Search Results (34)

Spray deposition and coverage within soybean canopies remain critical challenges for achieving effective pesticide applications, particularly under windy conditions. This research investigated the influence of wind speed, boom travel direction relative to wind direction, and nozzle type on droplet deposition, coverage uniformity, canopy penetration, and airflow distributions inside soybean canopies under controlled wind-tunnel airflow. Spray deposition, analyzed using a fluorometric tracer, and coverage, quantified with water-sensitive papers, were assessed in R3-stage soybeans in an 18-m wind tunnel using XR (perpendicular spray) and 3D (38° angle) flat fan nozzles under varying air speeds and boom travel directions in the wind tunnel. Potted plants were placed in the wind tunnel to mimic soybeans grown in field conditions. Droplet sizes of the nozzles were measured using a laser imaging particle sizing system. Airflow velocity and turbulence within the soybean canopy were investigated with a 3-D hot-film anemometer system. The results indicated that wind and boom direction were the main influential factors for spray coverage and deposition. The top canopy position, exposed to the highest air-turbulence intensity, received the greatest deposition, whereas the middle and bottom positions, characterized by lower turbulence, exhibited sharp declines in both deposition and coverage regardless of treatment. The 3D nozzle provided greater coverage and deposition than the XR nozzle only under no-wind conditions; however, under wind conditions, equivalent performance was observed from both nozzles. Therefore, it was essential to incorporate wind conditions and canopy structures into consideration when choosing nozzles to maximize spray penetration and achieve efficient and effective spray applications for soybeans. Full article

Turbulence and wind gusts pose significant risks to the safety and efficiency of UAVs (uncrewed aerial vehicles) in urban environments. In these settings, wind dynamics are strongly influenced by interactions with buildings and terrain, giving rise to small-scale phenomena such as vortex shedding and gusts. These wind speed oscillations generate unsteady forces that can destabilise UAV flight, particularly for small vehicles. Additionally, predicting their formation requires high-resolution Computational Fluid Dynamics (CFD) models, as current weather forecasting tools lack the resolution to capture these phenomena. However, such models require 3D representations of study areas with high geometric consistency and detail, which are not available for most cities. To address this issue, this work introduces an automated methodology for urban CFD mesh generation using open-source data. The proposed method generates error-free meshes compatible with OpenFOAM and includes tools for geometry modification, enhancing solver convergence and enabling adjustments to mesh complexity based on computational resources. Using this approach, CFD simulations are conducted for the city of Ourense, followed by an analysis of their impact on UAV operations and the integration of the system into a trajectory optimisation framework. The CFD model is also validated using experimental anemometer measurements. Full article

The peregrine falcon, known as the fastest bird in the world, has been studied for its ability to stabilize during high-speed dives, a capability attributed to the configuration of its dorsal feathers. These feathers have inspired the design of vortex generators devices that promote controlled turbulence to delay boundary layer separation on aircraft wings and turbine blades. This study presents an experimental wind tunnel investigation of a bio-inspired peregrine falcon prototype, equipped with movable artificial feathers, a hot-wire anemometer, and a 3D accelerometer. Wake velocity profiles measured behind the prototype revealed fluctuations associated with feather motion. Spectral analysis of the velocity signals, recorded with oscillating feathers at a wind tunnel speed of 10 m/s, showed attenuation of specific frequency components, suggesting that feather dynamics may help mitigate wake fluctuations induced by structural vibrations. Three-dimensional acceleration measurements indicated that prototype vibrations remained below 1 g, with peak differences along the X and Z axes ranging from −0.06 g to 0.06 g, demonstrating the sensitivity of the vibration sensing system. Root Mean Square (RMS) values of velocity signals increased with wind tunnel speed but decreased as the feather inclination angle rose. When the mean value was subtracted from the signal, higher RMS variability was observed, reflecting increased flow disturbance from feather movement. Fast Fourier Transform (FFT) analysis revealed that, for fixed feather angles, spectral magnitudes increased uniformly with wind speed. In contrast, dynamic feather oscillation produced distinctive frequency peaks, highlighting the feather’s influence on the wake structure in the frequency domain. To complement the experimental findings, 3D CFD simulations were conducted on two HAWT-type wind turbines—one with bio-inspired vortex generators and one without. The simulations showed a significant reduction in turbulent kinetic energy contours in the wake of the modified turbine, particularly in the Y-Z plane, compared to the baseline configuration. Full article

Originally introduced in the 1960s by DISA Elektronik as a calibration tunnel for hot-wire anemometers, the Type 55D41 has now been reengineered into a versatile and modern aerodynamic test platform. While retaining key legacy components, such as the converging nozzle and the 55D42 power unit, the upgraded system features a redesigned modular test section with optical-grade quartz windows. This enhancement enables compatibility with advanced flow diagnostics and visualization methods, including PTV, DIC, and schlieren imaging. The modernized facility maintains the precision and flow stability that made the original design widely respected, while expanding its functionality to meet the demands of contemporary experimental research. Its architecture supports the aerodynamic characterization of micro-scale static pressure probes used in aerospace, propulsion, and micro gas turbine applications. Special attention is given to assessing the influence of probe tip geometry (e.g., conical, ogive), port positioning, and stem interference on measurement accuracy. Full article

As resources are extracted from the deeper sections of a mine, the ventilation network becomes increasingly complex. Consequently, determining the optimal installation location for speed-measuring equipment that accurately reflects the average wind speed along the roadway remains a challenging task. In this study, two three-dimensional geometric models, smooth and rough, were developed based on field conditions. The cross-sectional widths, heights, and flow velocities of the model channels were processed dimensionlessly. The dimensionless velocity distributions of the smooth and rough models were then analyzed for different Reynolds numbers. It was observed that the dimensionless average velocity ring distributions for the rough model were smaller than those for the smooth model. Additionally, the maximum values of dimensionless flow velocities were negatively correlated with the flow velocities under laminar flow conditions, whereas they largely overlapped under turbulent flow. The dimensionless distances of the average velocity rings from the top and sidewalls of the channel were studied and determined for both models across different flow regimes. Specifically, the dimensionless distance values $d(-)$ were found to be 0.111 for the smooth model and 0.101 for the rough model under the laminar regime. Under the turbulence regime, the corresponding values were 0.106 and 0.108. Likewise, the values of $h(-)$ were 0.135 and 0.135 for the smooth and rough models in the laminar flow regime, while under turbulent flow, the values were 0.131 and 0.162, respectively. The largest dimensionless velocity value was identified at the center of the velocity distribution circle. For corners that did not maintain simple parallelism with the walls, these regions were incorporated into the circle equation using the Least Squares Method, providing a theoretical basis for the placement of velocity-measuring equipment in practical applications. By using the sidewall as the reference coordinate, an appropriate mathematical model was employed to establish the functional relationship between the centerline velocity of the roadway and the dimensionless horizontal coordinate. The fitting results showed good agreement, and this model can be used to back-calculate and expand the potential installation locations for a mine anemometer. Full article

The turbulent energy dissipation rate (EDR) is a quantitative measure of turbulence intensity, and it is widely used across various fields. Accurate estimation of EDR using Doppler lidar depends on the choice of estimation technique and scanning strategy. Therefore, a comparison of the techniques is still required to achieve an accurate estimation. However, the effect of the choice on estimation accuracy remains uncertain. This study systematically evaluates the accuracy of EDR estimation techniques by utilizing two distinct scanning strategies: a vertically pointing scan ($\mathrm{E}\mathrm{D}{\mathrm{R}}_{\mathrm{V}\mathrm{P}}$) and a Plan Position Indicator scan ($\mathrm{E}\mathrm{D}{\mathrm{R}}_{\mathrm{V}\mathrm{A}\mathrm{D}}$). We assess four different $\mathrm{E}\mathrm{D}{\mathrm{R}}_{\mathrm{V}\mathrm{P}}$ estimation techniques and assess the accuracy of $\mathrm{E}\mathrm{D}{\mathrm{R}}_{\mathrm{V}\mathrm{A}\mathrm{D}}$ for each elevation angle by comparing it with the measurements from sonic anemometers on a 300 m tall meteorological tower. $\mathrm{E}\mathrm{D}{\mathrm{R}}_{\mathrm{V}\mathrm{A}\mathrm{D}}$ shows a positive correlation coefficient exceeding 0.5 with the sonic anemometers. $\mathrm{E}\mathrm{D}{\mathrm{R}}_{\mathrm{V}\mathrm{A}\mathrm{D}}$ demonstrates dependency on the elevation angle, with lower angles resulting in higher EDR values. Conversely, all of the $\mathrm{E}\mathrm{D}{\mathrm{R}}_{\mathrm{V}\mathrm{P}}$ techniques exhibit high agreement, with correlation coefficients above 0.9. This study provides a comprehensive assessment of the accuracy of each technique, highlighting their respective characteristics and practical considerations. Full article

Drosophila suzukii is an invasive pest that poses a significant threat to fruit crops worldwide, leading to considerable agricultural losses and economic damage. Unlike chemical control measures against D. suzukii, integrating insect-proof nets within an IPM framework offers a more sustainable solution. This study evaluates the efficacy of nine commercial protective nets against this pest, focusing on determining optimal hole dimensions based on the effects of airflow velocity, temperature, and pest morphometry on net performance. To simulate field conditions in the laboratory, we developed a tubular device divided into three chambers with the tested net placed between the two, incorporating a fan to generate airflow and a thermo-anemometer. Our results confirm that higher air velocities and elevated temperatures reduce net efficacy. Additionally, morphometric analyses of lab-reared flies revealed significant sexual dimorphism and a strong temperature–size relationship, with flies reared at lower temperatures being consistently larger, an aspect that also affects net effectiveness. These findings highlight the importance of considering both abiotic factors and pest morphology when evaluating protective screens, challenging the assumption that exclusion net efficacy remains constant. Some tested nets proved completely effective against SWD, supporting their use as a preventive measure in IPM programs. Full article

The availability of multi-rotor UAVs with lifting capacities of several kilograms allows for a new paradigm in atmospheric measurement techniques, i.e., the integration of research-grade sonic anemometers for airborne turbulence measurements. With their ability to hover and move very slowly, this approach yields unrevealed flexibility compared to mast-based sonic anemometers for a wide range of boundary layer investigations that require an accurate characterization of the turbulent flow. For an optimized sensor placement, potential disturbances by the propeller-induced flow (PIF) must be considered. The PIF characterization can be done by CFD simulations, which, however, require validation. For this purpose, we conducted an experiment to map the PIF below a multi-rotor drone using a mobile array of five sonic anemometers. To achieve measurements in a controlled environment, the drone was mounted inside a hall at a 90° angle to its usual flying orientation, thus leading to the development of a horizontal downwash, which is not subject to a pronounced ground effect. The resulting dataset maps the PIF parallel to the rotor plane from two rotor diameters, beneath, to 10 D, and perpendicular to the rotor plane from the center line of the downwash to a distance of 3 D. This measurement strategy resulted in a detailed three-dimensional picture of the downwash below the drone in high spatial resolution. The experimental results show that the PIF quickly decreases with increasing distance from the centerline of the downwash in the direction perpendicular to the rotor plane. At a distance of 1 D from the centerline, the PIF reduced to less than 4 ms⁻¹ within the first 5 D beneath the drone, and no conclusive disturbance was measured at 2 D out from the centerline. A PIF greater than 4 ms⁻¹ was still observed along the center of the downwash at a distance of 10 D for both throttle settings tested (35% and 45%). Within the first 4 D under the rotor plane, flow convergence towards the center of the downwash was measured before changing to diverging, causing the downwash to expand. This coincides with the transition from the four individual downwash cores into a single one. The turbulent velocity fluctuations within the downwash were found to be largest towards the edges, where the shear between the PIF and the stagnant surrounding air is the largest. Full article

We demonstrated a new optical fiber modal interferometer (MI) for airflow sensing; the novelty of the proposed structure is that an MI is fabricated based on a piece of HAF, which makes the sensitive MI itself also a hotwire. The interferometer is made by applying arc-discharge tapering and then flame tapering on a 10 mm length high attenuation fiber (HAF, 2 dB/cm) with both ends spliced to a normal single mode fiber. When the diameter of the fiber in the processing region is reduced to about 2 μm, the near-infrared dispersion turning point (DTP) can be observed in the interferometer’s transmission spectrum. Due to the absorption of the HAF, the interferometer will have a large temperature increase under the action of a pump laser. At the same time, the spectrum of the interferometer with a DTP is very sensitive to the change in ambient temperature. Since airflow will significantly affect the temperature around the fiber, this thermosensitive interferometer with an integrated heat source is suitable for airflow sensing. Such an airflow sensor sample with a 31.2 mm length was made and pumped by a 980 nm laser with power up to 200 mW. In the comparative experiment with an electrical anemometer, this sensor exhibits a very high air-flow sensitivity of −2.69 nm/(m/s) at a flowrate of about 1.0 m/s. The sensitivity can be further improved by enlarging the waist length, increasing the pump power, etc. The optical anemometer with an extremely high sensitivity and a compact size has the potential to measure a low flowrate in constrained microfluidic channels. Full article

This study presents a computational fluid dynamics (CFD) based approach to determine the optimal positioning for an atmospheric turbulence sensor on a rotary-wing uncrewed aerial vehicle (UAV) with X8 configuration. The vertical ($z_{BF}$) and horizontal ($x_{BF}$) distances of the sensor to the UAV center to reduce the effect of the propeller-induced flow are investigated by CFD simulations based on the $k-ϵ$ turbulence model and the actuator disc theory. To ensure a realistic geometric design of the simulations, the tilt angles of a test UAV in flight were measured by flying the drone along a fixed pattern at different constant ground speeds. Based on those measurement results, a corresponding geometry domain was generated for the CFD simulations. Specific emphasis was given to the mesh construction followed by a sensitivity study on the mesh resolution to find a compromise between acceptable simulation accuracy and available computational resources. The final CFD simulations (twelve in total) were performed for four inflow conditions (2.5 m s⁻¹, 5 m s⁻¹, 7.5 m s⁻¹ and 10 m s⁻¹) and three payload configurations (15 kg, 20 kg and 25 kg) of the UAV. The results depend on the inflows and show that the most efficient way to reduce the influence of the propeller-induced flow is mounting the sensor upwind, pointing along the incoming flow direction at $x_{BF}$ varying between 0.46 and 1.66 D, and under the mean plane of the rotors at $z_{BF}$ between 0.01 and 0.7 D. Finally, results are then applied to the possible real-case scenario of a Foxtech D130 carrying a CSAT3B ultrasonic anemometer, that aims to sample wind with mean flows higher than 5 m s⁻¹. The authors propose $x_{BF}=1.7 \mathrm{m}$ and $z_{BF}=20 \mathrm{c}\mathrm{m}$ below the mean rotor plane as a feasible compromise between propeller-induced flow reduction and safety. These results will be used to improve the design of a novel drone-based atmospheric turbulence measurement system, which aims to combine accurate wind and turbulence measurements by a research-grade ultrasonic anemometer with the high mobility and flexibility of UAVs as sensor carriers. Full article

Vortex generators are devices that modify the wind behavior near the surface of wind turbine blades. Their use allows the boundary layer shedding transition zone to be varied. Bio-inspired design has been used to improve the efficiency of aerodynamic and hydrodynamic systems by creating devices that use shapes present in animals and plants. In this work, an experimental methodology is proposed to study the effect of bio-inspired vortex generators and their effect on the structural vibration of a blade. In addition, the wind wake generated by the blade with oscillating vortex generators at different oscillation frequencies is analyzed by means of a hot wire anemometer, obtaining appreciable vibration reduction results in the measured 3D acceleration signals for wind velocities between 10 and 15 m/s. Values of the spectral components of the wake velocity measured at higher tunnel wind velocities increase. Spectral variance is reduced at higher tunnel wind velocities. The system analyzed in this paper can contribute in the future to the construction of actuators for vibration compensation systems in wind turbines. Full article

We revisit two recent methodologies based on Monin–Obukhov Similarity Theory (MOST), the 2D method and Hybrid-Wind (HW), which are aimed at estimation of the Obukhov length, friction velocity and kinematic heat flux within the surface layer. Both methods use wind-speed profile measurements only and their comparative performance requires assessment. Synthetic and observational data are used for their quantitative assessment. We also present a procedure to generate synthetic noise-corrupted wind profiles based on estimation of the probability density functions for MOST-related variables (e.g., friction velocity) and the statistics of the noise-corrupting perturbational amplitude found during an 82-day IJmuiden observational campaign. In the observational part of the study, 2D and HW parameter retrievals from floating Doppler wind lidar measurements are compared against those from a reference mast. Overall, the 2D algorithm outperformed the HW in the estimation of all the three parameters above. For instance, when assessing the friction-velocity retrieval performance with reference to sonic anemometers, determination coefficients of ${\rho }_{2D}^2=0.77$ and ${\rho }_{HW}^2=0.33$ were found under unstable atmospheric stability conditions, and ${\rho }_{2D}^2=0.81$ and ${\rho }_{HW}^2=0.07$ under stable conditions, which suggests the 2D algorithm as a prominent method for estimating the above-mentioned surface-layer parameters. Full article

Wind measurement in confined spaces is a challenge due to the influence of the dimensions of anemometers in intrusive flow-field measurements where the anemometer probes directly contact and influence the near-probe flow field. In this work, a new wind speed detection methodology is proposed based on wind-induced motion of a stick via vision-based recognition. The target’s displacement in pixel coordinates is mapped to its angular displacement in world coordinates to derive wind speed and direction information by applying the calibration coefficients. Simulation experiments were carried out to validate the model, the error of which was within an angular displacement of 4.0° and 3.0° for wind speed and direction detections, respectively. When applied to the measurement of wind speed in the inner equipment cabin of a stationary high-speed train, the error was within ±1.1 m/s in terms of average RMSE. Thus, the proposed method provides an accurate and economic option for monitoring 2D wind in a confined space. Full article

Strawberry is a widely cultivated cash crop in China. In order to control pests and diseases on strawberries, there must be sufficient deposits on the abaxial surfaces of the leaves. Air-assisted technology can effectively increase the deposition on the abaxial surfaces of the leaves; however, most air-assisted equipment is not suitable for application due to the pattern of strawberry planting. Therefore, a novel air-assisted strawberry sprayer was developed, the static and dynamic wind fields were measured using a 3D anemometer, and the effectiveness of the application at different spray angles and wind speeds was evaluated. In addition, a comparison of the deposition effect in the strawberry canopy between the air-assisted strawberry sprayer, knapsack sprayer, and spray gun was conducted. The results showed that in the static wind field test, a difference between the center and edge wind fields was obtained, which was correlated with the distance and the outlet wind speed. In the dynamic wind field test, the wind field was found to be rolling backward during the movement, and an inward vortex was obtained. In the field, the data showed that a spray angle of 30° and a wind speed of 16 m·s⁻¹ had the best deposition on the abaxial surface, with a coverage of 36.5% and 38.3% in the upper canopy and 6.2% and 7.9% in the lower canopy, respectively. Moreover, the air-assisted strawberry sprayer was found to have a higher deposition efficiency on abaxial surfaces than the knapsack sprayer and spray gun at a lower spray volume, the values of which in the upper and lower canopies were 42.8% and 29.7%, respectively. In conclusion, the air-assisted strawberry sprayer has the potential for the crop protection of greenhouse strawberries, and more evaluations are needed to improve the sprayer in the future. Full article

Flow visualization is necessary in fields such as engineering, since it allows us to know what is happening around the element being studied by means of a preliminary method, although it is relatively close to future research and computation methodology. The present project studies the interference at the anemometers of the Mars rover Perseverance, caused by the mast holding one of its cameras. After obtaining the model, manufactured by a 3D printer, it was placed inside a hydrodynamic towing tank, and red dye was added for a visual observation of the interference during the experiment. A comparison was made between the results achieved and those seen in a wind tunnel, realizing the high correlation they have. Finally, this paper promotes the use of the hydrodynamic towing tank in preliminary studies due to its low costs, considering the adequate comparison with other higher precision methodologies. Full article
