Article

Performance Evaluation of Air-Based Heat Rejection Systems

by
Hannes Fugmann
1,*,
Björn Nienborg
1,†,
Gregor Trommler
2,†,
Antoine Dalibard
3,† and
Lena Schnabel
1
1
Fraunhofer ISE, Fraunhofer Institute for Solar Energy Systems, Heidenhofstr. 2, 79110 Freiburg, Germany
2
ILK Dresden, Institute of Air Handling and Refrigeration, Bertolt-Brecht-Allee 20, 01309 Dresden, Germany
3
Centre of Applied Research Sustainable Energy Technology – zafh.net, Stuttgart University of Applied Sciences, Schellingstr. 24, 70174 Stuttgart, Germany
*
Author to whom correspondence should be addressed.
†
These authors contributed equally to this work.
Energies 2015, 8(2), 714-741; https://doi.org/10.3390/en8020714
Submission received: 2 December 2014 / Accepted: 6 January 2015 / Published: 23 January 2015
Browse Figures
Versions Notes

Abstract

On the basis of the Number of Transfer Units (NTU) method a functional relation between electric power for fans/pumps and effectiveness in dry coolers and wet cooling towers is developed. Based on this relation, a graphical presentation method of monitoring and simulation data of heat rejection units is introduced. The functional relation allows evaluating the thermodynamic performance of differently sized heat rejection units and comparing performance among them. The method is used to evaluate monitoring data of dry coolers of different solar cooling field projects. The novelty of this approach is that performance rating is not limited by a design point or standardized operating conditions of the heat exchanger, but is realizable under flexible conditions.
Keywords: performance evaluation; cooling tower; dry cooler; solar cooling; heat exchanger performance evaluation; cooling tower; dry cooler; solar cooling; heat exchanger
