An Obstacle Avoidance Trajectory Planning Methodology Based on Energy Minimization (OTPEM) for the Tilt-Wing eVTOL in the Takeoff Phase
by
Guangyu Zheng
Guangyu Zheng 1
,
Peng Li
Peng Li 1,2,*
and
Dongsu Wu
Dongsu Wu 3
1
College of Automobile and Traffic Engineering, Nanjing Forestry University, Nanjing 210037, China
2
College of Design and Engineering, National University of Singapore, Singapore 117575, Singapore
3
College of Civil Aviation, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
*
Author to whom correspondence should be addressed.
World Electr. Veh. J. 2024, 15(7), 300; https://doi.org/10.3390/wevj15070300 (registering DOI)
Submission received: 17 April 2024
/
Revised: 16 June 2024
/
Accepted: 3 July 2024
/
Published: 6 July 2024
Abstract
Electric tilt-wing flying cars are an efficient, economical, and environmentally friendly solution to urban traffic congestion and travel efficiency issues. This article addresses the high energy consumption and obstacle interference during the takeoff phase of the tilt-wing eVTOL (electric Vertical Takeoff and Landing), proposing a trajectory planning method based on energy minimization and obstacle avoidance. Firstly, based on the dynamics analysis, the relationship between energy consumption, spatial trajectory, and obstacles is sorted out and the decision variables for the trajectory planning problem with obstacle avoidance are determined. Secondly, based on the power discretization during the takeoff phase, the energy minimization objective function is established and the constraints of performance limitations and spatial obstacles are derived. Thirdly, by integrating the optimization model with the SLSQP (Sequential Least Squares Quadratic Programming algorithm), the second-order sequential quadratic programming model and decision variable update equations are derived, establishing the solution process for the trajectory planning problem of the tilt-wing eVTOL takeoff with obstacle avoidance. Finally, the Airbus Vahana A3 is taken as an example to verify and validate the effectiveness, stability, and robustness of the model and optimization algorithm proposed. The validation results show that the OTPEM (obstacle avoidance trajectory planning methodology based on energy minimization) can effectively handle changes in the takeoff end state and exhibits good stability and robustness in different obstacle environments. It can provide a certain reference for the three-dimensional obstacle avoidance trajectory planning of Airbus Vahana A3 and other tilt-wing eVTOL trajectory planning problems.
