Previous Issue
Volume 9, August



Designs, Volume 9, Issue 5 (October 2025) – 16 articles

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
16 pages, 3404 KB
Article
Advancing Clean Solar Energy: System-Level Optimization of a Fresnel Lens Interface for UHCPV Systems
by Taher Maatallah
Designs 2025, 9(5), 115; https://doi.org/10.3390/designs9050115 - 25 Sep 2025
Abstract
This study presents the development and validation of a high-efficiency optical interface designed for ultra-high-concentration photovoltaic (UHCPV) systems, with a focus on enabling clean and sustainable solar energy conversion. A Fresnel lens serves as the primary optical concentrator in a novel system architecture [...] Read more.
This study presents the development and validation of a high-efficiency optical interface designed for ultra-high-concentration photovoltaic (UHCPV) systems, with a focus on enabling clean and sustainable solar energy conversion. A Fresnel lens serves as the primary optical concentrator in a novel system architecture that integrates advanced optical design with system-level thermal management. The proposed modeling framework combines detailed 3D ray tracing with coupled thermal simulations to accurately predict key performance metrics, including optical concentration ratios, thermal loads, and component temperature distributions. Validation against theoretical and experimental benchmarks demonstrates high predictive accuracies within 1% for optical efficiency and 2.18% for thermal performance. The results identify critical thermal thresholds for long-term operational stability, such as limiting mirror temperatures to below 52 °C and photovoltaic cell temperatures to below 130 °C. The model achieves up to 89.08% optical efficiency, with concentration ratios ranging from 240 to 600 suns and corresponding focal spot temperatures between 37.2 °C and 61.7 °C. Experimental benchmarking confirmed reliable performance, with the measured results closely matching the simulations. These findings highlight the originality of the coupled optical–thermal approach and its applicability to concentrated photovoltaic design and deployment. This integrated design and analysis approach supports the development of scalable, clean photovoltaic technologies and provides actionable insights for real-world deployment of UHCPV systems with minimal environmental impact. Full article
Show Figures

Figure 1

29 pages, 15083 KB
Article
Pseudo-Static Design and Analysis of Seismic Earth Pressure for Cantilever Retaining Walls with Limitation Assessment
by Zhiliang Sun, Wei Wang and Hanghang Liu
Designs 2025, 9(5), 114; https://doi.org/10.3390/designs9050114 - 24 Sep 2025
Abstract
By critically reviewing pseudo-static methods, it is demonstrated that approximating the earth pressure on a short heel’s vertical face (V-plane) using the Rankine solution for long-heel walls induces a negligible error. A finite element analysis is deployed to validate the pseudo-static [...] Read more.
By critically reviewing pseudo-static methods, it is demonstrated that approximating the earth pressure on a short heel’s vertical face (V-plane) using the Rankine solution for long-heel walls induces a negligible error. A finite element analysis is deployed to validate the pseudo-static results, with dynamic simulations incorporating 1–5 Hz sinusoidal seismic excitations to probe the resonance effects. The key results show that disregarding the impact of layered backfill placement on the initial stress states leads to non-conservative estimates of active earth pressure. Furthermore, the point of application of earth pressure rises significantly during strong shaking, and although the transient safety factors against sliding and overturning may fall below 1.0 during seismic events, the residual deformation analysis suggests that this does not necessarily lead to collapse. A significant amplification of bending moments and greater reductions in post-earthquake safety factors occur when the input frequency approaches the natural frequency of a wall. Finally, the paper proposes resonance prevention strategies for the seismic design of cantilever retaining walls, a methodology incorporating construction effects into the initial stress field modeling, and recommendations for selecting effective safety factors. Full article
(This article belongs to the Section Civil Engineering Design)
Show Figures

Figure 1

29 pages, 9768 KB
Article
Design, Construction, and Simulation-Based Validation of a High-Efficiency Electric Powertrain for a Shell Eco-Marathon Urban Concept Vehicle
by Kristaq Hazizi, Suleiman Erateb, Arnaldo Delli Carri, Joseph Jones, Sin Hang Leung, Stefania Sam and Ronnie Yau
Designs 2025, 9(5), 113; https://doi.org/10.3390/designs9050113 - 23 Sep 2025
Abstract
This study addresses a documented gap in detailed, cost-effective, and performance-validated electric vehicle (EV) powertrain solutions. It presents the complete design, construction, and simulation-based validation of a high-efficiency electric powertrain for a Shell Eco-marathon Urban Concept vehicle. Novel contributions of this work include [...] Read more.
This study addresses a documented gap in detailed, cost-effective, and performance-validated electric vehicle (EV) powertrain solutions. It presents the complete design, construction, and simulation-based validation of a high-efficiency electric powertrain for a Shell Eco-marathon Urban Concept vehicle. Novel contributions of this work include a unique drivetrain architecture: a BLDC motor with a modular two-stage chain drive and a custom lithium-ion battery pack. The design is optimized for compactness and reliability under stringent budget and packaging constraints. A comprehensive Simulink-based vehicle dynamics model was developed for robust validation. This model enabled the estimation of energy consumption, torque profiles, and battery State of Charge under realistic drive cycles. The system demonstrated a remarkably low energy consumption under competition conditions, signifying high efficiency with <50 Wh/km consumption and full compliance with technical regulations. Furthermore, the hardware is thoroughly documented with detailed build instructions, CAD models, and a full bill of materials. This promotes reproducibility. This research offers a validated, low-cost, and replicable electric powertrain. It provides a transferable framework for future Shell Eco-marathon teams and advances lightweight, cost-effective solutions for real-world low-speed electric mobility applications, such as micro-EVs and urban delivery vehicles. Full article
Show Figures

Figure 1

2 pages, 156 KB
Correction
Correction: Kantaros et al. Smart Design Aided by Mathematical Approaches: Adaptive Manufacturing, Sustainability, and Biomimetic Materials. Designs 2025, 9, 102
by Antreas Kantaros, Theodore Ganetsos, Evangelos Pallis and Michail Papoutsidakis
Designs 2025, 9(5), 112; https://doi.org/10.3390/designs9050112 - 22 Sep 2025
Viewed by 15
Abstract
In the published paper [...] Full article
24 pages, 529 KB
Review
Positive Energy District Success Factors: Learning from Global Challenges and Success Stories
by Dimitrios Siakas, Kerstin Siakas and Georgios Lampropoulos
Designs 2025, 9(5), 111; https://doi.org/10.3390/designs9050111 - 19 Sep 2025
Viewed by 246
Abstract
The aim of this study is to examine existing positive energy district (PED) initiatives by using an explanatory research approach for gaining insight, identifying patterns, clarifying underlying processes, exploring cause-and-effect relationships, and explaining phenomena in a greater depth. Specifically, studies from the existing [...] Read more.
The aim of this study is to examine existing positive energy district (PED) initiatives by using an explanatory research approach for gaining insight, identifying patterns, clarifying underlying processes, exploring cause-and-effect relationships, and explaining phenomena in a greater depth. Specifically, studies from the existing literature that have explored multiple PEDs were analyzed. Current challenges, barriers, and obstacles, as well as success factors, good practices, and policy guidelines are thoroughly investigated, evaluated, categorized and compared to unveil lessons learnt from diverse existing international projects for turning urban areas into self-sustainable and greener urban neighborhoods. The proposed framework aims to reveal the required processes for successful PED creation and operation. It provides an overview of the current state of the art and enhances comprehension and know-how about the processes needed for the successful adoption and integration of PEDs based on lessons learnt from global challenges and success stories. Full article
(This article belongs to the Special Issue Design and Applications of Positive Energy Districts)
Show Figures

Figure 1

25 pages, 3943 KB
Review
Role of Ventilation and Spatial Designs in Airborne Disease Transmission Within Residential Aged-Care Facilities
by Fahim Ullah, Oluwole Olatunji, Siddra Qayyum and Rameesha Tanveer
Designs 2025, 9(5), 110; https://doi.org/10.3390/designs9050110 - 17 Sep 2025
Viewed by 309
Abstract
The global aging population, particularly those aged 60 and above, is increasingly vulnerable to communicable diseases. Building ventilation (BV) plays a key role in residential aged-care (RAC) facilities, where COVID-19 has had a significant impact. This study systematically reviews the published literature to [...] Read more.
The global aging population, particularly those aged 60 and above, is increasingly vulnerable to communicable diseases. Building ventilation (BV) plays a key role in residential aged-care (RAC) facilities, where COVID-19 has had a significant impact. This study systematically reviews the published literature to examine the influence of BV systems (BVSs) on airborne disease (COVID-19) transmission in RACs and recommends strategies to protect vulnerable residents. Using the PRISMA framework, articles published in the last decade were sourced from Scopus, Web of Science, and PubMed. Bibliometric analyses revealed key research clusters on risk factors, transmission, facilities and services, and gender-based and retrospective studies. Australia, the USA, Africa, and the UK have made the most scholarly contributions to this field. Three main research areas emerged: BVS functionality, ventilation’s role in COVID-19 transmission, and spatial building design for effective airflow. Findings reveal that inadequate ventilation and poor indoor air quality are major contributors to disease spread, further influenced by ventilation rate, airflow, temperature, humidity, and air distribution. A hybrid ventilation design that integrates natural and mechanical systems with technologies such as HEPA filters, UVGI, and HVAC is recommended in the current study. In addition, building form and layout should incorporate spatial, engineering, administrative, and hierarchical controls in line with sustainable ventilation design guidelines. This study adds to the growing body of knowledge on the roles of ventilation and design in infection control. It offers practical recommendations for architects, RAC managers, government agencies, and policymakers involved in designing and managing RACs to reduce the risk of communicable disease transmission. Full article
(This article belongs to the Topic Sustainable Building Development and Promotion)
Show Figures

Figure 1

7 pages, 173 KB
Editorial
Design Process for Additive Manufacturing
by Paweł Turek
Designs 2025, 9(5), 109; https://doi.org/10.3390/designs9050109 - 16 Sep 2025
Viewed by 282
Abstract
Additive Manufacturing (AM) techniques are rapidly emerging as leading technologies for the creation of complex models [...] Full article
(This article belongs to the Special Issue Design Process for Additive Manufacturing)
25 pages, 4947 KB
Article
An Application of Reinforcement Learning to the Optimal Design of Road Vehicle Suspension Systems
by Lorenzo De Santanna, Riccardo Malacrida, Gianpiero Mastinu and Massimiliano Gobbi
Designs 2025, 9(5), 108; https://doi.org/10.3390/designs9050108 - 12 Sep 2025
Viewed by 387
Abstract
This study investigates the application of Multi-Objective Reinforcement Learning–Dominance-Based (MORL–DB) method to the optimal design of complex mechanical systems. The MORL–DB method employs a Deep Deterministic Policy Gradient (DDPG) agent to identify the optimal solutions of the multi-objective problem. By adopting the k [...] Read more.
This study investigates the application of Multi-Objective Reinforcement Learning–Dominance-Based (MORL–DB) method to the optimal design of complex mechanical systems. The MORL–DB method employs a Deep Deterministic Policy Gradient (DDPG) agent to identify the optimal solutions of the multi-objective problem. By adopting the k-optimality metric, which introduces an optimality ranking within the Pareto-optimal set of solutions, a final design solution can be chosen more easily, especially when considering a large number of objective functions. The method is successfully applied to the elasto-kinematic optimisation of a double wishbone suspension system, featuring a multi-body model in ADAMS Car. This complex design task includes 30 design variables and 14 objective functions. The MORL–DB method is compared with two other approaches: the Moving Spheres (MS) method, specifically developed for spatial design tasks, and the genetic algorithm with k-optimality-based sorting (KEMOGA). Comparative results show that the MORL–DB method achieves solutions of higher optimality while requiring significantly fewer objective function evaluations. The results demonstrate that the MORL–DB method is a promising and sample-efficient alternative for multi-objective optimisation, particularly in problems involving high-dimensional design spaces and expensive objective function evaluations. Full article
Show Figures

Figure 1

16 pages, 3953 KB
Article
3D-Printed Prosthetic Solutions for Dogs: Integrating Computational Design and Additive Manufacturing
by Jeremy Sarpong, Khalil Khanafer and Mohammad Sheikh
Designs 2025, 9(5), 107; https://doi.org/10.3390/designs9050107 - 7 Sep 2025
Viewed by 1201
Abstract
This study investigates the mechanical performance of two prosthetic forelimb designs for dogs—one with a solid structure and the other with a perforated structure—using Finite Element Analysis (FEA). Both models were analyzed under static loading conditions representing approximately 60% of a dog’s body [...] Read more.
This study investigates the mechanical performance of two prosthetic forelimb designs for dogs—one with a solid structure and the other with a perforated structure—using Finite Element Analysis (FEA). Both models were analyzed under static loading conditions representing approximately 60% of a dog’s body weight, the typical load borne by the forelimbs. The prosthetics were modeled with ABS plastic, a widely used 3D printing material, and evaluated for Von Mises stress, total deformation, elastic strain, and factor of safety. The analysis showed that both models remained within the elastic limit of the material, indicating that no permanent deformation would occur under the applied loads. The Solid Model demonstrated a significantly higher factor of safety (14) and lower deformation, confirming its structural strength but also highlighting excessive rigidity, increased material use, and higher cost. In contrast, the Perforated Model exhibited slightly higher localized stresses and a lower factor of safety (3.01), yet it still met essential safety requirements while providing greater compliance, flexibility, and material efficiency. These attributes are desirable for comfort, adaptability, and practicality in veterinary applications. Although its long-term durability requires further evaluation, the Perforated Model strikes a more effective balance between safety, comfort, and sustainability. Based on these findings, the perforated design is considered the more suitable option for canine prosthetic development. Future work will extend the analysis to dynamic loading scenarios, such as walking and running, to better simulate real-world performance. Full article
(This article belongs to the Special Issue Design Process for Additive Manufacturing)
Show Figures

Figure 1

18 pages, 3818 KB
Article
Effect of Cross-Section Designs on Energy Absorption of Mechanical Metamaterials
by Xinnian Wang, Sina Rastegarzadeh, Yayue Pan and Jida Huang
Designs 2025, 9(5), 106; https://doi.org/10.3390/designs9050106 - 7 Sep 2025
Viewed by 347
Abstract
Numerous studies have examined various geometric designs in cellular structures, yet the role of cross-sectional geometry remains underexplored. Cross-sections significantly influence the effective material properties of architected materials, where stress concentrations at junctions can reduce structural strength. This study investigates how different cross-sections [...] Read more.
Numerous studies have examined various geometric designs in cellular structures, yet the role of cross-sectional geometry remains underexplored. Cross-sections significantly influence the effective material properties of architected materials, where stress concentrations at junctions can reduce structural strength. This study investigates how different cross-sections affect energy absorption efficiency in both bending- and stretching-dominated cellular structures. Five classes of lattice structures, each designed with four distinct cross-sections, were fabricated using a custom stereolithography printer. Mechanical performance—specifically energy absorption and energy absorption efficiency—was evaluated through physical simulation and experimental testing. The results show that selecting optimal cross-sections can enhance yield stress by an average of 35% for cubic, 39% for BCC, 22% for BCCZ, and 41% for FCC structures. These findings demonstrate the critical impact of cross-sectional geometry on mechanical behavior. Both experimental and finite element analysis-based homogenization approaches were employed to validate results. The study proposes cross-section design guidelines aimed at optimizing strength-to-weight ratios, offering valuable insights for the development of high-performance mechanical metamaterials. Full article
Show Figures

Figure 1

17 pages, 6935 KB
Article
Improving the Torque of a Paddle Mini-Hydropower Plant Through Geometric Parameter Optimization and the Use of a Current Amplifier
by Almira Zhilkashinova, Igor Ocheredko and Madi Abilev
Designs 2025, 9(5), 105; https://doi.org/10.3390/designs9050105 - 4 Sep 2025
Viewed by 400
Abstract
In the presented work, the main challenge of small hydropower plants—converting low river flow velocities into high generator rotations—is investigated. It was established that applying the flow acceleration effect during interaction with surfaces makes it possible to increase the power output of a [...] Read more.
In the presented work, the main challenge of small hydropower plants—converting low river flow velocities into high generator rotations—is investigated. It was established that applying the flow acceleration effect during interaction with surfaces makes it possible to increase the power output of a small hydropower plant by up to 25%, which corresponds to the level of an innovative solution. Stationary flow amplifiers and their influence on the dynamic interaction of blades were studied. It was revealed that the use of the amplification effect in paired configurations contributes to achieving a multiplicative effect. The potential of small hydropower plants was analytically evaluated, taking into account their dimensions and gear systems. The study was carried out using the method of computational fluid dynamics (CFD), which enables the modeling of complex hydrodynamic processes. Based on the developed three-dimensional model of the object and its discretization into a computational mesh, boundary conditions were set, and the finite volume method was applied to solve the Navier–Stokes equations. To account for turbulent flows, the k-epsilon turbulence model was employed. Full article
Show Figures

Figure 1

17 pages, 1914 KB
Systematic Review
Fatigue Resistance of RAP-Modified Asphalt Mixes Versus Conventional Mixes Using the Indirect Tensile Test: A Systematic Review
by Giuseppe Loprencipe, Laura Moretti and Mario Saltaren Daniel
Designs 2025, 9(5), 104; https://doi.org/10.3390/designs9050104 - 1 Sep 2025
Viewed by 515
Abstract
The use of Reclaimed Asphalt Pavement (RAP) in asphalt mixtures offers environmental and economic advantages by reducing reliance on virgin aggregates and minimizing construction waste. However, the aged binder in RAP increases mixture stiffness, which can compromise fatigue resistance. This systematic review evaluates [...] Read more.
The use of Reclaimed Asphalt Pavement (RAP) in asphalt mixtures offers environmental and economic advantages by reducing reliance on virgin aggregates and minimizing construction waste. However, the aged binder in RAP increases mixture stiffness, which can compromise fatigue resistance. This systematic review evaluates the influence of RAP content on fatigue performance compared to conventional mixtures, with a focus on the Indirect Tensile Test (IDT) as the primary assessment method. Following the parameters of Preferred Reporting Items for Systematic Reviews and Meta-Analyses (PRISMA) guidelines, five studies published between 2014 and 2024 were identified through searches in Web of Science, ScienceDirect, ASCE, and Scopus. Study quality was assessed using the Cochrane Risk of Bias tool. The results indicate that although RAP enhances rutting resistance, higher contents (>30%) often lead to reduced fatigue performance due to binder hardening and reduced mixture flexibility. The incorporation of rejuvenators—such as heavy paraffinic extracts—and modifiers, including high-modulus agents, polymers, and epoxy binders, can partially restore aged binder properties and improve performance. Sustainable innovations, such as lignin-based industrial by-products and warm-mix asphalt technologies, show promise in balancing mechanical performance with reduced environmental impact. Variability in material sources, modification strategies, and test protocols limits direct comparability among studies, underscoring the need for standardized evaluation frameworks. Overall, this review highlights that optimizing RAP content and selecting effective rejuvenation or modification strategies are essential for achieving durable, cost-effective, and environmentally responsible asphalt pavements. Future research should integrate advanced laboratory methods with performance-based design to enable high RAP utilization without compromising fatigue resistance. Full article
Show Figures

Figure 1

14 pages, 1870 KB
Article
Development and Mechanical Evaluation of a Stent Graft for Endovascular Aneurysm Repair Using Finite Element Modeling
by Athanasios Konstantakopoulos, Nikolaos Kladovasilakis and Georgios E. Stavroulakis
Designs 2025, 9(5), 103; https://doi.org/10.3390/designs9050103 - 1 Sep 2025
Viewed by 559
Abstract
An abdominal aortic aneurysm (AAA) poses a significant risk of arterial wall rupture, which critically endangers the patient’s life. To address this condition, an endovascular aneurysm repair (EVAR) is required, involving the insertion and expansion of a stent-graft within the aorta, to support [...] Read more.
An abdominal aortic aneurysm (AAA) poses a significant risk of arterial wall rupture, which critically endangers the patient’s life. To address this condition, an endovascular aneurysm repair (EVAR) is required, involving the insertion and expansion of a stent-graft within the aorta, to support and isolate the weakened vessel wall. In this context, this article aims to approach the problem from a mechanical perspective and to simulate the expansion and deployment procedure realistically, utilizing the Finite Element Analysis (FEA). The process initiates with the computation evaluation of the aortic structure in order to identify critical regions of stress and strain in an aneurysmatic aortic region. Then, a customized 3D-designed stent graft model was developed for the aorta and positioned properly. Applying all the necessary boundary conditions, a complex nonlinear FEA was conducted until the stent-graft expanded radially, reaching a final diameter 25% larger than the aorta’s vessel wall while withstanding mean stress and strain values close to 400 MPa and 1.5%, respectively. Finally, the mechanical behavior of the stent-graft and its interaction with the internal aortic wall, during the expansion process, was evaluated, and the extracted results were analyzed. Full article
Show Figures

Figure 1

25 pages, 1017 KB
Review
Smart Design Aided by Mathematical Approaches: Adaptive Manufacturing, Sustainability, and Biomimetic Materials
by Antreas Kantaros, Theodore Ganetsos, Evangelos Pallis and Michail Papoutsidakis
Designs 2025, 9(5), 102; https://doi.org/10.3390/designs9050102 - 1 Sep 2025
Viewed by 636 | Correction
Abstract
The increased importance of sustainability imperatives has required a profound reconsideration of the interaction between materials, manufacturing, and design fields. Biomimetic smart materials such as shape-memory polymers, hydrogels, and electro-active composites represent an opportunity to combine adaptability, responsiveness, and ecological intelligence in systems [...] Read more.
The increased importance of sustainability imperatives has required a profound reconsideration of the interaction between materials, manufacturing, and design fields. Biomimetic smart materials such as shape-memory polymers, hydrogels, and electro-active composites represent an opportunity to combine adaptability, responsiveness, and ecological intelligence in systems and products. This work reviews the confluence of such materials with leading-edge manufacturing technologies, notably additive and 4D printing, and how their combining opens the door to the realization of time-responsive, low-waste, and user-adaptive design solutions. Through computational modeling and mathematical simulations, the adaptive performance of these materials can be predicted and optimized, supporting functional integration with high precision. On the basis of case studies in regenerative medicine, architecture, wearables, and sustainable product design, this work formulates the possibility of biomimetic strategies in shifting design paradigms away from static towards dynamic, from fixed products to evolvable systems. Major material categories of stimuli-responsive materials are systematically reviewed, existing 4D printing workflows are outlined, and the way temporal design principles are revolutionizing production, interaction, and lifecycle management is discussed. Quantitative advances such as actuation efficiencies exceeding 85%, printing resolution improvements of up to 50 μm, and lifecycle material savings of over 30% are presented where available, to underscore measurable impact. Challenges such as material scalability, process integration, and design education shortages are critically debated. Ethical and cultural implications such as material autonomy, transparency, and cross-cultural design paradigms are also addressed. By identifying existing limitations and proposing a future-proof framework, this work positions itself within the ongoing discussion on regenerative, interdisciplinary design. Ultimately, it contributes to the advancement of sustainable innovation by equipping researchers and practitioners with a set of adaptable tools grounded in biomimicry, computational intelligence, and temporal design thinking. Full article
Show Figures

Figure 1

25 pages, 14188 KB
Article
Assessment of Accuracy in Geometry Reconstruction, CAD Modeling, and MEX Additive Manufacturing for Models Characterized by Axisymmetry and Primitive Geometries
by Paweł Turek, Piotr Bielarski, Alicja Czapla, Hubert Futoma, Tomasz Hajder and Jacek Misiura
Designs 2025, 9(5), 101; https://doi.org/10.3390/designs9050101 - 28 Aug 2025
Viewed by 545
Abstract
Due to the rapid advancements in coordinate measuring systems, data processing software, and additive manufacturing (AM) techniques, it has become possible to create copies of existing models through the reverse engineering (RE) process. However, the lack of precise estimates regarding the accuracy of [...] Read more.
Due to the rapid advancements in coordinate measuring systems, data processing software, and additive manufacturing (AM) techniques, it has become possible to create copies of existing models through the reverse engineering (RE) process. However, the lack of precise estimates regarding the accuracy of the RE process—particularly at the measurement, reconstruction, and computer-aided design (CAD) modeling stages—poses significant challenges. Additionally, the assessment of dimensional and geometrical errors during the manufacturing stage using AM techniques limits the practical implementation of product replicas in the industry. This paper provides an estimation of the errors encountered in the RE process and the AM stage of various models. It includes examples of an electrical box, a lampshade for a standing lamp, a cover for a vacuum unit, and a battery cover. The geometry of these models was measured using a GOM Scan 1 (Carl Zeiss AG, Jena, Germany). Following the measurement process, data processing was performed, along with CAD modeling, which involved primitive detection, profile extraction, and auto-surface methods using Siemens NX 2406 software (Siemens Digital Industries, Plano, TX, USA). The models were produced using a Fortus 360-mc 3D printer (Stratasys, Eden Prairie, MN, USA) with ABS-M30 material. After fabrication, the models were scanned using a GOM Scan 1 scanner to identify any manufacturing errors. The research findings indicated that overall, 95% of the points representing reconstruction errors are within the maximum deviation range of ±0.6 mm to ±1 mm. The highest errors in CAD modeling were attributed to the auto-surfacing method, overall, 95% of the points are within the average range of ±0.9 mm. In contrast, the lowest errors occurred with the detect primitives method, averaging ±0.6 mm. Overall, 95% of the points representing the surface of a model made using the additive manufacturing technology fall within the deviation range ±0.2 mm on average. The findings provide crucial insights for designers utilizing RE and AM techniques in creating functional model replicas. Full article
(This article belongs to the Special Issue Design Process for Additive Manufacturing)
Show Figures

Figure 1

14 pages, 1425 KB
Article
Design-Informed Evaluation and Fretting Damage Mapping of Additive-Manufactured Ti-6Al-4V Components
by Ahmad Sadeghian and Saeed Adibnazari
Designs 2025, 9(5), 100; https://doi.org/10.3390/designs9050100 - 25 Aug 2025
Viewed by 533
Abstract
This paper experimentally investigates the fretting fatigue behavior of metal additive-manufactured Ti-6Al-4V alloy specimens fabricated using the selective laser melting (SLM) method, focusing on damage characterization and fatigue life assessment. Based on the ASTM E466 standard, the test components were manufactured using metal [...] Read more.
This paper experimentally investigates the fretting fatigue behavior of metal additive-manufactured Ti-6Al-4V alloy specimens fabricated using the selective laser melting (SLM) method, focusing on damage characterization and fatigue life assessment. Based on the ASTM E466 standard, the test components were manufactured using metal 3D printing technology. Fretting fatigue tests were conducted under varying axial stress levels and contact loads, followed by microscopic examinations using scanning electron microscopy (SEM) to analyze damage mechanisms. A fretting map was developed based on SEM observations, providing insights into damage evolution under different loading conditions. These findings contribute to a better understanding of the relationship between fretting fatigue parameters and failure mechanisms. The developed fretting map and experimental observations provide a foundation for further studies aimed at enhancing the fretting fatigue life assessment of standard specimens for different test parameters. Finally, this paper includes design-oriented evaluation frameworks that can guide engineers in integrating AM components into safety-critical systems under fretting fatigue conditions. Full article
(This article belongs to the Section Mechanical Engineering Design)
Show Figures

Figure 1
