Dye Laser Applications in Cosmetic Dermatology: Efficacy and Safety in Treating Vascular Lesions and Scars

by
Alessandro Clementi
1,*,
Giovanni Cannarozzo
2,
Simone Amato
2,
Elena Zappia
3,
Luigi Bennardo
3,
Simone Michelini
2,
Cristiano Morini
2,
Mario Sannino
2,
Caterina Longo
1 and
Steven Paul Nistico
2
1
Department of Dermatology, University of Modena and Reggio Emilia, 41124 Modena, Italy
2
Department of Clinical Sciences, Sapienza University of Rome, 00185 Rome, Italy
3
Department of Health Sciences, Magna Graecia University, 88100 Catanzaro, Italy
*
Author to whom correspondence should be addressed.
Cosmetics 2024, 11(6), 227; https://doi.org/10.3390/cosmetics11060227
Submission received: 8 October 2024 / Revised: 13 December 2024 / Accepted: 20 December 2024 / Published: 23 December 2024
(This article belongs to the Special Issue Current and Future Trends in Cosmetics Research: The 10th Anniversary of Cosmetics)
Browse Figures
Review Reports Versions Notes

Abstract

:
Cosmetic dermatology increasingly utilizes laser technologies to address various aesthetic concerns. This study evaluates the efficacy of the flash-lamp pulsed-dye laser (FPDL) in treating vascular and scar-related conditions. A cohort of 71 patients with diverse vascular lesions, including facial telangiectasia, port-wine stains (PWSs), striae rubrae, erythematous acne scars, facial traumatic scars, and keloids, was treated using the FPDL (Synchro Vas-Q, Deka MELA). Treatment protocols varied based on lesion type, with sessions ranging from one to eight at intervals of four to eight weeks. Clinical outcomes were assessed using a four-point grading scale and patient satisfaction surveys. Results indicated that 70.4% of patients achieved excellent clearance of lesions, while 16.9% and 9.9% showed moderate-good and slight clearance, respectively. Minimal or no improvement was observed in 2.8% of cases. High patient satisfaction was reported, correlating with effective lesion reduction and manageable side effects, primarily post-operative purpura. The study underscores FPDL’s selective efficacy for hemoglobin-rich lesions and its safety profile, advocating for its continued use in cosmetic dermatological practices. These findings contribute to the growing evidence supporting laser therapy as a pivotal tool in aesthetic medicine, emphasizing the importance of tailored treatment protocols and patient education for optimal outcomes.

1. Introduction

Cosmetic dermatology has undergone significant advancements with the integration of laser technologies, particularly the flash-lamp pulsed-dye laser (FPDL), which has emerged as a pivotal tool in addressing various aesthetic concerns [1,2]. The FPDL operates on the principle of selective photothermolysis, utilizing specific wavelengths of light (typically around 585–595 nm) that are preferentially absorbed by hemoglobin within blood vessels. This selective targeting minimizes damage to surrounding tissues, thereby enhancing both the safety and efficacy of treatments [3,4]. The ability of FPDL to precisely target vascular structures makes it exceptionally effective for treating conditions such as facial telangiectasia and port-wine stains (PWSs), which are not only cosmetically distressing but can also impact an individual’s psychological well-being [5,6,7].
In clinical practice, the assessment of lesions prior to treatment is crucial for determining the appropriate laser parameters and ensuring optimal outcomes. In this study, lesions were evaluated using multispectral analysis, a sophisticated imaging technique that allows for the detailed examination of the vascular components within the skin [8,9]. This comprehensive analysis facilitates the precise application of the dye laser by identifying the extent and depth of vascular involvement, thereby tailoring the treatment to each specific lesion. The utilization of multispectral analysis enhances the effectiveness of FPDL, particularly in the treatment of keloids, where the vascular component plays a significant role in scar formation and persistence [10,11].
Beyond vascular lesions, the application of FPDL has expanded to include scar-related conditions, such as keloids, hypertrophic scars, and striae rubrae. However, the variability in patient responses and the occurrence of side effects such as post-operative purpura necessitate a nuanced understanding of optimal treatment protocols [12,13]. Additionally, while FPDL has shown promise in treating erythematous acne scars and traumatic scars, the long-term outcomes and comparative effectiveness with other laser modalities remain areas of ongoing investigation [14,15].
Controversies in the field primarily revolve around the balance between achieving maximal lesion clearance and minimizing adverse effects. Some studies advocate for higher fluence settings to ensure complete vascular targeting, while others emphasize the importance of patient comfort and satisfaction by utilizing lower, non-purpuragenic settings [14,16]. This divergence underscores the need for individualized treatment plans tailored to specific lesion types and patient preferences.
The purpose of this study is to evaluate the efficacy and safety of FPDL in treating a spectrum of cosmetic dermatological conditions, including vascular lesions and various types of scars. By analyzing clinical outcomes and patient satisfaction in a diverse patient population, this research aims to propose a refined treatment protocol developed through clinical experience that incorporates progressively escalating fluences, tailored pulse overlaps, and optimal intervals between treatment sessions. Ultimately, the study seeks to contribute to the growing body of evidence supporting the use of laser therapy in cosmetic dermatology, emphasizing the importance of personalized treatment strategies and comprehensive patient education to achieve optimal clinical outcomes.

2. Materials and Methods

In this open study, a total of 71 patients (45 females and 27 males, with a mean age of 42 ± 9.50 years) were enrolled and treated at the Laser Unit of Sapienza and Magna Graecia University in Rome and Catanzaro, Italy. They all presented cosmetic concerns with evidence of vascular involvement. They were affected by various conditions, including 22 facial telangiectasia (with or without associated rosacea), 10 port-wine stains (PWSs), 8 striae rubrae, 12 erythematous acne scars, 4 facial traumatic scars, and 15 keloids.
Patients who had undergone previous laser treatments were excluded to eliminate potential confounding factors. All participants provided informed consent regarding the risks associated with the procedure and agreed to be photographed for documentation and evaluation purposes. The study was approved by the Local Ethical Committee of Calabria Region (protocol code 374; 17 December 2019). Before starting treatment, each patient underwent a comprehensive clinical examination and medical history assessment to identify any potential contraindications. Motivations and expectations were thoroughly discussed to ensure realistic goals and enhance patient satisfaction. A multispectral analysis was conducted before each session and at the end of the study to evaluate the extent of vascularization in each lesion.
Patients underwent between one and eight sessions with the FPDL (Synchro Vas-Q, Deka MELA, Florence, Italy) scheduled at intervals of four to eight weeks, as indicated in Table 1. All laser sessions were performed using fluences ranging from 6 to 10 J/cm2, with spot sizes of either 7 mm or 12 mm. The pulse durations varied between 0.5 and 1 ms, and pulses overlapped by 10% to 50% to ensure uniformity of treatment.
Topical anesthesia was not necessary due to the use of a cooling device during and after each session. Immediately after each laser treatment, compression of the treated area with cold, wet gauze for 10–15 min was essential to reduce edema and inflammation. A non-steroidal anti-inflammatory cream was then applied to soothe the skin and mitigate the inflammatory response.
Patients were advised to avoid trauma to the treated area, refrain from using cosmetics in the early days, and protect the area from direct sunlight exposure. Instructions were given to apply cold, wet gauze compresses several times daily to provide relief and control inflammation. Additionally, an antibiotic ointment (fusidic acid) was prescribed for application to the treated area twice daily for eight days following each laser session to prevent secondary infections. Treatments were performed year-round, with sunscreen application highly recommended between sessions, especially during the summer months.
Results were evaluated through clinical assessments and both photographic and multispectral documentation at each follow-up visit and eight weeks after the final session. The number of treatment sessions recommended for each lesion type, as outlined in Table 1, was based on our extensive clinical experience with similar cases. However, during each follow-up visit, the decision to schedule additional treatments was determined by the clinical outcomes achieved and the persistence of residual vascular components.
The efficacy of the treatments was assessed using a four-point grading scale that quantified lesion clearance relative to baseline. This scale categorized the outcomes as follows: a score of 1 indicated no or minimal improvement, corresponding to 0–25% of the lesion area cleared; a score of 2 represented slight clearance, with 26–50% of the lesion area cleared; a score of 3 denoted moderate to good clearance, reflecting a 51–75% reduction in the lesion area; and a score of 4 indicated excellent clearance, with 76–100% of the lesion area cleared.
At the conclusion of the treatment, patients were also asked to provide a subjective evaluation of the results with one of the following options: unsatisfied, moderately satisfied, satisfied, and very satisfied.

3. Results

Almost all patients exhibited overall improvements following the treatment protocol (Figure 1, Figure 2, Figure 3, Figure 4, Figure 5, Figure 6 and Figure 7).
The majority of lesions were successfully removed, with the exception of six cases involving striae rubrae and eight cases involving keloids (Figure 2 and Figure 3). Although complete elimination of the lesions was not achieved in these cases, the removal of the vascular component was observed in almost all instances.
Similarly, six cases of acne scars, two cases of port-wine stains (PWSs), and two cases of traumatic scars did not achieve complete clearance (Figure 4 and Figure 5). Notably, there was an improvement and a reduction in vascularization, as evidenced by multispectral analysis.
A total of 50 patients (70.4%) demonstrated excellent clearance, corresponding to a 76–100% reduction in lesion area. A reduction in lesion area between 51 and 75% was observed in 12 patients (16.9%). Seven patients (9.9%) exhibited slight clearance, indicating a 26–50% reduction. Only two patients (2.8%) demonstrated minimal or no improvement in their lesions (Table 2). No recurrences were observed after one year in patients who achieved excellent clearance.
At the conclusion of the treatment, patients were invited to provide a subjective evaluation of the results. A total of 50 patients (70.4%) were very satisfied, 15 patients (21.1%) were satisfied, 4 patients (5.6%) were moderately satisfied with the results, and 2 patients (2.8%) were unsatisfied (Table 3).
These high satisfaction rates highlight the necessity of meticulous patient selection and the establishment of realistic expectations prior to treatment.
The lower satisfaction ratings observed in some patients may be attributed to a lack of comprehensive understanding of the achievable results or discomfort with the postoperative purpura.
The only adverse effect observed was the anticipated post-operative purpura, which was accompanied by mild burning sensations and swelling in the treated areas. This purpura typically resolved within 12 to 14 days post-treatment. In rare instances, purpura persisted for up to 25 days.
No severe adverse effects, such as blistering, scarring, or significant pigmentary changes, were reported throughout the course of the study.

4. Discussion

The flash-lamp pulsed-dye laser (FPDL) is widely recognized for its efficacy in treating vascular lesions and dermatological disorders with vessel involvement [17,18,19]. This study underscores the important role of FPDL in cosmetic medicine, having successfully treated patients with primarily aesthetic concerns. This study employed laser settings optimized for vascular targeting, often inducing purpura, which has been shown to enhance efficacy [20,21]. For patients unable to tolerate purpura, comparable outcomes can be achieved through multiple sessions with lower fluence using non-purpuragenic parameters [5,6].
FPDL’s exceptional selectivity for blood vessels establishes it as a reliable therapeutic tool for conditions such as facial telangiectasias and rosacea [22,23]. It remains the preferred method in the management of port-wine stains (PWSs), especially when initiated before one year of age and for lesions smaller than 20 cm [24,25,26].
Recent studies highlight FPDL’s role in modulating scarring by reducing fibroblast activity, promoting apoptosis, and enhancing MMP expression, which supports its use in treating keloids and post-traumatic scars [10,11,27]. Moreover, its ability to improve wound healing reduces the risk of abnormal scarring [13,28].
Keloids with a lower vascular component are less responsive to dye laser treatment [29,30]. In these cases, an ablative CO2 laser is necessary to vaporize the fibrotic component of the lesion [31,32]. Careful patient selection is critical, as better outcomes are typically achieved in areas with minimal tension, such as auricular keloids [33,34].
The dye laser has also proven to be a safe and effective treatment for scars and vascular lesions involving the oral mucosa [35,36,37]. In this study, we achieved excellent results by treating a post-traumatic scar on the inner side of a patient’s left cheek (Figure 7). The presence of scar tissue on the mucosal cheek surface caused eating-related discomfort. Treating both the skin and mucosal surfaces was essential for achieving aesthetic improvement and restoring functionality.
The treatment of striae rubrae with FPDL, through the modulation of collagen synthesis and enhancement of elastin production, has been particularly effective on newer or recently occurred striae with a substantial vascular component [12,38].
In most cosmetic applications, a fluence of 6 to 7 J/cm2 with a 12 mm spot size is generally sufficient [39,40]. However, for the treatment of keloids or certain cases of striae rubrae, an increase in fluence is necessary [41,42].
Our experience has shown that higher efficacy can be achieved in such cases by reducing the spot size to 7 mm and increasing the fluence to between 8 and 10 J/cm2. Additionally, increasing the percentage of pulse overlap for these lesions is crucial (Table 1). While this may result in a more pronounced post-treatment purpuric reaction, it ultimately leads to improved treatment outcomes [43,44]. When employing higher fluences and greater pulse overlap, it is essential to provide meticulous post-treatment care and closely monitor the patient’s progress over time [45,46].
Furthermore, the efficacy of dye laser treatment for erythematous acne scars has been corroborated by our study, aligning with findings previously reported in the literature [47,48,49].
The efficacy of combining FPDL and fractional CO2 laser for improving outcomes in lesions such as striae rubrae and scars has been well-demonstrated [50,51].
Several studies have reported simultaneous use of both lasers in the same session [52,53,54,55]. An alternative approach could be to initially use FPDL as monotherapy until improvement in the lesion is observed. If no further improvements are obtained, fractional CO2 could be employed in cases where FPDL alone has not yielded the desired outcome.
Our refined treatment protocol (Table 1), defined by the use of progressively escalating fluences and tailored pulse overlaps specific to each lesion, has proven highly effective in clinical practice. Additionally, we propose the optimal interval between treatment sessions, as detailed in Table 1, based on our clinical experience. When combined with meticulous patient selection, this approach has consistently delivered exceptional outcomes and high levels of patient satisfaction.

5. Conclusions

The effectiveness of FPDL in this study reinforces its pivotal role in cosmetic medicine. The extreme selectivity for hemoglobin makes FPDL a safe and effective treatment option. To achieve the best possible results, it is crucial to ensure that patients have realistic goals and are informed of all the possible side effects. It is also essential to educate patients about the correct post-treatment care, which is an important part of the treatment process. In the field of aesthetic treatments, especially in laser therapy, careful patient selection is essential to ensure that the expected outcomes align with their expectations.

Author Contributions

Conceptualization, validation, writing—review and editing: A.C., S.A. and S.P.N.; methodology, investigation, data curation: A.C., S.A., G.C. and S.P.N.; writing—original draft preparation: A.C. and S.A.; visualization, supervision: S.P.N., G.C., C.L., E.Z., L.B., M.S., C.M. and S.M. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

The study was conducted in accordance with the Declaration of Helsinki, and approved by the the Local Ethical Committee of Calabria Region (protocol code 374; 17 December 2019).

Informed Consent Statement

Written informed consent has been obtained from the patients to publish this paper.

Data Availability Statement

The data supporting the findings of this study are available within the article.

Conflicts of Interest

The authors declare no conflicts of interest.

References

  1. Giovanni, C.; Marina, P.B.; Tiziano, Z. A Retrospective 10 Years- Experience Overview of Dye Laser Treatments for Vascular Pathologies. Skin Res. Technol. 2023, 29, e13427. [Google Scholar] [CrossRef] [PubMed]
  2. Nisticò, S.; Campolmi, P.; Moretti, S.; Del Duca, E.; Bruscino, N.; Conti, R.; Bassi, A.; Cannarozzo, G. Nonconventional Use of Flash-Lamp Pulsed-Dye Laser in Dermatology. BioMed Res. Int. 2016, 2016, 7981640. [Google Scholar] [CrossRef] [PubMed]
  3. Garden, J.M.; Bakus, A.D. Clinical Efficacy of the Pulsed Dye Laser in the Treatment of Vascular Lesions. J. Dermatol. Surg. Oncol. 1993, 19, 321–326. [Google Scholar] [CrossRef]
  4. Shi, M.D.; Yang, K.; Li, S.B.; Zhao, Q.; Huo, R.; Fu, C. Complication Rates and Safety of Pulsed Dye Laser Treatment for Port-Wine Stain: A Systematic Review and Meta-Analysis. Lasers Med. Sci. 2024, 39, 16. [Google Scholar] [CrossRef] [PubMed]
  5. Nouri, K.; Elsaie, M.L.; Vejjabhinanta, V.; Stevens, M.; Patel, S.S.; Caperton, C.; Elgart, G. Comparison of the Effects of Short- and Long-Pulse Durations When Using a 585-Nm Pulsed Dye Laser in the Treatment of New Surgical Scars. Lasers Med. Sci. 2010, 25, 121–126. [Google Scholar] [CrossRef]
  6. Jasim, Z.F.; Woo, W.K.; Handley, J.M. Long-Pulsed (6-Ms) Pulsed Dye Laser Treatment of Rosacea-Associated Telangiectasia Using Subpurpuric Clinical Threshold. Dermatol. Surg. 2004, 30, 37–40. [Google Scholar] [CrossRef] [PubMed]
  7. Zappia, E.; Marigliano, M.; Amato, S.; Bennardo, L.; Nisticò, S.P. Biophotonic Technology: Treating Rosacea Utilizing Fluorescent Light Energy (FLE). J. Plast. Dermatol. 2022, 18, 23–25. [Google Scholar]
  8. Cannarozzo, G.; Sannino, M.; Tamburi, F.; Morini, C.; Nisticò, S.P. Flash-Lamp Pulsed-Dye Laser Treatment of Keloids: Results of an Observational Study. Photomed. Laser Surg. 2015, 33, 274–277. [Google Scholar] [CrossRef] [PubMed]
  9. Amato, S.; Nisticò, S.; Bennardo, L.; Pellacani, G.; Cannarozzo, G. CO2 Laser Frenuloplasty: Advancing Minimally Invasive Techniques for Rapid Healing and Improved Patient Outcomes. Surgeries 2024, 5, 367–376. [Google Scholar] [CrossRef]
  10. De Las Alas, J.M.G.; Siripunvarapon, A.H.; Dofitas, B.L. Pulsed Dye Laser for the Treatment of Keloid and Hypertrophic Scars: A Systematic Review. Expert Rev. Med. Devices 2012, 9, 641–650. [Google Scholar] [CrossRef]
  11. Kuo, Y.R.; Wu, W.S.; Jeng, S.F.; Huang, H.C.; Yang, K.D.; Sacks, J.M.; Wang, F.S. Activation of ERK and P38 Kinase Mediated Keloid Fibroblast Apoptosis after Flashlamp Pulsed-Dye Laser Treatment. Lasers Surg. Med. 2005, 36, 31–37. [Google Scholar] [CrossRef] [PubMed]
  12. McDaniel, D.H.; Ash, K.; Zukowski, M. Treatment of Stretch Marks with the 585-Nm Flashlamp-Pumped Pulsed Dye Laser. Dermatol. Surg. 1996, 22, 332–337. [Google Scholar] [CrossRef]
  13. Davari, P.; Gorouhi, F.; Hashemi, P.; Behnia, F.; Ghassemi, A.; Nasiri-Kashani, M.; Firooz, A. Pulsed Dye Laser Treatment with Different Onset Times for New Surgical Scars: A Single-Blind Randomized Controlled Trial. Lasers Med. Sci. 2012, 27, 1095–1098. [Google Scholar] [CrossRef]
  14. Ouyang, H.W.; Li, G.F.; Lei, Y.; Gold, M.H.; Tan, J. Comparison of the Effectiveness of Pulsed Dye Laser vs Pulsed Dye Laser Combined with Ultrapulse Fractional CO2 Laser in the Treatment of Immature Red Hypertrophic Scars. J. Cosmet. Dermatol. 2018, 17, 54–60. [Google Scholar] [CrossRef]
  15. Zhang, J.; Zhou, S.; Xia, Z.; Peng, Z.; Cheng, X.; Yang, X.; Luo, W.; Yang, R. 595-Nm Pulsed Dye Laser Combined with Fractional CO2 Laser Reduces Hypertrophic Scar through down-Regulating TGFβ1 and PCNA. Lasers Med. Sci. 2021, 36, 1625–1632. [Google Scholar] [CrossRef] [PubMed]
  16. Alster, T.S.; McMeekin, T.O.; York, N. Improvement of Facial Acne Scars by the 585 Nm Flashlamp-Pumped Pulsed Dye Laser. J. Am. Acad. Dermatol. 1996, 35, 79–87. [Google Scholar] [CrossRef]
  17. Landthaler, M.; Ulrich, H.; Hohenleutner, S.; Wimmershoff, M.; Hohenleutner, U. Role of Laser Therapy in Dermatology—Clinical Aspects. Dermatology 2004, 208, 129–134. [Google Scholar] [CrossRef] [PubMed]
  18. Erceg, A.; De Jong, E.M.J.G.; Van De Kerkhof, P.C.M.; Seyger, M.M.B. The Efficacy of Pulsed Dye Laser Treatment for Inflammatory Skin Diseases: A Systematic Review. J. Am. Acad. Dermatol. 2013, 69, 609–615.e8. [Google Scholar] [CrossRef] [PubMed]
  19. Sheehan-Dare, R.A.; Cotterill, J.A. Lasers in Dermatology. Br. J. Dermatol. 1993, 129, 1–8. [Google Scholar] [CrossRef]
  20. Tan, S.R.; Tope, W.D. Pulsed Dye Laser Treatment of Rosacea Improves Erythema, Symptomatology, and Quality of Life. J. Am. Acad. Dermatol. 2004, 51, 592–599. [Google Scholar] [CrossRef]
  21. Alam, M.; Dover, J.S.; Arndt, K.A.; Goldman, M.P. Treatment of Facial Telangiectasia with Variable-Pulse High-Fluence Pulsed-Dye Laser: Comparison of Efficacy with Fluences Immediately above and below the Purpura Threshold. Dermatol. Surg. 2003, 29, 681–685. [Google Scholar] [CrossRef]
  22. Tan, S.T.; Bialostocki, A.; Armstrong, J.R. Pulsed Dye Laser Therapy for Rosacea. Br. J. Plast. Surg. 2004, 57, 303–310. [Google Scholar] [CrossRef]
  23. Ruiz-Esparza, J.; Goldman, M.P.; Fitzpatrick, R.E.; Lowe, N.J.; Behr, K.L. Flash Lamp-Pumped Dye Laser Treatment of Telangiectasia. J. Dermatol. Surg. Oncol. 1993, 19, 1000–1003. [Google Scholar] [CrossRef]
  24. Nguyen, C.M.; Yohn, J.J.; Huff, C.; Weston, W.L.; Morelli, J.G. Facial Port Wine Stains in Childhood: Prediction of the Rate of Improvement as a Function of the Age of the Patient, Size and Location of the Port Wine Stain and the Number of Treatments with the Pulsed Dye (585 Nm) Laser. Br. J. Dermatol. 1998, 138, 821–825. [Google Scholar] [CrossRef] [PubMed]
  25. Ortiz, A.E.; Nelson, J.S. Port-Wine Stain Laser Treatments and Novel Approaches. Facial Plast. Surg. 2012, 28, 611–620. [Google Scholar] [CrossRef] [PubMed]
  26. Katugampola, G.A.; Lanigan, S.W. Five Years’ Experience of Treating Port Wine Stains with the Flashlamp-pumped Pulsed Dye Laser. Br. J. Dermatol. 1997, 137, 750–754. [Google Scholar] [CrossRef]
  27. Kauvar, A.N.B.; Kubicki, S.L.; Suggs, A.K.; Friedman, P.M. Laser Therapy of Traumatic and Surgical Scars and an Algorithm for Their Treatment. Lasers Surg. Med. 2020, 52, 125–136. [Google Scholar] [CrossRef]
  28. Nouri, K.; Jimenez, G.P.; Harrison-Balestra, C.; Elgart, G.W.; Chan, H. 585-Nm Pulsed Dye Laser in the Treatment of Surgical Scars Starting on the Suture Removal Day. Dermatol. Surg. 2003, 29, 65–73. [Google Scholar] [CrossRef] [PubMed]
  29. Madan, V.; Stephanides, S.; Rai, S.; August, P.J.; Ferguson, J.E. Treatment of Refractory Keloids with Pulsed Dye Laser Alone and with Rotational Pulsed Dye Laser and Intralesional Corticosteroids: A Retrospective Case Series. Laser Ther. 2011, 20, 279–286. [Google Scholar] [CrossRef]
  30. Durani, P.; Bayat, A. Levels of Evidence for the Treatment of Keloid Disease. J. Plast. Reconstr. Aesthetic Surg. 2008, 61, 4–17. [Google Scholar] [CrossRef] [PubMed]
  31. Garg, G.; Sao, P.; Khopkar, U. Effect of Carbon Dioxide Laser Ablation Followed by Intralesional Steroids on Keloids. J. Cutan. Aesthet. Surg. 2011, 4, 2. [Google Scholar] [CrossRef] [PubMed]
  32. Scrimali, L.; Lomeo, G.; Tamburino, S.; Catalani, A.; Perrotta, R. Laser CO2 versus Radiotherapy in Treatment of Keloid Scars. J. Cosmet. Laser Ther. 2012, 14, 94–97. [Google Scholar] [CrossRef]
  33. Amato, S.; Nisticò, S.P.; Pellacani, G.; Guida, S.; Rossi, A.; Longo, C.; Berardesca, E.; Cannarozzo, G. Sequential and Combined Efficacious Management of Auricular Keloid: A Novel Treatment Protocol Employing Ablative CO2 and Dye Laser Therapy—An Advanced. Cosmetics 2023, 10, 126. [Google Scholar] [CrossRef]
  34. Morosolli, A.R.C.; De Oliveira Moura Cardoso, G.; Murilo-Santos, L.; Niccoli-Filho, W. Surgical Treatment of Earlobe Keloid with CO2 Laser Radiation: Case Report and Clinical Standpoints. J. Cosmet. Laser Ther. 2008, 10, 226–230. [Google Scholar] [CrossRef]
  35. Wang, L.C.; Krunic, A.L.; Medenica, M.M.; Soltani, K.; Busbey, S. Treatment of Hemorrhagic Lymphatic Malformation of the Tongue with a Pulsed-Dye Laser. J. Am. Acad. Dermatol. 2005, 52, 1088–1090. [Google Scholar] [CrossRef] [PubMed]
  36. Cheung, E.J.; Chuang, G.S.; Grassi, A.M. Cutaneous and Mucosal Manifestations of Hereditary Hemorrhagic Telangiectasia Treated with Pulsed Dye Laser. Dermatol. Surg. 2015, 41, 1186–1188. [Google Scholar] [CrossRef]
  37. Frigerio, A.; Tan, O.T. Laser Applications for Benign Oral Lesions. Lasers Surg. Med. 2015, 47, 643–650. [Google Scholar] [CrossRef] [PubMed]
  38. Jimé Nez, G.P.; Flores, F.; Berman, B.; Gunja-Smith, Z. Treatment of Striae Rubra and Striae Alba With the 585-Nm Pulsed-Dye Laser. Dermatol. Surg. 2003, 29, 362–365. [Google Scholar]
  39. Liu, A.; Moy, R.L.; Ross, E.V.; Hamzavi, I.; Ozog, D.M. Pulsed Dye Laser and Pulsed Dye Laser–Mediated Photodynamic Therapy in the Treatment of Dermatologic Disorders. Dermatol. Surg. 2012, 38, 351–366. [Google Scholar] [CrossRef] [PubMed]
  40. DeFatta, R.J.; Krishna, S.; Williams, E.F. Pulsed-Dye Laser for Treating Ecchymoses After Facial Cosmetic Procedures. Arch. Facial Plast. Surg. 2009, 11, 99–103. [Google Scholar] [CrossRef]
  41. Al-Mohamady, A.E.S.A.E.H.; Ibrahim, S.M.A.; Muhammad, M.M. Pulsed Dye Laser versus Long-Pulsed Nd:YAG Laser in the Treatment of Hypertrophic Scars and Keloid: A Comparative Randomized Split-Scar Trial. J. Cosmet. Laser Ther. 2016, 18, 208–212. [Google Scholar] [CrossRef] [PubMed]
  42. Yang, Q.; Ma, Y.; Zhu, R.; Huang, G.; Guan, M.; Avram, M.M.; Lu, Z. The Effect of Flashlamp Pulsed Dye Laser on the Expression of Connective Tissue Growth Factor in Keloids. Lasers Surg. Med. 2012, 44, 377–383. [Google Scholar] [CrossRef]
  43. Tanghetti, E.; Sherr, E.A.; Sierra, R.; Mirkov, M. The Effects of Pulse Dye Laser Double-pass Treatment Intervals on Depth of Vessel Coagulation. Wiley Online Libr. 2006, 38, 16–21. [Google Scholar] [CrossRef] [PubMed]
  44. Channual, J.; Choi, B.; Osann, K.; Pattanachinda, D.; Lotfi, J.; Kelly, K.M. Vascular Effects of Photodynamic and Pulsed Dye Laser Therapy Protocols. Lasers Surg. Med. 2008, 40, 644–650. [Google Scholar] [CrossRef] [PubMed]
  45. Haedersdal, M.; Gniadecka, M.; Efsen, J.; Bech-Thomsen, N.; Keiding, J.; Christian Wulf, H. Side Effects from the Pulsed Dye Laser: The Importance of Skin Pigmentation and Skin Redness. Acta Derm.-Venereol. 1998, 78, 445. [Google Scholar] [CrossRef] [PubMed]
  46. Levine, V.J.; Geronemus, R.G. Adverse Effects Associated with the 577-and 585-Nanometer Pulsed Dye Laser in the Treatment of Cutaneous Vascular Lesions: A Study of 500 Patients. J. Am. Acad. Dermatol. 1995, 32, 613–617. [Google Scholar] [CrossRef]
  47. Seaton, E.D.; Charakida, A.; Mouser, P.E.; Grace, I.; Clement, R.M.; Chu, A.C. Pulsed-Dye Laser Treatment for Inflammatory Acne Vulgaris: Randomised Controlled Trial. Lancet 2003, 362, 1347–1352. [Google Scholar] [CrossRef] [PubMed]
  48. Patel, N.; Clement, M. Selective Nonablative Treatment of Acne Scarring with 585 Nm Flashlamp Pulsed Dye Laser. Dermatol. Surg. 2002, 28, 942–945. [Google Scholar] [PubMed]
  49. Orringer, J.S.; Kang, S.; Hamilton, T.; Schumacher, W.; Cho, S.; Hammerberg, C.; Fisher, G.J.; Karimipour, D.J.; Johnson, T.M.; Voorhees, J.J. Treatment of Acne Vulgaris with a Pulsed Dye Laser: A Randomized Controlled Trial. Jama 2004, 291, 2834–2839. [Google Scholar] [CrossRef]
  50. Martin, M.S.; Collawn, S.S. Combination Treatment of CO2 Fractional Laser, Pulsed Dye Laser, and Triamcinolone Acetonide Injection for Refractory Keloid Scars on the Upper Back. J. Cosmet. Laser Ther. 2013, 15, 166–170. [Google Scholar] [CrossRef] [PubMed]
  51. Cooper, L.E.; Nuutila, K.; Kemp Bohan, P.M.; Diaz, V.; Batchinsky, M.; Carlsson, A.H.; Cancio, L.C.; Chan, R.K. Analysis of the Utility of CO2 and Pulse-Dye Lasers Together and Separately in the Treatment of Hypertrophic Burn Scars. Ann. Plast. Surg. 2022, 89, 166–172. [Google Scholar] [CrossRef] [PubMed]
  52. Kivi, M.K.; Jafarzadeh, A.; Hosseini-Baharanchi, F.S.; Salehi, S.; Goodarzi, A. The Efficacy, Satisfaction, and Safety of Carbon Dioxide (CO2) Fractional Laser in Combination with Pulsed Dye Laser (PDL) versus Each One Alone in the Treatment of Hypertrophic Burn Scars: A Single-Blinded Randomized Controlled Trial. Lasers Med. Sci. 2024, 39, 69. [Google Scholar] [CrossRef]
  53. Chen, H.Y.; Lei, Y.; OuYang, H.W.; Gold, M.H.; Tan, J. Experimental Comparative Study of the Effect of Fractional CO2 Laser Combined with Pulsed Dye Laser versus Each Laser Alone on the Treatment of Hypertrophic Scar of Rabbit Ears. J. Cosmet. Dermatol. 2022, 21, 979–990. [Google Scholar] [CrossRef] [PubMed]
  54. Matuszczak, E.; Weremijewicz, A.; Koper-Lenkiewicz, O.M.; Kamińska, J.; Hermanowicz, A.; Dębek, W.; Komarowska, M.; Tylicka, M. Effects of Combined Pulsed Dye Laser and Fractional CO2 Laser Treatment of Burn Scars and Correlation with Plasma Levels of Collagen Type I, MMP-2 and TIMP-1. Burns 2021, 47, 1342–1351. [Google Scholar] [CrossRef] [PubMed]
  55. Elrod, J.; Schiestl, C.; Neuhaus, D.; Mohr, C.; Neuhaus, K. Patient- And Physician-Reported Outcome of Combined Fractional CO2 and Pulse Dye Laser Treatment for Hypertrophic Scars in Children. Ann. Plast. Surg. 2020, 85, 237–244. [Google Scholar] [CrossRef] [PubMed]
Cosmetics 11 00227 g001
Figure 1. (a) A young woman affected by rosacea at baseline; (b) Outstanding results observed after two PDL sessions.
Figure 1. (a) A young woman affected by rosacea at baseline; (b) Outstanding results observed after two PDL sessions.
Cosmetics 11 00227 g001
Cosmetics 11 00227 g002
Figure 2. (a) Baseline appearance of a patient with a keloid on the nasolabial fold; (b) Typical post-PDL purpura; (c) Impressive improvement following four sessions of PDL therapy.
Figure 2. (a) Baseline appearance of a patient with a keloid on the nasolabial fold; (b) Typical post-PDL purpura; (c) Impressive improvement following four sessions of PDL therapy.
Cosmetics 11 00227 g002
Cosmetics 11 00227 g003
Figure 3. (a) Striae rubrae in a female patient prior to treatment; (b) Typical post-PDL purpura; (c) Marked clinical improvement with four PDL sessions.
Figure 3. (a) Striae rubrae in a female patient prior to treatment; (b) Typical post-PDL purpura; (c) Marked clinical improvement with four PDL sessions.
Cosmetics 11 00227 g003
Cosmetics 11 00227 g004
Figure 4. (a) A PWS on the nasolabial fold at baseline; (b) Purpura reaction post-PDL session; (c) Significant improvement observed 8 weeks following the last PDL session.
Figure 4. (a) A PWS on the nasolabial fold at baseline; (b) Purpura reaction post-PDL session; (c) Significant improvement observed 8 weeks following the last PDL session.
Cosmetics 11 00227 g004
Cosmetics 11 00227 g005
Figure 5. (a) A traumatic scar located in the pre-jowl area; (b) Immediate purpura following PDL therapy; (c) Disappearance of the lesion after three sessions of PDL therapy; (d) Treatment included the oral mucosa due to the presence of scar tissue in that area; (e) Typical post-PDL purpura.
Figure 5. (a) A traumatic scar located in the pre-jowl area; (b) Immediate purpura following PDL therapy; (c) Disappearance of the lesion after three sessions of PDL therapy; (d) Treatment included the oral mucosa due to the presence of scar tissue in that area; (e) Typical post-PDL purpura.
Cosmetics 11 00227 g005
Cosmetics 11 00227 g006
Figure 6. (a) Erythematous acne scars on the right cheek of a young patient before treatment; (b) Post-PDL treatment purpura; (c) Substantial reduction of scars after three PDL sessions.
Figure 6. (a) Erythematous acne scars on the right cheek of a young patient before treatment; (b) Post-PDL treatment purpura; (c) Substantial reduction of scars after three PDL sessions.
Cosmetics 11 00227 g006
Cosmetics 11 00227 g007
Figure 7. (a) Subpalpebral telangiectasias at baseline; (b) Significant improvement following a single PDL session.
Figure 7. (a) Subpalpebral telangiectasias at baseline; (b) Significant improvement following a single PDL session.
Cosmetics 11 00227 g007
Table 1. Treatment protocol for different lesion types.
Table 1. Treatment protocol for different lesion types.
Type of LesionsSessions PlanSettings
Facial telangiectasia1–2 Tx every 40 d
Port-wine stain (PWS)6–8 Tx every 75–120 dWavelength 595 nm
Energy 6–7 J/cm2
Spot size 12 mm
Pulse 0.5–1 ms
Overlap 20–30%
Striae rubrae4–6 Tx every 60–100 dWavelength 595 nm
Energy 6–10 J/cm2
Spot size 7 ÷ 12 mm
Pulse 0.5
Overlap 20–40%
Erythematous acne scars3–4 Tx every 40–60 dWavelength 595 nm
Energy 6–7 J/cm2
Spot size 12 mm
Pulse 0.5–1 ms
Overlap 10–20%
Facial traumatic scars3–6 Tx every 40–60 dWavelength 595 nm
Energy 6–10 J/cm2
Spot size 7 ÷ 12 mm
Pulse 0.5–1 ms
Overlap 10–30%
Keloids4–6 Tx every 60–120 dWavelength 595 nm
Energy 6–10 J/cm2
Spot size 7 ÷ 12 mm
Pulse 0.5
Overlap 30–50%
Table 2. Global improvements.
Table 2. Global improvements.
Score 1Score 2Score 3Score 4
Minimal or no improvement
2 (2.8%)		Slight clearance
7 (9.9%)		Moderate-good clearance
12 (16.9%)		Excellent clearance
50 (70.4%)
Table 3. Subjective evaluations of the results.
Table 3. Subjective evaluations of the results.
UnsatisfiedModerately SatisfiedSatisfiedVery Satisfied
2 (2.8%)4 (5.6%)15 (21.1%)50 (70.4%)
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.

Share and Cite

MDPI and ACS Style

Clementi, A.; Cannarozzo, G.; Amato, S.; Zappia, E.; Bennardo, L.; Michelini, S.; Morini, C.; Sannino, M.; Longo, C.; Nistico, S.P. Dye Laser Applications in Cosmetic Dermatology: Efficacy and Safety in Treating Vascular Lesions and Scars. Cosmetics 2024, 11, 227. https://doi.org/10.3390/cosmetics11060227

AMA Style

Clementi A, Cannarozzo G, Amato S, Zappia E, Bennardo L, Michelini S, Morini C, Sannino M, Longo C, Nistico SP. Dye Laser Applications in Cosmetic Dermatology: Efficacy and Safety in Treating Vascular Lesions and Scars. Cosmetics. 2024; 11(6):227. https://doi.org/10.3390/cosmetics11060227

Chicago/Turabian Style

Clementi, Alessandro, Giovanni Cannarozzo, Simone Amato, Elena Zappia, Luigi Bennardo, Simone Michelini, Cristiano Morini, Mario Sannino, Caterina Longo, and Steven Paul Nistico. 2024. "Dye Laser Applications in Cosmetic Dermatology: Efficacy and Safety in Treating Vascular Lesions and Scars" Cosmetics 11, no. 6: 227. https://doi.org/10.3390/cosmetics11060227

APA Style

Clementi, A., Cannarozzo, G., Amato, S., Zappia, E., Bennardo, L., Michelini, S., Morini, C., Sannino, M., Longo, C., & Nistico, S. P. (2024). Dye Laser Applications in Cosmetic Dermatology: Efficacy and Safety in Treating Vascular Lesions and Scars. Cosmetics, 11(6), 227. https://doi.org/10.3390/cosmetics11060227

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
