Assessment of the Potential Use of Young Barley Shoots and Leaves for the Production of Green Juices

Abstract

It is possible to use the aboveground parts of barley, which are cultivated as a forecrop. They are often simply composted or dried for bedding. It is worth trying other more effective methods of processing aboveground biomass. The aim of this study was to preliminary investigate the possibility of using young barley leaves and shoots for the production of green juice with potential health properties. The material was collected at days 7, 14, 21, and 28 after plant emergence. The length and strength of the shoots were measured and the pressing yield was calculated. The pH value and the content of protein, chlorides, and reducing sugars were also determined. The juice was additionally subjected to pasteurisation and freezing, and changes in pH and chlorophyll content occurring during storage were determined. The pressing yield of young barley leaves and shoots was estimated to be between 69% and 73%. The product was characterised by a high content of total protein (34.45%–51.81%_d.w.) and chlorophylls (6.62 mg·g⁻¹). The chlorophyll content declined during barley juice storage. Pasteurisation of the juice from young barley leaves does not induce statistically significant changes in the pH of the juice, but reduces the chlorophyll content. Our results revealed that the most effective way to preserve the green juice is by freezing. This process does not induce changes in juice acidity and only slightly reduces the chlorophyll content during storage of the product.

1. Introduction

In order to improve the soil quality and protect it from weeds and, consequently, obtain a better crop of the cultivated plant, producers often use forecrop cultivation. Depending on what kind of plant will be grown, an appropriate forecrop will be selected. For cereals, the best options are root crops (mainly potatoes), legumes, or rapeseed. However, when growing vegetables, such as tomatoes, carrots, or white cabbage, it is better to use a cereal forecrop, and rye, wheat, or barley can be used [1]. These cereals can be used via two techniques. The first method involves ploughing whole plants and using them as a fertilizer. Plants that are a forecrop can also be cut. Then, only roots and postharvest residues are ploughed. In the case of the latter method, it is possible to continue using the green parts of the plants, which are often simply composted or dried for bedding.

Recently, products from young barley leaves and shoots have gained popularity. They are available in a variety of forms, i.e., juice, tablets, or powder. Young parts of plants are a source of phenolic acids and many vitamins, e.g., C, E, and B group vitamins. Additionally, barley grass contains substantial amounts of carotenoids, folic acid, calcium, iron, magnesium, potassium, zinc, and copper. Importantly, products obtained from cereal leaves and shoots can be used as supplements in a high-protein diet. Barley grass contains approximately 30% of protein in dry matter [2,3,4]. The chemical index of nutritional value (Chemical Score, CS) is 41.44% (Methionine) [5]. Barley shoots and leaves are also a source of chlorides. Naturally occurring chlorides exert a beneficial effect on organism function. Chloride ions participate in the regulation of water, as well as electrolyte metabolism and maintaining acid–base balance [6].

One of the most important active compounds in “green food” is chlorophyll. Seed plants contain type A and B chlorophylls, which differ according to the type of substituent on the second pyrrole ring. However, these pigments are unstable. Many factors, e.g., UV radiation or pH and temperature changes, cause chlorophyll degradation in food products. Chlorophylls are a valuable source of magnesium; they can also improve metabolism and eliminate unpleasant mouth odours. Additionally, they have antibacterial and anti-inflammatory properties, remove toxins from the liver and blood [7,8,9,10,11], and even act as a haemoglobin substitute [12].

The consumption of green juices has therapeutic properties: it exerts an antidiabetic effect, regulates blood pressure, strengthens immunity, protects the liver, and has anti-acne and antidepressant activities. It also improves the function of the digestive tract and prevents hypoxia, cardiovascular diseases, fatigue, and constipation. Additionally, it alleviates atopic dermatitis and has anti-inflammatory, antioxidant, and anticancer effects [4]. Kubatka et al. [13] have demonstrated positive changes in tumour cells in rats treated with juice from young barley leaves. A significantly more pronounced effect of the therapeutic treatment was observed in a study group receiving a diet supplemented with the juice. It has also been confirmed that supplementation of the diet with barley leaf powder can relieve the clinical symptoms of diabetes [14]. Additionally, barley grass contains substantial amounts of dietary fibre (mainly an insoluble fraction), which has a positive effect on metabolism through regulating the appetite and, thus preventing the development of overweight. Son et al. [3] recommend enrichment of the diets of young children using valuable nutrients from young barley leaves.

Products from young barley leaves have been used in East Asia for a long time. Currently, they are available in supermarkets, as well as online, in the United States and many European countries. The increase in consumer awareness has contributed to an appreciation of the health benefits of “green food” [8]. A number of products based on young cereal leaves are recommended as dietary supplements and, hence, are currently being manufactured to be purchased in pharmacies.

There is a paucity of scientific publications confirming the health-promoting properties of the juice from young barley leaves. There are also no preliminary investigations describing the impact of production and processing on the quality of green juices. Furthermore, the relationship between the date of raw material harvesting and the pressing process, as well as the content of nutrients—including proteins—in the juice, has not yet been analysed. Another unexplored area is the changes occurring in the chlorophyll content of barley juice, depending on the thermal treatment. Knowledge of these relationships has great practical significance as it provides information on methods for the acquisition of a product with a high nutritional value and, at the same time, ensures the longest possible growth period for the plant (and, thus, the greatest mass of roots to be used as forecrop).

The aim of this work was to preliminary examine the efficiency of the process of pressing green juice from young barley leaves and shoots and to determine the chemical composition of the product obtained. An additional goal of the research was to compare the effect of preservation methods like pasteurization and freezing on the chlorophyll content and pH of barley juice.

2. Materials and Methods

2.1. Research Material

Barley grain cv. Kangoo was used for the investigations. The seeds, weighing 5 kg, were sown under laboratory conditions (Figure 1). No fertilisation was applied during the cultivation. The material was collected at days 7, 14, 21, and 28 after plant emergence. The crop area was divided into four parts, and these four parts were then divided again into 12 smaller ones. Three parts from the whole field were chosen at random for each series of investigation (different harvest time: 7, 14, 21, and 28 days). Each sample of shoots and leaves of young barley for juice production weighed 200 g.

2.2. Measurement of Physical Properties

Samples without mechanical damage were selected for determination of the length and strength of the barley. The length of five barley shoots was measured with the use of a calliper to the nearest 0.01 mm. The shoot strength was determined by applying a uniaxial tensile test to the leaves. The test was carried out using a Zwick/Roell Z0.5 materials testing machine (Zwick.Roell AG, BT1-FR0.5TN.D14, Ulm, Germany) equipped with a measuring head at a maximum force of 50 N (travel speed = 50 mm·min⁻¹). Tensile strength was applied to the material until rupture. TestXpert II software (Zwick/Roell AG, Ulm, Germany) was used to assess the force required for destruction of the barley grass.

2.3. Pressing

The juice was squeezed from barley grass (with a weight of 200 g for each repetition) using a press designed for pressing green plant leaves, i.e., Manual Juicer BL-30 (BioChef, Byron Bay, NS, Australia).

The pressing efficiency was calculated using the following equation:

$$W_j(\%)=\frac{M_j}{M_i}·100$$

(1)

where:

W_j—pressing yield, %;

M_j—mass of juice after pressing, kg;

M_i—mass of input material, kg.

2.4. Preserving Juice

The juice obtained in the first harvest term (at seven days after plant emergence) was additionally subjected to pasteurisation for 10 min at 75 °C and freezing. Immediately after the thermal treatment, the product was cooled (in a blast chiller–freezer) to 3 °C. The other batch of juice was blast-frozen to a temperature of −18 °C. The material was stored under appropriate conditions, i.e., 4 °C in the case of the unprocessed (UJ) and pasteurised (PJ) juice and −18 °C in the case of the frozen juice (FJ). The study material was analysed after three (UJ and PJ) and seven (UJ, PJ, and FJ) storage days.

2.5. Determination of pH

Juice samples were placed in 50 mL beakers and the pH was recorded with a pH meter (model 780, Metrohm AG, Herisau Switzerland).

2.6. Measurement of Total Protein Content

The determinations were carried out using the Kjeldahl method and a Foss Kjeltec 8400 automatic distiller (Foss Anatytical AB, Höganӓs, Sweden). The total protein content was calculated using a 6.25 conversion factor.

2.7. Determination of the Chloride Content

The chloride content was determined with the Mohr method using a TitraLab AT1000 Series automatic titrator (HACH Company, Willstӓtterstraße, Germany). The solution was titrated with a 0.1 N silver nitrate solution. The chloride content was given as g in 100 g_f.j. (of fresh juice).

2.8. Determination of the Content of Reducing Sugars

The Lane–Eynon method was used to determine the content of reducing sugars. The material was extracted and deproteinised. The content of reducing sugars was determined in the obtained liquid by direct hot titration of a specific copper salt with the analysed sugar solution (against methylene blue as an indicator of the end of the reaction) [15,16].

2.9. Determination of Dry Matter Content

The moisture content of the research material was measured by drying 3 g of juice at 105 °C for 3 h. The measurements were carried out in triplicate.

2.10. Measurement of Chlorophyll Content

The juice was analysed for the content of chlorophylls A and B. The pigments were extracted with methyl alcohol. The chlorophyll content was measured using a UV–vis Helios Omega 3 spectrophotometer (Thermo Scientific, England). The measurement consisted of the determination of the absorbance (A) at different wavelengths (λ): 650 and 665 nm [17]. Next, the content of chlorophylls A and B and the total chlorophyll content were calculated with Equations (2)–(4):

Chlorophyll A content (C_chl(a)):

C_chl(a) = 16.5·A₍₆₆₅₎ − 8.3·A₍₆₅₀₎

(2)

Chlorophyll B content (C_chl(b)):

C_chl(b) = 33.8·A₍₆₅₀₎ − 12.5·A₍₆₆₅₎

(3)

Total chlorophyll content (C):

C = 4.0·A₍₆₆₅₎ + 25.5·A₍₆₅₀₎

(4)

where:

A₍₆₅₀₎ = absorbance at a 650 nm wavelength;

A₍₆₆₅₎ = absorbance at a 665 nm wavelength.

The chlorophyll content was calculated in mg·g⁻¹, taking into account the sample weight.

2.11. Statistical Analysis

The data were analysed statistically. A significance level of α = 0.05 was assumed for inference. The analysis was carried out using ANOVA (StatSoft Polska, Poland) with post hoc tests for homogeneous groups based on Tukey’s test. These groups comprised means between which no statistically significant difference was found at the assumed significance level, α.

The determinations were carried out in triplicate, except for leaf length and strength tests, which were repeated five times.

3. Results and Discussion

3.1. Characterisation of the Physical Traits of the Raw Material

Changes in the length of the barley shoots relative to the harvest date are shown in

Table 1. Properties of the raw material relative to the harvest time of barley leaf harvesting.

Harvest Time (Day)	7	14	21	28	p-Value
Length of leaves (mm)	9.08 ± 1.14 a	15.48 ± 1.26 b	17.58 ± 1.44 bc	19.53 ± 1.35 c	<0.0001
Strength of leaves (N)	3.75 ± 0.25 a	3.27 ± 0.45 ab	3.20 ± 0.39 ab	3.01 ± 0.69 b	0.0144

^a,b,c,d Means in the same line denoted by different letters were significantly different. The results are expressed as mean ± SD (n = 5).

.

The largest gain in the length of barley shoots was noted within seven days after emergence. In the following days, the rate of shoot growth declined. There were no statistically significant differences in the length of shoots between the material harvested at day 21 and day 28 after emergence. The length of shoots collected on day 21 and day 28 was 17.58 and 19.53 cm, respectively. The height of the plants was characteristic of unfertilised crops [18,19,20].

The strength of the barley shoots decreased over time. However, there were only significant changes in the tensile strength of the shoots in the material collected on day 28 of growth (in comparison to the material collected on day 7). Changes in the strength of cereal shoots are associated with the chemical composition, which is modified during plant growth [18].

3.2. The Pressing Efficiency

The effect of the harvest date on the pressing yield is shown in Figure 2.

The pressing yield ranged from 69.04% to 73.26%. It was obtained from 137 to 146 mL of juice (depending on the time of harvest). The highest value was noted during the processing of material harvested on cultivation day 21. The longer period of cultivation was associated with a statistically significant drop in the pressing yield. The pressing yield of barley leaves collected on day 28 was estimated at 69.4%. These results are consistent with data obtained by other authors. Paulíčková et al. [2] reported a pressing yield of 68% in a study that involved the extraction of juice from barley shoots. The decline in the pressing yield accompanying the longer harvesting period is probably caused by changes in the chemical composition, which lead to an increase in the fibre content.

3.3. Juice Acidity

Irrespective of the harvest date, the juice from the leaves and shoots of young barley had an acidic reaction (changes in pH are shown in Figure 3), shown by the significant decrease in pH values over time. The pH of the products pressed from leaves and shoots collected on day 7–28 ranged from 5.71 to 5.95. These values are similar to the pH of vegetable juices such as carrot or beetroot juice [21,22,23].

The pH values of the juice from young barley leaves did not change significantly during storage (Figure 4). The statistical analysis only revealed significant differences in the pH value in the case of juice refrigerated for seven days. The pasteurisation and freezing processes did not change this parameter significantly. Juice acidity has an important effect on pigments and other ingredients (e.g., chlorophyll, carotenoids, anthocyanins, myoglobin, etc.) responsible for the colour of fruits, vegetables, and meat [21,24,25,26].

3.4. Total Protein Content

Protein content was expressed as a percentage of dry matter, which was 4.71% on average. Changes in the protein content of the analysed juices are shown in Figure 5. The total protein content in the juice increased along with the barley harvest date. The differences in the protein content between the harvest dates were statistically significant. The highest protein content, i.e., 51%, was determined in samples collected on day 21. The statistical analysis revealed that the content of this component in the juice produced after the next harvest (day 28) was significantly lower (42.68%). As demonstrated by Paulíčková et al. [2], the total amino acid content in juice from barley leaves and shoots decreased over time. The highest protein content recorded for the Malz cultivar (collected in phase I—DC 29) was 30.44%_d.m. However, it should be noted that the authors collected the raw material at a later stage of barley growth. Therefore, these results may explain the lower protein content in the juice from barley leaves and shoots harvested on day 28 of growth (in comparison with the material obtained on day 21).

3.5. Chloride Content

The changes in chloride content in the analysed juices are shown in Figure 6. The chloride content in the juices was positively correlated with the length of barley growth. The statistical analysis demonstrated statistically significant differences in this parameter between the harvest dates. The chloride content ranged from 0.021 to 0.117 g·100 g _f.j. ⁻¹ for juice pressed from barley leaves and shoots collected on days 7–28. The increase in the chloride content was clearly correlated with a decrease in the pH of the juice. Park et al. [27] also showed that the amount of chlorides in the aboveground parts of plants may depend on the type of fertilization used.

3.6. Content of Reducing Sugars

Changes in the content of reducing sugars are shown in Figure 7. Their highest content was determined in the juice from barley leaves and shoots collected on day 21 of growth (8.20 g·100 g_d.m. ⁻¹). The differences in the value of this parameter between products obtained from shoots collected on days 14 and 28 were not statistically significant. The statistical analysis confirmed the lower content of reducing sugars only for juice made from raw material collected on day 7. The study conducted by Paulíčková et al. [2] showed that the content of simple sugars varied, depending on the plant growth phase. Other factors that significantly determined the changes in the analysed parameter include the conditions of the soil and the variety of barley. Paulíčková et al. [2] demonstrated that the sugar content in most barley varieties steadily decreased throughout the growing season.

3.7. Chlorophyll Content

The chlorophyll content in the barley juice and the impact of the thermal treatment methods on changes in this parameter are shown in

Table 2. Changes in the chlorophyll content in juice from young barley leaves during storage in various conditions (p < 0.0001).

Type of Heat Treatment/Ti-Me of Storage	Fresh (Control Probe)	Unprocessed (UJ)		Pasteurised (PJ)		Frozen (FJ)
		3rd Day	7th Day	3rd Day	7th Day
Chlorophyll A (mg·g−1)	4.80 ± 0.01 a	4.15 ± 0.02c	2.99 ± 0.01 e	3.80 ± 0.00 d	2.83 ± 0.015 f	4.66 ± 0.01 b
Chlorophyll B (mg·g−1)	1.53 ± 0.00 a	1.51 ± 0.00 bc	0.85 ± 0.01 d	1.50 ± 0.00 c	0.83 ± 0.00 e	1.51 ± 0.00 b
Total chlorophylls (mg·g−1)	6.62 ± 0.01 a	6.02 ± 0.04 c	4.11 ± 0.04 e	5.72 ± 0.02 d	3.83 ± 0.007 f	6.46 ± 0.04 b

^a,b,c,d,e,f Means in the same line denoted by different letters were significantly different. The results are expressed as mean ± SD (n = 3).

. The content of chlorophyll A and B and the total chlorophyll content changed significantly during storage. The highest determined content of total chlorophylls, i.e., 6.62 mg/g, was found in fresh juice. The chlorophyll contents in fresh raw material obtained by other authors ranged from 10.15 to 19.62 mg/g [28,29]. After seven days of storage, the total chlorophyll content was reduced by 37.9% (UJ), 42.12% (PJ), and 2.43% (FJ), in comparison with the untreated juice. It can thus be concluded from the present investigations that chlorophyll A is more sensitive to heat than chlorophyll B. Similar findings were reported by Weemaes et al. [30], who analysed the kinetics of chlorophyll degradation in thermally treated broccoli juice.

The process of freezing had the lowest effect on changes in the content of chlorophyll A and total chlorophylls. By contrast, in the case of chlorophyll B, the least significant changes were noted for the unpasteurised product refrigerated for one day and in the case of the frozen juice stored for seven days. Paulíčková et al. [2] also confirmed the significant effect of thermal treatment of barley leaf juice (freezing, drying, and freeze-drying) on changes in the nutrient content. The analysis of their results also allows for the conclusion that freezing exerts the weakest effect on the quality of the product. Koca et al. [25] demonstrated a faster rate of degradation of chlorophylls at a lower pH value (from 5.5 to 7.5). Hence, the significantly lower chlorophyll content of juice stored for seven days may be caused by, e.g., changes in the pH of the product.

4. Conclusions

The present investigations confirm the potential benefits of consuming green juice from young barley shoots and leaves as part of a daily diet. The product obtained from the material harvested after 7, 14, 21, and 28 days of growth contains many valuable nutrients, e.g., a high level of total protein (with CS = 41.44 Meth). Additionally, high pressing yields of approximately 70% can be achieved.

The study has demonstrated that barley leaves and shoots harvested on day 21 of plant growth are the best raw material for the production of juice. The process of pressing material collected at this time exhibits the highest efficiency, and the juice contains the highest levels of protein and reducing sugars, as well as a high chloride content.

The most effective way to preserve the juice from young barley leaves is freezing. This process does not induce changes in juice acidity and only slightly reduces the content of chlorophylls A and B during storage of the product. Pasteurisation of the juice significantly reduces the chlorophyll content, but does not induce statistically significant changes in the pH of the juice.

The reported results are a preliminary study on the topic. However, it is necessary to continue research to determine the impact of other factors (e.g., barley varieties, growing conditions) on the quality of juices from young barley shoots and leaves. It is also possible scale-up the experiment using a higher number of samples, filed conditions, etc.

In addition, this way of using shoots and leaves of young barley will have economic importance. The costs of obtaining raw materials for juice production will be reduced. The use of shoots and leaves of young barley, which is grown as a forecrop, for the production of green juices, may have a beneficial effect on the development of sustainable crop production. This will allow more efficient use of the plants.
