Anti-Obesity Activity in 3T3-L1 Cells of Cornus officinalis Fruits Harvested at Different Times

Abstract

Obesity, a metabolic disease linked to several other diseases, is emerging as a global problem. We determined the harvest time that maximized the anti-obesity effect by evaluating the inhibition of lipid accumulation in 3T3-L1 cells treated with fruits of Cornus officinalis. FS1 (pericarp + seeds, harvested 15 September) showed excellent anti-obesity activity (Oil Red O; 26.12 ± 1.37% vs. MDI) and inhibited the expression of PPAR-γ (0.05 ± 0.01 ford vs. MDI), C/EBPα (0.03 ± 0.02 ford vs. MDI), and C/EBPβ (0.33 ± 0.07 ford vs. MDI) at 200 μg/mL. The antioxidant activity of FS1 was also the most effective. In addition, FS1 contained higher levels of active ingredients than samples harvested in other periods. Especially, content of loganin, verbenalin, and sweroside was high. In terms of anti-obesity activity and functional components, immature COF (FS1) was the best, and these results indicate that it is necessary to adjust the harvest time, when used as an anti-obesity agent.

1. Introduction

The fruit of Cornus officinalis (COF) is traditionally used for the prevention and treatment of various diseases in East Asian countries, such as Korea, Japan, and China [1]. It is harvested in autumn, and the seeds are removed and dried [2]. Components of COF include malic acid, tartaric acid, gallic acid, ursolic acid [3], and iridoid glycosides, such as morroniside, loganin, and sweroside [4]. COF extract and active components have immune-enhancing, cardioprotective, antibacterial, anti-hyperglycemic, antiaging, antioxidant, and renal- and neuro-protective effects [5].

The World Health Organization (WHO, Geneva, Switzerland) defines obesity as an excessive amount of adipose tissue in the body. Obesity, which occurs when the number of calories consumed is greater than the number of calories used, is caused by decreased physical activity, genetic factors, and changes in diet. Obesity is a metabolic disease that causes hypertension, cardiovascular disease, and diabetes [6]. Due to overeating and lack of exercise, obesity is increasing worldwide, and it is emerging as a risk factor for personal and social health issues [7].

Adipocyte differentiation, i.e., the differentiation of adipocytes to mature adipocytes, is closely related to obesity because it is involved in fat production and accumulation [8]. Adipogenesis is achieved, in part, by the C/EBP (CCAAT/enhancer binding protein) and PPAR-γ (peroximal proliferator-activated receptor-γ) [9,10]. Hormonal stimulation induces the PPAR-γ and C/EBPα expression by increasing the C/EBPβ expression at the early stage of differentiation and decreases the C/EBPβ expression at the late stage. Adipogenesis is regulated by the expression levels of these factors [11,12]. 3T3-L1 cells have been used to investigate the differentiation of preadipocytes into adipocytes and evaluate adipogenesis.

The anti-obesity activities of COF [13] are limited to the pericarp, and studies on fruits (including seeds) and anti-obesity effects, according to harvest time, are scarce. Therefore, we used 3T3-L1 to analyze lipid accumulation and related protein expression level to assess the effects of COF on adipocyte differentiation, lipid production, and identify the harvest time that maximizes the inhibition of adipocyte differentiation.

2. Materials and Methods

2.1. Sample Preparation

COFs were harvested on the 15th of each month, from September to December, 2020, respectively, in Gurye-Gun, Korea (Figure 1). The pericarp (seeds removed from the fruit) and fruits (with seeds) were freeze-dried and crushed into powder. The samples (pericarp and fruits containing seeds, 10 g) were extracted three times with 100 mL of 70% ethanolic solution for 1 h by ultrasonication. After filtration (0.45 µm regenerated cellulose filter, Phenomenex, Torrance, CA, USA), the extract was concentrated under vacuum and freeze-dried (

Table 1. Sample preparation.

	Samples	Harvest Time
F1	Pericarp	15 September
F2		15 October
F3		15 November
F4		15 December
FS1	Pericarp + seeds	15 September
FS2		15 October
FS3		15 November
FS4		15 December

).

2.2. Cell Culture of 3T3-L1 Pre-Adipocytes

The 3T3-L1 adipocytes were purchased from the ATCC (Manassas, VA, USA) and incubated in Dulbecco’s modified Eagle’s medium (DMEM; Gibco, Grand Island, NY, USA) with 10% bovine serum (Gibco), 100 µg/mL streptomycin (Gibco), and 100 units/mL penicillin at 37 °C in a 5% CO₂ incubator.

2.3. Cell Viability of Pre-Adipocytes

Cell viability was measured by methylthiazolyldiphenyl-tetrazolium bromide (MTT) assay. The 3T3-L1 pre-adipocytes were cultured in 48-well plates at 5 × 10⁴ cells/mL for 24 h and treated with COF extracts (50, 100, 200 µg/mL). After 24 h, the media was removed and replaced with 0.5 mg/mL MTT reagent (Sigma-Aldrich, St. Louis, MO, USA) in growth medium, and reacted at 37 °C in a CO₂ incubator for 1 h. The media was removed, and 100 µL of dimethyl sulfoxide was added to elute formazan crystal. The absorbance of samples was measured at 550 nm by using a microplate reader (Synergy H1; Biotek, Winooski, VT, USA).

2.4. Differentiation of Pre-Adipocytes

Differentiation was induced over 2 days in post-confluent cells, using DMEM with 10% FBS (fetal bovine serum, Gibco), streptomycin (100 µg/mL), and penicillin (100 units/mL) containing MDI (1 µM dexamethasone, 500 µM isobutylmethylxanthine, and 10 µg/mL insulin from Sigma-Aldrich). The cultures were replenished with DMEM containing 10% FBS, 100 units/mL penicillin, 100 µg/mL streptomycin, COF extract (50, 100, 200 µg/mL), and 10 µg/mL insulin medium every 2 days. The experiments were performed using adipocytes at 8 days from post-differentiation.

2.5. Oil Red O Staining of Adipocytes

After differentiation induction of adipocytes, the media was removed. The cells were washed with PBS (phosphate-buffered saline). The cells were fixed with 3.7% formalin for 15 min. Next, the cells were washed with distilled water and stained with oil red O solution (Sigma-Aldrich, St. Louis, MO, USA) for 15 min at 25 °C. The oil red O solution was then removed. The cells were washed with distilled water before being photomicrographed. To quantify the eluted reagent, isopropanol was added, and the absorbance of the samples was measured at 520 nm using a microplate reader.

2.6. Western Blot Analysis of Adipocytes

Adipocytes were washed with cold PBS. The cells were lysed in RIPA buffer containing protease and phosphatase inhibitor cocktail (GenDEPOT, Katy, TX, USA). After centrifugation at 12,000 rpm, the supernatant was obtained. The protein concentration in the supernatant was quantified by using the bicinchoninic acid protein assay kit (Pierce Biotechnology Inc., Rockford, IL, USA). The protein samples were separated in SDS-polyacrylamide gels and transferred to NC (nitrocellulose) membranes (Bio-Rad, Hercules, CA, USA). The NC membranes were blocked in Tris-buffered saline Tween 20 (TBST, 20 mmol/L Tris-HCl, 150 mmol/L NaCl, 0.1% Tween 20, pH 7.5) containing 2% bovine serum albumin (GenDEPOT, Katy, TX, USA). The primary antibody (Cell Signaling Technology, Beverly, MA) was added for incubation for 12 h at 4 °C, followed by the secondary antibody (Cell Signaling Technology, Danvers, MA, USA) for 30 min. The NC membranes were washed with TBST. The membranes were reacted with enhanced chemiluminescence solution (Bio-Rad, Hercules, CA, USA); then, the visualized data were taken using a ChemiDoc Imaging System (Bio-Rad, Hercules, CA, USA). Quantitative analysis was performed using ImageJ (NIH, Bethesda, MD, USA).

2.7. Antioxidant Activity Assays

2.7.1. DPPH Free Radical Scavenging Assay

A DPPH (2,2-diphenyl-picrylhydrazyl, Sigma-Aldrich) radical scavenging assay of COF was performed using the method of Tepe et al. [14]. Two-hundred microliters of 0.2 mM DPPH solution in ethanol were added to 50 μL of COF extract and reacted in darkness for 30 min; the absorbance of samples at 520 nm was measured using a microplate reader. Trolox standard (Sigma-Aldrich, St. Louis, MO, USA) was used as the positive control.

2.7.2. ABTS Radical Scavenging Assay

An ABTS (2,2′-azino-bis-3-ethylbenzthiazoline-6-sulphonic acid, Sigma-Aldrich) radical scavenging assay of COF was performed by modifying the method of Re et al. [15]. One-hundred-ninety microliters of ABTS solution were added to 10 μL of COF extract and reacted in darkness for 30 min, and the absorbance of samples at 735 nm was measured using a microplate reader. Ascorbic acid standard (Sigma-Aldrich, St. Louis, MO, USA) was used as the positive control.

2.7.3. Determination of TP Content

Total phenolic content was measured by modifying the method of Dewanto et al. [16]. After adding 2% Na₂CO₃ (Sigma-Aldrich, St. Louis, MO, USA) solution to COF extract, 1N Folin-Ciocalteu reagent (Sigma-Aldrich, St. Louis, MO, USA) was added. After the samples had been allowed to stand for 30 min, the absorbance of samples was measured at 750 nm using a microplate reader. Gallic acid (Sigma-Aldrich, St. Louis, MO, USA) was used as a standard.

2.7.4. FRAP Assay

Ferric reducing antioxidant power (FRAP) was measured by modifying the Mau et al. method [17]. A total of 0.2 M sodium phoshate buffer (pH 6.6) and potassium ferricyanide (Sigma-Aldrich) were mixed and reacted with COF extract, followed by mixing with trichloroacetic acid (Sigma-Aldrich, St. Louis, MO, USA). After centrifuging for 10 min, the absorbance was measured at 700 nm by mixing the supernatant, distilled water, and ferric chloride (Sigma-Aldrich, St. Louis, MO, USA). Trolox (Sigma-Aldrich, St. Louis, MO, USA) was used as a standard.

2.8. HPLC Analysis of Major Active Components

Quantitative analyses were performed on an Agilent 1200 series HPLC (Agilent Technologies Inc., Santa Clara, CA, USA) by modifying the method of Liu et al. [4]. Chromatography was carried out at 35 °C on an C18 column (YMC-Triart; 250 × 4.6 mm, S-5 µm, 12 nm, YMC, Kyoto, Japan). The mobile phase consisted of 0.2% (v/v) acetic acid in water (A) and 0.2% (v/v) acetic acid in acetonitrile (B) with gradient elution: 0–4 min, isocratic 1% B; 4–18 min, 1–12% B; 18–22 min, 12–20% B; 22–35 min, 20–30% B, 35–40 min, and 30–100% B. The gradient elution re-equilibration time was 10 min. The flow rate and UV detector were set at 1.2 mL/min and 254 nm, respectively. The injection volume of samples was 10 µL. The standards of active compounds were dissolved in methanol to 10 mg/mL and diluted. Loganin, morroniside, verbenalin, sweroside, 7-O-methyl morroniside, loganetin, and sarracenin analytical standards were purchased from ChemFaces (Wuhan, China). Gallic acid and cornuside analytical standards were purchased from Sigma-Aldrich (

Table 2. Calibration equations and correlation coefficients.

Compound	Linear Range (μg/mL)	Calibration Equation	Correlation Coefficient (r2)
Gallic acid	2.5–100	y = 10.5884x + 7.5749	R2 = 0.9998
Morroniside	40–200	y = 4.1525x + 11.5427	R2 = 0.9998
Loganin	2.5–100	y = 4.4595x − 0.3537	R2 = 1.0000
Verbenalin	10–400	y = 4.6197x − 18.8144	R2 = 0.9996
Sweroside	2.5–200	y = 7.8192x − 6.9401	R2 = 0.9997
Cornuside	2.5–100	y = 5.7834x − 0.4795	R2 = 1.0000

).

2.9. Statistical Analysis

The experiments were repeated three or four times and expressed as mean and standard deviation values. The significant difference between non-treated (VC, MDI) and treated (samples) cells was determined using the two-sample Student’s t-test. The significant difference among concentrations of same sample in anti-obesity activity and samples in antioxidant properties and active components was determined using the ANOVA by SPSS ver. 22 (SPSS Institute, IL, USA), with a significance level p < 0.05 by DMRT.

3. Results

3.1. Effect of COF on Cell Viability

The effect of COF extract on 3T3-L1 preadipocyte viability (50, 100, and 200 μg/mL) was evaluated by MTT assay. The survival rate was >80% (Figure 2); therefore, toxicity was insignificant.

3.2. Effect of COF on 3T3-L1 Cell Differentiation

ORO staining was performed to investigate the effect of COF on the adipocyte differentiation of 3T3-L1 preadipocytes (Figure 3). The pericarp (F) and pericarp + seeds (FS) decreased the differentiation rate of adipocytes in a concentration-dependent manner (MDI (methylisobutylxanthine, dexamethasone, and insulin): 100% vs. F4 50 μg/mL: 103.69%~FS1 200 μg/mL: 26.12%). In terms of parts, the effect was greater in pericarp + seeds (FS) than pericarp (F); in terms of the harvest period, the effect was greater in the first period. All samples, except F4, had a concentration-dependent anti-obesity effect (p < 0.05).

3.3. COF Inhibits the Expression of C/EBPα, β, and PPAR-γ

Western blotting was performed to evaluate the expression of proteins related to adipocyte differentiation and lipid accumulation. Protein expression of C/EBPα, β, and PPAR-γ was compared between the first and third periods using ORO staining (Figure 3). The expression of PPAR-γ (200 μg/mL) during the first and third periods was 0.14- and 0.88-fold higher vs. MDI in Fs and 0.05- and 0.09-fold higher vs. MDI in FSs, respectively. C/EBPα (200 μg/mL) expression was 0.07- and 0.78-fold higher vs. MDI in Fs and 0.03- and 0.11-fold vs. MDI in FSs, respectively. In PPAR-γ and C/EBPα expression levels, F1 and FS1 showed significant differences from MDI at all concentrations (p < 0.05). Finally, C/EBPβ (200 μg/mL) expression was 0.76- and 1.19-fold higher vs. MDI in Fs and 0.33- and 0.66-fold higher vs. MDI in FSs, respectively (Figure 4). Similar to the results of ORO staining, protein expression levels were lower in FSs than Fs, and in the first rather than third period.

3.4. Antioxidant Activity of COF

The DPPH radical scavenging activities (IC₅₀ values) of the extracts were 15.89–219.60 μg/mL, and the ABTS radical scavenging activities were 13.28–151.44 μg/mL. FRAP were 71.67–871.16 mg/g. FS1 and F4 had the highest and lowest activities (p < 0.05), respectively. The TPCs of the extracts were 39.37–288.96 mg/g; the TPCs were highest in FS1 and lowest in F4 (p < 0.05) (

Table 3. Antioxidant activities and total phenolic contents of Cornus officinalis fruit extracts.

	DPPH (IC50, μg/mL)	ABTS (IC50, μg/mL)	FRAP (mg TE/g)	TPC (mg GAE/g)
F1	55.93 ± 0.36 d	41.37 ± 0.27 d	539.95 ± 1.57 c	135.84 ± 3.08 d
F2	106.56 ± 0.29 c	81.72 ± 0.57 c	193.92 ± 1.57 f	68.51 ± 1.68 e
F3	130.51 ± 0.81 b	93.48 ± 0.64 b	140.41 ± 0.00 g	69.40 ± 1.33 e
F4	219.60 ± 1.54 a	151.44 ± 2.52 a	71.67 ± 0.20 h	39.37 ± 1.67 f
FS1	15.89 ± 0.03 g	13.28 ± 0.10 g	871.16 ± 2.36 a	288.96 ± 4.23 a
FS2	35.83 ± 0.05 e	31.58 ± 0.09 e	413.42 ± 0.79 d	142.07 ± 3.33 c
FS3	35.24 ± 0.16 e	30.77 ± 0.35 e	401.63 ± 1.36 e	139.18 ± 3.67 cd
FS4	25.54 ± 0.08 f	21.97 ± 0.16 f	549.02 ± 1.57 b	187.84 ± 3.42 b
Trolox	9.35 ± 0.13
Ascorbic acid		7.89 ± 0.08

Different small letters in the same items indicate a significant difference (p < 0.05) among the samples. Samples are listed in Table 1.

).

3.5. Active Components

The levels of all active components were highest in COF extracts (F1 and FS1) harvested in September, and the levels of all components, except morroniside, were higher in FS1 than F1 (p < 0.05). Morroniside showed higher contents of F1 (63.95 mg/g) and FS1 (48.28 mg/g) than other samples (p < 0.05) (

Table 4. Major components of Cornus officinalis fruit extracts.

	Gallic Acid (mg/g)	Morroniside (mg/g)	Loganin (mg/g)	Verbenalin (mg/g)	Sweroside (mg/g)	Cornuside (mg/g)
F1	1.49 ± 0.08 a	63.95 ± 0.49 a	25.85 ± 0.14 c	3.19 ± 0.51 d	2.71 ± 0.14 d	4.07 ± 0.07 b
F2	0.28 ± 0.03 e	25.38 ± 0.62 d	10.09 ± 0.22 f	0.66 ± 0.04 e	0.94 ± 0.10 e	1.62 ± 0.02 d
F3	0.14 ± 0.01 f	23.56 ± 0.76 e	11.79 ± 0.36 f	0.75 ± 0.06 e	0.98 ± 0.06 e	1.61 ± 0.07 d
F4	1.02 ± 0.01 b	31.15 ± 0.95 c	15.42 ± 0.38 e	0.57 ± 0.06 e	1.02 ± 0.10 e	1.85 ± 0.03 d
FS1	1.50 ± 0.07 a	48.28 ± 0.32 b	38.95 ± 0.39 a	37.10 ± 0.80 a	12.52 ± 0.47 a	5.68 ± 0.10 a
FS2	0.82 ± 0.11 c	20.11 ± 1.50 f	20.53 ± 2.53 d	17.55 ± 2.77 c	6.95 ± 1.05 c	2.20 ± 0.28 c
FS3	0.49 ± 0.11 d	20.00 ± 1.51 f	20.44 ± 1.25 d	16.90 ± 0.46 c	6.36 ± 0.38 c	1.82 ± 0.22 d
FS4	1.39 ± 0.06 a	26.76 ± 1.38 d	28.49 ± 1.08 b	27.05 ± 1.16 b	8.82 ± 0.53 b	2.33 ± 0.10 c

Different small letters in the same items indicate a significant difference (p < 0.05) among the samples. Samples are listed in Table 1.

, Figure S1). The loganin, verbenalin, and sweroside contents differed, according to the inclusion of seeds.

4. Discussion

Preadipocytes differentiate into adipocytes via various hormones and transcription factors and produce and accumulate intracellular lipid [18]. Lipid accumulation, as a marker of adipogenesis, was quantified by ORO staining. The first pericarp and pericarp + seed showed the greatest inhibition of lipid accumulation. COF is an immature green fruit; green fruits, such as green apples, contain high levels of active ingredients, such as polyphenols and iridoids, and they have antioxidant [19] and anti-obesity [20] effects. ROS suppresses the reduction of the energy consumption of adipocytes by inducing the dysfunction of the mitochondria by inhibiting the breathing process [21]. Substances with high antioxidant activity (such as N-acetyl cysteine) ameliorate obesity by inhibiting lipid accumulation [22,23]. Regarding antioxidant activity, the effect of unripe green fruit was superior to that of fruit containing seeds, rather than pericarp, which is consistent with the inhibition of lipid accumulation. Loganin and sweroside, the contents of which were high in FS1, modulate fat accumulation by regulating AMPKα, SIRT1, and PPARα [24,25]. Polyphenols inhibit adipocyte differentiation and lipid accumulation by regulating the expression of the transcription factors linked to adipogenesis [26]. The polyphenol and iridoid components of the COF had anti-obesity and -oxidant effects in this study. The sine this study did not measure the anti-obesity effect under the condition of increasing ROS, and the anti-obesity effect of COF is more likely to be the effect of iridoids, rather than antioxidants.

The adipogenesis of preadipocytes is mediated by transcription factors and hormones, including C/EBPα, C/EBPβ, and PPARγ [27]. Adipogenesis is achieved by the sequential expression of transcription factors, and C/EBPβ and C/EBPδ mediate the transcriptional activation of PPARγ and C/EBPα [28]. C/EBPβ is expressed at an early stage of differentiation, and its expression decreases at later stages. By contrast, PPARγ and C/EBPα expression levels increase as differentiation progresses. Regarding the effect of COF on transcription factors, there was little difference in C/EBPβ expression between the control and MDI groups. There was also little difference in the expression level of COF among the groups. C/EBPβ was expressed in the early stage of differentiation, and its expression decreased at later stages. However, FS1 suppressed the expression of C/EBPβ in a concentration-dependent manner. PPARγ and C/EBPα expression by C/EBPβ showed a significant difference between the control and MDI groups. Therefore, FS1 ameliorates obesity because it inhibits the transcription factors related to fat differentiation.

These results indicate that the main functional components and anti-obesity activities can vary greatly, depending on the harvest time of COF. In Korea, immature COF harvested earlier may be more valuable, in terms of functionality, than fruits at the normal harvest time.

5. Conclusions

Immature COF had anti-obesity and -oxidant effects, which were greater in COF containing seeds. The anti-obesity effect was caused by the suppression of C/EBPα, C/EBPβ, and PPARγ expression by various components of immature fruits. Therefore, immature pericarp + seeds of COF have therapeutic potential for obesity. In Korea, the typical harvest time for COF is November. However, in this study, it was found that COF harvested in September contained excellent activity and a large amount of active ingredients. Therefore, there is a need to advance the harvest time of COF; immature COF could be used as a material for anti-obesity agents. In addition, COF generally uses only the pericarp; it is also necessary to consider the use of seeds.
