Elemental Geochemistry and Pb Isotopic Compositions of the Thick No. 7 Coal Seam in the Datun Mining Area, China
Abstract
:1. Introduction
2. Samples and Methods
2.1. Samples Collected
2.2. Experimental Methods
3. Results and Discussion
3.1. Mineralogy
3.2. Geochemical Features
3.2.1. Major Element Oxides
3.2.2. Trace Elements
3.2.3. Rare Earth Elements
3.3. Modes of Occurrence of Pb and Pb Isotopes
3.4. Pb Isotope Characteristics
4. Conclusions
- (1)
- The major minerals in the thick coal seam of the Datun mining area are clay minerals, calcite, quartz, and dolomite; SiO2 and Al2O3 are mainly in the form of clay minerals, and there is a good correlation between them. Fe is mainly in the form of pyrite, and Ca is mainly in the form of calcite;
- (2)
- The samples from Kongzhuang, Longdong, and Yaoqiao mines basically fall in the felsic source area, so it is considered that the sediment source in the study area is felsic source rock;
- (3)
- There are differences in the enrichment degree of trace elements between the Kongzhuang mine, Longdong mine, and Yaoqiao mine samples. Compared with the average values of elements in coal in the world, Li and W elements were found to be enriched as a whole. In particular, W was enriched in the Yaoqiao mine and highly enriched in Longdong mine samples. The distribution curve of rare earth elements in the three mines is inclined to the right overall, indicating the light rare earth enrichment type;
- (4)
- The lead in the coal samples from the Datun mining area mainly exists in pyrite, and there is little radioactive lead. There is a good correlation between 206Pb/207Pb and 208Pb/206Pb, indicating that the source of Pb in this area is relatively singular, mainly from the orogenic belt and crust–mantle mixed subduction zone, as well as some upper crust and mantle source areas.
Author Contributions
Funding
Data Availability Statement
Conflicts of Interest
References
- Dai, S.; Finkelman, R.B.; French, D.; Hower, J.C.; Graham, I.T.; Zhao, F. Modes of occurrence of elements in coal: A critical evaluation. Earth-Sci. Rev. 2021, 222, 103815. [Google Scholar] [CrossRef]
- Tuncer, A.; Karayigit, A.I.; Oskay, R.G.; Tunoğlu, C.; Kayseri-Özer, M.S.; Gümüş, B.A.; Bulut, Y.; Akbulut, A. A multi-proxy record of palaeoenvironmental and palaeoclimatic conditions during Plio-Pleistocene peat accumulation in the eastern flank of the Isparta Angle: A case study from the Şarkikaraağaç coalfield (Isparta, SW Central Anatolia). Int. J. Coal Geol. 2023, 265, 104149. [Google Scholar] [CrossRef]
- Zdravkov, A.; Groß, D.; Bechtel, A.; Stojanović, K.; Kojić, I. Depositional settings of the Eocene Suhostrel bituminous coal, SW Bulgaria, inferred from organic petrology and molecular proxies. Int. J. Coal Geol. 2023, 276, 104319. [Google Scholar] [CrossRef]
- Li, X.; Zhuang, X.G.; Zhou, J.B.; Wang, H.; Ma, X.P. Coal facies analysis of thick coal seam of middle Jurassic Xishanyao Formation in the middle part of eastern Junggar coal field, Xinjiang. Geol. Sci. Tech 2010, 29, 84–88. [Google Scholar]
- Liu, J.; Spiro, B.F.; Dai, S.; French, D.; Graham, I.T.; Wang, X.; Zhao, L.; Zhao, J.; Zeng, R. Strontium isotopes in high-and low-Ge coals from the Shengli Coalfield, Inner Mongolia, northern China: New indicators for Ge source. Int. J. Coal Geol. 2021, 233, 103642. [Google Scholar] [CrossRef]
- Spiro, B.F.; Liu, J.; Dai, S.; Zeng, R.; Large, D.; French, D. Marine derived 87Sr/86Sr in coal, a new key to geochronology and palaeoenvironment: Elucidation of the India-Eurasia and China-Indochina collisions in Yunnan, China. Int. J. Coal Geol. 2019, 215, 103304. [Google Scholar] [CrossRef]
- Shao, L.; Dang, X.; Gao, X.; Wang, D.; Wen, H.; Wang, X.; Cao, D.; Lu, J. Genetic mechanism of thick coal seams: Astronomical-forcing superimposed multi-staged swamp model. Coal Sci. Technol. 2022, 50, 186–195. [Google Scholar]
- Hower, J.C.; Finkelman, R.B.; Eble, C.F.; Arnold, B.J. Understanding coal quality and the critical importance of comprehensive coal analyses. Int. J. Coal Geol. 2022, 263, 104120. [Google Scholar] [CrossRef]
- Hower, J.C.; Gebremedhin, M.; Zourarakis, D.P.; Finkelman, R.B.; French, D.; Graham, I.T.; Schobert, H.H.; Zhao, L.; Dai, S. Is hyperaccumulation a viable hypothesis for organic associations of minor elements in coals? Earth-Sci. Rev. 2024, 254, 104802. [Google Scholar] [CrossRef]
- Dai, S.; Bechtel, A.; Eble, C.F.; Flores, R.M.; French, D.; Graham, I.T.; Hood, M.M.; Hower, J.C.; Korasidis, V.A.; Moore, T.A.; et al. Recognition of peat depositional environments in coal: A review. Int. J. Coal Geol. 2020, 219, 103383. [Google Scholar]
- Dai, S.; Hower, J.C.; Finkelman, R.B.; Graham, I.T.; French, D.; Ward, C.R.; Eskenazy, G.; Wei, Q.; Zhao, L. Organic associations of non-mineral elements in coal: A review. Int. J. Coal Geol. 2020, 218, 103347. [Google Scholar] [CrossRef]
- Dai, S.; Finkelman, R.B.; Hower, J.C.; French, D.; Graham, I.T.; Zhao, L. Inorganic Geochemistry of Coal; Elsevier: Amsterdam, The Netherlands, 2023. [Google Scholar]
- Dai, S.; Yan, X.; Ward, C.R.; Hower, J.C.; Zhao, L.; Wang, X.; Zhao, L.; Ren, D.; Finkelman, R.B. Valuable elements in Chinese coals: A review. Int. Geol. Rev. 2018, 60, 590–620. [Google Scholar] [CrossRef]
- Dai, S.; Finkelman, R.B. Coal as a promising source of critical elements: Progress and future prospects. Int. J. Coal Geol. 2018, 186, 155–164. [Google Scholar] [CrossRef]
- Di, S.; Dai, S.; Nechaev, V.P.; French, D.; Graham, I.T.; Zhao, L.; Finkelman, R.B.; Wang, H.; Zhang, S.; Hou, Y. Mineralogy and enrichment of critical elements (Li and Nb-Ta-Zr-Hf-Ga) in the Pennsylvanian coals from the Antaibao Surface Mine, Shanxi Province, China: Derivation of pyroclastics and sediment-source regions. Int. J. Coal Geol. 2023, 273, 104262. [Google Scholar] [CrossRef]
- Di, S.; Dai, S.; Nechaev, V.P.; Zhang, S.; French, D.; Graham, I.T.; Spiro, B.; Finkelman, R.B.; Hou, Y.; Wang, Y.; et al. Granite-bauxite provenance of abnormally enriched boehmite and critical elements (Nb, Ta, Zr, Hf and Ga) in coals from the Eastern Surface Mine, Ningwu Coalfield, Shanxi Province, China. J. Geochem. Explor. 2022, 239, 107016. [Google Scholar] [CrossRef]
- Liu, J.; Dai, S.; Berti, D.; Eble, C.F.; Dong, M.; Gao, Y.; Hower, J.C. Rare Earth and Critical Element Chemistry of the Volcanic Ash-fall Parting in the Fire Clay Coal, Eastern Kentucky, USA. Clays Clay Miner. 2023, 71, 309–339. [Google Scholar] [CrossRef]
- Moore, T.A.; Dai, S.; Huguet, C.; Pearse, J.; Liu, J.; Esterle, J.S.; Jia, R. Petrographic and geochemical characteristics of selected coal seams from the late Cretaceous-Paleocene Guaduas Formation, Eastern Cordillera Basin, Colombia. Int. J. Coal Geol. 2022, 259, 104042. [Google Scholar] [CrossRef]
- Wang, Q.; Dai, S.; French, D.; Spiro, B.; Graham, I.; Liu, J. Hydrothermally-altered coal from the Daqingshan Coalfield, Inner Mongolia, northern China: Evidence from stable isotopes of C within organic matter and C-O-Sr in associated carbonates. Int. J. Coal Geol. 2023, 276, 104330. [Google Scholar] [CrossRef]
- Chatterjee, S.; Karacan, C.Ö.; Mastalerz, M. Exploring the uncertainty of machine learning models and geostatistical mapping of rare earth element potential in Indiana coals, USA. Int. J. Coal Geol. 2024, 282, 104419. [Google Scholar] [CrossRef]
- Du, F.; Qiao, J.; Zhao, X.; Tan, F.; Li, C.; Luo, Z. Enrichment of V in Late Permian coals in Gemudi Mine, Western Guizhou, SW China. J. Geochem. Explor. 2021, 221, 106701. [Google Scholar] [CrossRef]
- Jiu, B.; Huang, W.; Spiro, B.; Hao, R.; Mu, N.; Wen, L.; Hao, H. Distribution of Li, Ga, Nb, and REEs in coal as determined by LA-ICP-MS imaging: A case study from Jungar coalfield, Ordos Basin, China. Int. J. Coal Geol. 2023, 267, 104184. [Google Scholar] [CrossRef]
- Dai, S.; Ren, D.; Tang, Y.; Yue, M.; Hao, L.M. Concentration and distribution of elements in Late Permian coals from western Guizhou Province, China. Int. J. Coal Geol. 2005, 61, 119–137. [Google Scholar] [CrossRef]
- Liu, Z.; Wei, Y.; Ning, S.; Jia, X.; Qin, R.; Cao, D. The differences of element geochemical characteristics of the main coal seams in the Ningdong coalfield, Ordos Basin. J. Geochem. Explor. 2019, 202, 77–91. [Google Scholar]
- Zhou, M.; Zhao, L.; Wang, X.; Nechaev, V.P.; French, D.; Spiro, B.F.; Hower, J.; Dai, S. Mineralogy and geochemistry of the Late Triassic coal from the Caotang mine, northeastern Sichuan Basin, China, with emphasis on the enrichment of the critical element lithium. Ore Geol. Rev. 2021, 139, 104582. [Google Scholar] [CrossRef]
- Mishra, V.; Chakravarty, S.; Finkelman, R.B.; Varma, A.K. Geochemistry of rare earth elements in lower Gondwana coals of the Talchir Coal Basin, India. J. Geochem. Explor. 2019, 204, 43–56. [Google Scholar] [CrossRef]
- Equeenuddin, S.M.; Tripathy, S.; Sahoo, P.K.; Ranjan, A. Geochemical characteristics and mode of occurrence of trace elements in coal at West Bokaro coalfield. Int. J. Coal Sci. Technol. 2016, 3, 399–406. [Google Scholar] [CrossRef]
- Dai, S.; Xie, P.; Jia, S.; Ward, C.R.; Hower, J.C.; Yan, X.; French, D. Enrichment of U-Re-V-Cr-Se and rare earth elements in the Late Permian coals of the Moxinpo Coalfield, Chongqing, China: Genetic implications from geochemical and mineralogical data. Ore Geol. Rev. 2017, 80, 1–17. [Google Scholar] [CrossRef]
- Dai, S.; Ji, D.; Ward, C.R.; French, D.; Hower, J.C.; Yan, X.; Wei, Q. Mississippian anthracites in Guangxi Province, southern China: Petrological, mineralogical, and rare earth element evidence for high-temperature solutions. Int. J. Coal Geol. 2018, 197, 84–114. [Google Scholar] [CrossRef]
- Nechaev, V.P.; Bechtel, A.; Dai, S.; Chekryzhov, I.Y.; Pavlyutkin, B.I.; Vysotskiy, S.V.; Ignatiev, A.V.; Velivetskaya, T.A.; Guo, W.; Tarasenko, I.A.; et al. Bio-geochemical evolution and critical element mineralization in the Cretaceous-Cenozoic coals from the southern Far East Russia and northeastern China. Appl. Geochem. 2020, 117, 104602. [Google Scholar] [CrossRef]
- Arbuzov, S.I.; Chekryzhov, I.Y.; Verkhoturov, A.A.; Spears, D.A.; Melkiy, V.A.; Zarubina, N.V.; Blokhin, M.G. Geochemistry and rare-metal potential of coals of the Sakhalin coal basin, Sakhalin Island, Russia. Int. J. Coal Geol. 2023, 268, 104197. [Google Scholar] [CrossRef]
- Dai, S.; Zhou, Y.; Ren, D.; Wang, X.; Li, D.; Zhao, L. Geochemistry and mineralogy of the Late Permian coals from the Songzao Coalfield, Chongqing, southwestern China. Sci. China Ser. D-Earth Sci. 2007, 50, 678–688. [Google Scholar] [CrossRef]
- Dai, S.; Ren, D.; Chou, C.-L.; Finkelman, R.B.; Seredin, V.V.; Zhou, Y. Geochemistry of trace elements in Chinese coals: A review of abundances, genetic types, impacts on human health, and industrial utilization. Int. J. Coal Geol. 2012, 94, 3–21. [Google Scholar] [CrossRef]
- Dai, S.; Zou, J.; Jiang, Y.; Ward, C.R.; Wang, X.; Li, T.; Xue, W.; Liu, S.; Tian, H.; Sun, X.; et al. Mineralogical and geochemical compositions of the Pennsylvanian coal in the Adaohai Mine, Daqingshan Coalfield, Inner Mongolia, China: Modes of occurrence and origin of diaspore, gorceixite, and ammonian illite. Int. J. Coal Geol. 2012, 94, 250–270. [Google Scholar] [CrossRef]
- Sun, B.; Zeng, F.; Moore, T.A.; Rodrigues, S.; Liu, C.; Wang, G. Geochemistry of two high-lithium content coal seams, Shanxi Province, China. Int. J. Coal Geol. 2022, 260, 104059. [Google Scholar] [CrossRef]
- Wang, N.; Dai, S.; Nechaev, V.P.; French, D.; Graham, I.T.; Song, X.; Chekryzhov, I.Y.; Tarasenko, I.A.; Budnitskiy, S.Y. Detrital U-Pb zircon geochronology, zircon Lu-Hf and Sr-Nd isotopic signatures of the Lopingian volcanic-ash-derived Nb-Zr-REY-Ga mineralized horizons from eastern Yunnan, SW China. Lithos 2024, 468–469, 107494. [Google Scholar] [CrossRef]
- Wang, Q.; Dai, S.; Nechaev, V.P.; French, D.; Graham, I.; Zhao, L.; Zhang, S.; Liang, Y.; Hower, J.C. Transformation of organic to inorganic nitrogen in NH4+-illite-bearing and Ga-Al-REE-rich bituminous coals: Evidence from nitrogen isotopes and functionalities. Chem. Geol. 2024, 660, 122169. [Google Scholar] [CrossRef]
- Zhang, S.; Yuan, T.; Sun, B.; Li, L.; Ma, X.; Shi, S.; Liu, Q. Formation of boehmite through desilication of volcanic-ash-altered kaolinite and its retention for gallium: Contribution to enrichment of aluminum and gallium in coal. Int. J. Coal Geol. 2024, 281, 104404. [Google Scholar] [CrossRef]
- Zhao, L.; Dai, S.; Nechaev, V.P.; Nechaeva, E.V.; Graham, I.T.; French, D.; Sun, J. Enrichment of critical elements (Nb-Ta-Zr-Hf-REE) within coal and host rocks from the Datanhao mine, Daqingshan Coalfield, northern China. Ore Geol. Rev. 2019, 111, 102951. [Google Scholar] [CrossRef]
- Zhao, L.; Dai, S.; Nechaev, V.P.; Nechaeva, E.V.; Graham, I.T.; French, D. Enrichment origin of critical elements (Li and rare earth elements) and a Mo-U-Se-Re assemblage in Pennsylvanian anthracite from the Jincheng Coalfield, southeastern Qinshui Basin, northern China. Ore Geol. Rev. 2019, 115, 103184. [Google Scholar] [CrossRef]
- Finkelman, R.B.; Palmer, C.A.; Wang, P. Quantification of the modes of occurrence of 42 elements in coal. Int. J. Coal Geol. 2018, 185, 138–160. [Google Scholar]
- Finkelman, R.B.; Wolfe, A.; Hendryx, M.S. The future environmental and health impacts of coal. Energy Geosci. 2021, 2, 99–112. [Google Scholar] [CrossRef]
- Bi, X.Y.; Li, Z.G.; Wang, S.X.; Zhang, L.; Xu, R.; Liu, J.L.; Yang, H.; Guo, M.Z. Lead isotopic compositions of selected coals, Pb/Zn ores and fuels in China and the application for source tracing. Environ. Sci. Technol. 2017, 51, 13502–13508. [Google Scholar] [CrossRef] [PubMed]
- Dai, S.; Ren, D.; Chou, C.-L.; Li, S.; Jiang, Y. Mineralogy and geochemistry of the no. 6 coal (Pennsylvanian) in the Junger Coalfield, Ordos Basin, China. Int. J. Coal Geol. 2006, 66, 253–270. [Google Scholar] [CrossRef]
- Dai, S.; Hower, J.; Ward, C.R.; Guo, W.; Song, H.; O’Keefe, J.M.K.; Xie, P.; Hood, M.M.; Yan, X. Elements and phosphorus minerals in the middle Jurassic inertinite-rich coals of the Muli Coalfield on the Tibetan Plateau. Int. J. Coal Geol. 2015, 144, 23–47. [Google Scholar] [CrossRef]
- Hower, J.C.; Williams, D.A.; Eble, C.F.; Sakulpitakphon, T.; Moecher, D.P. Brecciated and mineralized coals in Union County, Western Kentucky coal field. Int. J. Coal Geol. 2001, 47, 223–234. [Google Scholar] [CrossRef]
- Swaine, D.J. The organic association of elements in coals. Org. Geochem. 1992, 18, 259–261. [Google Scholar] [CrossRef]
- Zhou, G.; Jiang, Y.; Liu, M. Sapropelic coal petrologic, quality and trace element characteristics in Datun mining area, Xuzhou. Coal Geol. China 2011, 23, 7–9. (In Chinese) [Google Scholar]
- Dai, Y.; Zhu, J.; Tan, D.; Ren, K.; Tao, F.; Wang, J. Preliminary investigation on concentration and isotopic composition of lead in coal from Guizhou Province, China. Earth Env. 2017, 45, 290–297. [Google Scholar]
- Dai, S.; Tian, L.; Chou, C.-L.; Zhou, Y.; Zhang, M.; Zhao, L.; Wang, J.; Yang, Z.; Cao, H.; Ren, D. Mineralogical and compositional characteristics of Late Permian coals from an area of high lung cancer rate in Xuan Wei, Yunnan, China: Occurrence and origin of quartz and chamosite. Int. J. Coal Geol. 2008, 76, 318–327. [Google Scholar] [CrossRef]
- Díaz-Somoano, M.; Kylander, M.E.; López-Antón, M.A.; Suárez-Ruiz, I.; Martínez-Tarazona, M.R.; Ferrat, M.; Kober, B.; Weiss, D.J. Stable lead isotope compositions in selected coals from around the world and implications for present day aerosol source tracing. Environ. Sci. Technol. 2009, 43, 1078–1085. [Google Scholar] [CrossRef]
- Díaz-Somoano, M.; Suárez-Ruiz, I.; Alonso, J.I.G.; Encinar, J.R.; López-Antón, M.A.; Martínez-Tarazona, M.R. Lead isotope ratios in Spanish coals of different characteristics and origin. Int. J. Coal Geol. 2007, 71, 28–36. [Google Scholar] [CrossRef]
- Mihaljevič, M.; Ettler, V.; Strnad, L.; Šebek, O.; Vonásek, F.; Drahota, P.; Rohovec, J. Isotopic composition of lead in Czech coals. Int. J. Coal Geol. 2009, 78, 38–46. [Google Scholar] [CrossRef]
- Ward, C.R. Analysis and significance of mineral matter in coal seams. Int. J. Coal Geol. 2002, 50, 135–168. [Google Scholar] [CrossRef]
- Ward, C.R. Analysis, origin and significance of mineral matter in coal: An updated review. Int. J. Coal Geol. 2016, 165, 1–27. [Google Scholar] [CrossRef]
- Chitlango, F.Z.; Wagner, N.J.; Moroeng, O.M. Characterization and pre-concentration of rare earth elements in density fractionated samples from the Waterberg Coalfield, South Africa. Int. J. Coal Geol. 2023, 275, 104299. [Google Scholar] [CrossRef]
- Willard, D.A.; Ruppert, L.F. Broadening the perspectives of sedimentary organic matter analysis to understand Earth system response to change. Int. J. Coal Geol. 2023, 274, 104281. [Google Scholar] [CrossRef]
- Finkelman, R.B.; Dai, S.; French, D. The importance of minerals in coal as the hosts of chemical elements: A review. Int. J. Coal Geol. 2019, 212, 103251. [Google Scholar] [CrossRef]
- Jiu, B.; Jin, Z.; Wang, Z. Multiscale in-situ elemental characterization of critical elements in low rank coal, implications for modes of occurrence. Fuel 2023, 349, 128632. [Google Scholar] [CrossRef]
- Qin, G.; Cao, D.; Wei, Y.; Wang, A.; Liu, J. Geochemical characteristics of the Permian coals in the Junger-Hebaopian mining district, northeastern Ordos Basin, China: Key role of paleopeat-forming environments in Ga-Li-REY enrichment. J. Geochem. Explor. 2020, 213, 106494. [Google Scholar] [CrossRef]
- Hayashi, K.I.; Fujisawa, H.; Holland, H.D.; Ohmoto, H. Geochemistry of ∼1.9 Ga sedimentary rocks from northeastern Labrador, Canada. Geochim. Cosmochim. Acta 1997, 61, 4115–4137. [Google Scholar]
- Dai, S.; Wang, X.; Zhou, Y.; Hower, J.C.; Li, D.; Chen, W.; Zhu, X.; Zou, J. Chemical and mineralogical compositions of silicic, mafic, and alkali tonsteins in the late Permian coals from the Songzao Coalfield, Chongqing, Southwest China. Chem. Geol. 2011, 282, 29–44. [Google Scholar] [CrossRef]
- Dai, S.; Li, T.; Jiang, Y.; Ward, C.R.; Hower, J.C.; Sun, J.; Liu, J.; Song, H.; Wei, J.; Li, Q.; et al. Mineralogical and geochemical compositions of the Pennsylvanian coal in the Hailiushu Mine, Daqingshan Coalfield, Inner Mongolia, China: Implications of sediment-source region and acid hydrothermal solutions. Int. J. Coal Geol. 2015, 137, 92–110. [Google Scholar] [CrossRef]
- Dai, S.; Yang, J.; Ward, C.R.; Hower, J.C.; Liu, H.; Garrison, T.M.; French, D.; O’Keefe, J.M. Geochemical and mineralogical evidence for a coal-hosted uranium deposit in the Yili Basin, Xinjiang, northwestern China. Ore Geol. Rev. 2015, 70, 1–30. [Google Scholar] [CrossRef]
- Zhou, M.; Dai, S.; Wang, X.; Zhao, L.; Nechaev, V.P.; French, D.; Graham, I.T.; Zheng, J.; Wang, Y.; Dong, M. Critical element (Nb-Ta-Zr-Hf-REE-Ga-Th-U) mineralization in Late Triassic coals from the Gaosheng Mine, Sichuan Basin, southwestern China: Coupled effects of products of sediment-source-region erosion and acidic water infiltration. Int. J. Coal Geol. 2022, 262, 104101. [Google Scholar] [CrossRef]
- Dai, S.; Seredin, V.V.; Ward, C.R.; Hower, J.C.; Xing, Y.; Zhang, W.; Song, W.; Wang, P. Enrichment of U–Se–Mo–Re–V in coals preserved within marine carbonate successions: Geochemical and mineralogical data from the Late Permian Guiding Coalfield, Guizhou, China. Miner. Depos. 2015, 50, 159–186. [Google Scholar] [CrossRef]
- Ketris, M.Á.; Yudovich, Y.E. Estimations of Clarkes for Carbonaceous biolithes: World averages for trace element contents in black shales and coals. Int. J. Coal Geol. 2009, 78, 135–148. [Google Scholar] [CrossRef]
- Shen, M.; Dai, S.; French, D.; Graham, I.T.; Spiro, B.F.; Wang, N.; Tian, X. Geochemical and mineralogical evidence for the formation of siderite in late Permian coal-bearing strata from western Guizhou, SW China. Chem. Geol. 2023, 637, 121675. [Google Scholar] [CrossRef]
- Shen, M.; Dai, S.; Nechaev, V.P.; French, D.; Graham, I.T.; Liu, S.; Chekryzhov, I.Y.; Tarasenko, I.A.; Zhang, S. Provenance changes for mineral matter in the latest Permian coals from western Guizhou, southwestern China, relative to tectonic and volcanic activity in the Emeishan Large Igneous Province and Paleo-Tethys region. Gondwana Res. 2023, 113, 71–88. [Google Scholar] [CrossRef]
- Chen, H.; He, S.; Zhang, A.; Sun, J.; Yan, Z.; Liu, J.; Zhang, L.; Qian, Y. Petrogenesis and tectonic setting of Middle Silurian A-type granite in Kaerqueka area, East Kunlun. Geol. Bull. China 2021, 40, 1380–1393. [Google Scholar]
- Seredin, V.V.; Dai, S. Coal deposits as potential alternative sources for lanthanides and yttrium. Int. J. Coal Geol. 2012, 94, 67–93. [Google Scholar] [CrossRef]
- Qin, S.J.; Gao, K.; Wang, J.X.; Li, Y.H.; Lu, Q.F. Geochemistry of the associated elements in the Late Permian Coal from the Huoshaopu and Jinjia Mines, Southwestern Guizhou. China Coal Soc. 2016, 41, 1507–1516. [Google Scholar]
- Liu, J.; Nechaev, V.P.; Dai, S.; Song, H.; Nechaeva, E.V.; Jiang, Y.; Graham, I.T.; French, D.; Yang, P.; Hower, J.C. Evidence for multiple sources for inorganic components in the Tucheng coal deposit, western Guizhou, China and the lack of critical-elements. Int. J. Coal Geol. 2020, 223, 103468. [Google Scholar] [CrossRef]
- Nechaev, V.P.; Dai, S.; Chekryzhov, I.Y.; Tarasenko, I.A.; Zin’kov, A.V.; Moore, T.A. Origin of the tuff parting and associated enrichments of Zr, REY, redox-sensitive and other elements in the Early Miocene coal of the Siniy Utyes Basin, southwestern Primorye, Russia. Int. J. Coal Geol. 2022, 250, 103913. [Google Scholar] [CrossRef]
- Shen, M.; Dai, S.; Graham, I.T.; Nechaev, V.P.; French, D.; Zhao, F.; Shao, L.; Liu, S.; Zuo, J.; Zhao, J.; et al. Mineralogical and geochemical characteristics of altered volcanic ashes (tonsteins and K-bentonites) from the latest Permian coal-bearing strata of western Guizhou Province, southwestern China. Int. J. Coal Geol. 2021, 237, 103707. [Google Scholar] [CrossRef]
- Wang, N.; Dai, S.; Wang, X.; Nechaev, V.P.; French, D.; Graham, I.T.; Zhao, L.; Song, X. New insights into the origin of Middle to Late Permian volcaniclastics (Nb-Zr-REY-Ga-rich horizons) from eastern Yunnan, SW China. Lithos 2022, 420–421, 106702. [Google Scholar] [CrossRef]
- Taylor, S.R.; McLennan, S.M. The Continental Crust: Its Composition and Evolution; U.S. Department of Energy: Oak Ridge, TN, USA, 1985. [Google Scholar]
- Dai, S.; Graham, I.T.; Ward, C.R. A review of anomalous rare earth elements and yttrium in coal. Int. J. Coal Geol. 2016, 159, 82–95. [Google Scholar] [CrossRef]
- Dai, S.; Seredin, V.V.; Ward, C.R.; Jiang, J.; Hower, J.C.; Song, X.; Jiang, Y.; Wang, X.; Gornostaeva, T.; Li, X.; et al. Composition and modes of occurrence of minerals and elements in coal combustion products derived from high-Ge coals. Int. J. Coal Geol. 2014, 121, 79–97. [Google Scholar] [CrossRef]
- Patra, K.C.; Rautray, T.R.; Tripathy, B.B.; Nayak, P. Elemental analysis of coal and coal ASH by PIXE technique. Appl. Radiat. Isot. 2012, 70, 612–616. [Google Scholar] [CrossRef] [PubMed]
- Qiao, J.; Du, F.; Wang, S.; Tan, F.; Zhang, Y. Enrichment and Occurrence of Mn in 5–2 Coal from Qinglongsi Coal Mine, Northern Ordos Basin, China. ACS Omega 2020, 5, 20202–20214. [Google Scholar] [CrossRef]
- Finkelman, R.B. Trace elements in coal: Environmental and health significance. Biol. Trace Elem. Res. 1999, 67, 197–204. [Google Scholar] [CrossRef]
- Liu, J.; Ward, C.R.; Graham, I.T.; French, D.; Dai, S.; Song, X. Modes of occurrence of non-mineral inorganic elements in lignites from the Mile Basin, Yunnan Province, China. Fuel 2018, 222, 146–155. [Google Scholar] [CrossRef]
- Dai, S.; Wang, P.; Ward, C.R.; Tang, Y.; Song, X.; Jiang, J.; Hower, J.C.; Li, T.; Seredin, V.V.; Wagner, N.J.; et al. Elemental and mineralogical anomalies in the coal-hosted Ge ore deposit of Lincang, Yunnan, southwestern China: Key role of N2-CO2-mixed hydrothermal solutions. Int. J. Coal Geol. 2015, 152, 19–46. [Google Scholar] [CrossRef]
- Shao, P.; Hou, H.; Wang, W.; Qin, K.; Wang, W. Distribution and enrichment of Al-Li-Ga-REEs in the High-Alumina coal of the Datong Coalfield, Shanxi Province, China. Ore Geol. Rev. 2022, 140, 104597. [Google Scholar] [CrossRef]
- Sun, B.; Guo, Z.; Liu, C.; Kong, Y.; French, D.; Zhu, Z. Lithium isotopic composition of two high-lithium coals and their fractions with different lithium occurrence modes, Shanxi Province, China. Int. J. Coal Geol. 2023, 277, 104338. [Google Scholar] [CrossRef]
- Xu, F.; Qin, S.; Li, S.; Wen, H.; Lv, D.; Wang, Q.; Kang, S. The migration and mineral host changes of lithium during coal combustion: Experimental and thermodynamic calculation study. Int. J. Coal Geol. 2023, 275, 104298. [Google Scholar] [CrossRef]
- Finkelman, R.B. Modes of occurrence of environmentally-sensitive trace elements in coal. In Environmental Aspects of Trace Elements in Coal; Springer: Dordrecht, The Netherlands, 1995; pp. 24–50. [Google Scholar]
- Çelebi, E.E.; Ribeiro, J. Prediction of acid production potential of self-combusted coal mining wastes from Douro Coalfield (Portugal) with integration of mineralogical and chemical data. Int. J. Coal Geol. 2023, 265, 104152. [Google Scholar] [CrossRef]
- Matýsek, D.; Jirásek, J. Mineralogy of the coal waste dumps from the Czech part of the Upper Silesian Basin: Emphasized role of halides for element mobility. Int. J. Coal Geol. 2022, 264, 104138. [Google Scholar] [CrossRef]
- Yang, P.; Dai, S.; Nechaev, V.P.; Song, X.; Chekryzhov, I.Y.; Tarasenko, I.A.; Tian, X.; Yao, M.; Kang, S.; Zheng, J. Modes of occurrence of critical metals (Nb-Ta-Zr-Hf-REY-Ga) in altered volcanic ashes in the Xuanwei Formation, eastern Yunnan Province, SW China: A quantitative evaluation based on sequential chemical extraction. Ore Geol. Rev. 2023, 160, 105617. [Google Scholar] [CrossRef]
- Arnold, B.J. A review of element partitioning in coal preparation. Int. J. Coal Geol. 2023, 274, 104296. [Google Scholar] [CrossRef]
- Xu, N.; Xu, C.; Finkelman, R.B.; Engle, M.A.; Li, Q.; Peng, M.; He, L.; Huang, B.; Yang, Y. Coal elemental (compositional) data analysis with hierarchical clustering algorithms. Int. J. Coal Geol. 2022, 249, 103892. [Google Scholar] [CrossRef]
- Zhu, B.Q. Theory and Application of Isotope System in Earth Science: Also on the Evolution of the Crust and Mantle of the Chinese Mainland; Science Press: Beijing, China, 1998. (In Chinese) [Google Scholar]
- Zartman, R.E.; Doe, B.R. Plumbotectonics—The model. Tectonophysics 1981, 75, 135–162. [Google Scholar] [CrossRef]
Mine | Sample | Mad | Ad | Vdaf | FCd | Std |
---|---|---|---|---|---|---|
Kongzhuang | KZ-C1 | 1.65 | 9.79 | 37.55 | 56.34 | 0.81 |
KZ-C2 | 2.72 | 24.24 | 42.50 | 43.56 | 1.67 | |
KZ-C3 | 2.63 | 32.76 | 44.74 | 37.16 | 1.93 | |
KZ-C4 | 1.80 | 6.80 | 39.29 | 56.58 | 0.57 | |
KZ-C5 | 1.58 | 7.86 | 38.11 | 57.02 | 0.59 | |
KZ-C6 | 1.68 | 7.28 | 36.92 | 58.48 | 0.49 | |
KZ-C7 | 1.57 | 9.00 | 38.19 | 56.24 | 0.45 | |
KZ-C8 | 1.44 | 9.59 | 38.87 | 55.27 | 0.49 | |
KZ-C9 | 1.60 | 13.74 | 36.07 | 55.14 | 0.41 | |
KZ-C10 | 1.81 | 6.74 | 35.97 | 59.71 | 0.51 | |
KZ-Y1 | 1.74 | 88.83 | 99.18 | 0.09 | 1.71 | |
Longdong | LD-C1 | 3.48 | 9.16 | 40.23 | 54.30 | 1.33 |
LD-C2 | 2.44 | 8.77 | 36.8 | 57.66 | 0.67 | |
LD-C3 | 2.66 | 11.14 | 38.15 | 54.96 | 0.62 | |
LD-C4 | 2.32 | 16.69 | 30.47 | 57.92 | 0.72 | |
LD-C5 | 2.26 | 12.18 | 38.80 | 53.74 | 0.61 | |
LD-C6 | 2.56 | 8.88 | 37.28 | 57.15 | 0.62 | |
LD-C7 | 2.50 | 14.23 | 31.39 | 58.85 | 0.62 | |
LD-C8 | 2.78 | 12.15 | 39.95 | 52.76 | 0.71 | |
LD-Y1 | 0.22 | 92.79 | 95.27 | 0.34 | 0.50 | |
Yaoqiao | YQ-C1 | 1.90 | 7.03 | 40.00 | 55.78 | 0.55 |
YQ-C2 | 2.02 | 6.53 | 34.85 | 60.89 | 0.53 | |
YQ-C3 | 1.91 | 6.30 | 34.98 | 60.92 | 0.51 | |
YQ-C4 | 2.17 | 7.20 | 38.18 | 57.38 | 0.55 | |
YQ-C5 | 1.80 | 6.52 | 39.49 | 56.57 | 0.53 | |
YQ-C6 | 2.04 | 9.94 | 35.80 | 57.82 | 0.43 | |
YQ-C7 | 1.92 | 9.54 | 35.48 | 58.36 | 0.58 | |
YQ-C8 | 2.08 | 7.88 | 39.27 | 55.94 | 0.71 | |
YQ-Y2 | 1.33 | 83.55 | 70.55 | 4.84 | 0.41 |
Mine | Sample | SiO2 | Al2O3 | Fe2O3 | MgO | CaO | Na2O | K2O | TiO2 | P2O5 | Loss on Ignition | FeO |
---|---|---|---|---|---|---|---|---|---|---|---|---|
Kongzhuang | KZ-C1 | 3.31 | 3.36 | 0.63 | 0.12 | 1.26 | 0.15 | 0.03 | 0.12 | 0.04 | 90.56 | 0.41 |
KZ-C2 | 13.93 | 11.63 | 1.72 | 0.18 | 0.75 | 0.13 | 0.19 | 0.26 | 0.02 | 71.13 | 0.73 | |
KZ-C3 | 16.51 | 13.53 | 2.39 | 0.17 | 0.72 | 0.12 | 0.25 | 0.26 | 0.03 | 65.95 | 0.93 | |
KZ-C4 | 2.72 | 2.45 | 0.39 | 0.08 | 0.69 | 0.10 | 0.02 | 0.03 | 0.01 | 93.36 | 0.31 | |
KZ-C5 | 3.00 | 2.72 | 0.35 | 0.08 | 0.61 | 0.09 | 0.01 | 0.03 | 0.01 | 92.82 | 0.29 | |
KZ-C6 | 5.11 | 4.05 | 0.43 | 0.11 | 0.64 | 0.10 | 0.02 | 0.27 | 0.02 | 89.17 | 0.25 | |
KZ-C7 | 4.91 | 3.06 | 0.54 | 0.10 | 3.76 | 0.08 | 0.03 | 0.28 | 0.01 | 87.16 | 0.20 | |
KZ-C8 | 2.41 | 2.02 | 0.31 | 0.09 | 0.91 | 0.08 | 0.02 | 0.04 | 0.01 | 94.02 | 0.26 | |
KZ-C9 | 6.26 | 5.18 | 0.38 | 0.07 | 1.53 | 0.08 | 0.04 | 0.18 | 0.01 | 86.12 | 0.29 | |
KZ-C10 | 6.65 | 5.46 | 0.24 | 0.08 | 0.58 | 0.06 | 0.03 | 0.09 | 0.01 | 86.42 | 0.20 | |
KZ-Y1 | 58.49 | 22.36 | 3.92 | 0.70 | 0.26 | 0.27 | 2.3 | 0.62 | 0.06 | 10.82 | 2.34 | |
Longdong | LD-C1 | 2.47 | 2.05 | 0.75 | 0.06 | 0.60 | 0.07 | 0.04 | 0.05 | 0.01 | 93.85 | 0.54 |
LD-C2 | 5.50 | 4.65 | 0.84 | 0.09 | 0.90 | 0.05 | 0.05 | 0.30 | 0.01 | 87.53 | 0.44 | |
LD-C3 | 2.47 | 2.09 | 0.60 | 0.15 | 3.43 | 0.04 | 0.03 | 0.11 | 0.01 | 90.93 | 0.35 | |
LD-C4 | 5.96 | 5.06 | 0.55 | 0.11 | 0.39 | 0.04 | 0.06 | 0.17 | 0.01 | 87.56 | 0.29 | |
LD-C5 | 8.48 | 6.61 | 0.80 | 0.11 | 0.94 | 0.06 | 0.09 | 0.31 | 0.02 | 82.31 | 0.49 | |
LD-C6 | 3.32 | 2.77 | 0.54 | 0.12 | 1.19 | 0.08 | 0.05 | 0.08 | 0.01 | 91.11 | 0.35 | |
LD-C7 | 3.35 | 2.71 | 0.43 | 0.14 | 2.90 | 0.05 | 0.03 | 0.10 | 0.01 | 89.77 | 0.31 | |
LD-C8 | 4.42 | 3.66 | 0.80 | 0.13 | 3.99 | 0.13 | 0.05 | 0.08 | 0.01 | 86.64 | 0.44 | |
LD-Y1 | 74.75 | 11.39 | 0.85 | 0.29 | 3.00 | 1.35 | 2.73 | 0.40 | 0.04 | 5.08 | 0.41 | |
Yaoqiao | YQ-C1 | 4.32 | 3.79 | 1.16 | 0.18 | 0.40 | 0.04 | 0.02 | 0.05 | 0.01 | 89.98 | 0.25 |
YQ-C2 | 3.26 | 2.90 | 0.35 | 0.06 | 0.14 | 0.08 | 0.02 | 0.05 | 0.01 | 93.01 | 0.25 | |
YQ-C3 | 5.11 | 4.53 | 0.36 | 0.06 | 0.11 | 0.10 | 0.02 | 0.06 | 0.01 | 89.58 | 0.30 | |
YQ-C4 | 3.99 | 3.88 | 0.44 | 0.15 | 0.46 | 0.22 | 0.02 | 0.04 | 0.01 | 90.01 | 0.25 | |
YQ-C5 | 2.75 | 2.48 | 0.65 | 0.18 | 1.32 | 0.09 | 0.02 | 0.04 | 0.02 | 92.32 | 0.31 | |
YQ-C6 | 4.18 | 3.6 | 0.39 | 0.06 | 0.25 | 0.13 | 0.02 | 0.08 | 0.02 | 91.25 | 0.32 | |
YQ-C7 | 5.32 | 4.65 | 0.51 | 0.10 | 1.52 | 0.07 | 0.02 | 0.16 | 0.02 | 87.54 | 0.34 | |
YQ-C8 | 9.14 | 7.64 | 0.80 | 0.11 | 0.50 | 0.10 | 0.07 | 0.82 | 0.02 | 80.67 | 0.34 | |
YQ-Y2 | 56.64 | 23.28 | 1.14 | 0.54 | 0.40 | 0.14 | 1.92 | 0.78 | 0.04 | 15.04 | 0.87 | |
Average in coal | KZ | 6.48 | 5.35 | 0.74 | 0.11 | 1.15 | 0.10 | 0.06 | 0.16 | 0.05 | / | 0.39 |
LD | 4.50 | 3.70 | 0.66 | 0.11 | 1.79 | 0.07 | 0.05 | 0.15 | 0.01 | / | 0.40 | |
YQ | 4.76 | 4.18 | 0.58 | 0.11 | 0.59 | 0.10 | 0.03 | 0.16 | 0.02 | / | 0.30 |
Sample | La | Ce | Pr | Nd | Sm | Eu | Gd | Tb | Dy | Y | Ho | Er | Tm | Yb | Lu |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
KZ-C1 | 35.8 | 56.7 | 6.95 | 27 | 4.47 | 0.886 | 4.37 | 0.67 | 3.5 | 20 | 0.668 | 1.81 | 0.247 | 1.51 | 0.256 |
KZ-C2 | 24.8 | 46.9 | 5.74 | 21.4 | 3.96 | 0.742 | 3.36 | 0.57 | 3.06 | 13.5 | 0.596 | 1.67 | 0.241 | 1.6 | 0.271 |
KZ-C3 | 28.9 | 47.2 | 5.45 | 19.4 | 3.29 | 0.582 | 2.89 | 0.487 | 2.69 | 11.6 | 0.52 | 1.49 | 0.209 | 1.44 | 0.241 |
KZ-C4 | 11.5 | 20.5 | 2.32 | 8.38 | 1.47 | 0.259 | 1.4 | 0.235 | 1.28 | 7.31 | 0.256 | 0.676 | 0.097 | 0.595 | 0.097 |
KZ-C5 | 13 | 21.9 | 2.34 | 8.01 | 1.36 | 0.239 | 1.28 | 0.206 | 1.07 | 5.6 | 0.203 | 0.541 | 0.074 | 0.468 | 0.074 |
KZ-C6 | 14.6 | 24.7 | 2.68 | 9.18 | 1.59 | 0.283 | 1.47 | 0.252 | 1.44 | 7.05 | 0.278 | 0.777 | 0.109 | 0.749 | 0.121 |
KZ-C7 | 13.6 | 23.2 | 2.58 | 9.05 | 1.5 | 0.263 | 1.43 | 0.243 | 1.31 | 7.01 | 0.26 | 0.75 | 0.105 | 0.726 | 0.12 |
KZ-C8 | 10 | 17.6 | 1.98 | 6.94 | 1.21 | 0.178 | 1.13 | 0.189 | 1.02 | 5.22 | 0.194 | 0.542 | 0.074 | 0.461 | 0.073 |
KZ-C9 | 15 | 26.1 | 2.87 | 9.74 | 1.73 | 0.245 | 1.55 | 0.268 | 1.49 | 6.83 | 0.276 | 0.771 | 0.108 | 0.717 | 0.106 |
KZ-C10 | 10.8 | 23 | 2.89 | 10.7 | 2.34 | 0.448 | 2.24 | 0.425 | 2.48 | 16.1 | 0.504 | 1.36 | 0.176 | 0.995 | 0.158 |
KZ-Y1 | 65.6 | 112 | 13.7 | 53.1 | 9.54 | 1.91 | 8.49 | 1.41 | 7.58 | 37.3 | 1.51 | 4.29 | 0.615 | 4.1 | 0.682 |
LD-C1 | 7.41 | 14.7 | 1.91 | 7.5 | 1.53 | 0.364 | 1.46 | 0.253 | 1.43 | 9.03 | 0.288 | 0.75 | 0.101 | 0.627 | 0.1 |
LD-C2 | 9.46 | 15.6 | 1.73 | 6.07 | 1.14 | 0.206 | 1.12 | 0.196 | 1.11 | 5.71 | 0.209 | 0.566 | 0.075 | 0.463 | 0.075 |
LD-C3 | 11.2 | 18.8 | 2.08 | 7.22 | 1.36 | 0.242 | 1.32 | 0.239 | 1.4 | 6.73 | 0.263 | 0.7 | 0.1 | 0.624 | 0.097 |
LD-C4 | 10.5 | 17 | 1.87 | 6.54 | 1.14 | 0.211 | 1.12 | 0.189 | 1.04 | 5.07 | 0.196 | 0.543 | 0.075 | 0.491 | 0.077 |
LD-C5 | 11.7 | 20.3 | 2.29 | 8.2 | 1.48 | 0.289 | 1.44 | 0.252 | 1.38 | 7.22 | 0.267 | 0.736 | 0.108 | 0.681 | 0.108 |
LD-C6 | 21.4 | 37.9 | 4.16 | 14 | 2.49 | 0.492 | 2.5 | 0.4 | 2.23 | 11.2 | 0.424 | 1.13 | 0.163 | 0.975 | 0.148 |
LD-C7 | 11.3 | 19.9 | 2.24 | 7.83 | 1.42 | 0.29 | 1.38 | 0.24 | 1.33 | 6.92 | 0.268 | 0.711 | 0.105 | 0.657 | 0.099 |
LD-C8 | 17.2 | 29.2 | 3.3 | 11.7 | 2.02 | 0.386 | 1.89 | 0.307 | 1.7 | 9.47 | 0.334 | 0.965 | 0.144 | 0.938 | 0.151 |
LD-Y1 | 28.4 | 51.4 | 5.72 | 21 | 3.47 | 0.949 | 3.32 | 0.523 | 2.77 | 14.4 | 0.533 | 1.42 | 0.202 | 1.23 | 0.202 |
YQ-C1 | 8.71 | 18 | 2.2 | 8.47 | 1.76 | 0.383 | 1.69 | 0.309 | 1.85 | 11.1 | 0.386 | 1.09 | 0.162 | 1 | 0.161 |
YQ-C2 | 11.8 | 22.1 | 2.53 | 8.96 | 1.67 | 0.319 | 1.56 | 0.271 | 1.49 | 8.52 | 0.29 | 0.777 | 0.11 | 0.678 | 0.105 |
YQ-C3 | 10.6 | 17.8 | 2.04 | 7.12 | 1.33 | 0.231 | 1.23 | 0.218 | 1.22 | 6.61 | 0.236 | 0.635 | 0.093 | 0.602 | 0.086 |
YQ-C4 | 11 | 18.3 | 2.08 | 7.29 | 1.34 | 0.224 | 1.28 | 0.217 | 1.19 | 6.38 | 0.23 | 0.646 | 0.094 | 0.567 | 0.085 |
YQ-C5 | 7.81 | 13.6 | 1.58 | 5.6 | 1.04 | 0.181 | 1 | 0.177 | 0.997 | 5.51 | 0.2 | 0.522 | 0.085 | 0.5 | 0.079 |
YQ-C6 | 8.63 | 15.1 | 1.67 | 5.77 | 0.995 | 0.167 | 0.957 | 0.161 | 0.928 | 4.87 | 0.181 | 0.501 | 0.079 | 0.479 | 0.073 |
YQ-C7 | 8.82 | 14.4 | 1.56 | 5.25 | 0.941 | 0.17 | 0.902 | 0.158 | 0.896 | 4.39 | 0.173 | 0.475 | 0.072 | 0.463 | 0.072 |
YQ-C8 | 20.7 | 34.2 | 3.44 | 10.9 | 1.74 | 0.282 | 1.69 | 0.253 | 1.4 | 6.61 | 0.264 | 0.725 | 0.106 | 0.69 | 0.099 |
YQ-Y2 | 56 | 104 | 12.6 | 48.1 | 8.35 | 1.78 | 7.1 | 1.08 | 5.67 | 25.2 | 1.07 | 3.02 | 0.435 | 2.84 | 0.458 |
Mine | Sample | LaN | SmN | GdN | LuN | LaN/SmN | LaN/LuN | GdN/LuN |
---|---|---|---|---|---|---|---|---|
Kongzhuang | KZ-7-C1 | 151.05 | 29.22 | 21.27 | 10.08 | 5.17 | 14.99 | 2.11 |
KZ-7-C2 | 104.64 | 25.88 | 16.35 | 10.67 | 4.04 | 9.81 | 1.53 | |
KZ-7-C3 | 121.94 | 21.50 | 14.06 | 9.49 | 5.67 | 12.85 | 1.48 | |
KZ-7-C4 | 48.52 | 9.61 | 6.81 | 3.82 | 5.05 | 12.71 | 1.78 | |
KZ-7-C5 | 54.85 | 8.89 | 6.23 | 2.91 | 6.17 | 18.83 | 2.14 | |
KZ-7-C6 | 61.60 | 10.39 | 7.15 | 4.76 | 5.93 | 12.93 | 1.50 | |
KZ-7-C7 | 57.38 | 9.80 | 6.96 | 4.72 | 5.85 | 12.15 | 1.47 | |
KZ-7-C8 | 42.19 | 7.91 | 5.50 | 2.87 | 5.34 | 14.68 | 1.91 | |
KZ-7-C9 | 63.29 | 11.31 | 7.54 | 4.17 | 5.60 | 15.17 | 1.81 | |
KZ-7-C10 | 45.57 | 15.29 | 10.90 | 6.22 | 2.98 | 7.33 | 1.75 | |
KZ-D-Y1 | 276.79 | 62.35 | 41.31 | 26.85 | 4.44 | 10.31 | 1.54 | |
Longdong | LD-7-C1 | 31.27 | 10.00 | 7.10 | 3.94 | 3.13 | 7.94 | 1.80 |
LD-7-C2 | 39.92 | 7.45 | 5.45 | 2.95 | 5.36 | 13.52 | 1.85 | |
LD-7-C3 | 47.26 | 8.89 | 6.42 | 3.82 | 5.32 | 12.37 | 1.68 | |
LD-7-C4 | 44.30 | 7.45 | 5.45 | 3.03 | 5.95 | 14.61 | 1.80 | |
LD-7-C5 | 49.37 | 9.67 | 7.01 | 4.25 | 5.10 | 11.61 | 1.65 | |
LD-7-C6 | 90.30 | 16.27 | 12.17 | 5.83 | 5.55 | 15.50 | 2.09 | |
LD-7-C7 | 47.68 | 9.28 | 6.72 | 3.90 | 5.14 | 12.23 | 1.72 | |
LD-7-C8 | 72.57 | 13.20 | 9.20 | 5.94 | 5.50 | 12.21 | 1.55 | |
LD-D-Y1 | 119.83 | 22.68 | 16.16 | 7.95 | 5.28 | 15.07 | 2.03 | |
Yaoqiao | YQ-7-C1 | 36.75 | 11.50 | 8.22 | 6.34 | 3.19 | 5.80 | 1.30 |
YQ-7-C2 | 49.79 | 10.92 | 7.59 | 4.13 | 4.56 | 12.04 | 1.84 | |
YQ-7-C3 | 44.73 | 8.69 | 5.99 | 3.39 | 5.15 | 13.21 | 1.77 | |
YQ-7-C4 | 46.41 | 8.76 | 6.23 | 3.35 | 5.30 | 13.87 | 1.86 | |
YQ-7-C5 | 32.95 | 6.80 | 4.87 | 3.11 | 4.85 | 10.60 | 1.56 | |
YQ-7-C6 | 36.41 | 6.50 | 4.66 | 2.87 | 5.60 | 12.67 | 1.62 | |
YQ-7-C7 | 37.22 | 6.15 | 4.39 | 2.83 | 6.05 | 13.13 | 1.55 | |
YQ-7-C8 | 87.34 | 11.37 | 8.22 | 3.90 | 7.68 | 22.41 | 2.11 | |
YQ-D-Y2 | 236.29 | 54.58 | 34.55 | 18.03 | 4.33 | 13.10 | 1.92 |
Mine | Sample | 208Pb/204Pb | Std err | 207Pb/204Pb | Std err | 206Pb/204Pb | Std err | Δβ | Δγ |
---|---|---|---|---|---|---|---|---|---|
Kongzhuang | KZ-C1 | 38.435 | 0.005 | 15.604 | 0.002 | 18.496 | 0.002 | 18.604 | 35.481 |
KZ-C2 | 37.979 | 0.009 | 15.523 | 0.003 | 18.217 | 0.004 | 13.316 | 23.196 | |
KZ-C3 | 38.226 | 0.007 | 15.567 | 0.003 | 17.882 | 0.004 | 16.189 | 29.850 | |
KZ-C4 | 37.767 | 0.007 | 15.457 | 0.003 | 17.73 | 0.003 | 9.008 | 17.484 | |
KZ-C5 | 38.299 | 0.012 | 15.487 | 0.004 | 18.065 | 0.005 | 10.966 | 31.817 | |
KZ-C6 | 38.386 | 0.007 | 15.548 | 0.003 | 18.322 | 0.003 | 14.948 | 34.161 | |
KZ-C7 | 39.655 | 0.007 | 15.629 | 0.003 | 18.867 | 0.003 | 20.236 | 68.349 | |
KZ-C8 | 38.049 | 0.007 | 15.488 | 0.002 | 18.039 | 0.003 | 11.032 | 25.082 | |
KZ-C9 | 37.731 | 0.005 | 15.345 | 0.002 | 17.315 | 0.002 | 1.697 | 16.514 | |
KZ-C10 | 37.768 | 0.005 | 15.351 | 0.002 | 17.374 | 0.002 | 2.088 | 17.511 | |
KZ-Y1 | 38.391 | 0.006 | 15.513 | 0.002 | 18.116 | 0.003 | 12.664 | 34.296 | |
Longdong | LD-C1 | 38.281 | 0.013 | 15.583 | 0.005 | 18.26 | 0.006 | 17.233 | 31.332 |
LD-C2 | 38.764 | 0.015 | 15.559 | 0.004 | 18.526 | 0.005 | 15.666 | 44.345 | |
LD-C3 | 38.089 | 0.003 | 15.518 | 0.002 | 18.351 | 0.002 | 12.990 | 26.159 | |
LD-C4 | 38.347 | 0.004 | 15.508 | 0.002 | 18.15 | 0.002 | 12.337 | 33.110 | |
LD-C5 | 38.423 | 0.005 | 15.43 | 0.002 | 17.621 | 0.002 | 7.245 | 35.158 | |
LD-C6 | 38.607 | 0.007 | 15.547 | 0.002 | 18.469 | 0.003 | 14.883 | 40.115 | |
LD-C7 | 38.754 | 0.005 | 15.566 | 0.002 | 18.338 | 0.002 | 16.123 | 44.075 | |
LD-C8 | 38.271 | 0.003 | 15.56 | 0.001 | 18.35 | 0.001 | 15.732 | 31.063 | |
LD-Y1 | 37.602 | 0.005 | 15.438 | 0.002 | 17.251 | 0.002 | 7.768 | 13.039 | |
Yaoqiao | YQ-C1 | 38.165 | 0.008 | 15.545 | 0.003 | 18.256 | 0.003 | 14.752 | 28.207 |
YQ-C2 | 38.678 | 0.004 | 15.583 | 0.002 | 18.579 | 0.002 | 17.233 | 42.028 | |
YQ-C3 | 38.686 | 0.003 | 15.59 | 0.001 | 18.56 | 0.001 | 17.690 | 42.243 | |
YQ-C4 | 38.34 | 0.005 | 15.545 | 0.002 | 18.221 | 0.003 | 14.752 | 32.922 | |
YQ-C5 | 38.127 | 0.005 | 15.539 | 0.002 | 18.083 | 0.002 | 14.361 | 27.183 | |
YQ-C6 | 37.835 | 0.007 | 15.463 | 0.003 | 17.752 | 0.003 | 9.400 | 19.316 | |
YQ-C7 | 37.776 | 0.003 | 15.459 | 0.001 | 17.705 | 0.001 | 9.138 | 17.727 | |
YQ-C8 | 38.942 | 0.005 | 15.411 | 0.002 | 17.642 | 0.002 | 6.005 | 49.140 | |
YQ-Y2 | 38.339 | 0.009 | 15.574 | 0.003 | 17.834 | 0.003 | 16.645 | 32.895 |
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content. |
© 2024 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access article distributed under the terms and conditions of the Creative Commons Attribution (CC BY) license (https://creativecommons.org/licenses/by/4.0/).
Share and Cite
Meng, N.; Xiao, Q.; Li, W. Elemental Geochemistry and Pb Isotopic Compositions of the Thick No. 7 Coal Seam in the Datun Mining Area, China. Minerals 2024, 14, 848. https://doi.org/10.3390/min14080848
Meng N, Xiao Q, Li W. Elemental Geochemistry and Pb Isotopic Compositions of the Thick No. 7 Coal Seam in the Datun Mining Area, China. Minerals. 2024; 14(8):848. https://doi.org/10.3390/min14080848
Chicago/Turabian StyleMeng, Na, Qianlong Xiao, and Wu Li. 2024. "Elemental Geochemistry and Pb Isotopic Compositions of the Thick No. 7 Coal Seam in the Datun Mining Area, China" Minerals 14, no. 8: 848. https://doi.org/10.3390/min14080848
