Incidence, Size and Orientation of Maxillary Sinus Septa—A Retrospective Clinical Study

by
Laura Andreea Schiller
1,2,
Horia Mihail Barbu
3,4,
Stefania Andrada Iancu
4,5,* and
Silviu Brad
1
1
Department of Radiology, Victor Babes University of Medicine and Pharmacy, 300041 Timisoara, Romania
2
Department of Oral Surgery, Stomdas Clinic, 600125 Bacau, Romania
3
Oral Implantology Department, Faculty of Dental Medicine, Titu Maiorescu University, 031593 Bucharest, Romania
4
European Centre of Oral Implantology, 011473 Bucharest, Romania
5
Department of Prosthodontics, Faculty of Dental Medicine, Titu Maiorescu University, 031593 Bucharest, Romania
*
Author to whom correspondence should be addressed.
J. Clin. Med. 2022, 11(9), 2393; https://doi.org/10.3390/jcm11092393
Submission received: 29 March 2022 / Revised: 21 April 2022 / Accepted: 22 April 2022 / Published: 24 April 2022
(This article belongs to the Topic State-of-the-Art Dentistry and Oral Health)
Browse Figures
Versions Notes

Abstract

:
Background: The purpose of this study is to analyze if there is any statistical correlation between the surgery’s complexity (easy to difficult—depending on the anatomical conditions) and the patient’s sex, type of edentulism, and left or right side of the maxilla. Methods: Cone beam computed tomography records of 1192 maxillary sinuses were evaluated, measured, and statistically analyzed with respect to patient sex, type of edentulism, and left or right side, taking into consideration Wen’s proposed sinus septum classification. Results: Our research suggests that most sinus augmentation procedures in patients presenting antral septum fall into the Moderate A category (31.94%) and that there is not a correlation between the surgery’s complexity (easy to difficult) and the patient’s sex, type of edentulism and left or right side of the maxilla. Conclusion: We suggest a minor modification to Wen’s classification in view of the fact that our findings revealed a combination of medio-lateral and antero-posterior septa that we could not classify in one of the existing categories.

1. Introduction

Implant dentistry offers the possibility to rehabilitate simple and complex cases of edentulism with the aid of various, convenient materials and techniques. When necessary, implant surgeries for the maxilla are accompanied by sinus floor augmentation procedures to ensure the quantity and quality of bone in the posterior region of the dental arch.
Good knowledge of the anatomical variation of the maxillary sinus is mandatory for oral surgeries performed in immediate proximity (implant insertion in the subantral bone), or directly in the sinus cavity (sinus floor elevation).
The antral septa represent the most frequent disparity when describing the anatomy of the maxillary sinus [1]. These are cortical bone extensions arising from the floor or from the walls of the maxillary sinus [2,3].
The presence of sinus septa is associated with Schneiderian membrane perforation during sinus floor elevation, which increases surgical morbidity and enchains possible complications such as graft displacement, graft infection, sinusitis, etc.
A preoperative radiological assessment of the maxillary sinus provides important information about the presence of sinus septa, their location, size, and orientation. In this way, the surgeon can anticipate possible intraoperative complications and predict the complexity of the procedure. In some cases, the sinus septa hinder the luxation of the bony window, thus a modified design of the osteotomy window is needed as an alternative to access the sinus cavity [4]. This study aims to evaluate the incidence of maxillary sinus septa and to introduce a modification to Wen’s classification of the maxillary sinus septa [1]. Wen et al. divide the sinuses presenting septa into three categories based on location, number, orientation, and size of antral septa: easy (E)—subclass A and B, moderate (M)—subclass A and B, and difficult (D)—subclass A, B, and C. Corresponding treatment approaches were suggested for each category [1].
Different examination techniques for evaluation of the maxillary sinus include standard oral radiography, orthopantomography, CBCT scans [5], ultrasonography, and magnetic resonance imaging [6,7,8,9]. CBCT allows high-resolution images and does not have the inherent drawback of superimposition and magnification [5,10]. Although CBCT is considered the gold standard, the patient’s exposure to ionizing radiation and therefore biological damage must be constantly monitored. For this reason, the development and improvement of the applications of radiation-free diagnostic tests such as ultrasounds and MRI (Magnetic Resonance Imaging) in the study of the maxillary sinus, in particular, is a great stimulus for future research [6,7,8].

2. Materials and Methods

2.1. Study Design

The following research was structured as a retrospective cohort study, respecting the STROBE (Strengthening the Reporting of Observational Studies in Epidemiology) guidelines. Maxillary sinuses in dentate, single, partial, and edentulous patients were analyzed on CBCTs (cone beam computed tomographies) from the point of view of the bony internal architecture and the antral septa, respectively. The radiographic findings belonged to the European Center of Implantology, located in Bucharest, Romania, and the Central Clinic located in Bacau, Romania. All patients included in the study group agreed to be part of the study and signed an informed consent document.
The CBCTs were performed for these patients for accurate diagnosis and treatment plan in various medical circumstances (orthodontics, sinus lift procedures, third molar impaction, maxillary sinus pathologies, implant insertion, etc.) and were later introduced in this research. Unnecessary exposure for CBCT analysis was not performed. The research respected the ethical principles of the Helsinki Declaration (2008) and the additional revisions included at Fortaleza (2013), taking into consideration to protect the health and rights of the patients.
For this research to begin, ethical approval was firstly signed by the Institutional Review Board within STOMDAS CLINIC (Bacau, Romania) (No STO07FEB22-C01/7 February 2022).

2.2. Study Population

Medical documents of the patients treated in the two clinics were screened for potential inclusion in this research.
Inclusion criteria:
-
Age > 18 years, with no other age or gender restrictions;
-
Partial (hemimaxilla) or total CBCTs comprising at least 2/3 of the floor of the sinus cavity;
-
CBCTs of the upper arch.
Exclusion criteria:
-
CBCTs with exposure errors (because of patient’s movement, other artefacts);
-
Maxillary sinus cavities with previous sinus grafts;
-
CBCTs which do not comprise entirely, anteroposteriorly the sinus cavity;
-
CBCTs with a field of view of 40 × 40 (for endodontic purposes);
-
Absence of patient’s informed consent;
-
Panoramic radiographies.

2.3. Radiographic Measurements

The radiological exams were performed by two different cone beam computed tomography apparatuses. One of the computed tomographs was Veravierpocs RD R100 CB (J. Morita Corporation, Tokyo, Japan) with 10 mA and 0.125 voxel size. The second device was Kavo OP 3D Pro (Kavo, Biberach an der Riss, Germany), having 18.54 mA and 0.25–0.4 voxel size. Image processing, as well as the measurements, were performed in One Volume Viewer (J. Morita Corporation, Tokyo, Japan) and OneDemand3DTM X-ray software (Cybermed, Daejeon, Korea), accordingly.
The analysis of the internal architecture of the maxillary sinus was accomplished by two examiners, who evaluated the antrum in coronal, axial, and sagittal planes, while 3-dimensional reconstructions were used as necessary. To avoid any errors in the localization of septa, the multiplanar reconstruction technique was used [11]. The operators calibrated the software with a slice thickness of 0.5 mm and a slice interval of 1 mm.
The number of sinus septa was counted, and they were further analyzed in terms of their location, orientation, and height. When present, the antrum septa were grouped anterior, or, posterior to the zygomatic process of the maxillary bone. The anatomic landmark was the anterior limit of the zygomatic arch analyzed in the axial plane. From the point of view of the orientation, they were divided into medio-lateral and antero-posterior oriented septa. The medio-lateral type, oriented in the bucco-palatal direction, connects the buccal and palatal floors [12]. The antero-posterior type is oriented parallel to the sagittal plane. Sagittal images were used to determine the height of the medio-lateral septa [13] and the coronal images were used to determine the height of the antero-posterior septa. The examiners grouped the septa in two sizes, short ≤ 6 mm and long > 6 mm (Figure 1).

2.4. Statistical Analysis

The obtained data and assigned scores were recorded in a Microsoft Excel 2019 Pro Plus worksheet. Statistical analysis was performed with TIBCO Statistica 14.0.0 software (Palo Alto, CA, USA). The incidence of the septa present was documented with respect to the number of scans, the number of patients, sex of patients, sides of the maxillary sinus, and type of edentulism taking into consideration Wen’s proposed sinus septum classification.

3. Results

The study included 1192 maxillary sinuses from 686 patients (368 female and 318 male patients) with a mean age of 42.74 years (range between 18–73 years). They all underwent CBCT scans for different purposes (orthodontics, sinus lift procedures, third molar impaction, maxillary sinus pathologies, implant insertion, etc.). Of the entire group of patients, 506 patients had bimaxillary investigations (260 women and 246 men) and 180 had unilateral CBCTs (108 women and 72 men).
Sinus septa were detected in 504 sinuses (42.28%), while 688 sinuses (57.72%) had no internal bone crests. A total number of 652 septa were found in 504 sinuses.
The antrum septa were analyzed regarding their size, location, orientation, and number in dentate (group A), single (group B), partial (group C), and total edentulism (group D) (Table 1).
The most common orientation of the septa was medio-lateral for a number of 555 septa (85.12%), whereas the incidence of antero-posterior oriented septa was 97 (14.88%). A greater number were located posterior to the zygomatic process of the maxillary bone 409 (62.73%), while the rest were located anterior to the zygomatic process 243 (37.27%).
Regarding their size, 464 (71.17%) belonged to short category of septa (≤6 mm) and 188 (28.83%) were defined as long septa (>6 mm).
Out of 504 sinuses, 111 (22.03%) were classified as E (Easy), 234 (46.42%) as M (Moderate), and 159 (31.55%) as D (Difficult) according to Wen’s classification (Table 2).
No statistically significant correlation was observed between the right side and the left side of the same patient. Out of 506 patients with bimaxillary investigations, 298 (58.89%) belonged to the same classification level with both maxillary sinuses (ex: if the right sinus was easy, so was the left one). A number of 71 patients (14.03%) had a difference of one level in the classification (ex: if the right sinus was easy, the left one was medium, or, if the right sinus was medium, the left one was difficult), 88 patients (17.39%) had a difference of two levels in the classification (ex: if the right sinus was easy, the left one was difficult) and 49 patients (9.69%) had no septum on one side and difficult septa on the other side.
Inferential statistics were used to analyze data collected from 1192 maxillary sinus investigations. Pearson’s chi-squared test showed that Wen class MB is significantly more likely to be found on the right side (p = 0.0006), and that class DC is more likely to be found on the left side of the maxilla (p = 0.0002). Long septa are more likely to be found on the right side of the maxilla (p = 0.033) while short septa are on the left side (p = 0.022). Single septa are more likely to be found on the right side of the maxilla (p = 0.0002) while 2 septa are on the left side (p < 0.0001).
No correlation was observed between the presence of septa and the type of edentulism.
Multivariate analysis showed no statistically significant correlation between the surgery’s complexity (easy to difficult) and the patient’s sex, type of edentulism, and left or right side of the maxilla.

4. Discussion

Sinus floor augmentation is often a simple, safe, and viable technique for pre-implant site augmentation surgeries. This is also one of the most frequent bone grafting procedures used for bone atrophy in the posterior region of the upper arch. The guarantee of a qualitative bone volume in the implant site represents a prerequisite for long time implant survival. Successful osseointegration of the bone substitute material and the implants depends on the accuracy of each treatment stage, from preoperative planning to postoperative protocol. The surgery may involve a variety of immediate, intraoperative, or delayed, postoperative complications, which can impede proper consolidation of the bone grafting material, or even bring additional damage to an already atrophied implant site.
The most frequent intraoperative complication of sinus floor elevation surgeries is the Schneiderian membrane perforation [14,15]. There is a large spectrum of possible causes for the sinus membrane perforation cited in the literature, such as the presence of the antrum septa, a frail Schneiderian membrane, thicker lateral walls, lack of experience of the surgeon, incorrect, abusive use of the instruments during antrostomy or during elevation [11,14,16,17,18,19,20,21,22,23,24].
To minimize the risk of complications of maxillary sinus floor elevation and other surgeries in this region, it is crucial to be familiar with different anatomic and pathologic findings in the sinus [25,26,27]. As the maxillary sinuses are significant anatomic structures in dentistry, their accurate radiological assessment is necessary, and considering CBCT as an important diagnostic method in dentistry, the recognition of anatomic variations of the maxillary sinuses in CBCT is noteworthy [25,28].
The antrum septa are extensions of the cortical plate, arising from the sinus floor, or from the walls, which can divide the maxillary sinus into two or more smaller cavities [29]. They are different in size, location, direction, thickness, number, and origin [1,29]. For this reason, there are many classifications proposed in the literature in order to have an organized description of the sinus septa [29].
Upon the congenital, or, inherited origin they are divided into primary and secondary septa [30,31,32,33]. They can result during middle face growth, as fragments of the ethmoidal infundibulum remain non-resorbed (primary septa) [30]. Another process that leads to sinus septa formation is the bone atrophy of the subantral bone (and maxillary sinus pneumatization) secondary to tooth extraction. The result is bone projections, indentations, and crests arising from the floor of the maxillary sinus (secondary septa) [30,31,32].
The incidence of the antral septa from our study corresponds to other results found in the literature. The overall prevalence of the sinus septa reported in the literature at the maxillary sinus level rates between 29.7% and 59.7% [5,26,28,29,34,35,36,37,38,39,40,41,42,43,44,45,46,47]. The incidence of the sinus septa identified on CBCT scan is directly associated with a risk of Schneiderian membrane perforation and the subsequent complications of the sinus membrane rupture (graft migration, infection, maxillary sinusitis) [11,16,17,18,19,20,21,22,23,24]. The incidence of the Schneiderian membrane perforation associated with the presence of antrum septa was 44.7% in a study performed by Irinakis and agreed with data from previous reports [47].
Besides the number, Wen attributes more characteristics to septa found in the maxillary sinus, in order to define them as easy (E), moderate (M) or difficult (D). He combines their incidence with their location, orientation and size. He also suggests a treatment option for each clinical situation [1].
From the results of our research in correlation to our clinical experience, it is relevant to divide the subclass of Difficult septa (D) proposed by Wen, into Difficult (D) including multiple medio-lateral oriented septa and short antero-posterior septa, and Highly Difficult (HD) including the long antero-posterior oriented septa and a combination of medio-lateral and antero-posterior septa (Table 3). The rationale for this separation is the degree of complexity in sinus augmentation surgeries.
Single or multiple medio-lateral oriented septa may still offer the possibility to elevate the membrane with a reduced risk of perforation compared to antero-posterior oriented septa. The surgeon can perform a different design of the osteotomy window to have full access on both sides of the septa during sinus membrane elevation. Multiple windows, or a single window with a wall-off technique and a modified design, can offer the possibility to elevate the sinus membrane from the anterior and the posterior sides of a medio-lateral oriented septa (Figure 2).
Antero-posterior oriented septa impede proper access and reduce partially or totally the operator’s visibility on the medial side, which increases the risk of membrane perforation.
In cases with short antero-posterior oriented septa, the Schneiderian membrane can be elevated on the lateral side, from the base to the upper edge, without risk of perforation. Depending on each clinical case (membrane thickness, inclination of the septa) the membrane can be elevated partially or totally from the medial side of the short septa.
For long septa with antero-posterior orientation, Wen proposed a crestal approach, which increases the visibility of the operator. The window preparation has to be made in a way that its border is beyond the extent of the septum anteroposteriorly. After removing the window wall, the septum is separated from the alveolar ridge and the membrane is elevated to the planned height [1]. This type of surgical intervention is more difficult than a lateral approach and requires a skilled surgeon.
Combined medio-lateral and antero-posterior septa, with a direct interest in the implant site, can require a two-staged surgery: the first one to remove the septa (in case of proper perforation sealing of the membrane, this situation can turn into one staged surgery), and a second one for proper maxillary sinus floor augmentation [48]. This clinical situation also requires an experienced surgeon (Figure 3). We could not place this last type of septum in any of the Wen classes, which is why we suggest a minor modification to the initial classification (Table 3).
We consider Wen’s classification to be of major importance because it also gives treatment suggestions. These represent a useful tool for less experienced surgeons, by helping them plan the intervention properly. Every case is unique, and you should treat it accordingly, but it gives you a good starting point.
An initial planning of the implant position is relevant to know the exact surgical site which needs augmentation. In some cases, the membrane elevation and graft placement are not necessary for the entire sinus floor (Figure 4). It is our opinion that the best treatment option is the one that requires less intraoperative risks, without compromising the final outcome.
Besides the surgeon’s experience, a proper choice of surgical instruments can reduce the risk of sinus membrane ruptures. Osteotomy with a piezoelectric device to minimize trauma and intraoperative complications is highly recommended [49]. Jung et al. suggested creating a single small window anterior to the septum, or extended distally, to include the septum. After the Schneiderian membrane is lifted carefully on all sides except at the septum, a linear indentation can be made with a piezoelectric instrument at the base of the septum. Mobilization of the septum is achieved by gentle malleting and the membrane is again carefully lifted up behind the septum [50].
There are studies that show that computer guided sinus floor elevation showed promising results in accurately modifying the lateral window osteotomy and represents a safe alternative to the standard technique [51]. We should also take into consideration computer-guided sinus approach based on a magnetic stackable surgical guide to transfer the exact position of the septum and optimize the positioning of the lateral access windows. This technique reduces the risk of sinus membrane injury, thereby increasing the safety and efficacy of the procedure as Teixeira et al. previously recommended [52].
We consider the limitations of our study to be the following: the radiological exams were performed by two different cone beam computed tomography apparatuses; image processing, as well as the measurements, were performed with different software by two examiners; the uneven sample distribution of dental status. Another limitation is the lack of a correlation between the presence of sinus septa and sinus pathology (maxillary sinusitis, cystic lesions, tumors, traumatic injury, allergic sinusitis, etc.). Future studies will be required to determine more about this topic.
Within the limitations of this study, our research revealed that sinus septa are common findings, representing 42.28% in 1192 CBCT exams of the maxilla. Out of the 504 sinuses presenting septa, 111 (22.03%) were classified as E (Easy), 234 (46.42%) as M (Moderate) and 159 (31.55%) as D (Difficult) according to Wen’s classification. The most frequent subclass was MA (Moderate A) 31.94% followed by DC (Difficult C) 21.03%.
No statistically significant correlation was observed between the surgery’s complexity (easy to difficult) and the patient’s sex, type of edentulism and left or right side of the maxilla.

5. Conclusions

We suggest a minor modification to Wen’s classification in view of the fact that our findings revealed a combination of medio-lateral and antero-posterior septa that we could not classify in one of the existing categories.

Author Contributions

Conceptualization, L.A.S.; methodology, L.A.S. and S.A.I.; software, L.A.S. and S.A.I.; validation, H.M.B. and S.B.; formal analysis, L.A.S.; investigation, L.A.S. and H.M.B.; resources, L.A.S. and H.M.B.; data curation, L.A.S.; writing—original draft preparation, L.A.S. and S.A.I.; writing—review and editing, H.M.B. and S.B.; visualization, L.A.S. and S.A.I.; supervision, H.M.B. and S.B.; project administration, L.A.S. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

The study was conducted in accordance with the Declaration of Helsinki, and the protocol was approved by the Ethics Committee of STOMDAS CLINIC (Bacau, Romania) (No STO07FEB22-C01/7 February 2022).

Informed Consent Statement

All subjects gave their informed consent for inclusion before they participated in the study.

Data Availability Statement

The data presented in this study are available on request from the corresponding author. The data are not publicly available due to privacy policy.

Acknowledgments

We are thankful to Irimia I. Andreea, who helped us in the process of technical support.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Wen, S.C.; Chan, H.L.; Wang, H.L. Classification and management of antral septa for maxillary sinus augmentation. Int. J. Periodontics Restor. Dent. 2013, 33, 509–517. [Google Scholar] [CrossRef] [PubMed]
  2. Aşantoğrol, F.; Coşgunarslan, A. The effect of anatomical variations of the sinonasal region on maxillary sinus volume and dimensions: A three-dimensional study. Braz. J. Otorhinolaryngol. 2021. [Google Scholar] [CrossRef] [PubMed]
  3. Whyte, A.; Boeddinghaus, R. The maxillary sinus: Physiology, development and imaging anatomy. Dentomaxillo Facial Radiol. 2019, 48, 20190205. [Google Scholar] [CrossRef] [PubMed]
  4. Malec, M.; Smektała, T.; Trybek, G.; Sporniak-Tutak, K. Maxillary sinus septa: Prevalence, morphology, diagnostics and implantological implications. Systematic review. Folia Morphol. 2013, 73, 259–266. [Google Scholar] [CrossRef]
  5. Tadinada, A.; Jalali, E.; Al-Salman, W.; Jambhekar, S.; Katechia, B.; Almas, K. Prevalence of bony septa, antral pathology, and dimensions of the maxillary sinus from a sinus augmentation perspective: A retrospective cone-beam computed tomography study. Imaging Sci. Dent. 2016, 46, 109–115. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  6. Reda, R.; Zanza, A.; Mazzoni, A.; Cicconetti, A.; Testarelli, L.; Di Nardo, D. An Update of the Possible Applications of Magnetic Resonance Imaging (MRI) in Dentistry: A Literature Review. J. Imaging 2021, 7, 75. [Google Scholar] [CrossRef]
  7. Patil, S.; Alkahtani, A.; Bhandi, S.; Mashyakhy, M.; Alvarez, M.; Alroomy, R.; Hendi, A.; Varadarajan, S.; Reda, R.; Raj, A.T.; et al. Ultrasound Imaging versus Radiographs in Differentiating Periapical Lesions: A Systematic Review. Diagnostics 2021, 11, 1208. [Google Scholar] [CrossRef] [PubMed]
  8. Hsu, C.C.; Sheng, C.; Ho, C.Y. Efficacy of sinus ultrasound in diagnosis of acute and subacute maxillary sinusitis. J. Chin. Med. Assoc. 2018, 81, 898–904. [Google Scholar] [CrossRef] [PubMed]
  9. Shokri, A.; Jamalpour, M.; Jafariyeh, B.; Poorolajal, J.; Sabet, N.K. Comparison of Ultrasonography, Magnetic Resonance Imaging and Cone Beam Computed Tomography for Detection of Foreign Bodies in Maxillofacial Region. J. Clin. Diagn. Res. 2017, 11, TC15–TC19. [Google Scholar] [CrossRef] [PubMed]
  10. Okuyama, K.; Sakamoto, Y.; Naruse, T.; Kawakita, A.; Yanamoto, S.; Furukawa, K.; Umeda, M. Intraoral extraction of an ectopic mandibular third molar detected in the subcondylar region without a pathological cause: A case report and literature review. CRANIO®—J. Craniomandib. Sleep Pract. 2017, 35, 327–331. [Google Scholar] [CrossRef] [PubMed]
  11. Schwarz, L.; Schiebel, V.; Hof, M.; Ulm, C.; Watzek, G.; Pommer, B. Risk Factors of Membrane Perforation and Postoperative Complications in Sinus Floor Elevation Surgery: Review of 407 Augmentation Procedures. J. Oral Maxillofac. Surg. 2015, 73, 1275–1282. [Google Scholar] [CrossRef]
  12. Qian, L.; Tian, X.M.; Zeng, L.; Gong, Y.; Wei, B. Analysis of the Morphology of Maxillary Sinus Septa on Reconstructed Cone-Beam Computed Tomography Images. J. Oral Maxillofac. Surg. 2016, 74, 729–737. [Google Scholar] [CrossRef]
  13. Jang, S.Y.; Chung, K.; Jung, S.; Park, H.J.; Oh, H.K.; Kook, M.S. Comparative study of the sinus septa between dentulous and edentulous patients by cone beam computed tomography. Implant Dent. 2014, 23, 477–481. [Google Scholar] [CrossRef] [PubMed]
  14. Barbu, H.M.; Iancu, S.A.; Jarjour Mirea, I.; Mignogna, M.D.; Samet, N.; Calvo-Guirado, J.L. Management of Schneiderian Membrane Perforations during Sinus Augmentation Procedures: A Preliminary Comparison of Two Different Approaches. J. Clin. Med. 2019, 8, 1491. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  15. Bathla, S.C.; Fry, R.R.; Majumdar, K. Maxillary sinus augmentation. J. Indian Soc. Periodontol. 2018, 22, 468–473. [Google Scholar] [CrossRef] [PubMed]
  16. Stacchi, C.; Lombardi, T.; Cusimano, P.; Berton, F.; Lauritano, F.; Cervino, G.; Di Lenarda, R.; Cicciù, M. Bone Scrapers Versus Piezoelectric Surgery in the Lateral Antrostomy for Sinus Floor Elevation. J. Craniofac. Surg. 2017, 28, 1191–1196. [Google Scholar] [CrossRef] [PubMed]
  17. Al-Dajani, M. Incidence, Risk Factors, and Complications of Schneiderian Membrane Perforation in Sinus Lift Surgery: A Meta-Analysis. Implant Dent. 2016, 25, 409–415. [Google Scholar] [CrossRef] [PubMed]
  18. von Arx, T.; Fodich, I.; Bornstein, M.M.; Jensen, S.S. Perforation of the sinus membrane during sinus floor elevation: A retrospective study of frequency and possible risk factors. Int. J. Oral Maxillofac. Implant. 2014, 29, 718–726. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  19. Sigaroudi, A.K.; Kajan, Z.D.; Rastgar, S.; Asli, H.N. Frequency of different maxillary sinus septal patterns found on cone-beam computed tomography and predicting the associated risk of sinus membrane perforation during sinus lifting. Imaging Sci. Dent. 2017, 47, 261–267. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  20. Tükel, H.C.; Tatli, U. Risk factors and clinical outcomes of sinus membrane perforation during lateral window sinus lifting: Analysis of 120 patients. Int. J. Oral Maxillofac. Surg. 2018, 47, 1189–1194. [Google Scholar] [CrossRef] [PubMed]
  21. Marin, S.; Kirnbauer, B.; Rugani, P.; Payer, M.; Jakse, N. Potential risk factors for maxillary sinus membrane perforation and treatment outcome analysis. Clin. Implant Dent. Relat. Res. 2019, 21, 66–72. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  22. Krennmair, S.; Malek, M.; Forstner, T.; Krennmair, G.; Weinländer, M.; Hunger, S. Risk Factor Analysis Affecting Sinus Membrane Perforation During Lateral Window Maxillary Sinus Elevation Surgery. Int. J. Oral Maxillofac. Implant. 2020, 35, 789–798. [Google Scholar] [CrossRef]
  23. Pizzini, A.; Basma, H.S.; Li, P.; Geurs, N.C.; Abou-Arraj, R.V. The impact of anatomic, patient and surgical factors on membrane perforation during lateral wall sinus floor elevation. Clin. Oral Implants Res. 2021, 32, 274–284. [Google Scholar] [CrossRef] [PubMed]
  24. Testori, T.; Yu, S.H.; Tavelli, L.; Wang, H.L. Perforation Risk Assessment in Maxillary Sinus Augmentation with Lateral Wall Technique. Int. J. Periodontics Restor. Dent. 2020, 40, 373–380. [Google Scholar] [CrossRef] [PubMed]
  25. Shahidi, S.; Zamiri, B.; Danaei, S.M.; Salehi, S.; Hamedani, S. Evaluation of Anatomic Variations in Maxillary Sinus with the Aid of Cone Beam Computed Tomography (CBCT) in a Population in South of Iran. J. Dent. 2016, 17, 7–15. [Google Scholar]
  26. Orhan, K.; Seker, B.K.; Aksoy, S.; Bayindir, H.; Berberoğlu, A.; Seker, E. Cone beam CT evaluation of maxillary sinus septa prevalence, height, location and morphology in children and an adult population. Med. Princ. Pract. 2013, 22, 47–53. [Google Scholar] [CrossRef]
  27. Dobele, I.; Kise, L.; Apse, P.; Kragis, G.; Bigestans, A. Radiographic assessment of findings in the maxillary sinus using cone-beam computed tomography. Stomatologija 2013, 15, 119–122. [Google Scholar] [PubMed]
  28. Lana, J.P.; Carneiro, P.M.; Machado, V.; de Souza, P.E.; Manzi, F.R.; Horta, M.C. Anatomic variations and lesions of the maxillary sinus detected in cone beam computed tomography for dental implants. Clin. Oral Implant. Res. 2012, 23, 1398–1403. [Google Scholar] [CrossRef] [PubMed]
  29. Nasseh, I.; Aoun, G.; El-Outa, A.; Nassar, J.; Nasseh, P.; Hayek, E. Mapping Maxillary Sinus Septa in a Lebanese Sample: A Radio-anatomical Study. Acta Inform. Med. 2020, 28, 214–218. [Google Scholar] [CrossRef]
  30. Faramarzie, M.; Babaloo, A.R.; Oskouei, S.G. Prevalence, height, and location of antral septa in Iranian patients undergoing maxillary sinus lift. J. Adv. Periodontol. Implant. Dent. 2009, 1, 43–47. [Google Scholar]
  31. Demirkol, M.; Demirkol, N. The effects of posterior alveolar bone height on the height of maxillary sinus septa. Surg. Radiol. Anat. 2019, 41, 1003–1009. [Google Scholar] [CrossRef] [PubMed]
  32. Bornstein, M.M.; Seiffert, C.; Maestre-Ferrín, L.; Fodich, I.; Jacobs, R.; Buser, D.; von Arx, T. An Analysis of Frequency, Morphology, and Locations of Maxillary Sinus Septa Using Cone Beam Computed Tomography. Int. J. Oral Maxillofac. Implant. 2016, 31, 280–287. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  33. Al-Zahrani, M.S.; Al-Ahmari, M.M.; Al-Zahrani, A.A.; Al-Mutairi, K.D.; Zawawi, K.H. Prevalence and morphological variations of maxillary sinus septa in different age groups: A CBCT analysis. Ann. Saudi Med. 2020, 40, 200–206. [Google Scholar] [CrossRef]
  34. Yildirim, T.T.; Güncü, G.N.; Colak, M.; Nares, S.; Tözüm, T.F. Evaluation of maxillary sinus septa: A retrospective clinical study with cone beam computerized tomography (CBCT). Eur. Rev. Med. Pharmacol. Sci. 2017, 21, 5306–5314. [Google Scholar]
  35. Schriber, M.; von Arx, T.; Sendi, P.; Jacobs, R.; Suter, V.G.; Bornstein, M.M. Evaluating Maxillary Sinus Septa Using Cone Beam Computed Tomography: Is There a Difference in Frequency and Type Between the Dentate and Edentulous Posterior Maxilla? Int. J. Oral Maxillofac. Implant. 2017, 32, 1324–1332. [Google Scholar] [CrossRef] [PubMed]
  36. Takeda, D.; Hasegawa, T.; Saito, I.; Arimoto, S.; Akashi, M.; Komori, T. A radiologic evaluation of the incidence and morphology of maxillary sinus septa in Japanese dentate maxillae. Oral Maxillofac. Surg. 2019, 23, 233–237. [Google Scholar] [CrossRef] [PubMed]
  37. Jung, J.; Park, J.S.; Hong, S.J.; Kim, G.T.; Kwon, Y.D. Axial Triangle of the Maxillary Sinus, and its Surgical Implication With the Position of Maxillary Sinus Septa During Sinus Floor Elevation: A CBCT Analysis. J. Oral Implant. 2020, 46, 415–422. [Google Scholar] [CrossRef]
  38. Toprak, M.E.; Ataç, M.S. Maxillary sinus septa and anatomical correlation with the dentition type of sinus region: A cone beam computed tomographic study. Br. J. Oral Maxillofac. Surg. 2021, 59, 419–424. [Google Scholar] [CrossRef] [PubMed]
  39. Rancitelli, D.; Borgonovo, A.E.; Cicciù, M.; Re, D.; Rizza, F.; Frigo, A.C.; Maiorana, C. Maxillary Sinus Septa and Anatomic Correlation With the Schneiderian Membrane. J. Craniofac. Surg. 2015, 26, 1394–1398. [Google Scholar] [CrossRef] [PubMed]
  40. Sakhdari, S.; Panjnoush, M.; Eyvazlou, A.; Niktash, A. Determination of the Prevalence, Height, and Location of the Maxillary Sinus Septa Using Cone Beam Computed Tomography. Implant Dent. 2016, 25, 335–340. [Google Scholar] [CrossRef] [PubMed]
  41. Chen, M.Z.; Xie, Y.F.; Xie, H.; Wang, G.H.; He, J.C. Cone-beam CT study of bone septa during maxillary sinus lift among Changzhou population. Shanghai J. Stomatol. 2016, 25, 77–81. [Google Scholar]
  42. Taleghani, F.; Tehranchi, M.; Shahab, S.; Zohri, Z. Prevalence, Location, and Size of Maxillary Sinus Septa: Computed Tomography Scan Analysis. J. Contemp. Dent. Pract. 2017, 18, 11–15. [Google Scholar] [CrossRef] [PubMed]
  43. Shen, E.C.; Fu, E.; Chiu, T.J.; Chang, V.; Chiang, C.Y.; Tu, H.P. Prevalence and location of maxillary sinus septa in the Taiwanese population and relationship to the absence of molars. Clin. Oral Implant. Res. 2012, 23, 741–745. [Google Scholar] [CrossRef] [PubMed]
  44. Kang, S.J.; Shin, S.I.; Herr, Y.; Kwon, Y.H.; Kim, G.T.; Chung, J.H. Anatomical structures in the maxillary sinus related to lateral sinus elevation: A cone beam computed tomographic analysis. Clin. Oral Implant. Res. 2013, 24, 75–81. [Google Scholar] [CrossRef]
  45. Li, J.; Zhou, Z.X.; Yuan, Z.Y.; Yuan, H.; Sun, C.; Chen, N. An anatomical study of maxillary sinus septum of Han population in Jiangsu region using cone-beam CT. Shanghai J. Stomatol. 2013, 22, 52–57. [Google Scholar]
  46. Hungerbühler, A.; Rostetter, C.; Lübbers, H.T.; Rücker, M.; Stadlinger, B. Anatomical characteristics of maxillary sinus septa visualized by cone beam computed tomography. Int. J. Oral Maxillofac. Surg. 2019, 48, 382–387. [Google Scholar] [CrossRef] [PubMed]
  47. Irinakis, T.; Dabuleanu, V.; Aldahlawi, S. Complications During Maxillary Sinus Augmentation Associated with Interfering Septa: A New Classification of Septa. Open Dent. J. 2017, 11, 140–150. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  48. Okada, T.; Kawana, H. Two-Step Procedure for the Treatment of a Maxillary Sinus with Complex Sinus Septa: A Highly Predictive Method for Sinus Floor Augmentation After Perforation of the Maxillary Sinus Membrane. Int. J. Periodontics Restor. Dent. 2019, 39, e175–e180. [Google Scholar] [CrossRef]
  49. Martins, M.; Vieira, W.A.; Paranhos, L.R.; Motta, R.H.; da Silva, C.S.; Rodriguez, C.; Ramacciato, J.C. Comparison of piezosurgery and conventional rotary instruments in schneider’s membrane sinus lifting: A pilot randomized trial. J. Clin. Exp. Dent. 2021, 13, e802–e808. [Google Scholar] [CrossRef] [PubMed]
  50. Jung, J.; Hwang, B.Y.; Kim, B.S.; Lee, J.W. Floating septum technique: Easy and safe method maxillary sinus septa in sinus lifting procedure. Maxillofac. Plast. Reconstr. Surg. 2019, 41, 54. [Google Scholar] [CrossRef] [PubMed]
  51. Osman, A.H.; Mansour, H.; Atef, M.; Hakam, M. Computer guided sinus floor elevation through lateral window approach with simultaneous implant placement. Clin. Implant Dent. Relat. Res. 2018, 20, 137–143. [Google Scholar] [CrossRef] [PubMed]
  52. Teixeira, K.N.; Sakurada, M.A.; Philippi, A.G.; Gonçalves, T. Use of a stackable surgical guide to improve the accuracy of the lateral wall approach for sinus grafting in the presence of a sinus septum. Int. J. Oral Maxillofac. Surg. 2021, 50, 1383–1385. [Google Scholar] [CrossRef] [PubMed]
Jcm 11 02393 g001 550
Figure 1. Radiological and clinical aspect of the maxillary sinus in partial edentulous patients before sinus floor augmentation. (a) CBCT sagittal view of a right maxilla with a long medio−lateral oriented septum. (b) Intraoperative view of the two windows technique. (c) CBCT sagittal view of a right maxilla with short medio−lateral oriented septa. (d) Intraoperative view of the osteotomy window.
Figure 1. Radiological and clinical aspect of the maxillary sinus in partial edentulous patients before sinus floor augmentation. (a) CBCT sagittal view of a right maxilla with a long medio−lateral oriented septum. (b) Intraoperative view of the two windows technique. (c) CBCT sagittal view of a right maxilla with short medio−lateral oriented septa. (d) Intraoperative view of the osteotomy window.
Jcm 11 02393 g001
Jcm 11 02393 g002 550
Figure 2. Management of medio−lateral septa. (a) CBCT sagittal view of the left maxilla with a medio−lateral oriented septum. (b) One window with a modified design of the osteotomy. (c) CBCT sagittal view after maxillary sinus floor augmentation.
Figure 2. Management of medio−lateral septa. (a) CBCT sagittal view of the left maxilla with a medio−lateral oriented septum. (b) One window with a modified design of the osteotomy. (c) CBCT sagittal view after maxillary sinus floor augmentation.
Jcm 11 02393 g002
Jcm 11 02393 g003 550
Figure 3. Combination of medio−lateral and antero−posterior septa (“Y” septum). (a) CBCT axial view of the left maxilla with simulation of implant placement. (b) CBCT axial view of the left maxilla revealing the “Y” septum. (c) CBCT sagittal view of the left maxilla with simulation of implant placement. (d) CBCT coronal view of the left maxilla with simulation of implant placement.
Figure 3. Combination of medio−lateral and antero−posterior septa (“Y” septum). (a) CBCT axial view of the left maxilla with simulation of implant placement. (b) CBCT axial view of the left maxilla revealing the “Y” septum. (c) CBCT sagittal view of the left maxilla with simulation of implant placement. (d) CBCT coronal view of the left maxilla with simulation of implant placement.
Jcm 11 02393 g003
Jcm 11 02393 g004 550
Figure 4. Management of antero-posterior septa. (a) CBCT coronal view of the left maxilla with a antero-posterior oriented septa. (b) CBCT coronal view after maxillary sinus floor augmentation with simultaneous dental implant placement (one window from lateral approach)—the implant prosthetically driven position did not require augmentation of the medial compartment of the sinus.
Figure 4. Management of antero-posterior septa. (a) CBCT coronal view of the left maxilla with a antero-posterior oriented septa. (b) CBCT coronal view after maxillary sinus floor augmentation with simultaneous dental implant placement (one window from lateral approach)—the implant prosthetically driven position did not require augmentation of the medial compartment of the sinus.
Jcm 11 02393 g004
Table
Table 1. The incidence of sinus septa in different type of edentulism.
Table 1. The incidence of sinus septa in different type of edentulism.
No. SinusesIncidence of Septa
Completely dentate patients (group A)19238.54%
Single edentulism (group B)32047.19%
Partial edentulism (group C)59642.62%
Total edentulism (group D)8432.14%
Table
Table 2. The incidence of surgery complexity according to Wen’s classification.
Table 2. The incidence of surgery complexity according to Wen’s classification.
Wen Sinus Septum ClassificationNumber of SinusesPercentage
Easy/A7715.28%
Easy/B346.75%
Medium/A16131.94%
Medium/B7314.48%
Difficult/A356.95%
Difficult/B183.57%
Difficult/C10621.03%
Table
Table 3. Minor modification brought to Wen’s classification, with the combination of medio-lateral and antero-posterior septa in Highly Difficult (HD) group. In both classes (D-Difficult and HD-Highly Difficult) there are two subdivisions (A and B), which vary in different orientation of the septa and treatment options.
Table 3. Minor modification brought to Wen’s classification, with the combination of medio-lateral and antero-posterior septa in Highly Difficult (HD) group. In both classes (D-Difficult and HD-Highly Difficult) there are two subdivisions (A and B), which vary in different orientation of the septa and treatment options.
ClassificationSubclassLocationNumberOrientationSize (mm)Proposed Treatment Approach
(D) DifficultAAnterior or posterior to zygomatic process≥2Medio-lateral Multiple windows and/or wall-gone technique
B1Antero-posterior≤6One window from the lateral approach
Highly Difficult (HD)AAnterior or posterior to zygomatic process1Antero-posterior>6One window from the crestal approach & the wall gone technique
BCombination of medio-lateral and antero-posterior septa One window from the lateral approach and removal of the septum; most likely second surgery for sinus floor augmentation
Publisher’s Note: MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Share and Cite

MDPI and ACS Style

Schiller, L.A.; Barbu, H.M.; Iancu, S.A.; Brad, S. Incidence, Size and Orientation of Maxillary Sinus Septa—A Retrospective Clinical Study. J. Clin. Med. 2022, 11, 2393. https://doi.org/10.3390/jcm11092393

AMA Style

Schiller LA, Barbu HM, Iancu SA, Brad S. Incidence, Size and Orientation of Maxillary Sinus Septa—A Retrospective Clinical Study. Journal of Clinical Medicine. 2022; 11(9):2393. https://doi.org/10.3390/jcm11092393

Chicago/Turabian Style

Schiller, Laura Andreea, Horia Mihail Barbu, Stefania Andrada Iancu, and Silviu Brad. 2022. "Incidence, Size and Orientation of Maxillary Sinus Septa—A Retrospective Clinical Study" Journal of Clinical Medicine 11, no. 9: 2393. https://doi.org/10.3390/jcm11092393

APA Style

Schiller, L. A., Barbu, H. M., Iancu, S. A., & Brad, S. (2022). Incidence, Size and Orientation of Maxillary Sinus Septa—A Retrospective Clinical Study. Journal of Clinical Medicine, 11(9), 2393. https://doi.org/10.3390/jcm11092393

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
