Optical Hydrogel Detector for pH Measurements
Abstract
:1. Introduction
2. Methodology
2.1. Materials
2.2. Fabrication of the pH Sensor
2.3. Measurement Techniques
3. Results and Discussion
4. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
References
