Enhancing Open BIM Interoperability : Automated Generation of a Structural Model from an Architectural Model

Building information modelling (BIM) is an appreciated technology in the field of architecture and construction management. Collaboration of information in BIM has not been fully utilized in the structural engineering stream as many engineers keep on working with previous prevailing design approaches. Failure to adequately facilitate automation in design could lead to structural defects, construction rework, or even structural clashes, with major financial implications. Given the inherent complexity of large-scale construction projects, the ‘manual design and detailing’ of structure is a challenging task and prone to human errors. Against this backdrop, this study developed a 4D building information management approach to facilitate automated structural models for professionals designing all the elements required in reinforced concrete (RC) structures like slabs, beams, and columns. The main contribution of this study is to obtain structural models directly from architecture models automatically, which reduces effort and possible errors in the previous prevailing approaches. The framework enables execution of all the model design works automatically through coding. This is achieved by executing a script which is beneficial for integrated project delivery (IPD). The 3D structural model in BIM software presented in this study extracts and transfers the geometrical data and links these data in Industry Foundation Classes (IFC) files using integration facilitated by Python3.6 and IFCopenshell. The developed automated programme framework offers a cost-effective and accurate methodology to address the limitations and inefficiencies of traditional methods of structural modelling, which had been carried out manually. The authors have developed a novel tool to extract structural models from architectural models without proprietary software, greatly benefiting BIM managers by enhancing 3D BIM models. This advancement toward Open BIM, crucial for the architecture, engineering, and construction (AEC) industry’s future, is accessible to educators and beginners and highlights BIM’s effectiveness in improving structural analysis and productivity. The core finding of this study is to generate a structural model from an architecture model by automating the script with Python integration of IFC and IFCopenshell. The merits of the developed framework are reduced clashes, more economical structural modelling, and fully automated smart work as functions of the IPD.
