Appl. Mech., Volume 5, Issue 4 (December 2024) – 4 articles

Power transformers play a vital role in adjusting voltage levels during transmission. This study focuses on optimizing the structural design of power transformer tanks, particularly high-voltage (HV) tank walls, to enhance their mechanical robustness, performance, and operational reliability. This research investigates various stiffener designs and their impact on stress distribution and deformation through finite element analysis (FEA). Ten different configurations of stiffeners, including thickness, width, type, and position variations, were evaluated to identify the optimal design that minimizes stress and deflection while considering weight constraints. The results indicate that specific configurations, particularly those incorporating 16 mm thick H beams, significantly enhance structural integrity. Experimental validation through pressure testing corroborated the simulation findings, ensuring the practical applicability of the optimized designs. This study’s findings have implications for enhancing the longevity and reliability of power transformers, ultimately contributing to more efficient and resilient power transmission systems. Full article

The paper presents the progressive collapse analysis of structures, focusing on the impact of the initial conditions (particularly initial velocity) and the damage. It proposes a method that calculates the residual axial load capacity and damage of columns based on their strain profile and considers the effects of multiple blast locations. The methodology involves the conventional design of a three-story moment-resisting frame, selecting blast parameters, calculating blast pressures, and performing structural and progressive collapse analyses. The findings reveal that the Alternate Load Path Method (APM) overestimates the capacity compared to a benchmark blast–structure interaction analysis, especially when unsuitable initial conditions and damage properties are used. To address this limitation, the paper concludes the recommendations for incorporating appropriate initial conditions and damage considerations for a relatively accurate progressive collapse analysis. Full article

While zinc die-casting alloy Zamak is widely used in vehicles and machines, its solidified state has yet to be thoroughly investigated experimentally or mathematically modeled. The material behavior is characterized by temperature and rate sensitivity, aging, and long-term influences under external loads. Thus, we model the thermo-mechanical behavior of Zamak in the solid state for a temperature range from −40 °C to 85 °C, and the aging state up to one year. The finite strain thermo-viscoplasticity model is derived from an extensive experimental campaign. This campaign involved tension, compression, and torsion tests at various temperatures and aging states. Furthermore, the thermo-physical properties of temperature- and aging-dependent heat capacity and heat conductivity are considered. One significant challenge is related to the multiplicative decompositions of the deformation gradient, which affects strain and stress measures relative to different intermediate configurations. The entire model is implemented into an implicit finite element program and validation examples at more complex parts are provided so that the predicability for complex parts is available, which has not been possible so far. Validation experiments using digital image correlation confirm the accuracy of the thermo-mechanically consistent constitutive equations for complex geometrical shapes. Moroever, validation measures are introduced and applied for a complex geometrical shape of a zinc die casting specimen. This provides a measure of the deformation state for complex components under real operating conditions. Full article

Many studies focus on brittle–ductile transition stress in intact rocks; however, in real life, we deal with rock mass which contains many discontinuities. To fill this gap, this research focuses on the brittle–ductile transition stress of rock mass by considering the influence of different Geological Strength Index (GSI) values on the brittle–ductile transition stress of rock mass. In other words, the Hoek–Brown failure criteria for rock mass were reformulated mathematically including the ductility parameter (d), which is defined as the ratio of differential stress to minor stress. Then, the results were analyzed and plotted between ${\displaystyle \frac{{\sigma }_3^{*}}{{\sigma }_c}}$ and GSI, considering different (d) and Hoek–Brown material constant (m_i) values. The brittle–ductile transition stress, σ₃^*, was determined by intersecting the Hoek–Brown failure envelope with Mogi’s line, with ductility parameters d ranging from 3.4 (silicate rocks) to 5.0 (carbonate rocks). Numerical solutions were derived for ${\displaystyle \frac{{\sigma }_3^{*}}{{\sigma }_c}}$ as a function of GSI using Matlab, and the results were fitted with an exponential model. The analysis revealed an exponential relationship between ${\displaystyle \frac{{\sigma }_3^{*}}{{\sigma }_c}}$ and GSI for values above 32, with accuracy better than 3%. Increased ductility reduces rock mass strength, with higher d values leading to lower ${\displaystyle \frac{{\sigma }_3^{*}}{{\sigma }_c}}$. The diminishing returns in confinement strength at higher GSI values suggest that rock masses with higher GSI can sustain more confinement but with reduced effectiveness as GSI increases. These findings provide a framework for predicting brittle–ductile transitions in rock engineering. Full article
