Near-wall flow around circular cylinders is commonly encountered in various engineering applications, such as submarine pipelines and river-crossing conduits. The wake structure significantly influences local flow stability and has become a critical focus in fluid dynamics research. Specifically, when the gap ratio (
G/D) ranges from 0.1 to 1.0, the interaction mechanism between the wall and the wake structure remains poorly understood. Moreover, the combined effects of the Reynolds number (
Re) and gap ratio on the flow field require further investigation. In this study, a series of experimental measurements were conducted using two-dimensional, two-component particle image velocimetry (2D–2C PIV) to examine the influence of
G/D and
Re on the near-wall wake characteristics. The results indicate that, at a gap ratio of
G/D = 0.1, the gap flow exhibits pronounced curling into the recirculation region, where the lower vortex is entrained and actively participates in wake evolution. When
G/D ≥ 0.3, an increase in
Re leads to a reduction in the lengths of both the upper and lower shear layers, a delayed attenuation of the wall-side shear layer, and a gradual symmetrization and contraction of the recirculation region behind the cylinder. Further analysis reveals that the evolution of the secondary vortex is strongly influenced by the combined effects of
Re and
G/D. Specifically, at
Re = 3300 and
G/D ≤ 0.3, the secondary vortex migrates away from the wall toward the upper shear layer, where it merges with the upper vortex. For 0.5 ≤
G/D ≤ 0.7, it interacts with the lower vortex, while at
G/D = 1.0, it evolves independently downstream along the wall. At
G/D = 0.5, the secondary vortex merges with the upper vortex at
Re = 1100, whereas at
Re = 5500, it interacts with the lower vortex instead. These findings contribute to a deeper understanding of the complex flow structures associated with near-wall cylinder wakes and offer valuable theoretical insights for engineering applications involving submarine pipelines in bottom-mounted or partially suspended configurations.
