of Implantable Therapies for Pain Management; Springer: New York, NY, USA, 2016; pp. 249–251. [Google Scholar]
- Gotman, I. Characteristics of metals used in implants. J. Endourol. 1997, 11, 383–389. [Google Scholar] [CrossRef] [PubMed]
- Sefton, M.V. Implantable pumps. Crit. Rev. Biomed. Eng. 1987, 14, 201–240. [Google Scholar] [PubMed]
- Bates, D.; Schultheis, B.C.; Hanes, M.C.; Jolly, S.M.; Chakravarthy, K.V.; Deer, T.R.; Levy, R.M.; Hunter, C.W. A Comprehensive Algorithm for Management of Neuropathic Pain. Pain Med. 2019, 20 (Suppl. S1), S2–S12. [Google Scholar] [CrossRef] [PubMed]
- Sutherland, A.M.; Clarke, H.A.; Katz, J.; Katznelson, R. Hyperbaric Oxygen Therapy: A New Treatment for Chronic Pain? Pain Pract. 2016, 16, 620–628. [Google Scholar] [CrossRef] [PubMed]
- Schiavo, S.; DeBacker, J.; Djaiani, C.; Bhatia, A.; Englesakis, M.; Katznelson, R. Mechanistic Rationale and Clinical Efficacy of Hyperbaric Oxygen Therapy in Chronic Neuropathic Pain: An Evidence-Based Narrative Review. Pain Res. Manag. 2021, 2021, 8817504. [Google Scholar] [CrossRef] [PubMed]
- Thom, S.R. Analytic Reviews: Hyperbaric Oxygen Therapy. J. Intensive Care Med. 2016, 4, 58–74. [Google Scholar] [CrossRef]
- Thom, S.R. Hyperbaric oxygen: Its mechanisms and efficacy. Plast. Reconstr. Surg. 2011, 127 (Suppl. S1), 131S–141S. [Google Scholar] [CrossRef] [PubMed]
- Moon, R. Hyperbaric Oxygen Therapy Indications, 14th ed.; Best Publishing Company: North Palm Beach, FL, USA, 2019. [Google Scholar]
- Jain, K.K. Indications, Contraindications, and Complications of HBO Therapy. In Textbook of Hyperbaric Medicine; Jain, K.K., Ed.; Springer International Publishing AG: Cham, Switzerland, 2017; pp. 79–84. [Google Scholar]
- Bartek, J., Jr.; Skyrman, S.; Nekludov, M.; Mathiesen, T.; Lind, F.; Schechtmann, G. Hyperbaric Oxygen Therapy as Adjuvant Treatment for Hardware-Related Infections in Neuromodulation. Stereotact. Funct. Neurosurg. 2018, 96, 100–107. [Google Scholar] [CrossRef] [PubMed]
- Kot, J. Medical devices and procedures in the hyperbaric chamber. Diving Hyperb. Med. 2014, 44, 223–227. [Google Scholar] [PubMed]
- Goel, V.; Patwardhan, A.M.; Ibrahim, M.; Shankar, H.; Schultz, D.M. Indented intrathecal drug delivery system with loss of reservoir volume. Reg. Anesth. Pain Med. 2019. ahead of print. [Google Scholar] [CrossRef] [PubMed]
- Akman, M.N.; Loubser, P.G.; Fife, C.E.; Donovan, W.H. Hyperbaric oxygen therapy: Implications for spinal cord injury patients with intrathecal baclofen infusion pumps. Case report. Paraplegia 1994, 32, 281–284. [Google Scholar] [CrossRef] [PubMed]
- Kot, J. Operation of Implantable Cardiac Devices in Hyperbaric Conditions. In Cardiac Rhythm Management; Min, M., Cismaru, G., Eds.; IntechOpen: Rijeka, Croatia, 2022; Ch.3. [Google Scholar]
- Dydyk, A.M.; Tadi, P. Spinal Cord Stimulator Implant. In StatPearls; StatPearls Publishing LLC.: Treasure Island, FL, USA, 2022. [Google Scholar]
- Deer, T.R.; Lamer, T.J.; Pope, J.E.; Falowski, S.M.; Provenzano, D.A.; Slavin, K.; Golovac, S.; Arle, J.; Rosenow, J.M.; Williams, K.; et al. The Neurostimulation Appropriateness Consensus Committee (NACC) Safety Guidelines for the Reduction of Severe Neurological Injury. Neuromodulation 2017, 20, 15–30. [Google Scholar] [CrossRef] [PubMed]
- Kratz, J.M.; Blackburn, J.G.; Leman, R.B.; Crawford, F.A. Cardiac pacing under hyperbaric conditions. Ann. Thorac. Surg. 1983, 36, 66–68. [Google Scholar] [CrossRef] [PubMed]
- Lafay, V.; Trigano, J.A.; Gardette, B.; Micoli, C.; Carre, F. Effects of hyperbaric exposures on cardiac pacemakers. Br. J. Sports Med. 2008, 42, 212–216; discussion 216. [Google Scholar] [CrossRef] [PubMed]
- Kot, J. Medical Equipment for Multiplace Hyperbaric Chambers Part I: Devices for Monitoring and Cardiac Support. Eur. J. Underw. Hyperb. Med. 2005, 6, 115–120. [Google Scholar]
- Medtronic Spinal Cord Stimulators: Overview. Available online: https://global.medtronic.com/xg-en/e/response/spinal-cord-stimulators.html (accessed on 22 February 2023).
- Schmitz, S.C.S.; Weaver, L.K. Hyperbaric oxygen in patients with implanted cardiac defibrillators and pacemakers. In Proceedings of the 39th Annual Undersea and Hyperbaric Medical Society Scientific Meeting, Orlando, FL, USA, 16—18 June 2006; Volume 33, p. 349. [Google Scholar]
- Hacene, B.; Draulans, N.; Theys, T. Problems with an intrathecal pump in a paraplegic scuba diver. Diving Hyperb. Med. 2018, 48, 110–111. [Google Scholar] [CrossRef] [PubMed]
- Draulans, N.; Roels, E.; Kiekens, C.; Nuttin, B.; Peers, K. Permanent mechanical deformation of an intrathecal baclofen pump secondary to scuba diving: A case report. Spinal Cord. 2013, 51, 868–869. [Google Scholar] [CrossRef] [PubMed]
- Sales Representative; (Abbott, Chicago, IL, USA). Personal communication, 2021.
- Sales Representative; (Medtronic, Minneapolis, MN, USA). Personal communication, 2021.
- Sales Representative; (Boston Scientific, Marlborough, MA, USA). Personal communication, 2021.
- Boston Scientific. Products: Spinal Cord Stimulators. Available online: https://www.bostonscientific.com/en-US/products/spinal-cord-stimulator-systems.html (accessed on 24 February 2023).
- Neuromodulation, B.S. Available online: https://www.uhms.org/images/MEDFAQs/Boston_Scientific_neuromodulation.pdf (accessed on 22 February 2023).
- Sales Representative; (Stimwave, Pompano Beach, FL, USA). Personal communication, 2021.
- Instruction for Use: Freedom (Stimwave, Pompano Beach, FL, USA). Available online: https://stimwavefreedom.com/freedom-therapy/freedom-scs (accessed on 22 February 2023).
- Clinical Engineer; (Flowonix, Budd Lake, NJ, USA). Personal communication, 2023.
- Instruction for Use: Prometra II (Flowonix, Budd Lake, NJ, USA). Available online: https://flowonix.com/healthcare-provider/us-instructions-for-use; https://flowonix.com/sites/default/files/pl-21611-06_-_prometra_ii_programmable_pump_ifu.pdf (accessed on 22 February 2023).
- Technical Support Specialist; (Nevro, Redwood City, CA, USA). Personal communication, 2023.
- Physician Product Manual: Senza, Senza II, Omnia (Nevro). Available online: https://nevro.com/English/us/providers/product-manuals/default.aspx (accessed on 22 February 2023).
- Instruction for Use/Product Manual: Evoke (Saluda Medical). Available online: https://content.saludamedical.com (accessed on 22 February 2023).
- User Instruction for Use: Nalu (Nalu). Available online: https://nalumed.com/wp-content/uploads/2019/06/MA-000007-Rev-C.pdf (accessed on 22 February 2023).
Indications for Hyperbaric Oxygen Therapy |
---|
Air or gas embolisms |
Carbon monoxide poisoning |
Clostridial Myositis and Myonecrosis |
Crush injury, Compartment Syndrome and other acute traumatic ischemia |
Decompression sickness |
Arterial insufficiencies (Central Retinal Artery Occlusion, Enhancement of healing in selected problem wounds) |
Severe Anemia |
Intracranial abscess |
Necrotizing soft tissue infections |
Refractory osteomyelitis |
Delayed radiation injury (Soft Tissue and Bony Necrosis) |
Acute Thermal Burn Injury |
Idiopathic Sudden Sensorineural Hearing Loss |
Side Effects of Hyperbaric Oxygen Therapy |
Middle ear barotrauma, Sinus squeeze, Claustrophobia, Progressive myopia, Pulmonary barotrauma, Seizures |
| |||
Manufacturer | Device (Models) | HBOT Feasibility and Maximum ATA Exposure | Notes |
Abbott (ex St. Jude Medical) | SCS: All models (Proclaim, Prodigy, Eon, EonC, EonMini, Protégé, Genesis, GenesisXP, GenesisRC) | 4.0 ATA [29] | Turn devices OFF during HBOT |
DBS: All models (Infinity, Libra, LibraXP, Brio) | |||
SCS-DRG: All models (Proclaim DRG, Axium DRG) | 1.5 ATA [29] | ||
Medtronic | Stimulators: All models including SCS (Intellis, PrimeAdvance), SNS (InterStim), PNS, DBS (Activa, Restore), | 2.0 ATA [30] | These devices can be left ON during HBOT |
IDD pump (SynchroMed II) | IDD pump must be refilled during HBOT in case of multiple sessions | ||
Boston Scientific | All models | No recommendations | No tests performed in humans, device functioning not guaranteed [31,32,33] |
Stimwave technologies | SCS (Freedom) | 1.5 ATA [34] | Instructions for use recommends 1.5 ATA, but also 13 m (45 feet) for diving, which would correspond to 2.3 ATA; no clarifications received by manufacturer [35] |
Flowonix | IDD pump (Prometra II) | 2.0 ATA [36] | Instructions for use states “an increase in environmental pressure of approximately 1 ATA or greater may cause the pump to temporarily stop delivering drug; when normal atmospheric pressure is returned, the pump will resume its programmed delivery rate” [37] |
Nevro | SCS: All models (Senza, Senza II, Senza Omnia) | 4.5 ATA [38] | Turn devices OFF during HBOT [39] |
Saluda Medical | SCS (Evoke) | 1.5 ATA [40] | No response from vendor |
Nalu | SCS/PNS (Nalu) | 1.48 ATA [41] | Instructions for use recommends 1.48 ATA, but also 13 m (45 feet) for diving, which would correspond to 2.3 ATA; no clarifications received by manufacturer Do not dive/hyperbaric the external Therapy Disc |
