A Scaled Monocular 3D Reconstruction Based on Structure from Motion and Multi-View Stereo

Three-dimensional digital modeling at actual scales is essential for digitally preserving cultural relics. While 3D reconstruction using a monocular camera offers a cost-effective solution, the lack of scale information in the resulting models limits their suitability for geometric measurements. Objects with monotonous textures, such as batteries, pose additional challenges due to insufficient feature points, increasing positional uncertainty. This article proposes a method incorporating point and line features to address the scale ambiguity in multi-view 3D reconstruction using monocular cameras. By pre-measuring the lengths of multiple sets of real line segments, building a lookup table, and associating the line features in different images, the table was input into the improved reconstruction algorithm to further optimize the scale information. Experimental results on real datasets showed that the proposed method outperformed the COLMAP method by 70.82% in reconstruction accuracy, with a scale recovery reaching millimeter-level accuracy. This method is highly generalizable, cost-effective, and supports lightweight computation, making it suitable for real-time operation on a CPU.
