Review

Pixel Circuit Designs for Active Matrix Displays

by
Dan-Mei Wei
1,2,
Hua Zheng
1,*,
Chun-Hua Tan
2,*,
Shenghao Zhang
1,
Hua-Dan Li
1,2,
Lv Zhou
1,
Yuanrui Chen
1,2,
Chenchen Wei
1,
Miao Xu
3,
Lei Wang
3,
Wei-Jing Wu
3,
Honglong Ning
3 and
Baohua Jia
4
1
School of Electrical Engineering & Intelligentization, Dongguan University of Technology, Dongguan 523808, China
2
School of Information and Optoelectronic Science and Engineering, South China Normal University, Guangzhou 510631, China
3
State Key Laboratory of Luminescent Materials and Devices, South China University of Technology, Guangzhou 510640, China
4
Centre for Atomaterials and Nanomanufacturing, School of Science, RMIT University, Melbourne, VIC 3000, Australia
*
Authors to whom correspondence should be addressed.
Appl. Syst. Innov. 2025, 8(2), 46; https://doi.org/10.3390/asi8020046
Submission received: 3 February 2025 / Revised: 21 March 2025 / Accepted: 28 March 2025 / Published: 31 March 2025
(This article belongs to the Section Control and Systems Engineering)
Browse Figures
Versions Notes

Abstract

Pixel circuits are key components of flat panel displays, including liquid crystal displays (LCDs), organic light-emitting diode displays (OLEDs), and micro light-emitting diode displays (micro-LEDs). Depending on the active layer material of the thin film transistor (TFT), pixel circuits are categorised into amorphous silicon (a-Si) technology, low-temperature polycrystalline silicon (LTPS) technology, metal oxide (MO) technology, and low-temperature polycrystalline silicon and oxide (LTPO) technology. In this review, we outline the fundamental display principles and four major TFT technologies, covering conventional single-gated TFTs to novel two-gated TFTs. We focus on novel pixel circuits for three glass-based display technologies with additional mention of pixel circuits for silicon-based OLED and silicon-based micro-LED.
Keywords: active matrix display; thin film transistor; pixel circuit active matrix display; thin film transistor; pixel circuit
