Battery State of Health Estimation with Improved Generalization Using Parallel Layer Extreme Learning Machine
Abstract
:1. Introduction
2. Methodology
2.1. Deterministic Extreme Learning Machine
2.2. Deterministic Parallel Layer Extreme Learning Machine
2.3. Experimental Dataset Description
2.4. State of Health (SOH)
2.5. Characterization and Feature Selection
2.6. Summary of Scheme Setup Procedure
Model Input: [V, SOC, E] |
Model Output:SOH |
|
3. Results and Discussion
3.1. PL-ELM Model Training
3.2. PL-ELM Model Validation
3.3. Model Comparison with Deterministic ELM and Demonstration of the Drift Problem
4. Summary and Conclusions
