Disassembly Study of Ultrasonically Welded Thermoplastic Composite Joints via Resistance Heating
Abstract
:1. Introduction
2. Materials and Experimental Methods
2.1. Materials
2.2. Nanocomposite Films and Thermoplastic Composites Fabrication
2.3. Thermo-Electrical Characterization
2.4. Ultrasonic Welding Procedure
2.5. Disassembly of Welded Joints
2.6. Scanning Electron Microscopy (SEM)
3. Prediction of Heat-Affected Zone for Disassembly Experiments
4. Experimental Results and Discussion
4.1. Nanocomposite Films Characterization
4.1.1. Electrical Conductivity
4.1.2. Resistance Heating
4.2. Disassembly Study of Ultrasonically Welded Joints
4.2.1. Tensile Test Results
4.2.2. Fractographic and Heat-Affected Zone Analysis
4.3. Discussion on Disassembly Method and Its Limitations
5. Conclusions
Author Contributions
Funding
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
