The Fossil Record of Elateridae (Coleoptera: Elateroidea): Described Species, Current Problems and Future Prospects

Simple Summary

Beetle fossils play an important role in our understanding of the origin and evolutionary history of this insect order. Despite the recently increasing rate of fossil research focused on the click-beetles (Coleoptera: Elateridae), the major group in the superfamily Elateroidea, their palaeodiversity has still remained largely understudied. In this study, we summarized current knowledge on the click-beetle fossil record with a main emphasis on the described diversity. We compiled an annotated catalogue of all described fossil species in Elateridae, assessed the reliability of their systematic placement, and discuss the current state of knowledge and prospects of research of the fossil record in the group. This study should serve as a comprehensive basis for all subsequent research dealing with the origin, early evolution and diversity of Elateridae.

Abstract

The Elateridae (click-beetles) are the largest family in Elateroidea; however, their relationships, systematics and classification remain unclear. Our understanding of the origin, evolution, palaeodiversity and palaeobiogeography of Elateridae, as well as reconstruction of a reliable time-calibrated phylogeny for the group, are hampered by the lack of detailed knowledge of their fossil record. In this study, we summarize the current knowledge on all described fossil species in Elateridae, including their type material, geographic origin, age, bibliography and remarks on their systematic placement. Altogether, 261 fossil species classified in 99 genera and nine subfamilies are currently listed in this family. The Mesozoic click-beetle diversity includes 143 species, with most of them described from the Jurassic Karatau, and 118 described species are known from the Cenozoic deposits, mainly from the Eocene North American Florissant Formation and European Baltic amber. Available data on the described past diversity of Elateridae suggest that almost all fossil lineages in this group are in urgent need of revision and numerous Mesozoic species might belong to different families. Our study is intended to serve as a comprehensive basis for all subsequent research focused on the click-beetle fossil record.

1. Introduction

The click-beetles (Elateridae) are the major family in Elateroidea, comprising more than 10,000 described species worldwide [1]. Despite the efforts of numerous studies using morphological or molecular data, the classification and phylogenetic relationships within the family remain far from fully understood [2,3,4,5,6,7,8,9,10,11]. Taking this into consideration, further development of click-beetle systematics and understanding their evolution would certainly benefit from integrating modern molecular-based methods and morphology with fossils into a combined phylogenetic approach. While our knowledge on the systematics and diversity of recent click-beetle lineages has grown considerably in recent decades, their fossil record has been only scarcely investigated, lacking any comprehensive studies [12].

The first fossil elaterid species were reported and described during the mid-19th century from European localities [13,14,15,16]. Those were usually compression fossils ranging in their age from the Upper Triassic to Miocene. Later, several other species were added from Europe and the USA [17,18,19,20,21]. Scudder [22,23,24] summarized information on fossil Coleoptera of that time, including Elateridae. Lomnicki [25] described a new species from the Miocene of Ukraine. Handlirsch [26], in his monumental work “Die fossilen Insekten und die Phylogenie der rezenten Formen”, listed numerous fossil taxa in Elateridae, many of them of doubtful placement. Wickham [27,28] described the diversity of Elateridae in the Florissant deposit in Colorado, USA, and he later provided a checklist of all North American fossil beetles, including Elateridae [29]. Klebs [30] provided a checklist of elaterid genera found in Eocene North European Baltic amber. Cockerell published hundreds of papers on various taxa and fossil deposits, including several ones treating Elateridae from the Triassic of the United Kingdom [31], Burmese amber [32,33], the Eocene of the United Kingdom [34], the Paleocene of Argentina [35] or the Eocene of the USA [36]. Tillyard [37,38] and Dunstan [39] studied beetle fossils from Triassic deposits in Australia and attributed several taxa to Elateridae. Later authors continued in dealing with just a single or several species of Elateridae without any revision or a more comprehensive picture, including Ping [40] (a new monotypic genus from the Cretaceous of China), Wickham [41] (a single new species from the Eocene of the USA), Theobald [42] (a single species from the Oligocene of Germany), Piton [43] (two species from the Paleocene of France), Haupt [44] (a single species from the Eocene of Germany), Gardiner [45] (a new monotypic genus), and Becker [46] (one new genus and three new species from Miocene Mexican amber).

Iablokoff-Khnzorian [47] was the first author who provided a comprehensive revision of Elateridae in Baltic amber. In that study, he described seven genera, three subgenera and 11 species, which were also included in subsequent studies devoted to the Baltic amber [48,49]. Dolin [50] studied a Mesozoic fossil in Kyrgyzstan and described two monotypic genera which he classified in his newly established tribe Protagrypnini within Agrypninae. Later, he focused on the detailed examination of click-beetle fossils from the Jurassic deposit of Karatau, Kazakhstan. First, he elevated Protagrypnini to the subfamily level and defined three tribes in it, describing 15 species in three genera [51]. Later, he described eight species in four genera in the subfamilies Cardiophorinae and Negastriinae [52], and finally summarized the diversity of Elateridae as a whole from the Karatau deposit [53], with 107 species classified in 31 genera and five subfamilies known from that locality. Crowson [54] was the first who reported two undescribed elaterids from Cretaceous Lebanese amber. Particular attention was also paid to Chinese fossil deposits. Several click-beetles were reported from Jurassic [55,56], Cretaceous [57] and Miocene sediments [58,59]. Whalley [60] revised Jurassic insects of Dorset, England, including Elateridae, and Zaragoza-Caballero [61] descibed a new species from Mexican amber. Tröster [62,63,64,65,66,67] studied in detail Elateridae of the Eocene Grube Messel Pit and Eckfeldt Maar deposits in Germany, and focused mainly on the agrypnine genus Macropunctum Tröster, 1991. The comprehensive, illustrated catalogue “Treatise on Invertebrate Paleontology” by Carpenter [68] was an important contribution, in which he also included a list of fossil Elateridae, and placed many dubious taxa, especially those described by Handlirsch [26], as Coleoptera incertae sedis.

In the 21st century, Wappler [69] and Alekseev [70] described additional species of Eocene Macropunctum from Germany and the United Kingdom, respectively. Martins-Neto et al. [71] and Martins-Neto and Gallego [72] reported several putative elaterids from the Triassic fossil deposits in Argentina, Martin [73] described a new click-beetle species from the Jurassic of Australia, and Alekseev [74,75] and Sohn et al. [76] discovered new fossil click-beetles in the Cretaceous deposits in Russia and South Korea, respectively. In their revision of fossil Cerophytidae, Chang et al. [77] discovered that some taxa which Dolin [53] described in Elateridae are in fact cerophytids. However, the main attention regarding the fossil Elateridae in the 21st century was definitely paid to the Chinese Mesozoic deposits and inclusions in various ambers. Regarding the Elateridae fossils discovered in China, they belong either to Jurassic [78,79,80,81] or Cretaceous deposits [82,83,84,85,86] (for reviews, see [87,88,89]). Regarding click-beetles included in amber, their diversity in Miocene Mexican “Chiapas” amber, along with other insects, was summarized by Solórzano Kraemer [90]. Schimmel [91] described several new species of Megapenthini from North European Baltic amber. Alekseev [92] provided a checklist of beetles described from that amber, and later Kirejtshuk and Kovalev [93] added the first representative of Omalisidae (currently the elaterid subfamily Omalisinae [7]), and Kundrata et al. [94] described a new genus in the lissomine tribe Protelaterini. Kirejtshuk and Azar [95] reported several unnamed Elateridae from Cretaceous Lebanese amber. Otto [96] added a new genus from Cretaceous Burmese amber, which he classified in Pityobiinae.

A comprehensive online checklist of fossil beetles by Kirejtshuk and Ponomarenko [97] also covers Elateridae but requires some updates, including changes in classification. Oberprieler et al. [98] reported a possible elaterid fossil from the Upper Jurassic of Australia. Most recently, Kundrata et al. [12] compiled an updated comprehensive summary of the fossil genera in Elateridae, including their systematic placement and information on the type species, gender, number of species, age range, and relevant bibliography, and Muona et al. [99] revised the clicking Elateroidea from Chinese Mesozoic deposits, with several former click-beetle taxa transferred to Throscidae and Eucnemidae. This study is a follow up to the annotated catalogue of fossil genera in Elateridae [12]. Our understanding of the origin, evolution, palaeodiversity and palaeobiogeography of Elateridae, as well as the reconstruction of a reliable time-calibrated phylogeny for the group, are hampered by the lack of a detailed investigation of their known fossil record. Therefore, this study aims to summarize the current knowledge on all described fossil species in Elateridae, including their synonyms, misspellings, type material, geographic origin, age, bibliography and their systematic placement according to the most recent publications. It should serve as a comprehensive basis for all subsequent research dealing with a click-beetle fossil record, including the studies on the early evolution and diversity of Elateridae.

2. Materials and Methods

We compiled information on all fossil species in Elateridae. Inclusions in the Holocene copal sensu Solórzano Kraemer et al. [100] were not included in this study as they most probably represent recent species [101,102,103,104,105]. The higher classification of Elateridae follows Kundrata et al. [6,12]. The compositions of the subfamilies and tribes follow Johnson [106], Cate [107], Douglas [108], Kundrata et al. [12,94,109], and citations therein. We follow the style used in the first part of the World catalogue of the genus-group names in extant Elateridae [109] and the catalogue of the genus-group names in fossil Elateridae [12]. The names of the family, genus- and species-group taxa are given with the name of the author, and the year and page of publication. The page given is the page where the taxon name and description are printed. The year and page given for the incorrect subsequent spellings are the first year and page in which they are used. The detailed information for family group names is given in Bouchard et al. [110] and that for genus-group names (including synonyms, misspellings, unavailable names, type species and their designations) can be found in various publications and catalogues [12,107,109,111,112] and is not repeated here. Only generic misspellings and unavailable names which were not included in the catalogue of fossil genera [12] are reported here, and these are given under genus-names only and are not repeated under species-names. Misspellings and unavailable names are followed by colon “:”. For each fossil species in Elateridae, we provide all synonyms, information on the type series and type depositories, fossil deposit and age, and relevant bibliography. Information on the type depositories was taken from the original descriptions, the museum webpages, curators, or from the Paleobiology Database (https://paleobiodb.org/; accessed on 10 October 2020). Taxa marked with an asterisk (*) also contain recent species. The age of fossils was taken from the Paleobiology Database (https://paleobiodb.org/; accessed on 10 October 2020). Divisions of geological time and their boundaries follow the ICS International Chronostratigraphic Chart v. 2020/03 (http://www.stratigraphy.org/; accessed on 10 October 2020) [113]. We assessed each fossil species based on its original description and available illustrations to conclude whether its position in Elateridae and its generic attribution can be considered reliable or not. Most doubtful family or generic placements are discussed within the Remark section under the particular species. General information about species within the same genus are given in the Remark section under the particular genus. Proper taxonomic placement of listed fossil click-beetle lineages needs a detailed investigation of the type material which was far beyond the scope of this study, and hence the remarks on potential systematic misplacement of some taxa do not represent formal taxonomic decisions unless stated otherwise. An overview of the fossil Elateridae is summarized in Appendix A (

Table A1. Overview of fossil Elateridae. Genera marked with an asterisk (*) also contain recent species. Geographic origin includes country and formation when available. Period/Epoch: T, Triassic; J, Jurassic; C, Cretaceous; P, Paleocene; E, Eocene; O, Oligocene; M, Miocene.

Subfamily, Tribe, Genus	Species	Geographic Origin	Age (Ma), Period/Epoch
Agrypninae
Agrypnini
Adelocera Latreille, 1829 *	A. perantiqua Cockerell and LeVeque, 1931	USA: Green River	50.3–46.2 (E)
Ageratus Dolin, 1980	A. delicatus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	A. p onomarenkoi Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Agrypnus Eschscholtz, 1829 *	A. exhumatus (Wickham, 1916)	USA: Florissant	37.2–33.9 (E)
Compsoderus Dolin, 1980	C. priscus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Lacon Laporte, 1838 *	L. granulatus (Heer, 1847)	Germany: Upper Freshwater-Molasse	12.7–11.608 (M)
	L. jungi (Piton, 1940)	France: Menat	61.6–59.2 (P)
	L. primordialis Heer, 1847	Germany: Upper Freshwater-Molasse	12.7–11.608 (M)
Litholacon Dolin, 1980	L. conicicollis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. derumpens Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. exilis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. major Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. panphilovi Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. ohiri Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. petrorsus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Macropunctum Tröster, 1991	M. angulosum Tröster 1999	Germany: Messel	48.6–40.4 (E)
	M. angustiscutellum Tröster, 1994	Germany: Messel	48.6–40.4 (E)
	M. densipunctum Wappler, 2003	Germany: Eifel	48.6–40.4 (E)
	M. eckfeldi Tröster, 1992	Germany: Eifel	48.6–40.4 (E)
	M. eocaenicum (Meunier, 1921)	Germany: Messel	48.6–40.4 (E)
	M. latiscutellum Tröster	Germany: Messel	48.6–40.4 (E)
	M. messelense Tröster, 1991	Germany: Messel	48.6–40.4 (E)
	M. meunieri Tröster, 1991	Germany: Messel	48.6–40.4 (E)
	M. minutum (Meunier, 1921)	Germany: Messel	48.6–40.4 (E)
	M. promptum (Meunier, 1921)	Germany: Messel	48.6–40.4 (E)
	M. rebugense Tröster, 1994	Germany: Messel	48.6–40.4 (E)
	M. rossi Alekseev, 2019	United Kingdom: Bouldnor	38.0–33.9 (E)
	M. senckenbergi Tröster, 1994	Germany: Messel	48.6–40.4 (E)
Plagioraphes Iablokoff-Khnzorian, 1961	P. fasciatus Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Cryptocardiini
Cryptocardius Dolin, 1980	C. mirabilis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Hemirhipini
Alaus Eschscholtz, 1829 *	A. spectabilis (Heer, 1865)	Germany: Upper Freshwater-Molasse	12.7–11.608 (M)
Oophorini
Monocrepidius Eschscholtz, 1829 *	M. dubiosus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
Pseudomelanactini
Lanelater Arnett, 1952 *	L. nicoleae Wappler, 2003	Germany: Eifel	48.6–40.4 (E)
	L. verae Tröster, 1993	Germany: Messel	48.6–40.4 (E)
Pyrophorini
Eopyrophorus Haupt, 1950	E. mixtus Haupt, 1950	Germany: Geiseltal	47.8–41.3 (E)
Cardiophorinae
Cardiophorus Eschscholtz, 1829 *	C. braunii Heer, 1847	Germany: Upper Freshwater-Molasse	12.7–11.608 (M)
	C. cockerelli Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	C. deprivatus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	C. exhumatus Cockerell, 1926	USA: Green River	50.3–46.2 (E)
	C. florissantensis Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	C. lithographus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	C. requiescens Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	C. yatsenkokhmelevskyi Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Horistonotus Candèze, 1860 *	H. coloradensis Wickham, 1916	USA: Florissant	37.2–33.9 (E)
Dendrometrinae
Dendrometrini
Athous Eschscholtz, 1829 *
Subg. Athousiomorphus Iablokoff-Khnzorian, 1961	A. (A.) olgae Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Subg. incertae sedis	A. contusus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	A. fractus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	A. holmgreni (Heer, 1870)	Norway: Firkanten	66.0–59.2 (P)
	A. lethalis Wickham, 1916	USA: Florissant	37.2–33.9 (E)
Limonius Eschscholtz, 1829 *
Subg. Paralimonius Iablokoff-Khnzorian, 1961	L.(P.) barovskyi Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Subg. incertae sedis	L. aboriginalis Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	L. florissantensis Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	L. impunctus Scudder, 1895	Canada: Allenby	56.0–47.8 (E)
	L. optabilis Heer, 1847	Germany: Upper Freshwater-Molasse	12.7–11.608 (M)
	L. praecursor Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	L. shoshonis Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	L. volans Wickham, 1916	USA: Florissant	37.2–33.9 (E)
Dimini
Alaodima Dolin, 1980	A. grandis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Hypnoidini
Ligmargus Stibick, 1976 *	L. terrestris (Scudder, 1879)	Canada: Nicola river	56.0–47.8 (E)
Oxynopterini
Campsosternus Latreille, 1834 *	C. atavus Deichmüller, 1881	Czech Republic: Kučlín	37.2–33.9 (E)
Melanactes LeConte, 1853 *	M. cockerelli Wickham, 1908	USA: Florissant	37.2–33.9 (E)
Prosternini
Ctenicera Latreille, 1829 *	C. emblemoelytra (Zhang, 1989)	China: Shanwang	20.44–15.97 (M)
	C. euprepes (Zhang et al., 1994)	China: Shanwang	20.44–15.97 (M)
	C. granulicollis (Wickham, 1908)	USA: Florissant	37.2–33.9 (E)
	C. primitiva (Wickham, 1908)	USA: Florissant	37.2–33.9 (E)
	C. prophetica (Wickham, 1916)	USA: Florissant	37.2–33.9 (E)
	C. restructa (Wickham, 1916)	USA: Florissant	37.2–33.9 (E)
	C. sincera (Zhang et al., 1994)	China: Shanwang	20.44–15.97 (M)
	C. submersa (Wickham, 1916)	USA: Florissant	37.2–33.9 (E)
	C. sutor (Heer, 1847)	Germany: Upper Freshwater-Molasse	12.7–11.608 (M)
	C. velata (Scudder, 1876)	USA: Green River	50.3–46.2 (E)
Eanus LeConte, 1861 *	E. exanimatus (Wickham, 1916)	USA: Florissant	37.2–33.9 (E)
	E. heeri (Wickham, 1916)	USA: Florissant	37.2–33.9 (E)
	E. laevissimus (Wickham, 1916)	USA: Florissant	37.2–33.9 (E)
Oxygonus LeConte, 1863 *	O. mortuus Scudder, 1876	USA: Green River	50.3–46.2 (E)
	O. primus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
Selatosomini
Selatosomus Stephens, 1830 *	S. miegi Theobald, 1937	Germany: Middle Member	33.9–28.4 (O)
Semiotini
Semiotus Eschscholtz 1829 *	S. ehrenswaerdi (Heer, 1870)	Norway: Firkanten	66.0–59.2 (P)
	S. menatensis Piton, 1940	France: Menat	61.6–59.2 (P)
Elaterinae
Agriotini
Agriotes Eschscholtz, 1829 *	A. comminutus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	A. nearcticus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	A. succiniferus Becker, 1963	Mexico: Chiapas amber	23.03–15.97 (M)
Ampedini
Ampedus Dejean, 1833 *
Subg. Octamenogonoides Iablokoff-Khnzorian, 1961	A. (O.) gebleri Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Subg. Ampedus Dejean, 1833 *	A. seyfriedii Heer, 1847	Germany: Upper Freshwater-Molasse	12.7–11.608 (M)
Ischnodes Germar, 1844 *	I. gracilis Heer, 1847	Germany: Upper Freshwater-Molasse	12.7–11.608 (M)
Elaterini
Diaraphes Iablokoff-Khnzorian, 1961	D. kozhantshikovi Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Elater Linnaeus, 1758 *	E. asmodeus Zhang, 1989	China: Shanwang	20.44–15.97 (M)
	E. berryi Wickham, 1929	USA: Cockfield	41.3–38.0 (E)
	E. burmitinus Cockerell, 1917	Myanmar: Burmese amber	99.6–93.5 (C)
	E. canabinus Zhang, 1989	China: Shanwang	20.44–15.97 (M)
	E. florissantensis Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	E. mitrus Zhang, 1989	China: Shanwang	20.44–15.97 (M)
	E. naumanni Giebel, 1856	Europe: Baltic amber	38.0–33.9 (E)
	E. rohweri Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	E. scudderi Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	E. wisniowskii Lomnicki, 1902	Ukraine: Bashkev	13.65–12.7 (M)
Elatron Iablokoff-Khnzorian, 1961	E. semenovi Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Holopleurus Iablokoff-Khnzorian, 1961	H. succineus Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Orthoraphes Iablokoff-Khnzorian, 1961	O. reichardti Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Megapenthini
Abelater Fleutiaux, 1947 *	A. succineus Schimmel, 2005	Europe: Baltic amber	38.0–33.9 (E)
Megapenthes Kiesenwetter, 1858 *	M. groehni Schimmel, 2005	Europe: Baltic amber	38.0–33.9 (E)
	M. primaevus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	M. voigti Schimmel, 2005	Europe: Baltic amber	38.0–33.9 (E)
Physorhinini
Anchastus LeConte, 1853 *	A. diluvialis Wickham, 1916	USA: Florissant	37.2–33.9 (E)
	A. eruptus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
Synaptini
Glyphonyx Candèze, 1863 *	G. chiapasensis Zaragoza Caballero, 1990	Mexico: Chiapas amber	23.03–15.97 (M)
	G. punctatus Becker, 1963	Mexico: Chiapas amber	23.03–15.97 (M)
Elaterinaeincertae sedis
Crioraphes Iablokoff-Khnzorian, 1961	C. rohdendorfi Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Lissominae
Lissomini
Lissomus Dalman, 1824 *	L. taxodii (Heer, 1870)	Norway: Firkanten	66.0–59.2 (P)
Protelaterini
Baltelater Kundrata et al., 2020	B. bipectinatus Kundrata et al., 2020	Europe: Baltic amber	38.0–33.9 (E)
Negastriinae
Ganestrius Dolin, 1976	G. elongatus Dolin, 1976	Kazakhstan: Karabastau	166.1–157.3 (J)
	G. stibicki Dolin, 1976	Kazakhstan: Karabastau	166.1–157.3 (J)
Paradonus Stibick, 1971 *	Paradonus exterminatus (Wickham, 1916)	USA: Florissant	37.2–33.9 (E)
	Paradonus hesperus (Wickham, 1916)	USA: Florissant	37.2–33.9 (E)
Protoquasimus Dolin, 1976	P. brevicollis Dolin, 1976	Kazakhstan: Karabastau	166.1–157.3 (J)
Omalisinae
Jantarokrama Kirejtshuk and Kovalev, 2015	J. utilis Kirejtshuk and Kovalev, 2015	Europe: Baltic amber	38.0–33.9 (E)
Pityobiinae
Cretopityobius Otto, 2019	C. pankowskiorum Otto, 2019	Myanmar: Burmese amber	99.6–93.5 (C)
Protagrypninae
Desmatini
Desmatinus Chang et al., 2010	D. cognatus Chang et al., 2010	China: Yixian	125.45–122.46 (C)
Desmatus Dolin, 1975	D. affinis Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	D. beckeri Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	D. lapidarius Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	D. ponomarenkoi (Chang et al., 2009)	China: Jiulongshan	166.1–157.3 (J)
	D. protensus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Plesiorhaphes Dolin, 1980	P. scaber Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Hypnomorphini
Abrotus Dolin, 1980	A. reconditus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	A. sepultus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Adiagnostus Dolin, 1980	A. ambiguus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	A. cardiophorinus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	A. minutulus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Codemus Dolin, 1980	C. alatus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	C. carinatus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	C. jejunus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	C. martynovi Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	C. micros Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	C. quadricolis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	C. sharovi Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	C. synaptoides Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	C. teres Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	C. zherichini Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Dolinelater Huber et al., 2017	D. asperatus (Dolin, 1980)	Kazakhstan: Karabastau	166.1–157.3 (J)
	D. singularis (Dolin, 1980)	Kazakhstan: Karabastau	166.1–157.3 (J)
Elaterophanes Handlirsch, 1906	E. acutus Cockerell, 1916	United Kingdom: Wainlode Cliff	208.5–201.3 (T)
	E. regius Whalley, 1985	United Kingdom: Charmouth Mudstone	196.5–189.6 (J)
	E. vetustus (Brodie, 1845)	United Kingdom: Lilstock	208.5–201.3 (T)
Graciolacon Dolin, 1980	G. aeternus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Hypnomorphoides Dolin, 1980	H. angularis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. catachtonius Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. latus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. procerulus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Hypnomorphus Dolin, 1975	H. aemulus Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. angulosus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. carpolithus Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. confusus Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. curtus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. distinctus Dolin, 1975	Kazakhstan: Karabastau	164.7–155.7 (J)
	H. dubius Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. gigas Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. imperspicuus Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. induratus Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. inventus Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. minutus Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. rasnitzyni Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	H. rohdendorfi Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
Lapidiconides Dolin, 1980	L. brevis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. excellens Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. innatus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Lapidostenus Dolin, 1980	L. infossus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. insignis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. longicornis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. scutellaris Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. tarbinskyi Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Lithoptychus Dolin, 1980	L. carinatissimus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. handlirschi Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. incertus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. minutus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Lithosomus Dolin, 1980	L. erosus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. longicollis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Necrocoelus Dolin, 1980	N. aselloides Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Negastrioides Dolin, 1980	N. globicollis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	N. tenuicornis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	N. tenuis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	N. tscherepanovi Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Parahypnomorphus Dolin, 1980	P. jurassicus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	P. longicornis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	P. similis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Platyelater Dolin, 1980	P. figeratus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	P. quiescentus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	P. reflexicollis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	P. sukatschevae Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Pollostelaterini
Pollostelater Alekseev, 2011	P. baissensis Alekseev, 2011	Russia: Zaza	125.0–113.0 (C)
Protagrypnini
Acheonus Dolin, 1980	A. abbreviatus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	A. gracilis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	A. minutissimus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Clavelater Dong and Huang, 2011	C. ningchengensis Dong and Huang, 2011	China: Jiulongshan	166.1–157.3 (J)
Koreagrypnus Sohn and Nam, 2019	K. jinju Sohn and Nam, 2019	South Korea: Jinju	113.0–100.5 (C)
Lithocoelus Dolin, 1975	L. detrusus Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. karatavicus Dolin, 1975	Kazakhstan: Karabastau	166.1–157.3 (J)
Lithomerus Dolin, 1980	L. brachycollis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. brevicollis Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. buyssoni Dolin and Nel, 2002	China: Yixian	125.45–122.46 (C)
	L. cockerelli Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. contiguus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. longulus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	L. wunda Martin, 2010	Australia: Cattamarra Coal Measures	182.7–174.1 (J)
Megalithomerus Sohn and Nam, 2019	M. magohalmii Sohn and Nam, 2019	South Korea: Jinju	113.0–100.5 (C)
Micragrypnites Dolin, 1973	M. issykiensis Dolin, 1973	Kyrgyzstan: Dzhil	201.3–190.8 (J)
Paragrypnites Dolin, 1980	P. jagemanni Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Paraprotagrypnus Chang et al., 2009	P. superbus Chang et al., 2009	China: Jiulongshan	166.1–157.3 (J)
Protagrypnus Dolin, 1973	P. exoletus Dolin, 1973	Kyrgyzstan: Dzhil	201.3–190.8 (J)
	P. robustus Chang et al., 2009	China: Jiulongshan	166.1–157.3 (J)
Sinolithomerus Dong and Huang, 2009	S. dolini Dong and Huang, 2009	China: Haifanggou	166.1–157.3 (J)
Elateridaeincertae sedis
Adocetus Scudder, 1900	A. buprestoides Scudder, 1900	USA: Green River	55.8–50.3 (E)
Artinama Lin, 1986	A. qinghuoensis Lin, 1986	China: Zaoshang	199.3–190.8 (J)
Bilineariselater Chang and Ren, 2008	B. foveatus Chang and Ren, 2008	China: Yixian	125.45–122.46 (C)
Cretoelaterium Alekseev, 2008	C. kazanovense Alekseev, 2008	Russia: Mirsanovo	129.4–125.0 (C)
Cryptagriotes Wickham, 1916	C. minusculus Wickham, 1916	USA: Florissant	37.2–33.9 (E)
Cryptocoelus Dolin and Nel, 2002	C. baissensis Alekseev, 2011	Russia: Zaza	125.0–113.0 (C)
	C. buffoni Dolin and Nel, 2002	China: Yixian	125.45–122.46 (C)
	C. dolini Alekseev, 2011	Russia: Zaza	125.0–113.0 (C)
	C. gianteus Chang et al., 2007	China: Yixian	125.45–122.46 (C)
	C. lukashevichae Alekseev, 2011	Russia: Zaza	125.0–113.0 (C)
	C. major Dolin and Nel, 2002	China: Yixian	125.45–122.46 (C)
	C. shcherbakovi Alekseev, 2011	Russia: Zaza	125.0–113.0 (C)
	C. sinitshenkovae Alekseev, 2011	Russia: Zaza	125.0–113.0 (C)
Curtelater Chang and Ren, 2008	C. wui Chang and Ren, 2008	China: Yixian	125.45–122.46 (C)
Elateridium Tillyard, 1918	E. subulatum (Dunstan, 1923)	Australia: Blackstone	228.0–208.5 (T)
	E. transversum (Dunstan, 1923)	Australia: Blackstone	228.0–208.5 (T)
	E. wianamattense (Tillyard, 1916)	Australia: Ashfield Shales	247.2–242.0 (T)
Elaterites Heer, 1847	E. amissus Heer, 1847	Switzerland: Greith coal mine	28.4–23.03 (O)
	E. bruchi Cockerell, 1926	Argentina: Margas Verdes	66.0–56.0 (P)
	E. dicrepidioides Deichmüller, 1881	Czech Republic: Kučlín	37.2–33.9 (E)
	E. laconoides Cockerell, 1920	United Kingdom: Poole	47.8–41.3 (E)
	E. lavateri Heer, 1847	Germany: Upper Freshwater-Molasse	12.7–11.608 (M)
	E. longus Haupt, 1956	Germany: Geiseltal	47.8–41.3 (E)
	E. microstictus Cockerell, 1926	Argentina: Margas Verdes	66.0–56.0 (P)
	E. murchisoni (Giebel, 1856)	United Kingdom: Poole	47.8–41.3 (E)
	E. obsoletus Heer, 1847	Germany: Upper Freshwater-Molasse	12.7–11.608 (M)
	E. palaeophilus Cockerell, 1920	United Kingdom: Peckham	56.0–47.8 (E)
	E. perditulus Cockerell, 1920	United Kingdom: Poole	47.8–41.3 (E)
	E. sculptilis Cockerell, 1920	United Kingdom: Poole	47.8–41.3 (E)
Elaterium Westwood, 1854	E. bipunctatum Dunstan, 1923	Australia: Blackstone	228.0–208.5 (T)
	E. pronaeus Westwood, 1854	United Kingdom: Lulworth	145.0–140.2 (C)
Gripecolous Lin, 1986	G. enallus Lin, 1986	China: Shiti	170.3–168.3 (J)
Ludiophanes Wickham, 1916	L. haydeni Wickham, 1916	USA: Florissant	37.2–33.9 (E)
Mercata Lin, 1986	M. festira Lin, 1986	China: Shiti	170.3–168.3 (J)
Mionelater Becker, 1963	M. planatus Becker, 1963	Mexico: Chiapas amber	23.03–15.97 (M)
Ovivagina Zhang, 1997	O. longa Zhang, 1997	China: Badaowan	201.3–190.8 (J)
Paralithomerus Chang et al., 2008	P. exquisitus Chang et al., 2008	China: Yixian	125.45–122.46 (C)
	P. parallelus Chang et al., 2008	China: Yixian	125.45–122.46 (C)
Protocardiophorus Dolin, 1976	P. ancestralis Dolin, 1976	Kazakhstan: Karabastau	166.1–157.3 (J)
	P. jurassicus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
Pseudocardiophorites Dolin, 1976	P. angustatus Dolin, 1980	Kazakhstan: Karabastau	166.1–157.3 (J)
	P. fragilis Dolin, 1976	Kazakhstan: Karabastau	166.1–157.3 (J)
	P. hayeki Dolin, 1976	Kazakhstan: Karabastau	166.1–157.3 (J)
	P. infractus Dolin, 1976	Kazakhstan: Karabastau	166.1–157.3 (J)
	P. quadricollis Dolin, 1976	Kazakhstan: Karabastau	166.1–157.3 (J)
Silicernius Heyden, 1859	S. spectabilis Heyden, 1859	Germany: Rott	28.4–23.03 (O)
Sinoelaterium Ping, 1928	S. melanocolor Ping, 1928	China: Yixian	125.45–122.46 (C)
Tetraraphes Iablokoff-Khnzorian, 1961	T. ebersini Iablokoff-Khnzorian, 1961	Europe: Baltic amber	38.0–33.9 (E)
Turonelater Alekseev, 2011	T. giganteus Alekseev, 2011	Kazakhstan: Kzyl-Zhar	93.9–89.8 (C)
Genus incertae sedis	Acmaeodera burmitina Cockerell, 1917	Myanmar: Burmese amber	99.6–93.5 (C)

).

Abbreviations

Abbreviations for museums and collections:

BMNH	Natural History Museum, London, The United Kingdom
CNU	Key Laboratory of Insect Evolution and Environmental Changes, College of Life Science, Capital Normal University, Beijing, China
CUB	University of Colorado Museum of Natural History, Boulder, Colorado, USA
ETH	Swiss Federal Institute of Technology, Zurich, Switzerland
FIS	Forschungsstation Grube Messel of the Senckenberg Forschungsinstitut und Naturmuseum, Frankfurt am Main, Germany (= SMF)
GIH	Geologisches Institut Halle (Saale), Germany
GNUE	Gongju National University of Education, Gongju, South Korea
GPIBO	Steinmann Institute for Geology, Mineralogy and Palaeontology, University of Bonn, Germany
GPIUH	Geological-Paleontological Museum of the University of Hamburg, Germany
GSC	Geological Survey of Canada, Ottawa, Canada
HLMD	Hessisches Landesmuseum, Darmstadt, Germany
MCZ	Museum of Comparative Zoology, Harvard University, Cambridge, Massachusetts, USA
MNHN	Museum National d’Histoire Naturelle, Paris, France
NHMB	Naturhistorisches Museum, Basel, Switzerland
NHMM	Naturhistorisches Museum Mainz, Mainz, Germany
NIGP	Nanjing Institute of Geology and Palaeontology, Nanjing, China
PIN	Palaeontological Institute of the Russian Academy of Sciences, Moscow, Russia
QM	Queensland Museum, Brisbane, Australia
SGMS	Shandong Geological Museum, Jinan, Shandong, China
SMJS	Shandong Museum (= Shandong Provincial Museum), Jinan, Shandong, China
SMNH	Swedish Museum of Natural History (Naturhistoriska Riksmuseet), Stockholm, Sweden
SMNK	Staatliches Museum für Naturkunde Karlsruhe, Germany
SNAA	Stiftung Naturama Aargau, Aarau, Switzerland
UCMP	University of California Museum of Paleontology, Berkeley, California, USA
UNAM	Instituto de Biología, Universidad Nacional Autónoma de México, Mexico
USNM	Smithsonian Institution, National Museum of Natural History, Washington, D.C., USA
UZH	University of Zurich, Switzerland
WAM	Invertebrate Paleontology collection, Western Australian Museum, Australia
WIRC	Wisconsin Insect Research Collection, Department of Entomology at the University of Wisconsin, Madison, Wisconsin, USA
YPM	Yale Peabody Museum of Natural History, New Haven, Connecticut, USA
ZIN	Zoological Institute of Russian Academy of Sciences, St. Petersburg, Russia

3. Results

Family Elateridae Leach, 1815 *

Elaterides Leach, 1815: 85 [114]. Type genus: Elater Linnaeus, 1758: 404 [115]. For more information, including synonyms, see Bouchard et al. [110] and Kundrata et al. [109].

3.1. Subfamily Agrypninae Candèze, 1857 *

Agrypnides Candèze, 1857: 17 [116]. Type genus: Agrypnus Eschscholtz, 1829: 32 [117]. For more information, including synonyms, see Kundrata et al. [109].

3.1.1. Tribe Agrypnini Candèze, 1857 *

Agrypnides Candèze, 1857: 17 [116]. Type genus: Agrypnus Eschscholtz, 1829: 32 [117]. For more information, including synonyms, see Kundrata et al. [109].



• Genus Adelocera Latreille, 1829 *

Adelocera Latreille, 1829: 451 [118]. Type species: Elater ovalis Germar, 1823: 49 [119] (ICZN application needed). For more information, including synonyms, see Kundrata et al. [109].



Adelocera perantiqua Cockerell and LeVeque, 1931

Adelocera perantiqua Cockerell and LeVeque, 1931: 359 [36].

Type material. Holotype, sex unknown, compression fossil, No. 15,571 (CUB).

Fossil deposit/age. USA: Colorado, Green River Formation, Station 20, Roan Plateau; 50.3–46.2 Ma (Eocene).

Literature. Cockerell and LeVeque (1931: 359): original description [36].

Remark. According to the body proportions, shape of antenna and structure of thorax (e.g., pronotosternal sutures apparently closed, posterior angles of pronotum sharp and long, and prosternal process long, acute and with a tooth), this species does not belong neither to the currently defined genus Adelocera nor to the tribe Agrypnini. Based on the general habitus, long posterior angles of pronotum and marked elytra, it might be a member of Agrypninae: Oophorini. We prefer to postpone any taxonomic changes pending a comprehensive review including the type material.



• Genus Ageratus Dolin, 1980

Ageratus Dolin, 1980: 72 [53]. Type species: Ageratus ponomarenkoi Dolin, 1980: 73 [53]. For more information, see Kundrata et al. [12].

Remark. Type species of Ageratus is morphologically similar to the genera currently classified in Pseudomelanactini, and, therefore, the systematic position of this genus needs further examination.



Ageratus delicatus Dolin, 1980

Ageratus delicatus Dolin, 1980: 73 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2452/87 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Galkino; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 73): original description [53]; Korneev and Cate (2005: 14): checklist [120].

Remark. This species differs from the type species of Ageratus in the body proportions and smaller body size, relatively shorter and broader prothorax, and the presence of long sublateral carinae on pronotum. Based on these characters, A. delicatus reminds representatives of genera Agrypnus Eschscholtz, 1829 or Compsolacon Reitter, 1905.



Ageratus ponomarenkoi Dolin, 1980

Ageratus ponomarenkoi Dolin, 1980: 73 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 1739/35 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Galkino; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 73): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 9): checklist [120]; Kundrata et al. (2020: 5): generic catalogue [12].

Remark. This species is similar in the shape of antennae, the elongated prothorax with deep, fully excavated pronotosternal sutures, and the elongated elytra to genera Lanelater Arnett, 1952 and Anthracalaus Fairmaire, 1888 (Agrypninae: Pseudomelanactini). Its placement in Agrypnini should be re-evaluated.



• Genus Agrypnus Eschscholtz, 1829 *

Agrypnus Eschscholtz, 1829: 32 [117]. Type species: Elater murinus Linnaeus, 1758: 406 [115]. For more information, including synonyms, see Sánchez-Ruiz [121] and Kundrata et al. [109].



Agrypnus exhumatus (Wickham, 1916), comb. nov.

Lacon exhumatus Wickham, 1916: 501 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2776, No. 4456 in Scudder coll. (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 501): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. This species was originally compared with Lacon rectangularis (Say, 1825) [28], which has been currently classified in Agrypnus. Lacon exhumatus Wickham, 1916 morphologically fits to the genus Agrypnus sensu Hayek [122].



• Genus Compsoderus Dolin, 1980

Compsoderus Dolin, 1980: 71 [53]. Type species: Compsoderus priscus Dolin, 1980: 72 [53]. For more information, see Kundrata et al. [12].

Remark. This genus might represent Eucnemidae based on the habitus and shape of prothorax; however, the type specimen should be examined to find supporting characters as defined by Muona et al. [99].



Compsoderus priscus Dolin, 1980

Compsoderus priscus Dolin, 1980: 72 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2975 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 72): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 5): generic catalogue [12].



• Genus Lacon Laporte, 1838 *

Lacon Laporte, 1838: 11 [123]. Type species: Elater atomarius Fabricius, 1798: 139 [124] (=Elater punctatus Herbst, 1784: 110 [125]). For more information, including synonyms, see Kundrata et al. [109].



Lacon granulatus (Heer, 1847), comb. nov.

Adelocera granulata Heer, 1847: 139 [14].

Type material. Holotype, sex unknown, compression fossil (SNAA).

Fossil deposit/age. Germany: Upper Freshwater-Molasse Formation, Öhningen; 12.7–11.608 Ma (Miocene).

Literature. Heer (1847: 139): original description [14]; Giebel (1852: 651): catalogue [126]; Giebel (1856: 96): redescription [16]; Scudder (1891: 459): catalogue [24]; Handlirsch (1907: 743): catalogue [127]; Piton (1940: 179): remark [43].

Remark. Based on the generic diagnoses of Adelocera and Lacon by Hayek [122] (see also [111,128]), we transfer A. granulata to Lacon. However, this placement should be taken as tentative due to the absence of crucial diagnostic characters in the fossil.



Lacon jungi (Piton, 1940), comb. nov.

Adelocera jungi Piton, 1940: 178 [43].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 76 (MNHN).

Fossil deposit/age. France: Menat Formation, Menat; 61.6–59.2 Ma (Paleocene).

Literature. Piton (1940: 178): original description [43].

Remark. Based on the general habitus, the length and shape of antenna, and the shape of pronotum, we transfer A. jungi to Lacon. For the generic diagnoses of Adelocera and Lacon see Hayek [122].



Lacon primordialis Heer, 1847

Lacon primordialis Heer, 1847: 138 [14].

Type material. Holotype, sex unknown, compression fossil, No. 7887 (ETH).

Fossil deposit/age. Germany: Upper Freshwater-Molasse Formation, Öhningen; 12.7–11.608 Ma (Miocene).

Literature. Heer (1847: 138): original description [14]; Giebel (1852: 651): catalogue [126]; Giebel (1856: 96): redescription [16]; Scudder (1891: 544): catalogue [24]; Handlirsch (1907: 743): catalogue [127].

Remark. Based on the body proportions and the closed pronotosternal sutures, this species does not fit into the current diagnosis of neither the genus Lacon nor the tribe Agrypnini [122]. Superficially this species resembles Dendrometrinae sensu lato [6]. However, we prefer to postpone any taxonomic changes pending a comprehensive review including the type material.



• Genus Litholacon Dolin, 1980

Litholacon Dolin, 1980: 67 [53]. Type species: Litholacon derumpens Dolin, 1980: 68 [53]. For more information, see Kundrata et al. [12].

Remark. This genus is in a need of revision since some species strongly differ from the type species (and also from each other) in various diagnostic characters, e.g., the body proportions and shapes of antenna, prothorax and elytra. Several species, especially those with closed pronotosternal sutures, which is a character typical for Agrypnini, resemble representatives of Negastriinae or Dendrometrinae: Hypnoidini. However, many species of this genus, if not all, might be in fact Eucnemidae, which is suggested by their rather short and broad thorax (in some species with furrowed pronotosternal sutures), short and broad prosternal process, compact elytra, and the shape of antenna.



Litholacon conicicollis Dolin, 1980

Litholacon conicicollis Dolin, 1980: 70 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2784/1371 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 70): original description [53]; Korneev and Cate (2005: 14): checklist [120].

Remark. Pronotosternal sutures of this species are closed (Figure 76 in [53]) which does not correspond neither with the diagnosis of genus Litholacon nor with Agrypnini.



Litholacon derumpens Dolin, 1980

Litholacon derumpens Dolin, 1980: 67/68 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/699 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 68): original description [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 5): generic catalogue [12].

Remark. This species was designated as the type species of Litholacon ([53], p. 67) and the concept of the species is clear from Figure 72 (without a page number), with the legend as follows: “Litholacon derumpens Dolin, sp. nov., holotype Nr. 2554/699”. Dolin obviously described L. derumpens on page 68 (based on the holotype number and reference to Figure 72) but under the name L. panphilovi, which he used also for the other species on the same page.



Litholacon exilis Dolin, 1980

Litholacon exilis Dolin, 1980: 71 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/2005 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 71): original description [53]; Korneev and Cate (2005: 15): checklist [120].

Remark. Pronotosternal sutures of this species are closed (Figure 78 in [53]) which does not correspond neither with the diagnosis of genus Litholacon nor with Agrypnini. The systematic placement of this species requires further study.



Litholacon major Dolin, 1980

Litholacon major Dolin, 1980: 71 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1452 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 71): original description [53]; Korneev and Cate (2005: 19): checklist [120].



Litholacon panphilovi Dolin, 1980

Litholacon panphilovi Dolin, 1980: 68 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2400 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2239/1407.

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 68): original description [53]; Korneev and Cate (2005: 21): checklist [120].



Litholacon ohiri Dolin, 1980

Litholacon ohiri Dolin, 1980: 69 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/420 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 69): original description [53]; Korneev and Cate (2005: 21): checklist [120].

Remark. Pronotosternal sutures of this species are closed (Figure 74 in [53]) which does not correspond neither with the diagnosis of genus Litholacon nor with Agrypnini. The systematic placement of this species requires further study.



Litholacon petrorsus Dolin, 1980

Litholacon petrorsus Dolin, 1980: 69 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2456 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 69): original description [53]; Korneev and Cate (2005: 21): checklist [120].



• Genus Macropunctum Tröster, 1991

Macropunctum Tröster, 1991: 100 [62]. Type species: Macropunctum messelense Tröster, 1991: 106 [62]. For more information, see Kundrata et al. [12].

Remark. This genus is similar in the body proportions and the structure of thorax and elytra to the Nearctic Agrypnus rectangularis (Say, 1825) and related species (previously assigned under a separate genus Colaulon Arnett, 1952). The relationships between these groups require more detailed examination.



Macropunctum angulosum Tröster, 1999

Macropunctum angulosum Tröster 1999: 13 [67].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, SMF MeI 4120 (FIS). Two paratypes, exoskeletons, compression fossils, sex unknown, SMF MeI 381, 796 (FIS).

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit (type locality: E10, 3.52–3.66 below alpha); 48.6–40.4 Ma (Eocene).

Literature. Tröster (1999: 13): original description [67]; Wappler (2003: 88): revision [69].



Macropunctum angustiscutellum Tröster, 1994

Macropunctum angustiscutellum Tröster, 1994: 154 [66].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, SMF MeI 2571 (FIS). 10 paratypes, sex unknown, exoskeletons, compression fossils, SMF MeI 637, 3357, 233, 253, 373, 794, 1109, 2262, 163 (originally as a paratype of M. messelense), 271 (originally as a paratype of M. messelense) (FIS).

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit (type locality: E9, 0.43–0.97 m above alpha); 48.6–40.4 Ma (Eocene).

Literature. Tröster (1994: 154): original description [66]; Wappler (2003: 89): revision [69].



Macropunctum densipunctum Wappler, 2003

Macropunctum densipunctum Wappler, 2003: 87 [69].

Macropunctum densepunctum: Kirejtshuk et al., 2019: 48 [70] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, exoskeleton, PE_2000/955, LS (NHMM). Paratype, sex unknown, exoskeleton, abdomen, PE_2000/744 a+b, LS (NHMM).

Fossil deposit/age. Germany: Eifel Formation, Eckfeld Maar; 48.6–40.4 Ma (Eocene).

Literature. Wappler (2003: 87): original description [69]; Kirejtshuk et al. (2019: 48): remark [70].



Macropunctum eckfeldi Tröster, 1992

Macropunctum eckfeldi Tröster, 1992: 114 [63].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, PE 1990/974-LS (NHMM).

Fossil deposit/age. Germany: Eifel Formation, Eckfeld Maar; 48.6–40.4 Ma (Eocene).

Literature. Tröster (1992: 114): original description [63]; Wappler (2003: 89): revision [69].



Macropunctum eocaenicum (Meunier, 1921)

Ancylochira eocaenica Meunier, 1921: 7 [130].

Macropunctum eocaenicum: Tröster, 1991: 102 [62].

Type material. Lectotype, sex unknown, exoskeleton, compression fossil, HLMD Me 1082 (HLMD). Nine paralectotypes, sex unknown, exoskeletons, compression fossils, HLMD 937, 1225, 1338, 593, 1182, 4090, 1393, 925, 927 (HLMD).

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit; 48.6–40.4 Ma (Eocene).

Literature. Meunier (1921: 7): original description [130]; Tröster (1991: 102): revision [62]; Tröster (1994: 148): remark [66]; Wappler (2003: 89): revision [69]; Schimmel (2005: 27): remark [91]; Schimmel and Tarnawski (2010: 363): remark [131]; Schimmel and Tarnawski (2012: 265): remark [132].



Macropunctum latiscutellum Tröster, 1994

Macropunctum latiscutellum Tröster, 1994: 151 [66].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, SMF MeI 628 (originally as a paratype of M. messelense) (FIS). 13 paratypes, sex unknown, exoskeletons, compression fossils, SMF MeI 696 (originally as a paratype of M. messelense), 2671, 5, 14, 230, 244, 256, 627, 1055, 1399, 2591, 2882, 3411 (FIS).

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit (type locality: F11, 1.0 m above alpha); 48.6–40.4 Ma (Eocene).

Literature. Tröster (1994: 151): original description [66].



Macropunctum messelense Tröster, 1991

Macropunctum messelense Tröster, 1991: 106 [62].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, SMF MeI 2392 (FIS). 10 paratypes, sex unknown, exoskeletons, compression fossils, SMF MeI 675, 2293, 8, 760, 911, 1103, 1132, 1351, 2487, 2490 (FIS).

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit (type locality: E11, 5.06–5.71 m below alpha); 48.6–40.4 Ma (Eocene).

Literature. Tröster (1991: 106): original description [62]; Tröster (1994: 148): remark [66]; Tröster (1999: 13): remark [67]; Wappler (2003: 89): revision [69]; Kirejtshuk et al. (2019: 48): remark [70]; Kundrata et al. (2020: 5): generic catalogue [12].



Macropunctum meunieri Tröster, 1991

Macropunctum meunieri Tröster, 1991: 112 [62].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, SMF MeI 2627 (FIS). Four paratypes, sex unknown, exoskeletons, compression fossils, SMF MeI 430, 536, 669, 2136 (FIS).

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit (type locality: grid square i8, 0.26–1.29 m above alpha); 48.6–40.4 Ma (Eocene).

Literature. Tröster (1991: 112): original description [62]; Wappler (2003: 89): revision [69].



Macropunctum minutum (Meunier, 1921)

Ancylochira minuta Meunier, 1921: 8 [130].

Macropunctum minutum: Tröster, 1994: 160 [66].

Type material. Lectotype, sex unknown, exoskeleton, compression fossil, HLMD Me 1206. (HLMD). Two paralectotypes reported by Tröster [66], sex unknown, exoskeletons, compression fossils, HLMD Me 1276 and 1124 (HLMD). Additional 12 specimens listed in the original description (988, 877, 1087, 1261, 1227, 1263, 1229, 1140, 1077, 1226, 4142, 648) [130].

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit; 48.6–40.4 Ma (Eocene).

Literature. Meunier (1921: 8): original description [130]; Tröster (1994: 160): remark, nomenclature [66].



Macropunctum promptum (Meunier, 1921)

Ancylochira prompta Meunier, 1921: 8 [130].

Macropunctum promptum: Tröster, 1991: 105 [62].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, HMLD Me 1003 (HLMD). Eight paratypes, sex unknown, exoskeletons, compression fossils, HMLD Me 755, 1330, 650, 1093, 809, 932, 1184, 952 (HLMD). Both Meunier [130] and Tröster [62] listed nine paratypes but No. 650 was mentioned twice.

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit; 48.6–40.4 Ma (Eocene).

Literature. Meunier (1921: 8): original description [130]; Tröster (1991: 105): remark [62], Tröster (1994: 160): remark [66].



Macropunctum rebugense Tröster, 1994

Macropunctum rebugense Tröster, 1994: 158 [66].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, SMF MeI 1145 (FIS). Three paratypes, sex unknown, exoskeletons, compression fossils, SMF MeI 143, 699, and 3474 (FIS).

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit (type locality: 5, E15, 1 m below to 2 m above alpha); 48.6–40.4 Ma (Eocene).

Literature. Tröster (1994: 158): original description [66]; Wappler (2003: 89): revision [69].



Macropunctum rossi Alekseev, 2019

Macropunctum rossi Alekseev in Kirejtshuk et al., 2019: 48 [70].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, NHMUK I.10085 (BMNH).

Fossil deposit. United Kingdom: England, Isle of Wight, Bouldnor Formation, Bembridge Marls; 38.0–33.9 Ma (Eocene).

Literature. Kirejtshuk et al. (2019: 48): original description [70].



Macropunctum senckenbergi Tröster, 1994

Macropunctum senckenbergi Tröster, 1994: 148 [66].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, SMF MeI 297 (FIS). Four paratypes, sex unknown, exoskeletons, compression fossils, SMF MeI 672, 2549, 3225, 3232 (FIS).

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit (type locality: grid square F11, 1.0 m above alpha); 48.6–40.4 Ma (Eocene).

Literature. Tröster (1991: 104): description, without formal name [62]; Tröster (1994: 148): original description [66]; Wappler (2003: 89): revision [69].



• Genus Plagioraphes Iablokoff-Khnzorian, 1961

Plagioraphes Iablokoff-Khnzorian, 1961: 84 [47]. Type species: Plagioraphes fasciatus Iablokoff-Khnzorian, 1961. For more information, see Kundrata et al. [12].



Plagioraphes fasciatus Iablokoff-Khnzorian, 1961

Plagioraphes fasciatus Iablokoff-Khnzorian, 1961: 85 [47].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 364/346 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 85): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 49): catalogue [49]; Keilbach (1982: 246): catalogue [133]; Carpenter (1992: 305): generic catalogue [68]; Alekseev (2013: 7): checklist [92]; Kundrata et al. (2020: 5): generic catalogue [12].

3.1.2. Tribe Cryptocardiini Dolin, 1980

Cryptocardiini Dolin, 1980: 74 [53]. Type genus: Cryptocardius Dolin, 1980: 74 [53].

Remark. This group most probably does not belong to Agrypninae. Dolin [53] compared Cryptocardiini with Oophorini due to similar habitus, closed pronotosternal sutures, and structure of prosternum (without further details). He wrote that Cryptocardiini differ from Oophorini in the narrowed mesoventrite, less broadened metacoxal plates, and simple tarsi. However, Dolin [53] mentioned that the shape of antennae (i.e., antennomeres being shortened from antennomere VI to apex) and the cordate scutellar shield of Cryptocardius are not typical for Agrypninae at all. Drawings of Cryptocardius in Dolin [53] show that this click-beetle has enlarged pronotum which is sinuate near posterior angles, and has short basal furrows. Additionally, there is a short incision near basal furrow on the posterior angle of pronotum. These characters suggest that Cryptocardius might have been related to Hypnoidini.



• Genus Cryptocardius Dolin, 1980

Cryptocardius Dolin, 1980: 74 [53]. Type species: Cryptocardius mirabilis Dolin, 1980: 75 [53]. For more information, see Kundrata et al. [12].



Cryptocardius mirabilis Dolin, 1980

Cryptocardius mirabilis Dolin, 1980: 75 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/649 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 75): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Alekseev (2011: 423): checklist [75]; Kundrata et al. (2020: 6): generic catalogue [12].

3.1.3. Tribe Hemirhipini Candèze, 1857 *

Hémirhipides Candèze, 1857: 199 [116]. Type genus: Hemirhipus Berthold, 1827: 336 [134]. For more information, including synonyms, see Kundrata et al. [109].



• Genus Alaus Eschscholtz, 1829 *

Alaus Eschscholtz, 1829: 33 [117]. Type species: Elater oculatus Linnaeus, 1758: 404 [115]. For more information, including synonyms, see Kundrata et al. [109].



Alaus spectabilis (Heer, 1865)

Elater (Alaus) spectabilis Heer, 1865: 378 [17].

Alaus spectabilis: Handlirsch, 1907: 744 [127].

Type material. Holotype, sex unknown, compression fossil (UZH).

Fossil deposit/age. Germany: Upper Freshwater-Molasse Formation, Öhningen; 12.7–11.608 Ma (Miocene).

Literature. Heer (1865: 378): original description, figure [17]; Heer (1870: 75): remark [18]; Heer (1872: 463): remark [135]; Heer (1876: 34): remark [136]; Heer (1883: 404): figure [137]; Scudder (1891: 518): catalogue [24]; Handlirsch (1907: 744): catalogue [127].

3.1.4. Tribe Oophorini Gistel, 1848 *

Oophoridae Gistel, 1848: 5 [138]. Type genus: Oophorus Dejean, 1833: 93 [139] (syn. of Aeolus Eschscholtz, 1829: 33 [117]). For more information, including synonyms, see Kundrata et al. [109].



• Genus Monocrepidius Eschscholtz, 1829 *

Monocrepidius Eschscholtz, 1829: 31 [117]. Type species: Monocrepidius pallipes Eschscholtz, 1829: 32 [117]. For more information, including synonyms, see Kundrata et al. [109].



Monocrepidius dubiosus Wickham, 1916

Monocrepidius dubiosus Wickham, 1916: 508 [28].

Type material. Holotype, sex unknown, compression fossil, No. 90,483 (USNM).

Fossil deposit/age. USA: Colorado, Florissant Formation, Wilson Ranch; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 508): original description [28]; Wickham (1920: 354): catalogue [29].

3.1.5. Tribe Pseudomelanactini Arnett, 1967 *

Pseudomelanactini Arnett, 1967: 111 [140]. Type genus: Pseudomelanactes Mathieu, 1961: 474 [141] (synonym of Anthracalaus Fairmaire, 1888: 349 [142]).



• Genus Lanelater Arnett, 1952 *

Lanelater Arnett, 1952: 105 [143]. Type species: Agrypnus schotti LeConte, 1853: 492 [144]. For more information, including synonyms, see Kundrata et al. [109].



Lanelater nicoleae Wappler, 2003

Lanelater nicoleae Wappler, 2003: 90 [69].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, PE_2000/349 a+b LS (NHMM). Three paratypes, sex unknown, exoskeletons, compression fossils, PE_1994/79 a+b, LS, PE_1993/256 a+b, LS, PE_1992/79, LS (NHMM).

Fossil deposit/age. Germany: Eifel Formation, Eckfeld Maar; 48.6–40.4 Ma (Eocene).

Literature. Wappler (2003: 90): original description [69].



Lanelater verae Tröster, 1993

Lanelater verae Tröster, 1993: 51 [64].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, SMF MeI 3735 (FIS). Five paratypes, sex unknown, exoskeletons, compression fossils, SMF MeI 1384, SMF MeI 1969, SMF MeI 1593, SMF MeI 1978, SMF MeI 226 (FIS).

Fossil deposit/age. Germany: Messel Formation, Grube Messel Pit (type locality: grid square H12, 0.00–0.26 m below horizon M); 48.6–40.4 Ma (Eocene).

Literature. Tröster (1993: 51): original description [64]; Wappler (2003: 92): remark [69].

3.1.6. Tribe Pyrophorini Candèze, 1863 *

Pyrophorites Candèze, 1863: 3 [145]. Type genus: Pyrophorus Billberg, 1820: 20 [146]. For more information, including synonyms, see Kundrata et al. [109].



• Genus Eopyrophorus Haupt, 1950

Eopyrophorus Haupt, 1950: 101 [44]. Type species: Eopyrophorus mixtus Haupt, 1950: 107 [44]. For more information, see Kundrata et al. [12].

Remark. Although this genus might indeed belong to Pyrophorini, its placement needs further examination since important tribal characters were not discussed by Haupt [44].



Eopyrophorus mixtus Haupt, 1950

Eopyrophorus mixtus Haupt, 1950: 107 [44].

Type material. Type, sex unknown, compression fossil (GIH).

Fossil deposit/age. Germany: Geiseltal; 47.8–41.3 Ma (Eocene).

Literature. Haupt (1950: 107): original description [44]; Haupt (1956: 48): catalogue [147]; Carpenter (1992: 304): generic catalogue [68]; Kundrata et al. (2020: 6): generic catalogue [12].

3.2. Subfamily Cardiophorinae Candèze, 1859 *

Cardiophorites Candèze, 1859: 4 [148]. Type genus: Cardiophorus Eschscholtz, 1829: 34 [117]. For more information, including synonyms, see Bouchard et al. [110] and Douglas [108].

Remark. Type material of most species should be examined in order to confirm their placement in Cardiophorinae. Some species may represent Negastriinae. Considering the current limits and diagnoses of cardiophorine genera, it is impossible for most species to assign them to a proper genus based on available characters [108].



• Genus Cardiophorus Eschscholtz, 1829 *

Cardiophorus Eschscholtz, 1829: 34 [117]. Type species: Elater thoracicus Fabricius, 1801: 236 [149] (synonym of Cardiophorus gramineus (Scopoli, 1763: 95) [150]). For more information, see Douglas [108].



Cardiophorus braunii Heer, 1847

Cardiophorus braunii Heer, 1847: 134 [14].

Cardiophorus brauni: Giebel (1852: 651) [126] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.4].

Type material. Holotype, sex unknown, compression fossil (SMNK).

Fossil deposit/age. Germany: Upper Freshwater-Molasse Formation, Öhningen; 12.7–11.608 Ma (Miocene).

Literature. Heer (1847: 134): original description [14]; Giebel (1852: 651): catalogue [126]; Giebel (1856: 97): redescription [16]; Scudder (1891: 486): catalogue [24]; Handlirsch (1907: 746): catalogue [127]; Cockerell (1926: 10): comparison with other species [35].



Cardiophorus cockerelli Wickham, 1916

Cardiophorus cockerelli Wickham, 1916: 503 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2765 (=1916 Scudder coll.) (MCZ).

Fossil deposit. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 503): original description [28]; Wickham (1920: 354): catalogue [29].



Cardiophorus deprivatus Wickham, 1916

Cardiophorus deprivatus Wickham, 1916: 504 [28].

Type material. Holotype, sex unknown, compression fossil, No. 8206 (99/127) (CUB).

Fossil deposit/age. USA: Colorado, Florissant Formation, Chadronian, Station 13; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 504): original description [28]; Wickham (1920: 354): catalogue [29].



Cardiophorus exhumatus Cockerell, 1926

Cardiophorus exhumatus Cockerell, 1926: 9 [35].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 69614 (USNM).

Fossil deposit/age. USA: Colorado, Green River Formation, head of East Alkali Creek, approximately 8 miles south of De Beque; 50.3–46.2 Ma (Eocene).

Literature. Cockerell (1926: 9): original description [35]; Wickham (1927: 55): catalogue [151].



Cardiophorus florissantensis Wickham, 1916

Cardiophorus florissantensis Wickham, 1916: 502 [28].

Type material. Holotype, sex unknown, compression fossil, No. 8205 (CUB).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant, Station 13; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 502): original description [28]; Wickham (1920: 354): catalogue [29].



Cardiophorus lithographus Wickham, 1916

Cardiophorus lithographus Wickham, 1916: 501 [28].

Type material. Holotype, sex unknown, compression fossil, 90,611 (USNM).

Fossil deposit/age. USA: Colorado, Florissant Formation, Wilson Ranch; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 401): original description [28]; Cockerell (1926: 10): comparison with other species [29].



Cardiophorus requiescens Wickham, 1916

Cardiophorus requiescens Wickham, 1916: 504 [28].

Type material. Holotype, sex unknown, compression fossil, 90,612 (USNM).

Fossil deposit/age. USA: Colorado, Florissant Formation, Wilson Ranch; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 504): original description [28]; Wickham (1920: 354): catalogue [29].



Cardiophorus yatsenkokhmelevskyi Iablokoff-Khnzorian, 1961

Cardiophorus yatsenkokhmelevskyi Iablokoff-Khnzorian, 1961: 94 [47].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 364/656 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 94): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 46): catalogue [49]; Keilbach (1982: 246): catalogue [133]; Hawkeswood et al. (2009: 189): catalogue [105]; Alekseev (2013: 7): checklist [92].



• Genus Horistonotus Candèze, 1860 *

Horistonotus Candèze, 1860: 243 [152]. Type species: Horistonotus flavidus Candèze, 1860: 250 [152]. For more information, see Douglas [108].



Horistonotus coloradensis Wickham, 1916

Horistonotus coloradensis Wickham, 1916: 505 [28].

Type material. Holotype, sex unknown, compression fossil, No. 90,547 (USNM).

Fossil deposit/age. USA: Colorado, Florissant Formation; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 505): original description [28]; Wickham (1920: 354): catalogue [29].

3.3. Subfamily Dendrometrinae Gistel, 1848 *

Dendrometridae Gistel, 1848: 5 [138]. Type genus: Dendrometrus Gistel, 1848: 5 [138]. For more information, including synonyms, see Bouchard et al. [110].

3.3.1. Tribe Dendrometrini Gistel, 1848 *

Dendrometridae Gistel, 1848: 5 [138]. Type genus: Dendrometrus Gistel, 1848: 5 [138]. For more information, including synonyms, see Bouchard et al. [110].



• Genus Athous Eschscholtz, 1829 *

Athous Eschscholtz, 1829: 33 [117]. Type species: Elater vittatus Fabricius, 1792: 224 [153]. For more information, including synonyms, see Sánchez-Ruiz [121] and Cate [107].



Subgenus Athousiomorphus Iablokoff-Khnzorian, 1961

Athousiomorphus Iablokoff-Khnzorian, 1961: 92 [47]. Type species: Athous (Athousiomorphus) olgae Iablokoff-Khnzorian, 1961: 92 [47]. For more information, see Kundrata et al. [12].



Athous (Athousiomorphus) olgae Iablokoff-Khnzorian, 1961

Athous (Athousiomorphus) olgae Iablokoff-Khnzorian, 1961: 92 [47].

Athous olgae Larsson, 1978: 153 [48].

Type material. Holotype, male, exoskeleton, amber inclusion, No. 364/655 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 92): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 46): catalogue [49]; Keilbach (1982: 246): catalogue [133]; Schimmel (2005: 27): remark [91]; Alekseev (2013: 7): checklist [92]; Kundrata et al. (2020: 7): generic catalogue [12].



Subgenus incertae sedis



Athous contusus Wickham, 1916

Athous contusus Wickham, 1916: 519 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2727 (=8346 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 519): original description [28]; Wickham (1920: 354): catalogue [29].



Athous fractus Wickham, 1916

Athous fractus Wickham, 1916: 519 [28].

Type material. Holotype, sex unknown, compression fossil, No. 8240 (CUB).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant, Station 14; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 519): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. Based on the body size, general habitus, structure of antenna and thorax, this species might belong to Prosternini or Selatosomini. Most striking character which challenges the position of this species in Athous is the pronotum, which is rather broad, more or less rounded at sides and sinuate near posterior angles (usually parallel sided and rather narrowed in Athous), and with each posterior angle bearing a sublateral carina (not typical for Athous). We prefer to postpone any taxonomic changes pending a comprehensive review including the type material.



Athous holmgreni (Heer, 1870)

Elater holmgreni Heer, 1870: 75 [18].

Athous holmgreeni: Birket-Smith, 1977: 18 [154] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, elytron, compression fossil, No. 53 (SMNH).

Fossil deposit/age. Norway: Svalbard and Jan Mayen, Firkanten Formation, Cap Staratschin; 66.0–59.2 Ma (Paleocene).

Literature. Heer (1870: 75): original description [18]; Scudder (1891: 517): catalogue [24]; Handlirsch (1907: 745): catalogue [127]; Birket-Smith (1977: 17): taxonomic remark [154]; Tröster (1994: 39): remark [65].

Remark. The description of this species was based on a part of isolated elytron and, therefore, its generic attribution is rather problematic.



Athous lethalis Wickham, 1916

Athous lethalis Wickham, 1916: 518 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2728 and 2729 (=8464 and 8713 in Scudder coll.) (MCZ).

Fossil deposit. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 518): original description [28]; Wickham (1920: 354): catalogue [29].



• Genus Limonius Eschscholtz, 1829 *

Limonius Eschscholtz, 1829: 33 [117]. Type species: Elater minutus Linnaeus, 1758: 406 [115]. For more information, including synonyms, see Sánchez-Ruiz [121], Cate [107] and Etzler [155].



Subgenus Paralimonius Iablokoff-Khnzorian, 1961

Paralimonius Iablokoff-Khnzorian, 1961: 91 [47]. Type species: Limonius (Paralimonius) barovskyi Iablokoff-Khnzorian, 1961: 91 [47]. For more information, see Kundrata et al. [12].



Limonius (Paralimonius) barovskyi Iablokoff-Khnzorian, 1961

Limonius (Paralimonius) barovskyi Iablokoff-Khnzorian, 1961: 91 [47].

Limonius barovskyi: Larsson, 1978: 153 [48].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 364/654 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 91): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 48): catalogue [49]; Keilbach (1982: 246): catalogue [133]; Schimmel (2005: 27): remark [91]; Alekseev (2013: 7): checklist [92]; Kundrata et al. (2020: 7): generic catalogue [12].



Subgenus incertae sedis



Limonius aboriginalis Wickham, 1916

Limonius aboriginalis Wickham, 1916: 514 [28].

Type material. Holotype, sex unknown, compression fossil, No. 90,474 (USNM).

Fossil deposit/age. USA: Colorado, Florissant Formation, Wilson Ranch, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 514): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. Representatives of Limonius and related genera have more elongated elytra and more or less campaniform or parallel-sided pronotum, whereas this species has elytra only slightly elongate, and the pronotum arcuate at sides and sinuate near posterior angles. Such body proportions and shape of thorax are usually found in Cardiophorinae and Negastriinae. Based on the image of prothorax [28], L. aboriginalis is most probably a member of Cardiophorinae; its prosternum is narrow and prosternal sutures almost parallel sided while in Negastriinae the prosternum is rather broad and prosternal sutures curved outward. However, we prefer to postpone any taxonomic changes pending a comprehensive review including the type material.



Limonius florissantensis Wickham, 1916

Limonius florissantensis Wickham, 1916: 515 [28].

Type material. Two syntypes (one with counterpart), sex unknown, compression fossils, No. 90,473 (USNM).

Fossil deposit/age. USA: Colorado, Florissant Formation, Wilson Ranch, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 515): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. Representatives of Limonius and related genera have more elongated elytra and more or less campaniform or parallel-sided pronotum, whereas this species has elytra only slightly elongate, and the pronotum arcuate at sides and sinuate near posterior angles. Such body proportions and shape of thorax are usually found in Cardiophorinae and Negastriinae. Based on the prothorax image in Wickham [28], L. florissantensis is most probably a member of Negastriinae as its pronotum is less globular than in typical Cardiophorinae. However, the type material should be thoroughly examined before any taxonomic change can be made.



Limonius impunctus Scudder, 1895

Limonius impunctus Scudder, 1895: 37 [156].

Type material. Holotype, sex unknown, elytron, compression fossil, No. 100a, b (GSC).

Fossil deposit/age. Canada: Allenby Formation (Princeton Group), North Fork of Similkameen River; 56.0–47.8 Ma (Eocene).

Literature. Scudder (1895: 37): original description [156]; Scudder (1900: 96): catalogue [157]; Handlirsch (1907: 746): catalogue [127]; Wickham (1920: 354): catalogue [29].

Remark. The generic attribution of this species is unclear as it was described based only on elytral characters.



Limonius optabilis Heer, 1847

Limonius optabilis Heer, 1847: 137 [14].

Type material. Holotype, sex unknown, compression fossil (ETH).

Fossil deposit/age. Germany: Upper Freshwater-Molasse Formation, Öhningen, Upper Öhningen beds; 12.7–11.608 Ma (Miocene).

Literature. Heer (1847: 137): original description [14]; Giebel (1852: 651): catalogue [126]; Giebel (1856: 95): redescription [16]; Heyden (1862: 69): remark [158]; Scudder (1891: 547): catalogue [24]; Handlirsch (1907: 746): catalogue [127].

Remark. Generic attribution of this species is doubtful. It might belong to Agrypnini based on the body proportions and the structure of thorax, especially as figured in Figure 6b in Heer [14]. Note, that drawing in Figure 6c in Heer [14] differs considerably in many features from Figure 6b in the same study.



Limonius praecursor Wickham, 1916

Limonius praecursor Wickham, 1916: 516 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2730 and 2731 (=9417 and 10,558 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 516): original description [28]; Wickham (1920: 354): catalogue [29].



Limonius shoshonis Wickham, 1916

Limonius shoshonis Wickham, 1916: 517 [28].

Type material. Holotype, sex unknown, compression fossil, No. 8251 (58) (CUB).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant, Station 14; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 517): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. Representatives of Limonius and related genera have more elongated elytra and more or less campaniform or parallel-sided pronotum, whereas this species has elytra only slightly elongate, and the pronotum arcuate at sides and sinuate near posterior angles. Such body proportions and shape of thorax are usually found in Cardiophorinae and Negastriinae. Based on the prothorax image in Wickham [28], L. shoshonis is most probably a member of Negastriinae as its pronotum is less globular than in typical Cardiophorinae. However, the type material should be thoroughly examined before any taxonomic change can be made.



Limonius volans Wickham, 1916

Limonius volans Wickham, 1916: 517 [28].

Type material. Holotype, sex unknown, compression fossil, No. 8252 (CUB).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant, Station 14; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 517): original description [28]; Wickham (1920: 354): catalogue [29].



3.3.2. Tribe Dimini Candèze, 1863 *

Dimites Candèze, 1863: 237 [145]. Type genus: Dima Charpentier, 1825: 191 [159]. For more information, see Kundrata et al. [12,160].



• Genus Alaodima Dolin, 1980

Alaodima Dolin, 1980: 75 [53]. Type species: Alaodima grandis Dolin, 1980: 76 [53]. For more information, see Kundrata et al. [12].

Remark. We keep this genus tentatively under Dimini although Schimmel [91] and Schimmel and Tarnawski [131] placed it to Elaterinae without any explanation. Some characters of A. grandis, e.g., large body size, pointed last ventrite, attenuate elytral apices, transverse scutellar shield, are more typical for species of Oxynopterini rather than Dimini, though A. grandis differs from Oxynopterini in the structure of metacoxal plate and the shape of prosternal process. Unfortunately, this fossil lacks head and legs so many crucial diagnostic characters are absent.



Alaodima grandis Dolin, 1980

Alaodima grandis Dolin, 1980: 76 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2970 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 76): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 9): checklist [120]; Schimmel (2005: 28): remark, photo [91]; Schimmel and Tarnawski (2010: 363): remark [131]; Kundrata et al. (2018: 69): catalogue [160]; Kundrata et al. (2020: 7): generic catalogue [12]; Kundrata et al. (2020: 8): remark [94].

3.3.3. Tribe Hypnoidini Schwarz, 1906 *

Hypnoidini Schwarz, 1906: 150 [161]. Type genus: Hypnoidus Dillwyn, 1829: 32 [162]. For more information, including synonyms, see Bouchard et al. [110].



• Genus Ligmargus Stibick, 1976 *

Ligmargus Stibick, 1976: 210 [163]. Type species: Cryptohypnus funebris Candèze, 1860: 62 [152]. For more information, see Cate [107].



Ligmargus terrestris (Scudder, 1879)

Cryptohypnus terrestris Scudder, 1879: 180 [20].

Ligmargus terrestris: Stibick, 1981: 247 [164].

Type material Holotype, sex unknown, compression fossil, No. 59 (GSC).

Fossil deposit/age. Canada: British Columbia, Princeton Group, Nicola river; 56.0–47.8 Ma (Eocene).

Literature. Scudder (1879: 180): original description [20]; Scudder (1890: 497): catalogue [165]; Scudder (1891: 503): catalogue [24]; Scudder (1895: 38): catalogue [156]; Scudder (1900: 96): catalogue [157]; Handlirsch (1907: 745): catalogue [127]; Wickham (1920: 354): catalogue [29]; Stibick (1981: 247): revision [164].



3.3.4. Tribe Oxynopterini Candèze, 1857 *

Oxynopterini Candèze, 1857: 355 [116]. Type genus: Oxynopterus Hope, 1842: 77 [166]. For more information, including synonyms, see Bouchard et al. [110].



• Genus Campsosternus Latreille, 1834 *

Campsosternus Latreille, 1834: 141 [167]. Type species: Elater fulgens Olivier, 1790: 12 [168] (syn. of Elater auratus Drury, 1773: 65 [169]). For more information, see Cate [107].



Campsosternus atavus Deichmüller, 1881

Campsosternus atavus Deichmüller, 1881: 306 [21].

Type material. Unknown number of type specimens, probably only one, sex unknown, compression fossil (type depository unknown).

Fossil deposit/age. Czech Republic: Kučlín (u Bíliny); 37.2–33.9 Ma (Eocene).

Literature. Deichmüller (1881: 306): original description [21]; Scudder (1891: 483): catalogue [24]; Handlirsch (1907: 743): catalogue [127].



• Genus Melanactes LeConte, 1853 *

Melanactes LeConte, 1853: 493 [144]. Type species. Melanactes densus LeConte, 1853: 494 [144]. For more information, see Mathieu [141].



Melanactes cockerelli Wickham, 1908

Melanactes cockerelli Wickham, 1908: 77 [27].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 3 (YPM).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant, Station 14; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1908: 77): original description [27]; Wickham (1916: 527): catalogue [28]; Wickham (1920: 354): catalogue [29].

3.3.5. Tribe Prosternini Gistel, 1856 *

Prosternidae Gistel, 1856: 367 [170]. Type genus: Prosternon Latreille, 1834: 151 [167]. This tribe includes also Ctenicerini Jakobson, 1913 and Corymbitini LeConte, 1861, which both have been currently synonyms of Prosternini. For more information, see Cate [107] and Bouchard et al. [110].



• Genus Ctenicera Latreille, 1829 *

Ctenicera Latreille, 1829: 454 [118]. Type species: Elater pectinicornis Linnaeus, 1758: 406 [115]. This genus includes also species earlier attributed to genera Ludius Eschscholtz, 1829 (nec Berthold [134], nec Latreille [167]) and Corymbites Latreille, 1834, which are currently both synonyms of Ctenicera. For more information, see Hyslop [111] and Cate [107].

Remark. The generic assignment of all species classified under Ctenicera needs serious re-examination. Many of them probably belong to Selatosomini.



Ctenicera emblemoelytra (Zhang, 1989), comb. nov.

Corymbites emblemoelytrus Zhang, 1989: 125 [58].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, 750115/750116 (part + counterpart) (SMJS).

Fossil deposit/age. China: Shanwang Formation, Linqu County; 20.44–15.97 Ma (Miocene).

Literature. Zhang (1989: 125): original description [58]; Dong and Huang (2011: 1225): checklist [81].

Remark. This species was described in genus Corymbites, which is, however, a synonym of Ctenicera [107,111]. Generic attribution of this species remains unclear. Since it was compared with a recent species of Pristilophus Latreille, 1834 and with fossil C. primitiva (Wickham, 1908) [58], which might in fact belong to Selatosomus Stephens, 1830, affinities of this species to the tribe Selatosomini should be taken into consideration.



Ctenicera euprepes (Zhang, Sun and Zhang, 1994), comb. nov.

Corymbites euprepes Zhang, Sun and Zhang, 1994: 92 [59].

Type material. Holotype, sex unknown, compression fossil, K0253 (SGMS).

Fossil deposit/age. China: Shanwang Formation, Linqu County; 20.44–15.97 Ma (Miocene).

Literature. Zhang et al. (1994: 92): original description [59]; Dong and Huang (2011: 1225): checklist [81].

Remark. This species was described in genus Corymbites, which is, however, a synonym of Ctenicera [107,111]. Its generic placement is unclear, since it superficially resembles the representatives of tribe Selatosomini.



Ctenicera granulicollis (Wickham, 1908), comb. nov.

Corymbites granulicollis Wickham, 1908: 76 [27].

Ludius granulicollis: Wickham, 1920: 354 [29].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 1 (YPM).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant Station 14; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1908: 76): original description [27]; Wickham (1916: 524): catalogue [28]; Wickham (1920: 354): catalogue [29]; Zhang et al. (1994: 93): remark [59].

Remark. This species was described in genus Corymbites and later transferred to Ludius Eschscholtz, 1829 (nec Berthold [134], nec Latreille [167]) [29] which are currently both synonyms of Ctenicera [107,111]. This species most probably belongs to genus Selatosomus based on the body proportions and shapes of prothorax and elytra. However, we prefer to postpone any taxonomic changes pending a detailed examination of the type material.



Ctenicera primitiva (Wickham, 1908), comb. nov.

Corymbites primitivus Wickham, 1908: 77 [27].

Ludius primitivus: Wickham, 1920: 354 [29].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2 (YPM).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant Station 13; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1908: 77): original description [27]; Wickham (1916: 524): catalogue [28]; Wickham (1920: 354): catalogue [29]; Zhang (1989: 126): remark [58].

Remark. This species was described in genus Corymbites and later transferred to Ludius Eschscholtz, 1829 (nec Berthold [134], nec Latreille [167]) [29] which are currently both synonyms of Ctenicera [107,111]. This species most probably belongs to genus Selatosomus based on the body proportions and shapes of prothorax and elytra. However, we prefer to postpone any taxonomic changes pending a detailed examination of the type material.



Ctenicera prophetica (Wickham, 1916), comb. nov.

Corymbites propheticus Wickham, 1916: 526 [28].

Ludius propheticus: Wickham, 1920: 354 [29].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2724 (=13,657 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 526): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. This species was described in genus Corymbites and later transferred to Ludius Eschscholtz, 1829 (nec Berthold [134], nec Latreille [167]) [29] which are currently both synonyms of Ctenicera [107,111]. This species superficially resembles Selatosomini but its placement remains unclear.



Ctenicera restructa (Wickham, 1916), comb. nov.

Corymbites restructus Wickham, 1916: 525 [28].

Ludius restructus: Wickham, 1920: 354 [29].

Type material. Holotype, sex unknown, compression fossil, No. 8215 (CUB).

Fossil deposit. USA: Colorado, Florissant Formation, Florissant, Station 14; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 525): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. This species was described in genus Corymbites and later transferred to Ludius Eschscholtz, 1829 (nec Berthold [134], nec Latreille [167]) [29] which are currently both synonyms of Ctenicera [107,111]. This species superficially resembles Selatosomini but its placement remains unclear.



Ctenicera sincera (Zhang, Sun and Zhang, 1994), comb. nov.

Corymbites sincerus Zhang, Sun and Zhang, 1994: 92 [59].

Type material. Holotype, sex unknown, compression fossil, SK000434 (Shanwang Fossil Protection Post collection; information taken from the Paleobiology Database, https://paleobiodb.org, accessed on 10 October 2020. May be “Shanwang Palaeontological Museum” in Linqu County (L. Qiu, personal communication). We have not been able to confirm depository information).

Fossil deposit/age. China: Shanwang Formation, Linqu County; 20.44–15.97 Ma (Miocene).

Literature. Zhang et al. (1994: 92): original description [59]; Dong and Huang (2011: 1225): checklist [81].

Remark. This species was described in genus Corymbites, which is currently a synonym of Ctenicera [107,111]. Generic attribution of this species remains unclear.



Ctenicera submersa (Wickham, 1916), comb. nov.

Corymbites submersus Wickham, 1916: 524 [28].

Ludius submersus: Wickham, 1920: 354 [29].

Type material. Holotype, sex unknown, compression fossil, No. 8216 (CUB).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant, Station 14; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 524): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. This species was described in genus Corymbites and later transferred to Ludius Eschscholtz, 1829 (nec Berthold [134], nec Latreille [167]) [29] which are currently both synonyms of Ctenicera [107,111]. This species superficially resembles Oxynopterini but its placement remains unclear.



Ctenicera sutor (Heer, 1847), comb. nov.

Diacanthus sutor Heer, 1847: 136 [14].

Corymbites sutor: Heer, 1861: 204 [171].

Type material. Two syntypes, sex unknown, compression fossils (SMNK, ETH (No. 7911)).

Fossil deposit/age. Germany: Upper Freshwater-Molasse Formation, Öhningen, MN 7 mammal zone; 12.7–11.608 Ma (Miocene).

Literature. Heer (1847: 136): original description [14]; Giebel (1852: 651): catalogue [126]; Giebel (1856: 95): revision, redescription [16]; Heer (1861: 204): catalogue [171]; Scudder (1891: 508): catalogue [24]; Handlirsch (1907: 746): catalogue [127]; Theobald (1937: 175): remark [42].

Remark. This species was classified in genus Corymbites [171] which is currently a synonym of Ctenicera [107,111]. This species is superficially similar to some species of Limonius but its placement remains unclear.



Ctenicera velata (Scudder, 1876), comb. nov.

Corymbites velatus Scudder, 1876: 81 [19].

Ludius velatus: Wickham, 1920: 354 [29].

Type material. Holotype, sex unknown, compression fossil, No. 3458 (MCZ).

Fossil deposit/age. USA: Wyoming, Green River Formation, Laney Member, Petrified fish cut; 50.3–46.2 Ma (Eocene).

Literature. Scudder (1876: 81): original description [19]; Scudder (1878: 762): catalogue [172]; Scudder (1890: 496): catalogue [165]; Scudder (1891: 501): catalogue [24]; Scudder (1900: 96): catalogue [157]; Handlirsch (1907: 746): catalogue [127]; Wickham (1920: 354): catalogue [29].

Remark. This species was described in genus Corymbites and later transferred to Ludius Eschscholtz, 1829 (nec Berthold [134], nec Latreille [167]) [29] which are currently both synonyms of Ctenicera [107,111]. The generic attribution of this species is unclear since it was described based almost exclusively on elytral characters.



• GenusEanus LeConte, 1861 *

Eanus LeConte, 1861: 171 [173]. Type species: Limonius estriatus LeConte, 1853: 434 [144]. This genus includes also species earlier attributed to genus Paranomus Kiesenwetter, 1858 (earlier also as part of Ludius Eschscholtz, 1829, nec Berthold [134], nec Latreille [167]), which is currently a synonym of Eanus. For more information, see Hyslop [111], Johnson [106] and Cate [107].

Remark. All fossil species listed under this genus should be re-examined as their body proportions and structure of prothorax resemble more Negastriinae or Cardiophorinae rather than Eanus. Current representatives of Eanus have more elongated elytra and more or less campaniform pronotum, while in the here listed fossil species, elytra are relatively shorter and the pronotum is more or less rounded and sinuate near posterior angles. The shapes of scutellar shields in drawings by Wickham [28] also suggest similarity with Negastriinae.



Eanus exanimatus (Wickham, 1916), comb. nov.

Paranomus exanimatus Wickham, 1916: 520 [28].

Ludius exanimatus: Wickham, 1920: 354 [29].

Type material. Holotype, sex unknown, compression fossil, No. 90,496 (USNM).

Fossil deposit/age. USA: Colorado, Florissant Formation, Wilson Ranch, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 520): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. This species was described in genus Paranomus (earlier also as part of Ludius Eschscholtz, 1829, nec Berthold [134], nec Latreille [167]), which is currently a synonym of Eanus.



Eanus heeri (Wickham, 1916), comb. nov.

Paranomus heeri Wickham, 1916: 521 [28].

Ludius heeri: Wickham, 1920: 354 [29].

Type material. Holotype, sex unknown, compression fossil (?CUB).

Fossil deposit/age. USA: Colorado: Florissant Formation, Florissant, Station 14; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 521): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. This species was described in genus Paranomus (later also as part of Ludius Eschscholtz, 1829, nec Berthold [134], nec Latreille [167]), which is currently a synonym of Eanus. Its generic placement is unclear, and already Wickham [28] mentioned that this was probably not true Paranomus (now Eanus).



Eanus laevissimus (Wickham, 1916), comb. nov.

Paranomus laevissimus Wickham, 1916: 521 [28].

Ludius laevissimus: Wickham, 1920: 354 [29].

Type material. Holotype, sex unknown, compression fossil (?CUB).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant, Station 14; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 521): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. This species was described in genus Paranomus (earlier also as part of Ludius Eschscholtz, 1829, nec Berthold [134], nec Latreille [167]), which is currently a synonym of Eanus.



• Genus Oxygonus LeConte, 1863 *

Oxygonus LeConte, 1863: 48 [174]. Type species: Elater obesus Say, 1823: 168 [175]. For more information, see Hyslop [111] and Johnson [106].



Oxygonus mortuus Scudder, 1876

Oxygonus mortuus Scudder, 1876: 81 [19].

Type material. Holotype, sex unknown, elytron, compression fossil (type depository has not been identified).

Fossil deposit/age. USA: Utah, Green River Formation, Fossil Cañon; 50.3–46.2 Ma (Eocene).

Literature. Scudder (1876: 81): original description [19]; Scudder (1877: 759): catalogue [176]; Scudder (1890: 496): catalogue [165]; Scudder (1891: 562): catalogue [24]; Scudder (1900: 97): catalogue [157]; Handlirsch (1907: 747): catalogue [127]; Wickham (1920: 354): catalogue [29].

Remark. The generic attribution of this species is unclear as it was described based only on elytral characters.



Oxygonus primus Wickham, 1916

Oxygonus primus Wickham, 1916: 526 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 4069 (=6381 in Scudder coll.) (MCZ) (Figure 1A).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 526): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. This species most probably does not belong to Oxygonus as it differs considerably in the shape of prothorax (almost globular versus more or less elongate, with arcuate sides in Oxygonus) [177].

3.3.6. Tribe Selatosomini Schimmel, Tarnawski, Han and Platia, 2015 *

Selatosomini Schimmel, Tarnawski, Han and Platia, 2015: 30 [178]. Type genus: Selatosomus Stephens, 1830: 268 [179]. For more information, see Schimmel et al. [178].



• Genus Selatosomus Stephens, 1830 *

Selatosomus Stephens, 1830: 268 [179]. Type species: Elater aeneus Linnaeus, 1758: 406 [115]. For more information, see Cate [107].



Selatosomus miegi Theobald, 1937

Selatosomus miegi Theobald, 1937: 175 [42].

Type material. Holotype, sex unknown, elytron, compression fossil, R 624 (NHMB).

Fossil deposit/age. Germany: Middle Member (Salt Formation), Kleinkembs; 33.9–28.4 Ma (Oligocene).

Literature. Theobald (1937: 175): original description [42].

Remark. The generic attribution of this species is unclear as this was described based only on elytral characters.



3.3.7. Tribe Semiotini Jakobson, 1913 *

Semiotina Jakobson, 1913: 736 [180]. Type genus: Semiotus Eschscholtz, 1829: 31 [117]. For more information, see Bouchard et al. [110].



• Genus Semiotus Eschscholtz 1829 *

Semiotus Eschscholtz 1829: 31 [117]. Type species: Elater furcatus Fabricius, 1775: 224 [181]. For more information, see Hyslop [111].



Semiotus ehrenswaerdi (Heer, 1870)

Elater ehrenswaerdi Heer, 1870: 74 [18].

Elater ehrenwaerdi: Scudder, 1891: 517 [24] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Elater ehrenwärdi [sic!]: Handlirsch, 1907: 745 [127].

Semiotus ehrensvaerdi: Birket-Smith, 1977: 18 [154] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Lectotype, sex unknown, elytron, compression fossil, No. 54a,b (SMNH). Paralectotype, sex unknown, elytron, compression fossil, No. 54c (SMNH).

Fossil deposit/age. Norway: Svalbard and Jan Mayen, Firkanten Formation, Cap Staratschin; 66.0–59.2 Ma (Paleocene).

Literature. Heer (1870: 74): original description [18]; Scudder (1891: 517): catalogue [24]; Handlirsch (1907: 745): catalogue [127]; Birket-Smith (1977: 18): taxonomic revision [154].

Remark. The description is based on a part of isolated elytron so the generic attribution of this species is rather problematic. However, based on the elytron reconstruction by Birket-Smith [154], it is really similar to that of Semiotus.



Semiotus menatensis Piton, 1940

Semiotus menatensis Piton, 1940: 179 [43].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 943 (MNHN).

Fossil deposit/age. France: Menat Formation, Menat; 61.6–59.2 Ma (Paleocene).

Literature. Piton (1940: 179): original description [43].

Remark. Based on the body proportions, shape of antenna and rather broad and short pronotum, this species strongly resembles recent Campsosternus (Oxynopterini). However, we prefer to postpone any taxonomic changes pending a comprehensive review including the type material.

3.4. Subfamily Elaterinae Leach, 1815 *

Elaterides Leach, 1815: 85 [114]. Type genus: Elater Linnaeus, 1758: 404 [115]. For more information including synonyms, see Bouchard et al. [110].

3.4.1. Tribe Agriotini Laporte, 1840 *

Agriotites Laporte, 1840: 233 [182]. Type genus: Agriotes Eschscholtz, 1829: 34 [117]. For more information, see Cate [107] and Bouchard et al. [110].



• Genus Agriotes Eschscholtz, 1829 *

Agriotes Eschscholtz, 1829: 34 [117]. Type secies: Elater sputator Linnaeus, 1758: 405 [115]. For more information, see Cate [107].



Agriotes comminutus Wickham, 1916

Agriotes comminutus Wickham, 1916: 513 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2747 (= 11,800 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 513): original description [28]; Wickham (1920: 354): catalogue [29].



Agriotes nearcticus Wickham, 1916

Agriotes nearcticus Wickham, 1916: 513 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2748 (=6653 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 513): original description [28]; Wickham (1920: 354): catalogue [29].



Agriotes succiniferusBecker, 1963

Agriotes succiniferus Becker, 1963: 127 [46].

Agriotes succinifer: Zaragoza Caballero, 1990: 147 [61] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, female, exoskeleton, amber inclusion, No. 12,972 (UCMP).

Fossil deposit/age. Mexico: Simojovel region, Mexican (Chiapas) amber; 23.03–15.97 Ma (Miocene).

Literature. Becker (1963: 127): original description [46]; Spahr (1981: 46): catalogue [49]; Keilbach (1982: 247): catalogue [133]; Zaragoza Caballero (1990: 147): remark [61]; Schimmel (2005: 27): remark [91]; Solórzano Kraemer (2007: 119): checklist [90]; Schimmel and Tarnawski (2010: 363): remark [131]; Schimmel and Tarnawski (2012: 265): remark [132].

3.4.2. Tribe Ampedini Gistel, 1848 *

Ampedidae Gistel, 1848: 5 [138]. Type genus: Ampedus Dejean, 1833: 92 [139]. For more information, see Bouchard et al. [110].



• Genus Ampedus Dejean, 1833 *

Ampedus Dejean, 1833: 92 [139]. Type species: Elater sanguineus Linnaeus, 1758: 405 [115]. For more information see Sánchez-Ruiz [121] and Cate [107].



Subgenus Octamenogonoides Iablokoff-Khnzorian, 1961

Octamenogonoides Iablokoff-Khnzorian, 1961: 88 [47]. Type species: Elater (Octamenogonoides) gebleri Iablokoff-Khnzorian, 1961: 88 [47]. For more information, see Alekseev [92] and Kundrata et al. [12].

Remark. Iablokoff-Khnzorian [47] described Octamenogonoides as a subgenus in Elater Linnaeus, 1758, and Schimmel and Tarnawski [131] treated it is a member of the tribe Elaterini. Alekseev [92] transferred Octamenogonoides to Ampedus and kept its subgeneric status.



Ampedus (Octamenogonoides) gebleri (Iablokoff-Khnzorian, 1961)

Elater (Octamenogonoides) gebleri Iablokoff-Khnzorian, 1961: 88 [47].

Elater gebleri: Larsson, 1978: 153 [48].

Ampedus (Octamenogonoides) gebleri: Alekseev, 2013: 7 [92].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 364/641 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 88): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 48): catalogue [49]; Keilbach (1982: 246): catalogue [133]; Schimmel (2005: 27): remark [91]; Schimmel and Tarnawski (2010: 364): remark [131]; Alekseev (2013: 7): checklist [92]; Kundrata et al. (2020: 8): generic catalogue [12].



Subgenus Ampedus Dejean, 1833

Ampedus Dejean, 1833: 92 [139]. Type species: Elater sanguineus Linnaeus, 1758: 405 [115]. For more information see Sánchez-Ruiz [121] and Cate [107].



Ampedus seyfriedii Heer, 1847

Ampedus seyfriedii Heer, 1847: 131 [14].

Ampedus seyfriedi: Giebel, 1852: 651 [126] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.4].

Type material. Holotype, sex unknown, compression fossil (ETH).

Fossil deposit/age. Germany: Upper Freshwater-Molasse Formation, Öhningen, MN-7 mammal zone, Upper Öhningen beds Member; 12.7–11.608 Ma (Miocene).

Literature. Heer (1847: 131): original description [14]; Giebel (1852: 651): catalogue [126]; Giebel (1856: 97): redescription [16]; Heer (1861: 204): catalogue [171]; Heer (1865: 362): remark [17]; Heer (1872: 444): remark [135]; Heer (1876: 16): remark [136]; Handlirsch (1907: 743): catalogue [127].



• GenusIschnodes Germar, 1844 *

Ischnodes Germar, 1844: 180 [183]. Type species: Elater sanguinicollis Panzer, 1793: 13 [184]. For more information, see Cate [107].



Ischnodes gracilis Heer, 1847

Ischnodes gracilis Heer, 1847: 133 [14].

Type material. Holotype, sex unknown, compression fossil, No. 7908 (ETH).

Fossil deposit/age. Germany: Upper Freshwater-Molasse Formation, Öhningen, Upper Öhningen beds; 12.7–11.608 Ma (Miocene).

Literature. Heer (1847: 133): original description [14]; Giebel (1852: 651): catalogue [126]; Giebel (1856: 97): redescription [16]; Scudder (1891: 542): catalogue [24]; Handlirsch (1907: 745): catalogue [127].

3.4.3. Tribe Elaterini Leach, 1815 *

Elaterides Leach, 1815: 85 [114]. Type genus: Elater Linnaeus, 1758: 404 [115]. For more information, including synonyms, see Bouchard et al. [110].



• Genus Diaraphes Iablokoff-Khnzorian, 1961

Diaraphes Iablokoff-Khnzorian, 1961: 89 [47]. Type species: Diaraphes kozhantshikovi Iablokoff-Khnzorian, 1961: 89 [47]. For more information, see Kundrata et al. [12].



Diaraphes kozhantshikovi Iablokoff-Khnzorian, 1961

Diaraphes kozhantshikovi Iablokoff-Khnzorian, 1961: 89 [47].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 364/645 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 89): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 47): catalogue [49]; Keilbach (1982: 246): catalogue [133]; Carpenter (1992: 304): generic catalogue [68]; Schimmel (2005: 27): remark [91]; Alekseev (2013: 7): checklist [92]; Kundrata et al. (2020: 8): generic catalogue [12].



• Genus Elater Linnaeus, 1758 *

Elater Linnaeus, 1758: 404 [115]. Type species: Elater ferrugineus Linnaeus, 1758: 405 [115]. For more information, see Cate [107].

Remark. Fossil species assigned to this genus urgently need a revision. It is possible that most, if not all, species in fact belong to another click-beetle genera. It should be also noted, that many older authors used the name “Elater” in erroneuous way (nec Elater Linnaeus [115]), i.e., for Ampedus (for more information, see Hyslop [111]), so they actually compared these fossil species with Ampedus and not with Elater.



Elater asmodeus Zhang, 1989

Elater asmodeus Zhang, 1989: 123 [58].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. s82747 (SMJS).

Fossil deposit/age. China: Shanwang Formation, Shanwang, Linqu County; 20.44–15.97 Ma (Miocene).

Literature. Zhang (1989: 123): original description [58]; Dong and Huang (2011: 1225): checklist [81].

Remark. This species superficially (i.e., in the body proportions and the structure of thorax) resembles Dendrometrinae rather than Elaterinae.



Elater berryi Wickham, 1929

Elater berryi Wickham, 1929: 148 [41].

Type material. Holotype, sex unknown, elytron, compression fossil, No. 80,474 (USNM).

Fossil deposit/age. USA: Tennessee, Cockfield Formation, 4 miles north of Jackson, Madison County; 41.3–38.0 Ma (Eocene).

Literature. Wickham (1929: 148): original description [41]; Wickham (1933: 103): catalogue [185].



Elater burmitinus Cockerell, 1917

Elater burmitinus Cockerell, 1917: 325 [33].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 19,102 (BMNH).

Fossil deposit/age. Myanmar: Burmese amber; 99.6–93.5 Ma (Cretaceous).

Literature. Cockerell (1917: 325): original description [33]; Fletcher (1920: 987): remark [186]; Zherikhin (1978: 114): remark [187]; Spahr (1981: 47): catalogue [49]; Keilbach (1982: 247): checklist [133]; Poinar (1992: 144): remark [188]; Ross and York (2000: 12): catalogue [189]; Peris and Háva (2016: 496): remark [190].

Remark. Cockerell [33] suggested that it is not a member of true Elater; however, he was not able to assign it to any other genus. It was listed as “Elateridae sens. l. burmitinus” by Keilbach [133]. The original description and available figure are not enough to make any conclusions about the placement of this species, and the proper study of the type specimen should be carried out in order to exclude the possibility that it is a member of Eucnemidae.



Elater canabinus Zhang, 1989

Elater canabinus Zhang, 1989: 124 [58].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 840,105 (SMJS).

Fossil deposit/age. China: Shanwang Formation, Shanwang, Linqu County; 20.44–15.97 Ma (Miocene).

Literature. Zhang (1989: 124): original description [58]; Dong and Huang (2011: 1225): checklist [81].



Elater florissantensis Wickham, 1916

Elater florissantensis Wickham, 1916: 510 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2752 (=8034 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 510): original description [28]; Wickham (1920: 354): catalogue [29].



Elater mitrus Zhang, 1989

Elater mitrus Zhang, 1989: 122 [58].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. s82713 (SMJS).

Fossil deposit/age. China: Shanwang Formation, Shanwang, Linqu County; 20.44–15.97 Ma (Miocene).

Literature. Zhang (1989: 122): original description [58]; Dong and Huang (2011: 1225): checklist [81].

Remark. This species is similar to Ampedini in the body proportions, the narrowed campaniform pronotum, the elongate, almost parallel-sided elytra and the slightly serrated antenna. In Elaterini, the pronotum is usually wider, elytra not parallel sided, often somewhat wedge-shaped, and antenna more serrated. However, we prefer to keep this species tentatively in Elater until the holotype is examined in detail.



Elater naumanni Giebel, 1856

Elater naumanni Giebel, 1856: 91 [16].

Type material. Holotype, sex unknown, amber inclusion (Leipzig University collection).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Giebel (1856: 91): original description [16]; Handlirsch (1907: 744): catalogue [127]; Larsson (1978: 153): catalogue [48]; Keilbach (1982: 246): catalogue [133]; Alekseev (2013: 7): checklist [92].

Remark. This species was considered by Larsson [48] more similar to Limonius than to Elater. Type material should be studied in order to confirm the placement of this species.



Elater rohweri Wickham, 1916

Elater rohweri Wickham, 1916: 509 [28].

Type material. Holotype, sex unknown, compression fossil, No. 8227 (CUB).

Fossil deposit. USA: Colorado, Florissant Formation, Florissant, Station 14; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 509): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. This species superficially resembles Ampedini in having slightly arcuate pronotum which is sinuate near posterior angles, and slightly elongated subparallel sided. However, we prefer to keep this species tentatively in Elater until the holotype is examined in detail.



Elater scudderi Wickham, 1916

Elater scudderi Wickham, 1916: 510 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2751 (=12,485 in Scudder coll.) (MCZ).

Fossil deposit. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 510): original description [28]; Wickham (1920: 354): catalogue [29].

Remark. Wickham [28] already mentioned that this species probably does not belong to true Elater. Indeed, it has notably arcuate pronotum, with small posterior angles which is not a character usually found in Elaterinae. The generic attribution of E. scudderi needs further investigation.



Elater wisniowskii Lomnicki, 1902

Elater wisniowskii Lomnicki, 1902: 11 [25].

Type material. Holotype (probably), sex unknown, elytron, compression fossil (type depository unknown).

Fossil deposit/age. Ukraine: Bashkev Formation: Myszyn, Galicia; 13.65–12.7 Ma (Miocene).

Literature. Lomnicki (1902: 11): original description [25]; Handlirsch (1907: 745): catalogue [127].

Remark. The generic attribution of this species is unclear as it was described based only on elytral characters.



• Genus Elatron Iablokoff-Khnzorian, 1961

Elatron Iablokoff-Khnzorian, 1961: 90 [47]. Type species: Elatron semenovi Iablokoff-Khnzorian, 1961: 90 [47]. For more information, see Kundrata et al. [12].



Elatron semenovi Iablokoff-Khnzorian, 1961

Elatron semenovi Iablokoff-Khnzorian, 1961: 90 [47].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 364/650 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 90): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 48): catalogue [49]; Keilbach (1982: 246): catalogue [133]; Carpenter (1992: 304): generic catalogue [68]; Schimmel (2005: 27): remark [91]; Alekseev (2013: 7): checklist [92]; Kundrata et al. (2020: 8): generic catalogue [12].



• Genus Holopleurus Iablokoff-Khnzorian, 1961

Holopleurus Iablokoff-Khnzorian, 1961: 86 [47]. Type species: Holopleurus succineus Iablokoff-Khnzorian, 1961: 86 [47]. For more information, see Kundrata et al. [12].



Holopleurus succineus Iablokoff-Khnzorian, 1961

Holopleurus succineus Iablokoff-Khnzorian, 1961: 86 [47].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 364/530 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 86): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 48): catalogue [49]; Keilbach (1982: 246): catalogue [133]; Carpenter (1992: 304): generic catalogue [68]; Schimmel (2005: 27): remark [91]; Alekseev (2013: 7): checklist [92]; Kundrata et al. (2020: 8): generic catalogue [12].



• GenusOrthoraphes Iablokoff-Khnzorian, 1961

Orthoraphes Iablokoff-Khnzorian, 1961: 86 [47]. Type species: Orthoraphes reichardti Iablokoff-Khnzorian, 1961: 87 [47]. For more information, see Kundrata et al. [12].



Orthoraphes reichardti Iablokoff-Khnzorian, 1961

Orthoraphes reichardti Iablokoff-Khnzorian, 1961: 87 [47].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 364/469 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 87): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 49): catalogue [49]; Keilbach (1982: 246): catalogue [133]; Carpenter (1992: 305): generic catalogue [68]; Schimmel (2005: 27): remark [91]; Alekseev (2013: 7): checklist [92]; Kundrata et al. (2020: 8): generic catalogue [12].

3.4.4. Tribe Megapenthini Gurjeva, 1973 *

Megapenthini Gurjeva, 1973: 448 [191]. Type genus: Megapenthes Kiesenwetter, 1858: 353 [192]. For more information, see Bouchard et al. [110].



• Genus Abelater Fleutiaux, 1947 *

Abelater Fleutiaux, 1947: 383 [193]. Type species: Melanoxanthus rubiginosus Candèze, 1878: 138 [194]. For more information, see Cate [107].



Abelater succineus Schimmel, 2005

Abelater succineus Schimmel, 2005: 106 [91].

Type material. Holotype, female, exoskeleton, amber inclusion, No. 4462 (CGG 2450) (GPIUH).

Fossil deposit/age. Baltic Amber; 38.0–33.9 Ma (Eocene).

Literature. Schimmel (2005: 106): original description [91]; Schimmel and Tarnawski (2010: 363): remark [131]; Schimmel and Tarnawski (2012: 265): remark [132]; Alekseev (2013: 7): checklist [92].



• Genus Megapenthes Kiesenwetter, 1858 *

Megapenthes Kiesenwetter, 1858: 353 [192]. Type species: Elater lugens Redtenbacher, 1842: 11 [195]. For more information, see Cate [107].



Megapenthes groehni Schimmel, 2005

Megapenthes groehni Schimmel, 2005: 107 [91].

Type material. Holotype, male, exoskeleton, amber inclusion, No. 4463 (CGG 1184) (GPIUH).

Fossil deposit/age. Baltic Amber; 38.0–33.9 Ma (Eocene).

Literature. Schimmel (2005: 107): original description [91]; Schimmel and Tarnawski (2010: 363): remark [131]; Schimmel and Tarnawski (2012: 265): remark [132]; Alekseev (2013: 7): checklist [92].



Megapenthes primaevus Wickham, 1916

Megapenthes primaevus Wickham, 1916: 511 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2750 (=10,859 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 511): original description [28]; Wickham (1920: 354): catalogue [29]; Alekseev (2013: 7): checklist [92].



Megapenthes voigti Schimmel, 2005

Megapenthes voigti Schimmel, 2005: 110 [91].

Type material. Holotype, female, exoskeleton, amber inclusion, No. 4469 (CGG 4612) (GPIUH). Paratype, male, exoskeleton, amber inclusion, CGG 2389 (BMNH) (Figure 1B).

Fossil deposit/age. Baltic Amber; 38.0–33.9 Ma (Eocene).

Literature. Schimmel (2005: 110): original description [91]; Schimmel and Tarnawski (2010: 363): remark [131]; Schimmel and Tarnawski (2012: 265): remark [132]; Alekseev (2013: 7): checklist [92].



3.4.5. Tribe Physorhinini Candèze, 1859 *

Physorhinites Candèze, 1859: 384 [148]. Type genus: Physorhinus Germar, 1840: 244 [196]. For more information, see Bouchard et al. [110].



• Genus Anchastus LeConte, 185 *

Anchastus LeConte, 1853: 459 [144]. Type species: Anchastus digitatus LeConte, 1853: 459 [144]. For more information, see Cate [107] and Johnson [106].



Anchastus diluvialis Wickham, 1916

Anchastus diluvialis Wickham, 1916: 507 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2759 (=11,277 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 506): original description [28]; Wickham (1920: 354): catalogue [29].



Anchastus eruptus Wickham, 1916

Anchastus eruptus Wickham, 1916: 507 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2760 (=11,281 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 506): original description [28]; Wickham (1920: 354): catalogue [29].

3.4.6. Tribe Synaptini Gistel, 1856 *

Synaptidae Gistel, 1856: 366 [170]. Type genus: Synaptus Eschscholtz, 1829: 32 [117]. For more information, see Cate [107] and Bouchard et al. [110].



• GenusGlyphonyx Candèze, 1863 *

Glyphonyx Candèze, 1863: 451 [145]. Type species: Glyphonyx gundlachii Candèze, 1863: 453 [145]. For more information, see Hyslop [111] and Cate [107].



Glyphonyx chiapasensis Zaragoza Caballero, 1990

Glyphonyx chiapasensis Zaragoza Caballero, 1990: 148 [61].

Type material. Holotype, probably male, amber inclusion (UNAM).

Fossil deposit/age. Mexico: Simojovel region, Mexican (Chiapas) amber; 23.03–15.97 Ma (Miocene).

Literature. Zaragoza Caballero (1990: 148): original description [61]; Solórzano Kraemer (2007: 119): catalogue [90].

Remark. The generic attribution of this species needs re-examination. Since this species has a very small body size and a rather unusual shape of body and prothorax (including a lack of the Synaptini-characteristic lateral basal indentations of pronotum), it might belong to another genus than Glyphonyx.



Glyphonyx punctatus Becker, 1963

Glyphonyx punctatus Becker, 1963: 127 [46].

Type material. Holotype, female, exoskeleton, amber inclusion, Nr. 12,873 (UCMP).

Fossil deposit/age. Mexico: Simojovel region, Mexican (Chiapas) amber; 23.03–15.97 Ma (Miocene).

Literature. Becker (1963: 127): original description [46]; Spahr (1981: 48): catalogue [49]; Keilbach (1982: 247): catalogue [133]; Zaragoza Caballero (1990: 147): redescription [61]; Schimmel (2005: 27): remark [91]; Solórzano Kraemer (2007: 119): catalogue [90]; Schimmel and Tarnawski (2010: 363): remark [131]; Schimmel and Tarnawski (2012: 265): remark [132].

3.4.7. Elaterinae Incertae Sedis



• GenusCrioraphes Iablokoff-Khnzorian, 1961

Crioraphes Iablokoff-Khnzorian, 1961: 93 [47]. Type species: Crioraphes rohdendorfi Iablokoff-Khnzorian, 1961: 94 [47]. For more information, see Douglas [4] and Kundrata et al. [12].



Crioraphes rohdendorfi Iablokoff-Khnzorian, 1961

Crioraphes rohdendorfi Iablokoff-Khnzorian, 1961: 94 [47].

Crioraphes rhodendorfi: Larsson, 1978: 153 [48] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 364/460 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 94): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 46): catalogue [49]; Keilbach (1982: 246): catalogue [133]; Carpenter (1992: 304): generic catalogue [68]; Alekseev (2013: 7): checklist [92]; Kundrata et al. (2020: 9): generic catalogue [12].

3.5. Subfamily Lissominae Laporte, 1835 *

Lissomidae Laporte, 1835: 178 [197]. Type genus: Lissomus Dalman, 1824: 13 [198]. For more information, including synonyms, see Kundrata et al. [12].

3.5.1. Tribe Lissomini Laporte, 1835 *

Lissomidae Laporte, 1835: 178 [197]. Type genus: Lissomus Dalman, 1824: 13 [198]. For more information, including synonyms, see Kundrata et al. [12].



• Genus Lissomus Dalman, 1824 *

Lissomus Dalman, 1824: 13 [198]. Type species: Lissomus punctulatus Dalman, 1824: 14 [198]. For more information, see Cate [107].



Lissomus taxodii (Heer, 1870)

Curculionites taxodii Heer, 1870: 76 [18].

Lissomus taxodii: Birket-Smith, 1977: 21 [154].

Type material. Holotype, sex unknown, elytron, compression fossil, No. 40 (SMNH).

Fossil deposit/age. Norway: Svalbard and Jan Mayen, Firkanten Formation, Cap Staratschin; 66.0–59.2 Ma (Paleocene).

Literature. Heer (1870: 76): original description [18]; Birket-Smith (1977: 21): revision, redescription [154]; Legalov (2015: 1497): catalogue (as Curculionites Heer, 1847) [199]; Legalov (2020: 23): catalogue (as Curculionites) [200].

Remark. The description of this species is based on a part of isolated elytron and, therefore, its generic attribution is rather problematic. It was originally described in Curculionites Heer, 1847 (Curculionoidea) and only later transferred to Lissomus in Elateridae [154]. Based on the reconstruction by Birket-Smith [154], it seems that this species belongs rather to Dendrometrinae than Lissominae. Legalov [199,200] kept this species in original genus in Curculionoidea in the catalogues of fossil curculionoids. The identity of this species should be confirmed by study of the type material.

3.5.2. Tribe Protelaterini Schwarz, 1902 *

Protelateridae Schwarz, 1902: 365 [201]. Type genus: Protelater Sharp, 1877: 482 [202]. For more information, including synonyms, see Kundrata et al. [94,109].



• Genus Baltelater Kundrata, Bukejs, Prosvirov and Hoffmannova, 2020

Baltelater Kundrata, Bukejs, Prosvirov and Hoffmannova, 2020: 2 [94]. Type species: Baltelater bipectinatus Kundrata, Bukejs, Prosvirov and Hoffmannova, 2020: 3 [94]. For more information, see Kundrata et al. [94].



Baltelater bipectinatus Kundrata, Bukejs, Prosvirov and Hoffmannova, 2020

Baltelater bipectinatus Kundrata, Bukejs, Prosvirov and Hoffmannova, 2020: 3 [94].

Type material. Holotype, male, exoskeleton, amber inclusion, No. 6685 (JDC 8374) (MAIG, ex coll. Jonas Damzen).

Fossil deposit/age. Baltic Amber; 38.0–33.9 Ma (Eocene).

Literature. Kundrata et al. (2020): original description [94].

3.6. Subfamily Negastriinae Nakane and Kishii, 1956 *

Negastriinae Nakane and Kishii, 1956: 203 [203]. Type genus: Negastrius Thomson, 1859: 106 [204]. For more information, see Bouchard et al. [110].



• Genus Ganestrius Dolin, 1976

Ganestrius Dolin, 1976: 69 [52]. Type species: Ganestrius stibicki Dolin, 1976: 71 [52]. For more information, see Kundrata et al. [12].



Ganestrius elongatus Dolin, 1976

Ganestrius elongatus Dolin, 1976: 71 [52].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2528 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1976: 71): original description [52]; Dolin (1980: 77): revision, catalogue [53]; Korneev and Cate (2005: 15): checklist [120].



Ganestrius stibicki Dolin, 1976

Ganestrius stibicki Dolin, 1976: 71 [52].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2823 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1976: 71): original description [52]; Dolin (1980: 77): revision, catalogue [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 9): generic catalogue [12].



• Genus Paradonus Stibick, 1971 *

Paradonus Stibick, 1971: 386 [205]. Type species: Elater pectoralis Say, 1839: 173 [206]. For more information, see Stibick [205].



Paradonus exterminatus (Wickham, 1916), comb. nov.

Cryptohypnus exterminatus Wickham, 1916: 506 [28].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2762 (= 11,280 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 506): original description [28]; Wickham (1920: 354): catalogue [29]; Stibick (1981: 246): systematic remark [164].

Remark. In his revision of Hypnoidinae, Stibick [164] examined Cryptohypnus exterminatus and suggested that it does not belong to Hypnoidinae. Instead, he suggested its placement in Negastriinae, close to Negastrius pectoralis group (=genus Paradonus sensu Stibick [205]), based on the “overall sculpture” and non-striate elytra. This relationship was already mentioned by Wickham [28] in the original description of C. exterminatus. Here, we formally place this species in Paradonus.



Paradonus hesperus (Wickham, 1916)

Cryptohypnus hesperus Wickham, 1916: 506 [28].

Paradonus hesperus: Stibick, 1971: 386 [205].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2761 (=5294 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 506): original description [28]; Wickham (1920: 354): catalogue [29]; Stibick (1971: 386): systematic remark [205]; Stibick (1981: 246): systematic remark [164].



• Genus Protoquasimus Dolin, 1976

Protoquasimus Dolin, 1976: 69 [52]. Type species: Protoquasimus brevicollis Dolin, 1976: 69 [52]. For more information, see Kundrata et al. [12].



Protoquasimus brevicollis Dolin, 1976

Protoquasimus brevicollis Dolin, 1976: 69 [52].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2993 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1976: 69): original description [52]; Dolin (1980: 76): revision, catalogue [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Dong and Huang (2011: 1227): checklist [81]; Kundrata et al. (2020: 9): generic catalogue [12].



3.7. Subfamily Omalisinae Lacordaire, 1857 *

Homalisides Lacordaire, 1857: 303 [207]. Type genus: Omalisus Geoffroy, 1762: 179 [208]. For more information, see Bouchard et al. [110].



• Genus Jantarokrama Kirejtshuk and Kovalev, 2015

Jantarokrama Kirejtshuk and Kovalev, 2015: 1413 [93]. Type species: Jantarokrama utilis Kirejtshuk and Kovalev, 2015: 1414 [93]. For more information, see Kundrata et al. [12].



Jantarokrama utilis Kirejtshuk and Kovalev, 2015

Jantarokrama utilis Kirejtshuk and Kovalev, 2015: 1414 [93].

Type material. Holotype, male, amber inclusion, A52062 (283) (MNHN).

Fossil deposit/age. Baltic Amber; 38.0–33.9 Ma (Eocene).

Literature. Kirejtshuk and Kovalev (2015: 1414): original description [93]; Kundrata et al. (2020: 9): generic catalogue [12]; Kundrata et al. (2020: 8): remark [94].

3.8. Subfamily Pityobiinae Hyslop, 1917 *

Pityobini Hyslop, 1917: 249 [209]. Type genus: Pityobius LeConte, 1853: 428 [144]. For more information, see Bouchard et al. [110].



• Genus Cretopityobius Otto, 2019

Cretopityobius Otto, 2019: 4 [96]. Type species: Cretopityobius pankowskiorum Otto, 2019: 4 [96]. For more information, see Otto [96] and Kundrata et al. [12]. The assignment of this genus to Pityobiinae needs further investigation.



Cretopityobius pankowskiorum Otto, 2019

Cretopityobius pankowskiorum Otto, 2019: 4 [96].

Type material. Holotype, sex unknown, amber inclusion (USNM). One paratype, sex unknown, amber inclusion (WIRC) (Figure 1C).

Fossil deposit/age. Myanmar: Burmese amber; 99.6–93.5 Ma (Cretaceous).

Literature. Otto (2019: 4): original description [96]; Kundrata et al. (2020: 9): generic catalogue [12]; Kundrata et al. (2020: 8): remark [94].

3.9. Subfamily Protagrypninae Dolin, 1973

Protagrypnini Dolin, 1973: 74 [50]. Type genus: Protagrypnus Dolin, 1973: 75 [50]. For more information, see Bouchard et al. [110] and Kundrata et al. [12].

Remark. This group was originally classified in Agrypninae [50,210]. Protagrypninae are mainly defined by the conspicuous structures on the prosternum and mesoventrite [50,53,75,76]. The validity of the first character was recently discussed and questioned by Muona et al. [99]. Protagrypninae are in urgent need of revision. Their monophyly, limits and systematic placement are unclear and it is possible that many lineages currently classified in this subfamily belong to another Elateridae group or even to other elateroid families, mainly Eucnemidae (see discussion in Muona et al. [99] and herein).

3.9.1. Tribe Desmatini Dolin, 1975

Desmatini Dolin, 1975: 60 [51]. Type genus: Desmatus Dolin, 1975: 60 [51]. For more information, see Bouchard et al. [110] and Kundrata et al. [12].

Remark. Representatives of this tribe differ from related groups mainly in the strongly developed metacoxal plates. This characters is typical for Elaterinae: Physorhinini but can be found in some other Elateridae and also in some other clicking elateroids such as Eucnemidae. Many species of this tribe indeed resemble Physorhinini in external characters, but not in all cases, so the composition and systematic position of Desmatini require further investigation (see discussion in Muona et al. [99]). Regarding genera formerly placed in Desmatini, Muona et al. [99] transferred Anoixis Chang, Kirejtshuk and Ren, 2010 (monotypic) to Eucnemidae: Palaeoxeninae, and Apoclion Chang, Kirejtshuk and Ren, 2010 (all 3 spp.) and Paradesmatus Chang, Kirejtshuk and Ren, 2009 (2 of 3 spp., including the type species) to Eucnemidae: Schizophilinae. One species of Paradesmatus was transferred to Desmatus Dolin, 1975.



• Genus Desmatinus Chang, Kirejtshuk and Ren, 2010

Desmatinus Chang, Kirejtshuk and Ren, 2010: 868 [86]. Type species: Desmatinus cognatus Chang, Kirejtshuk and Ren, 2010: 869 [86]. For more information, see Kundrata et al. [12].



Desmatinus cognatus Chang, Kirejtshuk et Ren, 2010

Desmatinus cognatus Chang, Kirejtshuk and Ren, 2010: 869 [86].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, CNU-COL-LB2008836 (CNU).

Fossil deposit. China: Liaoning Province, Shangyuan County, Beipiao City, Yixian Formation, Huangbanjigou, near Chaomidian Village; 125.45–122.46 Ma (Cretaceous).

Literature. Chang et al. (2010: 869): original description [86]; Dong and Huang (2011: 1225): checklist [81]; Yu et al. (2019: 383): remark [89]; Kundrata et al. (2020: 10): generic catalogue [12]; Muona et al. (2020: 9): revision [99].



• Genus Desmatus Dolin, 1975

Desmatus Dolin, 1975: 60 [51]. Type species: Desmatus lapidarius Dolin, 1975: 61 [51]. For more information, see Kundrata et al. [12].

Remark. This genus needs a revision since some species differ from the type species (and also from each other) in the body proportions, the shape of antenna, thorax, etc. The systematic placement of all species should be re-evaluated since they might represent Eucnemidae, based mainly on the presence of short and broad pronotum and enlarged metacoxal plates.



Desmatus affinis Dolin, 1975

Desmatus affinis Dolin, 1975: 62 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/672 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 62): original description [51]; Dolin (1980: 65): key, catalogue [53]; Korneev and Cate (2005: 11): checklist [120].



Desmatus beckeri Dolin, 1975

Desmatus beckeri Dolin, 1975: 62 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2364 (part + counterpart) (PIN). Two paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2554/689, 2384/489 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 62): original description [51]; Dolin (1980: 65): key, catalogue [53]; Korneev and Cate (2005: 12): checklist [120].



Desmatus lapidarius Dolin, 1975

Desmatus lapidarius Dolin, 1975: 61 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/3274 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2784/1377 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 61): original description [51]; Dolin (1980: 64, 65): key, catalogue [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 10): generic catalogue [12].



Desmatus ponomarenkoi (Chang, Kirejtshuk and Ren, 2009)

Paradesmatus ponomarenkoi Chang, Kirejtshuk and Ren, 2009: 10 [78].

Desmatus ponomarenkoi: Muona et al., 2020: 10 [99].

Type material. Holotype, female, exoskeleton, impression, CNU-COL-NN2006876PC (CNU). Paratype, sex unknown, exoskeleton, impression, CNU-C-NN2007870 (CNU).

Fossil deposit/age. China: Inner Mongolia, Ningcheng County, Jiulongshan Formation, Daohugou; 166.1–157.3 Ma (Jurassic).

Literature. Chang et al. (2009: 10): original description [78]; Chang et al. (2010: 867): remark [86]; Kirejtshuk et al. (2010: 791): checklist [87]; Dong and Huang (2011: 1225): checklist [81]; Schimmel and Tarnawski (2012: 265): remark [132]; Muona et al. (2020: 10): revision, nomenclatural change [99].



Desmatus protensus Dolin, 1980

Desmatus protensus Dolin, 1980: 65 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/2000 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 65): original description [53]; Korneev and Cate (2005: 22): checklist [120].



• Genus Plesiorhaphes Dolin, 1980

Plesiorhaphes Dolin, 1980: 65 [53]. Type species: Plesiorhaphes scaber Dolin, 1980: 66 [53]. For more information, see Kundrata et al. [12].



Plesiorhaphes scaber Dolin, 1980

Plesiorhaphes scaber Dolin, 1980: 66 [53].

Plesiorhaphes scabei: Carpenter, 1992: 305 [68].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2784/1383 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 66): original description [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 10): generic catalogue [12].

3.9.2. Tribe Hypnomorphini Dolin, 1975

Hypnomorphini Dolin, 1975: 54 [51]. Type genus: Hypnomorphus Dolin, 1975: 54 [51]. For more information, see Bouchard et al. [110] and Kundrata et al. [12].

Remark. This tribe needs a revision as it most probably includes various unrelated groups.



• Genus Abrotus Dolin, 1980

Abrotus Dolin, 1980: 62 [53]. Type species: Abrotus sepultus Dolin, 1980: 63 [53]. The systematic placement of this genus is uncertain and should be re-examined. For more information, see Chang et al. [77] and Kundrata et al. [12].



Abrotus reconditus Dolin, 1980

Abrotus reconditus Dolin, 1980: 63 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1451 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2384/482 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 63): original description [53]; Korneev and Cate (2005: 22): checklist [120].



Abrotus sepultus Dolin, 1980

Abrotus sepultus Dolin, 1980: 63 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/3291 (PIN). Paratype, No. 2239/1418.

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 63): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 9): checklist [120]; Chang et al. (2011: 36): remark [77]; Kundrata et al. (2020: 11): generic catalogue [12].



• Genus Adiagnostus Dolin, 1980

Adiagnostus Dolin, 1980: 44 [53]. Type species: Adiagnostus cardiophorinus Dolin, 1980: 45 [53]. For more information, see Kundrata et al. [12].



Adiagnostus ambiguus Dolin, 1980

Adiagnostus ambiguus Dolin, 1980: 45 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1423 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 45): original description [53]; Korneev and Cate (2005: 11): checklist [120].



Adiagnostus cardiophorinus Dolin, 1980

Adiagnostus cardiophorinus Dolin, 1980: 45 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/3231 (part) + 2066/3164 (counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 45): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 9): checklist [120]; Kundrata et al. (2020: 11): generic catalogue [12].



Adiagnostus minutulus Dolin, 1980

Adiagnostus minutulus Dolin, 1980: 46 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2384/455 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 46): original description [53]; Korneev and Cate (2005: 20): checklist [120].



• Genus Codemus Dolin, 1980

Codemus Dolin, 1980: 35 [53]. Type species: Codemus synaptoides Dolin, 1980: 36 [53]. For more information, see Kundrata et al. [12].



Codemus alatus Dolin, 1980

Codemus alatus Dolin, 1980: 39 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2734 (part) + 2066/2725 (counterpart) (PIN). Six paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2554/654 (part + counterpart), 2784/1368, 2784/1391, 2904/901 (part + counterpart), 2904/926, 2997/4462 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 39): original description [53]; Korneev and Cate (2005: 11): checklist [120].



Codemus carinatus Dolin, 1980

Codemus carinatus Dolin, 1980: 38 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2384/464 (PIN). Four paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2384/483, 2784/1405, 2784/1372, 2384/1399 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 38): original description [53]; Korneev and Cate (2005: 13): checklist [120].

Remark. This species strongly differs from its congeners in the presence of long sublateral carinae on pronotum, the short incision of posterior edge of pronotum, and less elongated elytra. It is probable that C. carinatus belongs to another genus.



Codemus jejunus Dolin, 1980

Codemus jejunus Dolin, 1980: 39 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/3261 (PIN). Two paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2239/1434, 2997/1960 (part) + 2997/1965 (counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 39): original description [53]; Korneev and Cate (2005: 17): checklist [120].



Codemus martynovi Dolin, 1980

Codemus martynovi Dolin, 1980: 37 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 1784/37 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Galkino; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 37): original description [53]; Korneev and Cate (2005: 19): checklist [120].



Codemus micros Dolin, 1980

Codemus micros Dolin, 1980: 40 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1441 (PIN). Six paratypes, sex unknown, exoskeletons, compression fossils, No. 2784/1384, 2904/917, 2904/924, 2904/925, 2997/4459, 2997/4460 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 40): original description [53]; Korneev and Cate (2005: 20): checklist [120].



Codemus quadricolis Dolin, 1980

Codemus quadricolis Dolin, 1980: 38 [53].

Codemus quadricollis Dolin, 1980: 35 [53] [also in the legend to Figure 28] [unavailable name, incorrect original spelling ([129], Art. 19.3); First Revisers ([129], Art. 24.2): Korneev and Cate (2005: 22) [120]].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2947 (part + counterpart) (PIN). Seven paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2066/2628, 2066/2658, 2239/1437, 2384/500, 2384/502, 2554/687, 2554/704 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 38): original description [53]; Korneev and Cate (2005: 22): checklist [120].



Codemus sharovi Dolin, 1980

Codemus sharovi Dolin, 1980: 36 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2384/474 (PIN). Five paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2384/465, 2066/2722 (part + counterpart), 2784/1378, 2997/4471, 2997/417 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 36): original description [53]; Korneev and Cate (2005: 23): checklist [120].



Codemus synaptoides Dolin, 1980

Codemus synaptoides Dolin, 1980: 36 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, Nos. 2239/1411 (part) + 2239/1443 (counterpart) (PIN). 11 paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2239/1433 (part + counterpart), 2066/2418, 2066/2696, 2066/3132, 2384/481 (part) + 2384/483 (counterpart), 2554/680, 2554/682, 2904/899 (part + counterpart), 2997/1994, 2997/2012, 2997/4473 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 36): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 12): generic catalogue [12].



Codemus teres Dolin, 1980

Codemus teres Dolin, 1980: 38 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2904/905 (part + counterpart) (PIN). Five paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2997/1996, 2997/2016, 2066/2703, 2066/2696, 2554/695 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 38): original description [53]; Korneev and Cate (2005: 24): checklist [120].



Codemus zherichini Dolin, 1980

Codemus zherichini Dolin, 1980: 37 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/1999 (PIN). Three paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2997/4464, 2784/1367 (part + counterpart), 2784/1365 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 37): original description [53]; Korneev and Cate (2005: 25): checklist [120].



• Genus Dolinelater Huber, Marggi and Menkveld-Gfeller, 2017

Idiomorphus Dolin, 1980: 60 [53]. Type species: Idiomorphus singularis Dolin, 1980: 60 [53]. For more information, see Kundrata et al. [12]. Preoccupied by Idiomorphus Chaudoir, 1846 (Coleoptera: Carabidae) [211].

Dolinelater Huber, Marggi and Menkveld-Gfeller, 2017: 2 [211]. Replacement name for Idiomorphus Dolin, 1980. Erroneously omitted in the generic catalogue by Kundrata et al. [12].



Dolinelater asperatus (Dolin, 1980)

Idiomorphus asperatus Dolin, 1980: 61 [53].

Dolinelater asperatus: Huber et al. 2017: 2 [211].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/3300 (PIN). Two paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2997/2021, 2997/1967 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 61): original description [53]; Korneev and Cate (2005: 12): checklist [120]; Huber et al. (2017: 2): nomenclatural remark [211].



Dolinelater singularis (Dolin, 1980)

Idiomorphus singularis Dolin, 1980: 60 [53].

Dolinelater singularis: Huber et al., 2017: 2 [211].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1438 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 60): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Huber et al. (2017: 2): nomenclatural remark [211]; Kundrata et al. (2020: 12): generic catalogue [12].



• GenusElaterophanes Handlirsch, 1906

Elaterophanes Handlirsch, 1906: 436 [26]. Type species: Elater socius Giebel, 1856: 91 [16] (=Elater vetustus Brodie, 1845: 101 [13]). For more information, see Kundrata et al. [12].

Remark. The diagnosis, limits and systematic placement of this genus are unclear.



Elaterophanes acutus Cockerell, 1916

Elaterophanes acutus Cockerell, 1916: 478 [31].

Type material. Holotype, sex unknown, elytron, impression, No. 61,401 (USNM).

Fossil deposit/age. United Kingdom: Gloucestershire, Wainlode Cliff; 208.5–201.3 Ma (Triassic).

Literature. Cockerell (1916: 478): original description [31]; Handlirsch (1938: 65): catalogue [212].

Remark. The description of this species is based on an isolated elytron and, therefore, its generic attribution is rather problematic [212].



Elaterophanes regius Whalley, 1985

Elaterophanes regius Whalley, 1985: 165 [60].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 59,385 (BMNH). One paratype, No. 53,952 (BMNH).

Fossil deposit/age. United Kingdom: Charmouth Mudstone Formation, Dorset, Flatstones, Black Ven, Charmouth; 196.5–189.6 Ma (Jurassic).

Literature. Whalley (1985: 165): original description [60]; Martin (2010: 934): remark [73].



Elaterophanes vetustus (Brodie, 1845)

Elater vetustus Brodie, 1845: 101 [13].

Elater socius Giebel, 1856: 91 [16]. Synonymized with E. vetustus by Whalley (1985: 165) [60].

Elaterophanes socius: Handlirsch, 1906: 436 [26].

Elaterophanes vetustus: Handlirsch, 1906: 437 [26].

Type material. Elater vetustus. Holotype, sex unknown, compression fossil, No. NHM I.3576 (BMNH). Elater socius. Holotype, sex unknown, compression fossil, No. NHM I.3563 (BMNH).

Fossil deposit/age. United Kingdom: Apperley, Lilstock Formation; 208.5–201.3 Ma.

Literature. Brodie (1845: 101): original description of E. vetustus [13]; Giebel (1856: 91): original description of E. vetustus, revision [16]; Phillips (1871: 123): checklist [213]; Heer (1883: 98): remark [137]; Scudder (1891: 204): catalogue [24]; Handlirsch (1906: 436): redescription of E. socius and E. vetustus [26]; Cockerell (1916: 478): catalogue [31]; Handlirsch (1938: 65, 69): checklist [212]; Haupt (1950: 102): remark [44]; Dolin (1973: 73): remark [50]; Whalley (1985: 165): taxonomy, remark [60]; Carpenter (1992: 304): generic catalogue [68]; Kundrata et al. (2020: 11): generic catalogue [12].

Remark. Brodie [13] described Elater vetustus based on a compression fossil from Lilstock Formation, Apperley (Triassic) in the United Kingdom. Heer [17] described Elaterites vetustus based on a single elytron from Schambelen, Aargau (Jurassic) in Switzerland, but he attributed the species name to Brodie. It is not clear whether Heer [17] thought that the fossil from Switzerland was conspecific with the Brodie’s Elater vetustus from Apperley beds of the United Kingdom, and if/why he transferred that species from Elater to Elaterites. Later, Handlirsch [26] transferred Elater vetustus Brodie, 1845 to Elaterophanes (as he did with E. socius Giebel, 1856), and he erected a new genus, Dysarestus Handlirsch, 1906, for Elaterites vetustus Heer, 1865. He suggested that it might belong to Elaterophanes. Here, we follow Carpenter [68], who classified Dysarestus in Coleoptera incertae sedis.



• GenusGraciolacon Dolin, 1980

Graciolacon Dolin, 1980: 61 [53]. Type species: Graciolacon aeternus Dolin, 1980: 62 [53]. For more information, see Kundrata et al. [12].

Graciolacou: Dolin, 1980: legend of Figure 67 [53] [unavailable name, incorrect original spelling ([129], Art. 19.3); First Reviser ([129], Art. 24.2): Carpenter (1992: 304) [68]].



Graciolacon aeternus Dolin, 1980

Graciolacon aeternus Dolin, 1980: 62 [53].

Graciolacou [sic!] aethernus: Dolin, 1980: legend of drawing 67 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 965/39 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Galkino, East Karatau; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 62): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 11): checklist [120]; Kundrata et al. (2020: 11): generic catalogue [12].



• GenusHypnomorphoides Dolin, 1980

Hypnomorphoides Dolin, 1980: 54 [53]. Type species: Hypnomorphoides catachtonius Dolin, 1980: 55 [53]. For more information, see Kundrata et al. [12].

Remark. This genus might belong to Eucnemidae as all its species have a compact body, with a short and broad thorax, and short elytra. Unfortunately, the main diagnostic characters [99] are either absent or not well visible on the original drawings or photographs [53].



Hypnomorphoides angularis Dolin, 1980

Hypnomorphoides angularis Dolin, 1980: 55 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/4461 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 55): original description [53].



Hypnomorphoides catachtonius Dolin, 1980

Hypnomorphoides catachtonius Dolin, 1980: 55 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/3062 (PIN). Three paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2904/916, 2997/2014, 2997/2028 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 55): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 11): generic catalogue [12].



Hypnomorphoides latus Dolin, 1980

Hypnomorphoides latus Dolin, 1980: 56 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1449 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2384/449 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 56): original description [53]; Korneev and Cate (2005: 19): checklist [120].



Hypnomorphoides procerulus Dolin, 1980

Hypnomorphoides procerulus Dolin, 1980: 56 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2904/915 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 56): original description [53]; Korneev and Cate (2005: 22): checklist [120].



• GenusHypnomorphus Dolin, 1975

Hypnomorphus Dolin, 1975: 54 [51]. Type species: Hypnomorphus rohdendorfi Dolin, 1975: 56 [51]. For more information, see Kundrata et al. [12].

Remark. This genus needs a revision since some species differ from the type species (and also from each other) in the body size, proportions, the shape of pronotum, elytra, etc. Most species probably belong to Eucnemidae based on the compact body, with a short and broad thorax, and short elytra. Additionally, H. rasnitzyni has antennae with last three antennomeres enlarged, which is a character present in Eucnemidae rather than Elateridae. Unfortunately, the main diagnostic characters [99] are usually absent or not well visible on the original drawings or photographs [51,53].



Hypnomorphus aemulus Dolin, 1975

Hypnomorphus aemulus Dolin, 1975: 56 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/692 (PIN). Three paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2239/1417, 2239/1454, 2554/690 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 56): original description [51]; Dolin (1980: 28, 30): key, additional specimens: Nos. 2784/1385, 2784/1388 (PIN) [53]; Korneev and Cate (2005: 11): checklist [120].



Hypnomorphus angulosus Dolin, 1980

Hypnomorphus angulosus Dolin, 1980: 29 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/415 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 29): original description [53]; Korneev and Cate (2005: 11): checklist [120].



Hypnomorphus carpolithus Dolin, 1975

Hypnomorphus carpolithus Dolin, 1975: 57 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2606 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 57): original description [51]; Dolin (1980: 27,30): key, additional specimens: Nos. 2997/419, 2997/2007, 2997/4457, 2784/1392, 2784/1386 (PIN) [53]; Korneev and Cate (2005: 13): checklist [120].



Hypnomorphus confusus Dolin, 1975

Hypnomorphus confusus Dolin, 1975: 59 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 1789/213 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Galkino; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 59): original description [51]; Dolin (1980: 27): key, additional specimens: Nos. 2784/1382, 2784/1393, 2784/1401, 2904/903, 2904/910, 2997/1393, 2997/2009 (PIN) [53]; Korneev and Cate (2005: 14): checklist [120].



Hypnomorphus curtus Dolin, 1980

Hypnomorphus curtus Dolin, 1980: 28 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2806 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2384/472 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 28): original description [53]; Korneev and Cate (2005: 14): checklist [120].



Hypnomorphus distinctus Dolin, 1975

Hypnomorphus distinctus Dolin, 1975: 56 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/653 (part + counterpart) (PIN). Three paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2554/652, 2239/1469, 2066/2764 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 164.7–155.7 Ma (Jurassic).

Literature. Dolin (1975: 56): original description [51]; Dolin (1980: 27,30): key, additional specimens: Nos. 2904/907 (part + counterpart), 2997/4470, 2904/923 (PIN) [53]; Korneev and Cate (2005: 14): checklist [120].



Hypnomorphus dubius Dolin, 1975

Hypnomorphus dubius Dolin, 1975: 60 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/651 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 60): original description [51]; Dolin (1980: 27,30): key, additional specimens: Nos. 2239/1453, 2784/1403, 2997/428, 2997/1969 (PIN) [53]; Korneev and Cate (2005: 14): checklist [120].



Hypnomorphus gigas Dolin, 1980

Hypnomorphus gigas Dolin, 1980: 29 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/4472 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 29): original description [53]; Korneev and Cate (2005: 15): checklist [120].



Hypnomorphus imperspicuus Dolin, 1975

Hypnomorphus imperspicuus Dolin, 1975: 59 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/678 (PIN). Two paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2066/3036, 2066/2838 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 59): original description [51]; Dolin (1980: 28,30): key, additional specimen: No. 2904/904 (PIN) [53]; Korneev and Cate (2005: 16): checklist [120].



Hypnomorphus induratus Dolin, 1975

Hypnomorphus induratus Dolin, 1975: 57 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1427 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 57): original description [51]; Dolin (1980: 27,30): key, additional specimen: No. 2997/4468 (PIN) [53]; Korneev and Cate (2005: 10): checklist [120].



Hypnomorphus inventus Dolin, 1975

Hypnomorphus inventus Dolin, 1975: 57 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2384/491 (PIN). Four paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2231/15 (Galkino), 2384/450, 2384/479, 2554/697 (Mikhailovka) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka (type locality), Karatau, Galkino; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 57): original description [51]; Dolin (1980: 27,30): key, additional specimens: Nos. 2384/498, 2784/1381, 2784/1364 (PIN) [53]; Korneev and Cate (2005: 17): checklist [120].



Hypnomorphus minutus Dolin, 1975

Hypnomorphus minutus Dolin, 1975: 59 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1431 (PIN). 10 paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2239/1428, 2239/1429, 2239/1430, 2239/1440 (part + counterpart), 2239/1424, 2554/691, 2554/655, 2554/700, 2066/2318, 2066/3248 (part) + 2066/2744 counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 164.7–155.7 Ma (Jurassic).

Literature. Dolin (1975: 59): original description [51]; Dolin (1980: 27,30): key, additional specimens: Nos. 2784/1395, 2997/1981, 2997/2004, 2997/4457, 2997/4460 (PIN) [53]; Korneev and Cate (2005: 20): checklist [120].



Hypnomorphus rasnitzyni Dolin, 1980

Hypnomorphus rasnitzyni Dolin, 1980: 28 [53].

Type material. Holotype, male, exoskeleton, compression fossil, No. 2784/1362 (part + counterpart) (PIN). Paratype, female, sex unknown, exoskeleton, compression fossil, No. 2997/418 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 164.7–155.7 Ma (Jurassic).

Literature. Dolin (1980: 28): original description [53]; Korneev and Cate (2005: 22): checklist [120]; Dong et al. (2011: 482): remark [214].

Remark. Based on the habitus and shapes of antenna and pronotum, this species most probably belongs to Eucnemidae.



Hypnomorphus rohdendorfi Dolin, 1975

Hypnomorphus rohdendorfi Dolin, 1975: 56 [51].

Hypnomorphus rohdendorphi: Dolin, 1980: 28 [53] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, male, exoskeleton, compression fossil, No. 2384/457 (part + counterpart) (PIN). Three paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2231/76 (Galkino), 2066/2341, 254/676 (Mikhailovka) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka (type locality), Karatau, Galkino; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 56): original description [51]; Dolin (1980: 28,30): key, additional specimens: Nos. 2997/415, 2997/416, 2997/4469 (PIN) [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 12): generic catalogue [12].



• GenusLapidiconides Dolin, 1980

Lapidiconides Dolin, 1980: 43 [53]. Type species: Lapidiconides excellens Dolin, 1980: 43 [53]. For more information, see Kundrata et al. [12].

Remark. Species of this genus strongly resemble Eucnemidae in the compact body, with wide prothorax and relatively short elytra, and also Throscidae in almost trapezoidal pronotum. Unfortunately, the main diagnostic characters [99] are either absent or not well visible on the original drawings or photographs [53]. Additionally, L. innatus is most probably not congeneric with other two species.



Lapidiconides brevis Dolin, 1980

Lapidiconides brevis Dolin, 1980: 44 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/3156 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 44): original description [53]; Korneev and Cate (2005: 13): checklist [120].



Lapidiconides excellens Dolin, 1980

Lapidiconides excellens Dolin, 1980: 43 [53].

Lapidoconides [sic!] excellens Dolin, 1980: 43 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2453 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 43): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 12): generic catalogue [12].



Lapidiconides innatus Dolin, 1980

Lapidiconides innatus Dolin, 1980: 44 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2784/1376 (part) + 2784/1400 (counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 44): original description [53]; Korneev and Cate (2005: 17): checklist [120].

Remark. This species differs considerably from its congeners in the large body size, shape of prosternum and hypomeron, less developed longitudinal sutures on prosternum, and more broadened metacoxal plates. Its systematic placement should be re-evaluated after the study of the type material.



• Genus Lapidostenus Dolin, 1980

Lapidostenus Dolin, 1980: 30 [53]. Type species: Lapidostenus infossus Dolin, 1980: 31 [53]. For more information, see Kundrata et al. [12].

Remark. This genus needs a revision since some species differ from the type species (and also from each other) in the body proportions, the shape of pronotum, elytra, etc. Most species probably belong to Eucnemidae based on the compact body, with a short and broad thorax, and short elytra. Only L. tarbinskyi Dolin, 1980 looks like a typical elaterid. Unfortunately, the main diagnostic characters [99] are usually absent or not well visible on the original drawings or photographs [53].



Lapidostenus infossus Dolin, 1980

Lapidostenus infossus Dolin, 1980: 31 [53].

Lapidostenus intossus: Dolin, 1980: legend of Figure 15 [53] [unavailable name, incorrect original spelling ([129], Art. 19.3); First Reviser ([129], Art. 24.2): Carpenter (1992: 304) [68]].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1439 (part + counterpart) (PIN). Two paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2066/2431, 2997/2015 (part + counterpart) (PIN).

Fossil deposit. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 31): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 12): generic catalogue [12].



Lapidostenus insignis Dolin, 1980

Lapidostenus insignis Dolin, 1980: 32 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2784/1379 (PIN).

Fossil deposit. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 32): original description [53]; Korneev and Cate (2005: 17): checklist [120].



Lapidostenus longicornis Dolin, 1980

Lapidostenus longicornis Dolin, 1980: 31/32 [53].

Lapidostenus lognicornis Dolin, 1980: 32 [53] [unavailable name, incorrect original spelling ([129], Art. 19.3); First Revisers ([129], Art. 24.2): Korneev and Cate (2005: 19) [120]].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2784/1393 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 32): original description [53]; Korneev and Cate (2005: 19): checklist [120].



Lapidostenus scutellaris Dolin, 1980

Lapidostenus scutellaris Dolin, 1980: 31 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2909 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2997/2010 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 31): original description [53]; Korneev and Cate (2005: 23): checklist [120].



Lapidostenus tarbinskyi Dolin, 1980

Lapidostenus tarbinskyi Dolin, 1980: 32 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1450 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 32): original description [53]; Korneev and Cate (2005: 24): checklist [120].

Remark. This species resembles Cardiophorinae in having the strongly arcuate sides of pronotum, with posterior angles short and curved inwards.



• GenusLithoptychus Dolin, 1980

Lithoptychus Dolin, 1980: 57 [53]. Type species: Lithoptychus handlirschi Dolin, 1980: 57 [53]. For more information, see Kundrata et al. [12].

Remark: This genus might belong to Eucnemidae because its type species, L. handlirschi, along with L. minutus Dolin, 1980, have a compact body, with a short and broad thorax, and short elytra. Unfortunately, the main diagnostic characters [99] are missing in the original figures [53], and, therefore, the taxonomic decision should be postponed until the type material is studied. Additionally, L. incertus Dolin, 1980 has antennae with last three antennomeres enlarged, which is a character present in Eucnemidae rather than Elateridae. Lithoptychus carinatissimus Dolin, 1980 externally also resembles Eucnemidae but it has very conspicuous sublateral carina on each side of pronotum.



Lithoptychus carinatissimus Dolin, 1980

Lithoptychus carinatissimus Dolin, 1980: 59 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2904/921 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 59): original description [53]; Korneev and Cate (2005: 13): checklist [120].



Lithoptychus handlirschi Dolin, 1980

Lithoptychus handlirschi Dolin, 1980: 57 [53].

Lithoptychus handlischi: Dolin, 1980: legend of Figure 60 [53] [unavailable name, incorrect original spelling ([129], Art. 19.3); First Reviser ([129], Art. 24.2): Carpenter (1992: 305) [68]].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/696 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2997/4439 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 57): original description [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 12): generic catalogue [12].



Lithoptychus incertus Dolin, 1980

Lithoptychus incertus Dolin, 1980: 58 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2452/41 (PIN). Three paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2784/1373, 2784/1390, 2784/1398 (Mikhailovka) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Galkino (type locality), Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 58): original description [53]; Korneev and Cate (2005: 16): checklist [120]; Dong and Huang (2011: 1228): morphological remark [81].



Lithoptychus minutus Dolin, 1980

Lithoptychus minutus Dolin, 1980: 58 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1461 (PIN). Three paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2239/1495, 2997/426, 2997/427 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 58): original description [53]; Korneev and Cate (2005: 20): checklist [120].



• GenusLithosomus Dolin, 1980

Lithosomus Dolin, 1980: 46 [53]. Type species: Lithosomus erosus Dolin, 1980: 47 [53]. For more information, see Kundrata et al. [12].

Remark. The systematic placement of this genus needs to be re-evaluated since its type species might actually represent Eucnemidae.



Lithosomus erosus Dolin, 1980

Lithosomus erosus Dolin, 1980: 47 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/1987 (part) + 2997/1995 (counterpart) (PIN). Two paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2997/1989, 2997/1967 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 47): original description [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 12): generic catalogue [12].

Remark. This species probably belongs to Eucnemidae due to its compact body, with a short and broad thorax, short elytra, and antennae with last three antennomeres enlarged. However, since the main diagnostic characters [99] are not well visible in the original figures [53], we prefer to postpone any taxonomic decision until the type material is examined in detail.



Lithosomus longicollis Dolin, 1980

Lithosomus longicollis Dolin, 1980: 47 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2784/1363 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 47): original description [53]; Korneev and Cate (2005: 19): checklist [120].

Remark. Generic attribution of this species needs re-examination as it strongly differs from the type species of Lithosomus in the elongated pronotum, with slightly arcuate sides (pronotum short, broad, strongly campaniform in L. erosus), more elongated elytra (elytra rather short in L. erosus), more broadened metacoxal plates which are only slightly narrowed outwards (metacoxal plates notably narrowed outwards in L. erosus), and larger punctures in elytral striae (small punctures in L. erosus).

Although the body proportions of L. longicollis somewhat resemble Cardiophorinae or Negastriinae, with almost parallel-sided prosternal sutures and only slightly broadened prosternum being more typical for Cardiophorinae, there are no reliable characters that would point us to the proper systematic placement of this species.



• GenusNecrocoelus Dolin, 1980

Necrocoelus Dolin, 1980: 59 [53]. Type species: Necrocoelus aselloides Dolin, 1980: 59 [53]. For more information, see Kundrata et al. [12].

Remark. This genus might represent Cardiophorinae based on the globose pronotum, with short posterior angles, and a thickened and short prosternal process.



Necrocoelus aselloides Dolin, 1980

Necrocoelus aselloides Dolin, 1980: 59 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2520 (part + counterpart) (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2904/909 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 59): original description [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 12): generic catalogue [12].



• Genus Negastrioides Dolin, 1980

Negastrioides Dolin, 1980: 52 [53]. Type species: Negastrioides tenuis Dolin, 1980: 52 [53]. For more information, see Kundrata et al. [12].

Remark. Species of this genus resemble Eucnemidae in having a broad prothorax with short pronotal posterior angles and a short prosternal process. Available figures in Dolin [53] also suggest that the type species, N. tenuis, along with N. globicollis Dolin, 1980, have a pedicel subapically attached to scape, a condition typical for Eucnemidae [99]. Basal antennomeres in remaining two species are absent in figures [53]. Systematic placement of Negastrioides needs further investigation.



Negastrioides globicollis Dolin, 1980

Negastrioides globicollis Dolin, 1980: 53 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/705 (PIN). Three paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2784/1375, 2997/1972, 2997/1993 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 53): original description [53]; Korneev and Cate (2005: 15): checklist [120].



Negastrioides tenuicornis Dolin, 1980

Negastrioides tenuicornis Dolin, 1980: 53 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2847 (PIN). Three paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2997/1971, 2997/2001, 2997/2006 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 53): original description [53]; Korneev and Cate (2005: 24): checklist [120].



Negastrioides tenuis Dolin, 1980

Negastrioides tenuis Dolin, 1980: 52 [53].

Type material. Holotype? male, exoskeleton, compression fossil, No. 2066/2320 (part + counterpart) (PIN). Three paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2066/2886 (part + counterpart), 2239/1447, 2997/2002 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 52): original description [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 13): generic catalogue [12].



Negastrioides tscherepanovi Dolin, 1980

Negastrioides tscherepanovi Dolin, 1980: 54 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2451 (PIN). Two paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2997/424, 2997/4458 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 54): original description [53]; Korneev and Cate (2005: 24): checklist [120].



• GenusParahypnomorphus Dolin, 1980

Parahypnomorphus Dolin, 1980: 33 [53]. Type species: Parahypnomorphus jurassicus Dolin, 1980: 33 [53]. For more information, see Kundrata et al. [12].

Remark. This genus might belong to Eucnemidae as all its species have a compact body, with a short and broad thorax, and short elytra. Illustrations of antennae also support this hypothesis [99], especially those of P. longicornis Dolin, 1980; however, they should be examined directly on the type material.



Parahypnomorphus jurassicus Dolin, 1980

Parahypnomorphus jurassicus Dolin, 1980: 33 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/703 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 33): original description [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 13): generic catalogue [12].



Parahypnomorphus longicornis Dolin, 1980

Parahypnomorphus longicornis Dolin, 1980: 34 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1442 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2997/1988 (PIN).

Fossil deposit. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 1661.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 34): original description [53]; Korneev and Cate (2005: 19): checklist [120].



Parahypnomorphus similis Dolin, 1980

Parahypnomorphus similis Dolin, 1980: 34 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/2013 (PIN).

Fossil deposit. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 34): original description [53]; Korneev and Cate (2005: 23): checklist [120].



• GenusPlatyelater Dolin, 1980

Platyelater Dolin, 1980: 40 [53]. Type species: Platyelater reflexicollis Dolin, 1980: 41 [53]. For more information, see Kundrata et al. [12].

Remark. All species other than the type species, P. reflexicollis, resemble Eucnemidae in having a compact body, with a short and broad thorax, and short elytra. Available figures of antennae also support this hypothesis. Additionally, P. figeratus Dolin, 1980 shares almost trapezoidal pronotum, with Throscidae. Systematic position of those species should be re-evaluated after study of the type material.



Platyelater figeratus Dolin, 1980

Platyelater figeratus Dolin, 1980: 42 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1963 (PIN). Seven paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2239/1408, 2239/1410 (female), 2239/1457, 2066/2461, 2904/920, 2997/1990, 2997/2003 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 42): original description [53]; Korneev and Cate (2005: 15): checklist [120].

Remark. This species notably differs from its congeners, especially in the body proportions and the shape of metacoxal plates.



Platyelater quiescentus Dolin, 1980

Platyelater quiescentus Dolin, 1980: 42 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/416 (PIN). Two paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2784/1402, 2997/414 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 42): original description [53]; Korneev and Cate (2005: 22): checklist [120].



Platyelater reflexicollis Dolin, 1980

Platyelater reflexicollis Dolin, 1980: 41 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2904/900 (part + counterpart) (PIN). Six paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2384/485, 2554/683, 2784/1387, 2904/906 (part + counterpart), 2904/914, 2997/423 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 41): original description [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Dong et al. (2011: 482): remark [214]; Kundrata et al. (2020: 13): generic catalogue [12].



Platyelater sukatschevae Dolin, 1980

Platyelater sukatschevae Dolin, 1980: 41 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/2026 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 41): original description [53]; Korneev and Cate (2005: 24): checklist [120].

3.9.3. Tribe Pollostelaterini Alekseev, 2011

Pollostelaterini Alekseev, 2011: 424 [75]. Type genus: Pollostelater Alekseev, 2011: 424 [75]. For more information, see Kundrata et al. [12].



• Genus Pollostelater Alekseev, 2011

Pollostelater Alekseev, 2011: 424 [75]. Type species: Pollostelater baissensis Alekseev, 2011: 424 [75]. For more information, see Kundrata et al. [12].

Remark. Based on the original description and available images [75], we cannot exclude the possibility that this genus belongs to Eucnemidae due to the compact body, with a short and broad thorax. The longitudinal sutures on prosternum are obviously situated close to pronotosternal sutures, so they might be just deeply furrowed pronotosternal sutures as in some Eucnemidae. The presence of a sublateral carina on pronotum, which is a character typical for Eateridae rather than Eucnemidae, should be re-evaluated on the type material.



Pollostelater baissensis Alekseev, 2011

Pollostelater baissensis Alekseev, 2011: 424 [75].

Type material. Holotype, sex unknown, exoskeleton, impression, No. 3064/7100 (PIN).

Fossil deposit/age. Russia: Buryatia, Zaza Formation, Baissa; 125.0–113.0 Ma (Cretaceous).

Literature. Alekseev (2011: 424): original description [75]; Kundrata et al. (2020: 13): generic catalogue [12].

3.9.4. Tribe Protagrypnini Dolin, 1973

Protagrypnini Dolin, 1973: 74 [50]. Type genus: Protagrypnus Dolin, 1973: 75 [50]. For more information, see Bouchard et al. [110] and Kundrata et al. [12].



• Genus Acheonus Dolin, 1980

Acheonus Dolin, 1980: 20 [53]. Type species: Acheonus abbreviatus Dolin, 1980: 21 [53]. For more information, see Kundrata et al. [12].

Remark. Species of this genus externally resemble Negastriinae but their placement in Elateridae should be rather confirmed by a study of type material. There are inconsistencies in original descriptions and corresponding images in Dolin [53] regarding the presence or absence of sublateral carinae in pronotal posterior angles.



Acheonus abbreviatus Dolin, 1980

Acheonus abbreviatus Dolin, 1980: 21 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2384/462 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2384/462 [in the original description, holotype and paratype have the same number, which is probably an error] (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 21): original description [53]; Carpenter (1992: 304): generic catalogue [68]; Korneev and Cate (2005: 9): checklist [120]; Schimmel and Tarnawski (2012: 265): remark [132]; Kundrata et al. (2020: 13): generic catalogue [12].



Acheonus gracilis Dolin, 1980

Acheonus gracilis Dolin, 1980: 21 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2784/1404 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 21): original description [53]; Schimmel and Tarnawski (2012: 265): remark [132].



Acheonus minutissimus Dolin, 1980

Acheonus minutissimus Dolin, 1980: 21 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/1992 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 21): original description [53]; Korneev and Cate (2005: 20): checklist [120]; Schimmel and Tarnawski (2012: 265): remark [132].



• Genus Clavelater Dong and Huang, 2011

Clavelater Dong and Huang, 2011: 1225 [81]. Type species: Clavelater ningchengensis Dong and Huang, 2011: 1226 [81]. For more information, see Kundrata et al. [12].

Remark. Muona et al. [99] suggested that this genus may represent an unknown lineage of Eucnemidae rather than Elateridae. They based their conclusions on the available literature and figures but the type material should be studied to solve the placement of Clavelater within Elateroidea. Nevertheless, we agree with the conclusions made by Muona et al. [99].



Clavelater ningchengensis Dong and Huang, 2011

Clavelater ningchengensis Dong and Huang, 2011: 1226 [81].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 151,836 (NIGP).

Fossil deposit/age. China: Inner Mongolia, Ningcheng County, Jiulongshan Formation, Daohugou; 166.1–157.3 Ma (Jurassic).

Literature. Dong and Huang (2011: 1226): original description [81]; Yu et al. (2019: 384): remark [89]; Kundrata et al. (2020: 14): generic catalogue [12]; Muona et al. (2020: 11): revision [99].



• Genus Koreagrypnus Sohn and Nam, 2019

Koreagrypnus Sohn and Nam in Sohn et al., 2019: 6 [76]. Type species: Koreagrypnus jinju Sohn and Nam in Sohn et al., 2019: 6 [76]. For more information, see Kundrata et al. [12].



Koreagrypnus jinju Sohn and Nam, 2019

Koreagrypnus jinju Sohn and Nam in Sohn et al., 2019: 6 [76].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, GNUE-I-2013002 and GNUE-I-2013002c (GNUE).

Fossil deposit/age. South Korea: Gyeongsangnamdo Province, Jinju Formation, Jeongchon Mountain, Jeongchon City, Jinju; 113.0–100.5 Ma (Cretaceous).

Literature. Sohn et al. (2019: 6): original description [76]; Kundrata et al. (2020: 14): generic catalogue [12].



• Genus Lithocoelus Dolin, 1975

Lithocoelus Dolin, 1975: 53 [51]. Type species: Lithocoelus detrusus Dolin, 1975: 53 [51]. For more information, see Kundrata et al. [12].

Remark. This genus might belong to Eucnemidae as both its species have a compact body, with a short and broad thorax, and relatively short elytra [51]. The type material needs to be checked for characters distinguishing (with more or less certainty) Elateridae from Eucnemidae [99].



Lithocoelus detrusus Dolin, 1975

Lithocoelus detrusus Dolin, 1975: 53 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2384/484 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 53): original description [51]; Dolin (1980: 20): remark [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 14): generic catalogue [12].



Lithocoelus karatavicus Dolin, 1975

Lithocoelus karatavicus Dolin, 1975: 54 [51].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1425 (part + counterpart) (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2335/82 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1975: 54): original description [51]; Dolin (1980: 20): remark [53]; Korneev and Cate (2005: 18): checklist [120].



• Genus Lithomerus Dolin, 1980

Lithomerus Dolin, 1980: 23 [53]. Type species: Lithomerus cockerelli Dolin, 1980: 23 [53]. For more information, see Kundrata et al. [12].

Remark. This genus needs a revision since some species differ from the type species (and also from each other) in the body proportions, the shape of pronotum, elytra, etc. Lithomerus cockerelli (type species) and L. brevicollis Dolin, 1980 are probably correctly assigned to Elateridae but other species from the Palearctic deposits currently assigned to this genus might belong to Eucnemidae as they have a compact body, with a short and broad thorax, and short elytra. Lithomerus wunda Martin, 2010 from Australia is most probably a member of Throscidae [99].



Lithomerus brachycollis Dolin, 1980

Lithomerus brachycollis Dolin, 1980: 23 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/4463 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 23): original description [53]; Martin (2010: 934): remark [73].

Remark. This species was mentioned by Dolin [53] only in the key on page 23 but the author obviously forgot to include the usual description which was otherwise available for all other new species in that paper. The holotype was figured in Figure 9 (drawing) and Plate I, Figure 3 (photograph), its collection number was mentioned in the figure legends, and the depository was specified in the introductory part of the paper [53]. The character states mentioned in the key on page 23 in Dolin [53] fulfill the requirements of Art. 13.1.1 [129] and, therefore, L. brachycollis is an available name.



Lithomerus brevicollis Dolin, 1980

Lithomerus brevicollis Dolin, 1980: 24 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2904/908 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 24): original description [53]; Dolin and Nel (2002: 341): remark [82]; Korneev and Cate (2005: 13): checklist [120]; Martin (2010: 934): remark [73]; Schimmel and Tarnawski (2012: 265): remark [132].



Lithomerus buyssoni Dolin and Nel, 2002

Lithomerus buyssoni Dolin and Nel, 2002: 341 [82].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MNHN-LP-R.55231 (MNHN).

Fossil deposit/age. China: Liaoning Province, Yixian Formation, Beipiao City, Chaomidian Village; 125.45–122.46 Ma (Cretaceous).

Literature. Dolin and Nel (2002: 341): original description [82]; Kirejtshuk et al. (2010: 792): checklist [87]; Martin (2010: 934): remark [73]; Muona et al. (2020: 11): revision [99].

Remark. Muona et al. [99] suggested that this species might belong either to Elateridae: Protagrypninae or Eucnemidae: Palaeoxeninae but they did not study the holotype.



Lithomerus cockerelli Dolin, 1980

Lithomerus cockerelli Dolin, 1980: 23 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2384/454 (PIN). Seven paratypes, sex unknown, exoskeletons, compression fossils, Nos. 2384/460, 2384/492, 2784/1389, 2554/685, 2997/1977, 2997/1984, 2784/1366 (part + counterpart) (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 23): original description [53]; Carpenter (1992: 305): generic catalogue [68]; Dolin and Nel (2002: 341): remark [82]; Korneev and Cate (2005: 10): checklist [120]; Martin (2010: 932): remark [73]; Schimmel and Tarnawski (2012: 265): remark [132]; Yu et al. (2019: 382): remark [89]; Kundrata et al. (2020: 14): generic catalogue [12].



Lithomerus contiguus Dolin, 1980

Lithomerus contiguus Dolin, 1980: 24 [53].

Lithomerus contiguous: Schimmel and Tarnawski, 2012: 265 [132] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2978 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2997/2019 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 24): original description [53]; Dolin and Nel (2002: 341): remark [82]; Korneev and Cate (2005: 14): checklist [120]; Martin (2010: 934): remark [73]; Schimmel and Tarnawski (2012: 265): remark [132].



Lithomerus longulus Dolin, 1980

Lithomerus longulus Dolin, 1980: 24 [53].

Lithomerus longulatus: Schimmel and Tarnawski, 2012: 265 [132] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/3018 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 24): original description [53]; Dolin and Nel (2002: 341): remark [82]; Korneev and Cate (2005: 19): checklist [120]; Martin (2010: 934): remark [73]; Schimmel and Tarnawski (2012: 265): remark [132].



Lithomerus wunda Martin, 2010

Lithomerus wunda Martin, 2010: 932 [73].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, WAM 08.179 (WAM). One paratype, sex unknown, exoskeleton, compression fossil, WAM 08.180 (WAM).

Fossil deposit/age. Australia: Cattamarra Coal Measures Formation, Mintaja M1 site; 182.7–174.1 Ma (Jurassic).

Literature. Martin (2010: 932): original description [73].

Remark. This species is obviously not conspecific with any other Lithomerus species. Based on the figures in the original description [73], Muona et al. [99] suggested that it should be placed within Throscidae based on the body size and the shape of antenna resting in the antennal groove. They postponed its transfer to Throscidae until the holotype is examined.



• Genus Megalithomerus Sohn and Nam, 2019

Megalithomerus Sohn and Nam in Sohn et al., 2019: 3 [76]. Type species: Megalithomerus magohalmii Sohn and Nam in Sohn et al., 2019: 3 [76]. For more information, see Kundrata et al. [12].



Megalithomerus magohalmii Sohn and Nam, 2019

Megalithomerus magohalmii Sohn and Nam in Sohn et al. 2019: 4 [76].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, GNUE-I-2013001 and GNUE-I-2013001c (GNUE).

Fossil deposit/age. South Korea: Gyeongsangnamdo Province, Jinju Formation, Jeongchon Mountain, Jeongchon City; 113.0–100.5 Ma (Cretaceous).

Literature. Sohn and Nam (2019: 4): original description [76]; Kundrata et al. (2020: 14): generic catalogue [12].



• Genus Micragrypnites Dolin, 1973

Micragrypnites Dolin, 1973: 76 [50]. Type species: Micragrypnites issykiensis Dolin, 1973: 77 [50]. For more information, see Kundrata et al. [12].

Remark. We cannot exclude the possibility that this genus might belong to Eucnemidae based on a short and broad prothorax with short posterior pronotal angles. Unfortunately, the main diagnostic characters [99] are either absent or not well visible on the images [53] and so the type material should be examined to confirm the placement of Micragrypnites in Elateridae.



Micragrypnites issykiensis Dolin, 1973

Micragrypnites issykiensis Dolin, 1973: 77 [50].

Type material. Holotype, sex unknown, exoskeleton, impression, No. 371/1648 (PIN).

Fossil deposit/age. Kyrgyzstan: Dzhil Formation, Ak-Bulak-Say, Sogjuta, Issyk-Kul; 201.3–190.8 Ma (Jurassic).

Literature. Dolin (1973: 77): original description [50]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): check list [120]; Dong et al. (2011: 482): remark [214]; Kundrata et al. (2020: 14): generic catalogue [12].



• Genus Paragrypnites Dolin, 1980

Paragrypnites Dolin, 1980: 22 [53]. Type species: Paragrypnites jagemanni Dolin, 1980: 22 [53]. For more information, see Kundrata et al. [12].



Paragrypnites jagemanni Dolin, 1980

Paragrypnites jagemanni Dolin, 1980: 22 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/1980 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 22): original description [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Schimmel and Tarnawski (2012: 265): remark [132]; Kundrata et al. (2020: 15): generic catalogue [12].



• GenusParaprotagrypnus Chang, Zhao and Ren, 2009

Paraprotagrypnus Chang, Zhao and Ren, 2009: 1433 [79]. Type species: Paraprotagrypnus superbus Chang, Zhao and Ren, 2009: 1434 [79]. For more information, see Kundrata et al. [12].

Remark. Muona et al. [99] examined this genus and concluded that it should be retained in Elateridae rather than transferred to Eucnemidae or Throscidae. They supported their conclusion by several morphological features, including antennomere II being attached apically to antennomere I. However, on the figures provided by Chang et al. [79], the antennomere II is attached somewhat subapically to antennomere I, and what is more, three apical antennomeres are enlarged, which is a character usually found in other clicking elateroids than Elateridae. The shape of prothorax, with broad and stout pronotum and anteriorly truncate prosternum, is also pointing to Eucnemidae. Another interesting character in this genus is a presence of sublateral carinae on pronotum, described and figured in Chang et al. [79]. These usually run from posterior angles more or less subparallel with sides. Muona et al. [99], however, wrote that “pronotal hind angles seemed to lack carina”. Here, we follow Muona et al. [99], who studied the type material of the only species classified in Paraprotagrypnus, and retain this genus in Protagrypnini as originally proposed.



Paraprotagrypnus superbus Chang, Zhao and Ren, 2009

Paraprotagrypnus superbus Chang, Zhao and Ren, 2009: 1434 [79].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, CNU-COL-NN2006878 (CNU). One paratype, male, exoskeleton, compression fossil, CNU-COL-NN2006879PC (CNU).

Fossil deposit/age. China: Inner Mongolia, Ningcheng County, Jiulongshan Formation, Shantou Township Daohugou; 166.1–157.3 Ma (Jurassic).

Literature. Chang et al. (2009: 1434): original description [79]; Kirejtshuk et al. (2010: 791): checklist [87]; Dong and Huang (2011: 1228): remark [81]; Yu et al. (2019: 382): remark [89]; Kundrata et al. (2020: 15): generic catalogue [12]; Muona et al. (2020: 10): revision [99].



• Genus Protagrypnus Dolin, 1973

Protagrypnus Dolin, 1973: 75 [50]. Type species: Protagrypnus exoletus Dolin, 1973: 75 [50]. For more information, see Kundrata et al. [12].

Remarks. In the original description of the genus, Dolin erroneously used the name Praelaterium Dolin, 1973 and vice versa, Protagrypnus was used in the original description of Praelaterium. However, species names were used correctly in both cases ([50], pp. 75, 78). Species in Protagrypnus do not seem to be congeneric. They differ considerably in body size, shape of pronotum and elytra, and shape and proportions of prosternum and hypomeron. We cannot exclude the possibility that the type species belongs to Eucnemidae.



Protagrypnus exoletus Dolin, 1973

Protagrypnus exoletus Dolin, 1973: 75 [50].

Type material. Holotype, sex unknown, exoskeleton, impression, No. 358/785 (PIN).

Fossil deposit/age. Kyrgyzstan: Dzhil Formation, Sogyuty, Issyk-Kul; 201.3–190.8 Ma (Jurassic).

Literature. Dolin (1973: 75): original description [50]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Dong and Huang (2009: 104): remark [80]; Chang et al. (2009: 10): remark [78]; Kundrata et al. (2020: 15): generic catalogue [12].



Protagrypnus robustus Chang, Kirejtshuk and Ren, 2009

Protagrypnus robustus Chang, Kirejtshuk and Ren, 2009: 11 [78].

Type material. Holotype, male, exoskeleton, impression, CNU-COL-NN2006843 (CNU). Two paratypes, exoskeletons, impressions, males, CNU-COL-NN2006875 and CNU-COL-NN2007869 (CNU).

Fossil deposit/age. China: Inner Mongolia, Ningcheng County, Jiulongshan Formation, Daohugou;166.1–157.3 Ma (Jurassic).

Literature. Chang et al. (2009: 11): original description [78]; Kirejtshuk et al. (2010: 791): checklist [87]; Dong and Huang (2011: 1227): remark [81]; Schimmel and Tarnawski (2012: 265): remark [132]; Yu et al. (2019: 381): remark [89]; Muona et al. (2020: 10): revision [99].

Remark. This species was examined by Muona et al. [99], who concluded that it should retain in Elateridae: Protagrypninae.



• Genus Sinolithomerus Dong and Huang, 2009

Sinolithomerus Dong and Huang, 2009: 103 [80]. Type species: Sinolithomerus dolini Dong and Huang, 2009: 104 [80]. For more information, see Kundrata et al. [12].

Remark. This genus might belong to Eucnemidae due to its relatively short and broad thorax, and short posterior angles of pronotum. Unfortunately, the main diagnostic characters [99] are either absent or not well visible on the original figures [53].



Sinolithomerus dolini Dong and Huang, 2009

Sinolithomerus dolini Dong and Huang, 2009: 104 [80].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 149,367 (NIGP).

Fossil deposit/age. China: Inner Mongolia, Ningcheng County, Haifanggou Formation, Beipiao City, Jiangjiagou village; 166.1–157.3 Ma (Jurassic).

Literature. Dong and Huang (2009: 104): original description [80]; Yu et al. (2019: 383): remark [89]; Kundrata et al. (2020: 15): generic catalogue [12]; Muona et al. (2020: 11): remark [99].

3.10. Elateridae Incertae Sedis



• Genus Adocetus Scudder, 1900

Adocetus Scudder, 1900: 97 [157]. Type species: Adocetus buprestoides Scudder, 1900: 97 [157]. For more information, see Kundrata et al. [12].

Remark. Based on the figure in original description, this genus might belong to Buprestidae rather than Elateridae. Therefore, the type material should be examined to confirm the proper family placement of Adocetus.



Adocetus buprestoides Scudder, 1900

Adocetus buprestoides Scudder, 1900: 97 [157].

Type material. Holotype, sex unknown, compression fossil (Newberry coll., Columbia University, NY, USA; based on the original description).

Fossil deposit/age. USA: Wyoming, Green River Formation, Bluffs by Twin Creek; 55.8–50.3 Ma (Eocene).

Literature. Scudder (1900: 97): original description [157]; Handlirsch (1907: 747): catalogue [127]; Carpenter (1992: 304): generic catalogue [68]; Kundrata et al. (2020: 16): generic catalogue [12].



• Genus Artinama Lin, 1986

Artinama Lin, 1986: 72 [55]. Type species: Artinama qinghuoensis Lin, 1986: 73 [55]. For more information, see Ponomarenko et al. [88] and Kundrata et al. [12].

Remark. Muona et al. [99] suggested that this genus belongs to Elateridae. Brief description of Artinama does not enable its placement even to a subfamily level. According to the images in Dong and Huang [81], Artinama resembles members of tribe Agrypnini (note that the drawing in that publication does not fully correspond with the photograph).



Artinama qinghuoensis Lin, 1986

Artinama qinghuoensis Lin, 1986: 73 [55].

Artinama qinghuanensis: Muona et al., 2020: 9 [99] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, exoskeleton, impression, No. 70,064 (NIGP).

Fossil deposit/age. China: Zaoshang Formation, Liuyang City, KHG 100, Shijiaba section, Wenjiashi; 199.3–190.8 Ma (Jurassic).

Literature. Lin (1986: 73): original description [55]; Dong et al. (2011: 483): remark [214]; Dong and Huang (2011: 1228): remark [81]; Ponomarenko et al. (2012: 480): revision [88]; Kundrata et al. (2020: 16): generic catalogue [12]; Muona et al. (2020: 9): revision [99].



• Genus Bilineariselater Chang and Ren, 2008

Bilineariselater Chang and Ren, 2008: 237 [84]. Type species: Bilineariselater foveatus Chang and Ren, 2008: 237 [84]. For more information, see Kundrata et al. [12].

Remark. This genus superficially resembles Selatosomini in having the frontal carina obsolete, the antenna weakly serrate, with elongated antennomere III, the pronotum rather broad, arcuate at sides and sinuate near hind angles, the posterior angles of pronotum moderately long, with sublateral carina, the prosternal lobe well developed, and elytra more or less ellipsoidal.



Bilineariselater foveatus Chang and Ren, 2008

Bilineariselater foveatus Chang and Ren, 2008: 237 [84].

Type material. Holotype, male, exoskeleton, compression fossil, CNU-C-LB2006801 (CNU).

Fossil deposit/age. China: Liaoning Province, Shangyan County, Beipiao City, Yixian Formation, Huangbanjigou, near Chaomidian Village; 125.45–122.46 Ma (Cretaceous).

Literature. Chang and Ren (2008: 237): original description [84]; Kirejtshuk et al. (2010: 792): checklist [87]; Dong and Huang (2011: 1225): checklist [81]; Yu et al. (2019: 382): remark [89]; Kundrata et al. (2020: 16): generic catalogue [12]; Muona et al. (2020: 9): revision [99].



• Genus Cretoelaterium Alekseev, 2008

Cretoelaterium Alekseev, 2008: 56 [74]. Type species: Cretoelaterium kazanovense Alekseev, 2008: 57 [74]. For more information, see Kundrata et al. [12].

Remark. We cannot exclude the possibility that this genus might belong to Eucnemidae.



Cretoelaterium kazanovense Alekseev, 2008

Cretoelaterium kazanovense Alekseev, 2008: 57 [74].

Type material. Holotype, sex unknown, exoskeleton, impression, No. 3693/1 (PIN).

Fossil deposit/age. Russia: Mirsanovo Formation, Chita Region, Shilka District, left bank of the Shilka river, Kazanovo railway station; 129.4–125.0 Ma (Cretaceous).

Literature. Alekseev (2008: 57): original description [74]; Kundrata et al. (2020: 16): generic catalogue [12].



• Genus Cryptagriotes Wickham, 1916

Cryptagriotes Wickham, 1916: 512 [28]. Type species: Cryptagriotes minusculus Wickham, 1916: 512 [28]. For more information, see Kundrata et al. [12].

Remark. Wickham [28] suggested that the body form of this genus is similar to Cryptohypnus Eschscholtz, 1830 (=Hypolithus Eschscholtz, 1829; Dendrometrinae: Hypnoidini) and the metacoxal plates are similar to those of Agriotes Eschscholtz, 1829 (Elaterinae: Agriotini). Based on the body size and proportions, and the more or less narrow prosternum with pronotosternal sutures almost parallel sided, this genus might belong to Cardiophorinae. However, its potential affinities to Eucnemidae should also be taken into account.



Cryptagriotes minusculus Wickham, 1916

Cryptagriotes minusculus Wickham, 1916: 512 [28].

Cryptagriotes minisculus: Carpenter, 1992: 304 [68] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MCZ 2749 (=8653 in Scudder coll.) (MCZ).

Fossil deposit/age. USA: Colorado, Florissant Formation, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 512): original description [28]; Wickham (1920: 354): catalogue [29]; Hyslop (1921: 637): generic catalogue [111]; Carpenter (1992: 304): generic catalogue [68]; Kundrata et al. (2020: 7): catalogue [12].



• Genus Cryptocoelus Dolin and Nel, 2002

Cryptocoelus Dolin and Nel, 2002: 342 [82]. Type species: Cryptocoelus buffoni Dolin and Nel, 2002: 342 [82]. For more information, see Chang et al. [83] and Kundrata et al. [12].

Remark. Species in this genus superficially resemble Selatosomini in the frontal carina obsolete, the antenna more or less weakly serrate, the pronotum rather broad, arcuate at sides and sinuate near posterior angles, the posterior angles of pronotum moderately long, with sublateral carina, and elytra more or less ellipsoidal.



Cryptocoelus baissensis Alekseev, 2011

Cryptocoelus baissensis Alekseev, 2011: 428 [75].

Type material. Holotype, sex unknown, exoskeleton, impression, No. 1989/2636 (PIN).

Fossil deposit/age. Russia: Buryatia, Zaza Formation, Baissa; 125.0–113.0 Ma (Cretaceous).

Literature. Alekseev (2011: 428): original description [75].



Cryptocoelus buffoni Dolin and Nel, 2002

Cryptocoelus buffoni Dolin and Nel, 2002: 342 [82].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MNHN-LP-R.55227 (MNHN). Three paratypes, sex unknown, exoskeletons, compression fossils, MNHN-LP-R.55228, MNHN-LP-R.55229, MNHN-LP-R.55230 (MNHN).

Fossil deposit/age. China: Liaoning Province, Beipiao City, Yixian Formation, Chaomidian Village; 125.45–122.46 Ma (Cretaceous).

Literature. Dolin and Nel (2002: 342): original description [82]; Korneev and Cate (2005: 13): checklist [120]; Chang et al. (2007: 1248): remark [83]; Kirejtshuk et al. (2010: 792): checklist [87]; Alekseev (2011: 424): checklist [75]; Dong and Huang (2011: 1225): checklist [81]; Kundrata et al. (2020: 16): generic catalogue [12]; Muona et al. (2020: 9): revision [99].

Remark. Based on Figures 3–10 in Dolin and Nel [82], there are more species included in the type series of C. buffoni. The specimen in Figure 10 has a well developed prosternal lobe, while specimens in Figures 4, 6 and 8 have anterior portion of prosternum truncate. Additionally, the shape of elytra is also different among the figured specimens.



Cryptocoelus dolini Alekseev, 2011

Cryptocoelus dolini Alekseev, 2011: 430 [75].

Type material. Holotype, sex unknown, exoskeleton, impression, No. 4210/6420 (PIN).

Fossil deposit/age. Russia: Buryatia, Zaza Formation, Baissa; 125.0–113.0 Ma (Cretaceous).

Literature. Alekseev (2011: 430): original description [75].



Cryptocoelus gianteus Chang, Ren and Shih, 2007

Cryptocoelus gianteus Chang, Ren and Shih, 2007: 1245 [83].

Cryptocoelus giganteus: Kirejtshuk et al., 2010: 792 [87] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, CNU-C-LB2006851-1, CNU-C-LB2006851-2 (CNU).

Fossil deposit/age. China: Liaoning Province, Shangyuan County, Beipiao City, Yixian Formation, Huangbanjigou, near Chaomidian Village; 125.45–122.46 Ma (Cretaceous).

Literature. Chang et al. (2007: 1245): original description [83]; Kirejtshuk et al. (2010: 792): checklist [87]; Alekseev (2011: 425): checklist [75]; Dong and Huang (2011: 1225): checklist [81]; Muona et al. (2020: 9): revision [99].



Cryptocoelus lukashevichae Alekseev, 2011

Cryptocoelus lukashevichae Alekseev, 2011: 428 [75].

Type material. Holotype, sex unknown, exoskeleton, impression, No. 3064/7102 (PIN).

Fossil deposit/age. Russia: Buryatia, Zaza Formation, Baissa; 125.0–113.0 Ma (Cretaceous).

Literature. Alekseev (2011: 428): original description [75].



Cryptocoelus major Dolin and Nel, 2002

Cryptocoelus major Dolin and Nel, 2002: 343 [82].

Crytocoleus [sic!] major: Yu et al., 2019: 381 [89].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, MNHN-LP-R.55226 (MNHN).

Fossil deposit/age. China: China: Liaoning Province, Shangyuan County, Beipiao City, Yixian Formation, Huangbanjigou, near Chaomidian Village; 125.45–122.46 Ma (Cretaceous).

Literature. Dolin and Nel (2002: 343): original description [82]; Korneev and Cate (2005: 10): checklist [120]; Chang et al. (2007: 1245): remark [83]; Chang et al. (2010: 873): remark [86]; Kirejtshuk et al. (2010: 787, 792): checklist [87]; Alekseev (2011: 424): checklist [75]; Dong and Huang (2011: 1225): checklist [81]; Yu et al. (2019: 381): remark [89]; Kundrata et al. (2020: 16): generic catalogue [12]; Muona et al. (2020: 9): revision [99].



Cryptocoelus shcherbakovi Alekseev, 2011

Cryptocoelus shcherbakovi Alekseev, 2011: 428 [75].

Type material. Holotype, sex unknown, exoskeleton, impression, No. 4210/6417 (PIN).

Fossil deposit/age. Russia: Buryatia, Zaza Formation, Baissa; 125.0–113.0 Ma (Cretaceous).

Literature. Alekseev (2011: 428): original description [75].



Cryptocoelus sinitshenkovae Alekseev, 2011

Cryptocoelus sinitshenkovae Alekseev, 2011: 427 [75].

Type material. Holotype, sex unknown, exoskeleton, No. 3002/2 (PIN).

Fossil deposit/age. Russia: Buryatia, Zaza Formation, Romanovka; 125.0–113.0 Ma (Cretaceous).

Literature. Alekseev (2011: 427): original description [75].



• Genus Curtelater Chang and Ren, 2008

Curtelater Chang and Ren, 2008: 238 [84]. Type species: Curtelater wui Chang and Ren, 2008: 239 [84]. For more information, see Kundrata et al. [12].

Remark. Muona et al. [99] examined this genus and confirmed that it belongs to Elateridae. However, based on the available morphological evidence, its position remains unclear, although it superficially resembles Selatosomini in several aspects including the morphology of head, antennae, and prothorax [84].



Curtelater wui Chang and Ren, 2008

Curtelater wui Chang and Ren, 2008: 239 [84].

Type material. Holotype, female, exoskeleton, compression fossil, CNU-C-LB2006830 (CNU).

Fossil deposit/age. China: Liaoning Province, Shangyuan County, Beipiao City, Yixian Formation, Huangbanjigou, near Chaomidian Village; 125.45–122.46 Ma (Cretaceous).

Literature. Chang and Ren (2008: 239): original description [84]; Kirejtshuk et al. (2010: 792): checklist [87]; Dong and Huang (2011: 1225): checklist [81]; Yu et al. (2019: 382): remark [89]; Kundrata et al. (2020: 17): generic catalogue [12]; Muona et al. (2020: 9): revision [99].



• Genus Elateridium Tillyard, 1918

Elateridium Tillyard, 1918: 751 [38]. Replacement name for Elaterites Tillyard, 1916: 41 [37]. Type species: Elaterites wianamattense Tillyard, 1916: 41 [37]. For more information, see Kundrata et al. [12].

Remark. The description of the type species of Elateridium is based on an isolated elytron, which makes the systematic placement of this genus rather problematic. Both species described by Dunstan [39] which are listed below should be excluded from Elateridae.



Elateridium subulatum (Dunstan, 1923)

Elaterites subulatus Dunstan, 1923: 44 [39].

Elateridium subulatum: Jell, 2004: 76 [215].

Type material. Holotype, sex unknown, elytron, compression fossil, Nr. 263a,b (part + counterpart) (QM; ex Geological Survey of Queensland).

Fossil deposit/age. Australia: Queensland, Blackstone Formation (Ipswich Coal Measures Group), Denmark Hill Insect Bed; 228.0–208.5 Ma (Triassic).

Literature. Dunstan (1923: 44): original description [39]; Handlirsch (1938: 13): catalogue [212]; Jell (2004: 76): catalogue [215]; Martins-Neto et al. (2006: 602): remark [71]; Martin (2010: 936): remark [73].

Remark. According to the drawing in the original description [39], it seems doubtful that this species belongs to Elateridae since the shape and structure of elytron are not typically elaterid like.



Elateridium transversum (Dunstan, 1923)

Elaterites trans versus Dunstan, 1923: 45 [39].

Elateridium transversum: Handlirsch, 1938: 13 [212].

Type material. Holotype, sex unknown, elytron, compression fossil, Nr. 159a, A (part+counterpart) (QM; ex Geological Survey of Queensland).

Fossil deposit/age. Australia: Queensland, Blackstone Formation (Ipswich Coal Measures Group), Denmark Hill Insect Bed; 228.0–208.5 Ma (Triassic).

Literature. Dunstan (1923: 45): original description [39]; Handlirsch (1938: 13): catalogue [212]; Jell (2004: 76): remark [215].

Remark. According to the drawing in the original description [39], it seems doubtful that this species belongs to Elateridae since the shape and structure of elytron are not typically elaterid like.



Elateridium wianamattense (Tillyard, 1916)

Elaterites wianamattensis Tillyard, 1916: 41 [37].

Elateridium wianamattense: Jell, 2004: 76 [215].

Type material. Holotype, sex unknown, elytron, impression, Nr. 130 (QM; ex Geological Survey of Queensland).

Fossil deposit. Australia: Ashfield Shales Formation, Carrington Brick Company’s clay pit, St. Peter’s; 247.2–242.0 Ma (Triassic).

Literature. Tillyard (1916: 41): original description [37]; Tillyard (1918: 751): nomenclatural remark [38]; Handlirsch (1938: 158): remark [212]; Carpenter (1992: 304): generic catalogue [68]; Jell (2004: 76): remark [215]; Kundrata et al. (2020: 17): generic catalogue [12].



• Genus Elaterites Heer, 1847

Elaterites Heer, 1847: 141 [14]. Type species: Elaterites lavateri Heer, 1847: 141 [14]. For more information, see Kundrata et al. [12].

Remark. This genus is obviously an assemblage of unrelated species of uncertain position. It includes taxa which authors were not possible to accommodate to any other genus in Elateridae [14,34]. Although it could be considered a “collective group” [129], some authors treated Elaterites as a genus with its own type species [127] and we follow this concept. The type species might represent Dendrometrinae based on the drawings in the original description [14].



Elaterites amissus Heer, 1847

Elaterites amissus Heer, 1847: 142 [14].

Type material. Holotype, sex unknown, elytron, compression fossil (type depository unknown).

Fossil deposit/age. Switzerland: Greith coal mine, Hohenrhone; 28.4–23.03 Ma (Oligocene).

Literature. Heer (1847: 142): original description [14]; Giebel (1852: 651): catalogue [126]; Giebel (1856: 94): revision, redescription [16]; Scudder (1891: 518): catalogue [24]; Handlirsch (1907: 747): catalogue [127].

Remark. The description of E. amissus was based on an isolated elytron, which makes the generic attribution of this species rather problematic.



Elaterites bruchi Cockerell, 1926

Elaterites bruchi Cockerell, 1926: 320 [35].

Type material. Holotype, sex unknown, elytron, compression fossil (BMNH).

Fossil deposit/age. Argentina: Margas Verdes Formation, Station 2; Sunchal; 66.0–56.0 Ma (Paleocene).

Literature. Cockerell (1926: 320): original description [35]; Cockerell (1936: 1): checklist [216].

Remark. The description of E. bruchi was based on an isolated elytron, which makes the generic attribution of this species rather problematic.



Elaterites dicrepidioides Deichmüller, 1881

Elaterites dicrepidioides Deichmüller, 1881: 308 [21].

Type material. Unknown number of type specimens, probably only one, sex unknown, compression fossil (type depository unknown).

Fossil deposit/age. Czech Republic: Kučlín (u Bíliny); 37.2–33.9 Ma (Eocene).

Literature. Deichmüller (1881: 308): original description [21]; Scudder (1891: 518): catalogue [24]; Handlirsch (1907: 748): catalogue [127].



Elaterites laconoides Cockerell, 1920

Elaterites laconoides Cockerell, 1920: 457 [34].

Type material. Holotype, sex unknown, elytron, compression fossil, No. 18,998 (BMNH).

Fossil deposit/age. United Kingdom: Poole Formation, Bournemouth; 47.8–41.3 Ma (Eocene).

Literature. Cockerell (1920: 457): original description [34].

Remark. The description of E. laconoides was based on an isolated elytron, which makes the generic attribution of this species rather problematic.



Elaterites lavateri Heer, 1847

Elaterites lavateri Heer, 1847: 141 [14].

Type material. Holotype, sex unknown, compression fossil (ETH).

Fossil deposit/age. Germany: Upper Freshwater-Molasse Formation, Upper Öhningen beds, Öhningen; 12.7–11.608 Ma (Miocene).

Literature. Heer (1847: 141): original description [14]; Giebel (1852: 651): catalogue [126]; Giebel (1856: 94): revision, redescription [16]; Scudder (1891: 518): catalogue [24]; Handlirsch (1907: 747): catalogue [127]; Tillyard (1918: 751): remark [38]; Cockerell (1920: 457): remark [34]; Kundrata et al. (2020: 17): generic catalogue [12].

Remark. This species might represent Dendrometrinae based on the drawings in the original description [14]. It looks especially similar to genera such as Elathous Reitter, 1890, Limonius and Pheletes Kiesenwetter, 1858.



Elaterites longus Haupt, 1956

Elaterites longus Haupt, 1956: 48 [147].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, G55/53 (GPIUH).

Fossil deposit/age. Germany: Geiseltal; 47.8–41.3 Ma (Eocene).

Literature. Haupt (1956: 48): original description [147].

Remark. The description of E. longus was based only on the characters of elytra and abdomen, which makes the generic attribution of this species rather problematic.



Elaterites microstictus Cockerell, 1926

Elaterites microstictus Cockerell, 1926: 320 [35].

Type material. Holotype, sex unknown, elytron, compression fossil (part + counterpart) (BMNH, YPM).

Fossil deposit/age. Argentina: Margas Verdes Formation, Station 2; Sunchal; 66.0–56.0 Ma (Paleocene).

Literature. Cockerell (1926: 320): original description [35]; Cockerell (1936: 1): checklist [216].

Remark. The description of E. microstictus was based on an isolated elytron, which makes the generic attribution of this species rather problematic.



Elaterites murchisoni (Giebel, 1856)

Elaterium murchisoni Giebel, 1856: 93 [16].

Elaterites murchisoni: Cockerell, 1920: 456 [34].

Type material. Holotype, sex unknown, elytron, compression fossil, No. 18,996 (BMNH).

Fossil deposit/age. United Kingdom: Poole Formation, Dorset, Creech, between Corfe and Wareham; 47.8–41.3 Ma (Eocene).

Literature. Giebel (1856: 93): original description [16]; Scudder (1891: 518): catalogue [24]; Handlirsch (1907: 748): catalogue [127]; Cockerell (1920: 456): revision [34].

Remark. The description of E. murchisoni was based on an isolated elytron, which makes the generic attribution of this species rather problematic. It was treated as a member of Buprestidae by Westwood [15].



Elaterites obsoletus Heer, 1847

Elaterites obsoletus Heer, 1847: 142 [14].

Type material. Holotype, sex unknown, compression fossil, No. 7969 (ETH).

Fossil deposit/age. Germany: Upper Freshwater-Molasse Formation, Upper Öhningen; 12.7–11.608 Ma (Miocene).

Literature. Heer (1847: 142): original description [14]; Giebel (1852: 651): catalogue [126]; Giebel (1856: 94): revision, redescription [16]; Scudder (1891: 518): catalogue [24]; Handlirsch (1907: 747): catalogue [127].



Elaterites palaeophilus Cockerell, 1920

Elaterites palaeophilus Cockerell, 1920: 458 [34].

Type material. Holotype, sex unknown, elytron, compression fossil, No. 1467 (BMNH).

Fossil deposit/age. United Kingdom: Lambeth Group, Peckham; 56.0–47.8 Ma (Eocene).

Literature. Cockerell (1920: 458): original description [34].

Remark. The description of E. palaeophilus was based on an isolated elytron, which makes the generic attribution of this species rather problematic.



Elaterites perditulus Cockerell, 1920

Elaterites perditulus Cockerell, 1920: 457 [34].

Type material. Holotype, sex unknown, elytron, compression fossil, No. 10,418 (BMNH).

Fossil deposit/age. United Kingdom: Poole Formation, Dorset, Corfe, Isle of Purbeck; 47.8–41.3 Ma (Eocene).

Literature. Cockerell (1920: 457): original description [34].

Remark. The description of E. perditulus was based on an isolated elytron, which makes the generic attribution of this species rather problematic.



Elaterites sculptilis Cockerell, 1920

Elaterites sculptilis Cockerell, 1920: 458 [34].

Elater sculptilis: Birket-Smith, 1977: 20 [154].

Type material. Holotype, sex unknown, elytron, compression fossil, No. 10420, 10,422 (two impressions of the same specimen [34]) (BMNH).

Fossil deposit/age. United Kingdom: Poole Formation, Dorset, Corfe, Isle of Purbeck; 47.8–41.3 Ma (Eocene).

Literature. Cockerell (1920: 458): original description [34]; Birket-Smith (1977: 20): taxonomic remark [154].

Remark. Remark. The description of E. sculptilis was based on an isolated elytron, which makes the generic attribution of this species rather problematic. Birket-Smith [154] suggested that this species is presumably congeneric with Semiotus ehrenswaerdi but the size of both elytra differs significantly.



• Genus Elaterium Westwood, 1854

Elaterium Westwood, 1854: 387/393 [15]. Type species: Elaterium pronaeus Westwood, 1854: 387/393 [15]. For more information, see Kundrata et al. [12].

Remark. The description of the type species of Elaterium is based on a part of an isolated elytron, which makes the systematic placement of this genus rather problematic. A species described by Dunstan [39] is most probably not congeneric with E. pronaeus.



Elaterium bipunctatum Dunstan, 1923

Elaterium bipunctatum Dunstan, 1923: 47 [39].

Type material. Holotype, sex unknown, elytra, compression fossil, No. 292 (QM; ex Geological Survey of Queensland).

Fossil deposit/age. Australia: Blackstone Formation (Ipswich Coal Measures Group), Denmark Hill Insect Bed; 228.0–208.5 Ma (Triassic).

Literature. Dunstan (1923: 47): original description [39]; Handlirsch (1938: 14): catalogue [212]; Jell (2004: 76): remark [215].

Remark. According to the description and drawing in the original publication [39], elytron of this species bears strong costae which are usually not present in Elateridae. The placement of this species not only in Elaterium but even in the family Elateridae needs further examination.



Elaterium pronaeus Westwood, 1854

Elaterium pronaeus Westwood, 1854: 393 [15].

Type material. Holotype, sex unknown, compression fossil (BMNH).

Fossil deposit/age. United Kingdom: Lulworth Formation, Durlston Bay, Lower Purbeck, Swanage; 145.0–140.2 Ma (Cretaceous).

Literature. Westwood (1854: 393): original description [15]; Giebel (1856: 92): revision, redescription [16]; Scudder (1891: 205): catalogue [24]; Handlirsch (1906: 553): catalogue [26]; Cockerell (1920: 456): catalogue [34]; Coram and Jepson (2012: 60): catalogue [217]; Jell (2004: 76): remark [215]; Kundrata et al. (2020: 17): generic catalogue [12].



• Genus Gripecolous Lin, 1986

Gripecolous Lin, 1986: 80 [55]. Type species: Gripecolous enallus Lin, 1986: 80 [55]. For more information, see Kundrata et al. [12].

Remark. Muona et al. [99] suggested that this genus belongs either to Elateridae: Protagrypninae or to Eucnemidae. According to the images in Dong and Huang [81], Gripecolous resembles members of tribe Agrypnini, especially Agrypnus (note that drawing in that publication does not fully correspond with the photograph).



Gripecolous enallus Lin, 1986

Gripecolous enallus Lin, 1986: 80 [55].

Type material. Holotype, female (see Muona et al. [99]), exoskeleton, impression, No. 70,073 (NIGP).

Fossil deposit/age. China: Shiti Formation, KHG 201, Xiwan coal mine, Hezhou City; 170.3–168.3 Ma (Jurassic).

Literature. Lin (1986: 80): original description [55]; Dong et al. (2011: 482): revision [214]; Dong and Huang (2011: 1228): remark [81]; Ponomarenko et al. (2012: 482): revision [88]; Kundrata et al. (2020: 18): generic catalogue [12]; Muona et al. (2020: 11): revision [99].



• Genus Ludiophanes Wickham, 1916

Ludiophanes Wickham, 1916: 522 [28]. Type species: Ludiophanes haydeni Wickham, 1916: 522 [28]. For more information, see Kundrata et al. [12].



Ludiophanes haydeni Wickham, 1916

Ludiophanes haydeni Wickham, 1916: 522 [28].

Ludiophanes hayden: Carpenter, 1992: 305 [68] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, compression fossil, No. 90,386 (part + counterpart) (USNM).

Fossil deposit/age. USA: Colorado, Florissant Formation, Wilson Ranch, Florissant; 37.2–33.9 Ma (Eocene).

Literature. Wickham (1916: 522): original description [28]; Wickham (1920: 354): catalogue [29]; Carpenter (1992: 305): generic catalogue [68]; Kundrata et al. (2020: 18): generic catalogue [12].



• Genus Mercata Lin, 1986

Mercata Lin, 1986: 79 [55]. Type species: Mercata festira Lin, 1986: 79 [55]. For more information, see Kundrata et al. [12].

Remark. Chang et al. [77] placed Mercata in Cerophytidae but this was not followed by subsequent authors [12,88,89,218]. Ponomarenko et al. [88] placed this genus in Elateridae: Protagrypninae.



Mercata festira Lin, 1986

Mercata festira Lin, 1986: 79 [55].

Type material. Holotype, sex unknown, exoskeleton, impression, No. 70,072 (NIGP).

Fossil deposit/age. China: Shiti Formation, KHG 201, Xiwan coal mine, Hezhou City; 170.3–168.3 Ma (Jurassic).

Literature. Lin (1986: 79): original description [55]; Chang et al. (2011: 33): remark [77]; Dong et al. (2011: 486): revision [214]; Ponomarenko et al. (2012: 481): revision [88]; Kundrata et al. (2020: 18): generic catalogue [12]; Muona et al. (2020: 11): remark [99].



• Genus Mionelater Becker, 1963

Mionelater Becker, 1963: 125 [46]. Type species: Mionelater planatus Becker, 1963: 126 [46]. For more information, see Douglas [108] and Kundrata et al. [12].

Minonelater Schimmel, 2005: 27 [91] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Remark. Becker [46] placed this genus in Cardiophorinae. However, Douglas [108] suggested that this genus might belong to Dendrometrinae or another subfamily based on the serrate antennae, large eyes, shelf-like supra-antennal carina, elongate posterior angles of pronotum, and open mesocoxal cavities. Additionally, Mionelater has a pronotum more elongated than in typical Cardiophorinae, and almost not arcuate at sides, and according to the description [46], the prosternal process in this genus is long and rather narrow, while in Cardiophorinae, it is rather short and thick. The combination of characters, such as small body size, shape of supra-antennal carina, pronotum rather large compared to elytra, and elongate posterior angles of pronotum, suggests that Mionelater might be related to Hypnoidini. However, we keep it tentatively without a subfamilial assignment until further, more detailed, study is conducted.



Mionelater planatus Becker, 1963

Mionelater planatus Becker, 1963: 126 [46].

Type material. Holotype, probably male, exoskeleton, amber inclusion, No. 12,734 (UCMP).

Fossil deposit/age. Mexico: Simojovel region, Mexican (Chiapas) amber; 23.03–15.97 Ma (Miocene).

Literature. Becker (1963: 126): original description [46]; Spahr (1981: 49): catalogue [49]; Keilbach (1982: 247): catalogue [133]; Zaragoza Caballero (1990: 147): remark [61]; Carpenter (1992: 305): generic catalogue [68]; Schimmel (2005: 27): remark [91]; Solórzano Kraemer (2007: 119): catalogue [90]; Schimmel and Tarnawski (2010: 363): remark [131]; Schimmel and Tarnawski (2012: 265): remark [132]; Kundrata et al. (2020: 6): generic catalogue [12]; Kundrata et al. (2020: 8): remark [94].



• Genus Ovivagina Zhang, 1997

Ovivagina Zhang, 1997: 71 [56]. Type species: Ovivagina longa Zhang, 1997: 72 [56]. For more information, see Kundrata et al. [12].

Remark. The placement of this genus in Elateridae is uncertain and needs further research [78,81,219].



Ovivagina longa Zhang, 1997

Ovivagina longa Zhang, 1997: 72 [56].

Type material. Holotype, sex unknown, exoskeleton, impression, 93-NA-3/K7,8 (?NIGP).

Fossil deposit/age. China: Badaowan Formation, Xinjiang, Shawan County, Nan’anchihai; 201.3–190.8 Ma (Jurassic).

Literature. Zhang (1997: 72): original description [56]; Yan and Zhang (2010: 451): remark [219]; Dong and Huang (2011: 1228): remark [81]; Kundrata et al. (2020: 18): generic catalogue [12]; Muona et al. (2020: 11): remark [99].



• Genus Paralithomerus Chang, Zhang and Ren, 2008

Paralithomerus Chang, Zhang and Ren, 2008: 55 [85]. Type species: Paralithomerus exquisitus Chang, Zhang and Ren, 2008: 55 [85]. For more information, see Kundrata et al. [12].

Remark. This genus was considered Protagrypninae incertae sedis [12] but Muona et al. [99] placed it to Elateridae incertae sedis.



Paralithomerus exquisitus Chang, Zhang and Ren, 2008

Paralithomerus exquisitus Chang, Zhang and Ren, 2008: 55 [85].

Paralithomerus exquisitius: Muona et al., 2020: 10 [99] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, exoskeleton, impression, CNU-C-LB2006874-1, CNU-C-LB2006874-2 (CNU).

Fossil deposit/age. China: Liaoning Province, Shangyuan County, Beipiao City, Yixian Formation, Huangbanjigou, near Chaomidian Village; 125.45–122.46 Ma (Cretaceous).

Literature. Chang et al. (2008: 55): original description [85]; Kirejtshuk et al. (2010: 792): checklist [87]; Dong and Huang (2011: 1225): checklist [81]; Yu et al. (2019: 382): remark [89]; Kundrata et al. (2020: 15): generic catalogue [12]; Muona et al. (2020: 10): revision [99].



Paralithomerus parallelus Chang, Zhang and Ren, 2008

Paralithomerus parallelus Chang, Zhang and Ren, 2008: 58 [85].

Type material. Holotype, sex unknown, exoskeleton, impression, CNU-C-LB2006872 (CNU).

Fossil deposit. China: Liaoning Province, Shangyuan County, Beipiao City, Yixian Formation, Huangbanjigou, near Chaomidian Village; 125.45–122.46 Ma (Cretaceous).

Literature. Chang et al. (2008: 58): original description [85]; Kirejtshuk et al. (2010: 792): checklist [87]; Dong and Huang (2011: 1225): checklist [81]; Muona et al. (2020: 10): revision [99].



• Genus Protocardiophorus Dolin, 1976

Protocardiophorus Dolin, 1976: 71 [52]. Type species: Protocardiophorus ancestralis Dolin, 1976: 73 [52]. For more information, see Douglas [108] and Kundrata et al. [12].

Photocardiophorus: Dolin, 1980: legend to Figure 84 [53] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Remark. Species of this genus do not seem to be congeneric. What is more, the type material should be studied in order to confirm that they belong to Elateridae and not to other clicking elateroid lineages, especially Eucnemidae.



Protocardiophorus ancestralis Dolin, 1976

Protocardiophorus ancestralis Dolin, 1976: 73 [52].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2571 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1976: 73): original description [52]; Dolin (1980: 78): key, additional specimen No. 2997/1973 [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 19): generic catalogue [12].



Protocardiophorus jurassicus Dolin, 1980

Protocardiophorus jurassicus Dolin, 1980: 78 [53].

Photocardiophorus [sic!] jurassicus: Dolin, 1980: legend to Figure 84 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/2020 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 78): original description [53]; Korneev and Cate (2005: 17): checklist [120].

Remark. Protocardiophorus jurassicus is morphologically similar to the species of Idiomerus which were transferred to Cerophytidae [77,218].



• Genus Pseudocardiophorites Dolin, 1976

Pseudocardiophorites Dolin, 1976: 73 [52]. Type species: Pseudocardiophorites fragilis Dolin, 1976: 73 [52]. For more information, see Douglas [108] and Kundrata et al. [12].

Remark. This genus needs a revision since some species differ from the type species (and also from each other) in the body proportions, the shape and structure of thorax, etc. We cannot exclude the possibility that at least some species currently classified in this genus might belong to Eucnemidae.



Pseudocardiophorites angustatus Dolin, 1980

Pseudocardiophorites angustatus Dolin, 1980: 80 [53].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2997/2019 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1980: 80): original description [53]; Korneev and Cate (2005: 11): checklist [120].



Pseudocardiophorites fragilis Dolin, 1976

Pseudocardiophorites fragilis Dolin, 1976: 73 [52].

Cardiophorites [sic!] fragilis: Dolin, 1976: 72 [52] (figure legend).

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2554/688 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1976: 73): original description [52]; Dolin (1980: 79): revision [53]; Carpenter (1992: 305): generic catalogue [68]; Korneev and Cate (2005: 10): checklist [120]; Kundrata et al. (2020: 19): generic catalogue [12].



Pseudocardiophorites hayeki Dolin, 1976

Pseudocardiophorites hayeki Dolin, 1976: 73 [52].

Cardiophorites [sic!] hayeki: Dolin, 1976: 72 [52] (figure legend).

Pseudocardiophorites hayekae: Dolin, 1980: 80 [53] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.4].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2066/2930 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1976: 73): original description [52]; Dolin (1980: 80): key [53]; Korneev and Cate (2005: 16): checklist [120].



Pseudocardiophorites infractus Dolin, 1976

Pseudocardiophorites infractus Dolin, 1976: 74 [52].

Cardiophorites [sic!] infractus Dolin, 1976: 72 [52] (figure legend).

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1468 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka; 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1976: 74): original description [52]; Dolin (1980: 80): key [53]; Korneev and Cate (2005: 17): checklist [120].



Pseudocardiophorites quadricollis Dolin, 1976

Pseudocardiophorites quadricollis Dolin, 1976: 74 [52].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2239/1422 (PIN). Paratype, sex unknown, exoskeleton, compression fossil, No. 2239/1435 (PIN).

Fossil deposit/age. Kazakhstan: Karabastau Formation, Karatau, Mikhailovka (PIN collection 2239); 166.1–157.3 Ma (Jurassic).

Literature. Dolin (1976: 74): original description [52]; Dolin (1980: 80): key [53]; Korneev and Cate (2005: 22): checklist [120].



• Genus Silicernius Heyden, 1859

Silicernius Heyden, 1859: 6 [220]. Type species: Silicernius spectabilis Heyden, 1859: 6 [220]. For more information, see Kundrata et al. [12].

Remark. This genus might be related to Oxynopterini based on the body proportions and shapes of pronotum and elytra.



Silicernius spectabilis Heyden, 1859

Silicernius spectabilis Heyden, 1859: 6 [220].

Type material. Holotype, sex unknown, compression fossil (GPIBO).

Fossil deposit/age. Germany: Rott Formation; 28.4–23.03 Ma (Oligocene).

Literature. Heyden (1859: 6): original description [220]; Scudder (1885: 797): catalogue [22]; Scudder (1891: 580): catalogue [24]; Handlirsch (1907: 747): catalogue [127]; Hyslop (1921: 669): generic catalogue [111]; Kundrata et al. (2020: 19): generic catalogue [12].

Remark. This species resembles Oxynopterini in the broadened and almost roundly campaniform pronotum, with moderately long posterior angles, and elytron notably elongated and attenuate to apex.



• Genus Sinoelaterium Ping, 1928

Sinoelaterium Ping, 1928: 22 [40]. Type species: Sinoelaterium melanocolor Ping, 1928: 23 [40]. For more information, see Kundrata et al. [12].

Remark. This genus needs a thorough re-examination as it is not clear whether it belongs to Elateridae [12,68]. Some authors suggested that it might belong to Artematopodidae [221,222], but it also resembles Cerophytidae by the habitus, shape of antennae, and structure of head and thorax.



Sinoelaterium melanocolor Ping, 1928

Sinoelaterium melanocolor Ping, 1928: 23 [40].

Sinoelaterium melanovolor: Carpenter, 1992: 305 [68] [unavailable name, incorrect subsequent spelling not in prevailing usage; [129], Art. 33.3].

Type material. Holotype, sex unknown, exoskeleton, compression fossil, No. 2132 (W. H. Wong coll., Geological Survey of China [40]).

Fossil deposit/age. China: Liaoning Province, Yixian Formation, Beipiao City, Locality 228; 125.45–122.46 Ma (Cretaceous).

Literature. Ping (1928: 23): original description [40]; Handlirsch (1938: 167, 169): catalogue [212]; Carpenter (1992: 305): generic catalogue [68]; Dolin and Nel (2002: 345): remark [82]; Dong and Huang (2009: 102): remark [80]; Dong and Huang (2011: 1227): remark [81]; Kundrata et al. (2020: 19): generic catalogue [12]; Muona et al. (2020: 11): remark [99].



• Genus Tetraraphes Iablokoff-Khnzorian, 1961

Tetraraphes Iablokoff-Khnzorian, 1961: 95 [47]. Type species: Tetraraphes ebersini Iablokoff-Khnzorian, 1961: 96 [47]. For more information, see Douglas [108] and Kundrata et al. [12].



Tetraraphes ebersini Iablokoff-Khnzorian, 1961

Tetraraphes ebersini Iablokoff-Khnzorian, 1961: 96 [47].

Type material. Holotype, sex unknown, exoskeleton, amber inclusion, No. 364/712 (PIN).

Fossil deposit/age. Baltic amber; 38.0–33.9 Ma (Eocene).

Literature. Iablokoff-Khnzorian (1961: 96): original description [47]; Larsson (1978: 153): catalogue [48]; Spahr (1981: 49): catalogue [49]; Keilbach (1982: 247): catalogue [133]; Carpenter (1992: 305): generic catalogue [68]; Alekseev (2013: 7): checklist [92]; Chang et al. (2010: 867): remark [86]; Kundrata et al. (2020: 19): generic catalogue [12].



• Genus Turonelater Alekseev, 2011

Turonelater Alekseev, 2011: 430 [75]. Type species: Turonelater giganteus Alekseev, 2011: 430 [75]. For more information, see Alekseev [75] and Kundrata et al. [12].

Remark. This genus probably belongs to Dendrometrinae based on the morphology of prothorax.



Turonelater giganteus Alekseev, 2011

Turonelater giganteus Alekseev, 2011: 430 [75].

Type material. Holotype, sex unknown, impression, No. 2383/252 (PIN).

Fossil deposit/age. Kazakhstan: Kzylorda region, Pond mudstone, Kzyl-Zhar; 93.9–89.8 Ma (Cretaceous).

Literature. Alekseev (2011: 430): original description [75]; Kundrata et al. (2020: 20): generic catalogue [12].

Remark. Turonelater giganteus has a broad pronotum, with arcuate sides, and moderately long and carinate posterior angles. Such pronotum can be found in the widely delimited Dendrometrinae, especially within Prosternini, Selatosomini, Dimini and Oxynopterini. This species might actually belong to Oxynopterini based on the large body size, the pronotum deeply arcuated anteriorly, and the prosternal lobe seemingly weakly developed.



• Genus incertae sedis



Acmaeodera burmitina Cockerell, 1917

Acmaeodera burmitina Cockerell, 1917: 323 [33].

Type material. Holotype, sex unknown, amber inclusion, No. PI In. 19,107 (BMNH).

Fossil deposit/age. Myanmar: Burmese amber; 99.6–93.5 Ma (Cretaceous).

Literature. Cockerell (1917: 14): remark [as Elateridae] [32]; Cockerell (1917: 323): original description [as Buprestidae] [33]; Fletcher (1920: 987): remark [186]; Štys (1969: 357): remark [as Buprestidae] [223]; Zherikhin (1978: 114): remark [187]; Spahr (1981: 14): catalogue [as Buprestidae] [49]; Keilbach (1982: 248): checklist [as Buprestidae] [133]; Poinar (1992: 136): remark [as Buprestidae] [188]; Bellamy (1995: 175): review [as Elateridae] [224]; Ross (1998: 13) remark [225]; Ross and York (2000: 12): catalogue [as Elateridae] [189]; Bellamy (2008: 41): catalogue [as Elateridae] [226]; Ding et al. (2014: Table ES1): checklist [as Buprestidae] [227]; Peris and Háva (2016: 496): remark [as Elateridae] [190]; Otto (2019: 2): remark [as Elateridae] [96].

Remark. Although this species was described in the buprestid genus Acmaeodera Eschscholtz, 1829, it represents a member of Elateridae [32,33,189,224,226].

4. Discussion

In this study, we summarized information on all described fossil species in Elateridae. Altogether, 261 fossil species classified in 99 genera and nine subfamilies are currently listed in this family. Nevertheless, our results show that our knowledge of click-beetle palaeodiversity varies widely with respect to systematic, spatial and temporal elements.

The highest diversity of fossil Elateridae lies in the only exclusively fossil subfamily Protagrypninae [12,51,53]. It contains 94 species in 31 genera classified in four tribes (Table A1), which is more than a third of the described species diversity of fossil Elateridae. Not surprisingly, the next most diverse subfamilies include Agrypninae (13 genera/35 spp.), Dendrometrinae (11/35) and Elaterinae (13/29), which are three most species-rich extant click-beetle subfamilies based on numbers of described species [1,228]. The remaining subfamilies are represented only by a few species each. It should be noted, however, that another 50 species are currently considered incertae sedis, without a subfamily assignment (Table A1).

Regarding the geographic origin of fossil click-beetle species, the highest diversity comes from Eurasian deposits. By far the richest locality is the famous Late Jurassic Karatau in Kazakhstan from which 100 species have been described in 29 genera [51,52,53]. Other, at least moderately rich localities, include the Jurassic Daohugou in Inner Mongolia of China (4 genera/4 spp.), the Lower Cretaceous Yixian Formation in northeastern China (7/10) and the Zaza Formation of Baissa in Siberia (2/6), and the Miocene Shanwang Formation in eastern China (2/6). In Europe, the highest diversity of click-beetles has been described from Eocene Baltic amber, which has been redeposited from its original stratigraphic positions mainly in marine sediments and fluvial deposits, and contains the most diverse assemblage of fossil insects to date, including 17 click-beetle species classified in 16 genera [47,48,229]. Other important localities include the world-famous Eocene Grube Messel Pit (2 genera/11 spp.) and the Miocene Öhningen within the Upper Freshwater-Molasse Formation in Germany (8/10). The world-famous Florissant in Colorado, USA (Eocene) is the richest deposit in North America, with 38 click-beetle species classified in 17 genera [28,29]. Five species in five genera are known from the Eocene Green River Formation in USA, and four species in three genera were described from Mexican “Chiapas” amber, which is Miocene in age [46,61]. Several fossil click-beetle lineages were reported also from South America. However, the genera Babuskaya Martins-Neto and Gallego, 2009, Cardiosyne Martins-Neto and Gallego, 2006, and Gemelina Martins-Neto and Gallego, 2006 from the Mesozoic Argentinian deposits [71,72] were recently transferred from Elateridae to Coleoptera incertae sedis [12], and two Paleocene species were described based on elytra only, and their placement in Elateridae is dubious [35]. The Australian click-beetle fossil fauna includes five species in four genera from Mesozoic deposits; however, at least four species highly probably do not belong to Elateridae (see, e.g., Muona et al. [99]). Nevertheless, considering the relatively unique and rich extant Australian click-beetle fauna [228], as well as the fact that at least some lineages were among the early splits in the elaterid phylogeny [5,11], a Mesozoic fossil record of that family in Australia would make sense. Indeed, Oberprieler et al. [98] reported a possible undescribed elaterid from the Jurassic Talbragar Fish Bed but this record needs further investigation. Thus far, there are no fossil Elateridae described from African deposits.

Our knowledge of the click-beetle fossil record should help us to better estimate the origin of the group and understand the evolutionary changes throughout its history. Based on the available data, it is possible that the Elateridae originated as early as the Triassic; however, this has to be confirmed by further research on the already described specimens and new material from Triassic deposits from around the globe. Currently, six described species are reported from the Triassic, most of them of highly doubtful family attribution, especially those from the Australian Blackstone Formation [39]. The highest diversity of fossil Elateridae is reported from the Jurassic (113 species/39 genera/five subfamilies), with the vast majority of lineages described from the rich Karatau deposit [51,52,53]. Only 24 species were described from Cretaceous localities, mainly from China and Russia, but we can expect that many more species will be discovered in Burmese amber in the near future. While 143 click-beetle species are recorded from the Mesozoic, only 118 described species are known from Cenozoic deposits. Most of them were from the Eocene Epoch, mainly due to the rich sources such as the North American Florissant Formation and European Baltic amber. It should be noted that all Mesozoic click-beetle species belong to fossil genera, i.e., those in which no extant representatives are included, with the apparently wrongly classified Burmese-amber species Elater burmitinus and “Acmaeodera” burmitina being exceptions [32,33]. On the other hand, slightly more than half of the elaterid genera known from the Paleogene (i.e., Paleocene, Eocene and Oligocene) also contain extant species, and among 12 genera known from the Neogene (Miocene) only two include exclusively fossil species.

Although our current study is the first comprehensive overview of described fossil species in Elateridae and is intended to serve as a solid basis for all future studies of the click-beetle fossil record, it is an annotated catalogue rather than a taxonomic revision. Therefore, it must be treated with caution and interpreted carefully. Our results clearly show that the major problem with the click-beetle fossil record lies in the highly questionable family placement of many lineages, incorrectly interpreted morphological characters for fossil higher click-beetle taxa, and dubious or sometimes clearly erroneous generic assignments of many species across the whole classification of Elateridae. Incorrect identification of Mesozoic specimens can obscure our understanding of the origin of Elateridae and greatly affect the accuracy of the dating of phylogenetic trees in various studies. Click-beetle fossils from the rich Karatau deposit were used as one of the calibration points for a recent Coleoptera phylogeny [230], and Elaterophanes was used as an important calibration point in a dated molecular phylogenetic analysis of Elateroidea [231] or even of the whole of Coleoptera [232]. Kusy et al. [10] showed that analyses using different datasets, applied models and calibrations often come to different age estimates for the major splits as well as for the origin of bioluminescence in Elateroidea.

Detailed investigation of the family placement of most Mesozoic taxa currently assigned to Elateridae is crucial for our understanding of the origin, early evolution and past diversity of the group. One of the problems is that some of the oldest fossils are known only from a single elytron or its fragment and therefore, their placement even to a (super) family remains questionable [31,37,39]. Another problem is the uncertain family placement of many compression fossils from the Mesozoic Asian deposits, mainly from China and Karatau in Kazakhstan. The systematic placement of some Chinese click-beetles was already questioned in several [86,233,234]. Recently, Muona et al. [99] studied the Mesozoic clicking Elateroidea from Chinese deposits and discussed the external characters for recognizing Eucnemidae from other clicking elateroids, especially Elateridae. They showed that only about a third, i.e., 12 of 27, described fossil click-beetle species from China can be attributed to Elateridae with more or less certainty. One species was transferred to Throscidae, six to Eucnemidae, three could be either Elateridae or Eucnemidae based on the available characters, and five could not be studied due to the unavailability of the type material. As correctly pointed out by the authors [99], this drastically changed our view of the Mesozoic clicking elateroid fauna in China.

Moreover, a similar or even more dramatic situation may occur after the putative click-beetle taxa from the extremely rich Karatau deposit are re-examined in detail based on the type material. Dolin [51,52,53] focused on that deposit and reported from there an exceptionally high diversity of Elateridae, with 107 described species in 31 genera from five subfamilies. Interestingly, the vast majority species from Karatau are classified in the only fossil elaterid subfamily, Protagrypninae (Table A1). It was proposed by Dolin [51] for the earlier defined tribe Protagrypnini, which he originally described based on two genera from the Dzhil Formation in Kyrgyzstan and placed it in Agrypninae [50], and two other tribes, Desmatini and Hypnomorphini, from Karatau. He defined the subfamily based on the presence of longitudinal furrows (sutures) definining a medial field on the prosternum, a transverse suture on the mesoventrite, and the additional division of the apex of the radial cell on the hind wing [51,53]. However, it was evident even from the descriptions and illustrations that many of the species originally assigned to the click-beetle subfamily Protagrypninae may in fact represent some other clicking elateroid lineages. Indeed, Chang et al. [77] removed several species of one genus from Hypnomorphini to Cerophytidae, and many other species with potentially eucnemid- or throscid-like characters should be re-examined (see Muona et al. [99] for extensive discussion on such characters, and remarks under various protagrypnine taxa in the overview of fossil species above). The diagnosis and monophyly of Protagrypninae are questionable, and especially problematic is the inclusion of Desmatini, which do not fully fit into the subfamily diagnosis as their representatives lack a clearly defined transverse suture on the mesoventrite [51,53]. They also have considerably broadened metacoxal plates, a character common in Eucnemidae ([86,234] but see [99]). Potential transfer of a number of taxa currently listed in Elateridae to Eucnemidae or Throscidae would make sense considering the earlier origin and longer evolutionary history of eucnemids, cerophytids and throscids [230,231,235]. Indeed, many recent studies confirm a high diversity of these families in the Mesozoic fossil record [96,99,218,233,234,236,237,238,239,240]. On the other hand, there might be some opposite cases. For example, Alekseev [74] described the monotypic genus Cretopoena from the Lower Cretaceous of Mongolia and attributed it to Eucnemidae; however, Li et al. [234] treated it as Elateriformia incertae sedis due to the lack of characters clearly separating Eucnemidae and Elateridae. Based on the general body shape and the structure of thorax this genus might indeed belong to Elateridae. Moreover, its thorax and elytra bear strong granulation which might be possible traces of scale-like setae typical for the Agrypnini. However, Cretopoena clearly differs from Agrypnini by its closed pronotosternal sutures and, therefore, its systematic position should be further investigated. Additionally, the suggested close relationship between Elateridae and recently discovered Mysteriomorphidae from the Cretaceous Burmese amber needs to be investigated using an analytical approach [241,242].

After the family placements of Mesozoic (and also younger) taxa are investigated in detail, it would be important to classify all fossil species to the proper genera and subfamilies. This will, however, be hampered not only by the lack of visible diagnostic characters on fossil specimens but also by the constantly changing definitions of the higher taxa and apparently unstable suprageneric classification of Elateridae [1,6,11,228]. The presence and character of the putative median plate-like structure on the prosternum laterally defined by furrows or sutures in Protagrypninae was discussed and questioned by Muona et al. [99] who concluded based on a study of fossil and extant specimens of clicking elateroids that it might be a place which is abruptly lower than the surrounding portions of the prosternum. The second important character, i.e., the transverse suture on the mesoventrite, which mainly defines Protagrypnini and Hypnomorphini, may in fact represent the line between the mesoventrite body and the depressions on the anterior edge of the mesoventrite and mesanepisternum, which are common in clicking elateroids and for which we use the terms “procoxal rests” [243] or “anterior articulating surface” [244]. The secondarily divided radial cell in the hind wing venation needs further investigation as this character is usually difficult to observe in compression fossils. Among the Cenozoic click-beetle fossils, those which are in the most urgent need of revision are species described by Scudder [19] and Wickham [27,28], especially those from the Green River and Florissant Formations [245], and species described by Heer from Öhningen [14], for which similarly inaccurate generic attributions were also reported in other beetle families [246,247]. Of special interest are the waste-basket genera such as Elater or Ctenicera. Further, maximum effort should be put into the study of the genera incertae sedis which include 50 species from various geological ages (Table A1), and also into description of the as-yet formally undescribed click-beetle fossils reported from various deposits [229,248,249], as they may provide further information on the diversity of the main click-beetle lineages.

Last but not least, Elateridae students should pay special attention to the study of fossils included in amber deposits. Although the research of beetles (and other taxa) from various ambers is nowadays very popular [92,188,189,250,251,252] and scientists were even able to describe within a short time span several new beetle families based on amber material [241,253,254,255,256,257], the diversity of click-beetles in fossilized plant resins has been highly understudied. A study of the Elateridae diversity in amber is of great importance due to the three-dimensional preservation of specimens which allows us to compare the fossil fauna with extant specimens in much greater detail than in the case of compression fossils [188,229]. With the use of modern techniques such as micro-CT, researchers are able to reconstruct the morphology of a particular beetle even when the imporant diagnostic characters are obscured by opaque bubbles or suboptimal body position [94,242,258]. Regarding the click-beetle diversity in amber, only a few formally undescribed Elateridae were reported from Cretaceous Lebanese and Oligocene/Miocene Dominican ambers [54,95,188,253]; personal observations of authors]. Becker [46] and Zaragoza Caballero [61] described four species from the Miocene Mexican “Chiapas” amber. Cretaceous Burmese amber contains a high number of Elateridae from various lineages [249,259]; personal observations of authors] but only two species were described by Cockerell [33] (although one originally in Bupestidae) and a single species by Otto [96]. Elateridae were among the most-represented beetle families in Eocene Baltic amber [30,48]; hence it is not surprising that most click-beetle species were described from that amber, mainly due to the work by Iablokoff-Khnzorian [47]. However, the vast majority of click-beetles known from all ambers remain undescribed.

5. Conclusions

An understanding of the origin, evolution, and past diversity of click-beetles is hampered by the lack of detailed knowledge on their fossil record. We summarized the current knowledge on all described fossil species in Elateridae, and assessed each species based on its description and available illustrations to conclude whether its position in Elateridae and its generic attribution can be considered reliable or not. Our results suggest that the Triassic records based largely on isolated elytra are mostly dubious and may belong to different beetle families, and numerous Jurassic and Cretaceous lineages currently listed in Elateridae might belong to Eucnemidae or Throscidae. The vast majority of the fossil click-beetle species are in urgent need of revision, and the incertae sedis genera should be investigated to correctly assign them to subfamilies and tribes. We can expect many more lineages to be discovered mainly from the more and more intensively studied amber inclusions, especially from Eocene Baltic amber and Cretaceous Burmese amber, which both include a relatively high proportion of elaterid fossils.
