Article

SpiroTiger and KS Brief Stimulator: Specific Devices for Breathing and Well-Being in Post-COVID-19 Patients

by
Maria Chiara Parisi
1,2,
Donatella Di Corrado
1,*,
Omar Mingrino
1,
Caterina Crescimanno
2,
Federica Longo
1,
Francesco Pegreffi
2 and
Vincenzo Cristian Francavilla
2
1
Department of Sport Sciences, Kore University, 94100 Enna, Italy
2
Department of Medicine and Surgery, Kore University, 94100 Enna, Italy
*
Author to whom correspondence should be addressed.
J. Funct. Morphol. Kinesiol. 2024, 9(4), 203; https://doi.org/10.3390/jfmk9040203
Submission received: 5 October 2024 / Revised: 21 October 2024 / Accepted: 24 October 2024 / Published: 24 October 2024
(This article belongs to the Section Physical Exercise for Health Promotion)
Browse Figures
Versions Notes

Abstract

:
Background. Post-COVID-19 patients may develop impaired lung function, with reduced lung capacities and volumes, respiratory muscle weakness, and physical inactivity. The aim of this study was to determine the effects of a detailed protocol based on breathing training with two specifically designed respiratory devices (SpiroTiger and KS Brief Stimulator) in post-COVID-19 individuals. Methods. Sixteen young volunteers were randomly allocated into two groups: experimental (n = 8) and control (n = 8). The experimental group performed breathing training for 12 min two times a week for 9 months (from August 2023 to May 2024). Spirometric and baropodometric measurements were recorded every 3 months to evaluate the effects of the protocol. Results. Data analysis showed significant improvements in the forced vital capacity, peak expiratory flow indices, and postural parameters in the experimental group. Conclusions. In conclusion, based on the study findings, the specific breathing training protocol developed for post-COVID-19 patients has proven to be effective and significantly impacted the quality of breathing functions and the postural system.

1. Introduction

Coronavirus disease 2019 (COVID-19) is caused by the highly transmissible severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) [1]. Post-COVID-19 patients still feel persistent symptoms such as breathlessness and fatigue, and may develop an impairment of the lung function, with reduced lung capacities and volumes, respiratory muscle weakness, limitations in exercising, and a decreased functional capacity [2]. These persistent symptoms can continue for several months, leading to a condition defined as Long COVID, an often-debilitating illness that occurs in at least 10% of patients with severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) infections [3]. The World Health Organization stated that there are many actions that can be taken during the post-COVID rehabilitation process, including breathing exercises and physical exercise after discharge from the hospital [4]. The COVID-19 pandemic has brought with it a sedentary lifestyle and inactivity among the population. Therefore, working on respiratory and motor re-education is of fundamental importance not only to fight against the complications and consequences of COVID-19 but also to prevent pathologies linked to the incorrect lifestyle acquired mainly during the period of forced quarantine and inactivity due to hospitalizations for respiratory difficulties. It has been demonstrated that there is a correlation between respiratory muscle fatigue and exercise tolerance in patients exhibiting both sedentary and active lifestyles [5]. The forced and reduced physical mobility has led, in fact, many people to perceive greater fatigue, breathlessness, pain, muscular weakness, osteo-articular stiffness, and more generally a deconditioning syndrome that results in respiratory and motor alterations [6]. In this regard, some hospitals have equipped themselves to allow their patients suffering from respiratory complications due to COVID-19 (such as pneumonia) to practice respiratory and motor re-education aimed at alleviating the symptoms of the disease and physical inactivity [4]. Many studies have focused on the strong interdependence of postural control and breathing; more precisely, researchers have found that the breathing muscles are incessantly involved in the control of posture, movement, stability, cranio-cervical regions, and limbs [7,8].
Breathing muscles are involved in the breathing mechanism. The inspiratory respiratory muscles include the diaphragm, external intercostal muscles, pectoralis, serratus anterior, latissimus dorsi, serratus posterior superior, and scalene muscles. The expiratory muscles include the internal intercostal muscles, subcostal muscle, transversus thoracis muscle, anterior and lateral abdominal muscles, and serratus posterior inferior [9]. Decreases in the strength and endurance of the respiratory muscles can affect several functional and quotidian activities. Sedentary behavior is often intertwined with poor posture, which can lead to musculoskeletal imbalances and potentially impact physiological processes, limiting chest expansion and joint range of motion [10].
According to the literature, these respiratory muscles can be strengthened through resistance exercises associated with trunk stabilization exercises, developing better trunk stability and improving functions respiratory [11,12,13]. It has been shown that the most effective method to improve the lung and physical capacities of post-COVID-19 individuals involves specific and structured interventions of re-education [14,15,16,17].
Unfortunately, not many studies have been published on the topic of post-COVID-19 re-education programs. Given the lack of detailed knowledge, the aim of the present investigation was therefore to first determine the effects of a detailed protocol based on breathing training with two specifically designed respiratory devices in post-COVID-19 individuals. We selected SpiroTiger (MVM Italia S.r.l.—20020 Milan, Italy) and KS Brief Stimulator (KS International Group SRL—83013 Avellino, Italy) to train breathing muscles and improve pulmonary function. The second aim was to determine whether positive changes in breathing capacity will benefit posture and well-being, and how these could be used in future interventions aimed at public health and the prevention of possible diseases of the respiratory system. We further hypothesized that the specific properties of the devices could not only provide respiratory muscle training but also achieve an improvement in the total lung function.

2. Results

Sixteen young participants were randomly assigned to the experimental (n = 8) and control (n = 8) groups. The anthropometric characteristics of participants are illustrated in Table 1.
Independent t-tests were conducted to identify a statistically significant difference between the experimental and control groups in the postural index (Table 2).
The experimental group showed greater and significant improvements in the center-of-pressure length between T2 and T3, whereas there was no change in the control group. A paired t-test was conducted to detect within-group differences in the levels of spirometric parameters for each assessment during sequential testing: forced vital capacity (FVC), forced expiratory volume in the first second (FEV1), and peak expiratory flow (PEF) (Table 3). First, there were no significant differences in baseline characteristics between groups. Our data showed a significant increase in the experimental group compared with the control group, indicating a large effect size for the forced vital capacity at T2, p = 0.04, and T3, p = 0.02. The findings were also replicated for the forced expiratory volume in the first second at T2, p = 0.05 and T3, p = 0.03. The eta square statistic indicated a medium effect size for peak expiratory flow at T2, p = 0.05, and T3, p = 0.05.

3. Discussion

“Long COVID” is a term used to describe presence of various symptoms, even weeks or months after acquiring SARS-CoV-2 infection irrespective of the viral status [18]. First, the aim of the present investigation was to first determine the effects of a detailed protocol based on breathing training with two specifically designed respiratory devices in post-COVID-19 individuals. Forced vital capacity (FVC), forced expiratory volume in one second (FEV1), and peak expiratory flow (PEF) were used as indicators to evaluate the levels of respiratory function. The results of the present study showed significant changes in respiratory function in the experimental group compared with the control group, including improvements in forced vital capacity and expiration ability. These results are in line with those of Gloeckl et al. [19] and Liu et al. [20], who reported significant improvements in respiratory function indexes, such as FVC and FEV1, following respiratory training in the intervention group (individuals with long-term COVID-19). Thoracic joint mobilization promotes muscle activities for improved ventilation, also enhancing the respiratory function based on the diaphragm [21]. In this condition, the diaphragm freely works, allowing an efficient postural re-education. At this regard, the second aim of this study was to determine whether positive changes in breathing capacity would benefit posture and well-being. Various studies have demonstrated that breathing muscle training strengthens the spinal muscles, resulting in better postural control and a significantly positive impact on balance [22,23,24]. Following this line, our results showed greater and significant improvements in the center-of-pressure length in the experimental group, also achieving positive impacts on postural muscles and on the total lung function, as confirmed by spirometry.

Limitations and New Lines of Investigation

The findings of the present study may be limited by the small sample size; in order to compare patients in groups, according to the classification of COVID-19 severity (mild, moderate, and severe), this group should be larger. Moreover, due to the small group of respondents (as the sample was less than 25), it was not possible to perform all statistical tests (e.g., a regression analysis), and this could limit the generalizability of the findings. Although the results are encouraging and relevant, further confirmatory studies are strongly recommended to assess and validate the effectiveness of the applied protocol by tracking participants over a longer period. It could provide insights into the long-term efficacy of the devices. Finally, further research is suggested to compare the SpiroTiger and KS Brief Stimulator to other breathing devices, highlighting their unique benefits and limitations.

4. Methods and Materials

4.1. Participants

Nineteen post-COVID-19 volunteers were recruited to participate in the research. The inclusion criteria were as follows: a history of COVID-19 at least 1 month prior, an absence of motor or neurological deficits, no trauma, and individuals who were available to participate in the program twice a week. The exclusion criteria were participants who had cancer or orthopedic injuries. Three participants receiving physical therapy were excluded. Sixteen young participants were randomly assigned to the experimental (n = 8) and control (n = 8) groups using the toss of a coin. The procedures were conducted according to the ethical principles stated in the Declaration of Helsinki and were performed with university ethics committee approval. The Departmental Research Committee approved the study design (approval number: 297/2023/MEDF-01/09). Before beginning the study, each participant received a full explanation of the study procedures and signed a written consent form to participate. Confidentiality of the responses was also assured.

4.2. Procedures

The study was conducted from August 2023 to May 2024. Participants were tested individually at four moments: T0 (baseline), T1 (after 3 months), T2 (after 6 months) and T3 (after 9 months). Every 3 months, the participants were subjected to postural stability and spirometric assessments. The postural stability assessment was performed using a baropodometric platform. All participants were placed bipedally with their bare feet side-by-side on the baropodometric platform, with each foot about 20 cm away from the other and without any type of other support.
The experimental group followed a breathing training protocol lasting 12 min twice a week; the control group observed a video clip of an individual performing the breathing function accurately and efficiently.

Breathing Training Protocol

The specific breathing training protocol was exclusively created for this study and included two phases: a first phase lasting for 2 min of training with SpiroTiger; and a second phase, lasting 10 min, which included the use of the KS Brief Stimulator. There were two minutes of rest between each phase.
  • SpiroTiger exercises
1. Half squat (exercise duration: 1 min): the execution of this exercise included an inhalation in an upright bipedal position and a subsequent exhalation in a half-squat position, and the exercise was then repeated on the next inhalation (Figure 1).
2. Inhalation and exhalation on an exercise bike (exercise duration: 1 min): this exercise consisted of inhaling and exhaling, this time coordinating breathing while pedaling on an exercise bike at one’s own subjective pace. The size (liters) of the breathing bag used was 3.5 L. Resistance was added to make it 2.5 L for female participants (Figure 2).
  • KS Brief Stimulator exercises
1. Abduction–adduction of the upper limbs (exercise duration: 5 min): the exercise required carrying out an abduction of the upper limbs (i.e., moving them away from the trunk) upon inspiration and a subsequent adduction of the same upon expiration (Figure 3).

4.3. Measurements

4.3.1. Baropodometric Platform

Postural stability was measured using the FreeMed® baropodometric platform and 145 FreeStep® software 2.0 (Sensor Medica®; Guidonia Montecelio, Rome, Italy) with the following specific features: platform surface 440 × 620 mm, with an active surface of 400 × 400 mm and 8 mm thickness. According to the Romberg test, each subject was in a standing position for 51.2 s with the feet placed side-by-side, forming an angle of 30°, and both heels were 4 cm apart. The examination was conducted with open eyes. The parameter of the postural stability measurement was the center-of-pressure length (CoPL−mm), representing the sum of postural sway in the anteroposterior and mediolateral directions. An increase in this variable represents a decreased ability to control posture; conversely, a decrease represents an improvement [25].

4.3.2. SpiroTiger

Spirometry is a procedure to measure lung function (the amount of air that enters and leaves the lungs) [26]. The first step of breathing muscle training was performed with the use of the SpiroTiger® device [27]. It consists of tubing connecting a silicon breathing bag with a side port containing an opening that allows inspiration from and expiration to fresh air. During training, the breathing bag fills with expired air, characterized by elevated concentrations of carbon dioxide. When the bag is full, the valve opens and expels the remaining expired air into the environment. During inspiration, the breathing bag is first emptied completely, and then the side port valve opens, providing fresh air from the environment. The following spirometric parameters were assessed: forced vital capacity (FVC), forced expiratory volume in the first second (FEV1), and peak expiratory flow (PEF) [28].

4.3.3. KS Brief Stimulator

The second step included the use of the KS Brief Stimulator®, a tool capable of specifically and permanently recovering the physiology of diaphragmatic breathing. It consists of a base with a rigid support on the ground, and two fixing systems: a set of regulating belts inserted in a linear and oblique way that move it on the chest and fix the shoulders to prevent the raising and antero-posterior expansion of the apical zone. The unique structures that can respond to the expansive force of the air are the ribs and the diaphragm, supporting their mobilization [29].

4.4. Statistical Analysis

The normality of the data distribution was tested using the Shapiro–Wilk test. Descriptive statistics were used to calculate the mean and standard deviation (SD). Independent t-tests were performed to identify statistically significant differences between the two groups in the postural index. A paired t-test was performed to detect within-group differences in each assessment during sequential testing. The effect size calculation (Cohen’s d) was used to evaluate the practical significance of findings, where values between 0 and 0.2 represent “very small” effects, values between 0.2 and 0.5 represent “small” effects, values between 0.5 and 0.8 represent “medium” effects, and values above 0.8 represent “large” effects [30]. All statistical analyses were processed using SPSS version 27 (SPSS Inc., Chicago, IL, USA) and presented as means ± SDs (significance level: p ≤ 0.05).

5. Conclusions

The detailed protocol based on breathing training with two specifically designed respiratory devices in post-COVID-19 individuals is highly effective at improving the functional parameters of the respiratory function. The effectiveness of the intervention had a positive impact on the functional capacity, respiratory muscle strength, and, consequently, on the postural stability, allowing for the development of a high-quality re-education protocol.

Author Contributions

Conceptualization, D.D.C. and M.C.P.; methodology, V.C.F., F.L. and O.M.; investigation, F.L., M.C.P. and C.C.; data curation, F.L., F.P. and D.D.C.; writing—original draft preparation, D.D.C., M.C.P. and V.C.F.; writing—review and editing, V.C.F. and D.D.C.; visualization, O.M. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

The study was conducted according to the recommendations of the Ethical Code of the University of Palermo and of the Code of Ethics approved by the General Assembly of the Italian Association of Psychology held on 27 March 2015. All participants were informed about the procedures of the study and the anonymity of their answers before providing their written consent to participate, in accordance with the Declaration of Helsinki. The study design was approved by the Departmental Research Committee (approval number: 297/2023/MEDF-01/09).

Informed Consent Statement

Informed consent was obtained from all subjects involved in the study.

Data Availability Statement

The data that support the findings of this study are available from the corresponding author (D.D.C.) upon reasonable request.

Conflicts of Interest

The authors declare no conflicts of interest.

References

  1. Coleman, K.K.; Tay, D.J.W.; Tan, K.S.; Ong, S.W.X.; Than, T.S.; Koh, M.H.; Chin, Y.Q.; Nasir, H.; Mak, T.M.; Chu, J.J.H.; et al. Viral load of severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) in respiratory aerosols emitted by patients with coronavirus disease 2019 (COVID-19) while breathing, talking, and singing. Clin. Infect. Dis. 2022, 74, 1722–1728. [Google Scholar] [CrossRef] [PubMed]
  2. Naralia, T.W.; Permatasari, H. The Effectiveness of Breathing Exercises for Post Covid-19 Patients during Rehabilitation: A Literature Review. STRADA J. Ilm. Kesehat. 2021, 10, 844–850. [Google Scholar]
  3. Davis, H.E.; McCorkell, L.; Vogel, J.M.; Topol, E.J. Long COVID: Major findings, mechanisms and recommendations. Nat. Rev. Microbiol. 2023, 21, 133–146. [Google Scholar] [CrossRef] [PubMed]
  4. Bull, F.C.; Al-Ansari, S.S.; Biddle, S.; Borodulin, K.; Buman, M.P.; Cardon, G.; Carty, C.; Chaput, J.P.; Chastin, S.; Chou, R.; et al. World Health Organization 2020 guidelines on physical activity and sedentary behaviour. Br. J. Sports Med. 2020, 54, 1451–1462. [Google Scholar] [CrossRef]
  5. Perenc, L.; Karczmarek-Borowska, B.; Tymczak, M. Endurance training of the respiratory muscles–literature research. Med. Rev. 2016, 2, 193–208. [Google Scholar] [CrossRef]
  6. Dennis, A.; Wamil, M.; Alberts, J.; Oben, J.; Cuthbertson, D.J.; Wootton, D.; Crooks, M.; Gabbay, M.; Brady, M.; Hishmeh, L.; et al. Multiorgan impairment in low-risk individuals with post-COVID-19 syndrome: A prospective, community-based study. BMJ Open 2021, 11, e048391. [Google Scholar] [CrossRef]
  7. Shao, Y.J.; Chan, M.L.; Chen, Y.H. Effects of Abdominal Exercise on Respiratory Muscles and Pulmonary Function in Healthy Males. Int. J. Physiother. Res. 2018, 6, 2606–2612. [Google Scholar] [CrossRef]
  8. Aktan, Ö.O.; Aktan, R.; Yakut, H.; Özalevli, S.; Kara, B. The effects of respiratory muscle functions on trunk muscle endurance in healthy young adults. J. Basic Clin. Health Sci. 2021, 7, 652–659. [Google Scholar] [CrossRef]
  9. Chatham, K. Respiratory muscle training. Br. J. Ther. Rehab. 1995, 2, 31–36. [Google Scholar] [CrossRef]
  10. Marijančić, V.; Kezele, T.G.; Peharec, S.; Dragaš-Zubalj, N.; Žeželj, S.P.; Starčević-Klasan, G. Relationship between Physical Activity and Sedentary Behavior, Spinal Curvatures, Endurance and Balance of the Trunk Muscles-Extended Physical Health Analysis in Young Adults. Int. J. Environ. Res. Public Health 2023, 20, 6938. [Google Scholar] [CrossRef]
  11. Romaszko-Wojtowicz, A.; Szalecki, M.; Olech, K.; Doboszyńska, A. Assessment of the Function of Respiratory Muscles in Patients after COVID-19 Infection and Respiratory Rehabilitation. Trop. Med. Infect. Dis. 2023, 8, 57. [Google Scholar] [CrossRef] [PubMed]
  12. Sliwka, A.; Pilinski, R.; Rosa, W.; Nowobilski, R. The influence of the trunk muscle activation on occlusion pressure and respiratory muscle strength in healthy participants: Randomized controlled trial. Respir. Physiol. Neurobiol. 2021, 290, 103682. [Google Scholar] [CrossRef] [PubMed]
  13. Kim, H.S.; Cho, S.H. Correlation between lung function and functional movement in healthy adults. Healthcare 2020, 8, 276. [Google Scholar] [CrossRef] [PubMed]
  14. Ostrowska, M.; Rzepka-Cholasinska, A.; Pietrzykowski, Ł.; Michalski, P.; Kosobucka-Ozdoba, A.; Jasiewicz, M.; Kasprzak, M.; Krys, J.; Kubica, A. Effects of Multidisciplinary Rehabilitation Program in Patients with Long COVID-19: Post-COVID-19 Rehabilitation (PCR SIRIO 8) Study. J. Clin. Med. 2023, 12, 420. [Google Scholar] [CrossRef]
  15. Besnier, F.; Bérubé, B.; Malo, J.; Gagnon, C.; Grégoire, C.A.; Juneau, M.; Simard, F.; L’Allier, P.; Nigam, A.; Iglésies-Grau, J.; et al. Cardiopulmonary Rehabilitation in Long-COVID-19 Patients with Persistent Breathlessness and Fatigue: The COVID-Rehab Study. Int. J. Environ. Res. Public Health 2022, 19, 4133. [Google Scholar] [CrossRef]
  16. Morrow, A.; Gray, S.R.; Bayes, H.K.; Sykes, R.; McGarry, E.; Anderson, D.; Boiskin, D.; Burke, C.; Cleland, J.G.F.; Goodyear, C. Prevention and early treatment of the long-term physical effects of COVID-19 in adults: Design of a randomized controlled trial of resistance exercise-CISCO-21. Trials 2022, 23, 660–673. [Google Scholar] [CrossRef]
  17. Chen, H.; Shi, H.; Liu, X.; Sun, T.; Wu, J.; Liu, Z. Effect of Pulmonary Rehabilitation for Patients with Post-COVID-19: A Systematic Review and Meta-Analysis. Front. Med. 2022, 9, 837420–837432. [Google Scholar] [CrossRef]
  18. Sudre, C.H.; Murray, B.; Varsavsky, T.; Graham, M.S.; Penfold, R.S.; Bowyer, R.C.; Steves, C.J. Attributes and predictors of long COVID. Nat. Med. 2021, 27, 626–631. [Google Scholar] [CrossRef]
  19. Gloeckl, R.; Leitl, D.; Jarosch, I.; Schneeberger, T.; Nell, C.; Stenzel, N.; Vogelmeier, C.F.; Kenn, K.; Koczulla, A.R. Benefits of pulmonary rehabilitation in COVID-19: A prospective observational cohort study. ERJ Open Res. 2021, 7, 108–119. [Google Scholar] [CrossRef]
  20. Liu, K.; Zhang, W.; Yang, Y.; Zhang, J.; Li, Y.; Chen, Y. Respiratory rehabilitation in elderly patients with COVID-19: A randomized controlled study. Complement. Ther. Clin. Pract. 2020, 39, 101166–101170. [Google Scholar] [CrossRef]
  21. Crimi, C.; Campisi, R.; Augelletti, T.; Heffler, E.; Ragusa, A.; Crimi, N. Inspiratory muscle training with SpiroTiger-MEDICAL® in patients with diaphragmatic dysfunction. Eur. Respir. J. 2018, 52 (Suppl. S62), 4127. [Google Scholar]
  22. Lee, Y.J. Thoracic Mobilization and Respiratory Muscle Endurance Training Improve Diaphragm Thickness and Respiratory Function in Patients with a History of COVID-19. Medicina 2023, 59, 906. [Google Scholar] [CrossRef] [PubMed]
  23. Pietranis, K.A.; Izdebska, W.M.; Kuryliszyn-Moskal, A.; Dakowicz, A.; Ciołkiewicz, M.; Kaniewska, K.; Dziecioł-Anikiej, Z.; Wojciuk, M. Effects of Pulmonary Rehabilitation on Respiratory Function and Thickness of the Diaphragm in Patients with Post-COVID-19 Syndrome: A Randomized Clinical Trial. J. Clin. Med. 2024, 13, 425. [Google Scholar] [CrossRef] [PubMed]
  24. Crisan, A.F.; Pescaru, C.C.; Maritescu, A.; Carunta, V.; Oancea, C.; Vastag, E. Respiratory Muscle Training and Its Impact on Balance and Gait in Patients with Severe COPD. Medicina 2024, 60, 257. [Google Scholar] [CrossRef]
  25. Palmieri, R.M.; Ingersoll, C.D.; Stone, M.B.; Krause, B.A. Center-of-pressure parameters used in the assessment of postural control. J. Sport. Rehabil. 2002, 11, 51–66. [Google Scholar] [CrossRef]
  26. Liou, T.G.; Kanner, R.E. Spirometry. Clin. Rev. Allergy Immunol. 2009, 37, 137–152. [Google Scholar] [CrossRef]
  27. Scherer, A.T.; Spengler, C.M.; Owassapian, D.; Imhof, E.; Boutellier, U. Respiratory muscle endurance training in chronic obstructive pulmonary disease, impact on exercise capacity, dyspnea and quality of life. Am. J. Respir. Crit. Care Med. 2000, 162, 1709–1714. [Google Scholar] [CrossRef]
  28. Kisner, C.; Colby, L.A.; Borstad, J. Therapeutic Exercise: Foundations and Techniques; Fa Davis: Philadelphia, PA, USA, 2017. [Google Scholar]
  29. Di Fabrizio, G.; Di Fabrizio, D.N.; Sberna, A.E.; Maugeri, F.; Mingrino, O.M.; Francavilla, V.C. The Ks Brief Stimulator® role in postural alterations treatment: Clinical case reports. J. Hum. Sport Exerc. 2020, 15, S1108–S1122. [Google Scholar]
  30. Cohen, J. Statistical Power Analysis for the Behavioral Sciences, 2nd ed.; Hillsdale: Erlbaum, MI, USA, 1988. [Google Scholar]
Jfmk 09 00203 g001
Figure 1. Half squat.
Figure 1. Half squat.
Jfmk 09 00203 g001
Jfmk 09 00203 g002
Figure 2. Exercise Bike.
Figure 2. Exercise Bike.
Jfmk 09 00203 g002
Jfmk 09 00203 g003
Figure 3. Upper Limbs 2. Flexion–extension of the head (exercise duration: 5 min): the exercise consisted of the movement of flexion of the head (forwards) on exhalation and extension of the same (backwards) on inspiration (Figure 4).
Figure 3. Upper Limbs 2. Flexion–extension of the head (exercise duration: 5 min): the exercise consisted of the movement of flexion of the head (forwards) on exhalation and extension of the same (backwards) on inspiration (Figure 4).
Jfmk 09 00203 g003
Jfmk 09 00203 g004
Figure 4. Exercise Head.
Figure 4. Exercise Head.
Jfmk 09 00203 g004
Table 1. Participants’ anthropometric characteristics. Means ± standard deviations.
Table 1. Participants’ anthropometric characteristics. Means ± standard deviations.
Age [Years]Height [cm]Weight [kg]Gender
Experimental group23 ± 2.87170 ± 3.8674 ± 9.294 m, 4 f
Control group23.8 ± 1.48169 ± 4.3170 ± 8.374 m, 4 f
p0.6710.5930.6820.514
Notes: Statistically, no differences were found between these groups in terms of age, height, or weight. The groups were equally well balanced in terms of gender.
Table 2. Mean ± SD for the postural parameter across sessions and groups.
Table 2. Mean ± SD for the postural parameter across sessions and groups.
Postural
Parameter		 T0T1T2T3
CoPL−mmEG279.81 ± 27.16257.11 ± 29.13262.47 ± 26.35 * 265.23 ± 25.14 *
CG282.12 ± 22.41279.14 ± 25.63274.14 ± 23.84277.91 ± 25.17
Notes: * p < 0.05. CoPL−mm = center-of-pressure length; EG = experimental group; CG = control group; T0 = baseline, T1 = after 3 months; T2 = after 6 months; T3 = after 9 months.
Table 3. Comparison of spirometric parameters.
Table 3. Comparison of spirometric parameters.
tpMean Difference
(95% CI)		Cohen’s d
FVCT0−1.240.26−0.59 (−1.15~0.30)−0.044
T1−1.990.08−0.88 (−1.46~0.09)−0.703
T2−2.430.04 *−1.01 (−1.66~−0.07)−0.861
T3−3.000.02 *−1.17 (−1.92~−0.16)−1.062
FEV1T0−1.310.23−0.41 (−1.18~0.28)−0.463
T1−1.560.16−0.49 (−1.28~0.21)−0.550
T2−2.190.05 *−0.64 (−1.55~0.05)−0.786
T3−2.560.03 *−0.71 (−1.72~−0.04)−0.904
PEFT0−2.030.08−1.46 (−1.52~0.08)−0.718
T1−2.160.06−1.66 (−1.54~0.05)−0.765
T2−2.240.05 *−1.74 (−1.48~0.03)−0.793
T3−2.110.05 *−1.93 (−1.42~0.06)−0.795
Notes: * p < 0.05. FVC = forced vital capacity, FEV1 = forced expiratory volume in the first second, PEF = peak expiratory flow; T0 = baseline, T1 = after 3 months; T2 = after 6 months; T3 = after 9 months.
